ELCOS RA-0511 User manual

1
ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN
WATER HEATERS
Suitable for heating water in diesel engines with closed
circuit cooling
- OPTIMUM DIELECTRIC STRENGTH.
- EASY CONNECTION VIA CABLE.
- TEMPERATURE MAINTAINED BY AN
INTERNAL THERMOSTAT.
A SECOND INTERNAL THERMOSTAT
PROTECTS THE APPLIANCE FROM ANY
OVERHEATING.
- CAN BE MOUNTED DIRECTLY ONTO THE
ENGINE.
Coolant drainage
plug
The heater prevents the cooling circuit temperature from falling below a certain value.
This value is regulated by an internal thermostat. A second internal thermostat protects the applian-
ce from any overheating.
INSTRUCTION AND USE MANUAL
(Connectors not provi-
ded)
Type
RA-0500 (500 W)
RA-1000 (1000 W)
RA-1500 (1500 W)
Type
RA-0501 (500 W)
RA-1001 (1000 W)
RA-1501 (1500 W)
RA-2501 (2500 W)
Version with GAS ½” thread
Version with GAS ½” thread
Version with hose connector-
for hose with 16 internal Ø
Type
RA-0511 (500 W)
RA-1011 (1000 W)
(Connectors not provided)
The key features of our water
heaters:
> Direct assembly, without
the use of brackets.
> Presence of a coolant
drainage plug.
> Factory fitted 3-metre
power feed cable.
> Special electro-coating
applied to body that
protects from glycol
corrosion

2ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN
DIMENSIONS
RA-0511
RA-1011
Type RA-0511
RA-1011

3
ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN
RA-0500
RA-1000
RA-1500
Type
RA-0501
RA-1001
RA-1501
RA-2501
Type
RA-0500
RA-1000
RA-1500
RA-0501
RA-1001
RA-1501
RA-2501

4ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN
BEFORE INSTALLING THE HEATER, CLEAN THE COOLING CIRCUIT
TO AVOID SIPHONS BEING PRODUCED; THERE SHOULD BE NO CURVES IN THE FLEXIBLE TUBES.
AIR
MOUNTING DIRECTION
INSTALLATION
A
B
CIRCULATION
PROBLEMS
POINT BMUST BE BELOW
POINT A
COULD WATER SOCKET
SHOULD BE AS LOW
AS POSSIBLE
HOT WATER INTAKE
AS HIGH AS POSSIBLE
A
B
A

5
ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN
Use the same type of coolant to top up the cooling system.
DO NOT USE HARD WATER.
HOT WATER OUT
The installer has to mount the mains power supply circuit overcurrent protection:
- fuses 10A (16A version 2500W)- 250V or
- automatic switch 10 A - 250V (16A version 2500W).
COLD
WATER
INLET
Coolant drainage plug
CONNECTIONS
POWER SUPPLY 230 VAC
LENGTH OF CABLE 3 m Yellow-green
ENGINE COOLANT
CONNECTIONS

6ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN
Used to pre-heat the water cooled Diesel engine, heating the cooling liquid.
Designed to be installed also on board the machine.
Warning:
adhere closely to the following advice
- Take great care to connect correctly the conductors coming out of the equipment.
- Adhere closely to the installation indications on page 4-5.
- Never supply the equipment unless it has liquid inside.
- During operation the device is at high temperature (~ 70°C).
- During operation, if it is necessary to open the radiator plug, protect with Individual Safety
Devices from any boiling water sprays.
- Do not use calcareous water as cooling liquid.
- Perform discharge actions only when device is cold and unsupplied.
THIS HEATER IS NOT SUITABLE FOR OPERATING IN THE FOLLOWING CONDITIONS:
- where the environmental temperature is outside the limits indicated in the technical sheet on page 7.
- where there are high levels of pollution caused by dust, smoke, vapour, salts and corrosive or radioactive
particles.
- where attacks from mould or small animals are possible.
- where there is the risk of re or explosions.
- where the panel can receive strong vibrations or knocks.
ELECTROMAGNETIC COMPATIBILITY
This equipment functions correctly only if inserted in plants which conform with the CE marking standards;
it meets the exemption requirements of the standard EN61326-1 but it cannot be excluded that malfun-
ctions could occur in extreme cases due to particular situations.
The installer has the task of checking that the disturbance levels are within the requirements of the stan-
dards.
CONDUCTION AND MAINTENANCE
The following maintenance operations should be performed every week:
- check the condition of the hydraulic connection tubes, sleeves and joints.
- check that the terminals to which the equipment is connected are tight.
- check the condition of the supply cable sheath. If the mains power supply cable is
damaged, it has to be replaced by the manufacturer.
Every year the plant should be descaled and the operating thermostat should be checked.
UNLESS WE MAKE A WRITTEN DECLARATION STATING THE CONTRARY, THIS HEATER
IS NOT SUITABLE FOR USE AS A CRITICAL COMPONENT IN EQUIPMENT OR PLANTS
RESPONSIBLE FOR KEEPING PERSONS OR OTHER LIVING BEINGS ALIVE.
Any use which differs from that which is indicated in this instruction and user manual must be authorized
by the manufacturer.
YOUR ELECTRICAL TECHNICIAN CAN ASK US ANYTHING ABOUT THIS HEATER
BY TELEPHONING ONE OF OUR TECHNICIANS
NOTICES
RA-0511
RA-0500
RA-1000
RA-1500
RA-1011
RA-0501
RA-1001
RA-1501
RA-2501
TYPE RA-0511
RA-0500
RA-1000
RA-1500
RA-1011
RA-0501
RA-1001
RA-1501
RA-2501

7
ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN
MAINS POWER SUPPLY 230VAC (± 10%) 50÷60 Hz
DIELECTRIC STRENGTH BETWEEN TERMINALS AND
APPLIANCE
1250V x 1 MINUTE
POWER ABSORBED:
TYPE RA-0511 RA-0500 RA-0501 500 W
RA-1011 RA-1000 RA-1001 1000 W
RA-1500 RA-1501 1500 W
RA-2501 2500 W
SERVICE CONTINOUS
OPERATIONAL THERMOSTAT NON ADJUSTABLE
DISENGAGED HEATING a 53° C ± 5%
ENGAGED HEATING a 33° C ± 5%
SAFETY THERMOSTAT TRIPPING TEMPERATURE 96°C ± 5%
CONNECTION CABLES FROR 450 / 750 V
DEGREE OF PROTECTION IP54
TEMPERATURE LIMITS
(ONLY IF SUPPLIED)
-20° C ÷ 120 °C
WEIGHT:
TYPE RA-0511 RA-1011 1100 gr
RA-500 RA-501 RA-1000
RA-1001 RA-1500 RA-1501
1270 gr
RA-2501 1800 gr
TECHNICAL DATA

8ELCOS SRL - Parma - RA-0511 1011 RA-0500 1000 1500 RA-0501 1001 1501 2501- EN
HEATER
Type Code
RA-0511 00706162
RA-1011 00706164
RA-0500 00706161
RA-1000 00706163
RA-1500 00706165
RA-0501 00706168
RA-1001 00706169
RA-1501 00706170
RA-2501 00706173
ORDERING INFORMATION
