Electrolux EMS20100OX User manual

EMS20100OX
Mikrovlnná trouba
Mikrovlnná rúra
CS
SK
návod k použití
návod na používanie
..................................... ..........................................
Microwave Oven
Mikroaaltouuni
EN
F I
user manual
käyttöohje
Mikrobølgeovn
NO
bruksanvisning
manual de instrucciones
Horno de microondas
ES
Mikrovågsugn
SV
bruksanvisning

Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com
Contents
Safety information 2
Product description 5
Operation 5
Helpful hints and tips 8
Care and cleaning 9
Technical data 10
Environment concerns 10
Installation 10
European Guarantee 11
Subject to change without notice
Safety information
General safety
READ CAREFULLY AND KEEP FOR FU-
TURE REFERENCE
• The built-in safety interlock switches pre-
vent the microwave oven from operating
when the door is open.
• Do not tamper with them, or attempt to
operate the oven with the door open as
open door operation can result in expo-
sure to microwave energy.
• Do not allow food spills or cleaner residue
to accumulate on door sealing surfaces.
See the Cleaning and Care section for
cleaning instructions.
• It is particularly important that the oven
door closes properly and that there is no
damage to the: (1) door (warped), (2) hing-
es and latches (broken or insecure), (3)
door seals and sealing surface.
Warning! If the door, hinges/latches or
door seals are damaged, the microwave
must not be operated until it has been
repaired by a authorized service person.
Warning! It is hazardous for anyone
except factory trained service personnel
to service or make adjustments to this
oven. Contact your nearest authorised
service agent if service should be
required.
• Do not remove the outer case, door or
control panel at any time. Doing so may
cause exposure to extremely high voltage.
• Install or locate this oven only in accord-
ance with 'installation instructions' found in
this manual.
• Use the appliance for its intended use as
described in this manual. Do not use cor-
rosive chemicals in this appliance. This
type of oven is specifically designed to
heat, cook, or defrost food. It is not de-
signed for industrial or laboratory use nei-
ther for commercial use as this will invalid-
ate the guarantee.
• Do not operate the oven empty. If food or
water is not present to absorb the micro-
wave energy, the magnetron tube can be
damaged.
• Do not store this appliance outdoors. Do
not use this product near water.
• Do not attempt to dry clothing or newspa-
pers in the microwave oven. These items
can ignite.
• Do not use the cavity for storage purposes.
Do not leave paper products, cooking
utensils, or food in the cavity when not in
use.
• The temperature of accessible surfaces
may be high when the appliance is oper-
ating.
Warning! If smoke is observed, switch
off or unplug the appliance and keep the
door closed in order to stifle any flames.
Never use water.
Warning! The appliance is not intended
for use by children or persons with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction.
• Do not force the turntable to rotate by
hand. This may cause malfunctioning.
2electrolux

• The appliance is not intended to be oper-
ated by means of an external timer or sep-
arate remote-control system.
• Care should be taken not to obstruct any
air vents located on the top, rear, side and
bottom of the oven.
Warning! Do not use this oven for
commercial purposes. This oven is
made for domestic use only.
Utensil safety
Only use utensils that are suitable for use in
a microwave oven.
Arcing in the oven during microwave opera-
tion usually occurs from use of metallic uten-
sils. Continuous arcing, however, can dam-
age the unit. Stop the programme and check
the utensil.
Most glass, glass ceramic and heat-resistant
glassware utensils are excellent for use in the
microwave oven. Although microwave ener-
gy will not heat most glass and ceramic
items, these utensils can become hot as heat
transfers from the food to the container. The
use of oven gloves to remove dishes is rec-
ommended.
Food safety
• Do not heat food in a can in the microwave
oven. Always remove the food to a suitable
container.
• Deep fat frying should not be done in the
microwave oven, because the fat temper-
ature cannot be controlled, hazardous sit-
uations can result.
• Popcorn may be prepared in the micro-
wave oven, but only in special packages or
utensils designed specifically for this pur-
pose. This cooking operation should never
be unattended.
• Pierce foods with nonporous skins or
membranes to prevent steam buildup and
bursting. Apples, potatoes, chicken livers,
and egg yolks are examples of items that
should be pierced.
• The contents of feeding bottles and baby
food jars are to be stirred or shaken and
the temperature is to be checked before
consumption, in order to avoid burns.
Warning! Liquids or other foods must
not be heated in sealed containers since
they are liable to explode.
Warning! Microwave heating of
beverages can result in delayed eruptive
boiling, therefore care must be taken
when handling the container.
Warning! When heating liquids, e.g.
soups, sauces and beverages in your
microwave oven, overheating the liquid
beyond boiling point can occur without
evidence of bubbling. This could result in
a sudden boil over of the hot liquid. To
prevent this possibility the following
steps should be taken:
1. Avoid using straight-sided contain-
ers with narrow necks.
2. Do not overheat.
3. Stir the liquid before placing the con-
tainer in the oven and again halfway
through the heating time.
4. After heating, allow to stand in the
oven for a short time, stirring again
before carefully removing the con-
tainer.
Warning! Some products such as
whole eggs and sealed containers - for
example, closed glass jars - may
explode and should not be heated in this
oven. Occasionally, poached eggs may
explode during cooking. Always pierce
the yolk, then cover and allow the
standing time of one minute before
removing cover.
It is quite normal for steam to be emitted
around the door, or for misting to occur
on the door, or even for water droplets
to appear below the door during the
cooking cycle. This is merely condensa-
tion from the heat of the food and does
not affect the safety of your oven. The
door is not intended to seal the oven
cavity completely.
Oven utensils and accessories guide
A variety of Utensils and Materials maybe
used for cooking in your microwave oven.
For your safety and to prevent damaging
utensils and your oven choose appropriate
utensils and materials for each cooking
method.
The list below is a general guide.
•: Utensils and accessories to use
•: Utensils and accessories to avoid
electrolux 3

Material Utensils Microwave
Ceramic & Glass Corning ware
1)
Heat resistant glass ware
Glass ware with metal decora-
tion
Lead crystal glass
China Without metal decoration
Pottery
2)
Plastic Microwave oven heat proof
wear
Plastic wrap
Metal Baking pan
Aluminium foil
3)
Paper Cups, plates, towels
Waxed paper
Wood
1) Only if there is no metal trim.
2) Only if it does not have a glaze containing metal.
3) Use aluminium foil only for shielding purposes, over use may cause arcing.
4electrolux

Product description
1
2
3
4
5
6
7
8
9
1. Display window
–- Microwave function indicator
–- Auto cook function indicator
–- Clock indicator
–- Microwave above 50% indicator
–- Microwave below 50% indicator
–- Defrost function indicator
–- Weight indicator (grammes)
–- Quantity indicator (mililitres)
–- Lock indicator
2. Defrost by weight
3. Clock
4. Defrost by time
5. Auto cook
6. Start
7. Microwave
8. Stop
9. Rotary encoder
Operation
To set the ‘time of day’ clock:
At initial switch on the oven display will
show ’0:00’ and you will hear a ‘beep’.
The clock adopts the 24 hour clock con-
figuration
1. Press push button. The hour numbers
will flash together with the symbol.
2. Rotate to select the hours.
3. Press push button. The minute num-
bers will flash:
4. Rotate to select the minutes.
electrolux 5

5. Press push button to complete ‘the
time of day’ setting. The ‘:’ will flash in the
display and the symbol will disappear.
The ‘time of day’ must be set to allow the
oven to function.
During the process of setting ‘time of
day’, by pressing at any time, the oven
will go back to the previous state.
Cooking with Microwave.
1. Press push button once and ‘P100’
will appear in the display and sym-
bols will illuminate. 100 indicate 100% i.e.
max. power setting of 800 watts.
2. Rotate to change the microwave pow-
er in steps from 100%, to 10% in the fol-
lowing sequence; ‘P100’, ‘P80’, ‘P50’,
‘P30’, and ‘P10’
symbol illuminates when 50% or less
power is selected
3. Press to confirm your power selection.
4. Rotate to select the required cook time
between 0.05 to 95.00 Note;
– Selected time between 0.05 and 1 mi-
nute are in increments of 5 seconds
– Selected time between 1 and 5 mi-
nutes are in increments of 10 seconds
– Selected time between 5 and 10 mi-
nutes are in increments of 30 seconds
– Selected time between 10 and 30 mi-
nutes are in increments of 1 minute
– Selected time between 30 and 95 mi-
nutes are in increments of 5 minutes
5. Press to start cooking. The display will
show the cooking time left and the and
or symbol will flash (depending on
power level selected).
Microwave Power Chart:
Power Percentage Display & Micro-
wave Power
100% P100 = 800W
80% P80 = 640W
50% P50 = 400W
30% P30 = 240W
10% P10 = 80W
The ‘plus 60 seconds’ function
1. Pressing the when the oven is in
‘stand by’ mode i.e. when not is use and
‘time of day’ is displayed, will automati-
cally start microwave cooking / reheating
at 100% full power of 800 watts (P100)
for 60 seconds. The symbol will flash
in the display.
Any additional operation of this push but-
ton will add ’60 seconds’ to the existing
cook time. The maximum cook time
which can be entered is 95 minutes.
Auto defrosting by weight
1. Press once and ‘dEF 1’ will appear in
the display and the symbols will illu-
minate.
2. Rotate to select the frozen weight in
grams of the food you are defrosting. (be-
tween 100g and 2000g)
3. Press to begin the automatic defrost-
ing function. The oven will calculate the
defrosting time and power level required
to defrost the food perfectly. The defrost-
ing time left will be shown in the display
and the symbols will flash.
Defrosting by time.
1. Press and ‘dEF 2’ will appear in the
display and the symbols will illumi-
nate.
2. Rotate to select the defrosting time –
max 95 minutes.
3. Press to begin the manual defrosting
function. The defrosting time left will be
shown in the display and the sym-
bols will flash.
Multi- stage cooking
The oven can be set to defrost / cook in three
stages.
If using a defrost function this should always
be the first stage.
A ‘beep’ will sound after the first stage is
complete and the second stage will begin
automatically.
6electrolux

Auto menus cannot be used as either
stage. For example: To defrost food
manually for 5 minutes and then cook for
7 minutes at 640 watts (P80),
1. Press and ‘dEF 2’ will appear in the
display and symbols will illuminate.
2. Rotate to select the defrosting time of
5 minutes.
3. Press push button once and ‘P100’
will appear in the display and the
symbols will illuminate. 100 indicates 800
watt (100%) i.e. max. power setting.
4. Rotate to select 640 watts (P80).
5. Press to confirm your power selection.
6. Rotate to select the cook time of 7 mi-
nutes.
7. Press to start the two stage pro-
gramme. The and symbols for stage
1 will flash and then after a ‘beep’, the
and symbols will flash to indicate
stage 2 has begun.
Delayed Start.
The oven can be set to start cooking at a pre-
determined time and up to three stages of
cooking can be used. Do not use defrosting
as either stage.
1. Press push button once and ‘P100’
will appear in the display. And sym-
bols will illuminate. 100 indicates 100%
i.e. max. power setting.
2. Rotate to select the power level.
3. Press to confirm your power selection.
4. Rotate to select the required cook time
between 0.05 to 95.00
5. Press . The hour figures will flash and
the symbol will illuminate.
6. Rotate to select the hour at which you
want the oven to begin cooking.
7. Press . The minute figures will flash.
Press . The minute figures will flash.
8. Rotate to select the minute at which
you want the oven to begin cooking.
9. Press to complete the setting. The
time of day will appear in the display, to-
gether with the symbol which will flash.
and remain until the start time is reached
when the oven will ‘beep’ twice and the
cooking process will begin automatically.
At the end of the cooking cycle the oven
will ‘beep’ 5 times. Note: The ‘time of
day’ must be set for this function to op-
erate.
Child Lock.
The oven can be rendered inoperable should
you wish to prevent unauthorised use i.e ex-
cluding children from using the appliance In
the ‘stand by’ mode,
press and hold for 3 seconds. You will hear
a long ‘beep’ which denotes that the child
lock has been engaged and the symbol will
illuminate in the display.
To exit the ‘child lock’ mode, press and hold
for 3 seconds. You will hear a long ‘beep’
which denotes that the child lock has been
disengaged and the symbol switch off in
the display.
Automatic cooking by food category.
1. With the oven in stand-by mode press
to select auto menu ‘A-1’.
2. Rotate clockwise to select A-2 to‘A-8’.
The will illuminate. Note: refer to ta-
ble below for food categories
3. Press to confirm your selection.
4. Rotate to select the food weight in
grams. The or will illuminate.
5. Press to begin cooking.
On completion of the cooking process a
‘beep’ will sound five times and the oven
will switch off.
Automatic Cooking Chart
Menu Weight / Portion
A-1 - Auto Reheat 200g, 400g, 600g
A-2 - Vegetables 200g, 300g, 400g
A-3 - Fish 250g, 350g, 450g
A-4 - Meat 250g, 350g, 450g
A-5 - Pasta 50g (with 450g of water), 100g (with 800g of water)
electrolux 7

Menu Weight / Portion
A-6 - Potato 200g, 400g, 600g
A-7 - Pizza 200g, 400g
A-8 - Soup 200g, 400g
Retrieval of information when in use.
1. Press during cooking and the display
will show the power selected for 3 sec-
onds.
2. In ‘delayed start’ mode press and the
cook start time will be displayed for 3
seconds, after which the time of day will
be displayed once more.
3. During cooking press to check the cur-
rent ‘time of day’ which will be displayed
for 3 seconds.
General information and user
guidelines.
1. Each time a push button is pressed a
‘beep’ will sound to confirm this action.
Each time a push button is pressed a
‘beep’ will sound to confirm this action.
2. The initial rotation of the control knob will
be accompanied by a ‘beep’.
3. After any cooking programme has been
set, failure to initiate cooking by pressing
within 1 minute will result in cancella-
tion, and the ‘time of day’ will be dis-
played.
4. At the end of every cooking cycle, the
oven will ‘beep’ five times.
5. Opening the door during the cooking cy-
cle will stop the oven operation. must
be pressed to resume cooking if the door
has been opened during the cooking cy-
cle.
Helpful hints and tips
Microwave hints
• Always keep the oven clean - avoid spill-
overs and do not forget to clean under the
glass tray and the inside of the door.
• Preferably use round or oval casseroles
with a lid when cooking in your microwave
oven.
• Do not use metal or metal decorated cas-
seroles. Certain plastic materials can melt
and be warped by hot food.
• Cover the food when cooking. Use a glass
lid, a plate or grease proof paper.
• Pastry, bread and the like can be defrosted
directly in a bread basket or on a paper
towel.
• If frozen food is heated in its packaging,
the packaging should be opened. Pack-
aging containing metal or metal decoration
must not be used unless specifically rec-
ommended for use in the microwave. Re-
move metal clips and wire ties.
• Smaller pieces of aluminium foil can be
used to cover parts that easily over cook
such as chicken legs.
• Food with peel or skin should be pierced
with a fork - e.g. potatoes and sausages.
Do not boil eggs in the microwave oven as
they can explode.
• Put large, thick pieces close to the edge of
the casserole and try to cut the food in to
even sized pieces. Always place the food
in the centre of the oven.
• The food will be evenly cooked if you stir
or turn it a few times.
• Always set a shorter cooking time than in-
dicated in your recipe to avoid over cook-
ing. The larger the amount of food the lon-
ger it takes.
• Use little or no water for vegetables.
• Use less salt and spices than for 'normal'
cooking.
• Season afterwards.
• Allow a few minutes 'standing' time after
the oven has switched off to ensure com-
plete and even cooking results.
• Always ensure food is piping hot through-
out before serving.
• Use pot holders or gloves when taking
dishes and food from the oven.
Microwave tips
•Softening Honey
If you have a jar of honey which has crys-
tallised, remove lid and place the jar in the
oven, microwave on medium power for 2
minutes.
8electrolux

•Melting Chocolate
Break 100g of chocolate into squares,
place in a bowl and heat on high power for
1-2 minutes and stir well.
•Softening or Melting Butter
Melting takes a few seconds on high pow-
er. Softening is best done more gently on
low power.
•Freshen or Warm Bread
Use medium power for few seconds.
•Peeling Garlic easily
Heat 3 or 4 cloves of garlic on high power
for 15 seconds. Squeeze at one end until
the clove pops out.
•Fruit Juice
Citrus fruits will yield more juice if they are
heated on high power for 15 seconds be-
fore squeezing.
•Cooking Porridge
Porridge is easily cooked in the serving
dish with no sticky pan to wash. Follow
food manufacturers' recommendations.
Care and cleaning
Cleaning is the only maintenance normally
required.
Warning! Your microwave oven should
be cleaned regularly, removing all food
remains. If the microwave is not kept
clean its surfaces may deteriorate,
reducing the oven’s working life and
possibly resulting in a dangerous
situation.
Warning! Cleaning should be done with
the oven power switched off. Take the
plug out of the socket or switch off the
oven’s power circuit.
Do not use aggressive or abrasive cleaning
products, scourers that scratch surfaces or
sharp objects, since stains may appear.
Do not use high pressure or stream jet clean-
ing appliances.
Accessories
Clean the accessories after each use. If they
are very dirty, soak them first of all and then
use a brush and sponge. The accessories
can be washed in a dish washing machine.
Make sure that the turntable plate and the
respective support are always clean. Do not
switch on the oven unless the turntable and
the respective support are in place.
Front surface
Normally you just need to clean the oven with
a damp cloth. If it is very dirty, add a few
drops of dish washing liquid to the cleaning
water. Afterwards, wipe the oven with a dry
cloth.
Use a glass cleaning product and a soft cloth
that does not release any fibres or threads.
Wipe from side to side without exerting any
pressure on the surface.
Immediately remove lime, fat, starch or egg
white stains. Corrosion can occur under
these stains.
Do not let any water get inside the oven.
Oven interior
After each time the oven is used, clean the
inside walls with a damp cloth since this is
the easiest way to remove splashes or spots
of food that may have stuck to the inside.
To remove dirt that is harder to shift, use a
non-aggressive cleaning product. Do not use
oven sprays or other aggressive or abrasive
cleaning products.
Always keep the door and the oven front very
clean to ensure that the door opens and
closes properly.
Make sure water does not enter the micro-
wave ventilation holes.
Regularly take out the turntable plate and the
respective support and clean the cavity base,
especially after any liquid spillage.
Do not switch on the oven without the turn-
table and the respective support being in
place.
If the oven cavity is very dirty, put a glass of
water on the turntable and switch on the mi-
crowave oven for 2 or 3 minutes at maximum
power. The steam released will soften the dirt
which can then be cleaned easily using a soft
cloth.
Unpleasant odours (e.g. after cooking fish)
can be eliminated easily. Put a few drops of
lemon juice in a cup with water. Put a spoon-
ful of coffee in the cup to avoid the water
electrolux 9

boiling over. Heat the water for 2 to 3 minutes
at maximum microwave power.
Technical data
Technical data category Value
AC Voltage
Power required 1250W
Microwave output power 800W
Microwave frequency 2450 MHz
Dimensions (WxHxD) 461 x 280 x 365 mm
Oven capacity. 20ltr
Weight 12.6 kg
Environment concerns
The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for
the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more
detailed information about recycling of this
product, please contact your local council,
your household waste disposal service or the
shop where you purchased the product.
Installation
• Remove any promotion label from the
door.
• The oven should be installed on a flat, level
surface. The surface must be strong
enough to safely bear the weight (12.6 Kg)
of the oven, and the contents. To avoid the
possibility of causing vibration or noise the
oven must be in a stable position.
• Keep the oven away from heat and water.
Exposure to heat and water can lower
oven efficiency and lead to malfunctioning,
so be sure to install the oven away from
heat and water sources.
• Do not block air vents on the top and the
sides of the cabinet and also do not place
any articles on the top of the oven. If air
vents are blocked during operation, the
oven may overheat, and this may lead to
malfunctioning. Hot air escapes from the
vents, so be sure not to obstruct it or let
curtains come between the oven and the
rear wall.
• Place the oven as far away from radios and
TV's as possible. This oven does conform
to EEC requirements of radio interference
suppression, but some interference may
occur if it is placed too close to a radio or
TV, so keep them as far apart as possible.
• If positioned in a corner, leave a gap of at
least 15 cm from the walls and 15 cm
above the microwave.
Important! The oven can be placed almost
anywhere in the kitchen. Make sure the oven
is placed on a flat, level surface and that
vents as well as the surface underneath the
oven are not blocked (for sufficient
ventilation).
Connecting to the mains
The oven is delivered with the power cord
and a plug for earthed
socket outlet. Earth protection minimises the
risks should a short circuit occur. Check to
10 electrolux
230V~50Hz
230V~50Hz
