Electrolux Compact front series User manual

© Electrolux
Muggenhofer Straße 135
D-90429 Nürnberg
ermany
Fax [phone]
Spares Operation
Publ.-Nr.:
599 518 355 EN
10.2003
D S-TDS-N - R.Kurzke
Ausgabe:
SERVICE MANUAL
Compact front loaded
Washing Machines
(Timer controlled)
Compact front loaded
Washing Mashines
from Torsvik
Timer controlled

- 2 -
10.2003 R.K. 599 518 355
Table of Contents
General features 3
Programs 4
Timer function 5
Operation principle 6
Types of Spin 7
Construction
Enclosure 9
Upperframe 9
owerframe 9
Rear of machine 10
Front panel 11
Detergent dispenser 11
Front hatch 12
Hatch locking switch 12
Washing unit with outer drum 13
Function
Monitoring of spin phase for imbalance 14
Water supply valve 15
evel regulator 15
Heating element 16
NTC-Thermistor 16
Drainage pump 17
Service/Accessibility
Top plate 18
Panel 19
Hatch 20
Hatch hinge 21
Rear ot machine 22
Drum unit 23
Shockabsorbers 23
Outer drum with drum bearing 24
Troubleshootings 25
Motor check 27
Diagrams 28
Washing programs table 30
Timer diagram 31
Timer connectors 32

- 3 -
10.2003 R.K. 599 518 355
Controls
Timer type VD55
Push button functions On/off Rinse hold
Knob/Command func. Program Temperature
Dimensions
Height 670 mm
Width 495 mm
Depth 515 mm
Tub material Carboran
Drum volume 27 l
Washing capacity 3.00 kg
Inlet hose length 130 cm
Outlet hose length 160 cm
Det. dispenser type of Two chambers
Cord length 170 cm

- 4 -
10.2003 R.K. 599 518 355

- 5 -
10.2003 R.K. 599 518 355

- 6 -
10.2003 R.K. 599 518 355
5 Heating element
6 Rubber bottom, fixed to outer drum
7 Drainage pump
8 Circulation hose
9 Drainage hose
OPERATION PRINCIP E
Traditional washing Operation
1 Detergent hatch
2 Hose between detergent dispenser and outer drum
3 Outer drum
4 Inner drum
- The partides of soiling substances which are freed from the textile fibres by the chemical action of the detergent
at the temperature of the washing water are re-moved by the flow of water through the fibres.
- The reversing rotation ofthe drum causes mechamcal interaction between the parts ofthe load and the
detergent solution which separates the partides from the textlies.
- The water level is at such a height that the load is successively lifted from the solution by the ridges formed
in the inner drum and then falls back into the solution.
- The Circulation ofthe solution during the rotation ofthe drum prevents the accumulation of detergent in the
rubber bottom.

- 7 -
10.2003 R.K. 599 518 355

- 8 -
10.2003 R.K. 599 518 355

- 9 -
10.2003 R.K. 599 518 355
CONSTRUCTION
Enclosure
The enclosure consists of: - a lacquered steel sheet
pressing forming the front and both sides, fixed
between upper and lower CARBORAN frames
- a removabie galvanized sheet steel back plate
- a top of lacquered steel sheet, fixed to the rear of
the upper ARBORAhOframe.
1 Top, lacquered steel sheet
2 Upper frame, CARBORAN
3 Back plate,
4 Front and sides, lacquered steel sheet
5 Lower frame, CARBORAN
Upper frame
1. Upper frame of CARBORAN®
2. Interference suppressor
4. Spring, drum suspension
5. Level regulator, level 1
level 2, and
anti-foam function
6. Level regulator, overflow protection
7. Water supply valve
ower Frame
1. Lower frame, of CARBORANO
2. Shock absorber, fixed to frame with plastic pin
3. Electronics unit
4. Drainage pump, inserted in track and locked to
lower frame with plastic snap fixing
5. Plastic protection for drainage pump
6. Drainage hose, fixed with two plastic clamps
7. Adjustable rear foot with lock nut

- 10 -
10.2003 R.K. 599 518 355
1 Water supply hose
2 Shock absorber
3 Electronics unit 4 Motor
5 Temperature sensor, NTC thermistor
6 Rubber bottom with "pin trap" (filter not provided)
7 Drainage pump
8 Heating element, 1600 W.
9 Pressure chamber
10 Connection terminal block
11 Level regulator, level and anti-foam function
12 Level regulator, overflow protection
13 Rear counterweight
Rear of machine

- 11 -
10.2003 R.K. 599 518 355
Front panel
1 Front panel
2 Program scale
3 Temperature scale
4 Knob
5 Detergent hatch/dispenser
6 Fixing screw, (behind detergent hatch)
7 Lamp lens
8 Pilot lamp
9 Fixing screw, (Under top plate)
11 Fixing screw for panel
Detergent dispenser
Water enters through the rear nozzle (6) and then through the water distributor to the detergent dispenser. Water is
directed to the detergent dispenser section in accord-ance with the position ofthe program-controlled cam-guided finger,
washing the detergent/rinsing agent it contams down into the drum.
1 Detergent hatch
2 Detergent dispenser with internal water distributor
3 Linkage arm
4 Water distributor cam, program-controlled
5 Programmed Controller
6 Nozzle, water supply
7 Link System pivot
8 Cam-guided finger

- 12 -
10.2003 R.K. 599 518 355
Front hatch
The hatch is locked during washing by a bimetallic
electric hatch lock and is opened by depressmg the
hatch lock pad. When the hatch is closed and the
On/Off button is pressed, a Signal lamp Illuminates
after approximately 5 seconds, the hatch 1s locked
electrically and the selected washing cycle Starts.
When the program has been exe-cuted, the lamp
extinguishes after 45-120 seconds and the hatch
can be reopened.
1 External hatch frame
2 Hatch lock pad
3 Hatch glass
4 Internal hatch frame
5 Hatch hinge
6 Electrical hatch lock
7 Locklever
8 Splash protection
9 Supporting beam
Hatch locking switch
The security of the hatch is ensured by an electromagnetlc lock
with function äs described below.
 when the lock is activated, the voltage-sensing unit closes
the switch which con-nects voltage to the electrical
components of the machine.
 During operations, the slide (A) remains mechanically
locked and thereby prevents opening of the hatch by fixing
the hatch lock lever
 When the hatch lock has been deactivated, It remains
locked for approximately 45-120 seconds to ensure that
the drum is statlonary before the hatch is opened.
ELECTRICAL DIAGRAM
1 Lock lever (in hatch)
2 Slide
3 PTC resistor
4 Switch activated by the PTC resistor

- 13 -
10.2003 R.K. 599 518 355
Washing unit with outer drum of CARBORAN®
1 Ring for fixing bellows to enclosure
2 Bellows
3 Screw, front counterweight
4 Front counterweight
5 Screw, front/rear outer drum
6 Ring for fixing bellows
7 Front section of outer drum, CARBORAN®
8 Packing
9 Inner drum, stamless steel
10 Rear section of outer drum, CARBORAN®
11 Drum shaft sealing ring
12 Inner ball bearing
13 Outer ball beanng
14 Rear counterweight
15 Pulley wheel
The outer drum consists of two sections of
CARBORAN® fixed together with a number
ofthread-cutting screws. The two counterweights
are screwed to the sections.

- 14 -
10.2003 R.K. 599 518 355
Programmed control unit
Imbalance control, f nction
A check for imbalance of the load 1s performed during 15 seconds at 85 rev/min. before the spin phase.
- If imbalance is detected, the tachometer generator and the motor current give an irregulär Signal
to the micro-processor on the electronics board which then Interrupts the spin phase. The
machine then returns to 55 rev/mm.. rotation and re-distributes the load to achieve balance
before performing a new check at 85 rev/min..
- If imbalance persists, redlstribution of the load is repeated for a period of 10 minutes (16
attempts) or until balance is achleved.
- If no balance is obtained after 10 minutes, the program continues forward with-outspln.
- When balance is obtained, the program continues with spin atthe speed speci-fied.
Monrtoring of spin phase for imbalance
This sequence is repeated while the
load remains unbalanced...
...a total of 16 times (10 minutes) or until
balance is achieved. if balance is not obtained,
the spin is omitted from the program.

- 15 -
10.2003 R.K. 599 518 355
Water supply valve
General characteristics
This electro-magnetic controlled valve regulates the supply of water
to the machine via the water distributor in the detergent distributor.
It 1s actuated by a solenold which is controlled electrically bythe
programmed Controller via the level regulator.
When the valve Is inactive, (without voltage) the spring holds the
splndle down and the rubber cone seals a small hole at the centre
of the membrane. A head of water bullds up which holds the
membrane against Its seating and closes the valve.
When voltage 1s applled to the solenold, the splndle with the rubber
cone is drawn up-ward against the spring and the hole in the
membrane 1s exposed, permitting the passage of water. The
pressure differential 1s lost and water can flow freely through the
valve.
1 Water entry
2 Valve housing
3 Filter
4 Flow regulator
5 Coil
6 Spring
7 Spindle
8 Rubber cone
9 Membrane 10 Water delivery
evel regulator
General characteristics
The level regulator momtors the level of the water in the
machlne and
 adapts the water level to that required at different stages
ofthe washing sequence selected.
 acts äs a low-water safety device äs It is connected in
series with the heating ele-ment. It disconnects the
voltage to the element when the water falls below a
certaln level.
 acts äs an anti-foam protection by sending a Signal to
the electromcs which Interrupts the spln phase and
restarts this when the foam has subsided. (VE 60 and
V 60 program med Controllers).

- 16 -
10.2003 R.K. 599 518 355
Heating Element
General characteristics
The element for heating the water is of the
encapsulated type, i.e. the spiral resistor is
hermetically sealed in a stainless steel enclosure.
Power 1600 W
Resistance 230 V 31.2 - 34.3 Ohm
240 V 33.9 - 37.4 Ohm
1 Element
2 Rubber packing
3 Fixed f lange
4 Electrical connection pin
5 Locking nut
6 Adjustable f lange
7 Fuse
The seal between the element and the outer drum is
obtained with a rubber packing which expands when
the locking nut is tightened.
NTC-Thermistor (Temperature control)
Temperature control by means of NTC thermistors is incorporated in models
controlled by Programmed control units VA 60, VB 60 and VE 60.
NTC temperature sensors
1 Plastic housing
2 Metal capsule
3 NTC resistance
4 Electrical contacts
Table with resistance at different temperatures (3%)
Temperature °C Resistance kOhm
30 17.3
40 11.5
50 7.84
60 5.46
70 3.90
78 2.97
85 2.32
The temperature of the washing water is controlled by the microprocessor via an NTC sensor.
The internal resistance ofthe sensor decreases äs the temperature increases. This decrease is registered by the
microprocessor which disconnects the heating element when the required temperature has been reached.
With a short-circult or other failure in the NTC thermistor, the control unit cancels the heating stage and completes the
program without heating.

- 17 -
10.2003 R.K. 599 518 355
Drainage pump
1 Impeller
2 Rotor
3 Stator
4 Pump housing
5 0-ring
The rotor consists of a permanent magnet which can rotate clockwise or anti clock-wise. The rotor can
rotate one quarter revolution without movement ofthe impeller.
Ifthe impeller seizes, the rotor can therefore make small movements in both directions until the impeller
is freed. An unusual sound may be heard at Start which is quite normal.
Function check
1 Check that the impeller can move freely.
2 Check the resistance of the Stator winding. This should be 170 Ohm.
Max. capacity = 20 l/mm.
Power consumptlon = 30 W

- 18 -
10.2003 R.K. 599 518 355
SERVICE/ACCESSIBI ITY
Top plate
1 Remove the 4 screws (A) at the rear edge of the
plate.
2 Draw the top plate backward
Accessibility:
A Supply valve
B Level regulator, level and anti-foam C Level
regulator, overflow protection D Capacitor/
Interference suppressor

- 19 -
10.2003 R.K. 599 518 355
Panel
1 Remove the top plate
2 Remove the 2 screws (9).
3 Remove the knob (4).
Unlock the holding catch
by msertmg a fine screwdriver
(or equivalent) straight through
the hole, rotating the knob
anti clockwise at the same
time until the knob can
be removed.
4 Remove the temperature
scale (3) by llfting the lock
on the plastlc shaft and
with-drawing the scale.
5 Remove the program scale after
removmg the nut.
Remove the screw behlnd the
program scale.
6 Remove the detergent hatch (5) by jerking iIt past a stop.
Remove the screw (6) inside the hatch.
7 Remove the screw (10) to free the detergent dispenser and llft the panel away
from the front edge of the detergent hatch.
Accessibility:
A Programmed control unit
B Press-operated switch
C Potentiometer, temperature setting
(Not provided on all modeis)

- 20 -
10.2003 R.K. 599 518 355
Hatch
Removal:
1 Remove the two screws (A) holding the hatch to Its hinge.
2 The outer hatch frame is snapped over the outer edge ofthe
inner hatch frame. Carefully lever the frames apart and
remove the outer frame.
3 The opening pad with springs, fixed to the inner frame
with 2 screws Is now accessible.
4 The hatch glass Is fixed in the inner frame with 4 plastic projections.
Bend these open to permit removal ofthe glass.
Re-assembly:
1 Place the glass agalnst the inner hatch frame. Check that the 2 projections (B) on the edge of the glass are in
llne with the corresponding spaces In the Inner frame and press Into positlon past the plastic projections.
2 Place the outer hatch frame agalnst the inner frame and press together.
Hatch lock fixed to the Inner hatch
