Electrolux W475H User manual

Installation manual
W475H/N/S, W485N/S, W4105H/N/S,
W4130H/N/S, W4180H/N/S, W4240H/N/S,
W4250N/S, W4300H, W4330N/S
Compass Control
438 9037-38/US
09.38

3
SAFETY AND WARNINGS SIGNS
Replace If Missing Or Illegible
One or more of these signs must be affixed on each machine as indica-
ted, when not included as part of the front instruction panel.
LOCATED ON THE OPERATING INSTRUCTION SIGN OF THE MACHINE:
CAUTION
1. Do not attempt to open door unitl "Door unlocked" indicator
is lit.
2. Machine must not be used by children.
3. Do not use flammable liquids in this machine.
MACHINE MUST NOT BE USED BY CHILDREN
Safety and warning signs
WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT
PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR
MACHINE.
PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S)
DATA PLATE(S).
MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE
REFERENCE.
MACHINE TYPE OR MODEL
MACHINE SERIAL NUMBER(S)
ELECTRICAL CHARACTERISTICS: _________ VOLTS, ________ PHASE, ________ HZ.

4
IMPORTANT SAFETY INSTRUCTIONS
WARNING -
To reduce the risk of fire, electric chock, or injury to persons when using your appliance:
1. Read all instructions before using the appliance.
2. This machine must be securely bolted to the floor according to the installation instructions.
3. This machine MUST be serviced and operated in compliance with manufacturers instructions.
CHECK DOOR LOCKS EVERY DAY FOR PROPER OPERATION TO PREVENT INJURY OR
DAMAGE. IF THE DOOR LOCK FAILS TO OPERATE PROPERLY, PLACE THE MACHINE
OUT OF ORDER UNTIL THE PROBLEM IS CORRECTED.
4. Do not wash articles that have been previously cleaned in, washed in, soaked in, or spotted
with gasoline, drycleaning solvents, or other flammable or explosive substances, as they give
off vapors that could ignite or explode.
5. Do not add gasoline, dry-cleaning solvents, or other flammable or explosive substances to
the wash water. These substances give off vapours that could ignite or explode.
6. Under certain conditions, hydrogen gas may be produced in a hot-water system that has not
been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water system
has not been used for such a period, before using a washing machine, turn on all hot-water
faucets and let the water flow from each for several minutes. This will release any accumula-
ted hydrogen gas. As the gas is flammable, do not smoke or use an open flame during this
time.
7. Do not allow children to play on or in the appliance. Close supervision of children is necessary
when the appliance is used near children.
8. Before the appliance is removed from service or discarded, remove the door.
9. Do not reach into the appliance if the tube is moving.
10. Do not install or store this appliance where it will be exposed to the weather.
11. Do not tamper with controls.
12. Do not repair or replace any part of the appleance or attempt any servicing unless specifically
recommanded in the user-maintenance instructions or in published user-repair instructions
that you understand and have the skills to carry out.
Safety and warning signs

5
Safety and warning signs
NOTICE TO: OWNERS, OPERATORS AND DEALERS
IMPROPER INSTALLATION AND INADEQUATE MAINTENANCE, POOR HOUSEKEEPING AND
WILLFUL NEGLECT OR BYPASSING OF SAFETY DEVICES MAY RESULT IN SERIOUS ACCI-
DENTS OR INJURY.
TO ASSURE THE SAFETY OF CUSTOMERS AND/OR OPERATORS OF YOUR MACHINE, THE
FOLLOWING MAINTENANCE CHECKS MUST BE PERFORMED ON A DAILY BASIS.
1. Prior to operation of the machine, check to make certain that all operating instruc-
tions and warning signs are affixed to the machine and legible. Missing or illegible
ones must be replaced immediately. Be sure you have spare signs and labels
available at all times. These can be obtained from your dealer.
2. Check the door safety interlock, as follows:
(a) OPEN THE DOOR of the machine and attempt to start in the normal manner:
For coin-operated models, insert the proper coins to start the machine.
For manually operated models, place the ON-OFF switch in the ON position
and press the Start switch.
THE MACHINE(S) MUST NOT START !
(b) CLOSE THE DOOR to start machine operation and, while it is operating,
attempt to open the door without exerting extreme force on the door handle.
The door should remain locked!
If the machine can start with the door open, or can continue to operate with
the door unlocked, the door interlock is no longer operating properly.
The machine must be placed out of order and the interlock immediately
replaced. (See the door interlock section of the manual.)
3. DO NOT UNDER ANY CIRCUMSTANCES ATTEMPT TO BYPASS OR REWIRE
ANY OF THE MACHINE SAFETY DEVICES AS THIS CAN RESULT IN SERIOUS
ACCIDENTS.
4. Be sure to keep the machine(s) in proper working order: Follow all maintenan-
ce and safety procedures. Further information regarding machine safety, service
and parts can be obtained from your dealer.
All requests for assistance must include the model, serial number and electrical
characteristics as they appear on the machine identification plate. Insert this infor
mation in the space provided on the previous page of this manual.
5. WARNING: DO NOT OPERATE MACHINE(S) WITH SAFETY DEVICES BYPASSED, REWI-
RED OR INOPERATIVE! DO NOT OPEN MACHINE DOOR UNTIL DRUM HAS STOPPED
ROTATING!

6
NOTICE TO INSTALLER
Improper installation of this machine:
•Maycauseseriousdamagetothemachine.
•Mayresultinotherpropertydamage.
•Maycausepersonalinjury.
•Willvoidthemanufacturer'swarranty.
Improper fastening of this machine to its foundation, inferior foundation materials, an
undersized foundation, the use of fabricated steel bases not provided by Electrolux or its
approved supplier(s), the use of an improper type, number, or size of mounting bolts, or
failure to use proper hardware on mounting bolts may result in damage to the machine
thatwillnotbecoveredbythemanufacturer'swarranty.
Use of a steel base beneath this machine DRAMATICALLY INCREASES the mechanical
stress placed on the underlying concrete floor or foundation. This must be taken into
consideration when employing a steel base to raise the height of the machine.
The use of steel bases more than six inches in height is NOT recommended. If instal-
lation requires a base higher than six inches, contact Electrolux Technical Support for
advice.
Connection to line Voltage or over-current protection devices other than those specified
on the data plate may result in severe damage to machine components, and will void the
manufacturer'swarranty.
Refer to complete installation instructions provided in manuals accompanying the
machine.
Contact Electrolux Technical Support with any questions BEFORE installing this
machine. Damage resulting from inadequate installation materials or improper
installation techniques will void the manufacturer's warranty.
Safety and warning signs

7
Contents
Contents
Safety precautions .....................................................................................9
Technical data..........................................................................................11
Installation W475H-W4330H....................................................................19
Transportation and unpacking, W475H, W4105H ..............................19
Transportation and unpacking, W4130H-W4300H .............................20
Siting and floor ....................................................................................21
Mechanical installation ........................................................................22
Installation W485N/S-W4330N/S.............................................................23
Siting ...................................................................................................23
Floor ....................................................................................................23
Casting a plinth ...................................................................................24
Installing the machine .........................................................................26
Water connections ..............................................................................27
Drain connection .................................................................................29
Steam connection ...............................................................................30
Connection of external liquid supplies ................................................31
Functions for I/O-cards .......................................................................34
Electrical installation............................................................................35
Function checks.......................................................................................41
The manufacturer reserves the right to make changes to design, material
and/or specifications without notice.

9
Safety Precautions
All external equipment which is connected to the machine must be CE/EMC-approved
and connected using an approved shielded cable.
Safety Precautions
The machine is designed for water washing only.
The machine must not be used by children.
All installation operations are to be carried out by qualified personnel. Licensed per-
sonnel are necessary for all electric power wiring and plumbing
Do not hose down the machine with water.
The door interlock must be checked daily for proper operation and must not be
bypased.
All seepage in the system, due to faulty gaskets etc., must be repaired immediately.
All service personnel must be fully familiar with the operating manual before attemp-
ting any repair or maintenance of the machine
The machine must not be sprayed with water
Do not add flammable or explosive substances to the wash water. There may give off
vapors that could ignite or explode
The machine is not intended to be used by people (including minors) with reduced
physical or mental capacity or lack of experience and knowledge. Such people must
be instructed in the use of the machine by a person who has responsibility for their
safety. Minors must be supervised to ensure that they do not play with the machine.

11
Technical data
W475H W4105H W4130H W4180H W4240H W4300H
75/2.6 105/3.7 130/4.6 180/6.4 240/8.5 300/10.6
520/20 1/2 595/23 7/16 650/25 9/16 725/28 9/16 795/31 5/16 795/31 5/16
49 49 49 44 42 42
1100 1025 980 930 890 820
5.4/7.5 7.5/10 13 18 23 23
x x x x x x
x x x x x x
350 350 350 350 350 300
159/350 201/443 267/588 350/771 400/882 509/1122
Connections
Technical data
Innerdrum
volume litres/ft3
diameter mm/inch
Drum speed
wash rpm
extraction rpm
Heating
electricity kW
steam
hot water
G-factor
Weight, net kg/lbs
W475H W4105H W4130H W4180H W4240H W4300H
DN20 DN20 DN20 DN20 DN20 DN20
3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
30-90 30-90 30-90 30-90 30-90 30-90
200-600 200-600 200-600 200-600 200-600 200-600
8-145 8-145 8-145 8-145 8-145 8-145
50-1000 50-1000 50-1000 50-1000 50-1000 50-1000
5 5 5 8 15 15
20 20 20 30 60 60
75/3 75/3 75/3 75/3 75/3 75/3
45 45 45 45 45 45
170 170 170 170 170 170
DN15 DN15 DN15 DN15 DN15 DN15
1/2" 1/2" 1/2" 1/2" 1/2" 1/2"
45-90 45-90 45-90 45-90 45-90 45-90
300-600 300-600 300-600 300-600 300-600 300-600
8-115 8-115 8-115 8-115 8-115 8-115
50-800 50-800 50-800 50-800 50-800 50-800
Water valves
connection
Rec. water pressure psi
kPa
Functioning limits psi
for water valve kPa
Capacity at 45 psi
(300 kPa) gallon/min
l/min
Drain valve
outer Ø mm/inch
Draining gallon/min
capacity l/min
Steam valve
connection
Rec. steam pressure psi
kPa
Functioning limits for psi
steam valve kPa

12 Technical data
W485N/S W4105N/S W4130N/S W4180N/S W4250N/S W4330N/S
85/3.0 105/3.7 130/4.6 180/6.4 250/8.8 330/11.7
520/20 1/2 595/23 7/16 595/23 7/16 650/25 9/16 725/28 9/16 795/31 5/16
49 49 49 44 44 42
587/830 548/776 548/776 525/742 497/702 474/671
2.0/3.0/5.6 3.0/6.5/ 3.0/ 4.8/9.3
5.4/7.5 7.5/10 7.5/10 13 18 23
x x x x x x
x x x x x x
100/200 100/200 100/200 100/200 100/200 100/200
135/298 145/320 175/386 228/503 287/633 330/727
W485N/S W4105N/S W4130N/S W4180N/S W4250N/S W4330N/S
DN20 DN20 DN20 DN20 DN20 DN20
3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
30-90 30-90 30-90 30-90 30-90 30-90
200-600 200-600 200-600 200-600 200-600 200-600
8-145 8-145 8-145 8-145 8-145 8-145
50-1000 50-1000 50-1000 50-1000 50-1000 50-1000
5 5 5 8 15 15
20 20 20 30 60 60
3 3 3 3 3 3
75 75 75 75 75 75
45 45 45 45 45 45
170 170 170 170 170 170
DN15 DN15 DN15 DN15 DN15 DN15
1/2" 1/2" 1/2" 1/2" 1/2" 1/2"
45-90 45-90 45-90 45-90 45-90 45-90
300-600 300-600 300-600 300-600 300-600 300-600
8-115 8-115 8-115 8-115 8-115 8-115
50-800 50-800 50-800 50-800 50-800 50-800
Water valves
connection
Rec. water pressure psi
kPa
Functioning limits psi
for water valve kPa
Capacity at 45 psi
(300 kPa) gallon/min
l/min
Drain valve inch
outer Ø mm
Draining gallon/min
capacity l/min
Steam valve
connection
Rec. steam pressure psi
kPa
Functioning limits for psi
steam valve kPa
Connections
Technical data
Innerdrum
volume litres/ft3
diameter mm/inch
Drum speed
wash rpm
extraction rpm
Heating
electricity kW
steam
hot water
G-factor
Weight, net kg/lbs

13
K
N
M
R
P
6
F
5
1
O
G
I
L
3
2
7
4
5283 B
Technical data
A
8
9
10
C
D
5281 B
B
E
6
5282 B
W475H, W4105H, W4130H
A
9
10
8
D
C
5377 A
5379 A
B
E
6
G
SL
M
I
5
1
F
6
P
R
KH
5378 A
7
3
2
2
W4180H, W4240H, W4300H
Rear side
Front Right side
Rear side
Front Right side
A B C D E F G H I K L M N O P R S
W475H 720 690 1115 355 720 825 45 1030 220 1010 135 910 830 360 100 240 –
W4105H 830 705 1300 365 740 910 45 1115 220 1095 135 995 910 415 100 295 –
W4130H 910 785 1325 435 825 1035 125 1245 215 1225 300 1125 – – 100 305 455
W4180H 970 870 1410 470 945 1120 115 1330 230 1290 315 1205 370 410 100 335 485
W4240H 1020 915 1445 500 955 1155 100 1360 215 1320 300 1240 350 360 100 360 510
W4300H 1020 1060 1445 500 1135 1155 100 1360 215 1320 300 380 – – 100 360 335
1 Electrical connection
2 Cold water
3 Hot water
4 Hard water (option)
5 Steam connection
6 Drain
7 Liquid detergent supply
8 Control panel
9 Soap box
10 Door opening, W475H: ø 310 mm/12 3/16", W4105H: ø 365 mm/14 3/8", W4130H: ø 395 mm/15 9/16",
W4180H, W4240H, W4300H: ø 435 mm/17 1/8"

14
W475H, W4105H, W4130H
W4180H, W4240H, W4300H
in inch A B C D E F G H I K
W475H 28 3/8 27 3/16 43 7/8 14 28 3/8 32 1/2 1 3/4 40 9/16 8 11/16 39 3/4
W4105H 32 11/16 27 3/4 51 3/16 14 3/8 29 1/8 35 13/16 1 3/4 43 7/8 8 11/16 43 5/16
W4130H 35 13/16 30 7/8 52 3/16 17 1/8 32 1/2 40 3/4 4 15/16 49 8 7/16 48 1/4
W4180H 38 3/16 34 1/4 55 1/2 18 1/2 37 3/16 44 1/8 4 1/2 52 3/8 9 1/16 50 13/16
W4240H 40 3/16 36 56 7/8 19 11/16 37 5/8 45 1/2 3 15/16 53 9/16 8 7/16 51 15/16
W4300H 40 3/16 41 3/4 56 7/8 19 11/16 44 11/16 45 1/2 3 5/16 53 9/16 8 7/16 51 15/16
in inch L M N O P R S
W475H 5 5/16 35 13/16 32 11/16 14 3/16 3 5/16 9 7/16 –
W4105H 5 5/16 39 3/16 35 13/16 16 5/16 3 5/16 11 5/8 –
W4130H 11 13/16 44 5/16 – – 3 5/16 12 17 15/16
W4180H 12 3/8 47 7/16 14 9/16 16 1/8 3 5/16 13 3/16 19 1/8
W4240H 11 13/16 48 13/16 13 3/4 14 15/16 3 5/16 14 3/16 20 1/16
W4300H 12 3/16 14 15/16 – – 3 15/16 14 3/16 13 3/16
Rear side
Front Right side
Rear side
Front Right side
A
8
9
10
C
D
5281 B
B
E
6
5282 B
K
N
M
R
P
6
F
5
1
O
G
I
L
3
2
7
4
5283 B
A
9
10
8
D
C
5377 A
5379 A
B
E
6
G
SL
M
I
5
1
F
6
P
R
KH
5378 A
7
3
2
2
Technical data

15
Technical data
1 Electrical connection
2 Cold water
3 Hot water
4 Steam connection
5 Drain
6 Liquid detergent supply
7 Control panel
8 Soap box
9 Water reuse
10 Door opening, W485S: ø 310 mm/12 3/16", W4105S, W4130S: ø 365 mm/14 3/8",
W4180S: ø 395 mm/15 9/16", W4250S, W4330S: ø 435 mm/17 1/8"
W485N/S-W4130N/S
Rear side
Right sideFront Rear side
W4180N/S-W4330N/S
87
C
D
A
10
5281
B
E
5
5282
N
G
I
F
L
R
P
H
M
K
5
4
1
3
2
6
5283
9
M
P
F
K
I
L
G
R
H
O
N
4
1
5
3
29
6
5459
A B C D E F G H I K L M N O P R
W485N/S 660 730 1115 355 765 825 45 1030 215 1010 130 830 385 - 100 225
W4105N/S 720 705 1200 365 740 910 45 1115 215 1095 130 910 420 - 100 235
W4130N/S 720 790 1200 365 825 910 45 1115 215 1095 130 910 420 - 100 235
W4180N/S 750 880 1325 435 915 1035 45 1245 130 1225 210 1040 325 295 100 225
W4250N/S 830 955 1410 470 990 1120 45 1330 160 1290 245 1125 325 325 100 265
W4330N/S 910 1040 1445 500 1075 1155 45 1365 160 1325 245 1155 280 325 100 210

16
W485N/S-W4130N/S
Rear side
Right sideFront Rear side
W4180N/S-W4330N/S
in inch A B C D E F G H I K
W485N/S 26 28 3/4 43 7/8 14 30 1/8 32 1/2 1 3/4 40 9/16 8 7/16 39 3/4
W4105N/S 28 3/8 27 3/4 47 1/4 14 3/8 29 1/8 35 13/16 1 3/4 40 7/8 8 7/16 43 1/8
W4130N/S 28 3/8 31 1/8 47 1/4 14 3/8 32 1/2 35 13/16 1 3/4 40 7/8 8 7/16 43 1/8
W4180N/S 29 1/2 32 11/16 52 3/16 17 1/8 36 40 3/4 1 3/4 49 5 1/8 48 1/4
W4250N/S 32 11/16 37 5/8 55 1/2 17 1/8 39 44 1/8 1 3/4 52 3/8 6 5/16 50 13/16
W4330N/S 35 13/16 40 15/16 56 7/8 19 11/16 42 5/16 45 1/2 1 3/4 53 3/4 6 5/16 52 3/16
in inch L M N O P R
W485N/S 5 1/8 32 11/16 15 3/16 – 3 15/16 8 7/8
W4105N/S 5 1/8 35 13/16 19 9/16 – 3 15/16 9 1/4
W4130N/S 5 1/8 35 13/16 16 9/16 – 3 15/16 9 1/4
W4180N/S 8 1/4 40 15/16 12 13/16 11 5/8 3 15/16 8 7/8
W4250N/S 9 5/8 44 5/16 12 13/16 12 13/16 3 15/16 10 7/16
W4330N/S 9 5/8 45 1/2 11 12 13/16 3 15/16 8 1/4
87
C
D
A
10
5281
B
E
5
5282
N
G
I
F
L
R
P
H
M
K
5
4
1
3
2
6
5283
9
M
P
F
K
I
L
G
R
H
O
N
4
1
5
3
29
6
5459
Technical data

17
Technical data
W475H W4105H W4130H W4180H W4240H W4300H
18.3 17.1 16.3 15.5 14.8 13.7
417±110 560±112 703±114 944±221 1158±221 1387±277
1.9±0.5 2.5±0.5 3.1±0.5 4.2±1.0 5.2±1.0 6.2±1.2
Frequency of the
dynamic force Hz
Max floor load lbs force
at extraction kN
W485N/S W4105N/S W4130N/S W4180N/S W4250N/S W4330N/S
Frequency of the
dynamic force
Hz 9.3/13.8 8.7/12.9 8.7/12.9 8.3/12.3 7.9/11.7 7.5/11.2
Max floor load
at extraction kN 1.7 ± 3.1/ 2.1 ± 3.6/ 2.3 ± 4.1/ 2.9 ± 4.7/ 3.7 ± 5.3/ 4.5 ± 5.8/
1.7 ± 2.6 2.1 ± 3.0 2.3 ± 3.7 2.9 ± 4.6 3.7 ± 5.8 4.5 ± 6.8
lbs force 375±696/ 468±813/ 518±912/ 648±1057/ 842±1189/ 1019±1310/
375±583 468±675 518±824 648±1038 842±1301 1019±1524

19
Installation
1
2
5325
1
5326
2
Installation W475H-W4330H
Transportation and unpacking,
W475H, W4105H
The machine is delivered complete with expan-
sion bolts etc. packed inside the machine in the
drum.
The machine is delivered bolted onto the trans-
port pallet and packed in a crate or box.
• Removepackingfromthemachine.
• Removefrontandrearpanel.Removethe
bolts between the machine and pallet.
• Mountfrontandrearpanel.
• Mountthefeet.
• Placethemachineonitsnalposition.
• Levelthemachinewiththefeetofthe
machine.
The machine also comes with transport safety
devices (four plate angles between the frame
and the drum).
In order to remove the safety devices:
• Unpackthemachine.
• Removefrontandrearpanel.
• Removebothfrontmetalangels.
• Removebothrearmetalangels.
NOTE!
Once the shipping safety devices have been
removed, handle the machine carefully to avoid
damage to the suspension components.

20
5340
3
6445
4
5341
5
Transportation and unpacking,
W4130H, W4180H, W4240H, W4300H
The machine is delivered complete with expan-
sion bolts etc. packed inside the machine in the
drum.
The machine is delivered bolted onto the trans-
port pallet and packed in a crate or box.
• Removepackingfromthemachine.
• Removefrontandrearpanel.Removethe
bolts between the machine and pallet.
• Mountfrontandrearpanel.
• Mountthefeet.
NOTE!
Regarding W4300H note the positioning of
the two front feet.
• Placethemachineonitsnalposition.
• Levelthemachinewiththefeetofthe
machine.
The machine also comes with transport safety
devices (two plate angles between the support
and the drum).
In order to remove the safety devices:
• Unpackthemachine.
• Removethetwosidepanels.
• Removethetwotransportsecurities.
NOTE!
Once the shipping safety devices have been
removed, handle the machine carefully to avoid
damage to the suspension components.
Installation
4
3
5
