Elitegroup Computer Systems P6VPA2T Setup guide

P
P6 6V VP PA A2 2T T
Setting Jumpers
Jumper Settings
Jumper Type Description Setting (default)
JP1 3-pin BIOS flash
protection
jumper
1-2: Disable
2-3: Enable JP1
1
JP2 3-pin Clear CMOS
jumper 1-2: Normal
2-3: Clear CMOS JP2
1
JP3
JP4
JP5
JP6
JP7
3-pin CPU core
voltage select
jumper
JP3
1
JP4JP5 JP6JP7
JP1: BIOS Flash Protect Jumper
This jumper is used to protect the BIOS from being uninten-
tionally flashed. Enable this jumper for protection and disable
this jumper when you want to flash the BIOS.
JP2: Clear CMOS Jumper
This jumper enables you to reset the BIOS. Follow these
instructions to reset the BIOS:
1. Turn the system off.
2. Short pins 2 and 3 on JP2.
3. Return the jumper to the normal setting.
4. Turn the system on. The BIOS is returned to the de-
fault settings.

2
Jumper 3 ~ 7: CPU Vcore adjust jumper
Use these 3 X 1 pin jumpers to manually set the CPU core
voltage. Refer to the table below for pin information.
Warning: These values are set at the factory. The following
information is for reference only. It is not recom-
mended to change the settings for jumper 3 ~ 7.
Please notice that the CPU will burn out if the
core voltage is higher than the default value.
Jumper 3 –7 pin settings
JP7 JP6 JP5 JP4 JP3 Vcore
1-21-21-21-21-2Auto*
2-3Open Open Open Open 1.300
2-3Open Open Open 2-31.350
2-3Open Open 2-3Open 1.400
2-3Open Open 2-32-31.450
2-3Open 2-3Open Open 1.500
2-3Open 2-3Open 2-31.550
2-3Open 2-32-3Open 1.600
2-3Open 2-32-32-31.650
2-32-3Open Open Open 1.700
2-32-3Open Open 2-31.750
2-32-3Open 2-3Open 1.800
2-32-3Open 2-32-31.050
2-32-32-3Open Open 1.100
2-32-32-3Open 2-31.150
2-32-32-32-3Open 1.200
2-32-32-32-32-31.250
JP7 JP6 JP5 JP4 JP3 Vcore
Open Open Open Open Open 1.325
Open Open Open Open 2-31.375
Open Open Open 2-3Open 1.425
Open Open Open 2-32-31.475
Open Open 2-3Open Open 1.525
Open Open 2-3Open 2-31.575
Open Open 2-32-3Open 1.625
Open Open 2-32-32-31.675
Open 2-3Open Open Open 1.725
Open 2-3Open Open 2-31.775
Open 2-3Open 2-3Open 1.825
Open 2-3Open 2-32-31.075
Open 2-32-3Open Open 1.125
Open 2-32-3Open 2-31.175
Open 2-32-32-3Open 1.225
Open 2-32-32-32-31.275

3
