ELTEC BAB 750 User manual

BAB 750
PowerPC 755 Based CompactPCI Board
manual
Revision 1B

Revision
Revision Changes Date / Name
1A First Edition, valid for Hardware revision 1A, 14.12.00 GM
1B Disclaimer new 08.11.06 hh

DISCLAIMER
Copyright
© 2006 ELTEC Elektronik AG. The information, data, and figures in this
document including respective references have been verified and
found to be legitimate. In particular in the event of error they may,
therefore, be changed at any time without prior notice. The complete
risk inherent in the utilization of this document or in the results of its
utilization shall be with the user; to this end, ELTEC Elektronik AG shall
not accept any liability. Regardless of the applicability of respective
copyrights, no portion of this document shall be copied, forwarded or
stored in a data reception system or entered into such systems without
the express prior written consent of ELTEC Elektronik AG, regardless of
how such acts are performed and what system is used (electronic,
mechanic, photocopying, recording, etc.). All product and company
names are registered trademarks of the respective companies.
Our General Business, Delivery, Offer, and Payment Terms and
Conditions shall otherwise apply.
Federal communications commission statement
Þ This device complies with FCC Rules Part 15. Operation is subject
to the following two conditions:
Þ This device may not cause harmful interference, and
Þ This device must accept any interference received including
interference that may cause undesired operation.
Þ This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with

manufacturer’s instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try correct the interference by
one or more of the following measures:
Þ Reorient or relocate the receiving antenna.
Þ Increase the separation between the equipment and receiver.
Þ Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
Þ Consult the dealer or an experienced radio/TV technician for help.
Þ The us of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC
regulations. Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
Canadian department of communications statement
Þ This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of
Communications.
Þ This class B digital apparatus complies with Canadian ICES-003
SAFETY INFORMATION
Electrical safety
Þ To prevent electrical shock hazard, disconnect the power cable
from the electrical outlet before reloading the system.

Þ When adding or removing devices to or from the system, ensure
that the power cables for the devices are unplugged before the
signal cables are connected. If possible, disconnect all power
cables from the existing system before you add device.
Þ Before connecting or removing signals cables from motherboard,
ensure that all power cables are unplugged.
Þ Make sure that your power supply is set to the correct voltage in
your area. If you are not sure about the voltage of the electrical
outlet you are using, contact your local power company.
Þ If the power supply is broken, do not try to fix it by yourself.
Contact a qualified service technician or your retailer.
Operation safety
Þ Before installing the motherboard and adding devices on it,
carefully read the manuals that came with the package.
Þ Before using the product, make sure all cables are correctly
connected and the power cables are not damaged. If you detect
any damage, contact your dealer immediately.
Þ To avoid short circuits, keep paper clips, screws, and staples away
from connectors, slots sockets and circuitry.
Þ Avoid dust, humidity, and temperature extremes. Do not place the
product in any area where it may become wet.
Þ Place the product on a stable surface.
Þ If you encounter technical problems with the product, contact a
qualified service technician or your retailer.
EMC Rules
This unit has to be installed in a shielded housing. If not installed in a
properly shielded enclosure, and used in accordance with the
instruction manual, this product may cause radio interference in which
case the user may be required to take adequate measures at his or her
own expense.

IMPROTANT INFORMATION
This product is not an end user product. It was developed and
manufactured for further processing by trained personnel.
RECYCLING
Please recycle packaging environmentally friendly:
Packaging materials are recyclable. Please do not dispose
packaging into domestic waste but recycle it.
Please recycle old or redundant devices environmentally
friendly:
Old devices contain valuable recyclable materials that should
be reutilized. Therefore please dispose old devices at collection points
which are suitable.

User’s Manual Table of Contents
BAB 750 I
Table of Contents
1 Specification...................................................................1—1
1.1 Main Features...............................................................1—1
1.2 Specification Details......................................................1—2
1.2.1 CPU Kernel................................................................1—2
1.2.2 Flash Memory............................................................1—2
1.2.3 PCI Devices ...............................................................1—2
1.2.4 CompactPCI Interface ...............................................1—3
1.2.5 PMC...........................................................................1—3
1.2.6 Mechanical.................................................................1—3
1.2.7 I/O ..............................................................................1—3
1.2.8 Compatibility ..............................................................1—4
1.2.9 Related Documents ...................................................1—4
2 Installation......................................................................2—1
2.1 Frontpanel I/O...............................................................2—1
2.2 Backpanel I/O ...............................................................2—2
2.2.1 CompactPCI Installation ............................................2—3
2.2.2 What‘s needed for Installation ...................................2—3
2.2.3 SODIMM Installation..................................................2—4

Table of Contents User’s Manual
BAB 750II
2.2.4 Activity LEDs..............................................................2—5
3 Connector Assignments ...............................................3—1
3.1 Onboard Connectors.....................................................3—2
3.1.1 Keyboard / Mouse Connector....................................3—2
3.1.2 Ethernet Connector....................................................3—3
3.1.3 Serial Ports 1 and 2 Connector..................................3—3
3.1.4 Parallel I/O Connector ...............................................3—4
3.1.5 CompactPCI Connectors...........................................3—5
3.2 Transition board..........................................................3—10
3.2.1 Additional Input/Output ............................................3—11
3.2.2 Floppy......................................................................3—12
3.2.3 IDE...........................................................................3—13
3.2.4 SCSI.........................................................................3—14
3.2.5 Serial (COM2)..........................................................3—16
3.3 PMC-Carrier (PMCC)..................................................3—17
3.3.1 PMC Slots................................................................3—18
3.3.2 CompactPCI.............................................................3—21
4 Board Parameters..........................................................4—1
4.1 Host Bus .......................................................................4—1

User’s Manual Table of Contents
BAB 750 III
4.2 CompactPCI..................................................................4—1
4.3 PCI Local Bus...............................................................4—2
4.4 Network.........................................................................4—2
4.5 SCSI..............................................................................4—3
4.6 Serial I/O.......................................................................4—3
4.7 Keyboard:......................................................................4—3
4.8 Mouse ...........................................................................4—3
4.9 Parallel I/O....................................................................4—4
4.10 MTBF Values..............................................................4—4
4.11 Environmental Conditions...........................................4—4
4.12 Maximum Operating Humidity: ...................................4—5
4.13 Power Requirements ..................................................4—5
5 Jumpers..........................................................................5—1
5.1 Onboard Jumpers.........................................................5—1
5.1.1 User-settable Jumpers...............................................5—2
5.1.2 SCSI-Termination ......................................................5—3
6 Booting ...........................................................................6—1
6.1 Printout of Boot Screen.................................................6—1
7 Appendix.........................................................................7—1

Table of Contents User’s Manual
BAB 750IV
7.1 Description of On-board Devices..................................7—1
7.1.1 Interrupt Controller.....................................................7—2
7.1.2 SRAM/RTC................................................................7—3
7.1.3 GPIO Use...................................................................7—4
7.1.4 Super-I/O Power-on Strappings.................................7—5
7.1.5 I/O Address Map........................................................7—6
7.1.6 Memory Address Map................................................7—7
7.1.7 PCI IDSEL..................................................................7—8
7.2 Factory Settable Jumpers.............................................7—9

User’s Manual Table of Contents
BAB 750 V

Table of Contents User’s Manual
BAB 750
VI
List of Tables
Table 1: Activity LEDs.........................................................2—5
Table 2: Keyboard (6-pin miniature circular connector)......3—2
Table 3: Ethernet (8-pin telephone jack connector)............3—3
Table 4: COM1, COM2 (9-pin min-D connector)................3—3
Table 5: Parallel I/O Connector ..........................................3—4
Table 6:CompactPCI Connector P1 ...................................3—5
Table 7: CompactPCI Connector P2 ..................................3—6
Table 8: CompactPCI Connector P4 ..................................3—7
Table 9: CompactPCI Connector P5 ..................................3—8
Table 10: Board-to-Board Connector..................................3—9
Table 11: Pinout additional Input/Output (X405) ..............3—11
Table 12: Pinout Floppy Connector (X401) ......................3—12
Table 13: Pinout IDE Connector (X403)...........................3—13
Table 14: Pinout SCSI Connector 8 bit (X402).................3—14
Table 15: Pinout SCSI Connector 16 bit (X404)...............3—15
Table 16: Pinout COM2 ....................................................3—16
Table 17: Pinout PMC Connector (X301, X303, X305) ....3—18
Table 18: Pinout PMC Connector (X302, X304, X306) ....3—19

User’s Manual Table of Contents
BAB 750 VII
Table 19: Pinout PMC Connector (X401, X402, X403) ....3—20
Table 20: Pinout PMCC CompactPCI Connector P1 .......3—21
Table 21: Pinout PMCC CompactPCI Connector P3 .......3—22
Table 22: Pinout PMCC CompactPCI Connector P4 .......3—23
Table 23: Boot ROM Select (J114).....................................5—2
Table 24: Jumper J1601-J1603..........................................5—3
Table 25: Interrupt...............................................................7—3
Table 26: SRAM/RTC Address Assignment.......................7—3
Table 27: GPIO Usage........................................................7—4
Table 28: Super-I/O Wake Up Configuration:.....................7—5
Table 29: I/O Address Map.................................................7—6
Table 30: Memory Address Map
(default used by VxWorks)..................................7—7
Table 31: IDSEL Connection .............................................7—8
Table 32: CPU PLL Configuration (J103...J106) ...............7—9
Table 33: System Clock (J111, J112, J113)......................7—9
Table 34: MPC106 PLL Configuration (J110...J107).......7—10
Table 35: Hardware Debugger Configuration (J1301).....7—10
Table 36: Revision EEPROM Write Protection (J1302) ..7—10

Table of Contents User’s Manual
BAB 750
VIII
List of Figures
Figure 1: Block Diagram .....................................................1—5
Figure 2: Frontpanel I/O......................................................2—1
Figure 3: Connectors ..........................................................3—1
Figure 4: Transition board.................................................3—10
Figure 5: Additional Input/Output......................................3—11
Figure 6: PMC-Carrier.......................................................3—17
Figure 7: Parts Side Jumpers.............................................5—1
Figure 8: Solder Side Jumpers...........................................5—2
Figure 9: BAB 750 Interrupt Diagram .................................7—2

User’s Manual Specification
BAB 750 1—1
Specification
1 Specification
 Main Features
•CompactPCI board with up to four PMC daughter card slots
One on-board and three on a optional PMC carrier board
(PMCC). Two slots required with PMC carrier board.
•PowerPC CPU 755 with 300 MHz.
•RAM: 8..128 MB (64-bit SODIMM) SDRAM (66/83 MHz,
CL=2).
•Cache: 1MB on-board.
•PCI host bridge: Motorola MPC106.
•PCI-ISA-Bridge: W83C553.
•Intel 21152 PCI-to-PCI bridge to compactPCI bus.
•Flash Eprom: 2 + 0,5 MB onboard, Flash programmable, byte
access implemented in hardware.
•Network interface: Ethernet using DEC21143 (10/100 Mbps)
with PCI-DMA, 10BaseT connector at front panel.
•Serial asynchronous: 2 * RS232 with PC97307.
•Real-time clock: MK48T59
•IDE
•Floppy
•SCSI (optional): 53C875

Specification User’s Manual
BAB 750
1—2
Specification
 Specification Details
1.2.1 CPU Kernel
The CPU kernel consists of the PowerPC 755 CPU with a clock rate
of 300 MHz and host bus clock of 66/83 MHz. The CPU contains
two parallel 32-bit integer execution units with an additional floating
point unit for 8 SPECint95 and 6.2 SPECfp95 at 200 MHz. It has an
external second-level cache running at 150 MHz. Memory is
controlled by the host bridge MPC106 which contains the bridge
between host bus and on-board PCI itself as well as the memory
interface for EDO or SDRAM modules in SODIMM format (144-pin
SODIMM module; 64-bit data bus). Memory size can be anywhere
between 8 and 128 MB, depending on the DIMM modules used.
1.2.2 Flash Memory
Up to 2 MB of user flash memory are supplied for storing user-
generated programs. Thus, diskless systems can be built.
1.2.3 PCI Devices
The board-internal PCI bus is used for all I/O devices as well as the
PCI-to-cPCI bridge. The PCI bus is of the master/slave type, capable
of DMA transfers as source and target.
A single-size PMC slot allows for interfacing, e.g. using a VGA
display adapter PMC module or a frame grabber interface. Due to the
bus-master DMA capabilities of the PMC implementation of the PCI
standard, frame grabber can be implemented efficiently without
frame buffers.
A optional PMC carrier board allows additional three PMC modules.

User’s Manual Specification
BAB 750 1—3
Specification
An Ethernet controller for either 10 Mbps or 100 Mbps Ethernet with
PCI DMA capabilities is provided on-board. Front panel interface is
10/100BaseT.
A optional ultra wide SCSI controller (53C875) allows transfer rates
of up to 40Mb/s.
The last interface on the local PCI bus is the ISA bridge (Winbond
W83C553), interfacing to the internal ISA bus with additional on-
board components. Additionally, there are the standard PC
components real-time clock, watchdog, keyboard controller, dual
serial I/O, floppy controller, IDE controller, and parallel controller.
1.2.4 CompactPCI Interface
A Intel 51152 32-bit PCI-to-PCI bridge is used to connect to the
compactPCI bus. The BAB 750 supplies system slot capabilities for
four other compactPCI boards.
1.2.5 PMC
A PCI extension card for PMC boards is provided. A PMC module
carrier board (PMCC) can be installed to provide three PMC module
slots. The PMC connectors are buffered with an additional 32-bit
PCI-PCI brdge device, located on the carrier board.
1.2.6 Mechanical
The board format is double Eurocard (6HU). If the optional PMC
carrier is used the BAB 750 requires two slots.
1.2.7 I/O
16-bit SCSI, floppy, IDE, keyboard, mouse, COM2, and speaker are
routed over the compactPCI P5 connector. Additionally printer and
PMC I/O is connected to compactPCI P4.

Specification User’s Manual
BAB 750
1—4
Specification
On the front panel the Ethernet 10BaseT connector is located as well
as the separate front panel for PMC I/O signals. The keyboard/mouse
connector and two serial RS232 channel are also routed to the front
panel.
1.2.8 Compatibility
The BAB 750 has been designed to be software-compatible to the
PowerPC reference platform (“Yellowknife”) as much as possible.
1.2.9 Related Documents
PowerPC 750 Programmer's Reference: This is the CPU manu-
facturer's description of the PowerPC itself and the assembly
language command set.

User’s Manual Specification
BAB 750 1—5
Specification
Figure 1: Block Diagram
66MHz (83MHz)/64-BitProcessor Bus
PCI Bus 33MHz/32-Bit
ISA Bus
PowerPC
Risc Microprocessor
(MPC755, MPC7400)
Ethernet Interface
SCSI Interface
IDE Interface
Serial #1/2, Parallel
PS2 Mouse, Keyboard
(Floppy)
EEPROM
(Config. Info)
Super I/O Controller
(PC97307)
Flash-EPROM
(512KB Boot)
(2MB User)
Real-Time Clock
(MK48T59)
PCI to ISA Bridge
(W83C553)
SCSI Controller
(SYM53C875)
Ethernet Controller
(DEC21143)
cPCI Bus
PCI to cPCI Bridge
(Intel 21152)
Memory
(SODIMM Socket)
PCI-/Memory Contr.
(MPC106)
L2 Cache
PCI/PMC
Extension Card
PCI/PMC Slot
I
2
C Bus

Specification User’s Manual
BAB 750
1—6
Specification
