Kontron CP6004-SA User manual

If it’s embedded, it’s Kontron.
» User Guide «
D R A F T — F O R I N T E R N A L U S E O N L Y
CP6004-SA
CP6004-RA
CP6004-RC
CP6004X-SA
IPMI Firmware
Doc. ID: 1053-0139, Rev. 3.0
August 13, 2013

Preface CP6004-SA/-RA/-RC/CP6004X-SA
Page 2 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
Revision History
Imprint
Kontron Europe GmbH may be contacted via the following:
MAILING ADDRESS TELEPHONE AND E-MAIL
Kontron Europe GmbH +49 (0) 800-SALESKONTRON
Sudetenstraße 7 [email protected]
D - 87600 Kaufbeuren Germany
For further information about other Kontron products, please visit our Internet website:
www.kontron.com.
Disclaimer
Copyright © 2013 Kontron AG. All rights reserved. All data is for information purposes only and
not guaranteed for legal purposes. Information has been carefully checked and is believed to
be accurate; however, no responsibility is assumed for inaccuracies. Kontron and the Kontron
logo and all other trademarks or registered trademarks are the property of their respective own-
ers and are recognized. Specifications are subject to change without notice.
Publication Title: CP6004-SA/-RA/-RC/CP6004X-SA IPMI Firmware User Guide
Doc. ID: 1053-0139
Rev. Brief Description of Changes Date of Issue
1.0 Initial issue 31-Oct-2012
2.0 General update, added description for the CP6004X-SA 8-Feb-2013
3.0 Added description for the CP6004-RA/CP6004-RC 13-Aug-2013

CP6004-SA/-RA/-RC/CP6004X-SA Preface
ID 1053-0139, Rev. 3.0 Page 3
D R A F T — F O R I N T E R N A L U S E O N L Y
Table of Contents
Revision History ........................................................................................................ 2
Imprint ....................................................................................................................... 2
Disclaimer ................................................................................................................. 2
Table of Contents ...................................................................................................... 3
List of Tables ............................................................................................................. 7
1. Introduction ...................................................................................9
1.1 Terminology and Acronym Definitions .......................................................... 9
1.2 Related Publications ...................................................................................11
1.3 IPMI Overview .............................................................................................11
2. IPMI Setup ....................................................................................12
2.1 IPMI in a CompactPCI Chassis .................................................................. 12
2.2 IPMI Setup for the CP6004-SA/-RA/-RC/CP6004X-SA ............................. 12
2.3 IPMI Setup for the Rack ............................................................................. 13
3. IPMI Controller Hardware ...........................................................13
4. IPMI Firmware ..............................................................................14
4.1 Key Features .............................................................................................. 14
5. Supported IPMI and ATCA Commands .....................................15
5.1 Standard IPMI Commands ......................................................................... 15
5.2 AdvancedTCA and AMC Commands ......................................................... 20
6. OEM Commands and Command Extensions ...........................21
6.1 Get Device ID Command with OEM Extensions ........................................ 21
6.2 Set Firmware Parameters .......................................................................... 22
6.3 Set Control State (SPI Boot Flash, Boot Order) ....................................... 23

Preface CP6004-SA/-RA/-RC/CP6004X-SA
Page 4 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
6.4 Get Control State (SPI Boot Flash, Boot Order) .........................................24
7. Sensors Implemented on the Board ......................................... 24
7.1 Sensor List ..................................................................................................25
7.2 Sensor Thresholds ......................................................................................28
7.3 OEM Event/Reading Types ........................................................................29
8. IPMI Firmware Code ...................................................................31
8.1 Structure and Functionality .........................................................................31
8.2 uEFI BIOS/IPMI Controller Interaction ........................................................31
8.3 IPMI Firmware Configuration ......................................................................31
8.4 Firmware Identification ................................................................................32
8.5 Firmware Upgrade ......................................................................................32
8.5.1 Firmware File Formats .......................................................................32
8.5.2 Firmware Upgrade - “ipmitool hpm” ..................................................33
8.5.3 Firmware Upgrade - “ipmitool fwum” .................................................34
8.6 Setting the SEL Time ..................................................................................34
8.7 IPMI Firmware Write Protection ..................................................................35
9. FRU Data ..................................................................................... 35
9.1 Structure and Functionality .........................................................................35
9.2 FRU Version Identification ..........................................................................35
9.3 Board-Specific FRU Data ...........................................................................36
9.4 FRU Data Update .......................................................................................36
9.5 FRU Data Write Protection .........................................................................36
10. XMC Card Support ...................................................................... 37
11. uEFI BIOS Failover Control - Automatic SPI Boot Flash Selection 37
12. OS Boot Order Selection by OEM IPMI ..................................... 37

CP6004-SA/-RA/-RC/CP6004X-SA Preface
ID 1053-0139, Rev. 3.0 Page 5
D R A F T — F O R I N T E R N A L U S E O N L Y
13. Hot Swap and Shutdown ............................................................38
13.1 Hot Swap Handle and Hot Swap LED ........................................................ 38
13.2 The Hot Swap and Shutdown Processes ................................................... 39
14. LAN Functions .............................................................................40
14.1 Overview .................................................................................................... 40
14.2 Setting Up the Ethernet Channel ............................................................... 41
14.3 Basic Setup from uEFI Shell ...................................................................... 41
14.4 Setup by “ipmitool” or IPMI Commands ..................................................... 41
14.5 Setup of User Accounts and Password ...................................................... 41
14.6 IPMI Over LAN ........................................................................................... 42
14.7 Serial Over LAN ......................................................................................... 43
15. OS Support / Tools ......................................................................44
15.1 Linux Tools ................................................................................................. 44
15.2 OS Support - Board Support Packages ..................................................... 44
16. IPMI and Hot Swap LEDs ............................................................45

Preface CP6004-SA/-RA/-RC/CP6004X-SA
Page 6 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
This page has been intentionally left blank.

CP6004-SA/-RA/-RC/CP6004X-SA Preface
ID 1053-0139, Rev. 3.0 Page 7
D R A F T — F O R I N T E R N A L U S E O N L Y
List of Tables
1 Terminology and Acronym Definitions ............................................................ 9
2 Related Publications .....................................................................................11
3 Standard IPMI Commands ........................................................................... 15
4 AdvancedTCA and AMC Commands .......................................................... 20
5 Get Device ID Command with OEM Extensions .......................................... 21
6 Set Firmware Parameters ............................................................................ 22
7 Set Control State .......................................................................................... 23
8 Get Control State ......................................................................................... 24
9 Sensor List ................................................................................................... 25
10 Gigabit Ethernet Link Sensor Assignment ................................................... 27
11 10 Gigabit Ethernet Link Sensor Assignment .............................................. 27
12 Thresholds - Standard and Extended Temperature Range ......................... 28
13 Voltage Sensor Thresholds .......................................................................... 28
14 OEM Event/Reading Types .......................................................................... 29
15 IOL/SOL Channel Assignment for the CP6004-SA/CP6004X-SA ............... 40
16 IOL/SOL Channel Assignment for the CP6004-RA/CP6004-RC ................. 40
17 IPMI and Hot Swap LEDs Function ............................................................. 46

Preface CP6004-SA/-RA/-RC/CP6004X-SA
This page has been intentionally left blank.
Page 8 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y

CP6004-SA/-RA/-RC/CP6004X-SA IPMI Firmware
ID 1053-0139, Rev. 3.0 Page 9
D R A F T — F O R I N T E R N A L U S E O N L Y
1. Introduction
1.1 Terminology and Acronym Definitions
The following table provides descriptions for terms and acronyms used in this guide. The de-
scriptions are derived primarily from the IPMI specifications.
Table 1: Terminology and Acronym Definitions
TERM or ACRONYM DESCRIPTION
BMC Baseboard Management Controller
Each board is equipped with an IPMI controller acting either as a BMC or as an SMC.
However, in a CompactPCI chassis, there can be only one BMC present. The BMC
administrates the SEL and the SDRR for the complete system. The BMC is connected
to the other boards in the shelf via a dedicated bus (IPMB-0). The CP6004-SA/-RA/-
RC/CP6004X-SA’s IPMI controller can be configured to operate in SMC mode or in
BMC mode via an IPMI OEM command or an uEFI Shell command. The factory
setting is SMC.
BSP Board Support Package
FRU Field Replaceable Unit
Every board is a FRU. The FRU data contains information about the board such as
the part number and the serial number. See PICMG Specification 2.9 for complete
details on the FRU data structure. The free Linux tool “ipmitool” can be used to
update or display the FRU data.
FWH Firmware Hub memory location where a complete uEFI BIOS code is stored.
I2CInter-Integrated Circuit
IPMB Intelligent Platform Management Bus
The dedicated I2C management bus where the BMC and the SMCs communicate.
IPMB-0 Intelligent Platform Management Bus which connects all SMCs with the BMC or the
shelf manager.
IPMI Intelligent Platform Management Interface
IOL IPMI over LAN. An IPMI controller is accessed via LAN, not IPMB.
KCS Keyboard Controller Style (Interface)
This is the IPMI mandatory interface on the host system (payload) to communicate
with the BMC.
MP Management Power
This powers the BMC or the SMC controller.
PICMG PCI Industrial Computer Manufacturer Group

IPMI Firmware CP6004-SA/-RA/-RC/CP6004X-SA
Page 10 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
PWR Payload Power
This powers the host side of the board where the application software runs. It is
granted by the BMC or the SMC after all prerequisites are met. Prerequisites can be,
for example, a closed handle switch, power on the backplane, etc.
SDR Sensor Data Record
This is the IPMI data structure that defines a sensor.
SDRR Sensor Data Record Repository
The SDRR is located in the BMC and contains all SDRs of the chassis’ boards that
are administrated. A free Linux utility named “ipmitool” makes a full chassis discovery
and fills the SDRR with the SDRs being found.
SEL System Event Log
The SEL is located in the BMC and keeps track of all events in the chassis. If an
event occurs on any board, the sensor event is sent through the IPMB bus to the
BMC, which additionally stores its own events as well.
SMBIOS System Management BIOS
SMC Satellite Management Controller
Each board is equipped with an IPMI controller acting either as a BMC or as an SMC.
In a CompactPCI chassis, there can be several SMCs. The SMC administrates the
sensor and FRU data of the CP6004-SA/-RA/-RC/CP6004X-SA and makes it avail-
able to the BMC. Each SMC can be connected to the BMC via a dedicated bus (IPMB-
0). The CP6004-SA/-RA/-RC/CP6004X-SA’s IPMI controller can be configured to
operate in SMC mode or in BMC mode via an IPMI OEM command or an uEFI Shell
command. The factory setting is SMC.
SMS System Management Software (designed to run under the OS)
SOL Serial over LAN
A serial interface is redirected by LAN using the RMCP+ protocol.
Table 1: Terminology and Acronym Definitions (Continued)
TERM or ACRONYM DESCRIPTION

CP6004-SA/-RA/-RC/CP6004X-SA IPMI Firmware
ID 1053-0139, Rev. 3.0 Page 11
D R A F T — F O R I N T E R N A L U S E O N L Y
1.2 Related Publications
The following publications contain information relating to this product.
1.3 IPMI Overview
This product fully supports the Intelligent Platform Management Interface and the PICMG 2.9
R1.0 specifications. All of its IPMI functionality operates under an autonomous management
controller even if the board is held in reset or power-down mode by a management card within
a system designed for high availability.
While the CP6004-SA/-RA/-RC/CP6004X-SA IPMI implementation is fully compliant with IPMI
v2.0 and has been designed to operate with any system management software (SMS) that re-
spects this specification, can be easily integrated with the ServiceAvailability Forum-Hardware
Platform Interface (SAF-HPI) specification.
More information about Service Availability can be found on the following website:
http://www.saforum.org/home
IPMI is an extensible and open standard that defines autonomous system monitoring. It is au-
tonomous because every management controller within a CompactPCI chassis monitors its
own sensors and sends critical events through a dedicated bus to the BMC that logs it into a
non-volatile System Event Log (SEL).The CP6004-SA/-RA/-RC/CP6004X-SA IPMI implemen-
tation includes a device SDR repository module that allows the user's system management
software to detect all system components and build a database of all management controller
sensors.
For further information concerning IPMI refer to the following website:
http://www.intel.com/design/servers/ipmi/
Table 2: Related Publications
PRODUCT PUBLICATION
IPMI IPMI Specification V2.0
IPMI IPMI- Platform Management FRU Information Storage Definition v1.0,
Document Revision 1.1
IPMI Addenda, Errata, and Clarifications document revision 4 for IPMI v2.0 rev 1.0 spec-
ification
IPMI Intelligent Platform Management Bus Communications Protocol Specification v1.0
Document Revision 1.0, November 1999
IPMI IPMB v1.0 Address Allocation Document Revision 1.0, September 1998
PICMG CompactPCI System Management Specification PICMG 2.9 Rev. 1.0
CompactPCI Hot Swap Specification PICMG 2.1 Rev. 2.0
PICMG® AMC.0 R2.0, Advanced Mezzanine Card Base Specification, Nov. 15, 2006
CP6004-SA/
CP6004-RA/
CP6004-RC/
CP6004X-SA
CP6004-SA User Guide
CP6004-RA/CP6004-RC User Guide
CP6004X-SA User Guide
CP6004-SA/CP6004-RA/CP6004-RC/CP6004X-SA uEFI BIOS User Guide
Linux Board Support Package for the CP6004-SA/CP6004-RA/CP6004-RC/CP6004X-SA
IPMI Tools OpenIPMI documentation: http://www.openipmi.sourceforge.net

IPMI Firmware CP6004-SA/-RA/-RC/CP6004X-SA
Page 12 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
2. IPMI Setup
2.1 IPMI in a CompactPCI Chassis
Kontron's IPMI implementation in the CompactPCI environment is compliant with the PICMG
2.9 R1.0 specification. This specification defines the pinout of the J1 and J2 CompactPCI con-
nectors as well as the addressing scheme. There should be only one BMC in the chassis, or at
least on the IPMB segment. The BMC mayreside eitheron anCP6004-SA/-RA/-RC/CP6004X-
SA, or on an external system management card, or in a shelf management controller (ShMC).
The specification allows all of these variants. As a BMC in the system slot, the CP6004-SA/-
RA/-RC/CP6004X-SA supports dual-ported IPMB (IPMB-0 to the SMCs and IPMB-1 to the ex-
ternal segments via the CompactPCI backplane connector in accordance with PICMG 2.9).
To use the IPMI resources in a rack requires an initial setup for IPMI operation. The following
actions must first be performed to achieve operable IPMI functionality.
2.2 IPMI Setup for the CP6004-SA/-RA/-RC/CP6004X-SA
Initially the default configuration for the board’s IPMI controller is:
•IRQ=11
• MODE = SMC
• IPMB = single-ported.
If this is the required configuration, no further action is required. If the configuration must be
modified, either the kipmi uEFI Shell command or one of the open-source tools “ipmitool” or
“ipmicmd” may be used to modify the configuration as required.
BMC
IPMB
Address
Fix: 20h
Backplane
SMC
IPMB
Address:
B0h(1)
SMC
IPMB
Address:
B2h(1)
SMC
IPMB
Address:
B4h(1)
SMC
IPMB address for SMC is determined via the location of the slot in the chassis
IPMB
Address:
B6h
SMC
IPMB
Address:
B8h(1)
(1)
SMC
IPMB
Address:
BAh(1)
SMC
IPMB
Address:
BCh(1)
IPMB 0
IPMB 0
(1)
IPMB 1

CP6004-SA/-RA/-RC/CP6004X-SA IPMI Firmware
ID 1053-0139, Rev. 3.0 Page 13
D R A F T — F O R I N T E R N A L U S E O N L Y
For further information on the kipmi uEFI Shell command, refer to the CP6004-SA/CP6004-
RA/CP6004-RC/CP6004X-SA uEFI BIOS User Guide. When uEFI BIOS stores the configura-
tion, it creates an “IPMI Device Information Record” entry in the SMBIOS table. This record
contains information, among others, about:
• Type of the supported interface (KCS style)
• Selected interrupt (11 or none).
This information is required by the CP6004-SA/-RA/-RC/CP6004X-SA payload’s IPMI OS ker-
nel drivers for Linux during their loading time. After the loading, most available IPMI communi-
cations tools which access the IPMI controller via IPMI OS drivers should work (e.g. “ipmicmd”,
“ipmitool”, etc.).
Now it is possible to use such a tool to issue the Set Firmware Parameters OEM IPMI
command to modify the configuration again. Changing the interrupt number always requires an
uEFI BIOS restart for a correct setup of the SMBIOS table.
2.3 IPMI Setup for the Rack
For a working IPMI configuration the SDRR of the BMC must be filled with all sensor data re-
cords of all IPMI controllers in the rack. After every system start the BMC uses the SDRR to
initialize all sensors of all boards. The SDRR setup must be done by a management tool, e.g.
the open-source tool “ipmitool”, after system modification. Then the command is:
This will work only if the IPMI controller configured as BMC is addressed. This addressing is
the default if the “ipmitool” is running on the payload side of the board where the BMC is resid-
ing.
3. IPMI Controller Hardware
The IPMI controller is implemented using the NXP ARM7 microcontroller with 512 kB of internal
flash and 56 kB of RAM.
An external 64 kB serial EEPROM chip is used for firmware private data and FRU inventory
storage. An additional external 2 MB serial SPI flash is used forredundant firmware imagestor-
age.
The IPMI controller implements a local Keyboard Controller Style (KCS) interface with interrupt
support for communication with system-side management software and the uEFI BIOS. The
IPMB bus is used for interconnection with the BMC or the shelf manager.
IPMI over LAN (IOL) and Serial Over LAN (SOL) are supported on four Ethernet channels of
the board (refer to Chapter 14.1 for information on the IOL/SOL channel assignment). SOL is
only available on one Ethernet channel at a time.
The IPMI controller provides access to various board sensors which permit the monitoring of:
• System power voltages: 5V (PWR), 3.3V, IPMI 5V, 12V, IPMI controller supply 4.7V
• Temperatures: CPU die, chipset, and board temperature
• Power Good, IPMB-0 link, board reset, POST code, boot error, CPU states (processor
hot, THERMTRIP, …), IPMB state, Health error, IPMI watchdog etc.
ipmitool sdr fill sensors

IPMI Firmware CP6004-SA/-RA/-RC/CP6004X-SA
Page 14 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
4. IPMI Firmware
4.1 Key Features
The following are key features of the CP6004-SA/-RA/-RC/CP6004X-SA’s IPMI firmware:
• Compliant with the IPMI specification 2.0
• Compliant with the PICMG 2.9 specification
• Firmware designed and specially made for CompactPCI implementation and easy
integration with SAF-HPI
• KCS SMS interface with interrupt support
• Dual-port IPMB support
• Out-of-band management and monitoring using the IPMB interface permits access to
sensors regardless of the board's CPU state
• Sensor thresholds fully configurable
• Sensor names prefixed with identification of owner (BMC without slot number or SMC
with slot number)
• Complete IPMI watchdog functionality
• Complete SEL, SDR repository and FRU functionality on BMC
• Complete FRU functionality
• Master Write-Read I2C support for external I2C devices communications (FRU,
EEPROM, FAN)
• Two IPMI firmware banks allow an automatic backup
This allows manual and automatic firmware image roll-back (in case of an upgrade
failure).
• The downloading of a new firmware image does not break currently running firmware or
payload activities.
• Firmware bank management is done by the open-source tool “ipmitool”, mode “fwum” or
“hpm”, which can update the firmware in the field.
• Firmware fully customizable via OEM IPMI commands to satisfy customer requirements
• Interoperable with other IPMI solutions
• OEMboardsupervisionandcontrol extensionssuch as boot flashselection andfirmware
boot order configuration
• uEFI BIOS fail-over control by automatic selection of the recovery SPI boot flash in the
event a non-working uEFI BIOS is detected
• IPMI over LAN (IOL) support
• Serial over LAN (SOL) support (on request)
• Graceful shutdown support
• Handle switch and blue Hot Swap LED operation
• The I0 and I1 LEDs indicate operational status of the IPMI firmware.
• The board's write protection feature for non-volatile memories is supported. These
memories are:
•I
2C EEPROM for FRU data
• SPI flash memory for firmware banks

CP6004-SA/-RA/-RC/CP6004X-SA IPMI Firmware
ID 1053-0139, Rev. 3.0 Page 15
D R A F T — F O R I N T E R N A L U S E O N L Y
5. Supported IPMI and ATCA Commands
5.1 Standard IPMI Commands
The following table shows an excerpt from the command list specified in the IPMI specification
2.0. The shaded table cells indicate commands supported by the CP6004-SA/-RA/-RC/
CP6004X-SA IPMI firmware.
M = mandatory, O = optional
Table 3: Standard IPMI Commands
COMMAND IPMI 2.0
SPEC.
SECTION NETFN CMD
KONTRON
SUPPORT
ON IPMI
CONTROLLER
IPM DEVICE “GLOBAL” COMMANDS M
Get Device ID 20.1 App 01h M / Yes [1]
Cold Reset 20.2 App 02h O / Yes
Warm Reset 20.3 App 03h O / No
Get Self Test Results 20.4 App 04h O / Yes
Manufacturing Test On 20.5 App 05h O / No
Set ACPI Power State 20.6 App 06h O / Yes
Get ACPI Power State 20.7 App 07h O / Yes
Get Device GUID 20.8 App 08h O / No
Broadcast “Get Device ID” 20.9 App 01h M / Yes
BMC WATCHDOG TIMER COMMANDS O
Reset Watchdog Timer 27.5 App 22h O / Yes
Set Watchdog Timer 27.6 App 24h O / Yes
Get Watchdog Timer 27.7 App 25h O / Yes
BMC DEVICE AND MESSAGING COMMANDS O
Set BMC Global Enables 22.1 App 2Eh O / Yes
Get BMC Global Enables 22.2 App 2Fh O / Yes
Clear Message Flags 22.3 App 30h O / Yes
Get Message Flags 22.4 App 31h O / Yes
Enable Message Channel Receive 22.5 App 32h O / Yes
Get Message 22.6 App 33h O / Yes
Send Message 22.7 App 34h O / Yes
Read Event Message Buffer 22.8 App 35h O / Yes
Get BT Interface Capabilities 22.9 App 36h O / No

IPMI Firmware CP6004-SA/-RA/-RC/CP6004X-SA
Page 16 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
Get System GUID 22.14 App 37h O / No
Get Channel Authentication Capabilities 22.13 App 38h O / Yes
Get Session Challenge 22.15 App 39h O / Yes
Activate Session 22.17 App 3Ah O / Yes
Set Session Privilege Level 22.18 App 3Bh O / Yes
Close Session 22.19 App 3Ch O / Yes
Get Session Info 22.20 App 3Dh O / Yes
Get AuthCode 22.21 App 3Fh O / No
Set Channel Access 22.22 App 40h O / Yes
Get Channel Access 22.23 App 41h O / Yes
Get Channel Info 22.24 App 42h O / Yes
Set User Access 22.26 App 43h O / Yes
Get User Access 22.27 App 44h O / Yes
Set User Name 22.28 App 45h O / Yes
Get User Name 22.29 App 46h O / Yes
Set User Password 22.30 App 47h O / Yes
Activate Payload 24.1 App 48h O / Yes
Deactivate Payload 24.2 App 49h O / Yes
Get Payload Activation Status 24.4 App 4Ah O / Yes
Get Payload Instance Info 24.5 App 4Bh O / Yes
Set User Payload Access 24.6 App 4Ch O / Yes
Get User Payload Access 24.7 App 4Dh O / Yes
Get Channel Payload Support 24.8 App 4Eh O / Yes
Get Channel Payload Version 24.9 App 4Fh O / Yes
Get Channel OEM Payload Info 24.10 App 50h O / No
Master Write-Read 22.11 App 52h O / Yes
Get Channel Cipher Suits 22.15 App 54h O / No
Suspend/Resume Payload Encryption 24.3 App 55h O / Yes
Set Channel Security Keys 22.25 App 56h O / No
Get System Interface Capabilities 22.9 App 57h O / No
CHASSIS DEVICE COMMANDS O
Get Chassis Capabilities 28.1 Chassis 00h O / Yes
Table 3: Standard IPMI Commands (Continued)
COMMAND IPMI 2.0
SPEC.
SECTION NETFN CMD
KONTRON
SUPPORT
ON IPMI
CONTROLLER

CP6004-SA/-RA/-RC/CP6004X-SA IPMI Firmware
ID 1053-0139, Rev. 3.0 Page 17
D R A F T — F O R I N T E R N A L U S E O N L Y
Get Chassis Status 28.2 Chassis 01h O / Yes
Chassis Control 28.3 Chassis 02h O / Yes
Chassis Reset 28.4 Chassis 03h O / No
Chassis Identify 28.5 Chassis 04h O / No
Set Chassis Capabilities 28.7 Chassis 05h O / No
Set Power Restore Policy 28.8 Chassis 06h O / No
Get System Restart Cause 28.11 Chassis 07h O / No
Set System Boot Options 28.12 Chassis 08h O / No
Get System Boot Options 28.13 Chassis 09h O / No
Get POH Counter 28.14 Chassis 0Fh O / Yes
EVENT COMMANDS M
Set Event Receiver 29.1 S/E 00h M / Yes
Get Event Receiver 29.2 S/E 01h M / Yes
Platform Event (a.k.a. “Event Message”) 29.3 S/E 02h M / Yes
PEF AND ALERTING COMMANDS O
Get PEF Capabilities 30.1 S/E 10h O / No
Arm PEF Postpone Timer 30.2 S/E 11h O / No
Set PEF Configuration Parameters 30.3 S/E 12h O / No
Get PEF Configuration Parameters 30.4 S/E 13h O / No
Set Last Processed Event ID 30.5 S/E 14h O / No
Get Last Processed Event ID 30.6 S/E 15h O / No
Alert Immediate 30.7 S/E 16h O / No
PET Acknowledge 30.8 S/E 17h O / No
SENSOR DEVICE COMMANDS M
Get Device SDR Info 35.2 S/E 20h M / Yes
Get Device SDR 35.3 S/E 21h M / Yes
Reserve Device SDR Repository 35.4 S/E 22h M / Yes
Get Sensor Reading Factors 35.5 S/E 23h O / No
Set Sensor Hysteresis 35.6 S/E 24h O / Yes
Get Sensor Hysteresis 35.7 S/E 25h O / Yes
Set Sensor Threshold 35.8 S/E 26h O / Yes
Get Sensor Threshold 35.9 S/E 27h O / Yes
Table 3: Standard IPMI Commands (Continued)
COMMAND IPMI 2.0
SPEC.
SECTION NETFN CMD
KONTRON
SUPPORT
ON IPMI
CONTROLLER

IPMI Firmware CP6004-SA/-RA/-RC/CP6004X-SA
Page 18 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
Set Sensor Event Enable 35.10 S/E 28h O / Yes
Get Sensor Event Enable 35.11 S/E 29h O / Yes
Re-arm Sensor Events 35.12 S/E 2Ah O / No
Get Sensor Event Status 35.13 S/E 2Bh O / No
Get Sensor Reading 35.14 S/E 2Dh M / Yes
Set Sensor Type 35.15 S/E 2Eh O / No
Get Sensor Type 35.16 S/E 2Fh O / No
FRU DEVICE COMMANDS M
Get FRU Inventory Area Info 34.1 Storage 10h M / Yes
Read FRU Data 34.2 Storage 11h M / Yes
Write FRU Data 34.3 Storage 12h M / Yes
SDR DEVICE COMMANDS O
Get SDR Repository Info 33.9 Storage 20h O / Yes
Get SDR Repository Allocation Info 33.10 Storage 21h O / Yes
Reserve SDR Repository 33.11 Storage 22h O / Yes
Get SDR 33.12 Storage 23h O / Yes
Add SDR 33.13 Storage 24h O / Yes
Partial Add SDR 33.14 Storage 25h O / Yes
Delete SDR 33.15 Storage 26h O / Yes
Clear SDR Repository 33.16 Storage 27h O / Yes
Get SDR Repository Time 33.17 Storage 28h O / No
Set SDR Repository Time 33.18 Storage 29h O / No
Enter SDR Repository Update Mode 33.19 Storage 2Ah O / No
Exit SDR Repository Update Mode 33.20 Storage 2Bh O / No
Run Initialization Agent 33.21 Storage 2Ch O / Yes
SEL DEVICE COMMANDS O
Get SEL Info 40.2 Storage 40h O / Yes
Get SEL Allocation Info 40.3 Storage 41h O / Yes
Reserve SEL 40.4 Storage 42h O / Yes
Get SEL Entry 40.5 Storage 43h O / Yes
Add SEL Entry 40.6 Storage 44h O / Yes
Table 3: Standard IPMI Commands (Continued)
COMMAND IPMI 2.0
SPEC.
SECTION NETFN CMD
KONTRON
SUPPORT
ON IPMI
CONTROLLER

CP6004-SA/-RA/-RC/CP6004X-SA IPMI Firmware
ID 1053-0139, Rev. 3.0 Page 19
D R A F T — F O R I N T E R N A L U S E O N L Y
[1] Has OEM extensions. Please refer to 6.1, Get Device ID Command with OEM Extensions.
Partial Add SEL Entry 40.7 Storage 45h O / No
Delete SEL Entry 40.8 Storage 46h O / Yes
Clear SEL 40.9 Storage 47h O / Yes
Get SEL Time 40.10 Storage 48h O / Yes
Set SEL Time 40.11 Storage 49h O / Yes
Get Auxiliary Log Status 40.12 Storage 5Ah O / No
Set Auxiliary Log Status 40.13 Storage 5Bh O / No
LAN DEVICE COMMANDS O
Set LAN Configuration Parameters 23.1 Transport 01h O / Yes
Get LAN Configuration Parameters 23.2 Transport 02h O / Yes
Suspend BMC ARPs 23.3 Transport 03h O / No
Get IP/UDP/RMCP Statistics 23.4 Transport 04h O / Yes
SERIAL/MODEM DEVICE COMMANDS O
Set Serial/Modem Configuration 25.1 Transport 10h O / No
Get Serial/Modem Configuration 25.2 Transport 11h O / No
Set Serial/Modem Mux 25.3 Transport 12h O / No
Get TAP Response Codes 25.4 Transport 13h O / No
Set PPP UDP Proxy Transmit Data 25.5 Transport 14h O / No
Get PPP UDP Proxy Transmit Data 25.6 Transport 15h O / No
Send PPP UDP Proxy Packet 25.7 Transport 16h O / No
Get PPP UDP Proxy Receive Data 25.8 Transport 17h O / No
Serial/Modem Connection Active 25.9 Transport 18h O / No
Callback 25.10 Transport 19h O / No
Set User Callback Options 25.11 Transport 1Ah O / No
Get User Callback Options 25.12 Transport 1Bh O / No
SOL Activating 26.1 Transport 20h O / Yes
Set SOL Configuration Parameters 26.2 Transport 21h O / Yes
Get SOL Configuration Parameters 26.3 Transport 22h O / Yes
Note ...
Some of the above-mentioned commands, such as SDR commands, work
only if the IPMI controller is configured as BMC. For further information, refer
to the IPMI specification 2.0.
Table 3: Standard IPMI Commands (Continued)
COMMAND IPMI 2.0
SPEC.
SECTION NETFN CMD
KONTRON
SUPPORT
ON IPMI
CONTROLLER

IPMI Firmware CP6004-SA/-RA/-RC/CP6004X-SA
Page 20 ID 1053-0139, Rev. 3.0
D R A F T — F O R I N T E R N A L U S E O N L Y
5.2 AdvancedTCA and AMC Commands
The following table shows an excerpt from the command list specified in the PICMG 3.0 R 2.0
AdvancedTCA Base Specification and the PICMG AMC.0 Advanced Mezzanine Card Specifi-
cation, R 1.0. The shaded table cells indicate commands supported by the IPMI firmware.
M = mandatory
Table 4: AdvancedTCA and AMC Commands
COMMAND PICMG 3.0
SPEC.
TABLE NETFN CMD
KONTRON
SUPPORT
ON IPMI
CONTROLLER
AdvancedTCA M
Get PICMG Properties 3-9 PICMG 00h M / Yes
Get Address Info 3-8 PICMG 01h N/A
Get Shelf Address Info 3-13 PICMG 02h N/A
Set Shelf Address Info 3-14 PICMG 03h N/A
FRU Control 3-22 PICMG 04h N/A
Get FRU LED Properties 3-29 PICMG 05h M / Yes
Get LED Color Capabilities 3-25 PICMG 06h M / Yes
Set FRU LED State 3-26 PICMG 07h M / Yes
Get FRU LED State 3-27 PICMG 08h M / Yes
Set IPMB State 3-51 PICMG 09h N/A
Set FRU Activation Policy 3-17 PICMG 0Ah N/A
Get FRU Activation Policy 3-18 PICMG 0Bh N/A
Set FRU Activation 3-16 PICMG 0Ch N/A
Get Device Locator Record ID 3-29 PICMG 0Dh M / Yes
Set Port State 3-41 PICMG 0Eh N/A
Get Port State 3-42 PICMG 0Fh N/A
Compute Power Properties 3-60 PICMG 10h N/A
Set Power Level 3-62 PICMG 11h N/A
Get Power Level 3-61 PICMG 12h N/A
Renegotiate Power 3-66 PICMG 13h N/A
Get Fan Speed Properties 3-63 PICMG 14h N/A
Set Fan Level 3-65 PICMG 15h N/A
Get Fan Level 3-64 PICMG 16h N/A
Bused Resource 3-44 PICMG 17h N/A
Get IPMB Link Info 3-49 PICMG 18h N/A
