EMCtools Microbox User manual

Fiber optic RS-485 transceiver
Microbox
EMCtools
Dipl.-Ing. (FH) Armin Lenk
Meginhardstrasse 50
88356 Ostrach-Magenbuch
Germany
Tel: [phone]
Mobile: [phone]
[email protected]
EMCtools –lab life made easy

Microbox
©2019 –EMCtools. All rights reserved. Subject to change (V1) Page 2 von 8
1. Introduction
Functional tests e.g. in test-labs often require insulated RS-485 bus installations to control and
monitor the device under test. For this purpose special Fiber Optic RS-485 transceivers are
available. They allow data transmission of RS-485 signals via fiber optic cables and can be used
during susceptibility tests at high field strength levels.
Our EMCtools Microbox has been designed for emission and susceptibility tests. Using multilayer
technology and sophisticated circuit design full RS-485 compatibility and the ability to perform
tests at electromagnetic field levels of 270 V/m and above could be achieved. The handy plastic
housing allows tests with limited test space and a minimum of impact on the field.
The EMCtools Microbox uses standard multimode fiber optic cables and allows direct connection
to the electric bus via SUB-D female connectors.
2. EMCtools Microbox RS-485
The Microbox is built into a handy, rugged plastic housing (65x66x27mm).
Power is supplied externally e.g. by using an external battery or power-supply.
Fig. 1: Front Panel Microbox RS-485
No. in
Fig. 1:
Description
1
Power supply (DC Power Jack 5.5/2.1mm)
2
Control-LEDs:
Green: Power on/off status and supply voltage
LED off when supply voltage less than 7V
Red: RXD and TXD (receive and transmit data)
3
9-pin Sub-D connector for bus-connection
An illuminated green LED (Fig.1 –No.2) indicates the operating status of the Microbox.
A first red LED (Fig.1 –No.2) indicates the status „RXD“ (= receive-data).
It indicates that fiber optic data are received.
A second red LEDs (Fig.1 –No.2) indicates the status of „TXD“ (= transmit-data).
It indicates the transmission of fiber optic data.
The 9-pin Sub-D connector (Fig.1 –No.3) is used to connect the Microbox to the electrical RS-
485-bus. See chapter 4 for pinning details.




Microbox
©2019 –EMCtools. All rights reserved. Subject to change (V1) Page 3 von 8
Fig.2: Rear panel
No. in
Fig.2:
Description
1
Fiber optic connector TXD (Transmitter)
2
Fiber optic connector RXD (Receiver)
3
Power on/off toggle switch
On the rear panel you can find the F-SMA connectors „TXD“ and „RXD“ for the fiber optic data
transmission (Fig.2 –No.1 and 2) . Here the fiber optic cables are connected.
The „TXD“ (= transmit-data) labeled connector is the transmitter and the „RXD“ (= receive-data)
labeled connector is the receiver of the fiber optic data transmission.
The Microbox is put into and is taken out of operation by using the toggle switch (Fig.2 –No.3).
3. Setup of EMCtools Microbox RS-485
The setup for operating a fiber optic data transmission for RS-485 using the Microbox is easy:
1. Connect two transceivers with a duplex fiber optic cable:
- connect Microbox No.1 „TXD“ with Microbox No.2 „RXD“
- connect Microbox No.1 „RXD“ with Microbox No.2 „TXD“
2. Connect the electrical RS-485-bus cables with attached cable ferrites to the Sub-D
connectors of both Microboxes (see chapter 4 for Sub-D pinning)
3. Set the Microbox RS-485 bus termination options (see chapter 5)
4. Plug in the power cables with attached cable ferrites acc. Photo 1 and connect power
5. Switch on both Microboxes
Photo 1: Microbox Setup
Fiber Optic Cables



RS-485 BUS Cable
Power supply Cable

Microbox
©2019 –EMCtools. All rights reserved. Subject to change (V1) Page 4 von 8
Fig.5: Microbox RS-485 setup in test environment
4. Pinning of 9-pin Sub-D connector
Sub-D
Pin #
Description
1
n.c.
2
n.c.
3
RS-485 +
4
n.c.
5
GND
6
n.c.
7
RS-485 -
8
n.c.
9
n.c.
5. Setting the Jumper options of the EMCtools Microbox RS-485
4 different termination modes for the RS-485 bus can be set using jumpers.
These jumpers can easily be accessed through a hole in the Microbox RS-485 housing top.
Photo 2: Microbox with Jumpers
One EMCtools Microbox RS-
485 is put into the test
environment.
It is connected to a second
Microbox RS-485 at the
control site using a duplex
fiber optic cable
Jumpers

Microbox
©2019 –EMCtools. All rights reserved. Subject to change (V1) Page 5 von 8
To check the fiber optic connection without a bus signal the „Test“-jumper may be used. The
TXD-LED of the Microbox with the jumper set then transmits permanently and the RXD-
Signal LED on the other end of the optical cable can be checked. During this test the control-
LED RXD of the second Microbox should be permanently on. Remove the „Test“-jumper for
proper bus operation.
RS-485 bus physical layer is described in EIA-485.
A printed label on the Microbox housing shows jumper setting options.
The “Test”-Jumper may be set at any time independent of the other jumper setting.
No Termination
Termination 60 Ohm
Termination 120 Ohm
Bias Termination 120 Ohm (standard setting)
Test off Test on

Microbox
©2019 –EMCtools. All rights reserved. Subject to change (V1) Page 6 von 8
6. Bus frontend circuit of EMCtools Microbox RS-485
Fig.4: EMCtools Microbox RS-485 bus frontend
7. ESD Protection:
Microbox RS-485 is protected against electrostatic discharge in lab use.
This built in protection is not sufficient if you intend to perform ESD tests.
Here an additional ESD protection is needed.
Please contact EMCtools for details.
8. Delivered devices of the system and accessories:
Microbox RS-485-Set:
2 pcs EMCtools Microbox RS-485
1 pcs printed manual
2 pcs power supply cable (1m) with cable ferrite (DC-plug: Switchcraft S761K)
2 pcs cable ferrite for the bus-line (Ferrite: Würth Part-No: 74271142)
9. Available accessories:
a) rechargeable Battery Box for EMCtools Microbox (Mod. 350)
- to be used inside the EMC chamber
- to be used for ESD-Tests in combination with EMCtools ESD-Protector
b) Plug-In wall supply for EMCtools Microbox (Mod. 165 or Mod.167)
- to be used outside the EMC chamber

Microbox
©2019 –EMCtools. All rights reserved. Subject to change (V1) Page 7 von 8
10. Technical data EMCtools Microbox RS-485:
Microbox RS-485:
Max. Bitrate: > 128 kBit/s
Power-Supply: 9 –15V DC (7V min)
max. 50mA (depending on DC output current)
DC Power Jack 2.1mm, center pin positive, reverse polarity protected
Fiber optic: F-SMA, duplex 50/125µm or 62.5/125µm
BUS-connector: 9-pin Sub-D (female)
BUS-termination: infinite, 60 Ohm, 120 Ohm and 120 Ohm biased
Temperature range: operating: -40 –85oC (-40 –185oF)
storage: -40 –85oC (-40 –185oF)
Housing Size: 66 x 65 x 27 mm (66 x 85 x 27 mm incl. connector jack / switch)
Weight: 85 g

Microbox
©2019 –EMCtools. All rights reserved. Subject to change (V1) Page 8 von 8
Dipl.-Ing. (FH) Armin Lenk
Meginhardstrasse 50
88356 Ostrach –Magenbuch
Germany
Declaration of Conformity
Hereby we declare, that our product is compliant with the CE directives and
standards listed below.
Product: EMCtools Microbox
Model: RS-485 Bus
Directives: 2004/108/EG (EMC)
Standards: DIN EN 61326-1 (2006)
DIN EN 61000-4-3 (2008)
DIN EN 61000-4-2 (2009)
DIN EN 55022 (2008)
Tested Setup: Typical setup for fiber optic conversion of
bus, locally supplied by battery.
Ostrach, July 27nd 2019
Lenk
Dipl.-Ing. (FH)
