EMR BDAMON02-MODEM User manual

BDAMON02-MODEM
Bi-Directional Power Amplifier Monitor
EMR CORPORATION
17431 N. 25th Avenue - Phoenix, Arizona 85023
Phone: [phone] - Toll Free: [phone] - Fax: [phone]
[e-mail] – www.emrcorp.com
USERS MANUAL
Rev. 7

Table of Contents
BDAMON02-MODEM Manual – V3.D1
BDAMON02-MODEM
© 2019 EMR Corporation
Introduction and Features
System Requirements
Physical Connectivity
Programming the BDA Monitor
Using Menus
Programming the Com Port
Setup Menu
Alarm Menu
Misc. Menu
Data String
Password Menu
Auto Dialer Menu
Modem Setup Menu
View Current Readings & Alarms
Resetting Alarms
Clock Setup
Hookup Diagram
Programming Flow Chart
U.S. FCC Part 68 Statement
.........................................................1
.............................................................1
..............................................................2
.....................................................3
......................................................................4
.......................................................4
.......................................................................5
.......................................................................5
.......................................................................6
.........................................................................7
....................................................................7
..................................................................8
..............................................................8
..................................................9
..................................................................9
.......................................................................9
.................................................................10
.........................................................10
......................................................11

1
BDAMON02-MODEM USERS MANUAL
BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
Introduction
The EMR BDA Monitor (Model #BDAMON02-MODEM) is a microprocessor-controlled unit
capable of monitoring the Primary AC, Power Supply/Battery DC Voltage, and the DC
Current for up to four RF amplifiers used in any EMR Signal Enhancement System. BDA
monitoring features vary depending on the relevant hardware configuration. This
documentation covers features which are common to most users.
Product Features:
• Monitoring for up to four RF Power Amplifiers
• Programmable using a standard terminal program direct or modem
• User programmable alarm set points
• 1 Relay Output Contact Closure
• Auto Dialer and 9600 Baud Modem
• LED Status Indicators
• AC Alarm
• Door Alarm
System Requirements:
• EMR Signal Enhancement Bi-Directional System
• IBM compatible computer with Com Port
• HyperTerminal or similar communication software package
• Standard Serial Cable

2BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
BDAMON02-MODEM USERS MANUAL
Physical Connectivity
The BDA monitor comes pre-installed in an EMR Bi-Directial Amplifier (BDA) system. When
the BDA system is plugged into a reliable power source the power indicators on the monitor
unit will light/glow. Connect the telephone line included to the RJ11 cable to the port located
at the base of the BDA enclosure.
The door alarm switch triggers an audible and LED alarm as the door opens. The alarm
must be reset from the web interface or reset button on the front of the monitoring unit before
the door is closed and the hysteresis period has lapsed.
Power Amplifier #1
Amplifier Connections
(J1 Plug)
Power Amplifier #2
Door Alarm Switch
Phone Line
COM Port
Power Amplifier #1
Amplifier Connections
(J1 Plug)
Power Amplifier #2
Door Alarm Switch
Phone Line
COM Port

3
BDAMON02-MODEM USERS MANUAL
BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
Programming the BDA Monitor
Open your communications software such as HyperTerminal in your computer. Set up a
COM port at 19200 baud 8, n, 1 flow control: none. Connect a serial cable from the COM
port of your computer to the DB-9 port of the BDA Monitor.
The BDA Monitor’s programming proceeds through a hierarchy of menus.
Press <Enter> once on your computer. The following screen should appear:
Fig. 1
The default password is “123456”. Enter this to load the Main Menu screen.
Fig. 2
Enter Password >
************************************************
EMR Corp. BDAMON2MODEM V1.021
************************************************
Main Menu
Select The Following
A>> Com Port Setup
B>> Alarm and Misc. Setup
C>> Auto Dialer Setup
D>> Modem Setup
E>> View Current Readings & Alarms
F>> Reset Alarms
G>> Clock Setup
X>> Exit
>

4BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
BDAMON02-MODEM USERS MANUAL
Using Menus
A menu option is selected by pressing the corresponding letter. For example to load the
Alarm and Misc. Setup Menu, press “B” in the “Main Menu“. In the “Setup Menu” press “X” to
return to the “Main Menu” screen.
Programming the Com Port
Press “A” from the “Main Menu” to display the “Com Port Menu”. Fig. 3 indicates the current
Baud Rate as 19200.
Fig. 3
Choose the desired Baud rate or type in a custom setting. By pressing “A” the Baud Rate will
change to 9600.
Fig. 4
Note: The current Baud rate remains until the user exits the programming mode.
Press “X” to exit and return to the main menu.
************************************************
EMR Corp. BDAMON2MODEM V1.021
************************************************
Com Port Menu
Select The Following
A>> Current Baud Rate: 19200
X>> Exit
>
A>> 9600 Baud
B>> 19200 Baud
Enter New Setting [X to Exit] >

5
BDAMON02-MODEM USERS MANUAL
BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
Setup Menu
Pressing “B” from the “Main Menu” displays the “Setup Menu”. This menu displays the
following options:
• Change Alarm Set points
• Change Miscellaneous Settings
• Change the Password
Fig. 5
Alarm Menu
Pressing “A” from the “Setup Menu” displays the “Alarm Setup” menu (Fig. 6). This menu the
displays the following options:
• Change the four Amp Low and High Current Alarms
• Change the DC Voltage Low and High Alarms
• Enable or Disable the AC Sense Alarm
• Enable or Disable the Door Alarm
• Enable or Disable the Audible Alarm
Fig. 6
************************************************
EMR Corp. BDAMON2MODEM V1.021
************************************************
Setup Menu
Select The Following
A>> Alarm Menu
B>> Misc. Menu
C>> Password Setup
D>> Modem Setup
E >> Current Readings & Alarms
F >> Reset Alarm
G>> Clock Setup
X>> Exit
************************************************
EMR Corp. BDAMON2MODEM V1.021
************************************************
Alarm Setup
Select The Following
A>> Amp #1 Current Low Alarm = Disabled
B>> Amp #1 Current High Alarm >=Disabled
C>> Amp #2 Current Low Alarm = Disabled
D>> Amp #2 Current High Alarm >=Disabled
E>> Amp #3 Current Low Alarm = Disabled
F>> Amp #3 Current High Alarm >=Disabled
G>> Amp #4 Current Low Alarm = Disabled
H>> Amp #4 Current High Alarm >=Disabled
I>> DC Voltage Low Alarm <=12.00 Vdc
J>> DC Voltage High Alarm >=14.90 Vdc
K>> AC Alarm =Disabled
L>> Door Alarm=Disabled
M>> Audible Alarm=Disabled
X>> Exit
>

6BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
BDAMON02-MODEM USERS MANUAL
Alarm Menu (continued)
From this screen the user can either view the current settings or edit.
For example, to change the “Amp #1 Current Low Alarm” press the “A” key and the “Current
Amp #1 Low Alarm” is displayed followed by the “Enter New Setting” prompt.
Fig. 7
To disable or enable a port press “D” to disable the alarm or “E” to enable.
Enter the new setting and press <Enter> or “X” to Exit.
Misc. Menu
Press “B” from the “Setup Menu” to display the “Misc. Setup” menu (Fig. 8). This menu
displays the following options:
Fig. 8
Note: Options A, B & C are factory settings and not user changeable.
Current Amp #1 Low Alarm <= 0.20 Amps
Enter New Setting
[D to Disable E to Disable X to Exit] >
************************************************
EMR Corp. BDAMON2MODEM V1.021
************************************************
Misc. Setup
Select The Following
A>> Recalibrate Unit
B>> Recalibrate Counter = 0
C>> TP-1 Voltage = 13.60
D>> Hysteresis (0 to 255) = 10
E>> Data String = Disabled
X>> Exit
>

7
BDAMON02-MODEM USERS MANUAL
BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
Data String
Changing the “E” Data String line to “Enabled” will send a comma delimited string in the
following format out the Com Port.
Time: Date, Door, Door Alarm, DC Voltage, DC Alarm, AC, AC Alarm, Port#1 Current, Port#1 Alarm,
Port#2 Current, Port#2 Alarm, Port#3 Current, Port#3 Alarm, Port#4 Current, Port#4 Alarm
For Example:
14:42:9/28/2010, 0, 0, 13.80, 0, 0, 0, 0.25, 0, 1.20, 0, 0.27, 0, 0.00,1
Translates to:
14:42:9,9/28/2010, Door Closed, no alarm, 13.80 VDC, no alarm, AC on, no alarm, 0.25
Amps on Amp #1, no alarm, 1.20 Amps on Amp #2, no alarm, 0.27 Amps on Amp #3, no
alarm, 0.00 Amps on Amp #4, alarm on
Password Menu
Press “C” from the “Setup Menu” to display the “Password Setup” menu (Fig. 9). This menu
displays the following option:
Fig. 9
Press “A” to change the password.
************************************************
EMR Corp. BDAMON2MODEM V1.021
************************************************
Password
Select The Following
A>> Password = 123456
X>> Exit
>

8BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
BDAMON02-MODEM USERS MANUAL
Auto Dialer Menu
Press “C” from the Main Menu to display the “Auto Dialer Setup” (Fig. 10). This menu
displays the following options:
• Change the Auto Dialer telephone numbers (2 available)
• Disable telephone #1 or telephone #2 or both telephone numbers
• Set the length of call from 15 to 60 seconds
• Enable or Disable Hourly Alarms
Fig. 10
Note: To dial a numeric pager use “,” to pause the output for 2 seconds before the next digit
is sent. For example: 1-555-555-5555,,,,,12345 dials 1-555-555-5555 then waits 10 seconds
then dials 12345.
Modem Setup Menu
Press “D” from the Main Menu to display the “Modem Setup” (Fig. 11). This menu displays
the following options:
• Select a Modem Baud Rate from 1200, 2400,4800 and 9600.
• Auto Answer from 0 to 255 Rings. Inputting “0” turns off auto answer.
Fig. 11
************************************************
EMR Corp. BDAMON2MODEM V1.021
************************************************
Auto Dialer Setup
Select The Following
A>>Telephone Number 1 = 7678900
B>>Telephone Number 2 = 7671111
C>>Length of Call = 15
D>> Redial Hourly Alerts = Disabled
X>> Exit
>
************************************************
EMR Corp. BDAMON2MODEM V1.021
************************************************
Modem Setup
Select The Following
A>> Modem Baud Rate = 9600 Baud
B>> Auto Answer = 1 Ring
X>> Exit
>

9
BDAMON02-MODEM USERS MANUAL
BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
View Current Readings & Alarms
Press “E” from the Main Menu to display “Current Readings & Alarms”.
Fig. 12
Resetting Alarms
Press “F” from the Main Menu to reset all alarms.
Fig. 13
To reset all alarms press the reset button on the unit.
Clock Setup
Press “G” from the Main Menu to display the “Clock Setup” menu. This menu displays the
following options:
• Change/View the Time
• Change/View the Date
• Refresh the Menu to see current time/date.
Fig. 13
************************************************
EMR Corp. BDAMON2MODEM V1.021
************************************************
Current Readings & Alarms
Door = Closed | Door Alarm = Off
DC Volts = 12.31 | DC Alarm = Off
AC = Off | AC Alarm = ON
Amp #1 Current = 1.30 Amps | Alarm = Off
Amp #2 Current = 1.32 Amps | Alarm = Off
Amp #3 Current = 0.00 Amps | Alarm = Off
Amp #4 Current = 0.00 Amps | Alarm = Off
First Alarm at: 12:59:28 9/28/2010
Press [E] or [V} To View again [X] to exit
Reset Alarm.
Are You Sure? [Y] or [N] > Y
Alarms are reset.
Clock Setup
Select The Following
A>> Time 15:26:07
B>> Date 09/28/2010
C>> Refresh Menu
X>> Exit

10 BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
BDAMON02-MODEM USERS MANUAL
Hookup Diagram
Programming Flow Chart
AMP 1 +
AMP 1 -
AMP 2 +
AMP 2 - AMP 3 -
AMP 3 +
DoorInput
Relay (COM)
Relay (NC)
Relay (NO)
AMP 4 -
AMP 4 +
Password
Entry
Main Menu
A
COM Port
Setup
B
Alarm & Misc.
Setup
C
Auto Dialer
Setup
D
Modem Setup
E
View Current
Readings & Alarms
F
Reset Alarms G Clock Setup
View Current
Baud Rate
A =Change
Select
A=9600 Baud
B= 19.200 Baud
A Alarm Setup
B =Misc Setup
C = Password Setup
A=Phone#1
B= Phone #2
C=Length of Call
A
Modem Baud
Rate
B
Auto Answer
A
Set Time
B
Set Date
C
RefreshMenu
A
Enter New
Number on D to
Usable orEto
Enable
B
Enter New
Number or D to
Disable or E to
Enable
C
Enter new Call
Length
(15-60 sec)
C
Password
& Setup
B
Change
Password
B
Misc Setup
D
Enter new
Hysteresis
E
Enable/Disable
Data String
A
Alarm Setup
A= View and
Select to Edit
Select and Edit
Amp. Settings
(1-4 ), DC
Settings, Alarm
Enable/Disable
(AC Alarm, Door
Alarm, Audible
Alarm)
Password
Entry
Main Menu
A
COM Port
Setup
B
Alarm & Misc.
Setup
C
Auto Dialer
Setup
D
Modem Setup
E
View Current
Readings & Alarms
F
Reset Alarms G Clock Setup
View Current
Baud Rate
A =Change
Select
A=9600 Baud
B= 19.200 Baud
A Alarm Setup
B =Misc Setup
C = Password Setup
A=Phone#1
B= Phone #2
C=Length of Call
A
Modem Baud
Rate
B
Auto Answer
A
Set Time
B
Set Date
C
RefreshMenu
A
Enter New
Number on D to
Usable orEto
Enable
B
Enter New
Number or D to
Disable or E to
Enable
C
Enter new Call
Length
(15-60 sec)
C
Password
& Setup
B
Change
Password
B
Misc Setup
D
Enter new
Hysteresis
E
Enable/Disable
Data String
A
Alarm Setup
A= View and
Select to Edit
Select and Edit
Amp. Settings
(1-4 ), DC
Settings, Alarm
Enable/Disable
(AC Alarm, Door
Alarm, Audible
Alarm)

11
BDAMON02-MODEM USERS MANUAL
BDAMON02-MODEM Manual – V3.D1
© 2019 EMR Corporation
U.S. FCC Part 68 Statement
This equipment complies with Part 68 of the FCC Rules. On this equipment is a label that
contains, among other information, the FCC registration number, and Ringer Equivalence
Number (REN) for this equipment. You must, upon request, provide this information to your
telephone company.
The REN for this product is part of the registration number that has this format:
[US: 3A4MM00BTM]
The digits shown after MM are the REN without the decimal point. (e.g., 00 is a REN of 0.0).
A plug and jack used to connect this equipment to the premises wiring and telephone network
must comply with applicable FCC Part 68 rules and requirements adopted by the ACTA.
If your telephone equipment causes harm to the telephone network, the Telephone Company
may discontinue your service temporarily. If possible, they will notify in advance. But, if
advance notice is not practical, you will be notified as soon as possible. You will be informed
of your right to file a complaint with the FCC.
Your telephone company may make changes in its facilities, equipment, operations, or
procedures that could affect proper operation of your equipment. If they do, you will be notified
in advance to give you an opportunity to maintain uninterrupted telephone service.
The FCC prohibits this equipment to be connected to party lines or coin-telephone service.
In the event that this equipment should fail to operate properly, disconnect the equipment from
the phone line to determine if it is causing the problem. If the problem is with the equipment,
discontinue use and contact your dealer or vendor.
The FCC also requires the transmitter of a FAX transmission be properly identified (per FCC
Rules Part 68, Sec. 68.381 (c) (3)).

17431 N. 25th Avenue – Phoenix, Arizona 85027
Tel: [phone] – Toll Free: [phone] – Fax: [phone]
www.emrcorp.com – [e-mail]
