Table Of Contents
3
Introduction 4
Installation 4
Step 1: Install the WZM and the ZIM 4
Step 2: Wiring 5
a) WZM to an Addressable Control Panel 5
b) WZM to System 5000 Control Panel 6
c) Remote WZM to System 5000 Control Panel, option 1 7
d) Remote WZM to System 5000 Control Panel, option 2 8
e) WZM to a Conventional Panel, option 1 9
f) WZM to a Conventional Panel, option 2 10
Wireless Zone Monitor Overview 11
Wireless Zone Monitor Display 11
Wireless Zone Monitor Rotary Control Operation 11
Wireless Zone Monitor Menu Structure 12
Step 3: Power Up the Devices 13
Step 4: Log On the Devices 14
Step 5: Install the Devices 16
Step 6: Check Signals 17
Frequently Asked Questions 19
WZM Fault Rectication 20
Troubleshooting (when connected to an Addressable Control Panel) 21
Troubleshooting (when connected to a System 5000 Control Panel) 21
How To Improve Device Signal Levels 22
www.acornfiresecurity.com
www.acornfiresecurity.com

4
Introduction
The EMS Wireless Zone Monitor (WZM) allows for 30 FireCell wireless devices to be
added to an existing Fire Alarm Control Panel, in conjunction with an EMS Zone
Interface Module (ZIM).
Existing
Fire Alarm
Control Panel
www.emsgroup.co.uk
RadioDetectorBase
PRESSHERETO
LOGON
IDENT
FireCell
Wireless
Devices
Wireless
Zone
Monitor
(WZM)
POWER
FAU LT
WIRELESS ZONEMONITOR
Zone
Interface
Monitor
(ZIM)
WIRELESSZONE INTERFACE MODULE
FIRE
Fire Alarm Control
Step 1: Install the WZM and the ZIM
Refer to the EMS Wireless Zone Monitor
Installation Guide (TSD141) and the EMS
Zone Interface Monitor Installation
Guide (TSD142) for full information.
If connecting to a Conventional Fire
Alarm Control Panel, also follow the
Conventional Interface Card Installation
Guide (TSD147).
Installation
©2014 EMS Radio Fire & Security Systems Ltd. All rights reserved 1/2 TSD147 Iss 2 11/08/14 AJM
Step 1 Introduction
Step 6 Connection Wiring
Step 2 Pre Installation
Part No Product Description
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE
EC-63-0001 EMS Conventional Interface Card
Conventional Interface Card (CIC)
Installation Guide
Step 3 Connect CIC to the ZIM
Step 5 Fasten the ZIMs Terminals
SOUNDERS FAULT ZONE/RESET
EOL L1L2 EOL L1L2 ALARM
RES
EOL L1L2
(+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-)
SOUNDERS FAULT ZONE/RESET
EOL L1 L2 EOL L1 L2 ALARM
RES EOL L1 L2
The CIC can be wired in two different ways.
Fault notification can either be monitored via the Conventional FAPs
Sounder or Zone Circuit.
See overleaf for the alternative wiring methods.
SOUNDER FAULT ZONE
EOL L1 L2 EOL L1L2
ALARM
RES
EOL L1 L2
SOUNDERS FAULT ZONE/RESET
EOL L1 L2 EOL L1L2 ALARM
RES EOL L1 L2
Ensure the pins line up with the ZIMs terminal connections as
shown.
!
The Conventional Interface Card (CIC) installation must
conform to applicable local installation codes and
should only be installed by a fully trained competent
person.
The following points require consideration upon installation:
The CIC is only to be fitted to the Zone Interface Module
(ZIM), when connection is required to a Conventional Control
Panel.
The CIC should only be connected to designated zone and
sounder circuits.
Refer to the EMS Wireless Zone Monitor Engineers Guide
(TSD143) for full programming information.
ZIM with
CIC fitted WZM
FireCell Wireless Devices
POWER
FAULT
WIRELESSZONEMONITOR
FC-ZIM-0
Conventional
FAP
The Conventional Interface Card (CIC) when fitted to the Zone
Interface Module (ZIM), enables 30 FireCell wireless devices to be
added to an existing Conventional Fire Alarm Panel (FAP), via a
Wireless Zone Monitor (WZM).
*
*Designated zone
and sounder circuits.
Step 4 Fasten the CIC PCB into the ZIM
©2014 EMS Radio Fire & Security Systems Ltd. All rights reserved 1/2 TSD142 Iss 2 11/08/14 AJM
Step 1 Pre Installation Step 2 ZIM Components
Part No Product Description
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE
!
The Zone Interface Module (ZIM) installation must
conform to applicable local installation codes and
should only be installed by a fully trained competent
person.
The following points require consideration upon installation:
Do NOT Press the Log On button on a pre-programmed
device, as this will cause communication with the Control
Panel to be lost. Should this happen, delete the device from
the system and add it back on.
ZIM location. Refer to the design drawings generated from the
radio survey.
Radio performance. Refer to step 3 to ensure the radio
performance is optimised.
4x Lid Fixing
Screws
Front
Lid
Part
Description
Item No 123
3
Back
Box
EC-41-0200 EMS Wireless Zone Interface Module
Zone Interface Module
Installation Guide
IDENTREV D ATE
FC-610-001
EN300200-2
0359
!
20K4K7
CN/O
20K=Red/Bl
4k7=Yellow
EOLResistor
Conguration
ANTENNA
2
1
Drill the required
cable entry points
where necessary.
Step 4 Prepare the Back Box Step 5 Fit
Back Box to the Wall
The units Back
Box can now be
fixed to the wall.
All four circled
fixing positions
are available for
use.
OUTPUT 2OUTPUT 1
3VDCSET RST
INPUT1 INPUT2
LED
ENABLE
POWER
INPUT1
INPUT2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/OCOM N/C
SERIALNO
LOGON
IP- IP+ IP- IP+
3VDCSET RST N/O COM N/C
EXPAN1 EXPAN2
RELAYON
RELAY ON
2
4
8
16
32
ANTENNA
KEEPCABLESAWAYFROM THIS AREA
Cabling should only
be passed via the
access points
available.
Cable glands should
be used.
Cable lengths should
be kept to a
minimum to ensure
cables are away from
the PCBs aerials.
ON
INPUT1 INPUT 2
EXPAN1 EXPAN2
OUTPUT2
OUTPUT1
IP-IP+ IP- IP+
3VDCSETRST
N/OCOM N/C
3VDCSET RST
N/OCOM N/C
Do Not Use
=
Available
Cable Entry
Points
=
Step 3 Mounting Location Guidelines
Ensure the ZIM is not installed
within 2m of the System 5000
Control Panel or any other radio
or electrical equipment.
Ensure the ZIMs aerials are not
installed within 0.6m of any metal
work.
To ensure the optimum
range performance of
the ZIM is achieved,
the following should be
considered:
WZM ZIM
0.6m
System 5000
Control Panel
WZM ZIM
System 5000
Control Panel
FirePoint
SYSTEM5024
1 2 3 4
5 6
7
8
910 11
12
1314
151617 18 19 20 21 22 23
OFFON
ISOLATE
1 2 3
456
789
0
NO YES
RESET/
LEDTEST
SILENCE
ALARM
SOUND
ALARMS
POWER EARTHFAULT
FIRE
ZONEFAULT AREDISABLED SOUNDERFAULT
GENERALFAULT TESTMODE SYSTEMFAULT
AREFAULT
SOUNDER&
OUTPUTSDISABLED
DETECTOR/ZONE
DISABLED
Ensure the ZIM and WZM are
seperated by a minimum of 0.6m.
0.6m
FirePoint
SYSTEM5024
1 2 3 4
5 6
7
8
910 11
12
1314
151617 18 19 20 21 22 23
OFF ON
ISOLATE
1 2 3
456
789
0
NO YES
RESET/
LEDTEST
SILENCE
ALARM
SOUND
ALARMS
POWER EARTHFAULT
FIRE
ZONEFAULT AREDISABLED SOUNDERFAULT
GENERALFAULT TESTMODE SYSTEMFAULT
AREFAULT
SOUNDER&
OUTPUTSDISABLED
DETECTOR/ZONE
DISABLED
POWER
FAULT
WIRELESSZONEMONITOR
2m
WIRELESSZONEINTERFACEMODULE
WIRELESSZONEINTERFACEMODULE
WIRELESSZONEINTERFACEMODULE
POWER
FAULT
WIRELESSZONEMONITOR
Wireless Zone Monitor
Installation Guide
©2014 EMS Security Systems Ltd. All rights reserved 1/2 TSD141 Iss 2b 03/09/14 AJM
EC-13-0000 EMS Wireless Zone Monitor
Part No Product Description
Step 1 Pre Installation
!
The EMS Wireless Zone Monitor (WZM) installation must
conform to applicable local installation codes and
should only be installed by a fully trained competent
person.
The following points require consideration upon installation:
WZM location. Refer to the design drawings generated from the
wireless survey.
Wireless performance. Refer to step 3 to ensure the wireless
performance is optimised.
Refer to the Wireless Zone Monitor Engineers guide (Doc Ref:
TSD143) for full programming details.
Step 2 WZM Components
45
4X Corner
covers
4x Lid
Screws
1x WZM
Lid
1x WZM
PCB
1x WZM Back
Box
Part Description
Item No 1 2 3 4 5
Step 5 Prepare the WZM Back Box
Drill the required
cable entry points
where necessary.
= Do Not Use
= Available Cable
Entry Points
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE
POWER
FAULT
WIRELESSZONEMONITOR
WIRELESSZONE
POWER
FAULT
12 3
Step 4 PCB Removal
The internal PCB of the WZM can be removed to ensure that
damage is not caused during installation.
Remove the central retaining screw prior to unclipping the PCB.
WD
BACK
POWER
FAULT
ISOLATE
0V
RX
TX
3V
SCR
+
-
LOOPIN
SCR
LOOPOUT
+
-
Ensure the WZM is not installed
within 2m of the Control Panel or
any other wireless or electrical
equipment.
Ensure the WZMs aerials are not
installed within 0.6m of any metal
work.
To ensure the optimum
range performance of
the WZM is achieved,
the following should be
considered:
WZM ZIM
0.6m
Existing
Control Panel
WZM ZIM
Existing
Control Panel
Ensure the WZM and ZIM are
seperated by a minimum of 0.6m.
0.6m
POWER
FAULT
WIRELESSZONEMONITOR
Step 3 Mounting Location Guidelines
2m
WIRELESSZONEINTERFACEMODULE
WIRELESSZONEINTERFACEMODULE
POWER
FAULT
WIRELESSZONEMONITOR
FIRE
FireAlarmControl
FIRE
FireAlarmControl
!Note For details on compatible
Conventional Fire Alarm
Control Panels refer to document
reference MK51, which is free to
download from www.emsgroup.co.uk.
www.acornfiresecurity.com
www.acornfiresecurity.com

5
Step 2: Wiring
a) WZM to an Addressable Control Panel
FIRE
Fire Alarm Control
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FAULT
ISOLATE
SCR
+
-
LOOPIN
SCR
LOOPOUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT1 INPUT2
LED
ENABLE
POWER
INPUT 1 INPUT 2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/O COM N/C
SERIAL NO
LOGON
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1 EXPAN2
RELAYON RELAYON
2
4
8
16
32
ANTENNA
KEEP CABLES AWAYFROM THIS AREA
LOOP IN LOOP OUT
OUTPUT 2
OUTPUT 1
INPUT 1 INPUT 2
N/O COM N/C
IP- IP+ IP- IP+
N/O COM N/C
Wireless
Zone
Monitor
(WZM)
Zone
Interface
Module
(ZIM)
FAULT
INPUT
AUX 24V
OUTPUT
FIRE
INPUT
+ - NO C
FIRE OUTPUT 2
(to clear when
panel reset)
NO C NC
FIRE OUTPUT 1
(to clear when
panel silenced)
NO C NC NO C
4k7
20k
4k7
20k
Addressable
Fire Alarm
Panel
*
*
Footnotes:
Optional cabling, required only when
wireless FireCell Detectors and
Callpoints are added to the WZM.
Wiring can be normally open or
normally closed orientation as required.
Note: if the WZM is to powered
remotely, the PSU must be monitored
e.g via a FireCell I/O Unit.
+ - + -
† †
†
www.acornfiresecurity.com
www.acornfiresecurity.com

Existing
FirePoint
System 5000
Control Panel
6
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FAULT
ISOLATE
SCR
+
-
LOOPIN
SCR
LOOPOUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT1 INPUT2
LED
ENABLE
POWER
INPUT 1 INPUT 2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/O COM N/C
SERIAL NO
LOGON
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1 EXPAN2
RELAYON RELAYON
2
4
8
16
32
ANTENNA
KEEP CABLES AWAYFROM THIS AREA
485SCREEN CONNECTION
TOPANEL
EARTHPOINT
THROUGH
CONNECTION
AUX
BATT
IN
24VOV 8V OV NC TX OV RX + - + - NO C NC NO C NC INOUT NO C NC NO C NC NONO NO
24V
0V
24V
0V
24V
0V
AUX
RELAY
SOUNDERS
21
CALL
POINT
REM
BUZZER
OUT
TAMPER
AUX232 RS485
IN OUT FAULT
RELAY
FAULT
RELAY
ARE
BRIG
MONIT
BRIGADE
RELAY
FIRE
RELAY
BOMB CLASS
CHNG
0V
08V
0V
12V
BANK INTRUDER & FIRE SYSTEMS
HERNE BAY, KENT
WARNING
DAMAGE TO THIS LABEL
WILL INVALIDATE
THE WARRANTY
FIRE
TRANC
V1.2
TXFREQ
459.2750
MHz
RXFREQ
173.2450
MHz
WARNING
Hazardous
Voltage
WARNING
AlwaysDisconnect
MainsSupply
Before
Removalof JP19
230V AC
b) WZM to System 5000 Control Panel
4k7
4k7
20k
4k7
20k
4k7 2k2
4k7
20k
4k7
NO C NC NO C NC
BRIGADE
RELAY
FIRE
RELAY
24V
0V
24V
0V
24V
0V
NO
CALL
POINT
21
SOUNDERS
AUX
RELAY
*
*
Footnotes:
Optional cabling, required only when
wireless FireCell Detectors and
Callpoints are added to the WZM.
Note: if the WZM is to powered
remotely, the PSU must be monitored
e.g via a FireCell I/O Unit.
Wireless
Zone
Monitor
(WZM)
Zone
Interface
Module
(ZIM)
LOOP IN LOOP OUT
+ - + -
OUTPUT 2
OUTPUT 1
INPUT 1 INPUT 2
N/O COM N/C
IP- IP+ IP- IP+
N/O COM N/C
www.acornfiresecurity.com
www.acornfiresecurity.com

7
FIRE SYSTEMS
FIRE SYSTEMS
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FAULT
ISOLATE
SCR
+
-
LOOPIN
SCR
LOOPOUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Wireless
Zone
Monitor
(WZM)
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT1 INPUT 2
LED
ENABLE
POWER
INPUT 1 INPUT 2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/O COM N/C
SERIAL NO
LOGON
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1 EXPAN2
RELAYON RELAYON
2
4
8
16
32
ANTENNA
KEEPCABLES AWAY FROMTHIS AREA
OUTPUT 2
OUTPUT 1
INPUT 1 INPUT 2
4k7
Zone
Interface
Module
(ZIM)
FirePoint
SYSTEM 5024
1 2 3 4 5 6 7 8 9 10 11 12
13 14 15 16 17 18 19 20 21 22 23 24
OFF ON
ISOLATE
1 2 3
456
789
0
NO YES
RESET/
LED TEST
SILENCE
ALARM
SOUND
ALARMS
POWER EARTHFAULT FIRE
ZONEFAULT ARE DISABLED SOUNDERFAULT
GENERALFAULT TESTMODE SYSTEM FAULT
AREFAULT SOUNDER&
OUTPUTSDISABLED
DETECTOR/ZONE
DISABLED
Existing
FirePoint
System 5000
Control Panel
LOOP IN
24V OUT
- +
2x System 5000
or Tempoint
I/O Units
Power
Supply
Unit
N/C
C
N/O
HARD
WIRED
INPUT
N/C
C
N/O
HARD
WIRED
INPUT
+ -
N/O COM N/C
IP- IP+ IP- IP+
N/O COM N/C
4k7 20k 4k7 20k
*
OUTPUTOUTPUT
Footnotes:
When powering the WZM via a
remote power supply unit, the
power supply should be
monitored using a FireCell I/O
unit.
Output programmed to clear
when the Control Panel is reset.
(Cause and eects req).
†
4k7
2k2
c) Remote WZM to System 5000 Control Panel, option 1
(when both sounders and detection are added to the WZM)
*
†
www.acornfiresecurity.com
www.acornfiresecurity.com

8
FIRE SYSTEMS
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FAULT
ISOLATE
SCR
+
-
LOOPIN
SCR
LOOPOUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Wireless
Zone
Monitor
(WZM)
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT1 INPUT 2
LED
ENABLE
POWER
INPUT 1 INPUT 2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/O COM N/C
SERIAL NO
LOGON
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1 EXPAN2
RELAYON RELAYON
2
4
8
16
32
ANTENNA
KEEPCABLES AWAY FROMTHIS AREA
OUTPUT 2
OUTPUT 1
INPUT 1 INPUT 2
4k7
Zone
Interface
Module
(ZIM)
FirePoint
SYSTEM 5024
1 2 3 4 5 6 7 8 9 10 11 12
13 14 15 16 17 18 19 20 21 22 23 24
OFF ON
ISOLATE
1 2 3
456
789
0
NO YES
RESET/
LED TEST
SILENCE
ALARM
SOUND
ALARMS
POWER EARTHFAULT FIRE
ZONEFAULT AREDISABLED SOUNDER FAULT
GENERALFAULT TESTMODE SYSTEM FAULT
AREFAULT SOUNDER&
OUTPUTSDISABLED
DETECTOR/ZONE
DISABLED
LOOP IN
24V OUT
- +
1x System 5000
or Tempoint
I/O Unit
Power
Supply
Unit
N/C
C
N/O
HARD
WIRED
INPUT
- +
N/O COM N/C
IP- IP+ IP- IP+
N/O COM N/C
4k7 20k
OUTPUT
Existing
FirePoint
System 5000
Control Panel
Footnotes:
When powering the WZM via a remote
power supply unit, the power supply
should be monitored using a FireCell
I/O unit.
d) Remote WZM to System 5000 Control Panel, option 2
(when only sounders are added to the WZM)
*
20k
www.acornfiresecurity.com
www.acornfiresecurity.com

9
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FAULT
ISOLATE
SCR
+
-
LOOPIN
SCR
LOOPOUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Wireless
Zone
Monitor
(WZM)
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT1 INPUT2
LED
ENABLE
POWER
INPUT 1 INPUT 2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/O COM N/C
SERIAL NO
LOGON
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1 EXPAN2
RELAYON RELAYON
2
4
8
16
32
ANTENNA
KEEP CABLES AWAYFROM THIS AREA
SOUNDER FAULT ZONE
EOL L1 L2 EOL L1 L2 ALARM
RES
EOL L1 L2
(+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-)
SOUNDERS FAULT ZONE/RESET
EOL L1 L2 EOL L1 L2 ALARM
RES
EOL L1 L2
(+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-)
LOOP IN
Conventional Fire
Alarm Panel
24V OUT
- +
SOUNDER
+ -
ZONE
+ -
+ -
13
2
1= Sounder circuits end of line
2= Alarm triggering resistor
3= Zone circuits end of line
e) WZM to a Conventional Panel, option 1
(providing fault notication on the sounder circuit)
Zone Interface Monitor
(ZIM) with Conventional
Interface Card (CIC) tted
Footnotes:
Ensure the manufacturer’s specied
end of line components and triggering
resistors are tted. See the Control
Panel’s instuctions for more information
*
*
www.acornfiresecurity.com
www.acornfiresecurity.com

10
f) WZM to a Conventional Panel, option 2
(providing fault notication on the zone circuit)
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FAULT
ISOLATE
SCR
+
-
LOOPIN
SCR
LOOPOUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
+ -
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT1 INPUT2
LED
ENABLE
POWER
INPUT 1 INPUT 2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/O COM N/C
SERIAL NO
LOGON
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1 EXPAN2
RELAYON RELAYON
2
4
8
16
32
ANTENNA
KEEP CABLES AWAYFROM THIS AREA
SOUNDER FAULT ZONE
EOL L1 L2 EOL L1 L2 ALARM
RES
EOL L1 L2
(+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-)
SOUNDERS FAULT ZONE/RESET
EOL L1 L2 EOL L1 L2 ALARM
RES
EOL L1 L2
(+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-) (+) (-)
LOOP IN
24V OUT
- +
SOUNDER
+ -
ZONE
+ -
13
2
1= Sounder circuits end of line
2= Zone circuits end of line
3= Alarm triggering resistor
Conventional Fire
Alarm Panel
Wireless
Zone
Monitor
(WZM)
Zone Interface Monitor
(ZIM) with Conventional
Interface Card (CIC) tted
Footnotes:
Ensure the manufacturer’s specied
end of line components and triggering
resistors are tted. See the Control
Panel’s instuctions for more information
*
*
www.acornfiresecurity.com
www.acornfiresecurity.com

Wireless Zone Monitor Overview
TX
RADIO
WD
RESET
HELP
RX
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
3V3
TX
RX
0V
868MHz
Aerials
Reset
Button
Front Lid
Tamper Switch
Help &
Back
Buttons
Rotary
Control
Status
LEDs
LCD
Contrast
Adjustment
LCD
Display
PCB
Retaining
Screw
Loop In
Power
Connections
Wireless Zone Monitor Display
DEV00 AL00 FT00
Wireless Zone Monitor Rotary Control Operation
The Rotary Control is used to navigate the WZM’s
menu structure. It can be pressed and released to
select a menu option. It can also be rotated to scroll
through the available options.
HELP
ON
1 2 3 4 5 6 7 8
BACK
SCR
+
-
LOOP IN
SCR
LOOP OUT
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
TOT00 AL00 FT00
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
The front display of the WZM indicates
the number of devices allocated to
the module, along with the amount of
devices currently in alarm and fault
conditions.
These three elds can range between
00 and 31 and are displayed as shown:
11
Number
of
Devices
Number
of
Alarms
Number
of
Faults
www.acornfiresecurity.com
www.acornfiresecurity.com

Front
Screen
Device Status Dev Address Fault Status
Add New Device Alarm Status*
Remove Device Battery Level
Interface Status Signal Level
Radio Channels Manual Update
Ident
Software Version
Dev Address
Type: **
* Alarm Status shown as I/O Status for
Input/Output Device types.
Fault Status
Background Level
** Type is only shown for Combined
Detector/Sounder variants. This screen shows
the type of Detector used. Either Optical,
Htemp, Heat or Multi will be shown.
Fast test
Ident
*** Highlighted menu options are only
available when switch 8 is ON.
Software Version
Audio Detect ***
**** Menu Options only available when
loop interface does not have any devices
allocated to it. Batt Smooth ***
Analogue 35 ***
Serial Data ***
Currently Used
Auto Select **** Scan Time
Manual Select ****
Second Channel
Wireless Zone Monitor Menu Structure
12
www.acornfiresecurity.com
www.acornfiresecurity.com

13
Step 3: Power Up the Devices
Detectors, Sounders, Callpoints, Input/Output Units and the Zone Interface Module
have power jumpers that power the device as shown:
Combined Sounder Detectors are
powered by changing the orientation of
Switch 1 as shown:
Switch 1 on = POWER ON
www.emsgroup.co.uk
Combined Sounder
and Detector Base
PRESS HERE TO
LOG ON
IDENT
!
ON
1234
ON
1234
SIZE C SIZE C SIZE C
SIZE AA
SIZE AA
SIZE AA
device
unpowered
(pins unlinked)
device
powered
(both pins linked)
Power jumper locations are shown below:
Wireless
Sounder
SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
Wireless
Detector SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
Wireless
Call Point
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT 1 INPUT 2
LED
ENABLE
PO WER
INPUT 1
INPUT 2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/O COM N/C
SERIAL NO
LOGON
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1 EXPAN2
RELAY ON RELAY ON
2
4
8
16
32
ANTENNA
KEEP CABLES AWAY FROM THIS AREA
Wireless Input
Output Unit
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT 1 INPUT 2
LED
ENABLE
PO WER
INPUT 1
INPUT 2
FAULT
CLOSED
0 1
1
64
F-SAFE
N/O COM N/C
SERIAL NO
LOGON
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1 EXPAN2
RELAY ON RELAY ON
2
4
8
16
32
ANTENNA
KEEP CABLES AWAY FROM THIS AREA
Wireless Zone
Interface Module
Wireless Combined
Sounder Detector
www.acornfiresecurity.com
www.acornfiresecurity.com

14
Programming is achieved manually within the menu structure of the WZM.
The Log On process is as follows:
From Front display:
Click the rotary control, and the
screen will display:
Turn the rotary control until the
screen displays:
Click the rotary control, and the
screen will display:
Press the device log on button for
3 seconds and the screen will
display the devices 5 character
alphanumeric ident:
E.G A1B2C
Step 4: Log On the Devices
The EMS Zone Interface Module
(ZIM) must be logged on before
adding other wireless devices
to the system.
!
Note
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
DEV000 AL00 FT00
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Add New Device
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Device Status
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Press Dev Log On
0 1
1
SERIAL NO
LOGON
RELAY ON RELAY ON
2
4
8
16
32
ANTENNA
KEEP CABLES AWAY FROM THIS AREA
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3
4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Add Dev A1B2C N?
www.acornfiresecurity.com
www.acornfiresecurity.com

15
Troubleshooting
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Add Dev A1B2C Y?
Step 4: Log On the Devices (continued)
Turn the rotary control to change
the N? to Y?
Where: N? = NO
Y? = YES
Click the rotary control and the
screen will display:
Followed by:
Click the rotary control and the
screen will display:
The new device has been
successfully added to the system.
Once all of the required devices
have been added to the system,
press the back button repeatedly
until the front screen is displayed:
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
New Device:001
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
DEV01AL00 FT00
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
ZM IO Added
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Adding
www.acornfiresecurity.com
www.acornfiresecurity.com

16
Step 5: Install the Wireless FireCell Devices
Refer to the associated FireCell device installation guides for more information.
Do NOT Press the Log On
button on a device that is
logged on to the system as
this will cause the
communication with the
WZM to be lost. Should
this happen, delete the
device from the system
and add it back on.
!Note
www.emsgroup.co.uk
Wireless Detector Base
PRESS HERE TO
LOG ON
IDENT
www.acornfiresecurity.com
www.acornfiresecurity.com

17
Step 6: Check Signals
The signal levels for all wireless
devices can be viewed as follows:
From Front display:
Click the rotary control, and the
screen will display:
Click the rotary control, and the
screen will display the rst
available device:
Turn the rotary control until the
screen displays the required
device:
Click the rotary control, and the
screen will display:
Turn the rotary control until the
screen displays :
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
DEV18 AL00 FT00
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Signal Level
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Device Status
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Fault Status
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Dev 001 L ZM IO
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Dev 007 L Optic
www.acornfiresecurity.com
www.acornfiresecurity.com

18
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Ch1 L1 D 100
Step 6: Check Signals (continued)
Click the rotary control, and the
screen will display the signal level
received at the WZM from the
device:
Click the rotary control, and the
screen will display the signal level
received at the device from the
WZM:
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
Ch2 L1 D 100
TX
RADIO
WD
RESET
HELP
RX
ON
1 2 3 4 5 6 7 8
BACK
POWER
FA U LT
ISOLATE
SCR
+
-
LOOP IN
SCR
LOOP OUT
+
-
1 2 3 4 5 6 7
3V3
TX
RX
0V
DEV18 AL00 FT00
When all levels have been
checked, press the back button
repeatedly until the front screen is
displayed:
This above displays detail information on the two signalling channels used by the
Wireless Zone Monitor. The signal levels shown range from 100 - 0, with 100 being the
highest signal to 0 where no signal is being seen, as shown below:
100
Shown indicates Good Signal Level
90 Shown indicates Good Signal Level
80 Shown indicates Good Signal Level
70 Shown indicates Good Signal Level
60 Shown indicates Good Signal Level
Shown indicates Good Signal Level
50
40
Shown indicates Low Signal Level
30
20 Shown indicates Caution Signal Level
10 Shown indicates Caution Signal Level
0 Shown indicates No Signal Level Received
Shown indicates Medium Signal Level
www.acornfiresecurity.com
www.acornfiresecurity.com

19
Frequently Asked Questions
When using these Frequently Asked Questions, the following symbols are shown for
the internal controls on the Wireless Zone Monitor.
BACK
= Turn & Press Rotary Button to select relevant menu option.
= Press the Back Button to exit the menu.
Q; How do I remove a device from the system?
A; To remove a device on the WZM, select:
Front display Remove Device Select required device Remove Device
xxxxx Y? 01 Removed Optic
To Exit
BACK
Q; How do I replace a device on the system?
A; To replace a device on the system, the device must rstly be removed from the
WZM (see above). Then the new device must be added to the system. (See previous
Step 3 Log On Devices)
Q; I’m struggling to get detectors to go into re upon routine test.
A; Detectors can be entered into fast test mode. Fast test hightens the detectors
sensitivities, allowing the detectors to be triggered into an alarm condition quicker
than normal. The led on the device will ash to indicate it is in this fast test mode. A
time period of between 1 and 30 minutes is selectable which decrements and is then
re-generated on a re alarm event. The devices automatically come out of fast test
mode when the timer expires or the fast test mode is exited. To place the detectors
in to Fast Test Mode, select:
Front Display Interface Status Fast Test Start Fast Test Select Time
To Exit
BACK
Q; Why can I not change my radio channels?
A; Radio Channels can only be changed whilst no devices are added to the system.
Q; My system is showing a device fault/alarm. How do I nd out what type of
fault/alarm it is?
A; To view devices currently in fault or alarm, select:
Front display Device Status Select required device*Fault Status or
Alarm Status
To Exit
* An exclamation mark (!) will be shown whilst a device is in fault.
A re symbol ( ) will be shown whilst a device in in alarm.
BACK
OUTPUT 2OUTPUT 1
3VDC SET RST
INPUT 1 INPUT 2
LED
ENABLE
PO WER
INPUT 1
INPUT 2
FA ULT
CLOSED
64
F-SAFE
N/O COM N/C
IP- IP+ IP- IP+
3VDC SET RST N/O COM N/C
EXPAN1 EXPAN2
2
4
8
16
32
www.acornfiresecurity.com
www.acornfiresecurity.com

20
Device Type
All Device Types.
All Device Types.
All Device Types.
I/O Unit and ZIM.
Sounder.
Sounder &
Detector.
Detector.
Detector.
Detector.
Detector.
Call Point
Symptom
In Tamper.
Battery Fault.
Signal Fault.
Short Circuit /
Open Circuit.
No Sndr Audio.
Head Missing.
Head Fault.
Head Dirty.
Pre Alarm.
Alarm.
Alarm.
Rectication Process
Check device is inserted correctly into its base.
Check all batteries are inserted correctly. Check voltage
on batteries. Replace batteries if necessary or re-insert
correctly.
Check devices is in its correct location.
Check that the device is powered (see step 3).
Test the device locally at the WZM.
Check the devices signal level (see step 6).
Check the 20k end of line resistor is in place and that
connections are secure.
Check for sounder audio. Also check the Audio Detect
Switch on the wireless module. See device installation
instructions for more information.
Check head in situ and check connectivity of head to
base. The head missing fault will clear upon successful
re-location.
Check the head is tted correctly. If the problem is not
related to the Detector Head connection it is
recommended that the Detector Head is replaced.
It is recommended that the Detector Head is replaced.
Check device is in a clean environment and is free from
smoke, dust and dirt.
Ensure that the environment of the devices location is
free of smoke residue and dust.
Check the devices glass is in tact.
WZM Fault Rectication
Fault symptoms seen at the WZM and their relevant rectication processes are shown
below:
www.acornfiresecurity.com
www.acornfiresecurity.com
