EMU CREATIVE TRACKER pre User manual

TRACKERpre Reference Manual 1
Reference ManualReference Manual
Audio Interface /
Mobile Preamp

2E-MU Systems
Reference Manual
© 2007 E-MU Systems
All Rights Reserved
Revision: A
Audio Interface / Mobile Preamp
E-MU World Headquarters
E-MU Systems
1500 Green Hills Road
Scotts Valley, CA 95066
USA
Europe
Creative Labs (Ireland) Ltd
Ballycoolin Business Park
Blanchardstown, Dublin 15
IRELAND
Asia Pacific, Africa, Middle East
Creative Technology Ltd
31 International Business Park
Creative Resource, Singapore 609921
SINGAPORE
Japan
Creative Media K. K.
Kanda Eight Bldg., 3F
4-6-7 Soto-Kanda
Chiyoda-ku, Tokyo 101-0021
JAPAN

TRACKERpre Reference Manual 3
TABLE OF CONTENTS
Introduction ................................................................................. 5
Package Includes .......................................................................... 6
Computer Requirements ............................................................... 7
Windows ..........................................................................................................7
OS X .................................................................................................................7
Software Installation .................................................................... 8
Windows XP or Windows Vista ..........................................................................8
Note About Windows Logo Testing ................................................................8
Uninstalling all Audio Drivers and Applications ................................................8
Macintosh OS X .................................................................................................9
Uninstalling the Audio Drivers and Applications ............................................11
Basic Connections ...................................................................... 12
Insert Connection Example .........................................................13
Controls & Headphone Output ...................................................14
Input/Output ............................................................................. 15
E-MU USB Audio Control Panel ................................................... 16
Direct Monitoring ....................................................................... 17
Tutorials ..................................................................................... 18
Introduction ....................................................................................................18
Before you Begin... ......................................................................................18
Getting Started with Steinberg Cubase LE 4 (Windows, OS X) ..........................19
1 - Setting up Cubase LE 4 ...........................................................................19
2 - Basic Multitrack Recording .......................................................................21
3 - Recording a MIDI Track using Proteus VX (Windows only) ........................23
Getting Started with Cakewalk Sonar 6 LE (Windows) ......................................26
1 - Setting up Sonar 6 LE ..............................................................................26
2 - Basic Multitrack Recording .......................................................................29
3 - Recording a MIDI Track using Proteus VX .................................................31
Getting Started with Ableton Live Lite 6 (Windows/OS X) .................................36
Before you Begin: ........................................................................................36
1 - Setting up the Preferences .......................................................................36
2 - Follow the Live 6 Lessons ........................................................................38
3 - Running Proteus VX from Ableton Live (Windows only) ............................39
4 - Record a MIDI Track in Live using your MIDI Keyboard .............................42
Other Cool Tips ............................................................................................45

4E-MU Systems
Troubleshooting ......................................................................... 46
Internet References .................................................................... 48
Forums ........................................................................................................ 48
Useful Information ..................................................................... 49
Cables - balanced or unbalanced? ................................................................... 49
Balanced Cables .......................................................................................... 49
Unbalanced Cables ...................................................................................... 49
Adapter Cables ................................................................................................ 50
Grounding ...................................................................................................... 50
Phantom Power .............................................................................................. 50
Technical Specifications .............................................................. 51
Declaration of Conformity .......................................................... 53
Index ......................................................................................... 55

Introduction
TRACKERpre Reference Manual 5
INTRODUCTION
Thank you for your purchase of the E-MU Tracker Pre USB 2.0 Audio Interface/
Mobile Preamp. This interface brings an unparalleled level of USB audio quality to
the Mac or PC, with pristine 24-bit/192kHz A/D and D/A converters, ultra-low
jitter clock, and XTC™ Class-A, ultra-low noise mic/line/hi-Z preamps. The signal-
to-noise specs of Tracker Pre USB 2.0 are unmatched by any other brand of USB
interface on the market! From its plug-and-play functionality and hands-on
ergonomic design, to professional features like zero-latency direct monitoring,
Tracker Pre will forever change your expectations of USB audio. We’ve also
included the powerful E-MU Production Tools Software Bundle so that you’ll have
everything you need to create, record, edit, and mix your music.
Some of the other key features are detailed below:
• Record and Playback support for a multitude of sample rates: 44.1k, 48k, 88.2k,
96k, 176.4k, 192k. (176.4k &192k available on PC version only)
• E-MU CurrentMorph™ (pat. pend.) phantom power circuit allows bus-powered
+48V without compromising audio performance.
• Insert jacks on both channels allow you to insert compressors, EQs, or other
processors after the XTC™ Class-A, ultra-low noise preamps.
• Hardware zero-latency direct monitoring (mono or stereo) allows you to record
and overdub with no annoying delay
• Can be used as a stand-alone, audiophile-quality microphone preamplifier
using an optional external power supply.
NOTE
There are some limitations
when operating at higher
sample rates. See page 16
for details.
• Independent ground lift switches for both analog TRS inputs help to solve
potential ground loop problems
• Studio-Grade Headphone Amplifier with level control

Package Includes
6E-MU Systems
PACKAGE INCLUDES
• E-MU Tracker Pre USB 2.0 Audio Interface
•USBCable(2meters)
• Installation Guide
E-MU Software/Manual Installation CD-ROM (OS X /Windows)
• Windows XP, Windows x64, Windows Vista, Windows Vista x64 Drivers
• Mac OS X 10.4, Mac OS X 10.5 Drivers
• Owner’s Manual and Tutorials
• Adobe Acrobat Reader (Windows only)
E-MU Production Tools Software Bundle DVD (OS X /Windows)
Windows Applications
• E-MU Proteus VX (with over 1000 sounds)
• Cakewalk Sonar 6 LE
• Steinberg Cubase LE4
• Celemony Melodyne essential
• IK Multimedia AmpliTube Duo
• SFX Machine LT
OS X Applications
• Steinberg Cubase LE4
• BIAS Peak Express 5
• Celemony Melodyne essential
• IK Multimedia AmpliTube LE
• SFX Machine LT
•T-RacksEQ
Ableton Live Lite 6 E-MU Edition CD-ROM (OS X, Windows)
• Ableton Live Lite 6 E-MU Edition
Waldorf Edition LE CD-ROM (OS X, Windows)
• Waldorf Edition LE

Computer Requirements
TRACKERpre Reference Manual 7
COMPUTER REQUIREMENTS
The minimum computer system requirements for the E-MU Tracker Pre USB 2.0
are listed below.
Windows
• Intel® or AMD® processor — 1.2 GHz or faster
• Intel, AMD, or 100% compatible motherboard & chipset
• Microsoft® Windows® XP (SP 2 or greater), Windows XP x64, Windows Vista,
or Windows Vista x64
• 1 available (Hi-Speed) USB 2.0 port *
• 512 MB System RAM
• 900 MB of free hard disk space for full installation
• CD-ROM/CD-RW drive required for software installation
• DVD-ROM drive required for bundled software installation
• XVGA Video (1024 x 768)
OS X
• Apple® Macintosh® G4 800 MHz G4 compatible or Intel-based processor
• Apple Macintosh OS X (10.4.3 or greater)
• 1 Available (Hi-Speed) USB 2.0 port †
• 512 MB System RAM
• 500 MB of free hard disk space for full installation
• CD-ROM/CD-RW drive required for software installation
• DVD-ROM drive required for bundled software installation
• XVGA Video (1024 X 768)
* When connecting the Tracker Pre to a USB 1.1 port on a Windows PC, performance is
limited to 16-bit and 44.1/48 kHz recording and playback.
†USB 1.1 is not supported on the Macintosh

Software Installation
8E-MU Systems
SOFTWARE INSTALLATION
Windows XP or Windows Vista
Follow these instructions to install the Tracker Pre USB 2.0 software and E-MU
Production Tools software bundle on a Windows XP or Windows Vista computer.
1. First connect the Tracker Pre USB 2.0 to your computer using the supplied USB
cable, and turn it on.
2. If Windows prompts you with an Add New Hardware Wizard, click Cancel.
3. Insert the E-MU Software/Manual Installation CD into your CD-ROM drive. If
Windows AutoPlay mode is enabled for your CD-ROM drive, the CD starts
running automatically. If not, from your Windows desktop, click Start->Run
and type d:\setup.exe (replace d:\ with the drive letter of your CD-ROM
drive). You can also simply open the CD and double-click Setup.exe.
4. The installation splash screen appears. Follow the instructions on the screen to
complete the installation. You will have the option to install Tracker Pre, and
Adobe Acrobat Reader.
5. Choose “Continue Anyway” when you encounter the “Windows Logo
Testing” warning screen. See the note below.
6. When prompted, restart your computer.
7. Be sure to register your Tracker Pre so we can advise you of future software
updates and special offers. You can register online at: www.emu.com/register
8. Your Tracker Pre USB 2.0 is now ready to use.
9. Insert the Windows Production Tools Software Bundle DVD into your DVD-
ROM drive.
10. The installation splash screen appears. Follow the instructions on the screen to
complete the installation.
Note About Windows Logo Testing
When you install the Tracker Pre USB 2.0 drivers, you will see a dialog box
informing you either that the driver has not been certified by Windows Hardware
Quality Labs (WHQL), or that the driver is signed by Creative Labs, Inc., and you
will be asked if you would like to continue with the installation.
The Tracker Pre USB 2.0 audio drivers are not certified by WHQL because the
driver does not support some of the features that the Microsoft Windows Logo
Program requires, most notably Universal Audio Architecture (UAA) and Digital
Rights Management (DRM).
Despite this, the Tracker Pre USB 2.0 audio drivers have been rigorously tested
using the same test procedures that a WHQL qualified driver requires, and it passes
in all of the other important categories, including those that measure the relative
stability of the driver. So, it is perfectly safe to install these drivers on your
computer.
Uninstalling all Audio Drivers and Applications
At times you may need to uninstall or reinstall the Tracker Pre USB 2.0 application
and device drivers to correct problems, change configurations, or upgrade
outdated drivers or applications. Before you begin, close the E-MU Audio control
application. Applications running during the uninstallation will not be removed.
1. Click Start -> Control Panel.
2. Double-click the Add/Remove Programs icon.
3. Click the Install/Uninstall tab (or Change or Remove Programs button).

Software Installation
TRACKERpre Reference Manual 9
4. Select the E-MU Audio Drivers entry and then click the Change/Remove
button.
5. In the InstallShield Wizard dialog box, select the Remove ALL option.
6. Click the Yes button.
7. Restart your computer when prompted.
You may now re-install existing or updated E-MU device drivers or applications.
To Reinstall the Drivers:
1. Disconnect the Tracker Pre USB connection.
2. Reboot your PC.
3. When the operating system has finished loading, re-connect the Tracker Pre
USB connection. Important! Make sure you are using a USB 2.0 port.
4. The Hardware Wizard will launch when it detects the Tracker Pre. Cancel it!
5. Run the Installer from the Software/Manual Installation CD-ROM.
6. Reboot the PC when asked. If you’re not asked, reboot anyway.
7. Check the Device Manager, Sounds Video and Game Controllers to make sure
the E-MU Tracker Pre|USB is shown.
Macintosh OS X
Follow these instructions to install the Tracker Pre USB 2.0 drivers and software on
a Macintosh OS X computer. First, connect the Tracker Pre to your computer as
shown on page 12.
Install the Tracker Pre USB 2.0 Software
1. Insert the E-MU Software/Manual CD-ROM into your CD-ROM drive.
2. Double-click on the E-MU icon on the desktop.
3. Double-click on the Install icon to start the installation.
4. The installation Welcome screen appears. Follow the instructions on the
screen.
5. When the Authenticate dialog box appears, enter the administrator password
you chose when you installed OS X.
6. Continue to follow the instructions on the screen to continue the installation.
You will be given the option to install:
•Easy Install: Installs the following applications and drivers.
E-MU Tracker Pre USB 2.0: USB Drivers and Control Application
•Custom Install: allows you to choose which components are installed.
7. Easy Install is recommended. The software will be quickly installed. When
prompted, restart your computer.
8. Be sure to register your Tracker Pre USB 2.0 so we can advise you of future
software updates and special offers. You can register online at:
www.emu.com/register

Software Installation
10 E-MU Systems
Set-up the Tracker Pre USB 2.0 as your Default Audio Device
9. Click Go -> Utilities from the menu bar.
10. Double-click Audio MIDI Setup, then click the Audio Devices button if it’s
not already selected. The window shown on the following page appears.
11. Select the Tracker Pre USB 2.0 for the following: Default Input, Default
Output, System Output, Properties For.
12. Play a song on iTunes to verify that the Tracker Pre USB 2.0 is the default
device for audio playback.
13. Quit iTunes.
Setup the MIDI Devices
If you plan to use a MIDI keyboard, now would be a good time to set up your MIDI
devices. Connecting a MIDI keyboard will allow you to use the virtual instruments
provided in the software bundle and get the most out of your purchase. You’ll also
need a MIDI interface such as the E-MU Xmidi 2x2 or Xmidi 1x1.
14. Click the MIDI Devices button. The window shown below appears.

Software Installation
TRACKERpre Reference Manual 11
15. If you have a USB class-compliant MIDI device connected, it will appear as an
icon in the MIDI Devices window.
16. Press the close button to close the Audio MIDI Setup window.
Install the Production Tools Software Bundle
17. Insert the Macintosh Production Tools CD into your CD-ROM drive.
18. Double-click on the installer package.
19. The installation splash screen appears. Follow the instructions on the screen.
20. Continue to install applications from the bundle as desired.
Uninstalling the Audio Drivers and Applications
At times you may need to uninstall or reinstall the Tracker Pre USB 2.0 application
and device drivers to correct problems, change configurations, or upgrade
outdated drivers or applications. Before you begin, close the E-MU Tracker Pre
Audio control panel application. Applications running during the uninstallation
will not be removed.
1. Open the Applications folder.
2. Open the Creative Professional folder.
3. Open the E-MU USB Audio folder.
4. Click the E-MU USB Audio Unistaller and follow the instructions.

Basic Connections
12 E-MU Systems
BASIC CONNECTIONS
WARNING!
Use only a USB 2.0
certified Hi-Speed cable
(like the one supplied) for
the USB connection. Using
a USB 1.1 cable may cause
erratic behavior and
degraded performance.
NOTE
The Main Outputs are
balanced and can be used
with either balanced or
unbalanced cables.
Balanced cables should
ONLY be used when
connecting to a device
with balanced inputs.
Computer
Phantom
Power
On/Off
Optional
External
Power
(forstandalone
operation)
Microphone
orLine
Stereo
Electret
Mic
1/4” male to 1/4” male
1/4” male TS
to female RCA
Male RCA to
male stereo 1/8”
Y-cable
Stereo 1/8”
stereo-stereo
coupler
Male stereo
1/8” to speakers
PoweredSpeakers
Powered
Computer
Speakers
Plug Instrument
orLine Levelinto
the centerof
the receptacle.
(balanced-TRS orunbalanced-TS)
(balanced-TRS orunbalanced-TS)
(unbalanced-TS)
Note: A mono microphone
connects to Input 1L.
(Bus-powered)

Insert Connection Example
TRACKERpre Reference Manual 13
INSERT CONNECTION EXAMPLE
Tip Ring
TRS Plug
POWER
BYPASS
ON
10
9
8
6
5
4
3
0
2
1
7
LINK
GAIN REDUCTION
COMPRESSOR
10
9
8
6
5
4
3
0
2
1
7
GAIN
METER
MEDIUM
RELEASE
ATTACK
FAST SLOW
SLOW
RED.
FAST
OUTPUT
112+33570
VU
1008060
40
Input Output
Mic Preamp
Insert
Device
A/D Converter
USB
EXTERNAL PROCESSOR
Mic
Send
Return
To Effect FromEffect
SEND/RETURN CABLE
BLOCK
DIAGRAM
Tip Ring
Tip Ring
The pre-amplifiedsignal is sent Out the
Tip of the plug and Returns to the
TrackerPre viathe Ring of the plug.
Inserting astereo send-return cable into an Insert jack breaks the
connectionbetweenthe Mic Preamp and the A/D converterand allows
youto insert aserial processing device, such as acompressororEQ.
(Compressor, EQ, etc.)
TIP . . .
Tracker Pre can be used as
a standalone, high-quality
stereo microphone preamp
if needed.
Preamp
Output
From
Preamp
Insert Jack
To tap off the Mic Preamps
without interrupting the
connection to the ADC,
insert a mono plug halfway
(to the first click) into the
insert jack.

Controls & Headphone Output
14 E-MU Systems
CONTROLS & HEADPHONE OUTPUT
1. Signal Level & Clip Indicators
The LED signal level indicators show that you are inputting a proper signal
level. With a proper input level, the green signal LED should be flickering, but
the red clip indicator should NOT ever be lit.
The clip indicators light and show that the input level has exceeded 0dBFS.
2. Left/Right Gain Controls
These controls set the input gain from 0dB to +60dB for the two inputs.
3. Direct Monitor Level Control
This continuous encoder controls the amount of direct monitor signal mixed
into the outputs. The level is adjustable from -24dB to off.
4. Direct Monitor On/Off & Mono-Stereo Switch
Press the button once to turn on Direct Monitoring. The stereo LED illumi-
nates. In this mode the left and right channels are passed through to their
respective outputs at the level set by the Direct Monitor Level control. Press
the button again to switch to Mono Direct Monitoring, which sums the left
and right direct monitor channels to mono. Mono mode is useful when the
two inputs are being used for separate instruments, or when only one input is
being used. See “Direct Monitoring” on page 17.
5. Headphone Jack
Connect your stereo headphones here.
6. Headphone Level Control
This knob controls the volume of the headphone output. This switch also
turns the Tracker Pre on or off.
Ground Lift Switches
There are “ground lift” switches for both analog 1/4” inputs located on the
bottom of the unit. These switches can be used to safely stop the hum if a
ground loop occurs in your setup. See page 46 for more information.
234 5 61
L-GND LIFT
R-GND LIFT
Input Ground Lifted
Input Grounded
The input ground is lifted when the L or R slide switch is closest to the GND LIFT label.

Input/Output
TRACKERpre Reference Manual 15
INPUT/OUTPUT
7. 5 VDC Power Adapter (optional)
Although the Tracker Pre is normally bus-powered via USB, it can also be
powered by an external 5-Volt DC power adapter (optional) to allow it to be
used as a stand-alone stereo microphone preamplifier.
NOTE to PC Users:
When using a USB 1.1 port,
performance is limited to
16-bit and 44.1/48 kHz
recording and playback.
(USB 1.1 is not supported
on the Macintosh.)
8. USB
Connects the Tracker Pre to your computer via the supplied USB cable. The
USB connection provides two-way communication when connected to the
computer.
Since the Tracker Pre receives its power from the USB, always connect to the
USB jack on the computer itself and NOT to a low-power USB connection
that may be present on your computer keyboard or other USB peripheral.
9. Main Outputs (1L & 2R)
The balanced outputs are normally connected to your monitoring system.
Either balanced or unbalanced cables may be used. The main output volume
can be controlled using the System Volume Control on your Mac or PC. Many
“multimedia” computer keyboards contain System Volume Controls.
10. Phantom Power on/off
This switch turns 48V Phantom Power on or off to the XLR inputs for use with
microphones which require phantom power. See page 50 to learn more.
11. Inserts (1L & 2R)
These unbalanced TRS jacks allow you to insert a signal processor, such as a
compressor or EQ, after the mic preamps, but before the A/D converter stage.
See “Insert Connection Example” on page 13.
The Insert jacks can also be used to tap off the mic preamp outputs when
using the Tracker Pre as a stand-alone stereo microphone preamp. Page 13.
12. Hi-Z / Line / Mic Inputs (1L & 2R)
Use the XLR connector for microphones or balanced line level signals. Use the
1/4¨ jack in the center of the XLR connector as a Hi-Z input for guitar/bass, or
as a line level input. The inputs are balanced, but they accept either balanced
or unbalanced input signals. See page 49 for additional information.
13. Stereo Mic Input
This 1/8” mini-phone jack is designed to accept a stereo, electret condenser
microphone. The jack supplies +5VDC phantom power. Mono microphones
can also be connected and will use input 1L.
•Note: The Stereo Mic jack takes precedence over the Hi-Z/Mic/Line inputs.
Inserting a 1/8” plug disables the other inputs.
811 1291213710
System Volume Control
Mac
PC

E-MU USB Audio Control Panel
16 E-MU Systems
E-MU USB AUDIO CONTROL PANEL
After you have successfully installed the audio drivers, launch the E-MU USB
Audio control panel. The E-MU USB Audio control panel is shown below.
•Windows: The E-MU USB Audio control icon will be visible in the Taskbar,
which is normally located in the bottom right of the screen. It can
also be launched from the Start Menu
(All Programs, Creative Professional, E-MU USB Audio Application).
•OS X The E-MU USB Audio control application is located in the
Applications folder . You can also open the E-Control
Application using the icon on the desktop.
1. Skin
Choose between different appearances for the E-MU USB Audio control
panel.
2. View
Hide the application (Ctrl+H, Windows) You can restore the application by
clicking the E-MU icon in the System Tray (Windows), or by clicking the
E-MU icon in the Dock (OS X).
3. Help
About Tracker Pre USB 2.0, Audio control, Launch Manual, Check Updates
4. Device
If you are using more than one E-MU USB Audio device, you can choose
which unit is currently being controlled.
NOTE
There are some limitations
when operating at 176.4/
192k sample rates.
PC - No Direct Monitor
Mac - Disabled
5. Sample Rate
Allows you to set the system sample rate: 44.1kHz, 48kHz, 88.2kHz, 96kHz,
176.4kHz or 192kHz.
1
23
4
5

Direct Monitoring
TRACKERpre Reference Manual 17
DIRECT MONITORING
Direct monitoring allows you to monitor inputs without having any software
applications open. It can also be used as an alternative to software monitoring if
you desire the lowest latency monitoring possible.
When using a computer for digital recording, an audible time delay occurs while
the audio signal is being input to the computer, processed by the software and then
returned to the output for monitoring. This time delay is called Latency.
Latency becomes a problem when you have to use high buffer settings to conserve
CPU resources. Because the Tracker Pre has hardware direct monitoring, you can
enjoy zero latency regardless of your buffer setting.
NOTE
Direct monitoring is not
available when using the
176.4 kHz or 192 kHz
sample rates.
The Direct Monitor feature connects the input signals to the output when recording
so that you can hear your performance without delay. The Direct Monitor level
control lets you adjust the volume of the input signal in relation to the recorded
tracks.
Direct monitoring is controlled manually from the Direct Monitor switch on the
Tracker Pre. It’s not necessary to turn it on in your recording application.
Direct Monitoring vs. Software Monitoring
Direct monitoring is lower latency and can also be used without software running.
(or even without a computer connected!)
Software monitoring has the advantage of allowing audio effects or EQ added in
the host software to be heard on the output. Its round-trip latency depends on
what latency is chosen in the ASIO/Core Audio configuration. If you choose to
software monitor, make sure to disable direct monitoring. If both are enabled, you
will experience a ‘comb filter’ or doubling effect.
USB
Software Monitoring
Direct Monitoring
Latency (delay)
Direct Monitoring allows you to listen to the direct sound of your instrument during
recording, without the delay incurred by going to the computer and back.

Tutorials
18 E-MU Systems
TUTORIALS
Introduction
This guide contains step-by-step walk-throughs of basic recording operations using
your Tracker Pre interface with software applications for your Windows or
Macintosh OS X computer. We encourage you to perform the steps on your
computer as you read so that you become familiar with the process. The first
tutorial only takes about half an hour to complete, by which time you’ll know how
to make a multitrack recording.
NEED MORE HELP?
If you need additional help with the bundled applications, please see:
•Windows: Program Files\Creative Professional\
E-MU Tracker Pre USB\Documents\3rdParty.htm.
•OS X: Applications Drive\Library\Documentation\
E-MU Tracker Pre USB\ 3rdParty.htm\
Before you Begin...
• You should have already installed the E-MU and Third-Party software on your
computer.
WARNING!
Windows Users -
After checking your audio,
be sure to quit Windows
Media Player.
• You should hear the computer sounds coming out of the Tracker Pre and
your speakers when you play a CD or an MP3 using Windows Media Player or
iTunes. If not, make sure your Tracker Pre is properly connected according to
the diagram on page 12.
• A source of audio should be connected to the inputs (a microphone, musical
instrument, or CD/MP3 player).

Tutorials
TRACKERpre Reference Manual 19
Getting Started with Steinberg Cubase LE 4 (Windows, OS X)
Steinberg Cubase LE 4 is a 24-bit, multi-track audio/MIDI sequencer with high-
quality effects, automation, virtual instruments (VSTi), and many other profes-
sional features.
The following step-by-step tutorials are designed to get you recording as quickly as
possible.
1 - Setting up Cubase LE 4
Follow these instructions carefully to ensure that Cubase LE 4 runs smoothly the first
time. Cubase LE 4 will remember these settings, so you’ll only have to do this once.
1. Open Cubase LE 4 from the Start
menu. An ASIO multimedia driver
test dialog box will pop up to ask if
you want to run the ASIO test.
Choose No, because you won’t be
using the driver anyway.
2. Select New Project from the File
menu.
3. Select Empty and click OK.
4. A Select Directory pop-up dialog
box will appear. Choose a location
on your hard disk where you want to
store your audio files, then click OK.
5. The Cubase LE 4 Project window appears.
6. Select Device Setup… from the Devices menu.
7. Select VST Audio System from the left pane.
8. Choose ASIO E-MU TRACKER Pre|USB as the ASIO Driver. A pop up dialog
box asks you if you want to keep or switch the ASIO driver. Select Switch.
Buffer Latency Setting
9. Click on ASIO E-MU Tracker Pre|USB (located immediately below VST
Audio System in the Devices pane).
TIP . . .
If you have two or more
hard disks, it’s better to
store audio files on a disk
that isn’t running your
OS.
Step 9:
VST
Audio

Tutorials
20 E-MU Systems
10. Click the Control Panel button.
The pop-up dialog box shown at
right appears.
11. Set the ASIO Buffer Latency as low
as your computer will allow and
click OK.
(10ms is a good starting point.)
A low latency setting is important
to assure fast response when using
virtual instruments and to
minimize delay when monitoring
through Cubase. If you hear crackles or other audio problems, try increasing
the Buffer Size.
NOTE
If the Cubase LE 4 appli-
cation crashes for any
reason, it is recommended
that you re-boot the
computer.
12. Close the Device Setup screen by clicking OK.
Setting up a New Project
13. Select New Project from File menu in Cubase LE 4. A pop-up Template
selection dialog box appears. Select Empty, then click OK.
TIP . . .
If you have more than one
hard disk, it’s usually best to
store your audio files on a
disk that doesn’t contain
your operating system.
14. Another pop-up dialog box appears asking you to select the directory in which
your audio files will be stored. Choose a location to store your audio files and
click OK.
15. Select Project Setup (Shift +S) from the Project menu. This is where you set
the Sample Rate and Record Format (bit depth), among other things. Set the
Record Format to 24 Bit and the Sample Rate to 44.100 kHz.
Step 10
Control
Panel
Step 9
VST
Audio
