Enterasys RBTSA-AA User manual

END USER LICENSE AGREEMENT
Conventions2
Related Documentation 4
Accessing Online Documentation 4
1INTRODUCTION
Product Features6
Security6
Wireless Network Standards7
Network Configuration and Planning 8
Example Configurations 9
2INSTALLING THE ETHERNET ADAPTER
Unpacking the Ethernet Adapter 10
Observing Safety Precautions 11
Deciding Where to Place the Ethernet Adapter 12
Wall-Mounting the Ethernet Adapter12
Connecting the Ethernet Adapter 14
Connecting to a Serial Device 14
Connecting to an EthernetDevice 15
About the Client List 15
Connecting to a Hub 16
Connecting to a Network Printer 16
Connecting toa Computer17
Checking the LED Indicators 17
Attaching An External Antenna 19
Determining if you Need to Configure the Ethernet Adapter19
Using theEnterasys Networks InstallationCD 22
CONTENTS
ABOUT THIS GUIDE
Getting Help

3CONFIGURING THE ETHERNET ADAPTER
Using SecureWeb Server Connection 24
Using theEnterasys Networks Wireless Infrastructure Device Manager 25
Using the Configuration Management System 28
Clearing and ApplyingSystem Configuration Settings 29
Changing System Properties 30
Setting IP Network Properties 31
Setting Wireless Network Properties 32
Manually Selecting Radio Channels 34
Setting Up an Ad-Hoc Network 34
Changing Wireless Security Settings 35
Changing RADIUS Settings 38
Changing SNMP Settings 39
Using the Access Control List 39
Serial Port 41
Resetting the Ethernet Adapter 44
Restoring the Ethernet Adapterto Factory Defaults44
Upgrading the System45
Changing the Administration Login Name and Password46
Backing up a Configuration47
Restoring a Configuration 47
LoggingOut 47
Clearing the Ethernet Client List 48
Viewing Connection Status 48
Viewing System Summary49
4TROUBLESHOOTING
Diagnosing Problems 50
Disconnecting the Ethernet Adapter52
Uninstalling Softwareand Documentation 53
Upgrading Ethernet Adapter Firmware53
ARegulatory and Compliance Information

REGULATORY INFORMATION
Safety Compliance

END USER LICENSE AGREEMENT
Customer shall take all steps necessary to protect Wind River's and its licensors' proprietary rights in the
Run-Time Module and to ensure that each Run-Time Module distributed by Customer will be accompanied
by a localized copy of an End User License Agreement.
Such End User License Agreement shall prohibit the End User from: (i) copying the Run-Time Module, except
for archive purposes consistent with the End User's archive procedures; (ii) transferring the Run-Time Module
to a third party apart from the Target Application; (iii) modifying, decompiling, disassembling, reverse
engineering or otherwise attempting to derive the Source Code of the Run-Time Module; (iv) exporting the
Run-Time Module or underlying technology in contravention of applicable U.S. and foreign export laws and
regulations; and (v) using the Run-Time Module other than in connection with operation of the Target
Application.
In addition, the EndUser License Agreement shall: (i)state that the Run-Time Module is licensed, notsold and
that Customer and its licensors retain ownership of all copies of the Run-Time Module; (ii) expressly disclaim
all implied warranties, including without limitation the implied warranties of merchantability, fitness for a
particular purpose, title and non-infringement; (iii) exclude liability for any special, indirect, punitive,
incidental and consequential damages; and (iv) require that any further distribution of the Run-Time Module
be subject to the same restrictions set forth herein.
The End User License Agreement shall also state that, with respect to the Run-Time Module, Wind River and
its licensors are third party beneficiaries of the End User License Agreement and that the provisions related to
the Run-Time Module are made expressly for the benefit of, and are enforceable by, Wind River and its
licensors.
This guide provides all the information you need to install and use the
Enterasys Networks 802.11a/b/g Wireless Ethernet Adapter in its default state.
The guide is intended for use by IT managers and experienced network
installation and administration professionals who have a basic knowledge
of current networking concepts.
If the information in the release notes that are shipped with your product
differ from the information in this guide, follow the instructions in the
release notes.
Most user guides and release notes are available in Adobe Acrobat
Reader Portable Document Format (PDF) or HTML on the Enterasys
Networks World Wide Web site:
http://www.enterasys.com/products/wireless/

2ABOUT THIS GUIDE
Conventions Table 1 and Table 2 list conventions that are used throughout this guide.
Table 1 Notice Icons
Icon Notice Type Description
Information note Information that describes important features or
instructions.
Caution Information that alerts you to potential loss of data or
potential damage to an application, system, or device.
Achtung:Verweist auf wichtige Informationen zum Schutz
gegen Beschadigungen.
Warning Information that alerts you to potential personal
injury.
Warnung Warnung vor samtlichen Handlungen, die zu Verletzung
von Personen oder Todesfallen - hervorgerufen durch
elektrische Spannung - fuhren konnen!
Table 2 Text Conventions
Convention Description
Screen displays This typeface represents information as it appears on the
screen.
Syntax The word “syntax” means that you must evaluate the syntax
provided and then supply the appropriate values for the
placeholders that appear in angle brackets. Example:
To change your password, use the following syntax:
system password <password>
In this example, you must supply a password for <password>.
The words “enter”
and “type” When you see the word “enter” in this guide, you must type something, and then press Return or Enter. Do not press
Return or Enter when an instruction simply says “type.”
Keyboard key names If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+). Example:
Press Ctrl+Alt+Del

Conventions 3
Words in italics Italics are used to:
■Emphasize a point.
■Denote a new term at the place where it is defined in the
text.
■Identify menu names, menu commands, and software
button names. Examples:
From the Help menu, select Contents.
Click OK.
Table 2 Text Conventions (continued)
Convention Description

4ABOUT THIS GUIDE
Related
Documentation In addition to this guide, each Ethernet Adapter documentation set
includes the following:
■Quick Start Guide—printed guide that describes basic installation.
■Online Help—product help systems that describe how to use the
Configuration Management System and Enterasys Networks Wireless
Infrastructure Device Manager.
■Release Note—printed note that describes important product
information.
■README.TXT file—text file located on the Enterasys Networks
Installation CD that describes last-minute product information.
Accessing Online
Documentation The CD supplied with your Ethernet Adapter contains the following
online documentation:
■Enterasys Networks 802.11a/b/g Wireless EthernetAdapter User Guide
■Enterasys Networks Wireless Infrastructure Device Manager Online
Help
■Enterasys Networks 802.11a/b/g Wireless Ethernet Adapter Configuration
Management System Online Help
To access the online documentation from the CD:
1Insert the Enterasys Networks Installation CD supplied with your Ethernet
Adapter in the CD-ROM drive.
The setup menu appears. If it does not appear, you can start the setup
menu from the Windows Start menu. For example: Start > Run >
d:launch.exe.
2In the menu, click View the Documentation to view the Ethernet Adapter
User Guide.
To view the online help, install and launch the Wireless Infrastructure
Device Manager or Configuration Management System. See Chapter 3
for instructions.

1INTRODUCTION
Enterasys Networks wireless technology has all of the benefits of a local
area network (LAN) without the constraints and expense of network
wiring.
Enterasys Networks 802.11a/b/g Wireless LAN products provide easy,
affordable, flexible ways to extend wireless networks to more users. This
guideshows how you can use the Enterasys Networks 802.11a/b/g Wireless
Ethernet Adapter in your office or classroom to connect groups of wired
Ethernet client devices to your wireless LAN.
Product Features The Enterasys Networks 802.11a/b/g Wireless Ethernet Adapter includes a
robust suite of standards-based security features, and supports wireless
network standards including 802.11a and 802.11g.
Security To protect sensitive data broadcast over the radio, Enterasys Networks
supports Wireless Equivalent Privacy (WEP) RC4 64-bit, 128-bit and
152-bit shared-key encryption. Enterasys Networks strengthens this basic
security mechanism with additional security features, including:
■MAC address access control lists
■IEEE 802.1x per-port user authentication with RADIUS server
authentication support
■Temporal Key Integrity Protocol (TKIP)
■Advanced Encryption Standard (AES)
■WiFi Protected Access (WPA)
■Extensible Authentication Protocol (EAP) support: EAP-TTLS and PEAP

7CHAPTER 1: INTRODUCTION
Wireless Network
Standards Understanding the characteristics of the 802.11a and 802.11g standards can help you make the best choice for your wireless implementation plans.
802.11a
Ratified in 2002, 802.11a is IEEE’s more recent wireless standard. It
operates at the 5 GHz band and supports data rates at up to 54 Mbps.
Because there are fewer devices in the 5 GHz band, there’s less potential for
RF interference. However, because it is at an entirely different radio spectrum,
it is not compatible with 802.11g.
The higher spectrum provides about 50 m (164 ft) of coverage—about
half what 802.11g offers.
Consider 802.11a when you need high throughput in a confined space
and you are:
■Running high-bandwidth applications like voice, video, or multimedia
over a wireless network that can benefit from a five-fold increase in
data throughput.
■Transferring large files like computer-aided design files, preprint
publishing documents or graphics files, such as MRI scans for medical
applications, that demand additional bandwidth.
■Supporting a dense user base confined to a small coverage area.
Because 802.11a has a greater number of non-overlapping channels,
you can pack more wireless devices in a tighter space.
802.11g
802.11g operates in the 2.4 GHz band at up to 54 Mbps. Ratified in
2003, it supports the widest coverage—up to 100 m (328 ft). However, is
subject to a greater risk of radio interference because it operates in the more
popular 2.4 GHz band.
802.11b operates at up to 11 Mbps and supports coverage up to 100 m
(328 ft).

Network Configuration and Planning8
Consider 802.11g when you need wider coverage and vendor
compatibility and you are:
■Maintaining support for existing 802.11b users and the existing
wireless investment while providing for expansion into 802.11g.
■Implementing a complete wireless LAN solution, including Ethernet
Adapters, gateways, access points and clients; Wi-Fi certification
guarantees compatibility among vendors.
■Providing access to hot spots in public spaces such as coffee shops or
university cafeterias.
Network
Configuration and
Planning
The Ethernet Adapter can operate in either infrastructure or ad-hoc
mode, and can support a stand-alone wireless network configuration or
an integrated configuration with 10/100 Mbps Ethernet LANs.
Operating in infrastructure mode and connected to an Ethernet hub, a
single Ethernet Adapter can combine up to 16 client devices—such as
computers with network adapters and printers—into a multiclient
workgroup. The workgroup associates with the wired network through a
wireless LAN access point such as the Enterasys Networks 802.11a/b/g
Wireless LAN Access Point. Infrastructure configurations extend your
wireless LAN to devices that would otherwise have to be connected to
the wired network.
Operating in ad-hoc mode, two or more Ethernet Adapters can associate
among themselves and communicate with one another at close range
without an access point. You may wish to set up an ad-hoc network, for
example, if a group is working away from the office, or if a group in the
office needs to share files apart from the wired LAN.

9 CHAPTER 1: INTRODUCTION
Example
Configurations The following examples illustrate ways you can use the Ethernet Adapter to
configure Ethernet client devices into workgroups. (Details for setting up
specific configurations are in “Installing the Ethernet Adapter” on page 11.)
Wireless Infrastructure Network
You can connect several computers, including those with non-Windows
operating systems, and network printers, as shown in Figure 1.
Figure 1 Wireless Infrastructure Network
Workgroup Ad-Hoc Network
You can provide flexible wireless network association for small groups in
areas that cannot be wired, as shown in Figure 2.
Figure 2 Workgroup Ad-Hoc Network
POWER
POWER
ETHERNET
ETHERNET
WIRELESS
WIRELESS
POWER
POWER
ETHERNET
ETHERNET
WIRELESS
WIRELESS
Access
Point
802.11a/b/g Wireless
Ethernet Adapter
Hub
802.11a/b/g Wireless
Ethernet Adapter
Hub
802.11a/b/g Wireless
Ethernet Adapter
Hub

2INSTALLING THE ETHERNET
ADAPTER
This chapter contains the information you need to install and set up the
Ethernet Adapter. It covers the following topics:
■Unpacking the Ethernet Adapter
■Observing Safety Precautions
■Deciding Where to Place the Ethernet Adapter
■Connecting the Ethernet Adapter
■Checking the LED Indicators
■Attaching An External Antenna
■Determining if you Need to Configure the Ethernet Adapter
■Using the Enterasys Networks Installation CD
Unpacking the
Ethernet Adapter Make sure that you have the following items, which are included with the
Ethernet Adapter:
■Power adapter and power cord.
■Standard Category 5 unshielded twisted pair (UTP) Ethernet cable.
■Rubber feet (four; used for a flat-surface installation).
■Enterasys Networks Installation CD.
For wall-mounting installations, you need the following items, which
are not included with the Ethernet Adapter:
■Mounting screws.
■Plastic anchors (for drywall mounting).

11 CHAPTER 2: INSTALLING THE ETHERNET ADAPTER
Figure 3 shows the front view of the Ethernet Adapter, including the LEDs and
connecting ports. It also shows the cradle, which is used to mount the
Ethernet Adapter to a wall or to install the Ethernet Adapter on a flat surface.
Figure 3 Ethernet Adapter
Observing Safety
Precautions This equipment must be installed in compliance with local and national
building codes, regulatory restrictions, and FCC rules. For the safety of
people and equipment, only professional network personnel should
install the Ethernet Adapter.
WARNING: To comply with FCC radio frequency (RF) exposure limits, a
minimum body-to-antenna distance of 20 cm (8 in.) must be maintained
when the Ethernet Adapter is operational.
WARNING: To avoid possible injury or damage to equipment, you must
use either the provided power supply or power supply equipment that is
safety certified according to UL, CSA, IEC, or other applicable national or
international safety requirements for the country of use. All references to
power supply in this document refer to equipment meeting these
requirements.
WARNUNG: In Übereinstimmung mit den von der FCC (Federal
Communications Commission) festgelegten Grenzwerten für die
Einwirkung von Radiowellen muss bei Betrieb des Ethernet-Adapters der
Abstand zwischen Körper und Antenne 20 cm betragen.
WARNUNG: Zur Vermeidung möglicher Verletzungen oder Schäden am
Gerät muss entweder das mitgelieferte Netzteil oder ein Netzteil
verwendet werden, das von der UL (Underwriters Laboratories Inc.), CSA
Power Port
802.11a/b/g Wireless
Ethernet Adapter
Serial Port
Ethernet Port

Deciding Where to Place the Ethernet Adapter 12
(Canadian Standards Organisation), IEC (International Electrotechnical
Commission) oder von anderen, nationalen oder internationalen
Sicherheitsvorschriften für das entsprechende Land zugelassen wurde.
Alle Verweise auf Netzteile in diesem Dokument beziehen sich auf
Netzgeräte, die diesen Anforderungen entsprechen.
CAUTION: The Enterasys Networks power supply (part number
61-0107-000) input relies on a 16A rated building fuse or circuit
protector for short circuit protection of the line to neutral conductors.
VORSICHT: Der Eingang des Enterasys Networks-Netzteils (Teilenummer
61-0107-000) benötigt zum Schutz vor Kurzschlüssen in den Nullleitern
eine 16-A-Sicherung oder eine Überstromsicherung.
Deciding Where to
Place the Ethernet
Adapter
Place the Ethernet Adapter in a dry, clean location near the hub,
computer, or printer that will be connected to the Ethernet Adapter. The
location must have a power source and be within the following distance
of a Wi-Fi compliant wireless LAN access point or ad-hoc wireless station:
■For 802.11a compatibility, place the Ethernet Adapter within 50 m
(164 ft) of a Wi-Fi compliant wireless LAN access point.
■For 802.11b/g compatibility, place the Ethernet Adapter within 100 m
(328 ft) of a Wi-Fi compliant wireless LAN access point.
The location should be away from transformers, heavy-duty motors,
fluorescent lights, microwave ovens, refrigerators, or other equipment
that could cause radio signal interference.
Wall-Mounting the
Ethernet Adapter The Ethernet Adapter comes with two plastic anchors and two flat head mounting screws for mounting on a wall.

13 CHAPTER 2: INSTALLING THE ETHERNET ADAPTER
To wall-mount the Ethernet Adapter:
11 Place the two plastic anchors into a wall, then place two flat head
mounting screws inside the plastic anchors, as shown in Figure 4.
Figure 4 Place the screw on the wall
2Place the Ethernet Adapter onto the wall, as shown in Figure 5.
Figure 5 Place the unit onto the wall
CAUTION: Do not place the Ethernet Adapter on any type of metal
surface. Select a location that is clear of obstructions and provides good
reception.
VORSICHT: Legen Sie den Ethernet-Adapter nicht auf Metallflächen ab.
Wählen Sie einen Ort ohne Störungen und mit gutem Empfang aus.
