Epson SF-510 User manual

mi
UserManual
GPSSportsMonitor

Introduction
1
Introduction
To use the product correctly, make sure you read this User Manual along with the supplied Quick Start Guide.
Keep the Quick Start Guide handy to help you resolve any problems. Your product may look different from the
illustrations in this guide, but the instructions are the same.
Descriptions in the User Manual
Trademarks
EPSON is a registered trademark, EPSON Exceed Your Vision is a registered logomark, and Runsense is a
trademark of Seiko Epson Corporation.
iPhone is a trademark of Apple Inc., registered in the U.S. and other countries.
The Bluetooth word mark is owned by Bluetooth SIG, Inc.
Android is a trademark of Google Inc.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of
their respective owners. Epson disclaims any and all rights in those marks.
Caution:
OUnapproved copying of part or all of this guide is strictly forbidden.
OThe content of this guide is subject to change without prior notice.
OWe cannot accept any responsibility for mishandling due to errors in this guide.
OWe cannot accept any responsibility for malfunctions and so on that occur due to ignoring the content of this
guide, the product being handled inappropriately, repairs or modifications performed by a third party that is
not our company or appointed by our company.
cImportant: Indicates things you must or must not do. Ignoring these instructions or mishandling
this product could cause malfunction or operational problems to the product.
Note: Indicates additional explanations and related information.
Menu Name Indicates menu items displayed on the screen of the product.
A/B/C or D Indicates the product buttons.
See “Descriptions in the User Manual”
on page 1.
Indicates related pages. Click the link in blue text to display the related page.

Introduction
2
Features
Chronograph function
Interval function
Goal function (timed race)
Allows you to measure workout data such as distance and time.
You can measure split and lap times, as well as use the GPS signal to measure distance and pace.
See “Measuring time, distance, and speed” on page 30.
You can use the recall screen to check your workout history.
See “Viewing past workouts” on page 48.
Allows you to perform interval training.
See “Using the interval function” on page 33.
Allows you to set a time as your goal and measure the time remaining until that goal is reached.
See “Using the goal function” on page 39.
You can use the recall screen to check your workout history.
See “Viewing past workouts” on page 48.

Introduction
3
Goal function (distance race)
Measurement function
Allows you to set a distance as your goal and measure the distance taken until that goal is
reached.
You can exercise while checking the distance. You can also calculate the estimated total time to
complete the set distance.
See “Using the goal function” on page 39.
You can use the recall screen to check recorded measurement data.
See “Viewing past workouts” on page 48.
Allows you to track a wide variety of data during your workout. You can:
OAutomatically record a lap when a set time or distance has been reached (AT Lap function)
See “Recording laps automatically” on page 43.
OAutomatically stop measuring when you stop running, and resumes when you continue
running (AT Pause function)
See “Starting/stopping measurement automatically” on page 44.
OSet and measure your target pace for one mile or kilometer
See “Setting a pace” on page 45.
OMonitor your heart rate with the optional heart rate chest strap
See “Wearing the heart rate chest strap” on page 60.
OChange the items and layout of the Measurement screen display (Screen settings function)
See “Screen settings” on page 86.
OTap to display a set function
See “Tap” on page 28.

Introduction
4
Settings
Other features
Allows you to change the settings for the product.
OCommunicate with external devices
See “Comm. Settings” on page 83.
OInvert the screen's display (Invert function)
See “System Set. options” on page 85.
OAdjust the screen's contrast (Adjust contrast function)
See “System Set. options” on page 85.
OTurn on the light automatically when the screen changes (Auto Light function)
See “System Set. options” on page 85.
OSet an alarm (Alarm function)
See “System Set. options” on page 85.
OTurn off operation tones (Operation Tones function)
See “System Set. options” on page 85.
OReset configuration information in the product's memory (Initialize function)
See “System Set. options” on page 85.
OYou can measure pitch and stride using the built-in stride sensor.
See “Calibrating the sensor” on page 21.
OYou can skip GPS positioning if it is taking too long.
See “Skipping GPS positioning” on page 19.
OYou can measure without performing GPS positioning.
See “Indoor mode” on page 19.
OYou can monitor, analyze, compare and share your recorded data using the RUNSENSE View
web app.
See “Using RUNSENSE View” on page 50.

Table of contents
5
Table of contents
Introduction
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Using your SF-510/SF-710 safely
Symbols in this manual . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Caring for your SF-510/SF-710 . . . . . . . . . . . . . . . . . . . 8
Notes on Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Notes on using the product and components . . . . . 9
Notes on using the cradle . . . . . . . . . . . . . . . . . . . . . . 9
Notes on Electromagnetic Waves . . . . . . . . . . . . . . . . 10
Setting up your SF-510/SF-710
What’s in the box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Before use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
About the battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
GPS Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Measuring function for the product . . . . . . . . . . . . 18
GPS positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Indoor mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Making precise measurements . . . . . . . . . . . . . . . . 20
Calibrating the stride sensor. . . . . . . . . . . . . . . . . . . . . 20
About the stride sensor. . . . . . . . . . . . . . . . . . . . . . . 20
Calibrating the sensor . . . . . . . . . . . . . . . . . . . . . . . . 21
Measurable items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Basic operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Changing screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Button functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Tap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Alarm (tones/vibration) . . . . . . . . . . . . . . . . . . . . . . 28
Measuring your workouts
Measuring time, distance, and speed. . . . . . . . . . . . . . 30
What is the chronograph function? . . . . . . . . . . . .30
Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Screen display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Using the interval function . . . . . . . . . . . . . . . . . . . . . . 33
What is the interval function? . . . . . . . . . . . . . . . . .33
Creating and using interval presets. . . . . . . . . . . . . 33
Loading interval presets . . . . . . . . . . . . . . . . . . . . . . 35
Screen display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Using the goal function . . . . . . . . . . . . . . . . . . . . . . . . .39
What is the goal function?. . . . . . . . . . . . . . . . . . . .39
Setting and measuring a goal . . . . . . . . . . . . . . . . . .40
Screen display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Recording laps automatically . . . . . . . . . . . . . . . . . . . .43
Starting/stopping measurement automatically . . . . .44
Setting a pace. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Checking past workouts
Viewing past workouts. . . . . . . . . . . . . . . . . . . . . . . . . .48
Measurement icons . . . . . . . . . . . . . . . . . . . . . . . . . .48
Deleting past workouts . . . . . . . . . . . . . . . . . . . . . . .49
Using RUNSENSE View
What is RUNSENSE View?. . . . . . . . . . . . . . . . . . . . . .51
Installing Epson Run Connect software . . . . . . . . . . .52
Creating a RUNSENSE View account . . . . . . . . . . . . .52
Uploading data to RUNSENSE View . . . . . . . . . . . . .54
Checking uploaded workout data . . . . . . . . . . . . . . . .56
Measuring heart rate
Wearing the heart rate chest strap . . . . . . . . . . . . . . . .60
Preparing the heart rate chest strap. . . . . . . . . . . . .60
Wearing the heart rate chest strap. . . . . . . . . . . . . .60
Pairing the heart rate chest strap . . . . . . . . . . . . . . .61
Enabling heart rate monitoring . . . . . . . . . . . . . . . .63
Measuring heart rate . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Checking the connection . . . . . . . . . . . . . . . . . . . . .64
Displaying your heart rate . . . . . . . . . . . . . . . . . . . .64
Replacing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Disabling heart rate monitoring. . . . . . . . . . . . . . . . . .68
Using your SF-510/710 with a comput-
er
Epson Run Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Viewing the Model Settings screen (SF-710 only) . . .71
Adjusting the AT Lap settings (SF-710 only) . . . . . . .73
Adjusting the AT lap settings. . . . . . . . . . . . . . . . . .73
Setting the Target Pace Function (SF-710 only) . . . .74
Setting the target pace . . . . . . . . . . . . . . . . . . . . . . . .74
Setting the Interval function (SF-710 only) . . . . . . . .76
Setting intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Settings

Table of contents
6
Measurement settings . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Changing measurement settings . . . . . . . . . . . . . . . 80
Measure set. options . . . . . . . . . . . . . . . . . . . . . . . . .81
General settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Changing settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Settings options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Screen settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Customizing the measurement screen . . . . . . . . . . 86
Screen Layout options. . . . . . . . . . . . . . . . . . . . . . . . 88
Measurement display abbreviations . . . . . . . . . . . . 90
Maintenance
Caring for your product . . . . . . . . . . . . . . . . . . . . . . . . 94
About the strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
About your SF-510/SF-710 battery . . . . . . . . . . . . . . . 94
About the product’s built-in rechargeable battery 94
Updating the firmware . . . . . . . . . . . . . . . . . . . . . . . . . 94
Checking the firmware version . . . . . . . . . . . . . . . . 94
Updating the firmware . . . . . . . . . . . . . . . . . . . . . . . 95
Troubleshooting
Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Problem solving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Resetting the system. . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Where to get help . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
Appendix
Understanding product icons. . . . . . . . . . . . . . . . . . .102
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Product specifications. . . . . . . . . . . . . . . . . . . . . . .102
Cradle specifications . . . . . . . . . . . . . . . . . . . . . . . .103
AC adapter specifications (optional) . . . . . . . . . .103
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

Using your SF-510/SF-710 safely
7
Using your SF-510/SF-710 safely
Make sure you read the manuals (Quick Start Guide and User Manual) first to use this product safely.
The product may malfunction, or an accident may occur if it is handled incorrectly.
OKeep the manuals handy to help you resolve any problems.
OWhen taking this product out of the country of purchase, check the laws and regulations in the destination
country before you travel.
OThis product is not a medical device. Use this product as an indicator during physical exercise.
Symbols in this manual
The following symbols are used in this guide to indicate possible dangerous operations or handling. Make sure you
understand these warnings before using the product.
Warning:
This symbol indicates information that, if ignored, could possibly result in serious personal injury.
Caution:
Ignoring these instructions and mishandling this product could cause injury or damage to property.
This symbol indicates an action that should be done.
This symbol indicates an action that must not be done.

Using your SF-510/SF-710 safely
8
Caring for your SF-510/SF-710
Your Runsense product is made from materials commonly used in watches and other consumer products. Since you
may wear your product over extended periods, including when you are exercising and sweating, it is important that
you take care of your skin and your product according to these instructions. Prolonged wearing of your product
without proper care could lead to skin irritation or rash.
Please follow the precautions below to ensure full enjoyment and benefit of your Runsense product:
1Keep Runsense and skin clean:
OClean the back of your product and the skin beneath on a regular basis, particularly after exercise, to
remove trapped dirt, sweat, lotion, sunscreen and other potentially irritating substances. You may also
use a soft brush to clean the back of your product.
ODo not use household, abrasive, or commercial cleaners on the product.
OSweat can be corrosive because it contains salt. Remove the product, rinse your skin carefully and
thoroughly and wipe the Runsense product with a soft damp cloth to make sure that no sweat, soap,
lotion or other material remains on the skin or under the product before replacing it on your arm.
ODo not submerge the Runsense product in water or wear it in the shower or bath.
ODo not allow products such as soap, lotions, sunscreen, dirt and sweat to build up under the product.
2Keep Runsense and skin dry:
OIf your Runsense product gets wet, such as from sweating, remove after use and clean your wrist and
Runsense product thoroughly.
OMake sure that both the product and the skin beneath the product are thoroughly dry before replacing
on your arm.
ODo not let a wet Runsense product remain in contact with skin for prolonged periods of time.
3Give skin a rest and some air.
OYour Runsense product should be worn snugly—not too loose or too tight.
OWhen putting on the product, make sure it does not rest on your wrist bone (ulna). This will be
uncomfortable and also interfere with the operation of the sensor.
OAlthough your product is intended for extended wear, prolonged touching or rubbing could lead to skin
irritation. Give your skin a break by periodically removing the product for an hour or so. You must also
take off the product while it charges.

Using your SF-510/SF-710 safely
9
Notes on Usage
Notes on using the product and components
Notes on using the cradle
Warning
Exercise according to your physical capabilities. Stop exercising and consult your doctor if you feel unwell
during exercise.
Persons with high skin sensitivity, eczema, allergies, or asthma may be more likely to experience skin irritation
or an allergic reaction from the Runsense product or similar products. Even persons without such conditions
may start to experience redness or skin irritation on wrists from prolonged use or if the product is not cleaned
regularly as indicated above. If you experience such symptoms:
OStop wearing and remove your product immediately. Do not put it back on.
OIf symptoms persist for more than 2-3 days after removing the product, consult a dermatologist.
OMake sure to follow the wear and care instructions above.
Do not use or store this product in the following environments. It may cause an electric shock or fire, or the
product may malfunction or be damaged.
OLocations with very high or low temperatures or humidity
ONear volatile substances
ODusty places
ONear a strong magnetic field (for example, near a loudspeaker)
Do not disassemble this product, and do not attempt to repair this product by yourself. It may cause an electric
shock or accident.
Do not leave this product within reach of young children.
Stop using the product immediately and consult your doctor if you have an allergic reaction or a rash during
use.
The product is water resistant at 5 bar (5 ATM). Although you can use the product for swimming, do not perform
button operations under water.
Do not pour water directly from the tap onto this product. The power of the tap water stream may be strong
enough to compromise the product’s waterproof feature.
Do not wear this product in a bath or sauna. The steam and soap may compromise the waterproof feature or
cause corrosion.
Do not use the cradle or AC adapter if they are in any way damaged, faulty or contaminated by foreign material
such as dust, water or dirt. Do not use any adapter other than the specified adapter for charging.
