Equator CMO 800 T User manual

1
Combo Microwave-Oven
Model – CMO 800 T
INSTALLATION GUIDE
these

MICROWAVE INSTALLATION KIT
450
28.4
568
94.7
320
380
1
2
4
35
6
7
8
Cabinet Measurement Requirements (illustrated above):
1. Cabinet's inner dimension in transverse direction is 22.36''. This is the minimum distance from the left batten to right batten.
Do not alter.
2. Cabinet's inner dimension in lengthways direction is 14.37''. This is the minimum distance from the left batten to right batten.
Do not alter.
3. Cabinet's depth should be no less than 21.65''.
4. Outside dimension of cabinet should be no less than 23.46'' as the frame length is 23.31''.
5. Cabinet's board less than 0.59'' or 0.78'' thick.
Attention: The bottom of the Microwave Oven should be 33.50"
away from the floor at least while doing the installation.
Microwave Oven Cabinet
vent
MICROWAVE CAVITY
vent
21.65''
5.91''
21.65''
5.91''
14.37''
3.94''
22.36''
15.75''
2
1. Frame
2. Fixing Bolt
3. Bolts (0.12” x 0.47”)
1 pc
4 pcs
8 pcs
4. Metal Piece
5. Base Seng Paper
6. Mounng Bracket
1 pc
1 pc
2 pcs
7. Bolts (0.16” x 10.39”)
8. Locking Bracket
9. Vent Shroud
4 pcs
2 pcs
1 pc
Technical Specifications of the Installation Kit
Overall Kit Dimensions Cavity dimensions
Internal Width 22.36''
External FRONT HEIGHT 14.37''
Depth 21.65''
Width 23.31''
Height 14.80''
Depth 0.79''
9

5
6
7
Install the Vent Shroud to the top of the microwave above the
air inlet using the screws provided.
Vent Shroud
INSTALLATION STEPS
Fix the cabinet as per diagram above. Put the base setting paper
(Component 5) on the bottom board of the cabinet cavity. Keep the
paper’s front edge and cabinet outside edge in one line. Then put the
base (Component 6) on the paper and adjust adjust their holes as per
the hole position in the drawing. Then, fix the required bolts.
N.B. Indentation is on
left-hand side
5. Keep the Microwave Oven in a horizontal direction.
Push the metal piece of the frame into the metal buckle.
The frame should now be installed.
Assemble fix metal sheet to the front
two feet after the oven fixed
2.
4. Put the Microwave Oven carefully into the cabinet, placing the
underside of the Microwave Oven into the base plate now created.
Metal Sheet
3
Fix Metal sheet end on the left and right of cabinet, another end
on the upper and lower of cabinet. After fixing the metal sheet, then
fix the buckle and let it touch another end of metal sheet tightly.
Please pay attention that buckle’s bent side shall be installed as to
the drawing while fixing the buckle. Then press the buckle and take
away metal sheet, tighten screws.
3.
1.
