ERA Audio-Video System Assembly instructions

DVD PLAYER WITH
DELUXE SOUND
The DVD player is a selectable
function of the multi-featured audio
system. The player unit contains DVD/
CD/MP3/AM-FM stereo radio. It also
accepts portable audio player inputs and
functions as an alarm clock.
The player is connected directly to
the TV and can output sound to either
the stereo speakers in the TV or to the
Deluxe Sound speakers in the lounge
area of the coach.
Refer to the manufacturer’s user
guide provided in your InfoCase for
complete feature descriptions and
operating instructions.
Provide 12V Power
The TV and
DVD player
operate on 12-volt
DC current.
• Turn ON the
Master 12V
Power switch
(located on
underside of
cabinet near
TV).
NOTE: When
the TV is not in use, the Master 12V
Power switch should be turned OFF
to eliminate drain on the 12-volt
house battery.
Connect Deluxe Sound
Speakers
• Press the TV/
Radio Speaker
Selector switch
(located near the
DVD player) to
theTVpositionto
connect speakers
to TV and DVD
player.
Set TV Video Input
• Turn TV and DVD player ON.
• PresstheMODEbuttonontheTVor
the SOURCE button on the DVD
player remote and select “INPUT 1”.
• TheTVscreen
will display
the DVD
player logo
when the
correct input is selected.
Play DVD
• InsertDVDfaceupintoslotonlower
face of the player.
• The DVD will begin to load
automatically. The TV screen will
typically display READING or
LOADING.
• The DVD may load directly
to the main title/menu screen
or it may begin to play
previews.Youmaybeableto
skip previews if desired by
pressing the NEXT button on the
DVDplayerremote until youseethe
main menu screen.
• Whenthemain
menu screen
appears, press
the ENTER
button on the
DVD player
remote or
PLAY/PAUSE
button on DVD player to begin
playing the main feature. Use the
arrow buttons on the DVD remote to
select another feature to play.
• Volume is adjusted with the DVD
remote.
Master 12V
Power Switch
(Located on underside
of cabinet near TV)
TV/RadioSpeaker
Selector Switch
(Located near
DVD player)
Continued—

Audio-Video System
Basic Operation
Guide
Part No. 161501-12-001
Rev. 1203120206
Copyright 2011 Winnebago Industries, Inc.
All rights reserved.
NOTE: See your InfoCase for specific
operating guides for audio and
video components.
Further Information
See the manufacturer’s quick
reference guide provided in your
InfoCase for complete feature
descriptions and operating instructions.
