Ercogener EG-IoT-40B1 User manual

ZI Chacé - Rue Docteur Weiss –F-49400 SAUMUR
Tél. : [phone]
SAS CAPITAL 500 000 € / R.C. ANGERS B 801 206 228 / SIRET 801 206 228 00018
User Guide
EG-IoT Demonstrators
EG-IoT-40B1 EG-IoT-4281 EG-IoT-4EA6 EG-IoT--4AB1 EG-IoT-4E81
EG-IoT-80B1 EG-IoT-8281EG-IoT-8AA6 EG-IoT-8AB1
Reference : EG-IoT_UG_demonstrator_006_UK
Rev.
Modifications
Author
Date
Validation
Date
000
Creation of preliminary version
YST/EFO
02/08/2017
001
Evolution LoRa frame format
PBR
21/08/2017
002
Additional info. Identifier management
LoRa/Sigfox, demo telemetering/counting/hour
meter
EFO/PBR
21/08/2017
003
Details about USB
Addition example of display
LGO
01/09/2017
004
Addition TCP
EFO
11/09/2017
005
Addition UDP, adjustment LoRa configuration
EFO
27/11/2017
MSU
01/12/2017
006
Additional information
YST
07/12/2017
The main modifications in this document compared to its previous version are easily identifiable by the blue color
of the text.

EG-IoT_UG_demonstrator_006_UK.docx
Page 2 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
TABLE OF CONTENTS
WARNING ......................................................................................................................................................... 4
SYMBOLS USED.............................................................................................................................................. 4
COPYRIGHT...................................................................................................................................................... 5
1PRESENTATION OF THE DEMONSTRATOR PRODUCTS .................................................................. 6
2.1 PACKAGING ....................................................................................................................................... 6
3TECHNICAL CHARACTERISTICS.......................................................................................................... 7
3.1 GENERAL........................................................................................................................................... 7
3.2 ACCELEROMETER,MAGNETOMETER ................................................................................................... 7
4OPERATING MODES............................................................................................................................... 7
5CONFIGURATION VIA INTERNAL SERIAL LINK.................................................................................. 8
5.1 OPENING THE CASING ......................................................................................................................... 8
5.2 INSTALLATION OF SIM CARD............................................................................................................... 9
5.3 POWER SUPPLY CONNECTION.............................................................................................................. 9
5.4 USB/TTL CABLE CONNECTION ........................................................................................................... 9
5.5 ACCESS TO CONFIGURATION MENU.................................................................................................... 10
5.6 UPDATE OF EMBEDDED SOFTWARE VIA BOOT LOADER ....................................................................... 15
5.7 CLOSING THE CASING ....................................................................................................................... 17
5.8 FIXING.............................................................................................................................................. 18
5.8.1 Standard.................................................................................................................................... 18
5.8.2 Installation ................................................................................................................................ 18
6DEMONSTRATION APPLICATION:...................................................................................................... 19
6.1.1 Principle.................................................................................................................................... 19
6.1.2 Application in tracking mode: ................................................................................................ 20
6.1.2.1 Operating chronogram and kind of frame .....................................................................20
6.1.2.2 Payload for Sigfox network or LoRa network ...............................................................21
6.1.2.3 Frame sent by SMS ..........................................................................................................22
6.1.2.4 Frame sent via TCP or UDP.............................................................................................23
6.1.3 Application with mode telemetering / pulse counting / Hour meter:.................................. 24
6.1.3.1 Operating chronograms and kind of frames .................................................................24
6.1.3.2 Functioning of inputs.......................................................................................................24
6.1.3.3 Counting............................................................................................................................25
6.1.3.4 Hour meter ........................................................................................................................25
6.1.3.5 Front detection .................................................................................................................25
6.1.3.6 Payload for Sigfox or LoRa ............................................................................................26
6.1.3.7 Frame sent via SMS ........................................................................................................27

EG-IoT_UG_demonstrator_006_UK.docx
Page 3 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
6.1.3.8 Frame sent via TCP or UDP.............................................................................................28
7INTERFACE ON M8 CONNECTOR....................................................................................................... 29
7.1 CONTACT INPUT................................................................................................................................ 29
7.2 OPTO-COUPLED INPUT...................................................................................................................... 29
7.3 POWER SUPPLY +VCC ....................................................................................................................... 30
ANNEX 1 - 8-WIRE CABLE............................................................................................................................ 31
ANNEX 2 –USB –TTL 4-PIN CABLE ............................................................................................................. 32
ANNEX 3 –GSM (RSSI/QUAL) LTE (RSRQ/RSRP) ..................................................................................... 33

EG-IoT_UG_demonstrator_006_UK.docx
Page 4 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
Warning
This document contains the commissioning information for engineering samples EG-IoT_xxxx based on an
embedded demonstration application.
ERCOGENER cannot be held responsible for:
- Problems arising from improper use of the EG-IoT xxxx.
- Problems arising from improper configuration
- Dysfunctions arising from the absence or poor coverage of GSM, GPRS, UMTS, LTE Cat.M1, GNSS, LoRa,
Sigfox networks
- Dysfunctions if the product is used for the monitoring of physical persons where human life is at stake.
ERCOGENER reserves the right to modify the functionalities of its products "EG-IoT xxxx" without prior
notice.
-When the equipment is open, do not carry out any operations other than those provided for in this
document.
- No internal parts can be repaired by the user. The EG-IoT xxxx must be returned to the factory for repairs.
- In order to ensure electromagnetic compatibility, the length of the serial link cable, the power cable and the input /
output cable must not exceed a length of 3 meters.
- The EG-IoT xxxx must not be powered directly by the mains, a voltage adapter must be used.
DISPOSE OF BATTERIES AND USED BATTERIES IN ACCORDANCE WITH USUAL
INSTRUCTIONS.
Symbols used
The following symbols are used to highlight important information in the manual.
Essential information for the integration and performance of the module.
Warning indicating actions that could harm or damage the module

EG-IoT_UG_demonstrator_006_UK.docx
Page 5 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
Copyright
Reproduction, transfer, distribution or storage of part or all of the contents of this document, in any form whatsoever,
without the prior written permission of ERCOGENER is prohibited.
EG-IoT xxxx is a trademark of ERCOGENER.
The use of certain products or services described in this document may require subscription to a paid service. The
availability of certain products or services described in this document may vary depending on the configuration and
hardware.
In some countries, there may be restrictions on the use of devices. Check with the local legal authorities.
The contents of this document are provided "as is". Except as required by applicable laws, no warranty of any kind,
either express or implied, including but not limited to implied warranties of merchantability and fitness for a particular
purpose, is granted as to the accuracy, reliability or content of the document. ERCOGENER reserves the right to
revise this document or withdraw it at any time without notice.
ERCOGENER cannot be held responsible for any loss of data or income, as well as for
any special, incidental, consequential or indirect damage.

EG-IoT_UG_demonstrator_006_UK.docx
Page 6 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
1 Presentation of the demonstrator products
Products from the EG-IoT-xxxx family are suitable for harsh outdoor environments. They are all waterproof and
resistant to mechanical shocks.
Compact, with integrated long-range antennas and a long battery life, they are easy to implement.
The ability to have two communication technologies LPWAN+3G allows to have a product dedicated to critical
applications.
These products are intended for use in various applications such as geolocation, remote control, metering, remote
supervision …
This document presents the general characteristics and the implementation of functional demonstrators.
Table 1 : General Presentation
Product
LPWAN
Cellular
GNSS
BLE
M8 interface
P.supply
Input
EG-IoT
Ana.
Opto
Conta
ct
One
Wire
Out
RS485
Pwr
40B1
LoRa
-
-

2*
-
2
1*
-
-
-
Battery
4281
LoRa
-


-
-
-
-
-
-
-
Battery
4AA6
LoRa
2G/3G


-
2
-
1*
Co*
1*
1
Ext./Lithi
um Bat.
4AB1
LoRa
2G/3G


2*
-
2
1*
-
-
-
Battery
4E81
LoRa
LTE Cat.M1


-
-
-
-
-
-
-
Battery
80B1
Sigfox
-
-

2*
-
2
1*
-
-
-
Battery
8281
Sigfox
-


-
-
-
-
-
-
-
Battery
8AA6
Sigfox
2G/3G


-
2
-
1*
Co*
1*
1
Ext./Lithi
um Bat.
8AB1
Sigfox
2G/3G


2*
-
2
1*
-
-
-
Battery
*Currently under development
LPWAN
Sigfox 868MHz Class 0 14dBm
BLE
BLE V4.2
LoRa 868MHz Class A 14dBm
Power supply
Ext. 8-30 VDC
Cellular
3G 800/850 900/1900 2100 MHz
Battery Li-SOCI2 3.6V –6Ah
2G 850/900 1800/1900 MHz
Lithium Bat. 1 A.h
3.7Vdc
LTE CAT.M1 800/1800 MHz
Out
Led
GNSS
GPS / GLONASS
Co Open collector
These products are supplied with a simple demo application allowing you to make preliminary tests. As this
application is evolvable, our technical support will be able to provide its evolutions. See the paragraph
« Demonstration application » to know the restrictions of use linked with the demonstration application version.
2.1 Packaging
Figure 1 : Packaging
Delivered with
A product EG-IoT - xxxx
A 8-wire cable equipped with a M8 connector (see Table 1 :
General Presentation)
A M8 sealing plug for products equipped with a M8 connector.
Installation instructions

EG-IoT_UG_demonstrator_006_UK.docx
Page 7 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
3 Technical characteristics
3.1 General
Table 2 : General characteristics
Operating temperature
With internal battery
With external power supply and internal
lithium battery
-30°C to +75°C
-20°C to +60°C
Storage temperature
With internal battery
With external power supply and internal
lithium battery
-40 °C to +85 °C
-20°C to +35°C (+60°C max 1 month)
Dimensions
90 x 65 x 35 mm
Waterproof casing
IP67 - IP69K
3.2 Accelerometer, Magnetometer
Table 3 : Accelerometer / Magnetometer characteristics
Specifications
Magnetic Dynamics
± 50 gauss
Accelerometer Dynamics
±2 / ±4 / ±8 / ±16 g
The X, Y and Z axes are identical for the
accelerometer and the magnetometer.
4 Operating modes
Deep sleep
The product is delivered in this mode.
Configuration / Software Update
Application configuration mode.
This is done via
The USB/TTL link with the corresponding cable
The Bluetooth link (future)
Service
The product is active according to the configuration.

EG-IoT_UG_demonstrator_006_UK.docx
Page 8 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
5 Configuration via internal serial link
5.1 Opening the casing
Tools : Screwdriver TORX T10.
Tape
Screwdriver or coin.
1 –Using the TORX T10 screwdriver, remove the 4
screws under the casing.
2 –Optional. Stick the adhesive tape to the bottom of the
M8 connector.
3 –Use the flathead screwdriver or a coin to remove the
upper part from the lower part using the notch
provided for this purpose.
4 –Rotate the upper part, taking as the axis of rotation
the base of the casing on the M8 connector side. The
duct tape will avoid from pulling on the connections.

EG-IoT_UG_demonstrator_006_UK.docx
Page 9 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
5.2 Installation of SIM card
1 –After having opened the casing (§ Erreur !
Source du renvoi introuvable. Erreur !
Source du renvoi introuvable. the casing),
Insert the Micro SIM card (format 3FF, format
N°2 on below picture).
2 –Push the Micro SIM card to the end.
5.3 Power supply connection
The product is delivered with its power supply connected. It is in deep sleep mode.
The product wakes up for a configuration:
When the converter cable USB/TTL is connected to the terminal,
At each transmission of character when the product is in sleep mode
If the power supply is disconnected, the product loses its activation capacity as its
configuration will be altered.
5.4 USB/TTL cable connection
1 –Carefully separate the upper part from the lower
part, using as the rotation axis the opposite side
of the M8 connector.
SIM card
insertion
marker
SIM card
insertion
marker

EG-IoT_UG_demonstrator_006_UK.docx
Page 10 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
2 –Connect the 4-pin USB –TTL cable to the board
connector.
Ref. ercogener : 4440Z00025
The USB/TTL converter component is situated
inside the molded part of the cable.

EG-IoT_UG_demonstrator_006_UK.docx
Page 11 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
5.5 Access to configuration menu
By default, the product is supplied with a demonstration application. This application allows to make tracking or to
read temperature and status of IN1 and IN2 digital inputs.
Use a Command Prompt software in order to communicate with the product.
The link between the product and the terminal is done with a USB/TTL cable: 115200,8,N,1.
Use only the USB/TTL cable recommended by ercogener (Ref. 4440Z00025).
Connect the product to the terminal.
Wait for the installation of the USB driver.
Once the driver installed, open the Device Manager to know the corresponding COM port.
Example:

EG-IoT_UG_demonstrator_006_UK.docx
Page 12 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
Launch the terminal with the corresponding communication port.
Send the character "Carriage Return" 0D in hexa.
The following menu appears (example):
Menu with Tracking mode
Menu with Remote Reading mode
AT&D4
READY
EG1114 version [8AB1]
LPWAN: "SIGFOX", Cellular: "3G", GNSS: "GPS+GLO+GAL", BT: "BLE"
Vbat:3.599V ,Bat capacity: 0%, Tint: 26°C
__________________________________________________________
EG-IoT_DEMO - V2.03b4 - 20/11/2017 16:01:29.20
CONFIGURATION MENU:
D: Mode [0:Tracking]
1: Date ("dd/mm/yyyy") [06/12/2017]
2: Hour ("hh:mm"24H) [16:58]
3: Start activation delay (0-1440mn) [0mn]
4: Keep alive time ("I,mn";"F,[0-7],hh:mm") [I,2]
5: Alert cyclic wakeup ("HH:MM:SS") [00:10:00]
6: Transmission mode [4:Sigfox + GSM]
7: GSM/GPRS configuration IMEI [357520072362771]
SMS destination phone number []
PIN code []
APN server []
APN username []
APN password []
protocol [TCP]
TCP server []
TCP port [0]
TCP ack []
I: SIGFOX ID
A: Accelerometer [1:Enable]
F: GNSS Geofencing radius [0m]
G: GNSS Geofencing reference (lat, long) [,]
Z: Erase memory
R: Restore default values
U: Update application
S: Save
E: Exit
AT&D4
READY
EG1114 version [8AB1]
LPWAN: "SIGFOX", Cellular: "3G", GNSS: "GPS+GLO+GAL", BT: "BLE"
Vbat:3.597V ,Bat capacity: 0%, Tint: 26°C
__________________________________________________________
EG-IoT_DEMO - V2.03b4 - 20/11/2017 16:01:29.20
CONFIGURATION MENU:
D: Mode [1:Remote Reading]
1: Date ("dd/mm/yyyy") [06/12/2017]
2: Hour ("hh:mm"24H) [16:58]
3: Start activation delay (0-1440mn) [0mn]
4: Keep alive time ("I,mn";"F,[0-7],hh:mm") [I,2]
5: Alert cyclic wakeup ("HH:MM:SS") [00:10:00]
6: Transmission mode [4:Sigfox + GSM]
7: GSM/GPRS configuration IMEI [357520072362771]
SMS destination phone number []
PIN code []
APN server []
APN username []
APN password []
protocol [TCP]
TCP server []
TCP port [0]
TCP ack []
I: SIGFOX ID
N: IN1 (Type, Rest state, Value, Threshold) [0,0,0,65535]
O: IN2 (Type, Rest state, Value, Threshold) [0,0,0,65535]
?: Read inputs state
T: Temperature threshold (Low, High) [-30°C,60°C]
Z: Erase memory
R: Restore default values
U: Update application
S: Save
E: Exit
For more details, see the paragraph «Demonstration Application».

EG-IoT_UG_demonstrator_006_UK.docx
Page 13 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
This menu allows to set:
The operating mode
The date and then the time (this order must be respected)
The timeout before its activation
The period of transmission of the Keep Alive frame
The period of transmission of frames in alert mode
The kind of transmission activated
The identifiers and the transmission modes depending on the communication technology available on the
product
oFor cellular : the IMEI number is the one of the EG-IoT internal module
oFor Sigfox, the Sigfox ID and the PACID can be read with the configuration application when
entering the character « i ».
oFor LoRa (use of OTAA connections) :
The DevEUI (8 digits : HWEUI of the embedded module)
The AppEUI (8 digits : 6572636F67656E65)
The AppKEY (16 digits : 4552434F47454E45522D454731313134).
These keys can be modified in the configuration menu.
For the tracking mode
oThe geofencing circular zone
oThe reference position
For the mode telemetering / pulse counting / Hour meter
oThe alert thresholds for high and low temperature
oThe modes of use of each digital input :
Pulse counting
Hour meter
Detection of status change
oAlert threshold on each digital input
oThe initialization value of meters

EG-IoT_UG_demonstrator_006_UK.docx
Page 14 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
The character has to be entered at the beginning of the line in order to activate the corresponding setting: enter 1 to
modify the date for example, and follow the instructions.
Example of display
Observation
D: Mode [0:Tracking]
Transmission mode [0]:
0: Tracking
1: Remote Reading
The menu will adapt depending on the selected
mode.
1: Date ("dd/mm/yyyy") [01/01/2000]
Date ("dd/mm/yyyy") [01/01/2000]
Réglage date
2: Hour ("hh:mm"24H) [00:00]
Time ("hh:mm" 24H) [00:00]:
Time setting
3: Start activation delay (0-1440mn) [0mn]
Start activation delay (0-1440mn,0: not
actived ): "0mn"
Activation timeout
4: Keep alive time ("I,mn";"F,[0-7],hh:mm") [I,480]
("I,mm";"F,[0-7],hh:mm")
Example :"I,1440" => Interval Time keep
alive every 1440mn [1-1440mn]
Example :"F,0,12:00" => Fix Time keep
alive everyday at 12:00
Example :"F,2,23:59" => Fix Time keep
alive every Tuesday at 23:59
Example :"F,7,01:00" => Fix Time keep
alive every Sunday at 01:00
[I,480]:
Timeout for transmission of regular frame
5: Alert cyclic wakeup ("HH:MM:SS") [00:10:00]
Cyclic wakeup ("HH:MM:SS") [00:10:00]:
Cyclical alert
6: Transmission mode [0:GSM/GPRS]
Transmission mode [0]:
0: GSM/GPRS
1: LoRa
2: Sigfox
3: LoRa + GSM/GPRS backup
4: Sigfox + GSM/GPRS
GSM/GPRS Mode requires SIM card
The menu will adapt depending on the
transmission modes selected
7: GSM/GPRS configuration IMEI [xxxxxxxxxxxxxxx]
Access to parameters below.
SMS destination phone number []
SMS destination phone number: ""
Enter phone number:
PIN code []
PIN Code: ""
Enter PIN Code (if requested):
APN server []
APN server: ""
Enter APN server:
APN username []
APN username: ""
Enter APN username:
APN password []
APN password: ""
Enter APN password:
protocol [TCP]
Transfert protocol: "UDP"
Enter protocol "T":TCP, "U":UDP
TCP server []
TCP server: ""
Enter TCP server:
TCP port [0]
TCP port: "0"
Enter TCP port:
TCP ack []
TCP ack: ""
Enter returns acknowledge string:
I: SIGFOX ID
$I0-FRW: "AX-Sigfox 1.1.0-ETSI"
$I2-HWL: "8F"
$I3-HWH: "51"
$I4-FWH: "1"
$I5-FWL: "1"
$I7-VAR: "ETSI"
$I8-VCS: "0"
$I9-LIB: "UDL1-1.8.7"
$I10-ID : "00192F6E"
$I11-PAC: "4DEDEAFA03481A22"
A: Accelerometer [1:Enable]
A: Accelerometer (0:Disable , 1:Enable):
"1:Enable"
N: IN1 (Type, Rest state, Value, Threshold) [0,0,0,65535]
IN1
(Type, Rest state, Value, Threshold)

EG-IoT_UG_demonstrator_006_UK.docx
Page 15 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
Type : 0=Disable / 1=Pulse Counter /
2=Minutes Meter / 3=Edge Detection
Rest state : 0=Low / 1=High
[0,0,0,65535]:
F: GNSS Geofencing radius [0m]
GNSS Geofencing Radius (0: not actived ):
"0m"
O: IN2 (Type, Rest state, Value, Threshold) [0,0,0,65535]
IN2
(Type, Rest state, Value, Threshold)
Type : 0=Disable / 1=Pulse Counter /
2=Minutes Meter / 3=Edge Detection
Rest state : 0=Low / 1=High
[0,0,0,65535]:
G: GNSS Geofencing reference (lat, long) [,]
GNSS Geofencing reference (lat, long):
"0.00000,0.00000"
?: Read inputs state
IN1: 0,IN2: 0
Z: Erase memory
Do you want to erase memory ? (Y-N)
T: Temperature threshold (Low, High) [-30°C,60°C]
Temperature threshold (Low, High) in °C
(To disable thresholds events : Low = -
30°C, High = 60°C)
[-30,60]:
R: Restore default values
Do you want to restore default values ?
(Y-N)
U: Update application
Are you sure to enter in Bootloader mode ?
(Y-N)
S: Save
Config saved
E: Exit
Exit menu
If the application does not receive any character after a timeout of 2 mn, the product goes
back to deep sleep mode.
To wake it up, a new character has to be entered.
Each wakeup of the application means a reset, so consequently, the actions programed
during this status change are processed (Restart of start activation).
Once the configuration is done, enter 'S' to save the parameters. The activation of the product
will be active after the timeout defined in line 3 of the menu 'Start activation delay
(0-1440mn)'.
If you enter 'U' to update the application, you enter in bootloader mode. The application is not
available anymore and the product is waiting for a new application without going back to a
deep-sleep mode.
The power supply must be disconnected and reconnected in order to go back to the
configuration menu if the update is not done immediately.

EG-IoT_UG_demonstrator_006_UK.docx
Page 16 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
5.6 Update of embedded software via Boot loader
For this, you must have the application STM32 Flash Loader.exe with its dll : STBootLib.dll
You also must have the new (latest) application to be installed: EG-IoT_Traceur_Vx.xx.bin (example)
Start the program STM32 Flash Loader.exe
1) The following window appears:
Select the port corresponding to
the cable
2) Select the port speed, other than
115 200 bauds:
3) Select the file
Select a port speed other than 115 200 bauds.
The software is ready to load the new application.
From the configuration menu
Enter Z and then Y (strongly advised)
Enter U and then Y
z
Do you want to erase memory ? (Y-N)
y
In progress...
…
…
u
Are you sure to enter in Bootloader mode ? (Y-N)
y
Bootloader waiting for STM32 Flash Loader...
Close the COM port currently used

EG-IoT_UG_demonstrator_006_UK.docx
Page 17 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
In the window of the STM32 Flash Loader, select « Write Firmware & Jump »
The message » Erasing » appears
The message « Programming »
appears
The message « Success » appears
The new software version is automatically launched.
To check it, open the COM port with the terminal software and from the menu, enter « V ».
In case the menu does not appear, disconnect the battery, wait a few seconds and reconnect it.

EG-IoT_UG_demonstrator_006_UK.docx
Page 18 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
5.7 Closing the casing
1 –Connect the Lexan in case it has been disconnected
A –Carefully unlock the connector.
B –Insert the Lexan.
C –Carefully lock the connector.
2 –Connect the battery or the lithium battery in
case it has been disconnected.
A –Check the presence of the SIM card.
B –Connect the battery or the lithium
battery.
3 –While placing the battery or the lithium battery,
check that the Lexan is not folded.
4 –After having installed the battery or the lithium
battery, check that the wires are positioned
according to this picture.
5 –Close the housing. Check the presence of the
seal on the 4 screws to ensure the
waterproofness.
6 –With the TORX T10 screwdriver, place the 4
screws under the housing.
Once the screws stop, make an additional
quarter turn to ensure the waterproofness.

EG-IoT_UG_demonstrator_006_UK.docx
Page 19 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
5.8 Fixing
5.8.1 Standard
With 2 screws
Self-drilling for thermoplastic
Ø 3 mm x LgMAX.: 12 mm
With 2 Polyamide tie raps
Length MIN. : 230 mm
Width MAX. : 7 mm
Minimum bending radius of the cable
Fix position RMIN. = 25,5 mm
Flexible position RMIN. = 51 mm
5.8.2 Installation
For optimum conditions of transmission and reception
The arrow must be positioned upwards (see figure below)
Avoid any obstacle on and in front of the product.
If the M8 cable is not connected, the cap must be placed on the connector of the
product in order to ensure its waterproofness
Figure 2 : Installation / Position

EG-IoT_UG_demonstrator_006_UK.docx
Page 20 / 34
Descriptions and non-contractual illustrations in this document are given as an indication only. ERCOGENER SAS reserves the right to make any
modifications. This document is the property of ERCOGENER SAS. It may not be reproduced or disclosed to a third party without the written
consent of ERCOGENER SAS.
6 Demonstration application:
This application will allow you to test the product for different cases of use.
This application will have evolutions and in this case, updates will be communicated.
1114_DEMO_V1.00
Tracking only, LoRa, Sigfox, SMS
1114_DEMO_V2.00
Addition telemetering/counting/hour meter (IN1, IN2, T°C), LoRa, Sigfox,
SMS
1114_DEMO_V2.01
Addition management of TCP protocol TCP in 3G
1114_DEMO_V2.03b4
Optimization of LoRa driver, addition UDP, addition LTE CAT.M1
management, addition estimation of battery remaining capacity
Not available yet
datalogger, ANA inputs management, magnetometer, BLE, RS485, 1W
6.1.1 Principle
This version of demonstration is unidirectional for the transmission of information to a server and the SMS
transmission.
The features taken into account are:
Management of internal serial port for configuration
Management of date and time
Management of timeout between the configuration and the activation
Management of keepalive frame
Management of ways of transmission : LoRa, Sigfox, 2G/3G, LTE CAT.M1 for transmission of SMS and/or
TCP/UDP frame
Management of internal temperature reading
For tracking
oManagement of position report
oManagement of entry/exit of a circular zone
oManagement of movement detection
oManagement of alert upon entry/exit of a zone
oManagement of alert upon start of movement and stop of movement
oManagement of cyclical transmission of frame during movement
For telemetering
oManagement of the 2 digital inputs
oManagement of pulse counting on each of the 2 inputs
oManagement of hour meter on each of the 2 inputs
oManagement of thresholds for counting (high level) and temperature (low level and high level)
oManagement of alert upon status change of an input (upwards or downwards from the normal level
of reference)
The main limits of this application are visible in the configuration menu of each parameter. The fixed limits not
indicated in the menu are :
The time is a UTC time
Hysteresis of zone entry/exit (geofencing) : 50m
Hysteresis around temperature threshold : 2°C
Resolution of pulse counting : Fmax =20Hz, Ton mini=12ms
Resolution of hour meter : duration mini 1s, resolution 1mn, duration max 65535mn, corresponding to 45
days
Detection of movement (vehicle transport mode) : start of movement constant during 2s, stop of movement
after 3 mn of immobilization
LPWAN networks coverage:
oSigfox : https://www.sigfox.com/en/coverage
oLoRa Objenius : http://objenious.com/reseau/
oLoRa LiveObject : not communicated
To save power, the product wakes up:
At the Keep alive frequency or at the alert cyclical frequency
Upon an asynchronous event: movement or front detection
There is no asynchronous event for the temperature threshold overrun. The first alert is sent depending on
the keep alive frequency.
