DESCRIPTION
Dual-band base station antenna conceived for GSM 900 & 1800, DCS 1.9, DECT and UMTS
working on 880-960 MHz and 1710-2170 MHz. The radiant dipole is realized on Microstrip PCB
and protected by a glassfiber tube.
SPECIFICATIONS
Electrical Data
Type : Dipole
Frequency Range : 880-960 MHz
1710-2170 MHz
Impedance : 50 ΩUnbalanced
Polarization : Linear Vertical
Gain : 0 dBd, 2.15 dBi at both band
3 dB Beamwidth Vertical : E-plane 50°
Beamwidth Horizontal : H-plane 360°Omnidirectional
Downtilt : 0°
S.W.R. in Bandwidth : ≤2:1
Max Power : 20 Watts (CW) at 50°C
Feed System / Position : Direct / Base
Connector type : N female
Mechanical Data
Housing Materials : Aluminium, Chromed brass, PCB, Stainless Steel
Radome Material : White Glassfiber
Wind Load / Resistance : 11 N at 150 Km/h / 200 Km/h
Wind Surface : 0.01 m2
Height (approx.) : 325 mm
Weight (approx.) : 350 gr
Operating Temperature : -20°C to 80°C
Mounting Mast Diameter : ∅35-54 mm
ID293
MOUNTING INSTRUCTIONS
HI-QUALITY ANTENNAS MADE IN ITALY
REMARK
Locking nut.
Do not release
