ETI ASTRO User manual

INFORMATION AND SAFETY
PRECAUTIONS
•It is advisable to read the installation and user
instructions carefully and to keep them for future
reference.
•The manufacturer reserves the right to make all the
technical and construction changes it deems
necessary without prior notice.
•Important: the installation, electrical connection and
commissioning of devices and equipment must be
performed by qualified personnel and in compliance
with regulations and applicable laws.
•Do not connect or power the unit if any part is visibly
damaged.
•Once installation is complete, inaccessibility to the terminals
without the use of special tools must be guaranteed.
•The manufacturer assumes no responsibility concerning
the use of products that must comply with specific
environmental and/or installation regulations.
•This unit must be intended only for the use for which
it was built.
Anyotherusemustbeconsideredimproperanddangerous.
DISPOSING OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on the product or on its packaging indicates that this product cannot be treated as household waste. On the contrary, it must be taken to a specific collection centre for recycling electrical
and electronic equipment, such as: - outlets, if a similar product to the one being disposed of is being purchased - local collection centres (waste collection centres, local recycling centres, etc.). By
making sure the product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inadequate
disposal of this product. Recycling materials will help conserve natural resources. For more detailed information about recycling this product, please contact the local office in your area, the household
waste disposal service in your area or the shop where you purchased this product.
IMPORTANT! The instructions are unique for both
models. The 2-channel model is represented in the
images below; certain parameters or symbols on
the display will not be present when programming
the 1-channel model.
34
1.1) Functional characteristics
1.2) First battery insertion
1.3) Technical specifications
1.4) Electrical connections
1.5) Disp yla
1.6) Keys
1.6.1) Specific key functions
1.6.2) Shortcut keys
1.6.3) Reset
2 - First start-up
2.1) Entering astronomical coordinates
2.2) Enabling the twilight sensor
2.2.1) Disabling the twilight sensor
3 - Menu and programming
3.2) Forcing and program priority
3.3) Example of programs
4- «PROG» menu (Programs)
4.1) Creating a new program
4.1.2) «LUX» program type
4.1.2.a) Forcing twilight (LUX)
4.1.3) T p program «TIME»y e of
4.1.3.a) Implementing a program lasting a few days
4.1.1) «ASTRO» program type
Contents
pag. 35
pag. 36
pag. 37
pag. 37
pag. 38
pag. 38
pag. 39
pag. 39
pag. 39
pag. 40
pag. 42
pag. 43
pag. 43
pag. 44
pag. 45
pag. 45
pag. 46
pag. 46
pag. 47
pag. 48
pag. 49
pag. 51
INFORMATION AND SAFETY
PRECAUTIONS pag. 34
pag. 35
1- Description of the unit
3.1) Menu - overview pag. 44
4.1.4) Combining ASTRO-LUX-TIME programs
4.1.4.a) Combining ASTRO/TIME programs
4.1.4.b) Combining TIME/ASTRO programs
4.1.4.c) Combining LUX/TIME programs
4.1.4.d) Combining TIME/LUX programs
4.2) Vi or modifying an ASTRO LUXsualizing ,
4.3) Copying a program
5 - «HOLIDAY» menuprogram
5.1) Creating a new HOLIDAY program
6 - Deleting a program
7 - «MANUAL» menu
8 - «OPTIONS» menu
8.1) Changing the language
8.3) Maintenance (MAINTEN)
8.3.a) Managing a aintenance operationm
8.4) Hour counter
8.5) Backlighting
8.6) Warranty
8.7) Info
8.8) External memory device (EMD)
8.8.a) Exclusion of the EMD
8.8.b) Accessing the EMD
8.2) Set-up (SETUP)
or TIME program already saved,
pag. 55
pag. 52
pag. 52
pag. 52
pag. 52
pag. 53
pag. 53
pag. 54
pag. 55
pag. 57
pag. 58
pag. 59
pag. 59
pag. 60
pag. 60
pag. 61
pag. 61
pag. 62
pag. 62
pag. 63
pag. 63
pag. 64
pag. 64
4.1.4.e) Combining ASTRO/LUX programs
4.1.4.f) Combining LUX/ASTRO programs
pag. 53
pag. 53
1.2.1) Low battery signal
pag. 36
1.2.2) Replacing the battery
pag. 36
5.2) Vi or modifying a HOLIDAY programsualizing
pag. 56
pag. 51
4.1.2.b) Disable twilight override(LUX) pag. 50
Total / Partial
ENGLISH
EN

astro
Time
LUX
1234567
astro
Time
LUX
1234567
1-channel mod. 2-channel mod.
DEVICES ACCESSORIES:
External cadmium-free
twilight sensor
«EMD» External
memory device
(s separately)upplied
The ASTRO-LUX-TIME weekly digital switches with 1 or 2 relay outputs
(mono or dual-channel) are equipped with a backlit display and programming
is easy and intuitive thanks to the browsing by Menu.
They are the ultimate solution to managing loads based on time or brightness
and/or their combinations; they consist of an ASTRONOMICAL TIME
SWITCH, a TWILIGHT SWITCH and a TIME SWITCH in a single device.
Ideally used in domestic buildings, industrial buildings, schools, offices,
public areas, etc.; they also have a special Slot to insert the EMD (External
Memory Device) that allows one or more programs to be
read/saved/copied/run on different ASTRO/LUX/TIME digital switches of the
same model.
1.1) Functional characteristics and special features of the device
• Device dimensions (LxDxH): 35 x 60 x 90 (2 DIN modules)
• Device with daily/weekly programming, guided by menus with the guidelines
read on the white backlit display.
• Models with one or two relay control outputs.
• Smart relay piloting that "zero crossing" increases the load values and the duration of
the relay as well as the connected load.
• Slot for external memory device to run, load Astro, lux, time programs and
download/upload the holiday programs alone.
• Twilight sensor connection input.
• Calendar: year - month - day - hour and minutes.
• Date/time setting with automatic winter/summer time change.
• Multilingual menu: Italian - English - German - French - Spanish.
• Memory capacity: 45 ON/OFF programs that are free to be set.
• Minimum ON/OFF 1-minute time scheduling to a maximum of 1 week less 1 minute.
• Types of programs: Astronomical (ASTRO), Twilight (LUX), Timer (TIME), Holiday
(suspension of programs for a preset period of time).
• Twilight operation 0.....1000 LUX.
• Possibility of entering 1 or more «Holiday programs», (suspension of Astro - Lux -
Time programs twilight override in progress) from a minimum of 1 day to a maximum-
of 12 months.
• Permanent memory for saving programs.
• Possibility of deleting the selected program rapidly.
• Program/s deletion menu.
• Possibility of permanent or temporary manual override (ON/OFF).
• Possibility of twilight override .(Total / Partial)
• Scheduled maintenance of the connected loads.
• Hour counter function to monitor the operating hours of the load.
• Warranty menu: view the elapsed time from when the product was connected.
• White backlit display.
• Managing the backlighting of the display: timed at 6 seconds / Fixed ON / Fixed OFF.
• Ecological LITHIUM battery, which can be replaced without removing the device
from its seat.
• Charge reserve guaranteed by the lithium battery (replaceable) is about 6 years.
• Key lock.
• Hinged and sealable .cover
Note: a back panel with optional accessories can be installed for all items.
2 DIN modules
1 - Description of the unit
35
EN

1.2) FIRST BATTERY INSERTION
+
1
2
3
When the battery reaches a minimum threshold level and there is a power cut, the display will
show and the symbol .
1.2.1) LOW BATTERY SIGNAL
1.2.2) REPLACING THE FLAT BATTERY
3.0V lithium
battery code
CR2032
Open the battery door to the left and insert the battery into its housing with the .positive side facing up
lose the battery compartment door properly to the right .C
Connect and activate the 230V power mains (see paragraph 1.4).
Set the required data as described in Chapter 2 - FIRST START-UP.
12
Disconnect the 230V mains.•
Note: the display shows and the symbol .
Open the battery door to the left and insert the battery into its housing with the positive side facing up .•
Close the battery compartment door properly to the right .
•Re-connect the 230V mains.
Note: the device will save all the previously set data in memory (with the exception of manual and twilight overrides).
The device displays the screen to select the language.
Press the OK button repeatedly to confirm all the settings saved in the memory until the normal operation main screen appears
(display of the status of the channel/s, current date and time).
13
If the 230V ~ power mains is disconnected, the current date and time are kept updated by
the backup battery (replaceable) with a power reserve of approximately 6 years.
The language, programs and all previously entered settings are saved in a permanent
memory.
3
2
36
EN

1.3) Technical specifications
Supply voltage 230 V c.a. +/- 10%
Frequency
50 Hz
Protection rating IP20
Output type
Potential-free changeover contact relay;
N.O. contact
Zero Crossing
N.C. contact = 16(2)A / 250V~
Operating temperature from -20 °C to +55 °C
Storage temperature from -30 °C to +60 °C
Consumption/Stand-by consumption 8 VA mono-channel / 6 VA dual-channel
Section of the cables to the terminals
1...6mm²
CE marking regulation LVD/EMC EN60730-2-7
Languages available in the device Italian, English, German, French, Spanish
Power reserve in case of
power failure
about 6 years from the first start-up, guaranteed
by the lithium battery (replaceable)
Rated impulse voltage 4kV
Operating accuracy
3000W 3000W 1100W 900W
(125 µF)
7W ÷ 23W
(max. 23 lamp.)
Installation
DIN bar - back panel (with optional kit)
Software
A class
Type of insulation II class
Rate of pollution normal
+/ 1 sec/day at 25 °C
Maximum controllable power
12 3 4 5
67 8 9 10
C1
C2
N
L
12 3 4 5
67 8 9 10
C1
N
L
230V~
230V~
twilight
sensor
twilight
sensor
1.4) Electrical connections
Maximum cable length to connect the
twilight sensor: 50 m
The electrical connections must only be
implemented after having disconnected
the 230V~ power supply.
Replaceable backup battery 3V lithium code CR2032
1-channel mod.
2-channel mod.
Type of action, disconnection
and unit 1 B S U / electronic
= 16(10)A / 250V~
Follow the instructions in the instruction
sheet for information concerning the
technical characteristics and assembly
of the external twilight sensor.
37
EN

1.5) DISPLAY
1.6) KEYS
Channel 1 Field (status of relay 1)
Channel 2 Field (status of relay 2) only dual-channel mod.
Date / Text indication to browse or program
Hour and Minutes / Menu functions / Parameter values indication
Browsing arrow (menu o next sub-menu)
ATTENTION! icon
Holiday icon (suspension of programs in progress)
Icon for the set of the connected loadMaintenance
“ ” iconKeypad lock
Summer time period icon (summer changeover)
and/or for Astro and Lux programs
Winter time period icon (winter changeover)
Day of the week field
Time program settings (TIME)
Twilight program settings (LUX)
Astronomical program settings (ASTRO)
Scroll list upwards / increase the value
Confirm setting / copy program
Reset (no setting entered is deleted - para. 1.6.3)
Access / Exit the menus and sub-menus
Scroll list downwards / decrease the value
Note: further details concerning the key functions are described in the specific paragraphs of use.
astro
Time
LUX
1234567
1 2
3
4
5
6
7
8
9
10
12
13
11
15
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
A
B
C
D
E
ABCD
E
D
38
EN

Lock / unlock keys ( )
Function Press the key combination
+
2 seconds
Access the directly to enable/disable«Manual» menu
the temporary or permanent override (see Chapter 7).
for channel 1 for channel 2
1.6.1) Specific key functions 1.6.2) Shortcut keys
Function
Immediate exit from the
menu or sub-menu
Press key/s
2 sec. until the main
screen appears
Press the key
pulse key
activated you can view the following consecutively:
- TimeSUNSET / SUNRISE as at today
- LUX readingCurrent of the sensor
- return to the «Main screen»
2 seconds
in the Programs menu,
access the first free
program that is to be set
astro
Time
LUX
1.6.3) RESET
Reset reboots the time switch and is used in the event of unusual displays or malfunctions. Gently
pressing the Reset button with a pointed object the time switch performs a lamp-test, thereby
switching on all the segments of the display and then viewing the screen on which the language is
selected. Implementing a Reset will lose the keypad lock and any activated manual overrides. All
settings are retained: current date and time, programs, data concerning maintenance, hour counter
and the warranty and activated twilight override.
Reactivate the device from the language selection screen by pressing the OK button repeatedly
to confirm all the settings saved in the memory until the normal operation main screen appears
(display of the status of the channel/s, current date and time).
in the Programs menu,
quickly deletes the
selected program
Any of the functions described below are carried out from the main screen
IMPORTANT: when programming, the settings made with the keys must be confirmed by pressing the OK key, and when OKAY appears on
the display for a few seconds, it indicates that the data have been entered correctly in the permanent memory. Otherwise, after 2 minutes (10
minutes for «program» and «hour counter» settings), the digital switch returns to the "Normal operation" main screen and the partial changes
will not be saved.
Press the key or pulse key to increase/decrease per unit and keep pressed to increase/decrease rapidly.
press simultaneously
for at least 2 seconds
With the ASTRO function and/or Twilight sensor
39
EN

2 - FIRST START-UP (language selection, entry of current year, month, day, hour and minutes, summer/winter time setting)
Set the summer or winter time. Select whit the keys between must be programmed and confirm with .EURO - FREE - NONE OK( )
Last Sunday in March
(default)
Possible selections on the display Summer changeover +1h ( summer time) Winter changeover -1h ( winter time)
Last Sunday in October
Month / Week / Day / Time
freely programmable
None None
Month / Week / Day / Time freely programmable
EXAMPLE:
40
EN
The unit is supplied with default settings. After inserting the battery (see paragraph 1.2) and connecting the power
supply, the unit resets the display (lamp-test) and then proceed as follows:
•Select the desired language.
•Set the current year, month and day.
•Set the current hour and minutes (keep the or keys pressed for the counter to advance rapidly).
The display shows for a few seconds and then displays the screen for the winter/summer time to be set.OKAY
Select/set the data by pressing the keys and press the OK key to confirm and move on to the next field.
= Central Europe UTC+1

e.g. main screen
(normal operation)
•Set the astronomical coordinates.
By setting them, you move on to enter the astronomical coordinates (see the procedureASTRO ON
in the next paragraph 2.1).
By confirming with , appears and it moves on to the next item (Enabling the«ASTRO OFF» OK OKAY
twilight sensor).
If ASTRO OFF is confirmed, the astronomical coordinates can then be entered in two ways:
- when an program is first entered (see paragraph 4 1.1)ASTRO .;
- entering the menu (see paragraph 8.2)OPTION > SETUP > ASTRO/SET .
•Set the twilight sensor (installed correctly).
Setting will activate the twilight sensor connected to the device (see paragraph 2.2).SENSOR L ON
Confirming key will display for a few seconds.«SENSOR L OFF» OK Deactive (deactivated)with the
•The display shows the normal operation main screen: proceed to enter the desired programs.
If SENSOR L OFF is confirmed, the next sensor can be activated:
- when a program is first entered (see paragraph 4 1.2);LUX .
- when a twilight override is first set (see paragraph 4 1.2.a)..
In the event of a power failure, (e.g. "black-out"), the digital switch:
disables the relay/s;•
switches off the backlighting, if activated;•
•
•disables the twilight probe if connected and activated;
41
EN
displays the flashing date and time for 20 seconds, then switches to stand-by
mode (display off). While keeping all the programmed data in memory until the
supply voltage is restored or by pressing a key that restarts the count for stand-
by mode for 1 second.
20 SEC.

The display of the digital switch shows : select with the keys•ASTRO ONOFF .
Confirm with .OK
The astronomical coordinates are then entered.•
2.1) Inserting the astronomical coordinates (ASTRO activation)
- Latitude 60 (Lat SOUTH) 64 (Lat NORTH)= use the keys to enter the latitude in degrees from - ° to ° .
Confirm with .OK
- Longitude 180 (Lon WEST) 180 (Lon EAST)= use the keys to enter the longitude in degrees from - ° to ° .
Confirm with .OK
- Time zone -14:00 14:00;= use the keys to set the time zone (in ± 1h steps): ÷
(this parameter represents the hours that shift from the zero line of Greenwich). Confirm with .OK
.
- OFFSET (offset correction) = you can set the switch-on at sunset and/or switch-off at sunrise for installation
requirements (e.g. if the unit is installed in the shade of obstacles: mountains, condominiums, etc.), the
following intervention can be corrected by using the keys:
-120 minutes 120 minutes at sunrise (icon by default the value is set at 0 (zero).)
-120 minutes 120 minutes ( )at sunset icon by default the value is set at 0 (zero).
Confirm with appears on the display for a few seconds.OK, OKAY
After which it displays the screen to activate the twilight sensor (1st start-up), proceed as described in the next
paragraph or press the key to exit and display the main screen.Menu
The operation consists of entering the latitude and longitude degrees ( ) of the place ofonly integers
installation of the device. These data can be obtained from any atlas, Smartphone or GPS system.
By default the unit indicates the coordinates of Milan (Italy) Lat. North 45 Lon. East 9 time zone +1
for the ASTRO programs to work properly it is important for some information to be entered (ASTRONOMICAL
PARAMETERS), which allow the device to identify the geographic area where it will be installed.
VIEWING SUNRISE-SUNSET TIMES (para. 1.6.1)
Press the pulse key on the main screen to verify the sunrise andOK
sunset times as at today.
note: the displayed time considers the entered sunrise and sunset
correction parameters
42
EN

2.2) Enabling the twilight sensor
(this is only possible with the twilight sensor installed and connected properly to the digital deviceoutdoor
)powered by 230V~ mains voltage
•The display of the digital switch shows ; use the keys to selectSENSOR L SENSOR L ONOFF .
Confirm with .OK
•The LUX value read in real-time by the sensor is displayed ( )CURRENT .
Confirm with .OK
OKAY appears on the display for a few seconds after which it moves to the main screen of normal
operation of the device.
Note: if the sensor is not connected, is not working or the read LUX value is less than 5 LUX,Current
Current 0000is displayed and the LUX value (example: ) flashes together with the symbol (by pressing
OK the sensor cannot be activated). Check the correct installation of the sensor and try activating once
again.
Even in this fault condition it is possible to exit (without activating the sensor) by pressing the key andMENU
the main normal operation screen will appear on the display.
2.2.1) Disabling the twilight sensor
Execute a (para. 1.6.3), confirm all the previously entered settings with the key until theReset OK
screen is displayed ; disable it by pressing one of the keys and confirm with the key.OK
The LUX value read in real-time by the sensor can be displayed at any time ( )CURRENT .
Press the pulse key on the main screen (see para. 1.6.1)OK .
43
EN

3 - MENU AND PROGRAMMING
3.1) Menu - overview
6 menus are listed in the sequence present in the unit:
PROG (Programs)
- Number of free programs
- Selection of no. of programs
- Selection of channel (only dual-channel) - Selection of day
- Selection of the (ASTRO or LUX or TIME) type of program (start-up)ON
data entry according to the type of program selected
- Selection of the (ASTRO or LUX or TIME) type of programOFF
1
ERASE PG (Program deletion)
- Deleting a single program
- Deleting all the programs
2
HOLIDAY
- Number of free programs
- Selection of no. of programs
- Selection of channel (only dual-channel)
- Setting - MONTH – DAY OFF
- Setting - MONTH – DAY ON
3
SETUP LUX (twilight override)
- Probe activation (if not activated on the 1st start-up)
- Channel selection (dual-channel only)
- LUX threshold setting/disabling
- Selecting the type of twilight override: Total / Partial
4
OVERRIDE (relay override)
- Selection of channel (only dual-channel)
-AUTO
ON PERM- permanent manual
- permanent manualOFF PERM
- temporary manualON TEMP
OFF TEMP- temporary manual
5
OPTION
- Language selection
- ASTRO or TIME settings
- Maintenance
- Hour counter
- LED light (backlighting)
- Warranty
- Info
- EM keyD (only with key inserted)
6
main screen
How to select the desired menu:
1. Press the key.MENU
The first selectable menu
appears.
2. Scroll through the various
menus using the keys .
3. Confirm the desired menu
with : the sub-menus andOK
settings are accessed.
Exit or return to the previous menu or
setting by pressing the pulse keyMENU
or keep it pressed to return to the main
screen.
(switch-off) data entry according to the type of program selected
44
EN

3.2) Forcing and program priority
A priority is assigned for each type of program/function as shown below on the right.
The output relay/s will be activated according to the set priorities.
Permanent or temporary
manual override
External memory “EMD”
“Holiday” programs
Twilight override
ASTRO-LUX-TIME programs
(astronomical, twilight, time or combined)
3.3) Example of programs
IMPORTANT: all programs (ASTRO-LUX-TIME) entered are simultaneously active regardless of their position; in the case of overlapping
commands on the same output, this is activated or remains so if at least one program is commanding it (OR LOGIC).
day 7 (Sunday) day 1 (Monday)
day 5 (Friday) day 6 (Saturday)
day 7 (Sunday) day 1 (Monday)
Note: programs P01 and P03 are set on the same day and are
therefore simultaneously active.
ON
OFF
ON
OFF
ON
OFF
T on T off
P01 ASTRO / ASTRO:type of program
P02 LUX / LUX:type of program
P03 TIME / TIMEtype of time program :
You can set the «COMBINED» programs starting with an
ON type of program (example: ASTRO) and ending with
OFF with another type (example: TIME).
MAXIMUM PRIORITY
MAXIMUM PRIORITY
P01
P03
P02
( )total / partial
45
EN

4 - «PROG» menu (Programs)
This menu allows you to create, test, modify, copy and delete
the programs (ASTRO / LUX / TIME).
Procedure valid for all types of programs.
Additional settings are described in the individual programs.
1. . Confirm with .Press the key to access the first menuMENU (PROG ) OKSET
The number of free programs will be displayed for about 2 seconds, then the first program will appearP01
flashing. If no text (ASTRO, LUX, TIME) appears on the left of the program it means that the program is free.
2. Select the desired program using the keys. Confirm with .OK
4.1) CREATING A NEW PROGRAM
If programs are saved, they are not displayed in this menu.Holiday
If there are several stored programs, to display the firstkeep the key pressed for 2 seconds
free program that is to be set.
Press the keys simultaneously for 2 seconds to rapidly delete the selected program.
3. Use keys to select channel C 1 or C 2 or both (only for the dual-channel model). Confirm with .OK
4. Use the keys to select the day when the program must start .(by default: 1 = monday)
The arrow indicates the selected day (example 7 = Sunday). Confirm with .OK
The ASTRO ON program type is suggested by default.
5. Use the keys to select the program type (ASTRO or LUX or TIME)
ON
and proceed with the settings according to the type of program selected: ASTRO para. 4.1.1; LUX para.
4.1.2; TIME para. 4.1.3.
main screen
Note: you can select different types of programs for ON and OFF in the same program.
«COMBINED programs» starting with an ON type of program (example: ASTRO) and ending with OFF
with another type (example: TIME).
46
EN

2. Select the keys. Confirm with theOFF ASTROtype of program with the key.OK
3. After entering the program, the display first shows , and immediately after the number of free programsOKAY
left and then the last set program.
Set a new program or press the key 2 times to exit: the display will show the main screen (normalMENU
operation).
4.1.1) ASTRO / ASTRO program type
1.Select the type of program with theON keys .
(the type is suggested by default). Confirm with theASTRO ASTRO OK key.
If the display shows this indicates that the astronomical coordinates
have not yet been activated/set; proceed as described in paragraph 2.1 to activate them.
Example : type of program: sunset and sunrise interventions are computedP01 ASTRO/ASTRO by an
astronomical algorithm based on the set coordinates and the local time.
The program begins at sunset (ASTRO ON) and ends at astronomical sunrise the next day (ASTRO OFF).
After having selected the program number, the channel (only for the dual-channel model) and the day as described in para. 4.1:
Useful for the management of electric utilities in relation to sunset and sunrise in the set geographical area,
without external sensors.
Correspondence with the actual time of sunrise and sunset of a particular location also depends on changes in the weather, altitude
and topography of the place, therefore, the calculated values must usually be corrected with the following parameters:
SUNSET TIME CORRECTION - SUNRISE TIME CORRECTION (see paragraph 2.1)
The time of sunrise and sunset is calculated by considering the type of "Official" twilight and corresponds with the Zenith at 90°50'.
day 7 (Sunday) day 1 (Monday)
ON
OFF
P01
47
EN
IMPORTANT! For , 4 3Copy a saved program on other days see the procedure in the paragraph . .

4.1.2) LUX/LUX type of program (twilight)
Note: this program can be activated if the sensor is connected and activated.
After having selected the program number, the channel (only for the dual-channel model) and the day as described in the procedure in paragraph 4.1.
Example type of programP02 LUX :
allows you to set programs that switch-on and off
according to the set brightness.
The program starts (LUX ON) when the brightness
value measured by the sensor is less than the set
threshold (e.g. at twilight) and ends (LUX OFF) when
the measured value exceeds the threshold (e.g.
sunrise of the next day).
Twilight operation
When the brightness received by the sensor is less than the
“LUX ON” set value, the relay will close the contact after a
delay (about 15 sec.) called T on.
In contrast, when the brightness received by the sensor
exceeds the “ ” set value, the relay will open theLUX OFF
contact after a delay (about 30 s) called T off.
If the display shows this indicates that the twilight sensor has not been activated;
press and proceed as described in paragraph 2.2 to activate it.OK
P02
day 5 (Friday) day 6 (Saturday)
ON
OFF
T on T off
1. On the request to select the type of program, selectON LUX OKwith the keys. Confirm with .
2. Use the keys to enter the LUX value at which the connected utility must switch-on (default 10 lux).
Confirm with .OK
3. Select the type of program with the keys. Confirm key.OFF LUX with the OK
4. .Use the keys to enter the LUX value at which the connected utility must switch-off. Confirm with OK
Important: the LUX value (OFF) must be greater than the LUX ON value entered in point 2, otherwise it will not be
accepted by the device and will appear for a few seconds on the display.Err
The display first shows , and immediately after the number of free programs left and then the last set program.OKAY
Set a new program or press the key 2 times to exit: the display will show the main screen (normal operation).MENU
48
EN
IMPORTANT! For , seecopy a saved program on other days
the procedure in the paragraph . .4 3

4.1.2.a) Forcing Twilight (LUX)
The unit is configured to activate the selected channel via twilight override, when the brightness received by the
sensor is less than the set LUX threshold value and disable it when the brightness is above the threshold.
TOTAL PARTIALor twilight override can be selected according to the system requirements:
intervention has priority over programs (ASTRO-LUX-TIME) in progress.TOTAL twilight override:
This type of override is useful, for example, to enable/disable the channel as a normal twilight device.
Type of PARTIAL twilight override:
note: PARTIAL twilight override can only be selected if the ASTRO procedure has been previously set (see
paragraph 2.1). Night time is calculated based on the astronomical coordinates.
In the night time, forcing partial twilight is disabled, thereby allowing any programs in progress to be executed
normally. This kind of override is useful for example, to enable/disable the channel if, during the day, the ambient
light drops below the set threshold (for example, when cloudy, rainy, etc.).
note: if the device is reset, no types of set twilight override are deleted.
main screen
continue
How to set the type of twilight override:
1. Press the key on the main menu to access the first menu .MENU PROG( )SET
2. Use the keys to select the menu. Confirm with .SETUP LUX OKSET
3. Use the keys to select channel or (only for the dual-channel model).CH1 CH2
note: in the dual-channel version you can set a LUX override threshold that is different for each channel.
4. Confirm with .OK
Deactive appears (indicating that no LUX override threshold is set for that channel).
5. Confirm with
Use the keys to set the desired LUX threshold value (minimum 5 lux). OK
If the display shows indicates that the twilight sensor has not been activated;
proceed as described in paragraph 2.2 to activate it.
49
EN

6. twilight override. Confirm withUse the keys to select the desired TOTAL or PARTIAL OK.
7. The display returns to the LUX override set-up screen and you can also set the other channel (only for the
dual-channel model) or press the key to exit the setting and view the normal operation main screen.MENU
4.1.2.b) Disable twilight override
To disable the twilight override, follow the steps described at previous page above up to step 4 and use the keys to decrease the LUX value previously set to,
zero and press to confirm the deactivation. Press the key to exit.OK MENU
main screen
If the set twilight override activates the channel/s, the display will
show C1 On and/or (only dual-channel model) C2 On (« »
symbol and LUX flashing).
Important: PARTIAL twilight override can only be selected if the ASTRO procedure has been
previously set (see paragraph 2.1).
50
EN

4.1.3) TIME/TIME type of program
P03
day 7 (Sunday) day 1 (Monday)
17
Example: time type of program day 7 (Sunday) start-up ON atP 03 TIME/TIME
17:45 - switch-off OFF at 19:30
After having selected the program number, the channel (only for the dual-channel model) and the day as described in the
procedure in paragraph 4.1:
ON
OFF
Allows a load to start-up (time ON) and switch-off (time OFF) in a defined period of time.
select TIME with the keys. Confirm with OK.
2. Use the keys to enter the start-up time (ON). Confirm with .OK
3. Use the keys to enter the minutes. Confirm with .OK
4. Select the , type of program and use the keys to select Confirm with .OFF TIME.OK
5. Use the keys to enter the switch-off time (OFF). Confirm with OK.
6. Use the keys to enter the minutes. Confirm with OK.
The display first shows and immediately after the number of free programs leftOKAY
and then the last set program. Set a new program or press the key to exit.MENU
The display shows the main screen (normal operation).
If the key is pressed beyond 00:00 while setting the switch-off time , the program willOFF
end on the day after activation; the arrow corresponding to the day after start-up will flash.
Scrolling the hours up to 00:00 once again will set the program active for two days, etc.;
the two arrows corresponding to the two days after start-up will flash. If you press the
key and a switch-off time earlier than start-up is set, the program
will remain active throughout the week; all the arrows
corresponding to the days will flash.
1. On the request to select the ON type of program (ASTRO is suggested by default),
4.1.3.a) Implementing a program lasting a few days
51
EN
IMPORTANT! For ,Copy a saved program on other days
see the procedure in the paragraph . .4 3

4.1.4.a) Combination of ASTRO / TIME
Combination of ASTRO / TIME programs You can set the programs that start at astronomical sunset (ASTRO ON) and end at a fixed time (TIME OFF).
NOTE: when creating the ASTRO / TIME program, 23:59 is suggested as TIME OFF (editable) on the selected day.
-A program ends on the same day if the TIME OFF setting is before midnight
example: program start-up (ASTRO ON) at astronomical sunset e.g. at 18:30 and ends (TIME OFF) at 22:30 on the same day.
NOTE: the TIME OFF switch-off time must be after the ASTRO ON time (otherwise the program is not valid and is not implemented).
- A program ends the next day if the TIME OFF is set after midnight
.example: program start-up (ASTRO ON) at astronomical sunset e.g. at 18:30 and ends (TIME OFF) at 06:30 the next day
NOTE: TIME OFF switch-off time cannot be after 11:59 the next day.
4.1.4.b) Combination of TIME / ASTRO programs
You can set the programs that start at a fixed time (TIME ON) and end at an astronomical sunrise (ASTRO OFF).
- A program ends on the same day if the TIME ON setting is before midday
.example: program start-up (TIME ON) at 05:30 and ends (ASTRO OFF) at astronomical sunrise on the same day e.g. at 06:30
NOTE: the TIME ON start-up time must be before the ASTRO OFF time (otherwise the program is not valid and is not implemented).
- A program ends the next day if the TIME ON setting is after midday
.example: program start-up (TIME ON) at 22:30 and ends (ASTRO OFF) at astronomical sunrise the next day e.g. at 06:30
4.1.4.c) Combination of LUX / TIME programs
You can set the programs that start at sunset (LUX ON) detected by the twilight sensor and end at a fixed time (TIME OFF).
When creating the program, 23:59 is suggested as TIME OFF (editable) on the first day.
- A program ends on the same day if the TIME OFF setting is before midnight
example: program start-up (LUX ON) at twilight according to the set threshold e.g. at 18:45 and ends (TIME OFF) at 22:30 on the same day.
- A program ends the next day if the TIME OFF setting is after midnight
.example: program start-up (LUX ON) at twilight according to the set threshold e.g. at 18:45 and ends (TIME OFF) at 06:30 the next day
NOTE: TIME OFF switch-off time cannot be after 11:59 on the next day.
NOTE: if the initial condition occurs, the amount of light is below the set threshold, the program does not run after the set switch-off time (TIME OFF).
(example: a LUX ON threshold is set that starts-up at about 19:20 and TIME OFF is set to switch-off at 19:00).
4.1.4) CombiningASTRO-LUX-TIME programs
You can also set the combined programs according to the specific requirements, starting with a type of program (example: ASTRO) and ending with
another type (example: TIME).
- « » programs: ASTRO / ASTRO - LUX / LUX - TIME / TIMEstandard
- « » programs: ASTRO / TIME - TIME / ASTRO - TIME / LUX - LUX / TIME - ASTRO / LUX - LUX / ASTROcombined
Follow the same procedure described in paragraph 4.1 to enter a desired combined program.
52
EN

You can view or edit a previously saved program as follows (or as described in Chap. 4.1):
1.Press the key on the main menu (normal operation) to access the first menu ( ). Confirm with .MENU PROG OKSET
2.Select the program that is to be viewed or modified using the keys. Confirm with .OK
Press the key consecutively for the settings to appear again and reconfirm them. Change a setting by using the keys and confirm with the key.OK OK
View or edit all the settings until appears for a few seconds.OKAY
Exit the menu by pressing the key twice.PROG MENUSET
4.1.4.d) Combination of TIME / LUX programs
You can set the programs that start at a fixed time (TIME ON) and end when the brightness will exceed the threshold set in the program (LUX OFF).
- A program ends on the same day if the TIME ON setting is before midday
example: program start-up (TIME ON) at 05:30 and ends (LUX OFF) at sunrise according to the set threshold e.g. at 06:30 on the same day.
NOTE: once switch-off is implemented, i.e. the amount of light is higher than the set threshold, the program is terminated. If dimming occurs (e.g. cloudy weather or a storm),
the program will not be executed.
- A program ends the next day if the TIME ON setting is after midday
example: program start-up (TIME ON) at 22:30 and ends (LUX OFF) at sunrise according to the threshold set on the next day e.g. at 06:30.
NOTE: if during the program start-up set time (TIME ON), switch-off occurs before, i.e. the amount of light is higher than the set threshold, the program will last about 1 minute
and will then restart when dimming occurs and will terminate at sunrise the next day when the light will be higher than the threshold set.
4.1.4. ) Combining LUX / ASTRO programsf
Programs can be set to start at sunset detected by the twilight sensor (LUX ON) and ends at sunrise the next day (ASTRO OFF).
4.1.4. ) Combining ASTRO/LUX programse
You can set the programs that start at astronomical sunset (ASTRO ON) and end at sunrise the next day (LUX OFF) when the brightness will be greater than
the threshold set in the program.
NOTE: if during program start-up (ASTRO ON), switch-off also occurs (LUX OFF), i.e. the amount of light is higher than the set threshold, the program will last about 1 minute.
The program will start again when dimming occurs and will terminate at sunrise the next day when the brightness will be higher than the threshold set in the program.
4.2) Vi ing or modifying a program (ASTRO / LUX / TIME) already savedsualiz
NOTE: if during the program start-up set time (TIME ON), switch-off occurs before, i.e. the amount of light is higher than the set threshold, the program is not executed
(example: TIME ON set to a fixed time: 7:30 and a LUX OFF threshold is set that switches off at about 06:20).
53
EN
