Euroboor ECO.50?T User manual







INSTRUCTION
MANUAL

ECO.50‐T

MagneticDrillingMachine






SERIALNO.____________DATEOFPURCHASE__________
EUROBOOR
FOR PROFESSIONALS BY PROFESSIONALS

ISSUE1/Originalversion/OCT2013

2
2
CongratulationsonyourpurchaseoftheEuroboorECO.50‐TPortableMagneticDrillingMachine.
Yourmodelisdesignedtoproducesuperiorholesquicklyandefficiently.Throughyearsof
experience,constantinnovationanddevelopment,EuroboorBViscommittedtoprovideyouwith
metalcuttingtoolsandproductstohelpyoubemoreproductive.

Beforeoperatingyournewmagneticdrillingmachine,pleasereadallinstructionsfirst.Theseinclude
theOperator’sManualandWarningLabelontheunititself.Withproperuse,care,and
maintenance,your
modelwillprovideyouwithyearsofeffectiveholedrillingperformance.

TOREDUCETHERISKOFINJURYUSERMUSTREADANDUNDERSTANDALLINSTRUCTIONS



EUROBOORBV

Kryptonstraat110
2718TDZoetermeer
Netherlands

T+31793614990
F+31793614989

[e-mail]
www.euroboor.com

ISSUE1/Originalversion/OCT2013

3
3
Fig.1

ISSUE1/Originalversion/OCT2013

4
4

SymbolTerm,meaningExplanation

Readdocumentation
Beabsolutelysuretoreadtheenclosed
documentationsuchastheInstructionManualand
theGeneralSafetyInstructions.

Wearearprotection

Useearprotectionduringoperation.

Weareyeprotection

Useeye‐protectionduringoperation.

Danger/warning/caution

Observetheinformationintheadjacenttext!

Europeanconformitysymbol

Confirmstheconformityofthepowertoolwith
thedirectivesoftheEuropeanCommunity.

ClassofprotectionI
Productwithbasicinsulationandexposed
(touchable),conductivepartsadditionally
connectedtotheprotectiveearthconductor.

mm

Millimeter

Unitofmeasureforlength,width,heightordepth

kg

Kilogram

Unitofmeasureforthemass

V

Volt

Unitofmeasurefortheelectricvoltage

A

Ampere

Unitofmeasurefortheelectriccurrentintensity

W

Watt

Unitofmeasurefortheoutput

N

Newton

Unitofmeasurefortheforce

min

Minutes

Unitofmeasureforthetime


no

No‐loadspeed

Revolutionspeedatno‐load

1/min

perminute

Unitofmeasurefornumberofrevolutions,
strokes,impactsoroscillationsperminute.


ISSUE1/Originalversion/OCT2013

5
5
GENERALPOWERTOOLSAFETYWARNINGS

Donotusethispowertoolbeforeyouhavethoroughlyreadandcompletelyunderstoodthis
InstructionManualandthe“GeneralSafetyInstructions”,includingthefigures,specifications,safety
regulationsandthesignsindicatingDANGER,WARNINGandCAUTION.

WARNING:Whenusingelectricaltoolsbasicsafetyprecautionsshouldalwaysbefollowedto
reducetheriskoffire,electricalshockandpersonalinjuryincludingfollowing.

Pleasealsoobservetherelevantnationalindustrialsafetyregulations.Non‐observanceofthesafety
instructionsinthesaiddocumentationcanleadtoanelectricshock,burnsand/orsevereinjuries.

ThisOperator’sManualandthe“GeneralSafetyInstructions”shouldbekeptforlateruseand
enclosedwiththepowertool,shoulditbepassedonorsold.

WORKAREA
1. Keepyourworkareacleanandwelllit.Clutteredbenchesanddarkareasinviteaccidents.
2. Donotoperatemagneticdrillingmachineinexplosiveatmospheres,suchasinthepresence
offlammableliquids,gasesordust.Magneticdrillingmachinemaycreatesparkswhichmay
ignitethedustorfumes.
3. Keepbystanders,children,andvisitorsawaywhileoperatingamagneticdrillingmachine.
Distractionscancauseyoutolosecontrol.


ELECTRICALSAFETY
1. Magneticdrillingmachineplugsmustmatchtheoutlet.Nevermodifythepluginanyway.Do
notusanyadapterplugs.
2. Avoidbodycontactwithgroundedsurfacessuchaspipes,radiators,rangesandrefrigerators.
Thereisanincreasedriskofelectricshockifyourbodyisgrounded.
3. Donotexposemagneticdrillingmachinestorainorwetconditions.Waterenteringa
machinewillincreasetheriskofelectricshock.
4. Donotabusethecord.Neverusethecordtocarrythemagneticdrillingmachineorpullthe
plugfromanoutlet.Keepcordawayfromheat,oil,sharpedgesormovingparts.Replace
damagedcordsimmediately.Damagedcordsincreasetheriskofelectricshock.
5. Whenoperatingamagneticdrillingmachine,useanextensioncordsuitableforoutdooruse.
Useofacordsuitableforoutdoorusereducestheriskofelectricshock.
6. Ifoperatingamagneticdrillingmachineinadamplocationisunavoidable,usearesidual
currentdevice(RCD)protectedsupply.UseofanRCDreducestheriskofelectricshock.


PERSONALSAFETY
1. Stayalert,watchwhatyouaredoingandusecommonsensewhenusingamagneticdrilling
machine.Donotusemachinewhiletiredorundertheinfluenceofdrugs,alcohol,or
medication.Amomentofinattentionwhileoperatingmagneticdrillingmachinesmayresult
inseriouspersonalinjury.
2. Dressproperly.Donotwearlooseclothingorjewelry.Containlonghair.Keepyourhair,
clothing,andglovesawayfrommovingparts.Looseclothes,jewelry,orlonghaircanbe
caughtinmovingparts.
3. Avoidaccidentalstarting.Besureswitchisoffbeforepluggingin.Carryingmagneticdrilling
machineswithyourfingerontheswitchorplugginginmagneticdrillingmachinesthathave
theswitchoninvitesaccidents.

ISSUE1/Originalversion/OCT2013

6
6
4. Neverplacehands,fingers,glovesorclothingnearcuttingareaorrotatingmachineparts.
5. Removeadjustingkeysorswitchesbeforeturningthemachineon.Awrenchorakeythatis
leftattachedtoarotatingpartofthemachinemayresultinpersonalinjury.
6. Donotoverreach.Keepproperfootingandbalanceatalltimes.Properfootingandbalance
enablesbettercontrolofthemagneticdrillingmachineinunexpectedsituations.
7. Usesafetyequipment.Alwaysweareyeprotection.Dustmask,non‐skidsafetyshoes,hard
hat,orhearingprotectionmustbeusedforappropriateconditions.
8. Alwaysusesuppliedsafetychainduringanyworkonnon‐horizontalcomponents.Mounting
canrelease.


MACHINEUSEANDCARE
1. Whenusingthemachineonnon‐horizontalsurfaces,youmustusecuttingpaste.Donotuse
oilbecausetheoilcandripintothemotorunit.
2. Duringmachineoperations,theannularcuttermustbecooledandlubricatedwithgood
qualitycuttingorlubricationoil.Removetheslugfromtheannularcutteraftereachhole.
Caution,theslugmaybehot!
3. Useclampsorotherpracticalwaytosecureandsupporttheworkpiecetoastableplatform.
Holdingtheworkbyhandoragainstyourbodyisunstableandmayleadtolossofcontrol.
4. Donotusemachineifswitchdoesnotturnitonoroff.Anytoolthatcannotbecontrolled
withtheswitchisdangerousandmustberepaired.
5. Disconnecttheplugfromthepowersourcebeforemakinganyadjustments,changing
accessories,orstoringthetool.Suchpreventivesafetymeasuresreducetheriskofstarting
thetoolaccidentally.
6. StoreidleMagneticdrillingmachinesoutofreachofchildrenandotheruntrainedpersons.
Toolsaredangerousinthehandsofuntrainedusers.
7. Maintainmachineswithcare.Keepcuttingtoolssharpandclean.Properlymaintainedtools,
withsharpcuttingedgesarelesslikelytobindandareeasiertocontrol.
8. Checkformisalignmentorbindingofmovingparts,breakageofparts,andanyother
conditionthatmayaffectthemachineoperation.Ifdamaged,havethetoolservicedbefore
using.Manyaccidentsarecausedbypoorlymaintainedtools.
9. UseonlyaccessoriesthatarerecommendedbyEuroboorBVforyourmodel.Accessoriesthat
maybesuitableforonemachine,maybecomehazardouswhenusedonanothermachine.


SERVICE
Toolservicemustbeperformedonlybyqualifiedrepairpersonnel.Serviceormaintenance
performedbyunqualifiedpersonnelcouldresultinariskofinjury.
Whenservicingatool,useonlyidenticalreplacementparts.Followinstructionsinthe
Maintenancesectionofthismanual.Useofunauthorizedpartsorfailuretofollow
MaintenanceInstructionsmaycreateariskofelectricshockorinjury.
Whenusingthismachine,youMUSTwearearandeyeprotection.


ISSUE1/Originalversion/OCT2013

7
7
ADDITIONALSPECIFICSAFETYRULESFORMAGNETICDRILLINGMACHINES

•Keepyourfingerswelloutofthedrillarea;
•Avoidtouchingthedrilledcorethatisautomaticallyejectedbythecenteringpinwhenthe
workingprocedureisfinished.Contactwiththecorewhenitishot,orifitfalls,cancause
personalinjuries;
•Alwaysusethedrillguard.Beforeturningonmachineensuretheguardisclosedsecurely;
•Alwaysusethesafetystrap;
•Themagneticdrillingmachineissuitableforuseonsteelwithathicknessstartingfrom6
mm,withzeroairgapbetweenthemagnetcoresurfaceandthemountingsurface.
Curvature,coatsofpaintandsurfaceirregularitieswillcreateanairgap.Keeptheairgaptoa
minimum;
•Alwaysplacethemachineonaflatsurface;
Donotclampthemagneticdrillingmachineonsmallorirregularlyshapedobjects;
•Alwaysplacethemachineonasurfacethatisclearofshavings,chips,swarfandsurfacedirt;
•Keepthemagnetcleanandfreeofdebrisandswarf;
•Donotturnonthemachineuntilithasbeenmountedandinstalledaccordingtothese
instructions;
•Donotturnonthemachinebeforehavingcheckedthatthemagneticstandhasbeen
tightenedfirmlytothemountingsurface;
•Adjustthetablesocutterdoesnotextendintotheworkpiecebeforedrilling.Donotperform
anydesign,assemblyorconstructionactivitiesontheworkpiecewhilethemachineisturned
on;
•Beforeturningonthemachine,makesuretheaccessoryhasbeenmountedcorrectly;
•Alwaysusetherecommendedspeedfortheaccessoriesandthematerial;
•Donotusethemachineonthesameworkpieceonwhichelectricweldersarebeingused;
•Useonlyanappropriatecuttingfluid.Useageneralnon‐oil‐basedmetalcuttingcoolant
dilutedwithwater;
•Donotuseliquidcuttingfluidswhiledrillingverticallyoroverhead.Dipthecutterincutting
pasteorapplyanappropriatesprayfortheseapplications;
•Donotpourcuttingfluidintothereservoirwhileitismountedinthebracket.Donotallow
cuttingfluidtoenterthedrillmotor;
•Beforeuse,ensuremovablechuckguardoperatesproperly;
•Ensurethatmetalchipsorresinousresiduecannotleadtoblockageofthefunction;
•Incaseofjammedcutterdisconnectthemachinefromthepowersupply,removethereason
forthejambeforeturningonthemachineagain.


RESIDUALRISKS
Inspiteoftheapplicationoftherelevantsafetyregulationsandtheimplementationofsafety
devices,certainresidualriskscannotbeavoided.
Theseare:
Impairmentofhearing
Riskofpersonalinjuryfromflyingparticles
Riskofburnsduetoaccessoriesbecominghotduringoperation
Riskofpersonalinjuryduetoprolongeduse.

ISSUE1/Originalversion/OCT2013

8
8

MARKINGSONTHETOOL
Thefollowingpictogramsareshownonthetool:


Readinstructionmanualbeforeuse.


Wearearprotectioninareaswithnoiseemissions>80db(A).


Weareyeprotection.



POSITIONSerialnumber
TheSerialNumber,whichalsoincludesthetypeofmachine,theyearandmonthofmanufacturing
andidentificationnumber,isengravedontheframe,magnetandthemotorunit.

Example:

050T1211001

Modeltype
YearofManufacture
Monthofmanufacture
Identificationnumber


PACKAGECONTENT

1Magneticdrillingmachine
4TapcolletsM10DIN376,M12DIN376,M14DIN376,M16DIN376
1Carryingcase
1Drillguard
3Handles
1AllenKey2.5
1AllenKey3
1AllenKey4
1AllenKey5
1Wrench8
1Lubricationsystem
1Safetychain
1Cuttingoil
1MT3
1MT3Ejectionpin
1Operatorsmanual
1Explodeddrawing
1SafetyEarProtection
1SafetyGlasses
1SafetyGloves

ISSUE1/Originalversion/OCT2013

9
9
TECHNICALDATAECO.50‐T

ANNULARCUTTERS ø12‐50mm
TWISTDRILLS  ø1‐23mm
THREADING  M3‐M16
COUNTERSINKING ø10‐40mm
LENGTH245mm
WIDTH   160mm
HEIGHT   385‐550mm
STROKE   170mm
WEIGHT  14kg
MAGNET(LxWxH) 170x85x48mm
MAGNETICFORCE 1850kg
MOTORPOWER1250W
TOTALPOWER  1360W
SPEED(noload)  (I)100‐280minˉ¹
(II)185‐530minˉ¹
SPEED(load1200W) (I)250minˉ¹
(II)460minˉ¹
SPINDLE  MT2‐19,05mmWeldon
AVAILABLE   110/120&220/240VoltAC


Emissionvaluesforsoundandvibration
(Two‐figure–specificationsasperISO4871)

Soundemission
MeasuredA‐weightedsoundpowerlevelLwA(re1pW),in
decibels103
MeasuringuncertaintyKwA,indecibels3

A‐weightedemissionpressurepowerlevelmeasuredatthe
workplaceLpA(re20μPa),indecibels103
MeasuringuncertaintyKpA,indecibels3

Vibrationemission
Ratedacceleration,inm/s²0.5
MeasuringuncertaintyK,inm/s²1.5


REMARK:Thesumofthemeasuredemissionvalueandrespectivemeasuringinaccuracyrepresents
theupperlimitofthevaluesthatcanoccurduringmeasuring.

Wearearprotection!

Formeasurementvaluesobtainedaccordingtotherespectiveproductstandard,seethelastpageof
thisInstructionManual.

ISSUE1/Originalversion/OCT2013

10
10
DESCRIPTION(fig.1)

WARNING:Nevermodifythepowertooloranypartofit.Damageorpersonalinjurycould
result.

1. SafetyGuard
2. Feedhandle
3. Coolingsystemtank
4. Magneticstand
5. Magnetswitch
6. Motorswitch

INTENDEDUSE
Thismagneticdrillingmachineisintendedforcommercialuseasadrillingmachinefordrilling
materialswithamagnetizablesurfaceusingannularcuttersandtwistdrills,andfortapping,
countersinkingandreaminginaweather‐protectedenvironmentusingtheapplicationtoolsand
accessoriesrecommendedbyEUROBOOR.
Themagneticdrillingmachinecanbeusedhorizontally,verticallyoroverhead.

INSTRUCTIONSFORPUTTINGINTOOPERATION
Pleasemakesurethatthecontactingsurfaceforthemagnetislevel,cleanandrust‐free.
Removeanyvarnishorprimer.Whenworkingonmaterialsthatarenotmagnetizable,suitable
fixationdevices,obtainableasaccessoriesfromEUROBOOR,e.g.suctionplate,vacuumplateor
pipe‐drillingdevicemustbeused.
Whenworkonsteelmaterialswithamaterialthicknessoflessthan12mm,theworkpiecemust
bereinforcedwithanadditionalsteelplateinordertoguaranteethemagneticholdingpower.

Checkthemachineforpossibledamage;Beforeusingthemachine,youmustcarefullycheck
protectivedevicesorslightlydamagedcomponentstoensuretheyareoperatingperfectlyandas
intended.
Checkthatmovingareinperfectworkingorderanddonotjamandcheckwhetherpartsare
damaged.Allpartsmustbecorrectlyinstalledandfulfillallconditionsnecessarytoensureperfect
operationofthemachine.
Damagedprotectivedevicesandpartsmustberepairedorreplacedaccordingtospecificationsby
EUROBOORofanyauthorizedEUROBOORdealer.

DONOTuseunderwetconditionsorinpresenceofflammableliquidsorgases.Thismagneticdrilling
machineisaprofessionalpowertool.

DONOTletchildrencomeintocontactwiththemachine.Supervisionisrequiredwhen
inexperiencedoperatorsusethismachine.

ELECTRICALSAFETY
Theelectricmotorhasbeendesignedforonevoltageonly.Alwayscheckthatthepowersupply
correspondstothevoltageontheratingplate.

YourEUROBOORMAGNETICDRILLINGMACHINEisdesignedinclassI(grounded)accordingto
EN61029‐1.Earthwireisrequired.

Ifthesupplycordisdamaged,itmustbereplacedbyaspeciallypreparedcordavailablethroughthe
EUROBOORserviceorganization.

ISSUE1/Originalversion/OCT2013

11
11
EXTENSIONCABLE
Ifanextensioncableisrequired,useanapproved3‐coreextensioncablesuitableforthepowerinput
ofthistool(seetechnicaldata).Theminimumconductorsizeis1.5mm²;themaximumlengthis30
meter.Whenusingacablereel,alwaysunwindthecablecompletely.


ASSEMBLYANDADJUSTMENTS
WARNING:Toreducetheriskofinjury,turnunitoffanddisconnectmachinefrompower
sourcebeforeinstallingandremovingaccessories,beforeadjustingorchangingset‐upsor
whenmakingrepairs.BesuretheswitchisintheOFFposition.Anaccidentalstart‐upcan
causeinjury.

PREPARATIONOFTHEMACHINE(FIG.1)
1. Assemblethefeedhandle.
2. Mountthedrillguard.
3. Fitthelubricationsystemasnecessary.
4. Placethemachineonaclean,levelandsolidsurface.Removeanyparticlesthatwillobstruct
fullcontactbetweenthemagneticstandandthemountingsurface.
5. Fitthesafetychain(inverticaloroverheaddrillingapplications).


MOUNTINGTHEDRILLGUARD(FIG.1)
Theguardprotectingagainstchippingsandaccidentalcontactmustalwaysbemountedduring
operation.
1. Holdtheguardinfrontofthemagnet,aligningtheslotsintheguardwiththeholesinthe
magnet.
2. Fitthescrewsintotheholelocatedinthesideofthemagnet.


WARNING:AlwaysusetheSafetyguard.


FITTINGTHELUBRICATIONSYSTEM(FIG.1)
Thelubricationsystemcanbeusedforhorizontaldrillingapplications(thedrillbeingusedvertically).
Holdthecoolingtankagainstthebracketontheslideandpushitinitsplace.
Connectthehosetothenippleonthespindledriveshaft.

Inordertousethelubricationsystem,itmustbefilledwithasufficientamountofcuttingfluid.
1. Makesuretheflowregulatorisclosed;
2. Unscrewthecap;
3. Fillthecontainerwithcuttingfluid;
4. Screwthecapbackon.

WARNING:Donotusethelubricationsysteminverticaloroverheaddrillingapplications.
InsteaduseEuroboorcuttingpaste


FITTINGTHESAFETYCHAIN
1. Passthesafetychainthroughtheopeningnearthegrip;
2. Wrapthechainaroundtheworkpiece;
3. Securelyclosethechainusingthelock.

WARNING:Alwaysusethesafetychainwhenusingmachineverticallyand/orup‐side‐down.

ISSUE1/Originalversion/OCT2013

12
12
INSERTINGANDREMOVINGANACCESSORY(FIG.1)
Thetoolholderacceptsannularcutterswitha19,05mmWeldonshankwithoneormoreflats.

WARNING:Theteethofacutterareverysharpandcanbedangerous.

1. Inordertofitanannualcutteritisnecessarytoremovetheguard(1);
2. Slidethepilotpinthroughtheholeinthecenterofthecuttershank.
3. Inserttheshankoftheaccessoryasfarintothetoolholderaspossible.
4. TightenthetwoAllenscrewswithAllenkey;
5. Toremovetheaccessory,loosentheAllenscrewsandtakeoutthecutter.


PRIOR TO OPERATION
Tryafewsimpleprojectsusingscrapmaterialuntilyoudevelopa“feel”forthemachine.
OPERATION
Instructions for Use

WARNING:Alwaysobservethesafetyinstructionsandapplicableregulations.

WARNING:Toreducetheriskofseriouspersonalinjury,turntooloffanddisconnecttoolfrom
powersourcebeforemakinganyadjustmentsorremoving/installingattachmentsor
accessories.

MAGNETICBASE
Materialofminimum10mmthicknessisrequiredforthemagnettoworkthebest.

Theattachmentforcegeneratedbythemagnetdependsonvariousfactors.

Thicknessofthematerialthemagnetisplacedon;
Paintorcoatingofthematerialthemagnetisplacedon;
Metalchips,oilorotherdirtunderthemagnet.

IftheLEDindicator(seepage13)lightsupGREEN,themagnetisgeneratingsufficientattachment
force.IftheLEDindicatorlightsupRED,themagnetmaynotgeneratingsufficientattachmentforce.

WARNING:DonotusethismachinewhenLEDindicatorisRED.Magnetmaynotgenerate
sufficientattachmentforce

Wewouldliketopointoutthatthisisonlyanindicationandnotacertainlythatthemagnetwill
notreleasefromthematerial.Eurobooracceptsnoliabilityensuringfromthemagnetindicatornot
functioningorfunctioningpoorly.

Makesurethatthemagnetattachestightlytotheworkpiecebeforeturningonthemotorunitofthe
magneticdrillingmachine.Euroboormagnetshave2coils;makesurethatbothcoilsareincontact
withthematerial.Donotconnectanyothermachinestotheelectricaloutletthemagneticdrilling
machineispluggedinto,asitmayresultinthelossofmagneticforce.

Alwaysusethesafetychainincluded.Drillingaboveyourheadisextremelydangerousandisnot
recommended.Fortheuseofmagneticdrillingmachinesonpipes,not‐flatornon‐magnetic
materials,werefertoourbrochureorourwebsitewww.euroboor.comwhereseveralvacuum
tighteningsystemsandpipeclampingsystemsarementioned.

ISSUE1/Originalversion/OCT2013

13
13
TURNINGMACHINEONANDOFF

THECONTROLPANEL
Thecontrolpanelonyourmagneticdrillingmachineisdesignedformaximumoperatingfacilityand
safety.

1. TheL/RSwitch:
Thisswitchcontrolsthedirectionofthe
motorunit.

2. TheMotorSwitch:
Thisswitchisusedtoswitchthemotor
unitONandOFF;

3. TheMagnetLEDIndicator:
ThisLEDindicatorshowsthegenerated
magneticforce;

4. TheFuseholderwithFuse:
ThisFuseholderisincludedonevery
EuroboorMagneticDrillingMachineand
holdsthefusetype:5x20,F2A.

5. ThePotentiometer:
Thiscontrolstherunningspeedofthemotorunit.
Note:Alowerpositionwilldecreasethepowerofthemotorunit. 

6. TheMagnetSwitch:
ThisswitchisusedtoswitchthemainpowerandalsothemagnetOnandOff.Thisswitchisincluded
oneveryEuroboormagneticdrillingmachine

Inordertooperateproperly,themachinehastobeturnedonfollowingtheprocedureasdescribed
below.

ACTIVATINGTHEMAGNET
Connectthemachinetothemains/workpiece.Toactivatethemagnet,presstheredbutton
(Fig.2–6).Theswitchwillbelit(red).TheLEDindicator(Fig.2‐3)willbelitGREENifgenerated
magneticforceissufficient.WhenLEDindicatorturnsREDthereisnotenoughmagneticforceandit
isnotsafetowork.Todeactivatethemagnet,pressthesamebutton(Fig.2‐6)again.

TURNINGTHEMOTORONANDOFF
ThemotorunitcanonlybeswitchedONwhenthemagnetisactivated.ToturnthemotorON,press
thegreenbuttonwithmarking“I”(Fig.2‐2).ToswitchthemotorOFF,presstheredbuttonwith
marking“O”(Fig.2‐2).

TORQUE
TheECO.50‐Tisequippedwithanall‐timeelectronictorqueprotection.Itwillstopthemotorunit
whenitgetsoverloadedinanyrpm.InthatcasejustpushtheOFFswitchtoresetandONswitchto
startdrillingagain.


Fig.2

ISSUE1/Originalversion/OCT2013

14
14
TEMPERATURE
TheECO.50‐Tisequippedwithanall‐timeelectronictemperatureprotection.Ifthetemperatureof
themotorunitrunsupto70DegreeCelsiusthemotorunitwillstop.Afterafewminutesitcanbe
startedagainandwerecommendrunningthemotorunloadedwiththeelectronicspeedadjustment
seton100%inordertoletthemotorunitcooldown.


DRILLINGAHOLE
Nowthatyouhavereadtheexplanatoryinformationandsafetyrecommendationsabove,youare
readytoactuallystartdrilling.Followthese10stepsforbestdrillingresult:

1Usethetipofthepilotpintodeterminethecenteroftheholetobedrilled.

2Turnthemagnetonandverifythatthedrillisintherightpositionandthatthemachineis
pushedtightagainsttheworkpiece.

3Ifyourmachineisequippedwithaautocoolantsystem,putopenthevalvetoreleasetheoil.If
yourmachinedoesnothaveaautocoolantsystem,filltheholesofthespindlewithoil.

4Turnthemotoronatthehighestsettingandallowittorunatfullspeed.

5Turnthearmstostartdrilling.ApplyonlyaslightpressurewhentheAnnularCuttertouchthe
metal.DonotpushtheAnnularCutterwithforceintothemetal.

6Applyaregularpressurewhiledrilling.Thedrillingperformancedoesnotimprovebyputting
morepressureonthetool.ToomuchpressurewilloverloadthemotorandyourAnnularCutter
willbewornsooner.Letthecutterdothejobandgiveittimetocutthemetal!!!

7Adjusttheoilsupplywhennecessary,ifyourdrilldoesnothaveaautocoolantsystem,stop
drillingregularly,refilltheholesofthespindleandcontinuedrilling.

8Applylesspressurewhenthedrillcutsthroughthematerial.

9Turnthearmstoputthemotorinhighestpositionandturnoffthemotorunit.

10Removetheburr,metalchipsandcleanthecutterandsurfacewithoutgettinginjuries.
Caution:Themetalpiecedrilledoutcanbesharpandveryhot!!


DRILLINGWITHANNULARCUTTERS
Annularcuttersonlycutmaterialattheperipheryofthehole,ratherthanconvertingtheentirehole
toshavings.Asaresult,theenergyrequiredtomakeaholeislowerthanforatwistdrill.
Whendrillingwithanannularcutter,itisnotnecessarytodrillapilothole.

WARNING:Donottouchthecutterorthepartsclosetothecutterimmediatelyafter
operation,astheymaybeextremelyhotandcauseburnstotheskin.Ensurenobodyisinthe
workareawherethemetalcoreisejected.



ISSUE1/Originalversion/OCT2013

15
15
DRILLINGCONDITIONS
Theeasewithwhichmaterialcanbedrilleddependsonseveralfactorsincludingtensilestrengthand
abrasionresistance.Whilsthardnessand/orstrengthistheusualcriterion,widevariationsin
machineabilitycanexistamongmaterialshowingsimilarphysicalproperties.

Thedrillingconditionsaredependentonrequirementsfortoollifeandsurfacefinish.These
conditionsarefurtherrestrictedbytherigidityofthetoolandtheworkpiece,lubricationand
machinepoweravailable.Theharderthematerial,thelowerthecuttingspeed.

Somematerialsoflowhardnesscontainabrasivesubstancesleadingtorapidcuttingedgewearat
highspeeds.Feedratesaregovernedbyrigidityofset‐up,volumeofmaterialtoberemoved,surface
finishandavailablemachinepower.


THREADING
Themachineisequippedwithareversibledirectionofrotationandcanalsobeusedforcutting
threads.Proceedasfollowsforcuttingthreads:

Drilltheholeforthethreadontherecommendedsizeofthetap;

Switchoffthemachine(Fig.2‐2)andchangethecutterforthetapcolletandthemachine
tap.Keepthemachineinthesameposition;

Selectthelowestgear(Fig.4)andlowestspeed(Fig.2‐5)andsetthedirectionofrotationto
clockwise(right=R)atswitch(Fig.2‐1);

Switchon(Fig.2‐2)themachineandsetthemachinetapontothedrilledhole;

Guidethemachineslidedownatthehandle(Fig.1‐2)withoutexerting;

Switchoff(Fig.2‐2)themachine(justbeforethetapiscompletelythroughthehole)andset
thedirectionofrotationtoanti‐clockwise(left=L)atswitch(Fig.2‐1).

Switchonthemachine(Fig.2‐2)againandallowthemachinetaptocomecompletelyoutof
theworkpiece.Thenguidethemotorunitslideupwardsathandlestoavoiddamagingthe
startofthethread.DONOTLETYOURTAPPUSHUPTHEMOTORUNITBYITSELF!!

COUNTERSINKING/REAMING
Thankstoitswiderangeofoperatingspeeds,themachinecanalsobeusedforreamingorcounter‐
sinking.


ISSUE1/Originalversion/OCT2013

16
16
LUBRICATION
INHORIZONTALAPPLICATIONS
Adjustthefluidflowasrequiredusingtheflowregulator;
Addmorecuttingfluidiftheshavings(metalchips)becomeblue.

VERTICALANDOVERHEADAPPLICATIONS
Dipthecutterincuttingpasteorapplyanappropriatespray.

LUBRICATINGTHEFEEDTRAVEL
Thefeedtravelshouldbelubricatedperiodicallywithgreasetoensuresmoothoperation.
Raisethemotorunittothehighestpositionpossible;
Lubricatethedove‐tailguidewayatbothsides;
Lubricatethegearrack.

Afterrepeateduse,thegearrackmaybecomeloose.Ifnecessary,adjustthe5self‐lockingset
screwsattheleftside.Tightenscrewsinseriesuntilthegearrackmovesfreelyinthedove‐tailguide
butdoesnotallowthemotortowobble.

Cleaning
WARNING:Blowdirtanddustoutofthemainhousingwithdryairasoftenasdirtisseen
collectinginandaroundtheairvents.Wearapprovedeyeprotectionandapproveddustmask
whenperformingthisprocedure.

WARNING:Neverusesolventsorotherharshchemicalsforcleaningthenon‐metallicpartsof
thetool.Thesechemicalsmayweakenthematerialsusedintheseparts.Useacloth
dampenedonlywithwaterandmildsoap.Neverletanyliquidgetinsidethetool;never
immerseanypartofthetoolintoaliquid.

OptionalAccessories
WARNING:Sinceaccessories,otherthanthoseofferedbyEUROBOOR,havenotbeentested
withthisproduct,useofsuchaccessorieswiththistoolcouldbehazardous.Toreducetherisk
ofinjury,onlyEUROBOORrecommendedaccessoriesshouldbeusedwiththisproduct.

Consultyourdealerforfurtherinformationontheappropriateaccessories.



ISSUE1/Originalversion/OCT2013

17
17
MAINTENANCE
YourEUROBOORpowertoolhasbeendesignedtooperateoveralongperiodoftimewitha
minimumofmaintenance.Continuoussatisfactoryoperationdependsuponpropertoolcareand
regularcleaning.

CAUTION:Toreducetheriskofinjury,turnunitoffanddisconnectmachinefrompower
sourcebeforeinstallingandremovingaccessories,beforeadjustingorchangingset‐upsor
whenmakingrepairs.BesuretheswitchisintheOFFposition.Anaccidentalstart‐upcan
causeinjury.

Justaseverymagneticdrillingmachinewithmovingparts,yourEuroboormagneticdrillingmachine
alsoneedsregularmaintenanceservice.Afewrecommendationsfollow:

VISUALLYCHECKTHEMACHINEFORDAMAGE
Machinemustbecheckedbeforeoperationforanysignsofdamagethatwillaffecttheoperationof
themachine.Particularnoticemustbetakenofthemainscable,ifthemachineappearstobe
damageditshouldnotbeusedfailuretodosomaycauseinjuryordeath.

CAUTION:Cleanalldirt,dust,metalchipsandburrsofyourmagneticdrillingmachine


OPERATIONOFTHEMACHINE
Themachinesoperationmustbecheckedtoensurethatallcomponentsareworkingcorrectly.
Replaceanydefectivepartsimmediately.Thispreventsproperlyfunctionpartsfrombeingdamaged.
CARBONBRUSHES
Brushesshouldbecheckedtomakesurethereisnoabnormalwearpresent.Thisshouldbechecked
atleastonceaweekifusedfrequently.Ifthecarbonbrushhaswornmorethan2/3theoriginal
lengththebrushesshouldbechanged.Failuretodosomaycausedamagetothemachine.

CHECKMAGNETICBASE
Beforeeveryoperationthemagneticbaseshouldbecheckedtomakesurethatthebaseisflatand
thereisnodamagepresent.Anunevenmagnetbasewillcausethemagnetnottoholdasefficiently
andmaycauseinjurytotheoperator.

CHECKMACHINESGREASE
Thegearboxgreaseshouldbecheckedonceamonthtoensureallmovingcomponentsarecovered
topreventwear.Thegreaseshouldbechangedatleastonceayeartoensureyougainthebestfrom
themachine.

CHECKARMATURE
Thisshouldbecheckedatleast1permonthtocheckthattherearevisualsignsofdamagetothe
bodyortothecommutator.Somesignsofwearwillbeseenonthecommutatoroveraperiodof
timethisisnormalasthisisthepartthatcomesincontactwiththebrushesbutanysignsof
abnormaldamageandthepartshouldbereplaced.


ISSUE1/Originalversion/OCT2013

18
18
ADJUSTMENTOFSLIDE
Anessentialrequirementofthemachineisthattheslidecanmoveinasmoothandcontrolled
manner,freeoflateralmovementandvibration.

Thissituationcanbemaintainedbyperiodicadjustmentoftheslideandisaccomplishedinthe
followingmanner:
1. Placethemachineinanuprightpositionand,bymeansofthecapstan,raisetheslidetoits
highestposition.Cleanthebrassrailstripsandapplyasmallamountoflightmachineoilto
thewearsurfaces.
2. Commencingwiththetopscrew,loosenbothsettingnut(#4onsparepartdrawing)with
includedwrench8andthesettingscrew(#5onsparepartdrawing)withincludedAllenkey
2.5.Thengentlyfeedinsettingscrewuntilslightresistanceisencountered.Followyourway
downadjustingallsettingnutsandscrews.
3. Operatetheslideupanddownafewtimestotestthemovementandmakeanyfurther
necessaryadjustments.Trytoensurethatallthescrewsareexertingauniformpressureon
theslidefromtoptobottom.Aperfectlyadjustedslidewilloperatefreelyupanddown
withoutanysidewaysmovement.

REPAIR,MODIFICATIONANDINSPECTION
Repair,modificationandinspectionofEuroboorMagneticdrillingmachinesmustbedoneby
EUROBOORoranEUROBOORauthorizeddealer.Thesparepartslistwillbehelpfulifpresentedwith
themachinetotheEuroboordealerforservicewhenrequestingrepairorothermaintenance.

Euroboormachinesareconstantlybeingimprovedandmodifiedtoincorporatethelatest
technologicaladvancements.Accordingly,someparts(i.e.partnumbersand/ordesign)maybe
changedwithoutpriornotice.Also,duetoEuroboor'scontinuingprogramofresearchand
development,thespecificationsofmachinesaresubjecttochangewithoutpriornotice.

ISSUE1/Originalversion/OCT2013

19
19
TROUBLESHOOTING

Magnetandmotordonot
function
‐Themagnetswitchisnotconnectedtothepowersupply
‐Damagedordefectivewiring
‐Defectivefuse
‐Defectivemagnetswitch
‐DefectiveControlUnit
‐Defectivepowersupply
Magnetdoesfunction,themotor
doesnotwork
‐Damagedordefectivewiring
‐Carbonbrushesarestuckorwornout
‐Defectivemagnetswitch
‐DefectiveOn/Offswitch
‐DefectiveControlUnit
‐Defectivearmatureand/orfield
Magnetdoesnotfunction,the
motordoes
‐Defectivemagnet
‐Defectivewiringofmagnet
‐DefectiveControlUnit
Annularcuttersbreakquickly,
holesarebiggerthanthehole
cutter
‐Clearanceintheguide
‐Bentspindle
‐Shaftextendingfromthemotorisbent
‐Bentpilot pin
Motorrunningroughlyand/or
seizingup
‐Bentspindle
‐Shaftextendingfromthemotorisbent
‐Triangularguidenotmountedstraight
‐Dirtbetweenspindleandtriangularguide
Motorstartsrunningwhen
magnetswitchisturnedon
‐Damageordefectiverelaisincontrolunit

Motormakingarattlingsound‐Gearring(bottomofthearmature)wornout
‐Gear(s)wornout
‐Nogreaseingearbox
Motorhumming,bigsparksand
motorhasnoforce
‐Armaturedamaged(burned)
‐Fieldburned
‐Carbonbrusheswornout
Motordoesnotstartorfails.

‐Damagedordefectivewiring
‐DirtinsensorSpeedControlUnit
‐Defectiveorloosemagnetontopofarmature
‐Damagedordefective(sensor)SpeedControlUnit
‐DamagetoArmatureorfieldcoil
‐Damagedordefectivecarbonbrushes
Guidingtakesagreatdealof
effort
‐Guideissettootight
‐Guideisdry,needstobegreased
‐Guide/gear‐rack/rotationsystemdirtyordamaged
Insufficientmagneticforce‐Damagedordefectivewiring
‐Bottomofmagnetnotcleananddry
‐Bottomofmagnetnotflat
‐Workpieceisnotbaremetal
‐Workpieceisnotcleanorflat
‐Workpieceislessthan10mm(toothin)
‐DefectiveControlUnit
‐Defectivemagnet

ISSUE1/Originalversion/OCT2013

20
20
Frameundervoltage‐Damaged/defectivewiring
‐Defectivemagnet
‐Motorseriouslydirty
Fuseblowswhenmagnetswitchis
turnedon
‐Damagedordefectivewiring
‐Wrongvaluefuse
‐Defectivemagnetswitch
‐DefectiveControlUnit
‐Defectivemagnet
Fuseblowswhenmotorisstarted ‐Damagedordefectivewiring
‐Wrongvaluefuse
‐Motorrunningroughly
‐DefectiveArmatureand/orField
‐Carbonbrusheswornout
‐DefectiveControlUnit
Rotationsystemfreestroketoo
long
‐Looseordefectivegear‐rack
‐Defectiverotationsystem


NOTE:PleasecontactEUROBOORifthereismachinefailureandtheproblemcannotbesavedwith
oneoftheabovesolutions!!


PROTECTINGTHEENVIRONMENT

Separatecollection.Thisproductmustnotbedisposedofwithnormalhouseholdwaste.



ShouldyoufindonedaythatyourEUROBOORproductneedsreplacement,orifitisofnofurtheruse
toyou,donotdisposeofitwithhouseholdwaste.Makethisproductavailableforseparate
collection.

Separatecollectionofusedproductsandpackagingallowsmaterialstoberecycledandused
again.Re‐useofrecycledmaterialshelpspreventenvironmentalpollutionandreducesthe
demandforrawmaterials.

Localregulationsmayprovideforseparatecollectionofelectricalproductsfromthehousehold,at
municipalwastesitesorbytheretailerwhenyoupurchaseanewproduct.
