Everflo EPU-HW User manual

INSTALLATION INSTRUCTIONS —
POINT OF USE WATER HEATERS
EPU - HW

CONTENTS
PAGE INSTALL CONTENT
2 Introduction
3 Component List & Technical Specification
4 Component Diagram
5 Installation
9 Commisioning & Maintenance
10 Warranty Policy
01

Thank you for purchasing this
instantaneous water heater. This
handwash unit is manufactured
to the highest standards and
has been designed to meet
all the latest relevant safety
regulations.
Please read and understand
these instructions before
starting work. Please leave
these instructions with the user
following installation.
This water heater must
be installed by a qualified
technician. The manufacturer
will not be held liable for
damages caused by incorrect
installation and/or the failure
to comply with the instructions
contained in this manual.
Particular attention should
be paid to the section headed
“Installation.”
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervison or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision.
Children must be supervised to
ensure they do not play with the
appliance.
The spray head must be
descaled regularly
WARNING: Do not switch on if
there is a possibility that the
water in the heater is frozen.
INTRODUCTION
02

TECHNICAL SPECIFICATION
Power 2605 ~ 3100W
Voltage 220 ~ 240V
Current 11.8 ~ 12.9A
Rated pressure 0 Pa
Water pressure 1 ~ 7bar (0.1 ~ 0.7MPa)
Water connection 1/2” BSP male
IP Code IPX4
Inlet and outlet distance 90mm
Dimensions 220 x 170 x 90mm
Weight 1.6kg
ErP Band A
Load Profile XXS
AEC 509.3kWh
COMPONENT CHECKLIST
Before commencing installation check that all the following
components have been supplied with water heater.
Heater
Spout
Fitting instructions
03

COMPONENT DIAGRAM
1 - Inlet
2 - Outlet
3 - Water container assembly
4 - Flow valve (To close: turn
. clockwise)
5- Flow switch
6 - Cable clamp
7 - Main connector block
8 - Thermal cut-out
12
3
8
4
5
6
7
04
Figure 1.

INSTALLATION
Products are manufactured are
in accordance to International
Standards; IEC 60335-1. These
appliances are safe and without
risk, provided they are installed,
used and maintained in good
working order in accordance
with our instructions and
recommendations.
Please read and understand
these instructions before
starting work and retain them
for later use.
DO NOT operate the appliance if
it is without water.
These heaters are of the opened
outlet type (0 rated pressure)
and are suitable for connection
to normal cold water mains
supplies up to a maximum of
0.7MPa (7bar).
DO NOT operate the appliance if:
• Water ceases to flow during
use.
• Water has entered inside the
unit because of an incorrectly
fitted cover.
• The appliance is damaged.
In all the above cases turn off
mains power and isolate water
supply.
ISOLATE the electrical and water
supplies before removing the
cover.
ISOLATE the electrical and water
supplies BEFORE proceeding
with installation or servicing.
CAUTION
It is recommended that persons
who may have difficulty
understanding or operating
the controls should not be left
unattended whilst using the
appliance. Special consideration
should be given to young
children and persons with
reduced physical, sensory, or
mental capabilities.
Only use designated entry points
for cable and pipe.
05

WALL MOUNTING
Mount the unit to the wall using
suitable fixtures for the wall
material.
Ensure the wall is suitable for
supporting the load.
Ensure there is no obstruction
at the screw holes such as
electrical cables or water pipes.
PLUMBING
All plumbing work must comply
with national and applicable
national and local plumbing
regulations.
The supply pipe must be flushed
to clear debris.
Cold water connection (inlet) is
on the right side of the unit, hot
water connection (outlet) is on
the left side of the unit; which
need to be connected with the
spout.
The outlet must not be
connected to any tap or fitting
other than those specified.
All plumbing connections must
be completed and checked
for leaks before making the
electrical connections.
INSTALLATION
06

INSTALLATION
ELECTRICAL
CAUTION: In order to avoid
a hazard due to inadvertent
resetting of the thermal cutout,
this appliance must not be
supplied through an external
switching device, such as a timer,
or connected to a circuit that is
regularly switched on and off by
the utility.
All electrical work must comply
with national and applicable
national and local electrical
regulations.
Before fitting the appliance,
ensure that the consumer unit
and any switches are suitable for
the additional load. If in doubt,
contact your electricity supplier
or a qualified electrician.
In each case a double pole
isolating switch with a contact
separation of at least 3mm in
each pole, and a minimum rating
of 13Amp must be incorporated
in the wiring of the appliance.
It is recommended that a
residual current device (RCD)
is used to provide additional
protection against electric
shock. This may be part
of the consumer unit or a
separate unit. The handwash
must be connected to its own
independent electrical circuit.
Feed the wires through side
entry point or break plastic for
wall entry and tighten down on
wire the cable grip as shown in
Figure 2. The “live” wires must
be connected to the slots on the
terminal block marked L. The
ground wire must be connected
to the slot marked with the
ground symbol.
A minimum heat resistance
cable size of 1.5mm2shall be
used.
Reinstall plastic cover.
07

Side Entry
Wall Entry
08
Figure 2.

COMMISIONING
Open the isolating stop valve for a few minutes until water flow is continuous
and all air is purged from water pipes. The unit’s plastic cover must be fitted
before the handwash is turned on.
Turn on main switch to bring electrical power to the unit.
WATER HEATER READY FOR USE
Adjust the water flow and/or temperature to the desired level using the knob on
the front cover of the unit.
Explain to the user how the unit works and familiarise him or her with its use.
Advise the user about possible hazards. Hand over these instructions, to be kept
for future reference.
MAINTENANCE
The handwash is designed for a very long service life.
Actual life expectancy will vary with water quality and use. The unit itself does
not require any regular maintenance.
To ensure consistent water flow, it is recommended to periodically remove scale
and dirt that may build up at spray head.
09

GUARANTEE AND SERVICE POLICY
This product is guaranteed against faulty materials and manufacture for a period
of one year from the date of purchase. In the event of issues with the product
the customer shall contact the technical help line. The branch the product shall
be returned to will be identified and a return number will be allocated. The cus-
tomer shall then return the product to the branch along with the returns number.
No on site field support will be provide for this product.
The Guarrantee is valid provided that:
1. The appliance has been installed by a competent person in accordance with the
Installation, User instructions, all relevant Code of Practice, Regulations in force
at the time of installation and that all necessary controls and safety devices have
been fitted correctly.
2. The appliance has only been used for heating potable water.
3. The appliance has been maintained as detailed in the Installation and User
Instructions.
4. The product has been returned with proof of purchase & returns number
Exclusions:
The inner container with integral heating element is not guaranteed against
excessive scale build-up.
The Warranty is void if:
1. The appliance has been modified or tampered with in any way.
2. The appliance has been damaged by frost.
This guarantee, in no way, affects the statutory rights of the
consumer
10

We take every care and precaution to ensure that information in this document is accurate at the point of publish but with continuous
product development the details given in this document are subject to alteration without notice.
REF: 025208 Everflo - Hand Wash Installation Manual - English - February 2017
Everflo
Unit 11 Capital Industrial Estate
Crabtree Manorway South, Belvedere,
Erith, Kent, DA17 6BJ
Sales Tel.: [phone]
Technical Helpline: 0330 999 0035
sales@everflocylinders.co.uk
www.everflocylinders.co.uk
