Excalibur Water Systems SMART PURIFIER BP-500G User manual

1
SMART PURIFIER™ MANUAL
Excalibur Water Systems Inc.
142 Commerce Park Drive
Barrie, ON, Canada
L4N 8W8
Telephone: [phone]
Fax: [phone]

2
Smart Purifier™ User Manual
Packing List…………………………………………………………………………………………………. 3
Notice………………………………………………………………………………………………………….. 4
Product Specifications……………………………………………………………………………….… 6
Purity to Waste Ratio………………………...………………………………………………………… 6
RO Technical Drawings………………………...……………………………………………………… 7
Product Introduction………………………...…………………………………………………………. 8
Installation & Maintenance……………………...………………………………………………..… 9
Troubleshooting………………………...……………………………………………………………… 16

3
Packing List
Water Purifier 1 pc 1/4" PE Pipe 3 m
Instruction Manual 1 pc 3/8" PE Pipe 3 m
Inlet Water T Valve 1 set Faucet 1 set
Tape
1 roll
Adapter
1 pc
Pipe Pulling Tool 1 pc 1/4" Blue clip 9 pcs
1/4" Quick connecting 2 pcs 3/8" Blue clip 6 pcs
1/4" 0 Ring 3 pcs 3/8" Plastic fitting 2 pcs
3/8" 0 Ring 2 pcs PP+C multi filter 1 pc
1 /4" Plastic fitting 3 pcs RO membrane 1 pc
Leak Sensor 1 set T33 filter 1 pc
Faucet Plate 1 pc Screws 3 pcs
Expansion Rubber 3 pcs
Please check the accessories according to the packing
list before installation.

4
Notice
Attention: Please obey the following safety regulations strictly
1. Do not use other accessories which are not permitted
by manufacturer to avoid any damage of the RO system.
2.Please check the RO system and all accessories
before installation.
3.Children are only permitted to maintain the system
under guardian supervision.
4. If malfunctions appear, please cut off the power, close
the inlet water valve immediately, do not keep the RO
system in working mode.
5.This RO system shall be repaired by authorised and
skilled personnel only.
6.The production capacity of pure water is dependent on
the feed water quality, pressure, and temperature.
Abnormal values will result in a lower flowrate.

5
Notice

6
Product Specifications
Product
Reverse Osmosis Water Purifier
Item Number BP-500G
Related Voltage and Frequency 10 0V-240V~50/60Hz
Rated Power
60W
Water Pressure
0.1-0.4MPa
Purified Water Rate 1.0L/min
Rated Capacity of Purified Water
2000L
Applicable Conditions
Temperature 4-40°C, ambient
humidity below 90%
Water Source
Municipal Water
Product Size 443*132*356mm
Purity to Waste Ratio
1:1
For every gallon of water this reverse osmosis system produces, one gallon is sent to
drain.

7
RO Technical Drawings
Product Spare Parts
Technical Principle

8
Electric Principle Diagram
Product Introduction
Product Function
Stage 1: PP+Carbon Filter: Removes dirt,corrosion,sediment,red
worms,sand and other physical particles to protect the RO membrane.
Stage 2: RO Membrane:Reverse Osmosis Membrane with the filtration
precision 0.0001 μm removes bacterial,virus,antibiotics and other harmful
substances,heavy metal and pesticide residues from water.
Stage 3: T33/Coconut Carbon Cartridge:Absorb odor and improve the taste
of drinking water

9
Installation & Maintenance
Installation
This RO system shall be installed by authorised and skilled personnel only.
Please check all accessories before installation.
Requirements of Installation Conditions
1.1 The RO system is equipped with a booster pump and shall
be used with tap water only.
1.2 Please use the right adapter for voltage 100V-240V.
1.3 Make sure the installation place is clean and not in the
proximity of direct sunlight, high humidity, flammables,
explosives or unsafe electrical equipment.
Attention: Please pay attention to the safety when drilling and
make sure there is no hidden water pipe, electric wire and gas
tube.

10
Installation of Quick Connector
3.1 Quick connector ports are adopted on the inlet and outlet of the RO system.
Quick connector is a port which can connect quickly and firmly without any
tools. Firstly,pull out the Ωtype clip on the port,push the movable plastic ring
to the port,make it attaching to the port to move the plastic plunge or PE pipe.
Insert the PE pipe to the end of the port,then pull slightly to make a gap between
the movable plastic ring and the port. Finally insert the Ωtype clip in the gap.
When taking the PE pipe from quick connector,first pull out the Ωtype clip,push
the movable plastic ring to the port to make it attaching the port,then could pull
out the PE pipe.
3.2 Divide and Connect of PE pipe and quick connector
Connect:Take down Ωtype clip,cut the PE pipe to a smooth end face
and insert into the quick connector,then pull slightly to check PE pipe has
been in the o ring seal of quick connector,finally insert the clip.
Divide:Take down Ωtype clip,make the plastic ring attaching to the port,pull out the
PE pipe.

11
RO Cartridge Installation
4.1 Press top button "Open”, take the lid down and put aside.
4.2 Take out the cartridges from carton, remove the outer
plastic packing.
4.3 Install cartridges according to the instructions on the top
cover.
4.4 After installation, put the lid back on machine.
Installation Place:
Place the machine on a flat and stable surface.
Installation of Water Inlet & Outlet
6.1 Installation of inlet water T valve :Clean the installation area,close the inlet water
valve,take apart the faucet or angle valve,then connect the inlet water T valve,finally
connect to the original faucet or angle valve.
(Attention:Connection of screw thread should be sealed with tape or 0
ring to avoid leakage)
6.2 Connection of inlet water port :connect one side of PE pipe to the inlet
water valve,and another side to the inlet water port on the machine.
6.3 Installation of faucet:According to the required place of faucet,drill a
29mm hole on the stainless steel sink,then fix the faucet.

12
6.4 Connection of purified water port:Connect the 1 /4" fitting to
one side of faucet,cut the 1/4" PE pipe to a suitable length,one side insert to the quick
connector and the other side connect to the port of purified water on the machine.
6.5 Connection of drinking water port:Connect directly with the connecting rod of
faucet,cut the 1 /4" PE pipe to a suitable length, one side insert to the quick connector and
the other side connect to the port of drinking water on the machine.
6.6 Connection of drain water port:Take a suitable length of 3/8" PE pipe to connect with
the port of drain water on the machine . And connect another side to the drain line and fix
the PE pipe to avoid drop.
6.7 Flush the cartridge: Install all the cartridges before flushing. Flushing of PP+C
cartridge: After all the installation, turn on the purified water tap to flush PP+C filter
about 10-20 minutes until the water is clean, then turn off the purified water tap.
Flushing of T33 cartridge: After all the installation, turn on the drinking water tap to flush
about 10-20 minutes until the water is clean.
Attention:
1. lf there is no water coming from the tap, please check the power supply.
2. Flush filter cartridges according to instruction 6. 7. before first usage
General Instructions
When using for the first time, please open the faucet and the inlet water valve.
When water is running from tap, close the tap for 30 minutes and check
for leakages. If there are no leaks, you can use the machine normally.
In normal user mode, keep the power connected, open and close the faucet.
When using the machine after a longer period of no usage, please
open the faucet and flush cartridges according to the instructions.

13
Operation
The RO system is equipped with an LED display.When connecting the power supply,the
machine buzzes once and goes into rinse mode.
1. Rinse
1 )Auto Rinse: Every time the power supply is connected the RO system will flush
automatically. If the system is not used for more than 72 hours, the system will flush
automatically.
2) When flushing,booster pump,inlet water solenoid valve and drain water
are all in working mode,flushing last for 15 seconds,this will be indicated on the front
panel.
3) If you press the"Select"button once,the machine will flush for 30 seconds.
2. Purify
Turn on the water tap and start filtering,the inlet water solenoid valve and booster pump
start working,this is indicated on the front panel.
3. Leak
When leaking,the"Leak"indicator on the front panel will turn red and a 6
seconds alarm goes off.After solving the problem,reconnect the power
and restart the machine.
4. Fault
When continuously filtering or rinsing for1 hour,the fault light turn red meanwhile
buzzing for 6 seconds until solve the problems to connect the power again.
5. Cartridge Life
Filter life time is indicated on the front panel.Over time and usage the
bars will lower.When the last bar is arrived,a 10 second alarm goes off.After that,for 3
more times,every half an hour an alarm goes off.
6. Replace Cartridge
Press "Reset" button for 3 seconds until you hear a sound.You are in replacement mode
now.To switch between cartridges,push "Select" once. Select the cartridge to be changed
and press "Reset" button for 3 seconds until you hear a sound.

14
7. LED display content as following:
Installation & Maintenance
Cartridge Replacement Time
Cartridge
PP + Carbon Filter RO Membrane T33/Coconut Carbon
Cartridge
Replacement Time
6 Months
18 Months
12 Months
The cartridge replacement time is according to the local water quality and usage.
Above replacement time is only for reference.
Attention:
1.Depending on the inlet water quality, please change 1st stage cartridge
accordingly.
2.When drinking water TDS increases rapidly, the RO membrane needs
to be changed soon.
3.T33 is for improving the taste of drinking water, if the water taste becomes bad
or when the cartridge life is expired, please replace the T33 cartridge.
2.Replacing the cartridges
Please change cartridges regularly to maintain an effective and efficient
filtration.
Close inlet water, cut off the power supply and open the faucet until
water stops running.
Remove the lid and put aside. Remove and install the cartridges as described.

15
Installation & Maintenance
Attention:
1. Please replace the cartridge in turn and make sure in right position.
2. The cartridge life will be different according to the area, water quality,
season and working time. Please change them in time as actual usage
Maintain the RO system
♦When cleaning the RO system, do not use soap, detergent and strong
volatile solvent like thinner, gasoline and alcohol, it will cause the cracks
and color change.
♦Do not wash the system directly in water.

16
Troubleshooting
