Excalibur Water Systems Filtermax EWS POUPCS075 User manual

BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
SUPERIOR CHEMICAL REMOVAL FILTER
INSTALLATION AND USER GUIDE

1
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
TABLE OF CONTENTS
Introduction .......................................................................................................................................... 2
Installation ............................................................................................................................................ 2
Water Test Results ........................................................................................................................ 2
General Installation and Service Warnings................................................................................... 2
Site Requirements......................................................................................................................... 2
Installation Drawing ...................................................................................................................... 3
System Drawing ............................................................................................................................ 4
Plumbing Instructions ................................................................................................................... 4
Setup ............................................................................................................................................. 5
Installation Instructions ................................................................................................................ 6
Specifications ........................................................................................................................................ 6
Bypass Valve.......................................................................................................................................... 7
Start Up Instructions ............................................................................................................................. 8
Service Instructions............................................................................................................................... 9
Media Replacement...................................................................................................................... 9
Sediment Filter Cartridge Replacement (if exists) ......................................................................10
Bypass Valve Components .................................................................................................................. 11
Installation Fitting Assemblies ............................................................................................................ 12
Troubleshooting Procedures............................................................................................................... 14
Warranty ............................................................................................................................................. 15

2
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
INTRODUCTION
The Pre-Treatment Chemical Removal system removes the Chlorine and other volatile chemicals. This
manual must be read prior to installation and service of Pre-Treatment Chemical Removal Filter.
INSTALLATION
Water Test Results
General Installation and Service Warnings
•The filter is designed so that it can be installed easily with minor plumbing changes at point of
entry on previous plumbing.
•The piping must be clamped properly and the weight of the plumbing must not be on the filter.
•Do not use any kind of lubricant including silicone. A silicone based lubricant can be only used on
black O-Rings but not necessary.
•Do not use pipe dope or other sealant on plastic nuts.
•The nuts can be fastened and unfastened by hand or the plastic service wrench. Do not use pipe
wrench to tighten the caps and nuts.
•Do not block access to main shut off, water meter and other equipment.
Site Requirements
•Water Pressure: - 30-100 psi
•Water Temperature: - 40-110°F (4.4-43°C)
•The tank should be installed on firm level surface
Parameter
Water Sample Results
Hardness
Iron
pH
Chlorine
Manganese
Sulphur
Phosphates
Total Dissolved Solids

3
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
Installation Drawing

4
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
System Drawing
Plumbing Instructions
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM

5
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
Setup
1) Unpack the system and confirm the components with list. If missing anything report the missing part
to dealer immediately.
2) Fasten the bypass valve nuts on the head of the tank.
3) Turn the bypass valve handles to the bypass position by facing both handles outwards.
Filter Installation With Soft-Tec System

6
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
Installation Instructions
1) The water heater’s inlet must be at least 10ft away from filter.
2) The unit must be located in a room temperature above 33° F.
3) If vacuum occurrence is expected then the vacuum breaker must be installed at the inlet of the
filter.
4) The unit must not be exposed to direct sunlight. Ultraviolet rays can damage the system
5) The primer, solder or solder flux must not get on the O-rings while installation.
6) After soldering the lines must be cooled before installing the O-Rings, nuts and caps.
7) If the electrical system is grounded to the plumbing, then a copper strap must be connected
between inlet and outlet as shown in figure.
8) The plumbing must be done by following the local plumbing codes.
9) If heavy dirt and debris has been tested or expected in future, then 20-micron sediment filter should
be installed in pre-treatment.
10) If booster pump is required always install the pump upstream of the system.
SPECIFICATIONS
Model Number1
Mineral Tank Media
ft3(Liters)
Flow
GPM (LPS)
Space
Required
Shipping
Weight
Dia X Height Continuous Peak LxWxH LBS
EWS POUPCS075 8X44 0.75 (21.2) 5.0 (0.32) 8.0 (0.50) 9x16x51 35
EWS POUSBCS075
8x44
0.75 (21.2)
5.0 (0.32)
8.0 (0.50)
9x16x51
37
1: - EWS POUPCS075 is Premium Model and EWS POUSBCS075 is Superior Model

7
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
BYPASS VALVE
NORMAL OPERATION
The inlet and outlet handles of bypass valve should be pointing
towards the direction of flow. Inlet is labelled on tank head as
downflow inlet. Water flows downwards through the filter bed.
BYPASS OPERATION
The inlet and outlet handles point towards the center of bypass
valve. The system is isolated from the water pressure in the
plumbing system. Untreated water is supplied to the house in this
position.

8
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
START UP INSTRUCTIONS
1. Turn off the cold main water supply and inlet to hot water tank to the home and open inside cold
faucets to relieve any pressure within the plumbing system.
2. Place the system in the desired location. Make sure that the location is level and sturdy enough
to support the weight.
3. Place the bypass valve in the up-flow service position.
4. Connect the cold water supply to the inlet of the Soft-tec system. NOTE: The Soft-tec system
operates in the UP-flow mode which is opposite of a conventional softener, see piping schematic in
manual.
5. Place a bucket under the outlet port or run a line from the outlet port to a drain location.
6. Slowly turn the water back on to the house feeding the Soft-tec system up-flow inlet. Allow the
tank to fill with water. Close the supply valve when a steady stream of water comes out of the
outlet port.
7. Close the inside faucets.
8. Connect the outlet of the Soft-tec system to the cold-water supply to the house.
9. Slowly open the supply valve to the Soft-tec system.
10. Open the closest cold water faucet downstream from the Soft-tec system to relieve any air
from the plumbing system and run until water is clear.
11. Open inlet feed water supply to hot water tank.
12. Open other cold water faucets in the house to release any excess air and run until water is clear.
13. The filter system is now ready for standard water usage providing filtered water to every tap.

9
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
SERVICE INSTRUCTIONS
Media Replacement
Step 1: - Shut the inlet water supply off by turning valve clockwise.
Step 2: - Open the faucet downstream of the filter to release the pressure and then shut off the faucet.
Step 3: - Turn the bypass valve handles towards the center to bypass operation.
Step 4: - Loosen the bypass valve – tank connections and keep the bypass valve installed on plumbing.
Step 5: - Hold the tank and rotate the in-out head counterclockwise to remove the tank head from the
tank.
Step 6: - If supply water is needed in house, the main water supply valve can be turned on.
Step 7: - Pour the tank water into the drain and use some type of screen to prevent the media particles
going to the drain.
Step 8: - Rinse the tank with water.
Step 9: - Place the distributor in the bottom center rim and plug the distributor tube opening with rag or
tape.
Step 10: - Use a funnel or other device to pour the appropriate quantity of media into the tank.
Step 11: - Fasten the tank head after inserting the distributor tube into the in-out head.
Step 12: - Fasten the bypass valve connections.
Step 13: - Follow the start-up instructions given in this manual.

10
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
Optional Sediment Filter Cartridge Replacement (if exists)
Step 1: - Shut off the main water supply.
Step 2: - Press the red button on the housing to release the pressure.
Step 3: - Loosen the blue housing by turning it counter clockwise with service wrench.
Step 4: - Remove the old cartridge and insert the new cartridge filter onto the stand pipe.
Step 5: - Inspect and lubricate the O-ring with silicone lubricant.
Step 6: - Fasten the housing to the head and slowly open the supply water and open the downstream
faucet to remove the air.
O-Ring
Groove
Housing
Service Wrench
Sediment Filter
Assembly
Pressure Release
Button

11
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
BYPASS VALVE COMPONENTS
CLK V3006
WS1 Bypass Valve Assembly
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 Nut 1” Quick Connect
2
2
CLK V3150
WS1 Split Ring
2
3
CLK V3105
O-Ring 215
2
4
CLK V3145
WS1 Bypass 1” Rotor
2
5
CLK V3146
WS1 Bypass Cap
2
6
CLK V3147
WS1 Bypass Handle
2
7
CLK V3148
WS1 Bypass Rotor Seal
2
8
CLK V3152
O-ring 135
2
9
CLK V3155
O-ring 112
2
10
CLK V3156
O-ring 214
2
*Bypass Valve Vertical Adapter not shown in drawing
CLK V319101
WS1 Bypass Vertical Asy Adapter
Order No.
Description
Qty
CLK V3151
WS1 Nut 1” Quick Connect
2
CLK V3150
WS1 Split Ring
2
CLK V3105
O-Ring 215
2
CLK V3191
WS1 Bypass Vertical
2

12
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
INSTALLATION FITTING ASSEMBLIES
CLK V3007
WS1 Fitting 1” PVC Male NPT Elbow Assembly
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 NUT 1” QUICK CONNECT
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V3149
WS1 FITTING 1 PVC MALE NPT
2
CLK V300702LF
WS1 Fitting 1” Brass Sweat Assembly LF
Drawing No.
Order No.
Description
Qty
1
CLK V3151
WS1 NUT 1” QUICK CONNECT
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V3188LF
WS1 FITTING 1 BRASS SWEATASSEMBLY LF
2
Do not install in California.
CLK V300703LF
WS1 Fitting ¾” Brass Sweat Assembly LF
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 NUT 1” QUICK CONNECT
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V318801LF
WS1 FITTING ¾ BRASS SWEAT LF
2
Do not install in California.
CLK V300704
WS1 Fitting 1” Plastic Male NPT Assembly
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 NUT 1” QUICK CONNECT
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V3164
WS1 FITTING 1" PLASTIC MALE NPT
2
CLK V300701
WS1 Fitting ¾” & 1” PVC Solvent 90
o
Assembly
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 NUT 1” QUICK CONNECT
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V3189
WS1 FITTING ¾ & 1 PVC SOLVENT 90
2

13
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
CLK V300705
WS1 Fitting 1-1/4” Plastic Male NPT Assembly
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 NUT 1” QUICK CONNECT
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V3317
WS1 FITTING 1-¼" PLASTIC MALE NPT
2
CLK V300709LF
WS1 Fitting 1-1/4” & 1-1/2” Brass Sweat Assembly LF
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 NUT 1” QUICK CONNECT
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V3375LF
WS1 FITTING 1-1/4" & 1-1/2" BRASS
2
CLK V300712LF
WS1 Fitting 3/4” Brass SharkBite Assembly LF
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 NUT 1” QUICK CONNECT
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V3628LF
WS1 FTG 3/4 BRASS SHARKBITE LF
2
CLK V300713LF
WS1 Fitting 1” Brass SharkBite Assembly LF
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 NUT 1” QUICK CONNECT
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V3629LF
WS1 FTG 1” BRASS SHARKBITE LF
2
CLK V300715
WS1 FTG ¾ JG QC 90 Assembly
Drawing No.
Order No.
Description
Quantity
1
CLK V3151
WS1 NUT 1 QC
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3105
O-RING 215
2
4
CLK V3790
WS1 ELBOW 3/4 QC W/STEM
2
CLK V300717
WS1 FTG 1” JG QC Assembly
Drawing No.
Order No.
Description
Quantity
1
CLK V3105
O-RING 215
2
2
CLK V3150
WS1 SPLIT RING
2
3
CLK V3151
WS1 NUT 1 QC
2
4
CLK V4045
WS1 FTG 1 INCH QC
2

14
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
TROUBLESHOOTING PROCEDURES
Problem Possible Cause Solution
1. Unfiltered water is
being delivered
a. Bypass valve is open or faulty a. Fully close bypass valve or replace
b. Water quality fluctuation
b. Test water and adjust pre-treatment
if exists
c. Damaged seal c. Replace seal
d. Fouled media bed d. Replace media bed
2. Water leaking at
the top of the tank
around the head
a. Loose tank head
a. Loosen and take out the inlet and
outlet plumbing connections and then
turn the head by holding the tank.
(Just snug the head over the tank do
not overtighten)
3. Water pressure
decreased
a. Plugged sediment filter (if exists) a. Replace the cartridge filter
b. Pre-Treatment filters plugged
b. Regenerate or replace the faulty pre-
treatment filters
c. Fouled media bed c. Replace the media
4. Leaking bypass
valve
a. Faulty O-ring a. Replace or lubricate the O-rings
b. Loose bypass valve plastic nuts
b. Fasten the connection nuts with
hands. (Never use pipe wrench to
fasten or unfasten)

15
SUPERIOR CHEMICAL REMOVAL FILTER INSTALLATION AND USER GUIDE
BARRIE ●ONTARIO ●CANADA 705.733.8900 WWW.EXCALIBURWATER.COM
WARRANTY
Lifetime Tank Warranty
Superior Pre-Treatment Chemical Removal Filter 5 Year Warranty
Premium Pre-Treatment Chemical Removal Filter 7 Year Warranty
Thank you for your purchase of our PRE-TREATMENT CHEMICAL REMOVAL SYSTEM. For proof of purchase, please retain your
Invoice / Sales Order Copy.
Warranty ~ Offered
Excalibur Water Systems warranties its products to be free from defect in materials and workmanship to the original owner
from the date on the proof of purchase as described below.
Warranty ~ Working Procedures
If during the suitable warranty period, a part is defective, then Excalibur Water Systems will repair or replace that part at no
charge to the original owner, with the exception of charges for nominal shipping, service and/or installation.
Warranty ~ Coverage Outlined
Excalibur Water Systems guarantees, to the original owner, a period of 5 or 7 years, the IN–OUT HEAD to be free of defects in
materials and workmanship and to perform its proper functions. Other parts to be free of defects in materials and
workmanship and to perform their normal functions to the original owner, the MINERAL TANK will not rust, corrode, leak, burst
or in any other form fail to perform their proper functions for a LIFETIME period of 20 YEARS.
Warranty ~ Service
In the event you require service, your local Excalibur Water Systems Dealer will provide all necessary service and installation for
your Pre-Treatment Chemical Removal Filter. To obtain warranty service within 30 days of discovery of the defect, notification
must be given to your local Excalibur Water Systems Dealer.
General Provisions
The above warranties are effective provided the PRE-TREATMENT CHEMICAL REMOVAL FILTER is operated at water pressures
not exceeding 125psi and at water temperatures not exceeding 120°F; also provided that the PRE-TREATMENT CHEMICAL
REMOVAL FILTER is not subject to abuse, misuse, alteration, neglect, freezing, accident or negligence; and provided further that
the Pre-Treatment Chemical Removal Filter is not damaged as the result of any unusual force of nature such as, but not limited
to flood, hurricane, tornado or earthquake. Excalibur Water Systems is excused if failure to perform its warranty obligations is
the result of strikes, government regulation, materials shortages or other circumstances beyond its control.
THERE ARE NO WARRANTIES ON THE PRE-TREATMENT CHEMICAL REMOVAL FILTER BEYOND THOSE SPECIFICALLY DESCRIBED
ABOVE. ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR OF FITNESS FOR A
PARTICULAR PURPOSE, ARE DISCLAIMED TO THE EXTENT THEY MIGHT EXTEND BEYOND THE ABOVE PERIODS. THE SOLE
OBLIGATION OF EXCALIBUR WATER SYSTEMS UNDER THESE WARRANTIES IS TO REPLACE OR REPAIR THE COMPONENT OR
PART PROVES TO BE DFEFECTIVE WITHIN THE SPECIFIED TIME PERIOD AND EXCALIBUR WATER SYSTEMS IS NOT LIABLE FOR
CONSEQUENTIAL OR INDIDENTAL DAMAGES. NO DEALER, AGENT, REPRESENTATIVE OR OTHER PERSON IS AUTHORIZED TO
EXTEND OR EXPAND THE WARRANTIES EXPRESSED ABOVE.
Certain provinces or states do not allow limitations on how long an implied warranty lasts or exclusions or limitations of
incidental or consequential damage, therefore limitations and exclusions in this warranty may not apply to you. This warranty
extends you specific legal rights as you may have other rights which vary from province to province or state to state.
Excalibur Water Systems is a manufacturer of water treatment products.
Barrie, ON
Canada
