Expand-it Expand-it UT15518F User manual

OPERATOR’S MANUAL
Expand-it
™
Edger Attachment
UT15518F
SAVE THIS MANUAL FOR FUTURE REFERENCE
Your Expand-it
™
Edger Attachment has been engineered and manufactured to a high standard for dependability, ease of
operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
Thank you for buying an Expand-it
™
Product.
WARNING:
To reduce the risk of injury, the user must read and understand the operator’s manual before
using this product.

2
TABLE OF CONTENTS

Introduction
...................................................................................................................................................................
2

General Safety Rules
....................................................................................................................................................
3

Specific Safety Rules
....................................................................................................................................................
4

Symbols
........................................................................................................................................................................
5

Features
.......................................................................................................................................................................
6

Assembly
......................................................................................................................................................................
7

Operation
...................................................................................................................................................................
8-9

Maintenance
..........................................................................................................................................................
10-11

Exploded View/Parts List
.......................................................................................................................................
12-13

Warranty
......................................................................................................................................................................
15

Parts, Ordering, and Service
..........................................................................................................................
Back page
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
INTRODUCTION

3
WARNING:
Read and understand all instructions. Failure to fol-
low all instructions listed below, may result in electric
shock, fire, and/or serious personal injury.
SAVE THESE INSTRUCTIONS

Read these instructions and the instructions for the power
head thoroughly before using the attachment.

Know the tool. Read and understand the operator’s
manual and observe the warnings and instruction labels
affixed to the tool.

Do not allow children or untrained individuals to use this
unit.

Wear safety glasses or goggles that are marked to comply
with ANSI Z87.1 standards and hearing protection when
operating this unit.

Wear heavy long pants, boots, and gloves. Do not wear
loose fitting clothing, short pants, jewelry of any kind, or
go barefoot.

Secure long hair so it is above shoulder level to prevent
entanglement in any moving parts.

Keep all bystanders, children, and pets at least 50 ft.
away.

Stay alert, watch what you are doing, and use com mon
sense when operating a power tool. Do not use tool while
tired or under the in flu ence of drugs, al co hol, or medica-
tion. A mo ment of in at ten tion while op er at ing power tools
may result in serious personal injury.

Do not operate in poor lighting.

Do not overreach. Keep proper footing and balance at all
times. Proper footing and bal ance enables better control
of the tool in unexpected situations.

Keep all parts of your body away from any moving part.

When using the attachment on a power head with a
gasoline engine, do not touch areas around the muffler
or cylinder of the power head. These parts get hot from
operation. Failure to heed this warning could result in
possible serious personal injury.

Always stop the engine and remove the spark plug wire
or disconnect from power supply before making any
ad just ments or repairs.

Inspect unit before each use for loose fasteners and
damaged or missing parts. Correct before using the
attachment. Failure to do so can cause serious injury.

Use only identical manufacturer’s replacement parts and
accessories. Use of any other parts may create a hazard
or cause product damage.

Do not, under any circumstance, use any attachment or
accessory on this product which was not provided with
the product, or identified as appropriate for use with this
product in the operator’s manual.

Avoid dangerous environments. Do not use the at tach ment
in damp or wet locations.

Do not use in rain.

Use the right attachment. Do not use attachment for any
job except that for which it is intended.
SAFETY RULES WHEN ATTACHMENT IS
ATTACHED TO AN ELECTRIC POWER HEAD

When this attachment is being used with the recom-
mended electric power unit, refer to
Electrical Safety
Rules
in the electric power unit’s Operator’s Manual, in
Rules in the electric power unit’s Operator’s Manual, in Rules
addition to items contained in this manual.

Make sure the cord is located so that it will not be stepped
on, tripped over, or otherwise subjected to damage or
stress. Keep cord clear of the working area.

Do not abuse the power cord. Never carry the product
by the cord. Never yank the plug out of the receptacle.
Keep the cord away from heat, oil, and sharp edges.

Inspect extension cords for deterioration, cuts, or cracks
in the insulation. Repair or replace the cords if any defects
appear.

Keep the extension cord clear of the working area. Posi-
tion the cord so that it will not come in contact with the
edger attachment when in use. Failure to do so can result
in serious personal injury.

Check extension cords before each use. If damaged
replace them immediately. Touching the damaged area
could cause serious injury due to electrical shock.
GENERAL SAFETY RULES

4
SPECIFIC SAFETY RULES

Clear the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string which
can be thrown or become entangled in the edger
blade.

Be sure all guards are properly and securely attached.

Replace dull or worn blade; do not attempt to sharpen.

Use this edger for edging along sidewalks, driveways,
flower beds, and similar areas. Do not use for any other
purpose.

Be thoroughly familiar with the controls. Know how to
stop the unit and disengage the controls quickly.

Do not use the edger on or near graveled surfaces.

If the edger strikes any type of foreign object:
a) Stop the edger and remove the spark plug wire or
disconnect from the power supply.
b) Inspect for damage to the edger attachment.
c) Correct damage before using the edger attachment.
Failure to do so can cause serious injury.

Make yourself familiar with the area you are edging. Be
aware of uneven sidewalks and holes in the terrain as well
as other similar hazardous conditions
(example: wire or
wire rope which can break off and become a dangerous
projectile). Always push the edger attachment slowly over
rough ground.

Always stop the engine and remove the spark plug wire
or disconnect from power supply before attempting to
remove any obstruction caught or jammed in the blade,
installing attachment, or making any adjustments.

Do not attempt to remove cut material nor hold material
to be cut when the engine is running or when the cutting
blade is moving.

Keep hands and feet away from the cutting area.

Always keep your right hand on the rear handle and your
left hand on the front handle when the blade is rotating.

A coasting blade can cause injury while it continues
to spin after the engine is stopped or throttle trigger
released. Maintain proper control until the blade has
completely stopped rotating.

Save these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If
you loan someone this tool, loan them these instruc-
tions also to prevent misuse of the product and
possible injury.

5
SYMBOLS
SERVICE
Servicing requires extreme care and knowl edge and should
be performed only by a qualified service tech ni cian. For ser-
vice we suggest you return the product to your nearest
AU THO RIZED SERVICE CENTER
for repair. When servicing, use
only iden ti cal replacement parts.
WARNING:
SAVE THESE IN STRUC TIONS
WARNING:
To avoid serious personal injury, do not attempt to use
this product until you read thoroughly and understand
completely the operator’s manual. If you do not understand the
warnings and instructions in the operator’s manual, do not use
this product. Call Expand-it customer service for assistance.
The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in
severe eye damage. Before beginning power tool operation, always wear safety goggles or safety glasses with
side shields and, when needed, a full face shield. We recommend Wide Vision Safety Mask for use over eye-
glasses or standard safety glasses with side shields. Always use eye protection which is marked to comply with
ANSI Z87.1.
Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to operate the tool better and safer.
SYMBOL
NAME
EXPLANATION
Safety Alert Symbol
Precautions that involve your safety.
Read The Operator’s Manual
To reduce the risk of injury, user must read and understand operator’s manual
before using this product.
Eye and Hearing Protection
Wear eye and hearing protection when operating this equipment.
Keep Bystanders Away
Keep all bystanders at least 50 ft. away.
Ricochet
Thrown objects can ricochet and result in personal injury or property dam-
age.
Sharp Blade
Danger – Keep hands and feet away from rotating blade.
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL
SIGNAL
MEANING
DANGER:
Indicates an imminently hazardous situation, which, if not avoided, will result in death
or serious injury.
WARNING:
Indicates a potentially hazardous situation, which, if not avoided, could result in death
or serious injury.
CAUTION:
Indicates a potentially hazardous situation, which, if not avoided, may result in minor
or moderate injury.
CAUTION:
(Without Safety Alert Symbol) Indicates a situation that may result in property damage.

6
BLADE
ADJUSTING
KNOB
BLADE GUARD
EDGER ATTACHMENT
SHAFT
END CAP
GUIDE WHEEL
GEAR HEAD
DEBRIS FLAP
FEATURES
KNOW YOUR EDGER ATTACHMENT
See Figure 1.
The safe use of this product requires an understanding of the information on the tool and in this operator’s manual as well
as a knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features
and safety rules.
PRODUCT SPECIFICATIONS
Weight
............................................................................................................................................................................
6 lbs.
Blade Length
....................................................................................................................................................................
9 in.
Edging Depth
.......................................................................................................................
Adjustable from 2 in. to 3-1/2 in.
Wheel Diameter
................................................................................................................................................................
4 in.
Wheel Width
..............................................................................................................................................................
1-1/4 in.
Fig. 1
HANGER
CAP
WHEEL ARM
HOLDING
PIN

7
UNPACKING
This product requires assembly.

Carefully remove the items from the box. Make sure that
all items listed in the packing list are included.

Inspect the product carefully to make sure no breakage
or damage occurred during shipping.

Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the tool.

If any parts are damaged or missing, please call
1-800-242-4672 for assistance.
PACKING LIST
Expand-it
™
Edger Attachment
Holding Pin
Hanger Cap
Operator’s Manual
WARNING:
If any parts are damaged or missing, do not operate
this tool until the parts are replaced. Failure to heed this
warning could result in serious personal injury.
WARNING:
Do not attempt to modify this tool or create accesso-
ries not recommended for use with this tool. Any such
alteration or modification is misuse and could result in a
hazardous condition leading to possible serious personal
injury.
JOINING THE POWER HEAD TO THE EDGER
ATTACHMENT
See Figure 2.
WARNING:
Never attach or adjust any attachment while power head
is running. Failure to stop the engine and disconnect the
spark plug wire or disconnect from power supply may
cause serious personal injury.
The edger attachment connects to the power head by means
of a coupler device.

Loosen the knob on the coupler of the power head shaft
and remove the end cap from the attachment shaft.

Push in the button located on the edger attachment. Align
the button with the guide recess on the power head cou-
pler and slide the two shafts together. Rotate attachment
shaft until button locks into the positioning hole.
NOTE:
If the button does not release completely in the
positioning hole, the shafts are not locked into place.
Slightly rotate from side to side until the button is locked
into place.

Tighten the knob securely.
WARNING:
Be certain the knob is fully tightened before operating
equipment. Check it periodically for tightness during use
to avoid serious injury.
REMOVING THE ATTACHMENT FROM THE
POWER HEAD
To remove or change the attachment:

Loosen the knob.

Push in the button and twist the shafts to remove and
separate ends.
ASSEMBLY
EDGER
ATTACHMENT
SHAFT
POWER HEAD SHAFT
GUIDE RECESS
KNOB
POSITIONING
HOLE
Fig. 2
BUTTON
COUPLER

8
WARNING:
Do not allow familiarity with tools to make you careless.
Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear safety goggles or safety glasses with side
shields when operating power tools. Failure to do so
could result in objects being thrown into your eyes
resulting in possible serious injury.
WARNING:
Do not use any attachments or accessories not
recommended by the manufacturer of this tool. The use
of attachments or accessories not recommended can
result in serious personal injury.
APPLICATIONS
You may use this tool for the purpose listed below:

Edging around walkways, curbing, and other similar
areas
USING THE EDGER ATTACHMENT
See Figure 3.
When using the edger attachment, hold the unit with your
right hand on the rear handle and your left hand on the front
handle. Keep a firm grip with both hands while in operation.
The edger should be held at a comfortable position with the
rear handle about hip height.
NOTE:
When the attachment is being used on a power
head with a gasoline engine, always operate at full throttle.
Prolonged cutting at partial throttle will result in oil dripping
from the muffler.
OPERATION
Fig. 3
OPERATING TIPS

The edger will edge along sidewalks, driveways, flower
beds, curbs, and similar areas.

Use the arrow guide on the blade guard to align the blade
with the edging surface.

Cut at a steady pace. If the blade begins to bog down,
you are edging too fast; slow your pace. Do not force the
blade into ground.

Light contact of the blade against the sidewalk edge, curb,
etc., is acceptable and will not damage the edger.

Best appearance is obtained when grass is dry. Avoid
edging in wet soil or wet grass areas or the blade guard
might clog and result in an uneven edge. If the blade
guard becomes clogged, stop the engine, remove the
spark plug wire or disconnect from the power supply,
and remove debris from the blade guard.
ARROW GUIDE

9
ADJUSTING DEPTH OF CUT
See Figures 4 - 5.
The depth of cut is determined by the distance from the
bottom of the wheel to the tip of blade.
To adjust the blade depth:

Stop the engine and remove the spark plug wire or dis-
connect from the power source.

Loosen the adjusting knob and move the wheel arm up
to increase the depth or down to decrease the depth.

After adjustment is complete, tighten the adjusting knob
securely.

Replace the spark plug wire or connect to the power
supply and start the unit.
NOTE:
Adjust the blade depth from 1/2 in. to 1 in.
deep
initially. Make a shallow cut to test the cutting depth. If the
cutting depth needs adjusting, this should be done progres-
sively until the desired depth is reached.
OPERATION
Fig. 4
CURB GUIDE
BLADE
BLADE
DEPTH
ADJUSTING
KNOB
TO INCREASE
DEPTH
TO DECREASE
DEPTH
WHEEL ARM
Fig. 5

10
WARNING:
When servicing, use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
WARNING:
Always wear safety goggles or safety glasses with side
shields during tool operation. If operation is dusty, also
wear a dust mask.
WARNING:
Before inspecting, cleaning, or servicing the machine,
shut off engine, wait for all moving parts to stop, and
disconnect spark plug wire and move it away from spark
plug
or disconnect from power supply
. Failure to follow
these instructions can result in serious personal injury or
property damage.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or de-
stroy plastic which may result in serious personal injury.
You can often make adjustments and repairs described here.
For other repairs, have the tool serviced by an authorized
service dealer.
REPLACING THE BLADE
See Figures 6 - 8.
Replace blades that are damaged or worn.

Stop the engine and remove the spark plug wire or dis-
connect from the power supply.

Align the slot in the upper flange washer and gear case
with the slot in the flange; place the holding pin through
all three slots to secure in place.

Using a 1/2 in. socket wrench, turn the blade nut clock-
wise to loosen.

Remove the old blade from the edger shaft.

Clean debris from the edger shaft and flange washers.

Center the new blade on the upper flange washer, mak-
ing sure the blade sits flat.
MAINTENANCE
HOLDING PIN
INSERTED INTO
ALIGNED SLOTS
Fig. 6
UPPER FLANGE
WASHER
GEAR CASE
FLANGE
BLADE NUT
Fig.
7
Fig.
8
1/2
in.
SOCKET WRENCH
SLOTS
BLADE
LOWER FLANGE
WASHER
FLANGE

Install the lower flange washer with the cupped hole away
from the blade.

Install the blade nut onto the edger shaft.

Using a 1/2 inch socket wrench, turn the blade nut coun-
terclockwise onto the edger shaft and tighten securely.
NOTE:
Always make sure the blade is correctly installed
and
securely fastened before each use.

11
REPLACING THE DEBRIS FLAP
See Figure 9.
Replace the debris flap if it is worn.

Using a 10 mm wrench or socket, remove the hex nuts,
washers, and debris flap.

Install the new debris flap. This replacement part is
available from the place of purchase, or by calling
1-800-242-4672.

Replace washers and hex nuts.

Tighten securely.
ATTACHING THE STORAGE HANGER
See Figure 10.
There are two ways to hang the attachment for storage.

To use the hanger cap, push in the button and place the
hanger cap over end of the lower end attachment shaft.
Slightly rotate the cap from side to side until the button
locks into place.

The secondary hole in the attachment shaft can be used
for hang ing pur pos es as well.
STORING THE EDGER ATTACHMENT
Store the edger attachment in a well-ventilated place that is
inaccessible to children. Keep away from corrosive agents
such as garden chemicals and de-icing salts.
Fig. 10
BUTTON
HOLE
HANGER
CAP
SECONDARY
HOLE
MAINTENANCE
Fig.
9
HEX NUT
WASHER
DEBRIS FLAP
EDGER GUARD

12
EXPLODED VIEW/PARTS LIST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
30
19
20
26
28
27
29
16
16
21
23
24
25
22

13
EXPLODED VIEW/PARTS LIST
* STANDARD HARDWARE ITEM — MAY BE PURCHASED LOCALLY
Key Part
No. Number Description Qty.
1 678018001 Blade Nut (M8)
......................................................................................
1
2 638017001 Cupped Washer
....................................................................................
1
3 638006005 Blade
.....................................................................................................
1
4 678011001 Flange Washer
......................................................................................
1
5 660887001 * Screw (10-24 x 5/8 in. Hex Hd.)
...........................................................
3
6 678263001 * Lock Washer (5 mm)
.............................................................................
3
7 678262001 Flange
...................................................................................................
1
8 940657011 Warning Decal
......................................................................................
1
9 940726004 Expand-it Logo Label
...........................................................................
1
10 308734001 Blade Guard (Includes Key Nos. 8-9)
.................................................
1
11 561382001 Debris Flap
...........................................................................................
1
12 678260001 Washer (6 mm)
.....................................................................................
2
13 678017001 * Hex Nut (10-24)
.....................................................................................
2
14 308485001 Plate with Stud
.....................................................................................
1
15 308484001 Wheel Arm
............................................................................................
1
16 678258001 * Washer (10 mm)
....................................................................................
3
17 308730001 Adjusting Knob with Hex Nut
...............................................................
1
18 678259001 * Hex Nut with Nylon Cap (5/16-18)
........................................................
1
19 660737001 * Hex Screw (10-24 x 1/2 in.)
..................................................................
1
20 638245001 Curb Guide
...........................................................................................
1
21 518377001 Guide Wheel
.........................................................................................
1
22 308483001 * Push Nut (10 mm)
.................................................................................
1
23 660641001 * Hex Screw (10-24 x 5/8 in.)
..................................................................
1
24 660642001 * Cap Screw (1/4-20 x 1.25 in.)
...............................................................
1
25 308210001 Gear Head Assembly
...........................................................................
1
26 308735001 Drive Shaft Assembly (Includes Key Nos. 27-28)
................................
1
27 940657007 Warning Decal
......................................................................................
1
28 940654019 Warning Label, UL
................................................................................
1
29 518019001 Hanger Cap
..........................................................................................
1
30 678020001 Holding Pin
...........................................................................................
1
983000931 Operator’s Manual

14
NOTES

15
WARRANTY
LIMITED WARRANTY STATEMENT
Techtronic Industries North America, Inc., warrants to the
original retail purchaser that this
EXPAND-IT
brand product
is free from defect in material and workmanship and agrees
to repair or replace, at Techtronic Industries North America,
Inc.’s discretion, any defective product free of charge within
these time periods from the date of purchase.

� One year for the following units: all Yard Broom, Trimlite,
and Bandit models;

� Two years if the product is used for personal, family or
household use;

90 days if used for any other purpose, such as commercial
or rental.
This warranty extends to the original retail purchaser only and
commences on the date of the original retail purchase.
Any part of the product found in the reasonable judgment
of Techtronic Industries North America, Inc., to be defective
in material or workmanship will be repaired or replaced
without charge for parts and labor by an Expand-it authorized
service center.
The product, including any defective part, must be returned
to an Expand-it authorized service center within the warranty
period. The expense of delivering the product to the service
center for warranty work and the expense of returning it
back to the owner after repair or replacement will be paid
by the owner. Techtronic Industries North America, Inc.’s
responsibility in respect to claims is limited to making the
required repairs or replacements and no claim of breach of
warranty shall be cause for cancellation or rescission of the
contract of sale of any EXPAND-IT brand product. Proof of
purchase will be required by the dealer to substantiate any
warranty claim. All warranty work must be performed by an
Expand-it authorized service center.
This warranty is limited to ninety (90) days from the date of
original retail purchase for any EXPAND-IT brand product
that is used for rental or commercial purposes, or any other
income-producing purpose.
This warranty does not cover any product that has been
subject to misuse, neglect, negligence, or accident, or that
has been operated in any way contrary to the operating
instructions as specified in this
operator’s manual. This
warranty does not apply to any damage to the product that
is the result of improper maintenance or to any product that
has been altered or modified. The warranty does not extend
to repairs made necessary by normal wear or by the use of
parts or accessories which are either incompatible with the
EXPAND-IT
brand product
or adversely affect its operation,
performance, or durability.
In addition, this warranty does not cover:
A. Tune-ups – Spark Plugs, Carburetor, Carburetor
Adjustments, Ignition, Filters
B. Wear items – Bump Knobs, Outer Spools, Cutting Lines,
Inner Reels, Starter Pulleys, Starter Ropes, Drive Belts,
Tines, Felt Washers, Hitch Pins, Mulching Blades, Blower
Fans, Blower and Vacuum Tubes, Vacuum Bags and
Straps, Guide Bars, Saw Chains
Techtronic Industries North America, Inc., reserves the right
to change or improve the design of any EXPAND-IT brand
product without assuming any obligation to modify any
product previously manufactured.
ALL IMPLIED WARRANTIES ARE LIMITED IN DURATION
TO THE STATED WARRANTY PERIOD. ACCORDINGLY,
ANY SUCH IMPLIED WARRANTIES INCLUDING
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR OTHERWISE, ARE DISCLAIMED IN THEIR
ENTIRETY AFTER THE EXPIRATION OF THE APPROPRIATE
TWO-YEAR, ONE-YEAR, OR NINETY-DAY WARRANTY
PERIOD.
TECHTRONIC INDUSTRIES NORTH AMERICA,
INC.
’S OBLIGATION UNDER THIS WARRANTY IS
STRICTLY AND EXCLUSIVELY LIMITED TO THE REPAIR OR
REPLACEMENT OF DEFECTIVE PARTS AND
TECHTRONIC
INDUSTRIES NORTH AMERICA, INC.,
DOES NOT ASSUME
OR AUTHORIZE ANYONE TO ASSUME FOR THEM ANY
OTHER OBLIGATION. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY
TO YOU.
TECHTRONIC INDUSTRIES NORTH AMERICA,
INC.,
ASSUMES NO RESPONSIBILITY FOR INCIDENTAL,
CONSEQUENTIAL, OR OTHER DAMAGES INCLUDING, BUT
NOT LIMITED TO, EXPENSE OF RETURNING THE PRODUCT
TO AN
EXPAND-IT
AUTHORIZED SERVICE CENTER AND
EXPENSE OF DELIVERING IT BACK TO THE OWNER,
MECHANIC’S TRAVEL TIME, TELEPHONE OR TELEGRAM
CHARGES, RENTAL OF A LIKE PRODUCT DURING THE TIME
WARRANTY SERVICE IS BEING PERFORMED, TRAVEL,
LOSS OR DAMAGE TO PERSONAL PROPERTY, LOSS OF
REVENUE, LOSS OF USE OF THE PRODUCT, LOSS OF
TIME, OR INCONVENIENCE. SOME STATES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO YOU.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
This warranty applies to all EXPAND-IT brand products
manufactured by or for Techtronic Industries North America,
Inc., and sold in the United States and Canada.
To locate your nearest Expand-it authorized service center,
dial 1-800-242-4672.

16
TECHTRONIC INDUSTRIES NORTH AMERICA, INC.
1428 Pearman Dairy Road
Anderson, SC 29625
Phone [phone]
983000-931
8-07-06 (REV:01)
SERVICE
For parts or service, contact your nearest Expand-it
™
authorized service center. Be sure to provide all
relevant information when you call or visit. For the location of the authorized service center nearest
you, please call 1-800-242-4672 or visit us online at www.homelite.com.
REPAIR PARTS
The model number of this tool is found on a plate or label attached to the housing. Please record
the serial number in the space provided below.
MODEL NUMBER
SERIAL NUMBER
UT15518F
OPERATOR’S MANUAL
Expand-it
™
Edger Attachment
UT15518F
