Exposure 3010S Instruction manual

1Installation
2Amplifier Connection
The Exposure 3010S CD Player is fitted with both analogue and digital audio outputs.
Please use your own preferred cables.
The Exposure 3010S CD Player : Back View
Analogue Output
• Connect RCA Phono sockets to appropriate line input
on the amplifier.
• Make sure right and left channels are properly connected.
(Right channel is marked in red)
Digital Output
Connect the digital outputs either to:
• An external digital to analogue converter.
or
• A digital device such as a CDR machine or
minidisc recorder.
(For hints on improving sound quality, please refer to “Extended Set-Up”
overleaf).
high fidelity engineering
since 1974
Thank you for purchasing the Exposure 3010S CD Player.
CD Player
Quick Start Manual
b) Connect to the mains outlet on the wall.
DO NOT switch on until all input and output
connections are made.
a) Connect the mains cable to
the IEC mains input socket.
3Operation
Ensure that the volume control knob on your amplier is set to minimum.
HS-101 Exposure System
remote control
Before you start
Please check the contents in the box:
Mains cable
Exposure 3010S
CD Player
2 x AAA batteries
Ensure your unit is switched off.
Please note that your Exposure 3010S CD Player
may take up to 48 hours to “run-in” before reaching
its optimal performance. Each subsequent “run-in”
will then take about 20 minutes.
The Exposure 3010S CD Player : Front View
The display will illuminate.
The LED power indicator will light up.
Press power switch.
Open Opens and closes the CD loading drawer.
Stop Stops disc playback.
Play/Pause Starts disc playback.
Pressing Play/Pause while a disc is playing will pause playback.
Pressing Play/Pause again will resume playback.
|<< Selects the previous track in sequence.
>>| Selects the next track in sequence.
Display Press once to turn display off. The display will stay off until
another button is pressed, and it will then go off again after
a short delay. Press Display again to turn it back on.
4Function Controls
5Remote Control
Press the black CD button on the remote control before using the grey
function buttons.
1~9,10+ Direct access track functions
Display Press once to turn display off. The
display will stay off until another
button is pressed, and it will then
go off again after a short delay.
Press again to turn it back on.
PROG Programmable track selection.
RANDOM Random track selection.
TIME Track time countdown.
RPT Track/disc repeat.
PREV Selects the previous track in
sequence.
NEXT Selects the next track in
sequence.
<SEARCH> Press and hold < for Backward
Scan. Press and hold > for Forward
Scan.
Open Opens and closes the CD loading
drawer.
Stop Stops disc playback.
Play Starts disc playback.
Pause Pauses playback. To resume play,
press again or press the “Play”
button.

Safety
Incorrect installation or inappropriate use of the Exposure 3010S Integrated
Amplier may result in injury due to electrical shock.
• Ensure that the voltage rating on the rear panel of this unit matches that
of your local mains supply.*
• Ensure that the mains cable and plug supplied with this unit are also
correct (Contact your dealer immediately if this is not the case).
• This unit is protected by a mains fuse, which is accessible as part of the
IEC socket on the rear panel.
• Fuse replacement specications:
220/240V units T1A fuse
110/120V units T2A fuse
• The Exposure 3010S CD Player MUST be earthed.
• Protect the unit against all forms of liquid. Never expose unit to dripping
or splashing, or place objects lled with water, such as vases, on the unit.
• Unplug unit from mains when not in use for prolonged periods.
• Do not open this unit - there are NO user serviceable parts inside
(except to remove the J2 jumper to disable the digital outputs).
• Set the amplier volume control to minimum before turning this unit
on or off.
• Ensure that this unit is switched off when connecting or disconnecting
interconnect cables.
* Contact your Exposure dealer or distributor for advice on moving your
equipment to another country or territory.
Caution
For a long and trouble-free life of your Exposure 3010S CD Player, please
ensure the following:
• Do not apply labels or stickers to CDs.
• Do not write on CDs.
• Do not use abrasive or solvent based cleaning uids on the surface of
CDs.
• Do not remove the cover of the unit or dismantle the case (except to
remove or re-t digital output jumper J2).
• Protect unit against all forms of liquid. Never expose unit to dripping or
splashing, or place objects lled with water, such as vases, on the unit.
• Do not attempt to bypass the mains fuse or replace the fuse with one
of a different specification.
• Do not use abrasive or solvent based cleaning uids on the unit’s case.
Failure to observe these precautionary measures may void your warranty.
Technical Specifications
Output Level: 2V RMS ref 1KHz 0dB
Frequency Response: 20Hz - 20KHz ± 0.25dB
Total Harmonic Distor tion: <0.003%, ref 1KHz, 0dB
Signal to Noise Ratio: >108dB, A weighted
Dynamic Range: >104dB
Digital Outputs: SP/DIF, Coaxial and Optical
Mains Supply: 110/120V or 220/240V,
50/60Hz (factory set)
Power Consumption: <25 VA
Dimensions (H x W x D): 90 mm x 440 mm x 300 mm
Nett Weight (Unpacked): 5 kg
Gross Weight (Packed): 7 kg
Exposure Warranty Policy
1. The Exposure warranty entitles you to FREE repair of this unit for the rst
three (3) years from the date of purchase.
2. This warranty is valid only if the unit is purchased from an authorised
Exposure dealer, registered with the authorised agent in your country
of residence and issued with a recognised warranty card.
3. The agent accepts no responsibility for defects arising from accident, misuse,
abuse, wear and tear, neglect or through unauthorised adjustment and or
repair or replacement of any components, nor will they accept responsibility
for damage or loss occurring during transit to or from the person making a
claim under the warranty.
4. The Exposure warranty covers:
• Parts and labour costs for three (3) years from the date of purchase.
Please retain your original receipt as proof of purchase and purchase date.
The guarantee is extended only to the original purchaser and is not
transferable.
When making claims under this warranty:
1. The unit should be suitably packed and returned to the dealer from whom
it was purchased, or directly to the local distributor, together with proof of
purchase or a copy of the dated sales receipt.
2. If necessary the unit should be sent carriage pre-paid by a reputable carrier,
NOT by post.
3. No responsibility is accepted for the unit whilst on transit to the dealer or
agent, and customers are advised to insure the unit against loss or damage
whilst in transit.
4. The warranty card MUST be produced when making claims against this
guarantee.
5. Any tampering or alteration made to the warranty card or to the serial
number on the unit will invalidate the warranty.
6. The dealer or the agent shall notify the customer when the repairs have
been completed. The customer must claim the goods within fourteen (14)
days from the date of notice, failing which, the Company reserves the right
to impose storage charges.
7. The Company reserves the right to dispose of the unit after 90 days from
the date of notice in a manner that it sees fit and without compensation to
the customer.
Exposure 3010S CD Player: Extended Set-Up
Improving Sound Quality through Digital Output
Connect the digital outputs either to:
a) An external digital to analogue converter, or b) A digital device such as a CDR machine or Minidisc recorder.
Both BNC coaxial and ‘Toslink’ sockets are provided for these applications
If neither of these outputs are used, sound quality may be improved by disabling these outputs. This is best carried out by your dealer. To disable the
outputs yourself:
1 Switch off the CD player. 2Remove the mains cable from the wall
and the IEC socket.
3Remove the four cover screws.
6Replace the cover and screws. 5Pull out the internal jumper plug J2 (found on the extreme left hand side about half way towards
the back) on the main circuit board inside the unit.
4 Slide the cover back about 2 cm until
it is free to move upwards.
Jumper J2 attached Jumper J2 removed. Please
keep the J2 jumper in a safe
place in case you need to
re-t it later.
