EZ-Guide 500 Reference guide

1
Cable assembly, power
to hitch connection (P/N 76941)
Lightbar power cable
(P/N 62817)
COnneCtinG tHe SYSteM
CAN-TBC active terminator
cable (with power) (P/N 75522)
Field-IQ master switch box
(P/N 75050-01)
Remote foot switch
(optional) (P/N 60490)
IBRC to DPT adaptor cable
(optional) (P/N 77413)
12-section switch box
(optional) (P/N 75060-01)
Cable assembly, CAN cab to
hitch connection (P/N 77368)
Field-IQ Master Switch Box
Item Positions
<Incement/decrement switch
=Rate switch Rate 1, Rate 2, Manual Rate
>LED indicator
?Automatic/Manual section
control switch
You can switch from Automatic to
Manual mode while traveling.
@Master switch Off, On, Jump Start
Use the jump start function if you
lose a GPS signal or you want
to start applying before your
implement is up to speed.
Field-IQ 12-section Switch Box
Item
<LED indicator
=Section switches
>Space to write which row the switch controls.
If the Master
Switch section
switch is set to...
And the 12-section
switch box
position is ...
Then the section
is...
Automatic Up / On controlled by the display.
Down / Off off.
Manual Up / On turned on
Down / Off off
Note: For more information on system calibration and settings, see the Field-IQ section in the EZ-Guide Lightbar Guidance System
Version 5.10 Release Notes.
< >
< = > ? @
=
EZ-Guide® 500 Lightbar Guidance System
with the Field-IQ™ Crop Input Control System Quick Reference Card
EZ-Guide 500 lightbar
Power cable with switch
(P/N 75743)

© 2010. Trimble Navigation Limited. All rights reserved. Trimble, the Globe and Triangle logo, and EZ-Guide are trademarks of
Trimble Navigation Limited, registered in the United States and in other countries. Field-IQ is a trademark of Trimble Navigation
Limited. Version 3.00, Rev A (April 2010).
P/N 80810-00-ENG
*80810-00-ENG*
2
EZ-Guide® 500 Lightbar Guidance System
with the Field-IQ™ Crop Input Control System Quick Reference Card
Field-IQ quick
settings icon
Actual rate currently
being applied
Target rate to be
applied
Rate switch position
The boom section is
currently spraying
The boom section is
on, but not spraying
Automatic/manual
boom switching
indicator
The boom section is disabled
(the switch is off)
Color = Automatic
Black and white =
Manual
OperatiOn
Definition of terms
Calibration
constant
Represents the applicator output per revolution of the drive.
Use this number to fine-tune the Field-IQ system to match the
actual output of the spreader.
Jump start Use this function to continue the application if you lose a GPS
signal or if want to start applying before the implement is up
to speed.
Prime system Fills the system with product in preparation for calibration.
Enabling the Field-IQ system
The lightbar contains an on-screen wizard that guides you
through each step to set up, calibrate and test the Field-IQ
system. The lightbar also has built-in, context-sensitive
help that allows you to quickly find information you need.
To see the definition of a term, or access help with a
screen, tap .
1. From the main guidance screen, tap and then press .
The Configuration screen appears.
2. Make sure that the user mode is set to Advanced.
3. Select Application Control / Controller Settings / Field-IQ:
4. Select an application controller mode. The options are:
– Row Crop Planting
– Granular
– Liquid
– Spreading
5. Complete the setup wizard to set up the Field-IQ application
type, set up the control modules, perform the Field-IQ
hydraulics test, and calibrate the Rawson control modules and
rate controller.
Field-IQ quick settings icon
When you are in the main guidance screen, the icon
contains:
• Refill bin
• Section switching setup
• Application setup
• Flush control
• Enable or disable boundaries
