Farberware FMO13AHTBKI User manual

MICROWAVE OVEN
INSTRUCTION MANUAL
Read these instructions carefully before using your
microwave oven, and keep it carefully. If you follow
the instructions, your oven will provide you with
many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
Model: FMO13AHTBKI
(rev. 08/07/19) MD

Farberware is a registered trademark of Farberware Licensing Company, LLC
Manufactured and sold pursuant to a license from Farberware Licensing Company, LLC
© Farberware Licensing Company, LLC. All rights reserved.
2019

Tables of Contents
PRECAUTIONS....................………………………………………….……….. 4
SPECIFICATIONS……………………………………………………..…........… 4
SAFETY………………………………………………………………………..…. 5
GROUNDING………………………………………………………….……..... 6
UTENSILS………………………................................................................... 8
SETTING UP YOUR OVEN……………...................................................... 10
CONTROL PANEL………………………………......................................... 12
OPERATION……………………………….................................................. 13
MAINTENANCE……………………………………………………………….. 19
WARRANTY INFORMATION.……………………………………………….. 20
3

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a)
result in harmful exposure to microwave energy.
It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allows soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the:
(1) DOOR (bent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACES
(d) Theovenshouldnotbeadjustedorrepairedbyanyoneexceptproperlyqualied
service personnel
SPECIFICATIONS
Model:
Rated Voltage: 120V~60Hz
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight: B
4
FMO13AHTBKI
1500W
1100W
1.3 cubic feet
12.4 inches
Approx 34.2 LBbs
20.4(W)x17.3(D)x12.4(H) inches
WARNING:
This product can expose you to chemicals
including Phthalates or other chemicals which are know to
the State of California to cause cancer birth defects and
other reproductive harm.
For more information, visit www.P65Warnings.ca.gov
n
,

2. Readandfollowthespecic:“PRECAUTIONSTOAVOIDPOSSIBLEEXPOSURETO
EXCESSIVEMICROWAVEENERGY”foundonpage4.
3. This appliance must be grounded. Connect only to properly grounded outlet. See
“GROUNDINGINSTRUCTIONS”foundonpage .6
4. Install or locate this appliance only in accordance with the provided installation
instructions.
5. Some products such as whole eggs and sealed containers - for example, closed glass
jars - are able to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in the manual. Do not
usecorrosivechemicalsorvaporsinthisappliance.Thistypeofovenisspecically
designed to heat, cook or dry food. It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when used by children.
8. Do not operate this appliance if it has a damaged cord or plug, if it is not working
properly, or if it has been damaged or dropped.
9. Thisapplianceshouldbeservicedonlybyqualiedservicepersonnel.Contact
nearest authorized service facility for examination, repair, or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this product near water - for
example, near a kitchen sink, in a wet basement, near a swimming pool, or similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes together on closing the door,
use only mild, nonabrasive soaps, or detergent applied with a sponge or soft cloth.
16. Toreducetheriskofreintheovencavity:
1). Do not overcook food. Carefully attend appliance when paper, plastic, or
other combustible materials are placed inside the oven to facilitate cooking.
2). Remove wire twist-ties from paper or plastic bag before placing bag in oven.
3). If material inside of the oven ignite, keep oven door closed, turn oven off, and
disconnect the power cord, or shut off power at the fuse or circuit breaker panel.
4). Do not use the cavity for storage purposes. Do not leave paper products,
cooking utensils, or food in the cavity when not in use.
5
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including
the following:
WARNING – Toreducetheriskofburns,electricshock,re,injurytopersonsorexposure
to excessive microwave energy:
1. Read all instructions before using the appliance.

To reduce the risk of injury to persons:
1) Do not overheat the liquid.
2) Stir the liquid both before and halfway through heating it.
3) Do not use straight-sided containers with narrow necks.
4) After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
5) Use extreme care when inserting a spoon or other utensil into the container.
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces
the risk of electric shock by providing an escape wire for the electric current. This appliance is
equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged
into an outlet that is properly installed and grounded.
WARNING – Improper use of the grounding can result in a risk of electric shock.
Consultaqualiedelectricianorservicemanifthegroundinginstructionsarenotcompletely
understood, or if doubt exists as to whether the appliance is properly grounded. If it is necessary
to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounded plug,
and 3-slot receptacle that will accept the plug on the appliance. The marked rating of the
extension cord shall be equal to or greater than the electrical rating of the appliance.
DANGER – Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death. Do not
disassemble this appliance.
WARNING – Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an outlet until
appliance is properly installed and grounded.
1. A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised
in their use.
6
17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling
point without appearing to be boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present.
THISCOULDRESULTINVERYHOTLIQUIDSUDDENLYBOILINGOVERWHENTHE
CONTAINERISDISTURBEDORAUTENSILISINSERTEDINTOTHELIQUID.

3. If a long cord or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at
least as great as the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord.
3) The longer cord should be arranged so that it will not drape over the counter
top or tabletop where it can be pulled on by children or tripped over unintentionally.
RADIO INTERFERENCE
1. Operation of the microwave oven may cause interference to your radio, TV or
similar equipment.
2. When there is interference, it may be reduced or eliminated by taking the
following measures:
1) Clean door and sealing surface of the oven
2) Reorient the receiving antenna of radio or television.
3) Relocate the microwave oven with respect to the receiver.
4) Move the microwave oven away from the receiver.
5) Plug the microwave oven into a different outlet so that microwave oven and
receiver are on different branch circuits.
SAFETY
1. The oven must be on a leveled surface.
2. The turntable and turntable roller rest must be in the oven during cooking. Place the
cookware gently on the turntable and handle it carefully to avoid possible breakage.
3. Incorrect use of browning dish may cause the turntable to break.
4.UseonlythespeciedbagsizewhenusingDirectAccessPopcorn.
5. The oven has several built-in safety switches to ensure that the power remains off when
the door is open. Do not tamper with these switches.
6. Do not operate the microwave oven empty. Operating the oven with no food or food that
isextremelylowinmoisturecancausere,charringorsparking.
7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable
may cause the turntable to break.
8. Do not heat baby bottles or baby food in the microwave oven. Uneven heating
may occur and could cause physical injury.
7

9. Do not heat narrow-necked containers, such as syrup bottles.
10. Do not attempt to deep-fry in your microwave oven.
11. Do not attempt home canning in this microwave oven, as it is impossible to be sure
all contents of the jar have reached boiling temperature.
12. Do not use this microwave oven for commercial purpose. This microwave oven is made
for household use only.
13. To prevent delayed eruptive boiling of hot liquids and beverages or scalding yourself, stir
liquid before placing the container in the oven and again halfway through cooking time. Let
stand in the oven for a short time and stir again before removing the container.
14. Use carefully when cooking food in the microwave oven to avoid burning due to
excessive cooking.
15. When the appliance is operated in the combination mode, children should only use the
oven under adult supervision due to the temperatures generated.
16. Failure to maintain the oven in a clean condition could lead to deterioration that could
adversely affect the life of the appliance and possibly result in a hazardous situation.
UTENSILS
!CAUTION – Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches
should be pierced before cooking.
Seetheinstructionson“Materialsyoucanuseinmicrowaveovenortobeavoidedin
microwaveoven.”
There may be certain non-metallic utensils that are not safe to use for microwaving. If in
doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
8

MATERIALS YOU CAN USE IN MICROWAVE OVEN
Utensils Remarks
Browningdish Follow manufacturer* instructions. The bottom of browning dish must
be at least 3/16 inch (5mm) above the turntable. Incorrect usage may
cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use
cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass
jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer* instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Paper plates and cups Use for short term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer* instructions. Should
belabeled“MicrowaveSafe”.Someplasticcontainerssoften,asthe
foodinsidegetshot.“Boilingbags”andtightlyclosedplasticbags
should be slit, pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
9

MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal
trim may cause arcing.
Metal twist ties Maycausearcingandcouldcauseareintheoven.
Paper bags Maycauseareintheoven.
Plastic foam Plastic foam may melt or contaminate the liquid inside
when exposed to high temperature.
Wood Wood will dry out when used in the microwave oven
and may split or crack.
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity. Your oven comes with the
following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
F
G
CB
ED
A) Control panel
B)Turntableshaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
10
A

Turntable Installation
Counter-top Installation
Hub (underside)
Glass tray
Tu
rntable ring assembly
Turntable shaft
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Bothglasstrayandturntableringassembly
must always be used during cooking.
c. All food and containers of food are always
placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Cabinet:Removeanyprotectivelmfound
on the microwave oven cabinet surface. Do
not remove the light brown Mica cover that
is attached to the oven cavity to protect the
magnetron.
1. Select a level surface that provide enough
open space for the intake and/or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is
required between the oven and any adjacent
walls. One side must be open.
(1) Leave a minimum clearance of 12 inches
(30cm) above the oven.
2) Do not remove the legs from the
bottom of the oven.
(3) Blockingtheintakeand/oroutletopenings
can damage the oven.
(4) Place the oven as far away from radios
and TV as possible. Operation of
microwave oven may cause interference
to your radio or TV reception.
2. Plug your oven into a standard household
outlet.Besurethevoltageandthefrequency
is the same as the voltage and the frequency
on the rating label.
WARNING – Do not install oven over
a range cook-top or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and the
warranty would be void.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
11

(9) Cook Time
(4) Time Defrost
(5) Weight Defrost
(8) Power (10 power levels available)
(12) Clock
(13) Kitchen Timer
(1) Sensor Cook Menu (Sensor Reheat,
Frozen Pizza,Fish,Meat,Fresh Vegetable,
Frozen Vegetable,
 Potato,Frozen Entree)
(6) Number Pad (0-9)
(7) Express Cook (Number Pad 1-3)
(11) START/ 30SEC(Begincooking.
time or add time to cooking)
(10) Stop/CANCEL(Beforecookingstarts,

press to clear all previous settings;
during cooking, press once to stop
oven; press twice to stop oven and
clear all settings.
(3) Memory function
12
CONTROL PANEL
+
(2) Popcorn
(2)
(1)
(3)
(4)
(5)
(6)
(7)
(9)
(10) (11)
(12) (13)
(8)

OPERATION
1. POWER LEVEL
10 power levels are available.
Level 10987654321
Power 100% 90% 80% 70% 60% 50% 40% 20% 10%
Display PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1
2. CLOCK SETTING
(1) Press“Clock“,“00:00”willdisplay.
(2) Press the number keys and enter the current time. For example, time is 10:12 now, please
press“1,0,1,2”inturn.
(3) Press“Clock“tonishclocksetting.“:”willashandtheclockwillbelighted.
(4) If the numbers input are not within the range of 1:00--12:59, the setting will be invalid until
valid numbers are input.
Note:
1. Intheprocessofclocksetting,ifthe“STOP/CANCEL“buttonispressedorifthereisnooperation
within 1 minute, the oven will go back to the former setting automatically.
2. If the clock need to be reset, please repeat step 1 to step 3.
3. MICROWAVE COOK
(1) Press“ COOK TIME ”once,thescreenwilldisplay“00:00”.
(2) Press number keys to input the cooking time; the maximum cooking time is 99 minutes and
99 seconds.
(3) Press once,screenwilldisplay“PL10”.Thedefaultpoweris100%power.
Now you can press number keys to adjust the power level.
(4) Press“START/ 30SEC.“tostartcooking.
Example: To cook the food with 50% microwave power for 15 minutes.
a. Press  once.”00:00”displays.
b. Press“1”,”5”,”0”,”0”inorder.
c. Press“ ” once,thenpress“5”toselect50%microwavepower.
d. Press to start cooking.
“  ”
13
+
“START/ 30SEC.“
+
30%
Note:
1. Intheprocessofsetting,ifthe“STOP/CANCEL“buttonispressedorifthereisnooperationwithin1
minute, the oven will go back to the former setting automatically.
2. Youcanskipthestepof“c”andcookat100%microwavepower.
“POWER LEVEL“
COOK TIME
POWER LEVEL

14
5. EXPRESS COOKING
4. KITCHEN TIMER
(1) Press“Timer“once,thescreenwilldisplay 00:00.
(2) Press the number keys and enter the timer time. (The maximum cooking time is 99 minutes
and 99 seconds.)
(3) Press“ “toconrmsetting.
(4) When
 thetimertimearrives,thebuzzerwillring5times,screendisplaythe current time.
Note:
1. The kitchen time is different from 12-hour system, Kitchen Timer is a timer.
2. Kitchen Timer and cooking (including microwave, defrosting, Auto menu) are independent,
all the cooking functions cannot be set during running Kitchen Timer, Kitchen Timer cannot be set
during running other cooking functions.
START/ 30sec.
+
Note:

““
button.
(1) In waiting state, instant cooking at 100% power level with 30 seconds cooking time can
bestartedbypressing“START/+30Sec.“Eachpressonthesamebuttonwillincrease cooking
time by 30 seconds. The maximum cooking time is 99 minutes and 99 seconds.
(2) If not ready cooking, press number pads 1-3 to quickly cook from 1-3 minutes at 100% power.
Press """"““to increase the cooking time; the maximum cooking time is 99 minutes
and 99 seconds.
START/ 30sec.
+
START/ 30sec.
+
(3)
to start cooking.
“START/ + 30sec. “
6. CANCEL QUICKLY
(1) Duringsettingorrunningprocedure,onlypressing“STOP/CANCEL“canstopcurrentstatesand
turn back to the waiting states.
7. WEIGHT DEFROST FUNCTION
(1) Press“Weight Defrost“ once, screen will display “0.0”;
(2) Press numerical buttons to input weight to be defrosted. Input the weight ranged
between 0.3~6.3lbs.ZZZ If the weight input is not within 0.3~6.3, the input will be invalid.
(3) Press  tostartdefrostingandthecookingtimeremainedwillbedisplayed.

“START/ 30SEC.“
+
Press "" “COOK TIME then press number keys to input the cooking time. Press
“
1.During microwave cooking, time defrost , time can be added by pressing
2. Under sensor menu and weight defrost state,time cannot be added by " "button.
““
START/ 30sec.
+

15
8. TIME DEFROST FUNCTION
(1) Press“Time Defrost“ once, screen will display “00:00”.
           
(2) Press number pads to input defrosting time. The effective time range is 00:01~99:99.
(4) Press tostartdefrosting.Theremainedcookingtimewillbedisplayed.


“START/ 30SEC.“
+
9. POPCORN
(1) Press“POPCORN“repeatedlyuntilthenumberyouwishappearsinthedisplay,
“3.0”,”3.5”,”1.75”Ozwilldisplayinorder.
Forexample,press“POPCORN”once,“3.0”appears.
      
(2) Press tocook,buzzersoundsonce.Whencookingnish,buzzer
soundsvetimesandscreenwilldisplaythe current time.


“START/ 30SEC.“
+
(3) Thedefaultpoweris power.30% And it cannot be changed.
2) During cooking process, following points must be done.
a. Keep the door close when the surplus time not displays or the buzzer
does not sound twice.
b. When the buzzer sound twice , the time will count down and display the suplus time,
you can open the door to mix the food up, turn over or replace the food. And then go
on the next operation.
3) Please leave the food alone for a while after cooking have been finished.
4) During sensor cooking process, if the time is not counting down, please do not open the oven
door or press " STOP/CANCEL " key. Otherwise,the sensor will make mistakes.
emanate the steam.Sealed utensil is forbidden.
Note:
1) When cooking or reheating food, you should do these in order to have the best effect.
a. The room temperature cannot be over 35 degrees.
b. The weight of food must be more than 110g (4 Oz).
c.
The cavity,glass tray and utensils must kept drying before putting the food in.
10. SENSOR COOK
““
(1) In waiting state, put the food in the oven, press the menu key in the sensor cook.
(2) Press "
“
START/+30SEC
“
" to start sensor reheat function and no need to set time.
(3) The sensor will sound twice when the steaming is emanated. The surplus time will
display, the buzzer will sound 5 beeps when finishing. At last, the oven will turn back
to the waiting state.
The reheat food can be covered with the lid, bBut the lid must has venthole in order to
d.

16
Sensor Reheat Menu
1) In waiting states,
"SC-1" is displayed.
2) Press " START/+30SEC " to start sensor reheat function and no need to set time.
3)The sensor will sound twice when the steaming was be emanated.The surplus time will
displays, the buzzer will sound 5 beeps when finishing and the oven will turn back to
the waiting states.
ess " SENSOR REHEAT". and put the food into the microwave oven. Pr
Be careful when removing the film cover after cooking.
Remove facing away from you to avoid steam burns. If
additional time is needed, continue to cook manually.
Cover the film before cooking and leave a spacing near
the edge of the container in order to let the steam out.
When buzzer sound twice, cooking time counts down.
Press " STOP/CANCEL " to pause and open the oven
If the weight is over 12 OzZ, please set the
additional cooking time manually.
Arrange in a single layer. Cover with lid or vented plastic
wrap. Cover the film before cooking and leave a spacing
near the edge of the container in order to let the steam
out. When cooking time counts down, press "
pause and open the oven door to turn
continue to cook.
Wash thoroughly, add 15ml water per 125g vegetables,
and cover with a lid or vented plastic wrap.
Do not salt/butter vegetables until after cooking.
Reheat food is dinner plate. When sensor time
finishes, cooking time counts down. Now you can
mix it and then continue reheating.
Pierce each potato with a fork 6 times around its surface.
Place potatoes around the edge of a paper-towel-lined
turntable. Do not cover. If additional time is needed,
continue to cook manually. Please let stand for 5 minutes
in the oven after finishing to avoid burning.
Sensor Cook Chart
Menu Weight
SC-1
Sensor
Reheat
SC-2
Frozen
Pizza
8~12 Oz
1~4 Units
6~12 Oz
(170~340g)
SC-3
Fish
SC-6
Frozen
Vegetable
4~16 g
(110~450g)
6~16Oz
(170~450g)
4~16Oz
(110~450g)
8~24 Oz
SC-5
Fresh
Vegetable
SC-4
Meat (225~680g)
Inicial Temp.
SC-7
Potato (6~8Oz
each one)
Room
Temp.
SC-8
Frozen
entree
8~32 Oz
(225~900g)
minus
18 degrees
5 degrees
minus
18 degrees
Room
Temp.
5 degrees
Additional Instructions
5 degrees
minus
18 degrees
STOP/
over and then
toCANCEL"
Break apart in glass bowl or colander. Cover with lid or
vented plastic wrap. JJuices should be clear when done,
then drain.When cooking time counts down,Press
"STOP/ CANCEL to pause and open the oven door to
mix and then continue to cook.
All pieces should be the same size. Wash thoroughly,
add 15ml water per 125g vegetables, and cover with a
lid or vented plastic wrap. When cooking time counts
down, press " STOP/CANCEL " to pause and open the
oven door to mix and then continue to cook.
door to mix.
““
“ “

17
11. MEMORY FUNCTION
         
Note:
Auto menu can not be set in memory function.
(1) Press“MEMORY”tochoosememory1-3procedure.Thescreenwilldisplay1,2,3.
(2) Iftheprocedurehasbeenset,press touseit.Ifnot,continuetoset
the procedure. Only one or two stages can be set.
(3) Iftheprocedurehasnotbeenset,afternishingthesetting,press once
to
save the
 procedureandturnbacktothewaitingstates.Ifpress itwillstart
cooking at once and save the procedure too.
Example: To set the following procedure as the second memory, that is memory 2.
To cook the food with 80% microwave power for 3minutes and 20 seconds.
The steps are as follow:
a. Inwaitingstates,press“MEMORY”twice,stoppressinguntilthescreendisplays“2”.
b. Press“COOK TIME “once,thenpress“3”,”2”,”0”inorder.
c. Press  once,”PL10”display,thenpress“8”and“PL8”displays.
d. Press tosavethesetting and turn back to the waiting state;
 Ifyoupress ,theprocedurewillbe  as the memory 2.
.
e. If the electricity is not cut off, the procedure will be saved all the time. If it is, the procedure
need to reset.
f. Whenyouwanttorunthesavedprocedure,inwaitingstates,press twice,screen
 displays“2”,thenpress tostartcooking.
“0/MEMORY”


“START/ 30SEC.“
+


“START/ 30SEC.“
+


“START/ 30SEC.“
+


“START/ 30SEC.“
+


“


“MEMORY “
5) The sensor reheat has different request for different food.
Casseroles- Add to 4 tablespoons of water, cover with lid or vented plastic wrap.
Stir when time appears in the display window.
Canned foods-Empty contents into casserole dish or serving bowl,cover dish with lid
or vented plastic wrap. After reheating, let stand for a few minutes.
Plate of food- Arranged food on plate; top with butter, gravy,etc. Cover with lid or vented
plastic wrap. After reheating, let stand for a few minutes.
3
3) The reheat food can be covered with the lid.BBBBBBBBBBAnd the lid must has venthole in order to
emanate the steam. Sealed utensil is forbidden.
4) During sensor cooking process, please do not open the oven door or press
STOP/CANCEL " key. Otherwise,the sensor will make mistakes.
1) Food to be avoided in sensor reheating.
a.Bread and other dry food, such as biscuit,cake.
b.For raw or uncooked foods.
c.Beverage and frozen food.
2) The oven cannot cook automatically when the temperature of the oven cavity is high.
“MEMORY
“POWER LEVEL“
““
12. MULTI-STAGE COOKING
At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is defrosting, then
defrostingshallbeplacedattherststageautomatically.
Note:
save and operatedd

13. INQUIRING FUNCTION
Inthemicrowavecookingstate,press toinquiremicrowavepowerlevel,and
the current microwave power will be displayed. After three seconds, the oven will turn back to
the previous state. In multi-stage state, the inquiring way can be done by the same way as above.
14. LOCK FUNCTION FOR CHILDREN
Lock:Inwaitingstate,press“STOP/CANCEL“for3seconds,therewillbealong“beep”denotingthe
entering into the children-lock state, and the lock indicator will light. The screen will display the
Unlock:Inlockedstate,press“STOP/CANCEL “for3seconds,therewillbealong“beep”denoting
that lock is released.
When

the

cooking

is

over,

the

buzzer will sound 5 “beep” to alert user the cooking is nished.
(1) Instandbystate,ifthesetclockdigitaltubedisplayscurrenttime,theicon“:“wouldash;
otherwise,itshows“0:00“.
(2) In setting function state, the screen displays corresponding setting.
(3) In working or pause state, the screen displays surplus cooking time.
(4) Whenthecookingisnish,thescreenwilldisplay Openingthedoororpressing
“STOP/CANCEL“canmaketheovenenterwaitingstate.
15. COOKING END REMINDING FUNCTION
the current time.
18
Inthemicrowavecookingstate,press“ toinquireCLOCK“ the current time.
Note:
Auto menu cannot work in the multi-stage cooking.
Example: If you want to cook with 80% microwave power for 5 minutes + 60% microwave
power for 10 minutes. The cooking steps are as following:
a. Press once,thenpress“5”,”0”,”0”tosetthecookingtime;
b. Press “POWER LEVEL“once,thenpress“8”toselect80%microwavepower.
c. Press once,thenpress“1”,”0”,”0”,”0”tosetthecookingtime;
d. Press once,thenpress“6”toselect60%microwavepower.
e. Press to start cooking.
“ “
“ “

“START/ 30SEC.“
+
COOK TIME
COOK TIME
“POWER LEVEL“
“POWER LEVEL“
17. OTHER SPECIFICATIONS
current time or 0:00.
In standby mode, press the "STOP/Cancel" once (less than 3 seconds to avoid starting the child lock
function to enter the Energy Saver mode.
)
In child-locked mode, press the "STOP/Cancel" once (less than 3 seconds) and release to enter the
Energy Saver Mode.
Above operation is the only way to start the Energy Saver mode.
The Energy Saver mode works only if the door is closed.
(1)
(2)
(3)
(4)
ENERGY SAVER MODE16.

MAINTENANCE
Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the
microwave oven still does not work properly, contact the nearest authorized service center.
Trouble Possible Cause Possible Remedy
Oven will not
start
a. Electrical cord for oven is not
plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try again.
c. Check instructions.
Arcing or
sparking
a. Materials to be avoided in
microwave oven were used.
b. The oven is operated when empty.
c. Spilled food remains in the cavity.
a. Use microwave-safe cookware only.
b. Do not operate with oven empty.
c. Clean cavity with wet towel.
Unevenly
cooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted completely.
c. Cooking time, power level is
not suitable.
d. Food is not turned or stirred.
a. Use microwave-safe cookware only.
b. Completely defrost food.
c. Use correct cooking time, power level.
d. Turn or stir food.
Overcooked
foods
Cooking time, power level is
not suitable.
Use correct cooking time, power level.
Undercooked
foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted completely.
c. Oven ventilation ports are restricted.
d. Cooking time, power level is not
suitable.
a. Use microwave-safe cookware only.
b. Completely defrost food.
c. Check to see that oven ventilation
ports are not restricted.
d. Use correct cooking time, power level.
Improper
defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe cookware only.
b. Use correct cooking time, power level.
c. Turn or stir food.
19

20


ONE YEAR LIMITED WARRANTY
This warranty applies to products purchased and used in the U.S and Canada
.
This is the only express warranty for this product and is in lieu of any other warranty
or condition.
This product is warranted to be free from defects in material and workmanship for a
period of one (1) year from the date of original purchase. This warranty is valid for the
original retail purchaser or gift recipient from the date of initial retail purchase
and is not transferable.
Keep your original sales receipt as proof of purchase is required to make a warranty claim.
IMPORTANT: This warranty does not cover damages resulting from use not in
conformity with the printed directions, accident, misuse or abuse, alternation, the
affixing of any attachments not provided with the product, loss of parts, or subjecting the
appliance to any but the specified voltage. (Read directions carefully.) This warranty is
void if the product is used for other than single-family household use or subjected to any
voltage and waveform other than as specified on the rating label (e.g., 120V ~ 60 Hz).
Englewood Marketing LLC excludes all claims for special, incidental, and consequential
damages caused by breach of express or implied warranty. All liability is limited to
the amount of the purchase price. Every implied warranty, including any statutory
warranty or condition of merchantability or fitness for a particular purpose, is
disclaimed except to the extent prohibited by law, in which case such warranty or
condition is limited to the duration of this written warranty. This warranty gives you
specific legal rights. You may have other legal rights that vary depending on where you
live. Some states or provinces do not allow limitations on implied warranties or special,
incidental, or consequential damages, so the foregoing limitations may not apply to you.
To make a warranty claim or if service is required, please call our CUSTOMER SERVICE
NUMBER.
For faster service, please have the model, type, and series numbers ready for the operator
to assist you.
Customer Service Number
Englewood Marketing LLC
In the US 844-918-0509
Email: [email protected]
