FCI SmartFlush ATF-0001 User manual

P a g e | 1
SmartFlush In-Wall Automatic
Toilet Flusher
ATF-0001
Installation Manual
Quality Guarantee
*Thank you for choosing the automatic urinal flusher. Please read the
instruction carefully before installation. This manual is for your reference
only.

P a g e | 2
Features
•Hands free sensor operation.
•Adjustable control stop for water flow
adjustment
•Manual push button for flushing.
•Adjustable sensing distance
Specifications
Power
6V (4 x Alkaline
AA)
AC 110-240V
50 –60 Hz
Water Pressure
0.3 –0.8 MPa
Water
Temperature
0.1 –50 oC
Water Flow
Volume
9 –12 L (Single flush @ 0.24
MPa)

P a g e | 3
Construction /
Installation Diagram
Plumbing installation must be in accordance with
applicable codes and regulations. Water supply
lines must be sized to provide an adequate
volume of water for each fixture. Flush all
waterlines prior to operation.
Prior to installing your Flush Valve, install the
items listed below:
•Tolilet fixture
•Drain line
•Water supply line
The supply piping to these devices must be
securely anchored to the building structure to
prevent the installed device moving during use.
Prevent marring to the exposed surface during
installation. IMPORTANT: Purge all air from the
supply lines before connecting flush valve to the
bowl.
To prevent valve malfunction, do not install a
handrail or any other object within the detection
range of the sensor. Do not install the flush valve

P a g e | 4
where sensor faces a mirror, stainless steel wall,
other highly reflective surfaces or another infrared
sensor.
Determine the installation location of the studs
and water supply pipe relative to the position of
the toilet.

P a g e | 5
Detection / Activation
No manual adjustments are required for most
settings. Default beam’s effective range is 65 –70
cm. The factory setting should be satisfactory for
most installations.
Water Flow Time
Adjustment
Default water flow delivery is 8 seconds.
1. Press te black push button 5 times (x5) unit
the red LED stays on. The valve will open,
flushing once to indicate ready for timing
adjustment.
2. Within 10 seconds, press the black push
once for 6 seconds delivery, push twice for
8 seconds, 3 times for 10 seconds delivery,
4 times for 12 seonds delivery.

P a g e | 6
Range Adjustment
If the range is too short or too long, it can be
adjusted.
1. Using a phillips screw driver remove the
stainless steel cover plate by unscrewing
the screw from the bottom of the plate.
2. Ensure both cables are connected.
3. Press the black push button three time (x3)
unitl the sensor red LED flashes.
4. Place a target sensor view at a desired
distance for 30 seconds. The LED will stay
on for 5 seconds before flashing twice
indicating distance set.

P a g e | 7
Solenoid Valve Maintenance
1. Shutfoff all water lines.
2. Remove the stainless steel front cover.
3. Disconnect the sensor & power cables.
4. Using a phillips screw driver remove the
black plastic front cover.
5. Remove the four solenoid valve screws
(black body).
6. Gently pull out the following solenoid cover
through diaphgram bracket.
7. Clean the valve seat using a dampened
soft cloth with diluted dishwashing
detergent and dry it with another soft cloth.
8. When completed, assemble back the
soelnodi valve.

P a g e | 8
Flow Rate Adjustment
Locate the control stop (stop valve) & with a flat
head screw driver adjust (counter clockwise) the
stop valve to desired flow rate.
Battery Replacement
Replace battery when RED LED indicator flashes
rapidly or when flusher stops functioning.
i. Turnoff the stop valve.
ii. Disconnect the battery box from the
sensor.
iii. Remove the battery holder
iv. Using a Philips screw driver remove
the battery cover and the batteries.
v. Replace 4 AA batteries
vi. Place back the battery cover and
fasten the four Phillip screws to
secure the cover.
vii. Connect the battery holder to the
sensor and place the battery holder
inside the junction box.
viii.Place the black plastic junction cover
& fasten cover onto the junction box.

P a g e | 9
Troubleshooting
1. Valve does not flush.
i. The main valve in water supply line or the
control stop is shut off. Open the main
valve or the stop valve.
ii. The connectors are not connected.
Connect the wires.
iii. The surface of the sensor is dirty. Clean
surface with soft cloth.
iv. There is a reflective surface in front of the
sensor. Remove the reflective surface
from the front of the sensor.
v. The sensor or the solenoid is not
functioning. Contact distributor for
possible part replacement.
vi. Small holes in the diaphgram is clogged.
Clean the small hole in the diaphgram
using a small needle.
2. Valve will not shutoff
i. Plunger damage. Contact distributor for
possible part replacement.
3. Water delivery is too small / too large
i. Stop valve flow rate not adjusted properly.
Adjust the water discharge rate by the
turning the stop valve clockwise or
counterclockwise.
4. Red LED flashing when user steps in sensor
range. Batteries are low.
i. Replace batteries.

P a g e | 10
Care & Cleaning
IMPORTANT! Do not scratch the sensor or
faceplate when cleaning. Avoid using any cleaning
materials that may scratch the surface.
Never use polishing powder, detergent that
includes coarse particles, thinners, benzene,
acids, alkaline detergents, or nylon scrub brushes.
To safely clean the surface, wipe it using a
dampened soft cloth with diluted dishwashing
detergent and dry it with another soft cloth. If this
does not adequately clean the surface, wipe the
area with a neutral detergent and wet cloth.

P a g e | 11
Resources
Warranty Information
For information on product
warranty, visit our resource page
through the QR code.
Alternatively, you can visit our
warranty claims page at
https://faucetscanada.ca//warranty-
claim/
For Installation guides, visit our
resource page through the QR
code
Alternatively, you can visit our
resource page at
https://faucetscanada.ca/resources/
To view more products from
Faucets Canada, visit our shop
page through the QR code.
Alternatively, you can visit our shop
page at
https://faucetscanada.ca/shop/

P a g e | 12
