Feider Machines FM1125 User manual

ORIGINAL INSTRUCTIONS
INSTRUCTION MANUAL
ANGLE GRINDER
FM1125
READ THIS INSTRUCTIONS MANUAL BEFORE USE THE TOOL
BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux - France

2
CONTENTS
1. SAFETY WARNINGS 3
2. SYMBOLS 5
3. THE PRODUCT 6
4. USE 7
5. MAINTENANCE AND SERVICNG 9
6.DISPOSAL 9
6. CE DECLARATION 10
7. WA R R A N T Y 11
8.PRODUCT FAILURE 12
9. WARRANTY EXCLUSIONS 13

3
1. SAFETY WARNINGS
WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a
power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position connecting to power source and/or
battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the
job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any
adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other
condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into
account the working conditions and the work to be performed. Use of the power tool for operations different from

4
those intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement parts.This will
ensure that the safety of the power tool is maintained .
Safety instructions for all operations
Safety Warnings Common for Grinding, Sanding, Wire Brushing, Polishing or Abrasive Cutting-Off
Operations:
a) This power tool is intended to function as a grinder. Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to follow all instructions listed below may result in electric
shock, fire and/or serious injury.
b) Operations such as sanding, wire brushing, polishing or cutting-off are not recommended to be performed
with this power tool. Operations for which the power tool was not designed may create a hazard and cause personal
injury.
c) Do not use accessories which are not specifically designed and recommended by the tool manufacturer.
Just because the accessory can be attached to your power tool, it does not assure safe operation.
d) The rated speed of the accessory must be at least equal to the maximum speed marked on the power tool.
Accessories running faster than their rated speed can break and fly apart.
e) The outside diameter and the thickness of your accessory must be within the capacity rating of your power
tool. Incorrectly sized accessories cannot be adequately guarded or controlled.
f) Threaded mounting of accessories must match the grinder spindle thread. For accessories mounted by
flanges, the arbour hole of the accessory must fit the locating diameter of the flange. Accessories that do not
match the mounting hardware of the power tool will run out of balance, vibrate excessively and may cause loss of
control.
g) Do not use a damaged accessory. Before each use inspect the accessory such as abrasive wheels for
chips and cracks, backing pad for cracks, tear or excess wear, wire brush for loose or cracked wires. If power
tool or accessory is dropped, inspect for damage or install an undamaged accessory. After inspecting and
installing an accessory, position yourself and bystanders away from the plane of the rotating accessory and
run the power tool at maximum no-load speed for one minute. Damaged accessories will normally break apart
during this test time.
h) Wear personal protective equipment. Depending on application, use face shield, safety goggles or safety
glasses. As appropriate, wear dust mask, hearing protectors, gloves and workshop apron capable of stopping
small abrasive or workpiece fragments. The eye protection must be capable of stopping flying debris generated by
various operations. The dust mask or respirator must be capable of filtrating particles generated by your operation.
Prolonged exposure to high intensity noise may cause hearing loss.
i) Keep bystanders a safe distance away from work area. Anyone entering the work area must wear personal
protective equipment. Fragments of workpiece or of a broken accessory may fly away and cause injury beyond
immediate area of operation.
j) Hold the power tool by insulated gripping surfaces only, when performing an operation where the cutting
accessory may contact hidden wiring or its own cord. Cutting accessory contacting a "live" wire may make
exposed metal parts of the power tool "live" and could give the operator an electric shock.
k) Position the cord clear of the spinning accessory. If you lose control, the cord may be cut or snagged and your
hand or arm may be pulled into the spinning accessory.
l) Never lay the power tool down until the accessory has come to a complete stop. The spinning accessory may
grab the surface and pull the power tool out of your control.
m) Do not run the power tool while carrying it at your side. Accidental contact with the spinning accessory could
snag your clothing, pulling the accessory into your body.
n) Regularly clean the power tool’s air vents. The motor’s fan will draw the dust inside the housing and excessive
accumulation of powdered metal may cause electrical hazards.
o) Do not operate the power tool near flammable materials. Sparks could ignite these materials.
p) Do not use accessories that require liquid coolants. Using water or other liquid coolants may result in
electrocution or shock.
Further safety instructions for all operations
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or any other accessory.
Pinching or snagging causes rapid stalling of the rotating accessory which in turn causes the uncontrolled power tool
to be forced in the direction opposite of the accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge of the wheel that is entering into
the pinch point can dig into the surface of the material causing the wheel to climb out or kick out. The wheel may
either jump toward or away from the operator, depending on direction of the wheel’s movement at the point of pinching.
Abrasive wheels may also break under these conditions.

5
Kickback is the result of power tool misuse and/or incorrect operating procedures or conditions and can be avoided by
taking proper precautions as given below.
a) Maintain a firm grip on the power tool and position your body and arm to allow you to resist kickback
forces. Always use auxiliary handle, if provided, for maximum control over kickback or torque reaction during
start-up. The operator can control torque reactions or kickback forces, if proper precautions are taken.
b) Never place your hand near the rotating accessory. Accessory may kickback over your hand.
c) Do not position your body in the area where power tool will move if kickback occurs. Kickback will propel the
tool in direction opposite to the wheel’s movement at the point of snagging.
d) Use special care when working corners, sharp edges etc. Avoid bouncing and snagging the accessory.
Corners, sharp edges or bouncing have a tendency to snag the rotating accessory and cause loss of control or
kickback.
e) Do not attach a saw chain woodcarving blade or toothed saw blade. Such blades create frequent kickback and
loss of control.
Additional safety instructions for grinding and cutting-off operations
Safety Warnings Specific for Grinding and Abrasive Cutting-Off Operations:
a) Use only wheel types that are recommended for your power tool and the specific guard designed for the
selected wheel. Wheels for which the power tool was not designed cannot be adequately guarded and are unsafe.
b) The grinding surface of centre depressed wheels must be mounted below the plane of the guard lip. An
improperly mounted wheel that projects through the plane of the guard lip cannot be adequately protected
c) The guard must be securely attached to the power tool and positioned for maximum safety, so the least
amount of wheel is exposed towards the operator. The guard helps to protect the operator from broken wheel
fragments, accidental contact with wheel and sparks that could ignite clothing.
d) Wheels must be used only for recommended applications. For example: do not grind with the side of cut-
off wheel. Abrasive cut-off wheels are intended for peripheral grinding, side forces applied to these wheels may cause
them to shatter.
e) Always use undamaged wheel flanges that are of correct size and shape for your selected wheel. Proper
wheel flanges support the wheel thus reducing the possibility of wheel breakage. Flanges for cut-off wheels may be
different from grinding wheel flanges.
f) Do not use worn down wheels from larger power tools. Wheel intended for larger power tool is not suitable for
the higher speed of a smaller tool and may burst.
2. SYMBOLS
Refer to the instructions manual
Wear ear protection
Wear eyes protection
In accordance with essential applicable safety standards of European directives
WEEE symbol for disposal
Class II product

6
3. THE PRODUCT
1) Description
2) Technical data
Model
FM1125
Voltage
230-240V˜ 50Hz
Power
1100W
Rated speed in revolution per minute
12000/min
Disc diameter in mm
Ø125mm
Spindle thread size
M14
Thickness of the disc
6 mm
Weight
Max 2,3 kg
Protection class
/II
Sound pressure level Lpa
Max: 91dB(A), K=3 dB(A)
Sound power level Lwa
Max: 102 dB(A) , K=3 dB(A)
Vibration value
Max: ah,AG=3.89 m/s2,K=1,5 m/s²
Information
The declared vibration total value has been measured in accordance with a standard test method and may be used
for comparing one tool with another;
The declared vibration total value may also be used in a preliminary assessment of exposure.
1. Spindle lock
2. Handle assembly
3. ON/OFF switch
4. Supply cord
5. Carbon brushes
6. Auxiliary handle
7. Guard
8. Wrench

7
Warning
The vibration emission during actual use of the power tool can differ from the declared total value depending on the
ways in which the tool is used; and
It is necessary to identify safety measures to protect the operator that are based on an estimation of exposure in
the actual conditions of use (taking account of all parts of the operating cycle such as the times when the tool is
switched off and when it is running idle in addition to the trigger time).
Wear hearing protection
4. USE
1) Intended use
This angle grinder is designed for grinding and roughing metal such as metal or stone. The tool can be used also
as a cutting off tool by using the correct disks. The capacity of the tool is 125mm maximum.
Do not use this tool for commercial purposes; it is only for a private household use.
Use only discs for grinding and cutting.
2) Before the first use
Check if the package is complete and not damaged. If some parts are missed or are damaged, please do not
use the tool and bring it back to your dealer.
3) Assembly
WARNING: The tool must be always switched off and unplugged before assembly!
- Installation of the disk
NOTE: The tool is delivered without grinding disc; see you dealer to buy recommended disc with this
tool.
oPlace the inner flange on the spindle.
oPlace then the corresponding disk.
oPlace the outer flange the disk and screw it firmly with the pin wrench.
NOTE: The flange is already installed and can be used with grinding and cutting discs.
Following the disk, the outer flange can be installed on the two sides:

8
- Installation of the auxiliary handle
The auxiliary handle can be installed on both sides of the tool. The place where to install the auxiliary handle
will depend of the position where you will use the tool. Install and screw firmly the handle until it locks in place.
See the operation part for install the handle according the position of tool. Switch off the tool when you want to
change the position of the auxiliary handle.
4) Operation
1. Before switch on the tool, find the correct position to use the tool.
2. Plug the supply cord to a socket.
3. Hold the angle grinder by both hands, one hand hold the machine body and the other hold the auxiliary
handle.
4. Push forward the switch button.
5. To stop the operation, Press and release the switch button.
Rough grinding
For the best rough grinding results, hold the grinding wheel at an angle of between 30oand 40oto the work-piece
surface and guide back and forth over the work-piece in steady movements.
Cutting
When you use the right-angle grinder for cutting purposes, avoid tilting it in the cutting plane. The cutting wheel
must have a clean cutting edge. A diamond cutting wheel is best used to cut hard stone. It is prohibited to use the
machine on asbestos materials!
Never use a cutting wheel for rough grinding.
5) Replace the disk
Warning: Beware – a disc which has been used may be very hot!
1. Pull out the power plug from the mains socket.
2. Depress and hold down the spindle lock button (2) to secure the spindle
3. Turn the shaft until it locks.
4. Remove the outer flange (a) and backing flange (b) by using the two-hole spanner provided.
5. Fit the desired disc (8) on the spindle and replace the outer flange and backing flange. Release the spindle
lock.

9
5. MAINTENANCE AND SERVICE
Keep your tool on a regular basis. This will keep your tool in good working order and extend its lifespan.
Do not use abrasive or corrosive agents to clean the tool. These types of products damage your tool.
Do not make any repairs by yourself. Repairs and inspections should be carried out by a competent person or an
authorized service center (please contact your dealer).
a. After each use
Check the condition of the accessories and the tool body (cleanliness, wear, damage, etc.). If you notice any
damage, wear or malfunction, do not use the tool and take it to a qualified service for inspection and repair.
b. Carbon brushes
One set of carbon brushes are provided with the tool. When the carbon brushes are worn, it can be replaced by
the new provided one. Bring your tool to our service center for the maintenance and replacement of the carbon
brushes.
c. Servicing
No specific maintenance is required by the user. After each season, please bring the tool to an authorized service
center for general machine maintenance.
d. Spare parts
You can order spare parts directly from our service center. Please place your order according to the type of
machine and the part number indicated in the explosion drawing.
If replacement of the cable is necessary, this must be done by the manufacturer or his agent to avoid a hazard.
e. Storage
-After use and cleaning, please keep your tool.
-Store the tool in a clean, dry place, preferably in its box.
-When transporting and storing, always put the protective cover on the blade.
-The tool should be stored away from children and pets.
-Avoid exposing the tool to direct sunlight.
6. DISPOSAL
Electrical products should not be discarded with household products. According to the European Directive 2012/19/EU
on waste electrical and electronic equipment and its implementation into national law, electrical products used must be
collected separately and disposed of at collection points provided for this purpose. Talk with your local authorities or
dealer for advice on recycling.

10
7.CE DECLARATION
BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux - France
Is in conformity with the requirements of the Directive Machine 2006/42/EC and to the followings Europeans
Directives:
EMC Directive 2014/30/EU
ROHS Directive (EU)2015/863 amending 2011/65/EU
This tool is also in conformity with the following these standards:
EN 60745-1: 2009+A11:2010
EN 60745-2-3:2011+A2:2013+A11:2014+A12:2014+A13:2015
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Responsible of the technical file:Julia Zou
Philippe MARIE / PDG
Declare that the following tool:
ANGLE GRINDER
FM1125
Serial number: 20210432672-20210433171
Cugnaux, 03/02/2021

WARRANTY
The manufacturer guarantees the product against defects in material and workmanship for a period of 2
years from the date of the original purchase. The warranty only applies if the product is for household use.
The warranty does not cover breakdowns due to normal wear and tear.
The manufacturer agrees to replace parts identied as defective by the designated distributor. The
manufacturer does not accept responsibility for the replacement of the machine, in whole or in part , and/or
ensuing damage.
The warranty does not cover breakdowns due to:
• insu󰀩cient maintenance.
• abnormal assembly, adjustment or operations of the product.
• parts subject to normal wear and tear.
The warranty does not extend to:
• shipping and packaging costs.
• using the tool for a purpose other than that for which it was designed.
• the use and maintenance of the machine done in a manner not described in the user manual.
Due to our policy of continuous product improvement, we reserve the right to alter or change specications
without notice. Consequently, the product may be di󰀨erent from the information contained therein, but a
modication will be undertaken without notice if it is recognized as an improvement of the preceding
characteristic.
READ THE MANUAL CAREFULLY BEFORE USING THE MACHINE.
When ordering spare parts, please indicate the part number or code, you can nd this in the spare parts list
in this manual. Keep the purchase receipt; without it, the warranty is invalid. To help you with your product,
we invite you to contact us by phone or via our website:
• +33 (0)9.70.75.30.30
• https://services.swap-europe.com/contact
You must create a "ticket" via the web platform.
• Register or create your account.
• Indicate the reference of the tool.
• Choose the subject of your request.
• Describe your problem.
• Attach these les: invoice or sales receipt, photo
of the identication plate (serial number), photo
of the part you need (for example: pins on the
transformer plug which are broken).
11
8. WARRANTY

WHAT TO DO IF MY MACHINE BREAKS DOWN?
If you bought your product in a store:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
Go to the store with the complete machine and with the receipt or invoice.
If you bought your product on a website:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
c) Create a SWAP-Europe service ticket on the site: https://services.swap-europe.com When making the
request on SWAP-Europe, you must attach the invoice and the photo of the nameplate (serial number).
d) Contact the repair station to make sure it is available before dropping o󰀨 the machine.
Go to the repair station with the complete machine packed, accompanied by the purchase invoice and the
station support sheet downloadable after the service request is completed on the SWAP-Europe site
For machines with engine failure from manufacturers BRIGGS & STRATTON, HONDA and RATO, please
refer to the following instructions.
Repairs will be done by approved engine manufacturers of these manufacturers, see their site:
• http://www.briggsandstratton.com/eu/fr
• http://www.honda-engines-eu.com/fr/service-network-page;jsessionid=5EE8456CF39CD572AA2AEEDFD
290CDAE
• https://www.rato-europe.com/it/service-network
Please keep your original packaging to allow for after-sales service returns or pack your machine
with a similar cardboard box of the same dimensions.
For any question concerning our after-sales service you can make a request on our website https://
services.swap-europe.com
Our hotline remains available at [phone].
9. PRODUCT FAILURE
12

THE WARRANTY DOES NOT COVER:
• Start-up and setting up of the product.
• Damage resulting from normal wear and tear of the product.
• Damage resulting from improper use of the product.
• Damage resulting from assembly or start-up not in accordance with the user manual.
• Breakdowns related to carburetion beyond 90 days and fouling of carburetors.
• Periodic and standard maintenance events.
• Actions of modication and dismantling that directly void the warranty.
• Products whose original authentication marking (brand, serial number) has been degraded, altered or
withdrawn.
• Replacement of consumables.
• The use of non-original parts.
• Breakage of parts following impacts or projections.
• Accessories breakdowns.
• Defects and their consequences linked to any external cause.
• Loss of components and loss due to insu󰀩cient screwing.
• Cutting components and any damage related to the loosening of parts.
• Overload or overheating.
• Poor power supply quality: faulty voltage, voltage error, etc.
• Damages resulting from the deprivation of enjoyment of the product during the time necessary for repairs
and more generally the costs related to the immobilization of the product.
• The costs of a second opinion established by a third party following an estimate by a SWAP-Europe repair
station
• The use of a product which would show a defect or a breakage which was not the subject of an immediate
report and/or repair with the services of SWAP-Europe.
• Deterioration linked to transport and storage*.
• Launchers beyond 90 days.
• Oil, petrol, grease.
• Damages related to the use of non-compliant fuels or lubricants.
* In accordance with transport legislation, damage related to transport must be declared to carriers within 48
hours maximum after observation by registered letter with acknowledgement of receipt.
This document is a supplement to your notice, a non-exhaustive list.
Attention: all orders must be checked in the presence of the delivery person. In case of refusal by the
delivery person, it you must simply refuse the delivery and notify your refusal.
Reminder: the reserves do not exclude the notication by registered letter with acknowledgement within 72
hours.
Information:
Thermal devices must be wintered each season (service available on the SWAP-Europe site). Batteries must
be charged before being stored.
13
10. WARRANTY EXCLUSIONS
