OPERATOR’S & PARTS MANUAL
ROTO-TILLER
SERIAL NUMBER: ___________________
MODEL NUMBER: ___________________
Manual Number: MR15639
Models: LAF3438, LAF3452 & LAF3468
Date: February 2007

1
TABLE OF CONTENTS
Introduction, General Information, Serial Number ……………………………………………….. 1
Owner and Operator Safety Information …………………………………………………………… 2-5
Definitions of Safety Terms and Symbols, Accident Prevention ……………………… 2
Safety Instructions ...............................……..…………………………………………… 3-4
Safety Signs ...............................…................................………………………………. 5
Power Unit Specifications, Mounting ……………………………………………………………… 6
Hydraulic Connection ……………………………………………………………………………….. 6
Operation, Maintenance …………………………………………………………………………….. 7
Service ………………………………………………………………………………………………... 8
Parts Illustration ………………………………………………………………………………………. 9
Parts List ……………………………..……………………………………………………………….. 10
Specifications ………………………………………………………………………………………… 11
Warranty …………………………………………………………………………………………….. i
INTRODUCTION
Congratulations on your purchase of a new FFC Attachments Roto-Tiller. This product has been designed and built to
till and loosen soil. This product can also be used for aeration purposes such as reconditioning of contaminated soil. You
or any other person who will be assembling, operating, maintaining, or working with this product are required to read and
completely understand the information and instructions contained in this manual. If anyone does not fully understand
every part of this manual, please obtain further assistance by contacting the dealer from which this product was
purchased or by contacting FFC Attachments at the telephone number or address listed on the cover of this manual.
Keep this manual available for reference whenever this product is being handled or used. Provide this manual to any new
owners and/or operators.
This manual covers model[s] :LAF3438,LAF3452 and LAF3468. The difference between these models is the width of the
product and the motor configuration, details of which are covered on the parts list and specification page[s].
GENERAL INFORMATION
The purpose of this manual is to assist in assembling, mounting, operating, and maintaining your Roto-Tiller: Read this
manual carefully to obtain valuable information and instructions that will help you achieve years of safe and dependable
service.
The illustrations and data used in this manual were current at the time of printing, but due to possible engineering and/or
production changes, this product may vary slightly in detail. FFC Attachments reserves the right to redesign and/or
change components as necessary without notification to anyone.
Throughout this manual, references may be made to:
Power Unit The engine-driven machine to which this product must be attached.
Right, Left, Front, Rear Directions that are determined in relation to the operator of the equipment when seated in
the normal operating position.
IMPORTANT Precautions that must be followed to prevent damage to equipment.
NOTICE Precautions that must be followed to prevent substandard performance.
SERIAL NUMBER LOCATION
Always refer to the model and serial number when ordering parts or requesting information from your dealer. The serial
number plate for this product is located on the upper left rear portion of the loader attachment plate of your
Roto-Tiller.
Reference Information
Model Number Loader Make
Serial Number Loader Model
Date Purchased Loader Serial #

2
DEFINITION OF SAFETY TERMS AND SYMBOLS
Throughout this manual, the terms DANGER,WARNING, and CAUTION are used to indicate the degree of hazard to
personnel if proper safety procedures are not followed. These words will be used in conjunction with the Safety Alert
Symbol: a dark triangle containing a white exclamation mark.
The Safety Alert Symbol means:
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
DANGER Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
WARNING Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury;
OR
may also be used to alert against unsafe practices which may result in personal injury.
ACCIDENTS CAN BE PREVENTED WITH
YOUR HELP!
No accident prevention program can be successful
without the wholehearted cooperation of the person who
is directly responsible for the operation of the equipment.
To read equipment accident reports from all over the
country is to be convinced that a large number of
accidents can be prevented only by operators who
consistently anticipate the results of their actions and
thus prevent accidents from ever occurring. No power-
driven equipment, whether it is on the highway, in a farm
field, or in an industrial plant, can be any safer than the
person who is at the controls.
If accidents are to be prevented [and accidents can be
prevented], that prevention will come from equipment
operators who accept their complete responsibility.
The designer, the manufacturer, and the safety engineer
all help create a safe product, but their combined efforts
can be wiped out with a single careless act by the
operator of that product.
The best safety device is a careful operator. FFC
Attachments and your dealer ask that YOU be that
careful, responsible equipment operator.
YOU ARE THE KEY TO SAFETY BECAUSE:
YOU are responsible for the SAFE operation and
maintenance of YOUR Roto-Tiller.
YOU are responsible to familiarize yourself, and anyone
else who will assemble, operate, maintain, or work
around this product, with the safety information
contained in this manual.
YOU are responsible to read ALL information contained
in this manual to any operators or maintenance
personnel who are not fully able to read the written
English language. Whether YOU read the manual as
written or translate it into another language, YOU must
make certain that all operators and maintenance
personnel have a complete understanding of the full and
exact contents of this manual. Translations of this
manual into other languages are available by submitting
a written request to FFC Attachments.
YOU can reduce the risk of injury or death by following
all safety precautions and by using good safety
practices.

3
SAFETY INSTRUCTIONS
WORK SAFELY - A CAREFUL OPERATOR IS THE BEST INSURANCE AGAINST ACCIDENTS !!
SECTION 1
WARNING SECTION
WARNING
Obey all the safety instructions listed in
this section and throughout this manual.
Failure to obey instructions in this
section could result in death or serious
injury.
BEFORE ATTEMPTING ANY TYPE OF ASSEMBLY,
OPERATION, MAINTENANCE, OR OTHER WORK ON
OR NEAR THIS PRODUCT:
xREAD AND COMPLETELY UNDERSTAND THIS
MANUAL.
xREAD AND COMPLETELY UNDERSTAND THE
MANUALS PROVIDED WITH YOUR POWER
UNIT,LOADER AND QUICK-ATTACH.
xRead and understand all safety signs on this
product and on your power unit, loader, and quick-
attach.
xKnow all your controls and know how to quickly stop
all power unit movement, the Roto-Tiller movement,
and the engine in case of an emergency.
xKnow and obey all applicable government rules,
O.S.H.A. regulations, local laws and other
professional guidelines for your operation.
xMake sure that anyone who will be assembling,
mounting, maintaining, repairing, removing, and/or
storing this product:
xhas been instructed in the safe operation of this
product and of the power unit and quick-attach
to which this product is attached.
xis physically and mentally capable of the safe
operation of this type of equipment.
xis not under the influence of drugs or alcohol.
xis carefully supervised from a safe distance,
especially if such person is inexperienced.
xwears appropriate protective equipment (i.e.
hardhat, safety glasses, work gloves, protective
shoes, respirator, ear protection, etc.).
xdoes not wear loose fitting clothing, loose or
uncovered hair, or any accessories (jewelry,
necktie, scarf, wrist watch, etc.) that can catch in
moving parts.
xhas annually reviewed all safety instructions.
xKnow and follow good work practices when
assembling, mounting, maintaining, repairing,
removing, and storing this product:
xWork on a level surface in a well lit area.
xKeep the area clean and dry.
xUse properly grounded electrical outlets & tools.
xUse the right tool for the job at hand.
xMake sure that your tools are in good condition for
performing the desired function.
xWhen using tools, wear the protective equipment
specified by the tool manufacturer. (i.e. hardhat,
safety glasses, work gloves, protective shoes, etc.)
WHEN YOUR POWER UNIT IS USED DURING ANY
TYPE OF ASSEMBLY, OPERATION, MAINTENANCE,
OR OTHER WORK ON OR NEAR THIS PRODUCT:
xBefore leaving the operator’s station or before
beginning any type of work on this product, lower
this product to the ground, apply your power unit’s
parking brake, stop the engine, remove the starter
key, wait for all moving parts to stop, and then
relieve all pressure in the hydraulic lines. Refer to
your power unit’s operator’s manual for instructions
on how to relieve hydraulic pressure in lines.
xKnow your loader’s safe lifting and operating
capacity and the weight of this product. See the
specifications in this manual for the weight of this
product and refer to your power unit’s and loader’s
operator’s manuals for safe operating limits. Lift
capacity may be reduced if using a quick-attach.
xNever allow anyone, except the operator, to be
around the power unit or this product when either is
in motion. Do not startup unless others are clear of
the work area.
xDo not allow riders on this product or the power unit.
xDo not stand or climb on this product when raised.
xDo not place any part of your body under any part of
this product unless this product is securely resting
on adequate blocking or on the ground.
xDo not use blocking made of concrete blocks, logs,
buckets, barrels or any other material that could
suddenly collapse or shift positions. Do not use
wood or steel blocking that shows any signs of
material decay. Do not use blocking that is warped,
twisted, or tapered.
xNever operate controls from the ground. Operate
the controls only from the operator’s station.
xNever leave equipment unattended with the engine
running or with this product raised on the loader.
xBe aware of the added weight and width of this
product. Reduce travel speeds accordingly,
especially when traveling over rough ground.
xKeep this product close to the ground and under
control when transporting.

4
SAFETY INSTRUCTIONS
WORK SAFELY - A CAREFUL OPERATOR IS THE BEST INSURANCE AGAINST ACCIDENTS !!
WARNING SECTION [CONTINUED]
WARNING
Obey all the safety instructions
listed in this section and throughout
this manual. Failure to obey
instructions in this section could
result in death or serious injury.
WHEN DEALING WITH HYDRAULICS DURING ANY
TYPE OF ASSEMBLY, OPERATION, MAINTENANCE,
OR OTHER WORK ON OR NEAR THIS PRODUCT:
xHydraulic fluid under pressure can penetrate the
skin and cause serious injury or death. Hydraulic
leaks under pressure may not be visible!
xIf any fluid penetrates the skin, GET IMMEDIATE
MEDICAL ATTENTION!!
xWear safety glasses, protective clothing, and use a
sound piece of cardboard or wood when searching
for hydraulic leaks. DO NOT USE YOUR HANDS!
xBefore connecting or disconnecting hydraulic hoses,
read your tractor or power unit’s operator’s manual
for detailed instructions on connecting and
disconnecting hydraulic attachments.
xMake certain that all parts meet the specifications for
this product when installing or replacing hydraulic
hoses or fittings.
xAfter connecting hydraulic lines:
xSlowly and carefully raise the loader and cycle
the rollback / dump cylinders to check hose
clearances and to check for any interference.
xOperate the hydraulics on this product to check
hose clearances and to check for any
interference.
xMake certain that the hoses cannot interfere with
or actuate the quick-attach mechanism.
xMake certain that hoses will not be pinched, or
get tangled, in any equipment.
xDo not lock the auxiliary hydraulics of your power
unit in the “ON” position.
xRefer to your power unit’s operator’s manual and
this manual for procedures and intervals, then
inspect and maintain the entire hydraulic system to
insure that the fluid remains clean, that all devices
function properly, and that there are no fluid leaks.
WHEN MOUNTING THIS PRODUCT TO YOUR
POWER UNIT:
xRefer to the operator’s manuals of your power unit,
your loader, and your quick-attach for special or
detailed mounting instructions.
xThis product should fit onto the quick-attach or
loader arms of your power unit the same as the
original products that were designed by your loader /
quick-attach manufacturer.
xIf this product does not fit properly, contact FFC
Attachments before operating.
xNever place your finger into the mounting plate or 3-
point hitch or loader holes. A slight movement of the
power unit or this product could cause serious injury.
BEFORE EACH USE, THOROUGHLY INSPECT THIS
PRODUCT AND:
xMake certain that all safety signs are in place and
legible. Refer to the safety sign page in this manual
for the placement of safety signs for this product.
xReplace all damaged or excessively worn parts and
hardware only with genuine FFC Attachments parts
or with properly rated fasteners, hydraulic hoses, or
fittings.
xMake certain that all locking pins, latches, and
connection devices are properly installed and
secured.
xMake certain that all protective guards, canopies,
doors, etc., are in place and secure.
WHEN OPERATING THIS PRODUCT IN
ACCORDANCE WITH DESIGN INTENTIONS:
xKeep everyone at least nine feet away from the unit
when operating.
WHEN ADJUSTING, SERVICING OR REPAIRING THIS
PRODUCT:
xMake no modifications to your Roto-Tiller.
xWhen making repairs, use only genuine FFC
Attachments parts or, for fasteners, hydraulic hoses,
or hydraulic fittings, use only properly rated parts.
xReplacement parts, for parts with safety signs
attached, must also have safety signs attached.
SECTION 2
CAUTION
Obey all the safety instructions listed in
this section and throughout this
manual. Failure to obey instructions in
this section may result in personal
injury.
xDo not use the top of this product as a step. Under
certain conditions, this area can be slippery.

5
SAFETY SIGN LOCATIONS
ITEM QTY. PART # DESCRIPTION
1 1 50-0723 READ MANUAL
2 1 50-0724 HYDRAULIC
3 2 RDL3100 STAND CLEAR
4 1 RDL3178 NOT A STEP
INSTRUCTIONS
xKeep all safety signs clean and legible.
xReplace all missing, illegible, or damaged
safety signs.
xReplacement parts for parts with safety
signs attached must also have safety
signs attached.
xSafety signs are available, free of charge,
from your dealer or from FFC
Attachments.
PLACEMENT OR REPLACEMENT OF
SAFETY SIGNS
1. Clean the area of application with non-flammable
solvent, then wash the same area with soap and water.
2. Allow the surface to fully dry.
3. Remove the backing from the safety sign, exposing
the adhesive surface.
4. Apply the safety sign to the position shown in the
diagram above and smooth out any bubbles.
ITEM 1
ITEM 2 ITEM 3 ITEM 4

6
POWER UNIT SPECIFICATIONS
IMPORTANT Exceeding any of the maximum recommended power unit specifications
CAN result in damage to this product and
WILL
void all FFC Attachments warranties.
DESCRIPTION SPECIFICATIONS
Weight of Power Unit without Planer 11,000 lbs. maximum
Operating Capacity of Power Unit’s loader 3,750 lbs. maximum
Lift Capacity of Power Unit’s loader 7,500 lbs. maximum
Hydraulic Pressure Output 3,500 psi. maximum
Rear Ballast As required to maintain full power unit stability.
(see the shipping weight on page 11, then see the
operator’s manual(s) for you power unit, loader, and quick-
attach for your ballasting needs.)
ROTO-TILLER MOUNTING
SAFETY FIRST!! READ AND UNDERSTAND THE SAFETY INSTRUCTIONS (pages 2-5 of this
manual) BEFORE BEGINNING ANY ROTO-TILLER MOUNTING
1. Place this product on a firm, level surface that is large enough to safely accommodate this product, your power unit,
and all workers involved in the mounting process.
2. Refer to the operator’s manual(s) for your power unit, loader, and quick-attach and follow the mounting instructions
contained therein.
3. Carefully raise the loader arms or three point linkage and cycle the tilt cylinders or lower link arms to check clearances
and to verify that all mounting procedures have been successfully completed.
ROTO-TILLER HYDRAULIC CONNECTION
SAFETY FIRST!! READ AND UNDERSTAND THE SAFETY INSTRUCTIONS (pages 2-5 of this
manual) BEFORE BEGINNING ANY ROTO-TILLER HYDRAULIC CONNECTION
1. Disconnect the hydraulic hose quick couplers from one another and attach the quick couplers to your power unit as
per the instructions in your power unit’s operator’s manual.
2. Carefully raise the loader arm and cycle the tilt cylinders to check hose clearances and to check for any interference.
WARNING
Do not lock the auxiliary hydraulics of your tractor or power unit in the “ON”
position. Failure to obey this warning could result in death or serious injury.

7
ROTO-TILLER OPERATION
SAFETY FIRST!! READ AND UNDERSTAND THE SAFETY INSTRUCTIONS (pages 2-5 of this
manual) BEFORE BEGINNING ANY ROTO-TILLER OPERATION
WARNING
Failure to obey the following procedures could result in death or serious injury.
xNever lift the lowest portion of this product higher than 1’-0” above the ground while operating.
xDo not lock the auxiliary hydraulics of your power unit in the “ON” position.
xKeep everyone at least nine feet away from the unit when operating.
xThis product may be operated while moving forward or backward with your power unit.
xThe auxiliary hydraulics must be engaged so that:
¾the tines rotate down into the untilled area in the direction of travel to achieve the fastest tilling speeds
and the most efficient use of power or
¾the tines rotate up from under the untilled area in the direction of travel to achieve greatest conditioning of
the soil.
IMPORTANT Tilling while moving forward with the hinged shroud panel fully down
CAN result in damage to this product and
WILL void all FFC Attachments warranties.
xWhen tilling while moving forward, the hinged shroud panel must be chained up in a horizontal position to avoid
damaging the panel. The hinged shroud panel is not designed to push any soil or other materials.
xYour power unit should be operating at full throttle with the auxiliary hydraulics fully engaged. The speed of the
movement of your power unit should be varied as required to pulverize the soil to extent desired.
xThe maximum tilling depth is 6”. This depth is attained when the motor guard is about 1” below the surface of the
soil. Compacted soils may require two passes to reach this depth.
IMPORTANT Attempting to grind stumps or dig into rigid or frozen materials
CAN result in damage to this product and
WILL void all FFC Attachments warranties.
ROTO-TILLER MAINTENANCE
SAFETY FIRST!! READ AND UNDERSTAND THE SAFETY INSTRUCTIONS (pages 2-5 of this
manual) BEFORE BEGINNING ANY ROTO-TILLER MAINTENANCE
BEFORE EACH USE
xMake sure that all nuts and bolts are in place and properly tightened.
xMake sure that all other fasteners are in place and are performing their specified function.
xMake sure that all hydraulic fittings are tightened and that there are no leaks in any fittings or hoses.
xMake sure that all safety signs are in place, are clean, and are legible.
(SEE THE SAFETY SIGN SECTION ON PAGE 5.)
xReplace any damaged parts and excessively worn parts.
AFTER EVERY 10 HOURS OF USE
xOil the hinge at the top of the hinged shroud panel.
AFTER EVERY 40 HOURS OF USE
xMake sure the taper lock adapter assemblies are tight by turning the bearing locknut by hand.
If the bearing locknut moves by hand, retighten the taper lock adapter assembly as specified in Roto-tiller Service
(on page 8).

8
ROTO-TILLER SERVICE
SAFETY FIRST!! READ AND UNDERSTAND THE SAFETY INSTRUCTIONS (pages 2-5 of this
manual) BEFORE BEGINNING ANY ROTO-TILLER SERVICE
Removing Wire, Twine, Weeds, etc. that are Wrapped Around the Roller
1. Park your power unit on a level surface with this product properly attached.
2. Place your power unit’s transmission in “Park” and engage the parking brake.
3. Lower this product onto preplaced blocking that will support the motor guards of this product so that the tines are not
in contact with the ground.
WARNING
Failure to obey the following procedures could result in death or serious injury.
xDo not use blocking made of concrete blocks, logs, buckets, barrels or any other material that
could suddenly collapse or shift positions. Do not use wood or steel blocking that shows any
signs of material decay. Do not use blocking that is warped, twisted, or tapered.
4. Shut off your power unit’s engine, remove the starter key, wait for all moving parts to come to a stop, and relieve all
pressure in the hydraulic lines.
5. Disconnect the hydraulic lines from your power unit and connect the two ends to each other. This should permit the
tines to rotate freely.
6. Pull the material from the tine shaft while allowing the shaft to rotate.
ALTERNATE METHOD
If your power unit is equipped with safety stops for the lift arms of the loader that can be activated from the operator’s
position or if the safety stops must be activated from outside the operator’s position and a second person is present, then
Step 3 above may be replaced with these steps:
a) Fully raise the lift arms and fully extend the tilt cylinders to the fully dumped position.
b) Activate the safety stops for the lift arms. Test the stops to verify that no downward movement of the lift arms can
occur.
c) Continue with Step 4 above.
Replacing Tines
1. Perform steps 1 through 5 above.
2. Remove the clip and pin that secure the strip; then slide the tine out.
a) If most of the tilling is done in one direction, the tine may be reversed and reinstalled.
NOTICE To achieve the best tilling results, all the tines should be reversed at one time, not just one or two tines
at a time.
b) If the tine is worn out or damaged, properly dispose of the tine and install a new tine.
3. Replace the pin and clip.
4. Repeat the process for all other tines.
Bearing Lock Adjustment
1. Bend the locking tang of the bearing lock washer out to free the bearing lock nut.
2. Loosen the bearing lock nut.
3. Retighten the bearing lock nut until finger - tight.
4. Tighten the lock nut an additional 1-1/4 turns and, if necessary, continue tightening until the first time one tang of the
bearing lock washer is aligned with a notch on the locknut.
5. Bend that tang of the bearing lock washer back into the notch on the lock nut.

9
PARTS ILLUSTRATION

10
ROTO-TILLER: PARTS LIST
LAF3438 LAF3452 LAF3468
ITEM QTY. 38” 52” 68” DESCRIPTION
1 1 DHF2021 Chain: 18 links
2 varies 20 (28) (36) LAF3400 Tine
3 varies (1) (2) (2) LAF3401 Motor Guard
4 varies (1) (2) (2) LAF3402 Motor Mounting Plate
5 varies (1) (2) (2) LAF3403 Motor-Tine Shaft Coupler
6 1
LAF3416 LAF3404 LAF3408 Shroud
7 1
LAF3414 LAF3405 LAF3409 Hinged Shroud Panel
8 1
LAF3415 LAF3406 LAF3411 Hinge Pin
9 1
LAF3413 LAF3407 LAF3410 Tine Shaft Weldment
10 1
Not Used LAF3412 Gusset Grommet
11 1
Not Used Not Used LAF3412 Gusset Grommet
12 2
Not Used LAF4075 Jamb Nut: #10
13 varies (2) (4) (4) LAF4414 Hydraulic Fitting, 10MB-10MJ Straight
14 varies (1) (2) (2) LAF4655 Hydraulic Motor
15 2
Not Used LAF4656
Bulkhead Run Tee 10MJ-10MJ-10MJ
16 2
Not Used LAF4657 Hydraulic Hose: 1/2” dia., 10FJ-10FJ x 4’-0”
17 2
LAF4552
(84”)
LAF4659
(32”)
LAF4657
(48”)
Hydraulic Hose: 1/2” dia., 10FJ-10FJ x Length Noted
18 4 LAF9447 Anti-Slip Abrasive Tape: 4” x 12”
19 1 RHW1108 Grade 5 Hex Head Cap Screw: 5/16” x 1-1/2”
20 1 RHW1112 Grade 5 Hex Head Cap Screw: 5/16” x 2-1/2”
21 varies (4) (8) (8) RHW1406 Grade 5 Hex Head Cap Screw: ½ x 1-3/4”
22 varies (1) (2) (2)RHW1714 Grade 5 Hex Head Cap Screw: 3/4” x 4-1/2”
23 16 RHW2405 Grade 5 Carriage Bolt: 1/2” x 1-1/2”
24 varies (2) (1) (1) RHW6102 Grade 5 Lock Washer: 5/16”
25 varies (20) (24) (24) RHW6402 Grade 5 Lock Washer: 1/2”
26 varies (20) (24) (24) RHW7401 Grade 5 Hex Nut: 1/2”, 13 tpi
27 varies (1) (2) (2) RHW7703 Grade 5 Locknut: 3/4”
28 varies (22) (30) (38) RHW8011 Grade 2 Cotter Pin: 1/8” x 1-1/4”
29 1 RHW8098 Grade 2 Fender Washer 5/64” x 5/16” x 1-1/2”
31 varies (20) (28) RHW8134 (36) Grade 8 Clevis Pin: 1/2” x 1-1/4”
32 1 RHW8317 D-Shackle With 5/16” Dia. Round Pin & Cotter Pin, Galvanized
33 1 RHW8613 Weld Plate: 5/16” Dia. Threaded Hole
34 1 RHW8614 Cover Plate For Hose Clamp Cradles
35 2 RHW8616 Clamp Cradle For (2) 7/8 O.D. Hoses
36 1 RHW8618 Spring: 1-1/2” x 11-5/8” With 7-1/4” Coil
37 2 RMR5002 Nylon Cable Ties: 1/4” x 11”
38 1 Contact FFC to obtain correct item Hydraulic Hose Protector: 1-7/8”
39 2
Not Used 03-10025 03-10025 Hydraulic Hose: 5/8” ID with (1) #10 Female JIC Fitting
40 2 Contact FFC to obtain correct item Hydraulic Elbow (not required on all models).
41 2 Contact FFC to obtain correct item Hydraulic Adapter (not required on all models).
42 1 Contact FFC to obtain correct item Hydraulic Hose Quick Coupler: Male Connection
43 1 Contact FFC to obtain correct item Hydraulic Hose Quick Coupler: Female Connection
44 1
LAF3418 Not Used Not Used Dust Guard
45 1
LAF3512 Not Used Not Used Bearing Taper Lock Adapter
46 1
LAF3513 Not Used Not Used Rotor Bearing
47 1 RHW5162 Grade 5 Flat Washer:5/16”, USS
48 1 RHW7101 Grade 5 Hex Nut: 5/16”
49 1
RHW8091 Not Used Not Used Grease Zerk: ¼”, 90q, Self-tapping, 28 tpi.
50 1
LAF3417 Not Used Not Used Bearing Mount
NOTE: All parts are the same as the LAF3468 except for those parts numbered under the other models.

11
ROTO TILLER SPECIFICATIONS
Model
Number
Overall
Width
Overall
Height
Overall
Depth
Offset to
Right
Torque @
2,500 psi
Shipping
Weight
LAF3438 53” 27” 27” varies 469 ft. lbs. 450 lbs.
LAF3452 67-13/16” 27” 33-1/2” 12-1/2” 939 ft. lbs. 600 lbs.
LAF3468 78-1/4” 27” 33-1/2” 4-3/4” 939 ft. lbs. 695 lbs.
All replacement hydraulic hoses must have a minimum rated working pressure of 4,000 psi.
TORQUE SPECIFICATIONS FOR STANDARD MACHINE HARDWARE
(FOR REFERENCE ONLY)
Bolt Size SAE Grade Bolt Torque Ft./Lbs
0.31 - 18 5 17
0.50 - 13 5 75
0.75 - 10 5 260

Warranty Registration Form and Delivery Inspection Report
IMPORTANT! Warranty Void if card is not returned with 10 days.
All Applicable sections must be filled in.
This section to be filled out and signed by Dealer at time of delivery.
Warranty Registration
Customer’s Name Dealer’s Name
Address Address
City State Zip City State Zip
Phone CHECK ONE:
Loader / Tractor Model Construction Use
Delivery Date Agricultural Use
Model or Part # Landscape Use
Serial # Other:
Dealer Inspection (check items applicable)
All Decals installed (see operator’s manual) Review Operating and Safety Instructions
Hydraulic fittings tight and free of leaks Guards and covers in place and secure
Fasteners tight Does Product Function Properly
I have thoroughly instructed the buyer on the above described equipment. This review included: The Operator’s manual content,
equipment care, adjustments, safe operation and applicable warranty policy.
Date Dealer’s Rep. signature
This section to be completed and signed by the customer
QUALITY ASSURANCE RATING
Question: FFC Local Dealer
Quality of Product: Appearance . . . . . . . . . . . . . . . . . . . . . . . . .
Construction . . . . . . . . . . . . . . . . . . . . . . . . .
Quality of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Value (Priced Fairly) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Does it perform as claimed . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The above described equipment and Operator’s Manual have been received by me and I have been thoroughly instructed
as to care, adjustments, safe operation and applicable warranty policy.
Date: Owner’s signature
NOTE! Make one copy each for the dealer’s and owner’s records. Mail original to FFC Attachments.
Form MR00000-000 Rev. 09/04
FFC Attachments • 100 E. Lee Road • PO Box 122 • Lee, IL 60530 • 800-747-2132 • Fax [phone]
www.ffcattachments.com
123 4 5
Excellent Good Average Unsatisfactory Poor
PLEASE TRI-FOLD AND AFFIX TAPE HERE

FFC LIMITED 12 MONTH WARRANTY
Thank you for purchasing a FFC product. Warranty protection is valid only when this Warranty
Registration is completed and signed by the customer and dealer, and mailed to FFC. I hereby
acknowledge that I have received a copy of the owners Limited Warranty and I accept the terms
therein.
For a period of 12 months from date of delivery of product to the original user, FFC, warrants
each product to be free from manufacturing defects, subject to the limitations contained in this
policy.
This warranty does not apply to defect caused, in whole or in part, by unreasonable use while in
the possession of the user, including, but not limited to: failure to properly set up product; failure
to provide reasonable and necessary maintenance; normal wear; routine tune ups or
adjustments; improper handling or accidents; operation at speed or load conditions contrary to
published specification; improper or insufficient lubrication; improper storage. This warranty is
also not a guarantee that the performance of each product will meet the expectations of the
purchaser.
FFC shall not be liable for consequential damages of any kind, including, but not limited to:
consequential labor costs or transportation charges in connection with the replacement or repair
of defective parts; lost time or expense which may have accrued because of said defects. In no
event shall FFC, Inc.’s total liability hereunder exceed the product purchase price.
FFC makes no warranty with respect to trade accessories or any component or accessory of the
product which was not manufactured by FFC, including any purchased components on any kind.
These are subject to the warranties of their respective manufacturers. The warranty will be
considered void if the product or any part of the product is modified or repaired in any way not
expressly authorized by FFC, or if closed components are disassembled prior to return. Closed
components include, but are not limited to: gearboxes, hydraulic pumps, motors, cylinders, and
actuators.
Our obligation under the warranty is expressly limited, at our option, to the replacement or repair
at FFC, of Lee, Illinois, or at a service facility designated by us, or such part or parts as inspection
shall disclosed to have been defective. We are not responsible for unauthorized repairs or
replacements. Any implied or statutory warranties, including any warranty of merchantability or
fitness for a particular purpose, are expressly limited to the duration of this written warranty. We
make no other express or implied warranty, nor is anyone authorized to make any in our behalf.
This warranty cannot be extended, broadened, or changed except in writing by an authorized
officer of FFC.
