FINO FINOSINT KOMPAKT Operation manual

Gebrauchsinformation
•
User Information
•
Mode
d’emploi
Inform ac i ó n sob r e el us o
•
In f orm a zio ni d ’ uso
G e b r u i k s a a n w i j z i n g
•
I n s t r u k c j a
FINO • der feine Unterschied • the fine difference • la fine différence • la fina diverencia • la fine differenz
a
Original FINO
Germany
FINO
SINT KOMPAKT
Hochtemperatur
-
Sinterofen
High-Temperature Sinter Furnace
6839

2
Version 1/2 17. Read the User Manual prior to commencing work.
ABLE OF CON EN S
1. General Information
• Limitation of liability • Responsibilities of the operator
2. Documentation
• Content and structure • Labelling scheme • Formatting and symbols
3. Safety
• Requirements for personnel
4. ransport, packaging, storage
• ransport • Packaging • Storage
5. echnical description
• Function • Intended use • Potential misuse
6. echnical Data
7. Installation
• Installation location • Local installation
8. Operation
• Operating elements and displays • Switching on the sintering oven
9. Initial commissioning
• Feeding the sintering oven • Selecting and loading a heating program • Starting/stopping a
heating program • Removing the sintering dish from the heating oven • Programming the
heating phases • Programming phase temperatures, holding times • Saving the heating
program • Starting a heating program automatically • Preparing the sintering aid •
Recommended filling of the standard sintering dish • Sintering with the sintering disc
10. Basic settings
• Parameter settings • Setting the day and the time • Switching off the sintering oven
11. RS-232 interface
12. Care and maintenance
• Service programs
13. Faults and error messages
• Safety • Faults • Error messages
14. Decommissioning
15. Disposal

1. General Information
1.1 Limitation of liability
The content of this operating manual has been created taking the applicable laws and standards into ac-
count. The unit has been developed using state-of-the-art technology.
1.2 Responsibilities of the operator
The unit is used for commercial purposes. The operator of the unit is therefore subject to the statutory obliga-
tions relating to occupational safety.
In addition to the safety instructions in this operating manual, the regulations on safety, accident prevention
and environmental protection that apply to the unit's field of use must be complied with.
In particular, the following apply:
•The operator must be familiar with the applicable occupational safety regulations.
•The operator must ensure that all employees who use the unit have read and understood this operating
manual.
•The operator must also train personnel at regular intervals and inform them of the dangers that can arise
when using the unit.
•The operator must provide personnel with the necessary protective equipment.
•The operator must have all safety devices checked regularly for operability and completeness.
NO ICE
he manufacturer assumes no liability for damage resulting from:
➤ Disregard/non-observance of the operating manual
➤ Intentional misuse
➤ Use other than as intended
➤ Operation by untrained personnel
➤ Operation by lay persons (to carry out maintenance work, etc.)
➤ Technical modifications to the unit that have not been agreed with the manu-
facturer
➤ Use of replacement parts that have not been approved by the manufacturer

4
2. Documentation
2.1 Content and structure
This operating manual is an essential part of this unit. It contains instructions and information on how to use
the unit safely and must be available to all users throughout the unit's service life. This operating manual is
intended for use by trained operating personnel.
2.2 Labelling scheme for integrated text boxes and references
The following safety notices are used in this manual:
2.3 Formatting and symbols
indicates a general safety instruction
indicates that a requirement must be met
1.
indicates a step to be carried out
indicates the outcome of carrying out a step
•
indicates a list
indicates a button
DANGER
Indicates an imminent danger
that may cause serious physical injury or
death.
WARNING
Indicates a potentially dangerous si
tuation that may cause serious
physical
injury or death.
CAU ION
Indicates a potentially dangerous
situation that may cause minor
physical
injury.
NO ICE
Indicates a potentially dangerous
situation that may cause minor
physical
injury.
NO ICE
Information or tips for easier operation.

5
ENG
3. Safety
The FINOSINT KOMPAKT High-Temperature Sinter Furnace High-Temperature Sinter Furnace is a high-
temperature oven for commercial use in dental laboratories and may be used only for sintering sinterable
ceramics.
3.1 Requirements for personnel
Trained and qualified personnel who know how to use the unit and whose specialist training, skills, experi-
ence and knowledge of the relevant regulations enables them to carry out the tasks assigned to them inde-
pendently and recognise and avoid potential hazards.
DANGER
Electricity
!
Risk of death from electric shock.
➤ Do not touch live cables and components with wet hands.
➤ Observe the accident-prevention regulations when working with electric cur-
rent.
➤ Before carrying out any installation, maintenance, cleaning or repair work,
disconnect the power supply of the sintering oven (pull out mains plug) and
secure it against being switched back on.
DANGER
Risk of ignition!
Use of inflammable and explosive materials near the oven.
➤ Do not operate the sintering oven near highly inflammable sources.
➤ Do not install the sintering oven on highly inflammable supporting surfaces.
WARNI
NG
Risk of burns from hot surfaces!
The surfaces of the sintering oven become hot during operation.
These may cause burns if touched.
➤ Do not touch the housing or the oven door during operation.
➤ Do not reach into the heating chamber. It may still retain a high level of resi-
dual heat from the previous heating process.
➤ Ensure that the sintering oven has cooled down before carrying out mainte-
nance, cleaning and repair work.
➤ Wear heat-resistant safety gloves if it is necessary to carry out work on hot
components.
➤ Use a suitable and sufficiently long pair of tongs to place items to be sintered
into the oven and remove sintered items from the oven.

6
CAU ION
Incorrect operation!
No liability is assumed for damage that may be caused by misuse, incorrect
operation, incorrect connections or improper maintenance/repair work carried out
by untrained personnel. All warranty services are also excluded in such cases.
The unit must not be used if it or the mains cable becomes damaged and no
longer functions correctly. In this case contact the manufacturer immediately.
For your own safety and to increase the service life of your unit, use only original
replacement parts.
To ensure safe operation of the sintering oven, regional regulations (e.g. acci-
dent-prevention regulations) apply in addition to the instructions in this operating
manual. The former must be made available by the operator of the unit. The
safety notices on the sintering ovenmust be kept in a legible condition.
NO ICE
This operating manual must be read and understood by each user before working
on and with the unit.
The operating manual must be kept for the specified service life of the sintering
oven.

7
ENG
4. ransport, Packaging, Storage
4.1 ransport
WARNI
NG
Injury due to the sintering oven falling down!
Slipping/falling when lifting and carrying the sintering oven can lead to serious
injuries.
➤ Only carry/hold the sintering oven at the lower edge of the housing (base).
➤ Always have at least two persons carry the sintering oven (max. 3
kg/person).
CAU ION
Risk of injury due to oven weight!
Physical strain/back injuries due to the high inherent weight.
➤ Have at least two persons carry/move the sintering oven together.
NO ICE
ransport damage!
To prevent injury to personnel and material damage:
➤ Transport the unit in an upright position only.
➤ Do not stack units on top of each other.
➤ Do not place any other objects on the unit.
➤ Transport must be as free of shaking and vibrations as possible to prevent the
unit from being damaged.
➤ Make sure that the unit is secured against slipping and falling during transport.
➤ The goods must be inspected for damage and loss immediately upon receipt.
Defects must be documented by the freight carrier on the letter of consignment
in order to lodge claims. The manufacturer assumes no liability for any dama-
ge and loss that is only found subsequently.

8
3.2 Packaging
3.3 Storage
4. echnical description
4.1 Function
The FINOSINT KOMPAKT High-Temperature Sinter Furnace is used to fire sinterable ceramics.
The product to be sintered is placed in the sintering dish and set on the support pins in the combustion
chamber.The heat-up process starts after entering the heating parameters and pressing the Start button.
Once the heating program has ended and the sintering oven has cooled down, the finished product can be
removed from the oven.
Heating chamber
The product is sintered in the heating chamber. This consists of two different ceramic insulation layers and is
operated using four heating elements connected in series. The outer insulating layer is designed for tempera-
tures up to 12 °C; the inner layer for temperatures up to 165 °C.
Oven door
The oven door consists of a two-part ceramic door panel. A safety switch disconnects the heating current as
soon as the oven door is opened.
The oven door has an electronic lock and can be opened only if the temperature is below 3 °C.
Oven housing
The oven housing consists of steel plate coated with plastic on both the inside and the outside and is cooled
by a permanent ventilation system.
NO ICE
The packaging protects the sintering oven against transport damage, corrosion
and other forms of damage. Only remove it shortly before initial commissioning
and store it in dry conditions for later reuse.
NO ICE
emperature damage!
To prevent temperature damage:
➤ Store the unit only at temperatures between +5 and +4 °C.
➤ Always store the unit in dry and dust-free conditions.
➤ Avoid exposure to direct sunlight.
➤ Avoid mechanical vibrations.

9
ENG
Program controller
The program controller has a finishing-time setting that can be used to specify a day and time for the program
to finish. The switch-on time is calculated automatically so that the heating process is stopped at the required
time and the sintered item can be removed.
Operating parameters and heating programs are stored in a non-volatile memory and are retained even if the
power supply fails.
The set target temperature is maintained within an accuracy of ± 1 °C. A temperature sensor integrated into
the heating chamber measures the temperature of the chamber close to the product.
A thermocouple fail-safe prevents the sintering oven from overheating if the temperature sensor becomes
defective.
4.2 Intended use
The FINOSINT KOMPAKT High-Temperature Sinter Furnace is a high-temperature oven for commercial
application in dental laboratories and may be used only for sintering sinterable ceramics using original spare
parts.
At a total output >1kW, no limit values for the harmonics apply.
4.3 Potential misuse
•Operation by untrained and insufficiently qualified personnel.
•Use of products that have not been approved by the manufacturer.
•Use of replacement parts that have not been approved by the manufacturer.
•Any use not in accordance with the declaration of conformity.
•Technical modifications to and conversions of the unit that have not been approved by the manufacturer.
NO ICE
The protection of persons can no longer be ensured and no liability can be assu-
med for damage that is caused by misuse, incorrect operation, incorrect connec-
tions or improper maintenance/repair work carried out by untrained personnel. All
warranty services are also excluded in such cases.
The use of spare and wearing parts that have not been procured from the manu-
facturer will render the approval and guarantee of the sintering oven null and
void.

10
5. echnical Data
General information
Dimensions (W x D
x H)
4 x 4 x 6 mm
Combustion chamber volume
1 dish
ø 1 x 35 mm
Max. t
emperatur
e
155 °C
Weight
55 kg
Minimum clearance around the sintering oven
5 mm
Connected electrical load
Voltage supply
2
-
24 V
Frequency
5 /6 Hz
Max. power
consumption
17 W
Protection
Device end
1 AT
Customer end
Connection to a separate electrical circuit with a 16
-
A
circuit breaker, type K or type Z (other types of circuit
breaker depending on the country of use)
Protection class
IP 2 (
protection against the ingress of foreign bo-
dies, but not against the ingress of water)
Operating conditions
Installation area
Indoors only (in dry rooms)
Temperature range
+5 to +4 °C
Relative air humidity
Up to 31 °C: 8 %
Maximum air humidity
Up to 4 °C: 5 % No condensation
Height
Max. 2 m
Pollution degree
2

11
ENG
Combustion chamber
Image 1: Combustion chamber volume
Max. useful space of the combustion chamber (WxDxH): 1 x 115 x 45 mm
Image 2: Combustion chamber volume, max. filling

12
6. Installation
6.1 Installation location
The FINOSINT KOMPAKT High-Temperature Sinter Furnace is designed as a table-top unit. To ensure
stability, we recommend a level surface of at least 5 cm x 6 cm that can support a load of up to 6 kg.
Installation conditions
➤ Always install the sintering oven in dry rooms that are as dust-free as possible and make sure that liquids
cannot penetrate the unit.
➤ Highly inflammable and combustible gases and liquids must not be stored in the installation rooms.
➤ Do not place any combustible and inflammable objects near the sintering oven.
➤ Keep a distance of 5 mm around the sintering oven for sufficient cooling.
1. Align the supporting surface horizontally.
Lift and carry the sintering oven only at the unit base.
2. Place the sintering oven on the supporting surface.
Make sure the surface is non-slip.
CAU ION
ipping loads!
Supporting surface with an insufficient load-bearing capacity.
➤ When installing the sintering oven, make sure that the supporting surface has
a sufficient load-bearing capacity.
CAU ION
Risk of injury due to oven weight!
Physical strain/back injuries due to the high inherent weight.
➤ Have at least two persons carry/move the sintering oven together (max. 3 kg
load bearing capacity/person).
CAU ION
Risk of overheating!
In the event of overheating, the electronic system will switch the heater off.
➤ Make sure that the air vents remain clear on all sides.

13
ENG
Electrical connection
7.2 Local installation
The sintering oven requires its own electrical circuit.
The building's electrical circuit must have a type-K or type-Z circuit breaker with a rated current of at least
16 A (other types of circuit breaker depending on the country of use).
An additional residual-current circuit breaker (designed for 3 mA tripping current) must be installed.
To ensure electrically safe operation, the sintering oven requires a protective earth conductor connected
to the power socket.
When selecting the installation location, ensure that the accompanying mains cable is 2. m long. Ex-
tending the cable is not permitted. The supply voltage must be within the rated voltage range of 2 - 24
V (see section „Technical Data“).
WARNI
NG
Release of pollutants!
Pollutants can be inhaled when the insulating materials are handled.
➤ Wear personal protective equipment (respiratory protection) during disposal.
DANGER
Electricity
!
Risk of death from electric shock.
➤ Do not touch live cables and components with wet hands.
➤ Observe the accident-prevention regulations when working with electric cur-
rent.
➤ Only connect the unit to a voltage supply that matches the specifications on
the rating plate.

14
8. Operation
8.1 Operating elements and displays
The microprocessor-controlled program controller enables a wide range of heating curves to be run through
with high precision. The unit is operated via a membrane keyboard and menus displayed on a 7-segment
screen.
The program controller has the following operating elements:
1
Function display
5
Program phase
2
Week day/Time
6
Current program
3
Door opener
7
Navigation buttons
4
Start/Stop
8
Main on/off switch
8.1.1 Operating elements
Function:
Mains switch; lights up when switched on (at bottom switch position)
Mains switch; lights up when switched on (at bottom switch position)
Increases the value
Decreases the value
Activates programming mode

15
ENG
Starts/stops the program
Activates the door opener
8.1.2 Displays
Function:
In heating mode: Displays the oven temperature/holding time.
In programming mode: Displays the increase rate/holding temperature/holding time.
Displays the current program phase.
Displays the current program number.
In standby mode: Displays the day (1 = Mon, 2 =
Tue, 3 = Wed, etc.) and time
(hh:mm).
In heating mode: Displays the finishing time.
LED lights up orange when finishing-time mode is activated.
LED lights up greenwhen heating mode is activated.
Oven door is open.

16
8.2 Switching on the sintering oven
1. Connect the voltage supply.
2. Switch the sintering ovenon at the mains switch.
The mains-switch indicator lamp lights up.
The current temperature of the oven is displayed after approx. three seconds.
9. Initial commissioning
9.1 Feeding the sintering oven
The ceramic door panel is extremely porous and sensitive to scratching and impacts.
1
Switch the
sintering oven on.
2
Press the door opener
button.
The electronic door lock is released for three seconds and the oven door can be
opened.
3Place the supporting stone in the sintering oven.
4Fill the standard sintering dish included in the scope of delivery (you can find more information about filling
the sintering dish in the section „9.9 Preparing the sintering aid“).
5Place the item to be sintered into the standard sintering dish.
6Once filled, use a pair of tongs to place the standard sintering dish on the support pins.
7Close the oven door.
8Start a firing program by pressing the Start/Stop button.
NO ICE
Check the basic settings of the sintering oven (see “1 . Basic settings”).
NO ICE
The oven door has an electronic lock and can only be opened if the temperature
is below 3 °C.

17
ENG
9.2 Selecting and loading a heating program
1Press the Right-hand arrow button until the LED under the "Prog." display lights up.
2Select a program (1 - 9) using the and buttons.
9.3 Starting/stopping a heating program
Requirements:
The sintering oven has been fed
The heating program has been loaded
1Press the Start/Stop button.
The heating program starts.
While the program is running:
The function display shows the oven temperature or the remaining holding time.
The day/time display shows the finishing time of the program.
The respective target temperature can be displayed by pressing the Right-hand arrow button.
The program can be stopped at any time by pressing the Start/Stop button.
Pressing the Start/Stop button again restarts the program from the beginning.
9.3 Removing the sintering dish from the heating oven
Requirements:
The sintering oven has cooled down to 3 °C to enable the oven door to be opened.
1Guide the tongs under the sintering dish and lift it off the support pins.
2Place the sintering dish on a suitable heat-resistant surface.

18
9.4 Programming the heating phases
1Press the Right-hand arrow button until the LED under the "Prog." display lights up.
2Select a program (1 - 9) using the and buttons.
3Press and hold the Programmingbutton until the function display shows that it is ready for
input.
The LED flashes.
9.5 Programming phase temperatures and holding times
Entering the heating parameters for phase 1:
2Select the temperature by pressing the Right-hand arrow button.
3Select the temperature using the and buttons.
4Select the holding time by pressing the Right-hand arrow button.
5Select the holding time using the and buttons.
NO ICE
Up to nine different heating programs can be set in the program controller.
NO ICE
If a button is not pressed within 6 seconds in Programming mode,
the program controller will skip back to the previous display.
NO ICE
In programming mode,
individual heating curves can be specified by
setting up to four phases.
1Select the heating speed using the and buttons.
The minimum heating speed is 1 °C/min (2 °F/min),
the maximum heating speed is 25 °C/min (54 °F/min).
NO ICE
The maximum temperature is
155
°C (2786
°F).

19
ENG
6
Navigate to the level selection u
sing the Right
-
hand arrow
button
.
The levels are selected using the and buttons.
7
Carry out steps 1 to 5 for additional phases.
9.6 Saving the heating program
After programming the specific heating parameters for a phase, you can exit programming mode.
1To exit programming mode, press and hold the Program button until the LED under the
function display lights up permanently.
The program has been permanently saved.
9.7 Starting a heating program automatically
The sintering oven can be programmed via an integrated timer so that it finishes the heating program
currently loaded at a specific finishing time. The integrated timer is used to specify the day and time at which
a program should finish.
1Select a program.
2Activate the timer by pressing both of the Arrow buttons.
The “weekday" LED (item A) lights up.
NO ICE
The maximum holding time is 999 minutes.
If a longer holding time is required, another phase must be added.

20
4Press the Right-hand arrow button.
The orange “Time" LED lights up.
5Select the hour using the and buttons.
6Press the Right-hand arrow button.
7Select the minutes using the and buttons.
8Press the Right-hand arrow button to finish entering the finishing time.
A toggles between weekday/time of completion
B displays Autostart mode
C shows selected program
3Select a day of the week using the and buttons.
(1 = Mon, 2 = Tue, 3 = Wed, etc.).
NO ICE
The next day is preselected automatically when the
timer is activated.
