Coleman TM8V*C Quick start guide

TECHNICAL GUIDE
80% TWO STAGE VARIABLE SPEED ECM
MULTI-POSITION RESIDENTIAL
GAS FURNACES STANDARD & LOW NOx
MODELS: TM8V*C / TMLV*C
NATURAL GAS
60 - 120 MBH INPUT
Due to continuous product improvement, specifications are
subject to change without notice.
Visit us on the web at www.york.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY
A 20-year limited warranty on heat exchangers in residen-
tial applications.
A 10-year warranty on the heat exchanger in commercial
applications.
Standard 5-year limited Parts warranty.
Extended 10-year limited parts warranty when product
is registered online within 90 days of purchase for
replacement or closing for new home construction.
See Limited Warranty certificate in Users Information Manual for details.
1071765-CTG-A-0913
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
These compact units employ induced combustion, reliable hot
surface ignition and high heat transfer aluminized tubular heat
exchangers. The units are factory shipped for installation in
upflow or horizontal applications and may be converted for
downflow applications.
These furnaces are designed for residential installation in a
basement, closet, alcove, attic, recreation room or garage and
are also ideal for commercial applications. All units are factory
assembled, wired and tested to assure safe dependable and
economical installation and operation.
These units are Category I listed and may be common vented
with another gas appliance as allowed by the National Fuel Gas
Code.
FEATURES
• Two stage heating operation includes two stage gas valve,
two stage inducer operation and variable speed ECM blower
operation. Adjustable delay timer allows two stage operation
with a single stage thermostat.
• Easily applied in upflow, horizontal left or right, or downflow
installation with minimal conversion necessary.
• Compact, easy to install, ideal height 33" tall cabinet.
• ECM variable speed drive for cooling SEER enhancement,
improved comfort with optional airflow delay profiles, and
continuous fan options for IAQ performance.
• Easy access to controls to connect power/control wiring.
• Built-in, high level self diagnostics with fault code display.
• Low unit amp requirement for easy replacement application.
• All models are convertable to use propane (LP) gas.
• Electronic Hot Surface Ignition saves fuel cost with increased
dependability and reliability.
• 100% shut off main gas valve for extra safety.
• 24V, 40 VA control transformer and blower relay supplied for
add-on cooling.
• Hi-tech tubular aluminized steel primary heat exchanger.
• Solid removable bottom panel allows easy conversion.
• Airflow leakage less than 1% of nominal airflow for
ductblaster conditions.
• No knockouts to deal with, making installation easier.
• Movable duct connector flanges for application flexibility.
• Quiet inducer operation, burner, and blower operation.
• Inducer rotates for easy conversion of venting options.
• Fully supported blower assembly for easy access and
removal of blower.
• External air filters used for maximum flexibility in meeting
customers IAQ needs.
• Insulated blower compartment for thermal and acoustic
performance.
• Low NOx models have been designed to meet specific code
requirements.
• Venting applications - may be installed as a common vent
with other gas-fired appliances or use a masonry chimney.
• 1/4 turn knobs provided for easy independent door removal.
• These models may be connected as part of a communicating
control system using a 4-wire connection bus.

1071765-CTG-A-0913
2Johnson Controls Unitary Products
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
LEFT SIDE RIGHT SIDE
.5”
.5”
RETURN END
B
24.25”
29.5”
28.5”
Electrical
Entry
Gas Pipe
Entry
Thermostat
Wiring
FRONT
14”
1”
1.5”
23”
SUPPLY END
C
24.38”
20”
.5”
B
Gas Pipe
Entry
Thermostat
Wiring
33”
A
.5”
Electrical
Entry
Vent Connection
Outlet
Vent
Connection
Outlet
4” Diameter
Outlet
Vent Connection
Cabinet & Duct Dimensions
Model Nominal
CFM (m3/min) Cabinet
Size Cabinet Dimensions (Inches)
ABC
TM(8,L)V060A12MP11C 1200 A 14 1/2 13 3/8 10.3
TM(8,L)V080B12MP11C 1200 B 17 1/2 16 3/8 11.8
TM(8,L)V080C16MP11C 1600 C 21 19 7/8 13.6
TM(8,L)V100C16MP11C 1600 C 21 19 7/8 13.6
TM(8,L)V100C20MP11C 2000 C 21 19 7/8 13.6
TM(8,L)V120C20MP11C 2000 C 21 19 7/8 13.6
Table 1: Ratings & Physical / Electrical Data
Models High Fire
Input Low Fire Input High Fire Output Low Fire Output Nominal Airflow Total Unit
Amps
Max.
Over-current
Protect
Max. Outlet
Air Temp
MBH MBH MBH MBH CFM °F
TM(8,L)V060A12MP11C 60 39 47 31 1200 9.0 10 160
TM(8,L)V080B12MP11C 80 52 63 42 1200 9.0 10 160
TM(8,L)V080C16MP11C 80 52 63 42 1600 12.0 15 160
TM(8,L)V100C16MP11C 100 65 80 52 1600 12.0 15 160
TM(8,L)V100C20MP11C 100 65 80 52 2000 14.0 20 160
TM(8,L)V120C20MP11C 120 78 96 62 2000 14.0 20 160
Models
High Fire
Air Temp.
Rise
Low Fire
Air Temp. Rise Blower Blower
Size AFUE Min. wire Size
(awg) @ 75 ft
one way
Operating
weight
°F °F HP Amps In. % Lbs.
TM(8,L)V060A12MP11C 30-60 15-45 1/2 7.7 11 x 8 80.0 14 94
TM(8,L)V080B12MP11C 30-60 20-50 1/2 7.7 11 x 8 80.0 14 103
TM(8,L)V080C16MP11C 30-60 20-50 3/4 9.6 11 x 10 80.0 14 114
TM(8,L)V100C16MP11C 30-60 20-50 3/4 9.6 11 x 10 80.0 14 118
TM(8,L)V100C20MP11C 30-60 20-50 1 12.8 11 x 11 80.0 12 122
TM(8,L)V120C20MP11C 30-60 20-50 1 12.8 11 x 11 80.0 12 129

1071765-CTG-A-0913
Johnson Controls Unitary Products 3
HORIZONTAL SIDEWALL VENTING
For applications where vertical venting is not possible, the only
approved method of horizontal venting is the use of an auxiliary
power vent. Auxiliary power venters must be approved by CSA,
UL, or other recognized safety agencies. Follow all application
and installation details provided by the manufacturer of the
power vent.
FILTER PERFORMANCE
The airflow capacity data published in the “Blower Perfor-
mance” table shown represents blower performance WITHOUT
filters.
All applications of these furnaces require the use of field
installed air filters. All filter media and mounting hardware or
provisions must be field installed external to the furnace cabi-
net. DO NOT attempt to install any filters inside the furnace. 1. Air velocity through throwaway type filters may not exceed 300 feet per min-
ute (91.4 m/min). All velocities over this require the use of high velocity fil-
ters.
2. Do not exceed 1800 CFM using a single side return and a 16x25 filter. For
CFM greater than 1800, you may use two side returns or one side and the
bottom or one return with a transition to allow use of a 20x25 filter.
ACCESSORIES
Propane (LP) Conversion Kit -
1NP0347 - All Models
This accessory conversion kit may be used to convert natural
gas units for propane (LP) operation.
Side Return Filter Racks -
1SR0200 - All Models
1SR0302 - All Models
1SF0101 - All Models
Bottom Return Filter Racks -
1BR0514 or 1BR0614 - For 14-1/2” cabinets
1BR0517 or 1BR0617 - For 17-1/2” cabinets
1BR0521 or 1BR0621 - For 21” cabinets
1BR05xx series are galvanized steel filter racks. 1BR06xx are
pre-painted steel filter racks to match the appearance of the fur-
nace cabinet.
Masonry Chimney Kits -
1CK0603
1CK0604
For installations where these furnaces are vented using existing
or new lined masonry chimneys.
Combustible Floor Base Kit -
For installation of these furnaces in downflow applications
directly onto combustible flooring material, These kits are
required to prevent potential overheating situations. These kits
are also required in any applications where the furnace in
installed in a downflow configuration without an evaporator coil,
where the combustible floor base kit provides access for com-
bustible airflow.
1CB0514 - For 14-1/2” cabinets
1CB0517 - For 17-1/2” cabinets
1CB0521 - For 21” cabinets
High Altitude Pressure Switches -
For installation where the altitude is less than 5,000 feet it is not
required that the pressure switch be changed. For altitudes
above 5,000 feet, see kits below.
1PS3309
Thermostats - Compatible thermostat controls are available
through accessory sourcing. For optimum performance, these
indoor units are fully compatible with the Residential Touch-
screen Communicating Control S1-TTSCC01.
Single side return above 1800 CFM is approved as long as
the filter velocity does not exceed filter manufacturer’s rec-
ommendation and a transition is used to allow use on a
20x25 filter.
Recommended Filter Sizes
CFM Cabinet
Size Side (in) Bottom (in)
1200 A 16 x 25 14 x 25
1200 B 16 x 25 16 x 25
1600 C 16 x 25 20 x 25
2000 C (2) 16 x 25 20 x 25
NOTICE
Unit Clearances to Combustibles (All dimensions in inches, and all surfaces identified with the unit in an upflow configuration)
Application Top Front Rear Left
Side Right Side Flue Floor/ Bottom Closet Alcove Attic Line Contact
Upflow 1 1 0 0 0 6 Combustible Yes Yes Yes No
Upflow B-Vent 1 1 0 0 0 1 Combustible Yes Yes Yes No
Downflow 1 1 0 0 0 6 11
1. Special floor base or air conditioning coil required for use on combustible floor.
Yes Yes Yes No
Downflow B-Vent 1 1 0 0 0 1 11Yes Yes Yes No
Horizontal 1 1 0 0 0 6 Combustible No Yes Yes Yes2
2. Line contact only permitted between lines formed by the intersection of the rear panel and side panel (top in horizontal position) of the furnace jacket and build-
ing joists, studs or framing.
Horizontal B-Vent 1 1 0 0 0 1 Combustible No Yes Yes Yes2

Subject to change without notice. Published in U.S.A. 1071765-CTG-A-0913
Copyright © 2013 by Johnson Controls, Inc. All rights reserved. Supersedes: 523198-UTG-D-0513
York International Corp.
5005 York Drive
Norman, OK 73069
AIR FLOW DATA
HIGH / LOW SPEED COOLING AND HEAT PUMP CFM
TM(8,L)V060A12MP11C TM(8,L)V080B12MP11C Jumper Settings
High Low High Low COOL Tap ADJ Tap*
1309 851 1331 865 A B
1108 720 1090 708 B B
1190 774 1210 786 A A
1007 655 991 644 B A
1071 696 1089 708 A C
901 586 891 579 C B
906 589 892 580 B C
686 446 636 413 D B
819 532 810 526 C A
624 406 578 410 D A
737 479 729 474 C C
553 403 520 410 D C
TM(8,L)V080C16MP11C TM(8,L)V100C16MP11C Jumper Settings
High Low High Low COOL Tap ADJ Tap*
1794 1166 1765 1147 A B
1570 1020 1568 1019 B B
1631 1060 1605 1043 A A
1427 928 1425 926 B A
1468 954 1444 939 A C
1351 878 1331 865 C B
1284 835 1282 833 B C
1115 725 1086 706 D B
1228 798 1210 786 C A
1014 659 987 642 D A
1105 718 1089 708 C C
913 593 888 577 D C
TM(8,L)V100C20MP11C TM(8,L)V120C20MP11C Jumper Settings
High Low High Low COOL Tap ADJ Tap*
2230 1450 2200 1430 A B
1792 1165 1826 1187 B B
2030 1320 2065 1342 A A
1629 1059 1660 1079 B A
1827 1188 1858 1208 A C
1584 1030 1642 1067 C B
1466 953 1494 971 B C
1382 898 1401 911 D B
1440 936 1493 970 C A
1256 816 1274 828 D A
1296 842 1344 874 C C
1130 734 1147 746 D C
HIGH / LOW HEAT CFM
TM(8,L)V060A12MP11C TM(8,L)V080B12MP11C Jumper Settings
High Low High Low HEAT Tap ADJ Tap*
1111 963 1480 1284 AAny
988 825 1317 1100 BAny
889 722 1185 963 CAny
808 642 1077 856 DAny
TM(8,L)V080C16MP11C TM(8,L)V100C16MP11C Jumper Settings
High Low High Low HEAT Tap ADJ Tap*
1480 1289 1851 1604 AAny
1317 1100 1646 1375 BAny
1185 960 1481 1204 CAny
1077 855 1347 1070 DAny
TM(8,L)V100C20MP11C TM(8,L)V120C20MP11C Jumper Settings
High Low High Low HEAT Tap ADJ Tap*
1851 1604 2220 1925 AAny
1646 1375 1975 1651 BAny
1481 1204 1778 1444 CAny
1347 1070 1616 1284 DAny
All CFM’s are shown at 0.5” w.c. external static pressure.These units have variable speed motors that automatically adjust to provide constant CFM from 0.0” to 0.6” w.c.
static pressure. From 0.6” to 1.0” static pressure, CFM is reduced by 2% per 0.1” increase in static. Operation on duct systems with greater than 1.0” w.c. external static
pressure is not recommended.
NOTE: At some settings, LOW COOL and/or LOW HEAT airflow may be lower that what is required to operate an airflow switch on certain models of electronic air clean-
ers. Consult the instructions for the electronic air cleaner for further details.
* The ADJ “D” tap should not be used.
