Firenzi FCB 285 User manual

REFRIGERATOR-
FREEZER
FCB 285
INSTRUCTION BOOKLET
2222 010-11

2
IMPORTANT SAFETY INFORMATION
It is most important that this instruction book should be retained with the appliance or uture
re erence. Should the appliance be sold or trans erred to another owner, or should you move house and
leave the appliance, always ensure that the book is le t with the appliance in order that the new owner
can get to know the unctioning o the appliance and the relevant sa ety in ormation.
This in ormation has been provided in the interest o sa ety.You MUST read it care ully be ore installing
or using the appliance.
Installation
• This appliance is heavy. Care should be taken when
moving it.
• It is dangerous to alter the speci ications or attempt
to modi y this product in any way.
• Care must be taken to ensure that the appliance
does not stand on the electrical supply cable.
Important: i the supply cable is damaged, it must
be replaced by a special cable available rom your
local Service Force Centre.
• Any electrical work required to install this appliance
should be carried out by a quali ied electrician or
competent person.
• Parts which heat up should not be exposed.
Whenever possible, the back o the appliance
should be close to a wall but leaving the required
distance or ventilation as stated in the installation
instructions.
• The appliance should be le t or 2 hours a ter
installation be ore it is turned on, in order to allow
the re rigerant to settle.
Child Sa ety
• Do not allow children to tamper with the controls or
play with the product.
• Keep all packaging well away rom children.
General Sa ety
• This appliance contains hydrocarbons in its
cooling unit; maintenance and recharging must
there ore only be carried out by authorized
technicians.
• Take utmost care when handling your appliance
so as not to cause any damages to the cooling
unit with consequent possible luid leakages.
•The appliance must not be located close to
cookers, radiators or boilers.
•Avoid prolonged exposure o the appliance to
direct sunlight.
•Do not use other electrical appliances (such as
ice cream makers) inside o re rigerating
appliances.
During Use
• This appliance is designed or domestic use only,
speci ically or the storage o edible oodstu s.
• Frozen ood must NOT be re- rozen once it has
thawed out.
• Do not place carbonated or izzy drinks in the
reezer.
• Do not remove items rom the reezer i your
hands are damp/wet, as this could cause skin
abrasions or rost/ reezer burns.
• Ice lollies can cause ‘ rost/ reezer burns’ i
consumed straight rom the reezer.
• Manu acturers’ storage recommendations should
be strictly adhered to. Re er to relevant
instructions.
• The cooling plate or re rigerated reezer shelves
in this appliance contain channels through which
the re rigerant passes. I these are punctured this
will cause substantial damage to the appliance
and result in ood loss. DO NOT USE SHARP
INSTRUMENTS to scrape o rost or ice. Under
NO circumstances should solid ice be orced o
the lining or shelves. Solid ice should be allowed
to thaw, when de rosting the appliance. See
De rost Instructions.
Maintenance and Cleaning
• Switch o and unplug the appliance be ore
carrying out any cleaning or maintenance work.
Servicing
• This product should be serviced by an authorised
engineer and only genuine spare parts should be
used.
• Under no circumstances should you attempt to
repair the machine yoursel . Repairs carried out
by inexperienced persons may cause injury or
serious mal unctioning. Re er to your local
Service Force Centre and always insist on
genuine spare parts.
At the end o the Appliance
Li e
• When disposing o your appliance, use an
authorised disposal site.
• Remove the plug and ensure that any locks or
catches are removed, to prevent young children
being trapped inside.
19
I the appliance is ixed to the side o the kitchen unit,
simply slacken the screws in ixing brackets (D),
move the brackets as shown in the igure and re-
tighten the screws.
Then it cover (E).
PR168
PR167/1
D
B
Should adjustment o the urniture door be
necessary, use the clearance o slots as required.
At the end o operations, it is necessary to check i
the door o the urniture closes properly.
Fix cover (D) on guide (B) until it clips into place.
D
E
D734
A ter completion o the door reversing operation,
check that the door gasket adheres to the
cabinet. I the ambient temperature is cold (i.e. in
Winter), the gasket may not it per ectly to the
cabinet. In that case, wait or the natural itting o
the gasket or accelerate this process by heating
up the part involved with a normal hairdryer on a
low setting.

3
CONTENTS
Instructions or the User
Important Sa ety In ormation 2
Operation 4
Be ore use 4
Setting the temperature 4
The reezer compartment 4
Freezing resh ood 4
Frozen ood storage 5
Thawing 5
Making ice cubes 5
Fresh ood re rigeration 5
Normal operating sounds 5
Movable shelves 6
Positioning the door shelves 6
Hints and Tips 7
Maintenance and Cleaning 8
Internal cleaning 8
External cleaning 8
When the appliance is not in use 8
Changing the light bulb 8
De rosting 8
Something Not Working 10
Service and Spare Parts 11
Customer Care 11
Guarantee Conditions 12
Instructions or the
Installer
Technical Speci ication 13
Installation 14
Positioning 14
Electrical Connection 15
Door Reversal 16
18
Place guide (A) on the inside part o the urniture
door, in the upper and lower position as shown in the
igure and mark the position o external holes.
Having drilled the holes, ix the guide with the
screws supplied.
20 mm
A
50mm
PR166
Separate parts A, B, C, D as shown in the igure
PR266
AB
C
D
PR33
C
A
Fix cover (C) on guide (A) until it clips into place.
Open the appliance door and the urniture door at
90°. Insert the small square (B) into guide (A). Put
together the appliance door and the urniture door
and mark the holes as indicated in the igure.
Remove the squares and drill holes with ø 2 mm at 8
mm rom the outer edge o the door. Place the small
square on the guide again and ix it with the screws
supplied.
8mm
PR167
A
B

4
OPERATION
Be ore using
Remove all securing tapes. Wash inside the
appliance with lukewarm water and bicarbonate o
soda (5 ml to 0.5 litre o water).
Do not use soap or detergent as the smell may
linger. Dry thoroughly.
Setting the temperature
The temperature inside the re rigerator and the
reezer is regulated by a single thermostat with 6
temperature positions and an “OFF” (O) position.
Position 1 = minimum coldness
Position 6 = maximum coldness
Turn the thermostat dial to the required position.
The intermediate position is usually the most
suitable (3-4).
The thermostat setting can vary as the temperature
inside the re rigeration compartment depends on the
ollowing actors:
– room temperature
– how o ten the door is opened
– how much ood is stored
– position o the appliance
Important
During prolonged periods o abnormally hot weather,
i the thermostat is set on too high a number, the
cooling system may operate continuously and the
ridge cooling plate may not de rost. Turning the knob
to a lower number will cause the automatic
de rosting to resume.
Low Room Temperature Switch
To ensure that the appliance is working e iciently
when the room temperature drops below 16°C, the
switch mounted next to the thermostat control should
be switched on.
No damage can be caused by leaving the switch in
this position or any period o time (see page 10 Low
room temperature operation). However should the
temperature rise above 16°C remember to turn the
switch o again.
The reezer compartment
The our-star reezer compartment is suitable or
storage o commercially rozen ood and or reezing
resh oods.
Freezing resh ood
It is not necessary to adjust the thermostat setting
when reezing resh ood. Depress the ambient
switch at least 12 hours be ore loading ood to be
rozen.
In any 24 hours you can reeze up to 10 kg. o resh
ood.
Place ood to be rozen in the upper drawer o the
reezer as this is the coldest part.
I large quantities o ood are to be stored , remove
all drawers and baskets rom the appliance and
place ood on cooling shelves. Pay care ul attention
not to exceed load limit
stated on the side o the upper section (where
applicable).
Caution
In the event o a power cut the ood in the reezer will
not be a ected i the power cut is short and i the
reezer is ull. Do not open the door. Should the ood
begin to thaw, it must be consumed quickly and must
not be re- rozen.
DEFROSTED COOKED FOOD MUST NOT BE
REFROZEN.
A - Low Room Temperature Switch
D710
A
17
D726
B
Apply covers (B) on joint cover lugs and into hinge
holes.
Push appliance into housing until stop strip (A)
touches the kitchen unit.
For a correct alignment make sure that the distance
between the appliance and the cabinet is o 44 mm.
Open the door and push the appliance against the
side o the kitchen unit opposite to that o appliance
hinges.
Fasten the appliance with 4 screws provided in the
kit included with the appliance.
Snap ventilation grille (C) and hinge cover (D) into
position
Press in the joint covers between the appliance and
the kitchen unit.
A
D023
D
C
D723
D724
44 mm

5
Normal Operating Sounds
• You may hear aint gurgling or bubbling sounds
when the re rigerant is pumped through the coils
or tubing at the rear, to the cooling
plate/evaporator or to the ixed reezer shelves.
• When the compressor is on, the re rigerant is
being pumped round, and you will hear a whirring
sound or pulsating noise rom the compressor.
• A thermostat controls the compressor, and you
will hear a aint ’click’ when the thermostat cuts in
and out.
Making ice cubes
The appliance is provided with one or more trays or
ice-cubes trays.
Fill the tray(s) 3/4 ull to give the ice space to expand
and place them in the reezer compartment.
To release the ice cubes simply give the tray a slight
twist.
Do not use sharp or metallic instruments to remove
the trays rom the reezer.
Fresh ood re rigeration
To obtain the best per ormance, do not store warm
ood or evaporating liquids in the re rigerator; do
cover or wrap the ood, particularly i it has a strong
lavour.
Do not cover the shelves with any protective
material, such as paper, cardboard or plastic, which
may obstruct the air circulation through them.
To help you use your re rigerator correctly, here are
some more use ul hints:
Raw meat (bee , pork, lamb & wild owl): wrap in
polythene bags and place on top o the salad
crispers.
Meat can only be stored sa ely in this way or
one or two days at the most.
Fruit & vegetables: these should be thoroughly
cleaned and placed in the bottom salad crispers.
Butter & cheese: these should be placed in special
airtight containers or wrapped in aluminium oil or
polythene bags to exclude as much air as possible.
Milk bottles: these should have a cap and should be
stored in the bottle rack on the door.
Thawing
Frozen ood, prior to being used, can be thawed in
the ridge or at room temperature depending on the
time available. Small ood items may even be cooked
rom rozen; in this case cooking will take longer.
Any rozen ood which is allowed to thaw accidentally
should either be eaten as soon as possible or thrown
away. Alternatively, i the ood is uncooked and has
not been completely de rosted it can be cooked and
then re rozen.
Meat, ish and ruit should be thawed in the
re rigerator compartment and small pieces o meat
can even be cooked while still rozen, but you must
ensure that it is thoroughly cooked through.
Vegetables should be directly immersed in boiling
water; ready-cooked dishes can be placed directly in
the oven in their aluminium wrapping.
A microwave oven is particularly suitable or thawing
any type o rozen or deep- rozen ood: ollow the
oven instructions, particularly regarding the
placement o aluminium wrapping or containers in
the oven.
De rosted cooked ood must never be re rozen.
Frozen ood storage
When irst starting-up or a ter a period o non use,
be ore putting the products in the reezer
compartment let the appliance run or at least two
hours on the coldest setting, then turn the thermostat
knob to the normal opertion position.
Do not exceed the storage period indicated by the
manu acturer.
Finally, do not open the door requently or leave it
open longer than is absolutely necessary.
Important
Do not put carbonated liquids, ( izzy drinks etc.), in
the reezer compartment.
Ice Iollies, i consumed immediately a ter removal
rom the reezer, can cause low temperature skin
burns.
Do not remove items rom the reezer i your hands
are damp/wet, as this could cause skin abrasions or
“ rost/ reezer burns”.
16
Instructions or totally built-in
appliances
Door reversal
Recess dimensions
Height (1) 1780 mm
Depth (2) 550 mm
Width (3) 560 mm
To ensure adequate ventilation, allow the clearances
shown in igure.
50 mm
min.
200 cm
2
200 cm
2
min.
D567
The appliance is supplied with the right
or le t door opening. To change the opening
direction o the door proceed as in the
ollowing instructions be ore installing it.
1. Unscrew the upper pin and remove the spacer
2. Remove the upper door
3. Unscrew the middle hinge and the brackets and
re it them on the opposite side
4. Re it the upper door, the upper pin and the
spacer on the opposite side
5. Unscrew the lower pin and remove the spacer
and re it them on the opposite side
PR01
540
50
3
21
Furthermore, it is necessary that the cabinet has a
ventilation recess with the ollowing dimensions:
depth 50 mm
width 540 mm

6
Movable shelves
The walls o the re rigerator have runners so that the
shelves can be positioned as desired .
Positioning the door shelves
To permit storage o ood packages o various sizes,
the door shelves can be adjusted in height.To make
these adjustments proceed as ollows:
Gradually pull the shel in the direction o the arrows
until it comes o , then reposition as required.
D040
15
Electrical connections
Any electrical work required to install this appliance
should be carried out by a quali ied electrician or
competent person.
WARNING: THIS APPLIANCE MUST BE
EARTHED.
The manu acturer declines any liability should
this sa ety measure not be observed.
I the plug that is itted to your appliance is not
suitable or your socket outlet, it must be cut o and
the appropriate plug itted.
Remove the use rom the cut o plug.
The cut o plug should then be disposed o to
prevent the hazard o shocks in case it should be
plugged into a 13amp socket in another part o your
home.
Important
The wires in the mains lead are coloured in
accordance with the ollowing code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
I you it your own plug, the colours o the wires in
the mains lead o your appliance may not correspond
with the markings identi ying the terminals in your
plug, proceed as ollows:
Connect the Green and Yellow (earth) wire to the
terminal in the plug which is marked with the letter
«E» or the earth symbol or coloured green and
yellow.
Connect the blue (neutral) wire to the terminal in the
plug which is marked with the letter «N» or coloured
black.
Connect the brown (live) wire to the terminal in the
plug which is marked with the letter «L» or coloured
red.
The plug moulded onto the lead incorporates a use.
D207
GREEN & YELLOW 13 AMP. FUSE
BROWN
CORD CLAMP
BLUE
13 AMP
For replacement, use a 13amp BSI362 use. Only
ASTA or BSI approved uses should be used.
The plug must not be used i the use cover/carrier is
lost. The cover/carrier is indicated by the coloured
insert at the base o the plug.
A replacement cover/carrier must be obtained rom
your local Service Force Centre.
This appliance complies with the E.E.C. Directive
No. 87/308 o 2.6.87 relative to radio inter erence
suppression.
This appliance complies with the ollowing
E.E.C. Directives:
- 73/23 EEC o 19.2.73 (Low Voltage Directive)
and subsequent modi ications;
- 89/336 EEC o 3.5.89 (Electromagnetic
Compatibility Directive) and subsequent
modi ications.
Please ensure that when the appliance is
installed it is easily accessible or the engineer in
the event o a breakdown.

7
Food Storage
• To obtain the best results rom your appliance,
neither hot oods nor liquids which may
evaporate, should be placed in the larder
compartment.
• Keep the time between buying chilled ood and
placing it in your ridge as short as possible.
• Do not push ood together too much, try to allow
air to circulate around each item.
• Do not store ood uncovered.
• Remove suspect ood rom your re rigerator and
clean, re er to ‘Maintenance and Cleaning’.
• Ensure that ood placed in the reezer is dated
and labelled and used in date order to ensure
that ood is consumed at its best.
• Avoid buying rozen ood i you cannot store it
straight away. The use o an insulated container is
advisable. When you arrive home place the rozen
ood in the reezer immediately.
• The symbols on the drawers show di erent types
o rozen goods. The numbers indicate storage
times in months or the appropriate types o
rozen goods. Whether the upper or lower value o
the indicated storage time is valid depends on the
quality o the oods and pre-treating be ore
reezing.
Energy Saving Advice
• Do not install the cabinet close to sources o
heat, i.e. boiler or radiator.
• Locate the appliance in a cool well ventilated
room and make sure that the air openings o the
cabinet are not obstructed.
• Avoid unnecessary rosting in the cabinet by
packing all oodstu s into airtight packages
be ore placing them in the reezer.
• Always leave warm ood to cool down to room
temperature be ore placing in the ridge or
reezer.
• Food which is to be rozen (when cool) should be
placed in the ridge be ore being trans erred to
the reezer.
• Thaw rozen ood in the ridge. This will ensure
sa er de rosting o oods and reduce the work o
the re rigeration unit.
• Try to avoid keeping the door open or long
periods, or opening the door too requently as
warm air will enter the cabinet, and cause the
compressor to switch on unnecessarily o ten.
• Ensure there are no obstructions preventing the
door rom closing properly.
In the Event o a Power Failure
I there is a power ailure during the storage o rozen
oods, keep the door closed. I the temperature within
your reezer should rise do not re reeze the ood
without checking its condition.
The ollowing guidelines should assist you.
Ice Cream:
Once thawed should be discarded.
Fruit and Vegetables:
I so t should be cooked and used up.
Bread and Cakes:
Can be re rozen without danger.
Shell ish:
Should be re rigerated and used up quickly.
Cooked Dishes:
i.e. casseroles, should be re rigerated and used up.
Large Pieces o Meat:
Can be re- rozen providing there are ice crystals
remaining within them.
Small Joints:
Should be cooked and then re- rozen as cooked
dishes.
Chicken:
Should be cooked and re- rozen as a resh dish.
HINTS AND TIPS
14
INSTALLATION
Positioning
This appliance should only be installed at a location
where the ambient temperature corresponds to the
climate classi ication indicated on the rating plate,
which is located at the le t on the inside o the
appliance.
The ollowing table shows which ambient
temperature is correct or each climate classi ication:
SN +10°C to + 32°C
N +16°C to + 32°C
ST +18°C to + 38°C
T +18°C to + 43°C
The appliance should be located in a dry
atmosphere, out o direct sunlight and away rom
continuous heat and extreme temperature, e.g. not
next to a boiler or radiator, or in a very cold room e.g.
an outhouse. I these temperatures are exceeded i.e.
warmer or colder, then the appliance may not
operate correctly.
For building-in and door reversal instructions please
re er to the relevant instructions on the ollowing
pages.
Warning
IF YOU ARE DISCARDING AN OLD APPLIANCE
THAT HAS A LOCK OR CATCH ON THE DOOR,
YOU MUST ENSURE THAT IT IS MADE
UNUSABLE TO PREVENT YOUNG CHILDREN
BEING TRAPPED INSIDE.
Depending upon the position which you choose or
your appliance, you may wish to reverse the way in
which the door opens. To do this, re er to instructions
under “Door reversal”.
Important
It must be possible to disconnect the appliance rom
the mains power supply; the plug must there ore be
easily accessible a ter installation.

8
De rosting
Re rigerator
The re rigerator automatically de rosts every time the
compressor stops. The water is discharged, via the
pipe, into a tray located at the back o the appliance
above the compressor, where it evaporates.
Important
To avoid de rost water over lowing into the ridge,
periodically clean the water discharge hole in the
centre o the V shaped drip collector at the back o
the re rigerator compartment behind the ruit and
vegetable drawer. Use the de rost cleaner provided
which you will ind already inserted into the
discharge hole.
D037
MAINTENANCE AND CLEANING
Be ore any maintenance or cleaning work is carried
out, DISCONNECT the appliance rom the
ELECTRICITY supply.
Internal cleaning
Clean the inside and accessories with warm water
and bicarbonate o soda (5ml to 0.5 litre o water).
Rinse and dry thoroughly.
NEVER USE DETERGENTS, ABRASIVE
POWDERS, HIGHLY PERFUMED
CLEANING PRODUCTS OR WAX
POLISHES, TO CLEAN THE INTERIOR AS
THESE WILL DAMAGE THE SURFACE AND
LEAVE A STRONG ODOUR.
When the appliance is not in use
When the appliance is not in use or long periods,
disconnect rom the electricity supply, empty all
oods and clean the appliance, leaving the doors ajar
to prevent unpleasant smells.
Changing the light bulb
Should the interior light ail to work, irst switch o
the appliance and disconnect rom the electricity
supply, then replace the bulb as ollows;
Unscrew the light cover and then pull it outward by
pressing as shown in the igure. Unscrew the bulb
and replace it with a new 15 watt bulb (available rom
your nearest Service Force Centre).
Replace the light cover by sliding it into its original
position and replacing the screw.
D411
External cleaning
Once or twice a year dust the condenser (black grill)
and the compressor at the back o the appliance,
with a brush or vacuum cleaner, see igure, as an
accumulation o dust will a ect the per ormance o
the appliance and cause excessive electricity
consumption.
PR259
13
TECHNICAL SPECIFICATIONS
POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz
TOTAL POWER ABSORBED 160 W
AVERAGE DAILY UNITS ELECTRICITY * 1.10 kWh
GROSS CAPACITY
Fridge 170 l
Freezer 173 l
NET CAPACITY
Fridge 92
Freezer 110 l
STAR RATING
* This igure is based on standard test results in accordance with European Standard EN 153.
Actual consumption will depend on how the appliance is used and where it is located.

9
Remember to wash the de rost cleaner in hot soapy
water at regular intervals. Dry throughly be ore
replacing.
Freezer
When the rost has reached a thickness o up to
4mm it can be removed using the ice scraper
provided with the appliance. During this operation it
is not necessary to disconnect the appliance rom
the mains and remove the ood. Never use metal
tools or this operation.
For complete de rosting (once or twice a year)
proceed as ollows:
- turn the thermostat control knob to the «OFF»
position (O) or disconnect the appliance rom the
mains.
- Remove any ood rom inside the reezer and
ridge, wrap it in several sheets o newspaper and
store in a cool,dry place.
- Leave the door openand insert the ice scraper
under the channelin the centre o the lower part
o the appliance; place a low-sided container
beneath the scraper to collect the water.
- Clean and dry thoroughly.
- Replace the scraper in one o the drawers .
- Reconnect the appliance to the mains or reset
the thermostat control knob to a unctioning
position.
- A ter letting the appliance run or a least hal an
hour, replace the previously removed ood into
the compartment.
Important
When de rosting the reezer, the ridge is also
controlled by the thermostat and will not be
operational during this period. A temperature rise o
the rozen ood packs, during de rosting, may
shorten their sa e storage li e.
D068
12
Standard guarantee conditions
We, EHP, undertake that i within 12 months o the date o the purchase this Firenzi appliance or any part
thereo is proved to be de ective by reason only o aulty workmanship or materials, we will, at our option repair
or replace the same FREE OF CHARGE or labour, materials or carriage on condition that:
The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
The appliance has been used or normal domestic purposes only, and in accordance with the manu acturer’s
instructions.
The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any person not
authorised by us.
All service work under this guarantee must be undertaken by a Service Force Centre. Any appliance or
de ective part replaced shall become the Company’s property.
This guarantee is in addition to your statutory and other legal rights.
Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available outside these
hours in which case a premium will be charged.
Exclusions
This guarantee does not cover:
Damage or calls resulting rom transportation, improper use or neglect, the replacement o any light bulbs or
removable parts o glass or plastic.
Costs incurred or calls to put right an appliance which is improperly installed or calls to appliances outside the
United Kingdom.
Appliances ound to be in use within a commercial environment, plus those which are subject to rental
agreements.
European Guarantee
I you should move to another country within Europe then your guarantee moves with you to your new home
subject to the ollowing quali ications:
The guarantee starts rom the date you irst purchased your product.
The guarantee is or the same period and to the same extent or labour and parts as exists in the new country o
use or this brand or range o products.
This guarantee relates to you and cannot be trans erred to another user.
Your new home is within the European Community (EC) or European Free Trade Area.
The product is installed and used in accordance with our instructions and is only used domestically, i.e. a
normal household.
The product is installed taking into account regulations in your new country.
Be ore you move please contact your nearest Customer Care centre, listed below, to give them details o your
new home. They will then ensure that the local Service Organisation is aware o your move and able to look
a ter you and your appliances.
France Senlis [phone]
Germany Nürnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Slough [phone]
GUARANTEE CONDITIONS

10
SOMETHING NOT WORKING
Symptom
No power to the appliance
The light does not come on
The temperature in the ridge or reezer section is
too high
The reezer door will not open
The compressor runs continously
Excessive rost and ice has built up
Noise
Water under the salad bin
Solution
Check there is power at the socket.
Check there is not a power cut by checking the
household lights.
Check the use has not blown.
Ensure that the bulb is correctly itted.
Replace the bulb i it has blown.
Check the door light switch is not jammed.
Check the thermostat control knob in the ridge is
turned to the correct setting relative to ambient
conditions.
Check the ambient temperature is within the
appliance’s operating limits, please re er to the
installation section in this instruction book.
Relocate the appliance i necessary.
Has door just been opened? I so leave or a ew
minutes to allow the air pressure to equalise.
Adjust the thermostat control knob to give correct
temperature control. See “Setting the temperature”.
Check that the doors are closed.
Large quantities o ood have recently been placed in
the cabinet and/or door is requently opened.
Check that air ventilation is not obstructed.
Ensure the doors are not le t open.
Check that nothing is preventing the doors rom
closing.
Is the door gasket intact and clean.
Re er to normal operating sounds.
Check the drain hole is not blocked. (see
Maintenance and Cleaning).
Important: I you call out an engineer to a ault listed below, or to repair a ault caused by incorrect use or
installation a charge will be made, even i the appliance is under guarantee.
Be ore contacting your local Service Force Centre, check the ollowing points:
Low room temperature operation
During prolonged periods o low room temperatures,ie;10°C and lower, the compressor on single compressor
ridge reezers can remain inoperative during this time .
This is due to the air temperature within the re rigerator compartment being maintained at 6°C or under thus not
calling the thermostat to energise the compressor .
11
CUSTOMER CARE DEPARTMENT
In the event o your appliance requiring service, or i you wish to purchase spare parts, please contact your local
Service Force Centre by telephoning:-
0870 5 929929
Your telephone call will be automatically routed to the Service Force Centre covering your post code area.
For the address o your local Service Force Centre and urther in ormation about Service Force, please visit the
website at www.service orce.co.uk
Be ore calling out an engineer, please ensure you have read the details under the heading ‘Something Not
Working?
When you contact the Service Force Centre you will need to give the ollowing details:
1. Your name, address and post code
2. Your telephone number
3. Clear and concise details o the ault
4. The model and serial number o the appliance ( ound on the rating plate)
5. The purchase date
Please note that a valid purchase receipt or guarantee documentation is required or in-guarantee
service calls.
For general enquiries concerning your appliance, please contact our Customer Care Department by letter or
telephone at the address below:
Customer Care Department
EHP
55-77 High Street
Slough
Berkshire
SL1 1DZ
08705 950 950 *
* calls to this number may be recorded or training purposes.
SERVICE AND SPARE PARTS
During a normal night time period o approximately 8 hours a traditional ridge reezer can normally maintain the
rozen ood temperature but i the appliance is le t or longer period in a low ambient temperature the reezer will
de rost .
I , a ter the above checks, there is still a ault, call your local Service Force Centre.
In-guarantee customers should ensure that the above checks have been made as the engineer will make a
charge i the ault is not a mechanical or electrical breakdown.
Please note that proo o purchase is required or any in-guarantee service calls.

10
SOMETHING NOT WORKING
Symptom
No power to the appliance
The light does not come on
The temperature in the ridge or reezer section is
too high
The reezer door will not open
The compressor runs continously
Excessive rost and ice has built up
Noise
Water under the salad bin
Solution
Check there is power at the socket.
Check there is not a power cut by checking the
household lights.
Check the use has not blown.
Ensure that the bulb is correctly itted.
Replace the bulb i it has blown.
Check the door light switch is not jammed.
Check the thermostat control knob in the ridge is
turned to the correct setting relative to ambient
conditions.
Check the ambient temperature is within the
appliance’s operating limits, please re er to the
installation section in this instruction book.
Relocate the appliance i necessary.
Has door just been opened? I so leave or a ew
minutes to allow the air pressure to equalise.
Adjust the thermostat control knob to give correct
temperature control. See “Setting the temperature”.
Check that the doors are closed.
Large quantities o ood have recently been placed in
the cabinet and/or door is requently opened.
Check that air ventilation is not obstructed.
Ensure the doors are not le t open.
Check that nothing is preventing the doors rom
closing.
Is the door gasket intact and clean.
Re er to normal operating sounds.
Check the drain hole is not blocked. (see
Maintenance and Cleaning).
Important: I you call out an engineer to a ault listed below, or to repair a ault caused by incorrect use or
installation a charge will be made, even i the appliance is under guarantee.
Be ore contacting your local Service Force Centre, check the ollowing points:
Low room temperature operation
During prolonged periods o low room temperatures,ie;10°C and lower, the compressor on single compressor
ridge reezers can remain inoperative during this time .
This is due to the air temperature within the re rigerator compartment being maintained at 6°C or under thus not
calling the thermostat to energise the compressor .
11
CUSTOMER CARE DEPARTMENT
In the event o your appliance requiring service, or i you wish to purchase spare parts, please contact your local
Service Force Centre by telephoning:-
0870 5 929929
Your telephone call will be automatically routed to the Service Force Centre covering your post code area.
For the address o your local Service Force Centre and urther in ormation about Service Force, please visit the
website at www.service orce.co.uk
Be ore calling out an engineer, please ensure you have read the details under the heading ‘Something Not
Working?
When you contact the Service Force Centre you will need to give the ollowing details:
1. Your name, address and post code
2. Your telephone number
3. Clear and concise details o the ault
4. The model and serial number o the appliance ( ound on the rating plate)
5. The purchase date
Please note that a valid purchase receipt or guarantee documentation is required or in-guarantee
service calls.
For general enquiries concerning your appliance, please contact our Customer Care Department by letter or
telephone at the address below:
Customer Care Department
EHP
55-77 High Street
Slough
Berkshire
SL1 1DZ
08705 950 950 *
* calls to this number may be recorded or training purposes.
SERVICE AND SPARE PARTS
During a normal night time period o approximately 8 hours a traditional ridge reezer can normally maintain the
rozen ood temperature but i the appliance is le t or longer period in a low ambient temperature the reezer will
de rost .
I , a ter the above checks, there is still a ault, call your local Service Force Centre.
In-guarantee customers should ensure that the above checks have been made as the engineer will make a
charge i the ault is not a mechanical or electrical breakdown.
Please note that proo o purchase is required or any in-guarantee service calls.

9
Remember to wash the de rost cleaner in hot soapy
water at regular intervals. Dry throughly be ore
replacing.
Freezer
When the rost has reached a thickness o up to
4mm it can be removed using the ice scraper
provided with the appliance. During this operation it
is not necessary to disconnect the appliance rom
the mains and remove the ood. Never use metal
tools or this operation.
For complete de rosting (once or twice a year)
proceed as ollows:
- turn the thermostat control knob to the «OFF»
position (O) or disconnect the appliance rom the
mains.
- Remove any ood rom inside the reezer and
ridge, wrap it in several sheets o newspaper and
store in a cool,dry place.
- Leave the door openand insert the ice scraper
under the channelin the centre o the lower part
o the appliance; place a low-sided container
beneath the scraper to collect the water.
- Clean and dry thoroughly.
- Replace the scraper in one o the drawers .
- Reconnect the appliance to the mains or reset
the thermostat control knob to a unctioning
position.
- A ter letting the appliance run or a least hal an
hour, replace the previously removed ood into
the compartment.
Important
When de rosting the reezer, the ridge is also
controlled by the thermostat and will not be
operational during this period. A temperature rise o
the rozen ood packs, during de rosting, may
shorten their sa e storage li e.
D068
12
Standard guarantee conditions
We, EHP, undertake that i within 12 months o the date o the purchase this Firenzi appliance or any part
thereo is proved to be de ective by reason only o aulty workmanship or materials, we will, at our option repair
or replace the same FREE OF CHARGE or labour, materials or carriage on condition that:
The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
The appliance has been used or normal domestic purposes only, and in accordance with the manu acturer’s
instructions.
The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any person not
authorised by us.
All service work under this guarantee must be undertaken by a Service Force Centre. Any appliance or
de ective part replaced shall become the Company’s property.
This guarantee is in addition to your statutory and other legal rights.
Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available outside these
hours in which case a premium will be charged.
Exclusions
This guarantee does not cover:
Damage or calls resulting rom transportation, improper use or neglect, the replacement o any light bulbs or
removable parts o glass or plastic.
Costs incurred or calls to put right an appliance which is improperly installed or calls to appliances outside the
United Kingdom.
Appliances ound to be in use within a commercial environment, plus those which are subject to rental
agreements.
European Guarantee
I you should move to another country within Europe then your guarantee moves with you to your new home
subject to the ollowing quali ications:
The guarantee starts rom the date you irst purchased your product.
The guarantee is or the same period and to the same extent or labour and parts as exists in the new country o
use or this brand or range o products.
This guarantee relates to you and cannot be trans erred to another user.
Your new home is within the European Community (EC) or European Free Trade Area.
The product is installed and used in accordance with our instructions and is only used domestically, i.e. a
normal household.
The product is installed taking into account regulations in your new country.
Be ore you move please contact your nearest Customer Care centre, listed below, to give them details o your
new home. They will then ensure that the local Service Organisation is aware o your move and able to look
a ter you and your appliances.
France Senlis [phone]
Germany Nürnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Slough [phone]
GUARANTEE CONDITIONS

8
De rosting
Re rigerator
The re rigerator automatically de rosts every time the
compressor stops. The water is discharged, via the
pipe, into a tray located at the back o the appliance
above the compressor, where it evaporates.
Important
To avoid de rost water over lowing into the ridge,
periodically clean the water discharge hole in the
centre o the V shaped drip collector at the back o
the re rigerator compartment behind the ruit and
vegetable drawer. Use the de rost cleaner provided
which you will ind already inserted into the
discharge hole.
D037
MAINTENANCE AND CLEANING
Be ore any maintenance or cleaning work is carried
out, DISCONNECT the appliance rom the
ELECTRICITY supply.
Internal cleaning
Clean the inside and accessories with warm water
and bicarbonate o soda (5ml to 0.5 litre o water).
Rinse and dry thoroughly.
NEVER USE DETERGENTS, ABRASIVE
POWDERS, HIGHLY PERFUMED
CLEANING PRODUCTS OR WAX
POLISHES, TO CLEAN THE INTERIOR AS
THESE WILL DAMAGE THE SURFACE AND
LEAVE A STRONG ODOUR.
When the appliance is not in use
When the appliance is not in use or long periods,
disconnect rom the electricity supply, empty all
oods and clean the appliance, leaving the doors ajar
to prevent unpleasant smells.
Changing the light bulb
Should the interior light ail to work, irst switch o
the appliance and disconnect rom the electricity
supply, then replace the bulb as ollows;
Unscrew the light cover and then pull it outward by
pressing as shown in the igure. Unscrew the bulb
and replace it with a new 15 watt bulb (available rom
your nearest Service Force Centre).
Replace the light cover by sliding it into its original
position and replacing the screw.
D411
External cleaning
Once or twice a year dust the condenser (black grill)
and the compressor at the back o the appliance,
with a brush or vacuum cleaner, see igure, as an
accumulation o dust will a ect the per ormance o
the appliance and cause excessive electricity
consumption.
PR259
13
TECHNICAL SPECIFICATIONS
POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz
TOTAL POWER ABSORBED 160 W
AVERAGE DAILY UNITS ELECTRICITY * 1.10 kWh
GROSS CAPACITY
Fridge 170 l
Freezer 173 l
NET CAPACITY
Fridge 92
Freezer 110 l
STAR RATING
* This igure is based on standard test results in accordance with European Standard EN 153.
Actual consumption will depend on how the appliance is used and where it is located.

7
Food Storage
• To obtain the best results rom your appliance,
neither hot oods nor liquids which may
evaporate, should be placed in the larder
compartment.
• Keep the time between buying chilled ood and
placing it in your ridge as short as possible.
• Do not push ood together too much, try to allow
air to circulate around each item.
• Do not store ood uncovered.
• Remove suspect ood rom your re rigerator and
clean, re er to ‘Maintenance and Cleaning’.
• Ensure that ood placed in the reezer is dated
and labelled and used in date order to ensure
that ood is consumed at its best.
• Avoid buying rozen ood i you cannot store it
straight away. The use o an insulated container is
advisable. When you arrive home place the rozen
ood in the reezer immediately.
• The symbols on the drawers show di erent types
o rozen goods. The numbers indicate storage
times in months or the appropriate types o
rozen goods. Whether the upper or lower value o
the indicated storage time is valid depends on the
quality o the oods and pre-treating be ore
reezing.
Energy Saving Advice
• Do not install the cabinet close to sources o
heat, i.e. boiler or radiator.
• Locate the appliance in a cool well ventilated
room and make sure that the air openings o the
cabinet are not obstructed.
• Avoid unnecessary rosting in the cabinet by
packing all oodstu s into airtight packages
be ore placing them in the reezer.
• Always leave warm ood to cool down to room
temperature be ore placing in the ridge or
reezer.
• Food which is to be rozen (when cool) should be
placed in the ridge be ore being trans erred to
the reezer.
• Thaw rozen ood in the ridge. This will ensure
sa er de rosting o oods and reduce the work o
the re rigeration unit.
• Try to avoid keeping the door open or long
periods, or opening the door too requently as
warm air will enter the cabinet, and cause the
compressor to switch on unnecessarily o ten.
• Ensure there are no obstructions preventing the
door rom closing properly.
In the Event o a Power Failure
I there is a power ailure during the storage o rozen
oods, keep the door closed. I the temperature within
your reezer should rise do not re reeze the ood
without checking its condition.
The ollowing guidelines should assist you.
Ice Cream:
Once thawed should be discarded.
Fruit and Vegetables:
I so t should be cooked and used up.
Bread and Cakes:
Can be re rozen without danger.
Shell ish:
Should be re rigerated and used up quickly.
Cooked Dishes:
i.e. casseroles, should be re rigerated and used up.
Large Pieces o Meat:
Can be re- rozen providing there are ice crystals
remaining within them.
Small Joints:
Should be cooked and then re- rozen as cooked
dishes.
Chicken:
Should be cooked and re- rozen as a resh dish.
HINTS AND TIPS
14
INSTALLATION
Positioning
This appliance should only be installed at a location
where the ambient temperature corresponds to the
climate classi ication indicated on the rating plate,
which is located at the le t on the inside o the
appliance.
The ollowing table shows which ambient
temperature is correct or each climate classi ication:
SN +10°C to + 32°C
N +16°C to + 32°C
ST +18°C to + 38°C
T +18°C to + 43°C
The appliance should be located in a dry
atmosphere, out o direct sunlight and away rom
continuous heat and extreme temperature, e.g. not
next to a boiler or radiator, or in a very cold room e.g.
an outhouse. I these temperatures are exceeded i.e.
warmer or colder, then the appliance may not
operate correctly.
For building-in and door reversal instructions please
re er to the relevant instructions on the ollowing
pages.
Warning
IF YOU ARE DISCARDING AN OLD APPLIANCE
THAT HAS A LOCK OR CATCH ON THE DOOR,
YOU MUST ENSURE THAT IT IS MADE
UNUSABLE TO PREVENT YOUNG CHILDREN
BEING TRAPPED INSIDE.
Depending upon the position which you choose or
your appliance, you may wish to reverse the way in
which the door opens. To do this, re er to instructions
under “Door reversal”.
Important
It must be possible to disconnect the appliance rom
the mains power supply; the plug must there ore be
easily accessible a ter installation.

6
Movable shelves
The walls o the re rigerator have runners so that the
shelves can be positioned as desired .
Positioning the door shelves
To permit storage o ood packages o various sizes,
the door shelves can be adjusted in height.To make
these adjustments proceed as ollows:
Gradually pull the shel in the direction o the arrows
until it comes o , then reposition as required.
D040
15
Electrical connections
Any electrical work required to install this appliance
should be carried out by a quali ied electrician or
competent person.
WARNING: THIS APPLIANCE MUST BE
EARTHED.
The manu acturer declines any liability should
this sa ety measure not be observed.
I the plug that is itted to your appliance is not
suitable or your socket outlet, it must be cut o and
the appropriate plug itted.
Remove the use rom the cut o plug.
The cut o plug should then be disposed o to
prevent the hazard o shocks in case it should be
plugged into a 13amp socket in another part o your
home.
Important
The wires in the mains lead are coloured in
accordance with the ollowing code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
I you it your own plug, the colours o the wires in
the mains lead o your appliance may not correspond
with the markings identi ying the terminals in your
plug, proceed as ollows:
Connect the Green and Yellow (earth) wire to the
terminal in the plug which is marked with the letter
«E» or the earth symbol or coloured green and
yellow.
Connect the blue (neutral) wire to the terminal in the
plug which is marked with the letter «N» or coloured
black.
Connect the brown (live) wire to the terminal in the
plug which is marked with the letter «L» or coloured
red.
The plug moulded onto the lead incorporates a use.
D207
GREEN & YELLOW 13 AMP. FUSE
BROWN
CORD CLAMP
BLUE
13 AMP
For replacement, use a 13amp BSI362 use. Only
ASTA or BSI approved uses should be used.
The plug must not be used i the use cover/carrier is
lost. The cover/carrier is indicated by the coloured
insert at the base o the plug.
A replacement cover/carrier must be obtained rom
your local Service Force Centre.
This appliance complies with the E.E.C. Directive
No. 87/308 o 2.6.87 relative to radio inter erence
suppression.
This appliance complies with the ollowing
E.E.C. Directives:
- 73/23 EEC o 19.2.73 (Low Voltage Directive)
and subsequent modi ications;
- 89/336 EEC o 3.5.89 (Electromagnetic
Compatibility Directive) and subsequent
modi ications.
Please ensure that when the appliance is
installed it is easily accessible or the engineer in
the event o a breakdown.

5
Normal Operating Sounds
• You may hear aint gurgling or bubbling sounds
when the re rigerant is pumped through the coils
or tubing at the rear, to the cooling
plate/evaporator or to the ixed reezer shelves.
• When the compressor is on, the re rigerant is
being pumped round, and you will hear a whirring
sound or pulsating noise rom the compressor.
• A thermostat controls the compressor, and you
will hear a aint ’click’ when the thermostat cuts in
and out.
Making ice cubes
The appliance is provided with one or more trays or
ice-cubes trays.
Fill the tray(s) 3/4 ull to give the ice space to expand
and place them in the reezer compartment.
To release the ice cubes simply give the tray a slight
twist.
Do not use sharp or metallic instruments to remove
the trays rom the reezer.
Fresh ood re rigeration
To obtain the best per ormance, do not store warm
ood or evaporating liquids in the re rigerator; do
cover or wrap the ood, particularly i it has a strong
lavour.
Do not cover the shelves with any protective
material, such as paper, cardboard or plastic, which
may obstruct the air circulation through them.
To help you use your re rigerator correctly, here are
some more use ul hints:
Raw meat (bee , pork, lamb & wild owl): wrap in
polythene bags and place on top o the salad
crispers.
Meat can only be stored sa ely in this way or
one or two days at the most.
Fruit & vegetables: these should be thoroughly
cleaned and placed in the bottom salad crispers.
Butter & cheese: these should be placed in special
airtight containers or wrapped in aluminium oil or
polythene bags to exclude as much air as possible.
Milk bottles: these should have a cap and should be
stored in the bottle rack on the door.
Thawing
Frozen ood, prior to being used, can be thawed in
the ridge or at room temperature depending on the
time available. Small ood items may even be cooked
rom rozen; in this case cooking will take longer.
Any rozen ood which is allowed to thaw accidentally
should either be eaten as soon as possible or thrown
away. Alternatively, i the ood is uncooked and has
not been completely de rosted it can be cooked and
then re rozen.
Meat, ish and ruit should be thawed in the
re rigerator compartment and small pieces o meat
can even be cooked while still rozen, but you must
ensure that it is thoroughly cooked through.
Vegetables should be directly immersed in boiling
water; ready-cooked dishes can be placed directly in
the oven in their aluminium wrapping.
A microwave oven is particularly suitable or thawing
any type o rozen or deep- rozen ood: ollow the
oven instructions, particularly regarding the
placement o aluminium wrapping or containers in
the oven.
De rosted cooked ood must never be re rozen.
Frozen ood storage
When irst starting-up or a ter a period o non use,
be ore putting the products in the reezer
compartment let the appliance run or at least two
hours on the coldest setting, then turn the thermostat
knob to the normal opertion position.
Do not exceed the storage period indicated by the
manu acturer.
Finally, do not open the door requently or leave it
open longer than is absolutely necessary.
Important
Do not put carbonated liquids, ( izzy drinks etc.), in
the reezer compartment.
Ice Iollies, i consumed immediately a ter removal
rom the reezer, can cause low temperature skin
burns.
Do not remove items rom the reezer i your hands
are damp/wet, as this could cause skin abrasions or
“ rost/ reezer burns”.
16
Instructions or totally built-in
appliances
Door reversal
Recess dimensions
Height (1) 1780 mm
Depth (2) 550 mm
Width (3) 560 mm
To ensure adequate ventilation, allow the clearances
shown in igure.
50 mm
min.
200 cm
2
200 cm
2
min.
D567
The appliance is supplied with the right
or le t door opening. To change the opening
direction o the door proceed as in the
ollowing instructions be ore installing it.
1. Unscrew the upper pin and remove the spacer
2. Remove the upper door
3. Unscrew the middle hinge and the brackets and
re it them on the opposite side
4. Re it the upper door, the upper pin and the
spacer on the opposite side
5. Unscrew the lower pin and remove the spacer
and re it them on the opposite side
PR01
540
50
3
21
Furthermore, it is necessary that the cabinet has a
ventilation recess with the ollowing dimensions:
depth 50 mm
width 540 mm

4
OPERATION
Be ore using
Remove all securing tapes. Wash inside the
appliance with lukewarm water and bicarbonate o
soda (5 ml to 0.5 litre o water).
Do not use soap or detergent as the smell may
linger. Dry thoroughly.
Setting the temperature
The temperature inside the re rigerator and the
reezer is regulated by a single thermostat with 6
temperature positions and an “OFF” (O) position.
Position 1 = minimum coldness
Position 6 = maximum coldness
Turn the thermostat dial to the required position.
The intermediate position is usually the most
suitable (3-4).
The thermostat setting can vary as the temperature
inside the re rigeration compartment depends on the
ollowing actors:
– room temperature
– how o ten the door is opened
– how much ood is stored
– position o the appliance
Important
During prolonged periods o abnormally hot weather,
i the thermostat is set on too high a number, the
cooling system may operate continuously and the
ridge cooling plate may not de rost. Turning the knob
to a lower number will cause the automatic
de rosting to resume.
Low Room Temperature Switch
To ensure that the appliance is working e iciently
when the room temperature drops below 16°C, the
switch mounted next to the thermostat control should
be switched on.
No damage can be caused by leaving the switch in
this position or any period o time (see page 10 Low
room temperature operation). However should the
temperature rise above 16°C remember to turn the
switch o again.
The reezer compartment
The our-star reezer compartment is suitable or
storage o commercially rozen ood and or reezing
resh oods.
Freezing resh ood
It is not necessary to adjust the thermostat setting
when reezing resh ood. Depress the ambient
switch at least 12 hours be ore loading ood to be
rozen.
In any 24 hours you can reeze up to 10 kg. o resh
ood.
Place ood to be rozen in the upper drawer o the
reezer as this is the coldest part.
I large quantities o ood are to be stored , remove
all drawers and baskets rom the appliance and
place ood on cooling shelves. Pay care ul attention
not to exceed load limit
stated on the side o the upper section (where
applicable).
Caution
In the event o a power cut the ood in the reezer will
not be a ected i the power cut is short and i the
reezer is ull. Do not open the door. Should the ood
begin to thaw, it must be consumed quickly and must
not be re- rozen.
DEFROSTED COOKED FOOD MUST NOT BE
REFROZEN.
A - Low Room Temperature Switch
D710
A
17
D726
B
Apply covers (B) on joint cover lugs and into hinge
holes.
Push appliance into housing until stop strip (A)
touches the kitchen unit.
For a correct alignment make sure that the distance
between the appliance and the cabinet is o 44 mm.
Open the door and push the appliance against the
side o the kitchen unit opposite to that o appliance
hinges.
Fasten the appliance with 4 screws provided in the
kit included with the appliance.
Snap ventilation grille (C) and hinge cover (D) into
position
Press in the joint covers between the appliance and
the kitchen unit.
A
D023
D
C
D723
D724
44 mm

3
CONTENTS
Instructions or the User
Important Sa ety In ormation 2
Operation 4
Be ore use 4
Setting the temperature 4
The reezer compartment 4
Freezing resh ood 4
Frozen ood storage 5
Thawing 5
Making ice cubes 5
Fresh ood re rigeration 5
Normal operating sounds 5
Movable shelves 6
Positioning the door shelves 6
Hints and Tips 7
Maintenance and Cleaning 8
Internal cleaning 8
External cleaning 8
When the appliance is not in use 8
Changing the light bulb 8
De rosting 8
Something Not Working 10
Service and Spare Parts 11
Customer Care 11
Guarantee Conditions 12
Instructions or the
Installer
Technical Speci ication 13
Installation 14
Positioning 14
Electrical Connection 15
Door Reversal 16
18
Place guide (A) on the inside part o the urniture
door, in the upper and lower position as shown in the
igure and mark the position o external holes.
Having drilled the holes, ix the guide with the
screws supplied.
20 mm
A
50mm
PR166
Separate parts A, B, C, D as shown in the igure
PR266
AB
C
D
PR33
C
A
Fix cover (C) on guide (A) until it clips into place.
Open the appliance door and the urniture door at
90°. Insert the small square (B) into guide (A). Put
together the appliance door and the urniture door
and mark the holes as indicated in the igure.
Remove the squares and drill holes with ø 2 mm at 8
mm rom the outer edge o the door. Place the small
square on the guide again and ix it with the screws
supplied.
8mm
PR167
A
B

2
IMPORTANT SAFETY INFORMATION
It is most important that this instruction book should be retained with the appliance or uture
re erence. Should the appliance be sold or trans erred to another owner, or should you move house and
leave the appliance, always ensure that the book is le t with the appliance in order that the new owner
can get to know the unctioning o the appliance and the relevant sa ety in ormation.
This in ormation has been provided in the interest o sa ety.You MUST read it care ully be ore installing
or using the appliance.
Installation
• This appliance is heavy. Care should be taken when
moving it.
• It is dangerous to alter the speci ications or attempt
to modi y this product in any way.
• Care must be taken to ensure that the appliance
does not stand on the electrical supply cable.
Important: i the supply cable is damaged, it must
be replaced by a special cable available rom your
local Service Force Centre.
• Any electrical work required to install this appliance
should be carried out by a quali ied electrician or
competent person.
• Parts which heat up should not be exposed.
Whenever possible, the back o the appliance
should be close to a wall but leaving the required
distance or ventilation as stated in the installation
instructions.
• The appliance should be le t or 2 hours a ter
installation be ore it is turned on, in order to allow
the re rigerant to settle.
Child Sa ety
• Do not allow children to tamper with the controls or
play with the product.
• Keep all packaging well away rom children.
General Sa ety
• This appliance contains hydrocarbons in its
cooling unit; maintenance and recharging must
there ore only be carried out by authorized
technicians.
• Take utmost care when handling your appliance
so as not to cause any damages to the cooling
unit with consequent possible luid leakages.
•The appliance must not be located close to
cookers, radiators or boilers.
•Avoid prolonged exposure o the appliance to
direct sunlight.
•Do not use other electrical appliances (such as
ice cream makers) inside o re rigerating
appliances.
During Use
• This appliance is designed or domestic use only,
speci ically or the storage o edible oodstu s.
• Frozen ood must NOT be re- rozen once it has
thawed out.
• Do not place carbonated or izzy drinks in the
reezer.
• Do not remove items rom the reezer i your
hands are damp/wet, as this could cause skin
abrasions or rost/ reezer burns.
• Ice lollies can cause ‘ rost/ reezer burns’ i
consumed straight rom the reezer.
• Manu acturers’ storage recommendations should
be strictly adhered to. Re er to relevant
instructions.
• The cooling plate or re rigerated reezer shelves
in this appliance contain channels through which
the re rigerant passes. I these are punctured this
will cause substantial damage to the appliance
and result in ood loss. DO NOT USE SHARP
INSTRUMENTS to scrape o rost or ice. Under
NO circumstances should solid ice be orced o
the lining or shelves. Solid ice should be allowed
to thaw, when de rosting the appliance. See
De rost Instructions.
Maintenance and Cleaning
• Switch o and unplug the appliance be ore
carrying out any cleaning or maintenance work.
Servicing
• This product should be serviced by an authorised
engineer and only genuine spare parts should be
used.
• Under no circumstances should you attempt to
repair the machine yoursel . Repairs carried out
by inexperienced persons may cause injury or
serious mal unctioning. Re er to your local
Service Force Centre and always insist on
genuine spare parts.
At the end o the Appliance
Li e
• When disposing o your appliance, use an
authorised disposal site.
• Remove the plug and ensure that any locks or
catches are removed, to prevent young children
being trapped inside.
19
I the appliance is ixed to the side o the kitchen unit,
simply slacken the screws in ixing brackets (D),
move the brackets as shown in the igure and re-
tighten the screws.
Then it cover (E).
PR168
PR167/1
D
B
Should adjustment o the urniture door be
necessary, use the clearance o slots as required.
At the end o operations, it is necessary to check i
the door o the urniture closes properly.
Fix cover (D) on guide (B) until it clips into place.
D
E
D734
A ter completion o the door reversing operation,
check that the door gasket adheres to the
cabinet. I the ambient temperature is cold (i.e. in
Winter), the gasket may not it per ectly to the
cabinet. In that case, wait or the natural itting o
the gasket or accelerate this process by heating
up the part involved with a normal hairdryer on a
low setting.

REFRIGERATOR-
FREEZER
FCB 285
INSTRUCTION BOOKLET
2222 010-11
