AE DR10 SWEEPER
ASSEMBLY INSTRUCTIONS
FOR AE DR10RTR OR DR10 KIT
To Our Valued Customer:
Thank you for your purchase from Five Star Hobbies. We are a small
business with a goal to make high quality items that our customer can
enjoy. We also want to thank all of you, the customer, for believing in
us and spending your hard earned money on our products.
We are constantly looking for ways to imporve our products and
customer support. ALL constructive criticism is always welcome. Also,
if you have an issues with your product or maybe you just have a
question, there are many places to go get help. If you are on Facebook,
you can check out our group page. It is called Five Star Hobbies
Breakout and Street Sweeper Group. We also have our own Facebook
page called Five Star Hobbies. You can message us through Facebook,
but we do not monitor Facebook messages as closely as we would like
because of our busy schedule. If you need Immediate assistance or have
questions, pleas call the store at 531-867-3301. We have helpful staff at
the store that will be happy to help. If they do not have the answer, they
will find it for you and call you back. Here is our contact information:
FiveStarHobbies
10935EmmetSt.
Omaha,NE68164
Phone:531‐867‐3301
Email:[email protected]m
www.fivestarhobbies.com
PartNumber DescriptionOfProduct Quantity
KIT61005 DR10STREETSWEEPERKIT 1
70027 DR10TeamKit 1
PartNumber DescriptionOfProduct Quantity
DescriptionOfproduct Quantity
FrontWheels 2
FrontTires 2
Rearwheels 2
RearTries 2
Servo 1
Transmitter 1
Receiver 1
ElectronicSpeedControler 1
Motor 1
PinionGear 1
SpurGear 1
BodyandPaint 1
FrontBodyPosts 2
RearBodyPosts 2
ShockOilOfChoice 1
FiveStarhobbies
BREAKOUTOPTIONALUPGRADES
Popular items to change on your "SLIDER" are these items:
Wealsohavemanyoptionalpartsavailableatourwebsite.Www.fivestarhobbies.comHerearesomelinks:
To complete your DR10 Sweeper build in "SLIDER" form, you will need the following items:
To complete your DR10 Sweeper build, you will need the following items:
Bag1
PartNumber Description Quantity
61003 FrontBumper‐2.5mm 1
61004 FrontMidBumper‐2.5mm 1
61024 PrintedSkidPlate 1
3x10mmFH ChassistoMidBumper 2
3x10mmBH MidBumpertoFrontBumper 4
M3LockNuts MidBumpertoFrontBumper 6
Bag2
PartNumber Description Quantity
61207 DR10PrintedKickup 1
61213 PrintedBulkheadSpacer 1
35mmStandoff ChassistoDR10TopPlate 2
3x10mmBH TopPlatetoStandoff 2
3x8mmFH ServoMount 2
3x10mmFH ChassistoKickupandChassistoStandoff 5
3x18mmBH KickuptoAEBulkhead 4
Attachthe61207printedbulkheadspacerontotheAEfrontbulkhead.
Linethekickup,bulkheadspacer,andbulkheadupandinsert(4)3x18mmBHscrewsintothebottomofthe
kickup.
Oncetightened,lineupthekickuptothechassisplateandinsert(3)3x10mmFHintothekickup.
Install(2)35mmstandoffsintotheAETopPlatewith(2)3x10mmBHontopand(2)3x10mmFHunderthe
chassisplate.
Installyourservomountsusingtheincluded(2)3x8mmFHscrews.
Attachthefrontbumpertothemidbumperandskidplateusing(4)3x10BHscrewsand(4)Locknuts.At
thistimeyoumayattachthebumpertothechassiswiththeremaining(2)3x10mmFHandlocknuts.
Bag3
PartNumber Description Quantity
61206 V2ChassisSideRail 2
3x10mmFH ChassistoRail 8
M3LockNut ChassistoRail 8
Bag4
PartNumber Description Quantity
61214 DR10RearRiserPlate 1
3x10mmBH RearShockTower 2
3x10mmFH ChassistoRearRiser 6
3x30mmFH BackHalftoCamberplate 2
3x35mmFH BackHalftoShockTower 2
M3LockNut 10
Bag5
PartNumber Description Quantity
61228 WaterfallChassisMount 1
61229 WaterfallTowerMount 1
61230 WaterfallTurnbuckle 1
3x10mmFH ChassistoLowerWaterfallBrace 3
3x25mmFH UpperWaterfallBracetoShockTower 2
3x25mmBH LowerWaterfallBracetoTurnbuckle 1
3x45mmBH UpperWaterfallBracetoTurnbuckle 1
M3LockNuts 2
Attachthesiderailstothechassisplatewith(4)3x10FHoneachsideofthecar.
Linetherearriserplateupwiththechassisandinsert(6)3x10mmFHscrewsand(6)M3locknuts.Slidethe
rearendoftheDR10ontothe61214rearriserplateandinsert(2)3x35mmFHintotherearmosttwoholes.
Securethemwithlocknuts.Use3x30mmFHforthefrontholesmatingtherearriserplatetotheDR10back
half.Finallyusethe(2)3x10mmBHontheforwardfacingshocktowerholes.
Part# Description Quantity
61003 FrontBumper 1
61004 MidBumper 1
61024 SkidPlate 1
61205 DR10SSChassisPlate 1
61206 DR10SSChassisSideRail 2
61207 DR10SSKickup1
61213 DR10SSKickupSpacer 1
61214 DR10SSRearRiser 1
61228 DR10SSWaterfallChassisMount 1
61229 DR10SSWaterfallShockTowerMount 1
61230 DR10SSWaterfallTurnbuckle 1
Hardware
3x10mmBH 8
3x18mmBH 4
3x25mmBH 1
3x45mmBH 1
3x8mmFH 2
3x10mmFH 24
3x25mmFH 2
3x30mmFH 2
3x35mmFH 2
INSTALLTHEUPPERWATERFALLBRACEMOUNTONTOTHEREARSHOCKTOWERWITH(2)3X25MMFH
SCREWS.THENINSTALLTHELOWERWATERFALLBRACEMOUNTONTOTHECHASSISUSING(3)3X10MMFH
INTHETHREENEARESTHOLESTOTHEBACKHALFPLATE.FINALLYINSTALLTHETURNBUCKLETOLINKTHE
UPPERANDLOWERWATERFALLMOUNTS.
DR10SweeperPickList
