INSTALLATION INSTRUCTIONS
PROFESSIONAL RANGE MODELS
48” DUAL FUEL,CONVECTION,SELF-CLEAN WITH SEALED BURNERS**
48” NATURAL GAS MODELS
*TN537-7BW
*TN537-7W
**THESE MODELS ARE NOT FIELD CONVERITBLE FOR LP/PROPANE GAS.THEY MUST BE
ORDERED FROM THE FACTORY SET FOR NATURAL OR LP/PROPANE GAS.**
48” LP/PROPANE GAS MODELS
*PN537-7BW
*PN537-7W
**THESE MODELS ARE NOT FIELD CONVERTIBLE FOR NATURAL GAS.THEY MUST BE
ORDERED FROM THE FACTORY SET FOR NATURAL OR LP/PROPANE GAS.**
IF YOU HAVE QUESTIONS,CALL 800-251-7224, 8AM TO 5PM EASTERN TIME,OR VISIT OUR
WEBSITE,WWW.FIVESTARRANGE.COM.

Installation Instructions
BEFORE YOU BEGIN CAUTION:
Read these instructions completely and
carefully.
THESE RANGES SHOULD BE INSTALLED IN
CONJUNCTION WITH A SUITABLE
OVERHEAD
VENT HOOD. Due to the high heat capacity of this unit,
• IMPORTANT -Save these instructions for local particular attention should be paid to the hood and duct
inspector's use. work installation to assure it meets local building codes.
• IMPORTANT - Observe all governing codes and Standard countertop installations:
ordinances.
A 1200 CFM hood is recommended for 48" & 60" ranges.
A 600 CFM hood is recommended for 30" & 36" ranges.
• Note to Installer - Be sure to leave these instructions
with the Consumer. Hoods should be 24" min. deep and at least the same width
as the cooktop.
• Note to Consumer - Keep these instructions for future
reference. Check local building codes for the proper method of gas
range installation. Local codes vary. Installation, electrical
• FiveStar recommends this product be installed by a connections and grounding must comply with applicable
licensed professional. codes. In the absence of local codes, the gas range should
be installed in accordance with the National Fuel Gas Code
• Product failure due to improper installation is not ANSI 223.1, latest edition and National Electrical Code
covered under the Warranty. ANSI/NFPA 70, latest edition
WARNING: CAUTION:
This appliance must be properly grounded. These ranges weigh up to 510 pounds. Some
disassembly will reduce the weight considerably. Due to
In the Commonwealth of Massachusetts: the weight and size of the range and to reduce the risk of
• This product must be installed by a licensed plumber personal injury or damage to the product and/or damage
or gas fitter. to the floor, TWO PEOPLE ARE REQUIRED FOR PROPER
INSTALLATION.
• When using ball type gas shut-off valves, they shall
be T handle type.
• A flexible gas connector, when used, must not
exceed 3 feet.

INSTALLATION INSTRUCTIONS
Please read these instructions
before attempting to install this
range
Inspection and Unpacking
Check the range carton for visible
damage. If there is damage or even
creases in the carton, contact the
carrier, request an inspection and file
the appropriate freight claim. Do not
refuse shipment. Responsibility for
shipping damage is with the carrier
and the dealer or end user. Cut the
shipping straps, then carefully lift the
carton up from the range. This will
help eliminate possible damage to the
backguard that is packed in the top of
the range carton.
Remove, unwrap and temporarily lay
aside any parts that are not attached
to the range. Make sure no parts are
left in the carton for accidental
disposal. Carefully inspect the range
for damage.

STEP 1
REMOVE PACKAGING
Before moving the range indoors:
Remove outer carton and packing material from the
shipping base. The range is now ready for removal
from the wooden base.
STEP 2
Due to the weight of these ranges, use a dolly with
soft wheels to move this range.
Lift the range onto the dolly and move indoors.
The range should be placed onto sliders to
prevent damage to the floor.
STEP 3
To simplify handling and to reduce the weight of
the range:
Remove the grates and the drawers below the
Knobs (on grill and griddle models).
Remove grill or griddle.
Remove the broiler pans, racks and literature
Package from inside oven(s).

STEP 5
CONNECTING THE RANGE TO ELECTRIC
WARNING:
THIS APPLIANCE MUST BE CONNECTED AS SHOWN IN FIGURE 1 OR 2. IF
THE CORD IS REPLACED IT MUST BE RATED AT 250 VOLTS, 40 AMPERES
AND CERTIFIED FOR USE ON HOUSEHOLD RANGES.

STEP 7
INSTALLING THE BACKGUARD –SEALED BURNER MODELS
NOTE:PLEASE READ ALL INSTRUCTIONS BEFORE STARTING INSTALLATION.
7-1
Remove the burner grates, griddle/grill and housing.
7-2
From the front of the range, remove the Phillip screws in the rear of each burner pan (black pan
where the top burners are located).
7-3
From the rear of the range, remove two screws from the rear of the side panels, the upper most
screw on each side. You will need a 5/16” nut-driver or 5/16” socket to remove these screws. (Tools
with a magnetized tip will be helpful in replacing the backguard screws.)
7-4
From the rear of the range, locate the upper wire cover with tab slots. Remove two 5/16” mounting
screws. This cover will be reinstalled once the backguard is installed.
7-5
Screws are installed in the backguard, at the Factory for assembly to the backguard support. It is
important that you locate and remove these four screws from the backguard before you attempt to
install the backguard to the range backguard support.
7-6
Remove the vinyl protective covering from the front of the backguard.
7-7
The front of the backguard should fit between the back burner pans and the rear support. If the
burner pan and rear support have a tight tolerance, place a thin bladed screw driver at either end,
between the burner pan and rear support, to start placement of the backguard. Slide the backguard
over the exhaust vent(s). Align the slots in the front of the backguard with the rear support bar
locator studs.
7-8
With the backguard in position, secure the backguard to the rear backguard support using the four
5/16” screws removed in step 7-4, re-install the screws in the edge of the side panels and replace
the screws in the back of each burner pan. Re-install griddle/grill housing. Do not re-install the
grates at this point.
7-9
Reinstall the upper wire cover that was removed in Step 7-4. Place the cover into position with
the lower backguard panel fitting into the tab slots. Reinstall the two 5/16” mounting cover screws.

DIAGRAM FOR STEP 7
STEP 8
LEVEL THE RANGE
1. Remove shipping tape from the leveling
legs.
2. Carefully slide the range into position.
Be careful not to damage the floor or
entangle power cord and gas flexible
tubing.
3. To adjust leveling legs, turn counter-
clockwise to raise the range; clockwise
to lower. “Channel-lock” type pliers are
recommended. Avoid using a pipe wrench
which can scar the legs.
IMPORTANT: The range should always be
installed at countertop height or higher. DO
NOT INSTALL THE RANGE LOWER THAN
ADJACENT COUNTERTOP HEIGHT, DUE
TO RISK OF A FIRE HAZARD

STEP 11
OVEN OPERATION
GAS OVEN
•Turn oven thermostat knob counter clockwise to 350°.
•The oven burner should light within 60 seconds.
ELECTRIC OVEN
•Turn oven thermostat knob counter clockwise to 350°
in bake position. It will take a couple of minutes before
a change in color will occur to the lower element.
•Turn oven thermostat knob to broil position. It will take
a couple of minutes before a change in color will occur
to the upper element.
GRIDDLE OPERATION
•Turn griddle thermostat knob counter clockwise to 350°.
•The griddle burner should light within 60 seconds.
STEP 12
GAS & ELECTRIC SUPPLY
•Turn gas supply “on”.
•Turn electric supply “on”.

STEP 13
CHECKLIST FOR SEALED BURNER INSTALLATION
MAKE SURE ALL CONTROLS ARE IN THE “OFF” POSITION.
Gas supply is “on”
Electric power is “on”
Check for proper seating of burner caps into burner base
Burner grates in position
Oven and broiler racks installed
Surface burner ignition test
Griddle/Grill burner ignition test
Griddle/Grill assembly in position
Gas oven ignition test
Electric oven – Check bake and broil function
Check operation of convection fan
MAKE SURE ALL CONTROLS ARE LEFT IN THE “OFF” POSITION.
Date Installed & Inspected __________________________________________________
Authorized Installer’s Signature _____________________________________________
Please Print Name ________________________________________________________
NOTE: Please leave this checklist, Use & Care manual and product registration
card with the Homeowner.
