FlashLogic RDSUSBV1 Troubleshooting guide

Owner’s Manual/Installation Guide
RDSUSBV1

2
Copyrights and Trademarks
Copyright 2014 Audiovox Electronics Corporation
The Audiovox and FlashLogic logos are trademarks of Audiovox Electronics
Corporation
iPod and iPhone are trademarks of Apple, Inc.
Sirius and Sirius XM are trademarks of Sirius XM Radio Inc.
All Trademarks and Logos are the property of their respective owners.
All rights reserved.

3
Warning And Safety
Product Registration
Kit Contents
Frequency Conguration Settings
Compatible Devices
Note To Installers
Connection Diagram
Installation
User’s Manual
RDS / Text Display Example
Basic Operation I.
Basic Operation II.
OEI Control Application - Settings
OEI Control Application - Music Remote Control
..........................................................4
.........................................................5
......................................................................6
.....................................6
.........................................................7
..............................................................8
.........................................................9
......................................................................10
................................................................11
..........................................13
...........................................................14
..........................................................15
................................16
...........17
Table of Contents
Wireless Remote Function for iPod/iPhone App
Wireless Remote Function for USB Flash Drive
Notes on USB Memory Source
Basic Operation - Satellite Radio
OEI Control App - Satellite Radio
Wireless Remote Function for SIRIUS
Sirius XM Operation
Internet Radio App
iPod/iPhone Charging
Troubleshooting
Firmware Update
Installer Notes
Warranty
............18
...........19
.....................................20
..................................21
..................................22
XM...................23
(Using Wireless Remote)..............24
........................................................25
....................................................27
.......................................................28-30
...........................................................31
...............................................................32
........................................................................34

4
Please read these instructions carefully before proceeding. Failure to follow instructions may result in
improper operation or injury. Neither Audiovox Electronics Corporation nor Apple Inc., it’s regional ofces,
distributors or resellers take any responsibility for any damage or injury as a result of using the integration kit.
- Do not open, disassemble or alter the interface in any way.
- Do not insert anything into the casing.
- Do not cut or try to alter cables in any way and always use the correct connections.
- Only operate unit when the vehicle is stationary or ask passengers to operate it for you.
- Do not allow the Apple iPod/iPhone to distract you from driving.
- Exercise good judgement and keep your eyes on the road at all times.
- Do not expose unit to extreme temperatures, humidity or shock.
- Keep the unit and iPod/iPhone away from uids.
- Keep away from children! - Interface components may contain small parts, that may be broken or
disassembled and components may become loose from vibration and heat. Small components and
packaging materials may be a choking hazard when handled by children.
Warnings and Safety Instructions

5
Thank you for purchasing this integration kit. Please review this booklet before operating the unit. This
interface was designed and manufactured to seamlessly integrate with your vehicle’s factory audio system.
We recommend registering your Audiovox product so you can receive news about important rmware updates
and have unlimited access to our online support system.
To register your FlashLogic product, please complete the following steps:
1. Visit http://www.audiovoxoei.com
2. Look up and save the serial number of the product.
3. Complete the product registration form.
4. Submit the form.
5. Save the registration sheet in a safe place for future reference.
If you are unable to complete the registration via internet, please call Audiovox at 1-800-645-4994.
Congratulations on your purchase!
Product Registration
Prior to installation make sure the module’s rmware is up to date to ensure compatibility
with the latest features and enhancements. Please refer to page 31 to update rmware.

6
RDSUSBV1 Kit Contents
Frequency Conguration Settings
Interface
Module
ON/OFF Switch Positions FM (MHz) Dip switch 1 Dip switch 2
Module
Frequency Selector
Power
Cable
ON
12
OFF 88.7
93.3
97.5
107.7
OFF
ON
ON
OFF
OFF
OFF
ON
ON
USB
Extension
IR Receiver &
Remote
NOTE - Other frequencies can be selected using the
Original Equipment Industry (OEI) Control Application!
112-4213 112-4191 112-4217

7
Supported Devices
iPhone support
iPhone 5s
iPhone 5c
SXV200V1
iPhone 5
iPhone 4s
SXV300
iPhone 4
iPhone 3GS
iPhone 3G
iPod touch 5th
iPod touch 4th
iPod touch 3rd
iPod touch 2nd
iPod nano 7th
iPod nano 6th
iPod nano 5th
iPod nano 4th
iPod Classic
iPod support Sirius XM support
For the most up to date supported device list,
please visit www.ashlogic.com
iPhone 6
iPhone 6 Plus

8
Attention installer! Please read the following!
Audiovox strongly recommends that the unit be installed in an easily accessible place!
DO NOT PLACE IT BEHIND THE RADIO AND DO NOT HIDE UNDER CARPET!
Whether the unit is professionally or self installed, put the module where you can get to it easily in the future.
(Have the installer show you where the box is located.)
Installing the RDSUSBV1 module behind the radio will make it difcult to:
-Add possible future upgrades, changing software, adding new features, improving operation.
-Access the AUX input on the module to attach any audio device.
-Access the DIP switches located on the module.
-Remove the unit in case of failure.
MAKE SURE THAT THE MODULE IS INSTALLED IN AN ACCESSIBLE PLACE!

9
Connection Diagram
USB/Dock Cable
USB
FLash
Drives
Sirius XM Satellite
Radio Tuner
USB
Upgrade Port
+12
(Yellow)
Ground
(Black)
Ignition
(Red)
Power Cable
iPhone
or
Antenna
Out
Antenna
In
Module (Front)
Module (Back)
IR Receiver
Wireless Remote
PLAYLIST ARTISTALBUM
1
MENUSOURCE
2 3
45 6

10
Installation
1. Verify compatibility. Certain radios require
antenna adapter(s), not included in the kit.
5. Test for 12V constant, 12V switched, and ground sources.
Splice into with leads from power cable.
6. Route kit to glove box or other accessible location.
7. Connect battery and test*
8. Complete installation by re-installing the radio
9. Save the frequency to a preferred preset on the radio if
desired.
*CAUTION: Do NOT connect any mini-din and iPod cable used on other Audiovox
products to the mini-din port. Failure to follow this will cause permanent damage
to the unit/iPod!
2. Disconnect battery.
3. Remove radio from car.
4. Install Universal RDS USB cable. Plug the
factory radio antenna to the receptacle on
the module.

11
Owner’s Manual

12
Please make sure to register the product to receive updates and technical support.
The following pages will guide you through the operation of the product.
Some features may vary depending on the factory car radio, the iPod or iPhone and the Satellite Radio
tuner type as well as rmware updates applied to the interface module.
Thank you for purchasing this product!

13
Radio Data System (RDS) Text Display On Typical Car Radios
123456--
AM FM
m
+
FM 88.7 * Song * Artist RDS
TEXT
Radio
Source
RDS text display
available on RDS
capable radios.
Radio tuned
to frequency
as selected on
page 6.
Some radios
feature a text/
info button
for additional
station infor-
mation.
Image is for illustration purposes only. Please review your vehicle radio’s documentation
for specic details on how to operate it and for details on RDS technology.

14
Basic Operation I.
1. Turn on the vehicle ignition to (ACC/ON) and turn the radio ON.
2. Select the FM source to tune to the preset station set by the conguration switches (see page 6).
3. Tune the radio to the channel that is set by the frequency selector.
123456--
AM FM
m
+
FM 88.7 RDS
TEXT

15
4. Connect the iPhone or iPod using an Apple authorized USB cable to the RDSUSBV1 module.
5. Use wireless remote to control devices, or control desired music on your iPod/iPhone.
6. Launch the music player or any music application and press play to start music playback.
7. To resume listening to local radio stations either pause or disconnect your iPod/iPhone, or press
the Source button on the optional wireless remote controller.
Basic Operation II.

16
OEI Control Application - Settings
1. Download the Audiovox Original Equipment Industry OEI Control App
from the Apple iTunes store.
2. Launch the application and connect the iPhone to the RDSUSBV1
module using an Apple authorized USB cable. This application only
works when the iPhone is connected through the USB port.
3. Explore the features and settings of the application.
4. Customize the RDSUSBV1 settings with the help of the OEI control
app.
A rmware update might be required to the RDSUSBV1 module.
For more information, please visit www.audiovoxoei.com

17
OEI Control App - Music Remote Control
The control app features a “car friendly” remote control User Interface (UI)
for the iPod playback.
OBEY ALL TRAFFIC LAWS AND NEVER OPERATE A MOBILE PHONE
WHILE DRIVING YOUR VEHICLE.
NOTE: User Interface functions are subject to change.

18
Wireless Remote Function For iPod / iPhone
iPod: Shufe SONG (within a PLAYLIST/
FOLDER) / Shufe ALBUM / Shufe off
Toggle the audio sources between iPod/
USB, SIRIUS/AUX and FM
iPod: Skip to the next ALBUM
iPod: Skip to the previous ALBUM
Play / Pause
iPod: Repeat one / Repeat all / Repeat
off
iPod: Skip to the next PLAYLIST
iPod: Skip to the previous PLAYLIST
3
1
4
6
*Next / Previous ARTIST function is currently not supported.
iPod: Next Track
App: Next station/song (App dependent)
iPod: Previous Track
App: Prev station/song (App dependent)

19
*Next / Previous ARTIST function is currently not supported.
Shufe SONG (within the ash drive) /
Shufe FOLDER /Shufe off
Repeat one / Repeat all / Repeat
FOLDER
Wireless Remote Function For USB Flash DriveS
Next Track
Previous Track
Skip ahead 10 Tracks every 1 second
Skip back 10 Tracks every 1 second
PLAYLIST ARTIST ALBUM
MENU SOURCE
1
2
3
4
5
6
Toggle the audio sources between iPod/
USB, SIRIUS/AUX and FM
Play / Pause
Skip to the next folder on the USB drive
Skip to the previous folder on the USB
drive

20
• This unit will recognize the rst 8 levels of folders, with up to 50 accessible folders within each folder. Only the rst 650
les will be read in each folder, the rest will be ignored.
• Songs play in the order they were added to the ash drive.
• The USB device must be in FAT16/32 format and contain supported MP3, WMA or AAC content.
• USB hard drives and USB hubs are not supported
Notes on USB Memory Structure
FAT16/32 MP3 - WMA - AAC
