INSTALLATION GUIDE
for the
SB-CAN-G2MVX3D/10TW3
SB-CAN-G2MVX3P/10TW3
SKU# 94672 & 94673
2019 & Up Can-Am Maverick X3
Thank you for choosing a JL Audio Stealthbox® for your automotive sound system.
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox® installed by your
authorized JL Audio dealer. The installation professionals employed by your
dealer have the necessary tools and experience to disassemble and reassemble
your vehicle properly. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
If you choose to perform the installation yourself, it is absolutely
vital that the Stealthbox®be properly mounted to the vehicle
according to these instructions. Failure to mount the enclosure
properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the
enclosure caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a
collision or sudden deceleration.
INSTALLATION
D IFF ICU LT Y:
ESTIMATED TIME:
2 HOURS
Enclosure Type: Sealed
Driver Type: 10TW3-D4
Nominal Impedance: 2 ohms
Continuous Power Handling: 400 watts (RMS method)
Continued on Next Page
25
OUT
OF
SB-CAN-G2MVX3D/10TW3 & SB-CAN-G2MVX3P/10TW3 INSTR_SKU# 011529
INCLUDED HARDWARE
1
1
5
2
4
3
2
3
Continued on Next Page
Page 2 • JL Audio, Inc., 2019
BOM ID Qty SKU Description
1 6 151709 1/4 - 20 x 1-1/2” Socket Cap Screw
2 6 150066 1/4” Split Lock Washer
3 6 153734 1/4” Flat Washer
4 2 153764 Stainless Steel Cushion Clamp
5 1 152729 Template
- 2 154058 1-1/4” Aluminum Spacer (not shown)
- 1 150249 Foam Tape (not shown)
Note: For optimum performance, JL Audio recommends applying the included Foam Strips (or sound damping material) to surrounding plastic panels to reduce unwanted vibrations.
SB-CAN-G2MVX3D/10TW3 & SB-CAN-G2MVX3P/10TW3 INSTR_SKU# 011529
POWER RECOMMENDATION
JL Audio recommends high quality ampliers such as the JL Audio MX300/1. The diagram below shows the recommended crossover settings for the MX300/1. For a detailed description of the
amplier settings, consult the owner’s manual for the amplier. If another amplier is being used, please reference this illustration and use similar settings on that amplier.
CONNECTIONS
Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbox®. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your
Stealthbox® amplier. Other kits are available should you be using more than one amplier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for
both channels of the amplier. JL Audio recommends using 12AWG speaker wire for subwoofers such as our XC-BCS12-25.
Continued on Next Page
Page 3 • JL Audio, Inc., 2019
SB-CAN-G2MVX3D/10TW3 & SB-CAN-G2MVX3P/10TW3 INSTR_SKU# 011529
Page 4 • JL Audio, Inc., 2019 Continued on Next Page
STEP 8
Carefully remove the seat from the vehicle.
STEP 7
Cover the cage and frame rails to prevent
scratching prior to removing the seat.
STEP 6
NOTE: This step is required for the driver’s
side Stealthbox® only.
Disconnect the seat belt harness at the inner
seat belt bolt.
STEP 5
Slide the seat forward. Remove the two 18mm
rear seat nuts and the two 16mm seat belt
bolts.
STEP 4
Pass the seat belt through the openings in the
seat back.
STEP 3
Flip the seat cushion forward and separate the
seat belt.
STEP 2
Remove the two front 1/2” seat bolts from the
seat bracket.
NOTE: The indicated lower seat bolt
locations should not be used after the
Stealthbox® installation. Be sure to use the
upper seat bolt locations during
reassembly.
STEP 1
NOTE: This manual illustrates the
installation of the passenger side
Stealthbox®. The installation procedure for
the driver side Stealthbox® will be the same.
Empty the front of the vehicle.
SB-CAN-G2MVX3D/10TW3 & SB-CAN-G2MVX3P/10TW3 INSTR_SKU# 011529
Page 5 • JL Audio, Inc., 2019 Continued on Next Page
STEP 16
Carefully set the enclosure into the vehicle, and
slide it forward and under the front seat
bracket, as shown. Be sure the rear of the
enclosure is flush with the plastic floor panel.
STEP 15
Turn the enclosure over. Attach Foam Tape to
the bottom of the enclosure, as shown.
STEP 14
Remove the eight subwoofer mounting screws,
then remove and disconnect the subwoofer.
STEP 13
Place the Stealthbox® on a flat surface with the
subwoofer facing up.
STEP 12
Remove the Template from the vehicle.
Using a 1/8” drill bit, drill a pilot hole through
each of the marks made in the previous step.
Using a 5/16” drill bit, enlarge each of the pilot
holes.
STE P 11
Using a small pick tool, mark each of the four
hole locations through the Template onto the
plastic floor panel.
STEP 10
Position the Template on the vehicle floor, as
shown. Push the Template forward and to the
outside, as shown, until flush with the frame
rails.
STEP 9
Place a 1-1/4” Aluminum Spacer over each of
the rear seat studs, as shown.
SB-CAN-G2MVX3D/10TW3 & SB-CAN-G2MVX3P/10TW3 INSTR_SKU# 011529
Page 6 • JL Audio, Inc., 2019
CONGRATULATIONS!
You have completed the installation for this model! Enjoy your new Stealthbox®!
MID/HIGH FREQUENCY DRIVER FITMENT
VeX™ Enclosed Speaker Systems are ideal for powersports and o-road vehicle applications. Each
weatherproof pod can be mounted to a roll cage precisely aimed for optimum sound. Mounting
xtures are available to t a variety of roll cage diameters.
STEP 19
Wrap a Stainless Steel Cushion Clamp over the
outside front frame rail, aligning its holes with
the threaded insert in the top of the enclosure.
Slide a 1/4” Split Lock Washer and a 1/4” Flat
Washer over a 1/4 - 20 x 1-1/2” Socket Cap
Screw, pass the assembly through the holes
in the Stainless Steel Cushion Clamp, and into
the threaded insert. Repeat the process for the
inside front frame rail, then fully tighten.
STEP 18
Slide a 1/4” Split Lock Washer and a 1/4” Flat
Washer over each of four 1/4 - 20 x 1-1/2”
Socket Cap Screws.
From under the vehicle, pass each assembly
through a drilled hole in the plastic floor panel,
into a threaded insert in the bottom of the
enclosure, and fully tighten.
STEP 17
Connect and reinstall the subwoofer and eight
subwoofer mounting screws.
STEP 20
Carefully reinstall the seat, and pass the
seat belt back through the openings in the seat
back. Connect the seat belt harness (driver’s
side only). Reinstall the rear seat nuts, seat belt
bolts, and front seat bolts.
Note: For optimum performance, we
recommend applying the included Foam Strips
(or sound damping material) to surrounding
plastic panels to reduce unwanted vibrations.
All specifications are subject to change without notice. “JL Audio®” and “How we play®” are registered trademarks of JL Audio, Inc. “Ahead of the Curve” and its respective logo are trademarks
of JL Audio, Inc.
Printed in USA • ©2019 JL Audio, Inc. • For more detailed information please visit us online at www.jlaudio.com.
(954) 443-1100
www.jlaudio.com
JLA-SKU# 011529 • ver. 09.05.2019 • 10369 NORTH COMMERCE PARKWAY • MIRAMAR, FLORIDA • 33025 • USA
®
SB-CAN-G2MVX3D/10TW3 & SB-CAN-G2MVX3P/10TW3 INSTR_SKU# 011529
*011529*
