Flavel WFA5100W User manual

Washing Machine
User’s Manual
WFA5100W

2/ EN Washing Machine / User’s Manual
1 Important instructions for safety and environment
Thissectioncontainssafetyinstructionsthatwillhelpprotectfromriskofpersonalinjury
orpropertydamage.Failuretofollowtheseinstructionsshallvoidanywarranty.
1.1 General safety
• Thisproductcanbeusedbychildrenatandabove8yearsoldandbypersonswhose
physical,sensoryormentalcapabilitieswerenotfullydevelopedorwholackexpe-
rienceandknowledgeprovidedthattheyaresupervisedortrainedonthesafeusage
oftheproductandtherisksitbringsout.Childrenmustnotplaywiththeproduct.
Cleaningandmaintenanceworksshouldnotbeperformedbychildrenunlesstheyare
supervised by someone.
• Neverplacetheproductonacarpet-coveredfloor.Otherwise,lackofairflowbeneath
themachinewillcauseelectricalpartstooverheat.Thiswillcauseproblemswithyour
product.
• Iftheproducthasafailure,itshouldnotbeoperatedunlessitisrepairedbythe
AuthorizedServiceAgent.Thereistheriskofelectricshock!
• Thisproductisdesignedtoresumeoperatingintheeventofpoweringonaftera
powerinterruption.Ifyouwishtocanceltheprogramme,see"Cancellingthepro-
gramme" section.
• Connecttheproducttoagroundedoutletprotectedbya16Afuse.Donotneglectto
havethegroundinginstallationmadebyaqualifiedelectrician.Ourcompanyshallnot
beliableforanydamagesthatwillarisewhentheproductisusedwithoutgrounding
inaccordancewiththelocalregulations.
• Thewatersupplyanddraininghosesmustbesecurelyfastenedandremainundama-
ged.Otherwise,thereistheriskofwaterleakage.
• Neveropentheloadingdoororremovethefilterwhilethereisstillwaterinthedrum.
Otherwise,riskoffloodingandinjuryfromhotwaterwilloccur.
• Donotforceopenthelockedloadingdoor.Theloadingdoorwillbereadytoopenjust
afewminutesafterthewashingcyclecomestoanend.Incaseofforcingtheloading
door to open, the door and the lock mechanism may get damaged.
• Unplugtheproductwhennotinuse.
• Neverwashtheproductbyspreadingorpouringwaterontoit!Thereistheriskof
electric shock!
• Nevertouchtheplugwithwethands!Neverunplugbypullingonthecable,always
pull out by grabbing the plug.
• Usedetergents,softenersandsupplementssuitableforautomaticwashingmachines
only.
• Followtheinstructionsonthetextiletagsandonthedetergentpackage.
• Theproductmustbeunpluggedduringinstallation,maintenance,cleaningandrepai-
ring procedures.
• AlwayshavetheinstallationandrepairingprocedurescarriedoutbytheAuthorized
Service Agent. Manufacturer shall not be held liable for damages that may arise from
procedures carried out by unauthorized persons.
• Ifthepowercableisdamaged,itmustbereplacedbythemanufacturer,aftersales
serviceorasimilarlyqualifiedperson(preferablyanelectrician)orsomeonedesigna-
ted by the importer in order to avoid possible risks.

3 / EN Washing Machine / User’s Manual
• Placetheproductonarigid,flatandlevelsurface.
• Donotplaceitonalong-pilerugorsimilarsurfaces.
• Donotplacetheproductonahighplatformorneartheedgeonacascadedsurface.
• Donotplacetheproductonthepowercable.
• Neverusespongeorscrubmaterials.Thesewilldamagethepainted,chromeplated
and plastic surfaces.
1.2 Intended use
• Thisproducthasbeendesignedfordomesticuse.Itisnotsuitableforcommercial
use and it must not be used out of its intended use.
• Theproductmustonlybeusedforwashingandrinsingoflaundrythataremarked
accordingly.
• Themanufacturerwaivesanyresponsibilityarisenfromincorrectusageortransporta-
tion.
1.3 Children's safety
• Packagingmaterialsaredangeroustochildren.Keeppackagingmaterialsinasafe
placeawayfromreachofthechildren.
• Electricalproductsaredangerousforthechildren.Keepchildrenawayfromthepro-
ductwhenitisinuse.Donotletthemtotamperwiththeproduct.Usechildlockto
preventchildrenfrominterveningwiththeproduct.
• Donotforgettoclosetheloadingdoorwhenleavingtheroomwheretheproductis
located.
• Storealldetergentsandadditivesinasafeplaceawayfromthereachofthechildren
by closing the cover of the detergent container or sealing the detergent package.
Whilewashingthelaundryathightemperatures,theloadingdoorglass
becomeshot.Therefore,keepespeciallythechildrenawayfromthe
loadingdoorofthemachinewhilethewashingoperationisinprogress.
1.4 Package information
• Packagingmaterialsoftheproductaremanufacturedfromrecyclablematerialsinac-
cordancewithourNationalEnvironmentRegulations.Donotdisposeofthepackaging
materialstogetherwiththedomesticorotherwastes.Takethemtothepackaging
material collection points designated by the local authorities.
1.5 Disposing of the waste product
• Thisproducthasbeenmanufacturedwithhighqualitypartsandmaterialswhichcan
bereusedandaresuitableforrecycling.Therefore,donotdisposetheproductwith
normaldomesticwasteattheendofitsservicelife.Takeittoacollectionpointforthe
recyclingofelectricalandelectronicequipment.Pleaseconsultyourlocalauthorities
tolearnthenearestcollectionpoint.Helpprotecttheenvironmentandnaturalresour-
cesbyrecyclingusedproducts.Forchildren'ssafety,cutthepowercableandbreak
thelockingmechanismoftheloadingdoorsothatitwillbenon-functionalbeforedis-
posing of the product.

4 / EN Washing Machine / User’s Manual
1.6 Compliance with WEEE Directive
ThisproductcomplieswithEUWEEEDirective(2012/19/EU).Thisproduct
bearsaclassificationsymbolforwasteelectricalandelectronicequipment
(WEEE).
Thisproducthasbeenmanufacturedwithhighqualitypartsandmaterials
whichcanbereusedandaresuitableforrecycling.Donotdisposeofthe
wasteproductwithnormaldomesticandotherwastesattheendofitsservi-
celife.Takeittothecollectioncenterfortherecyclingofelectricalandelec-
tronicequipment.Pleaseconsultyourlocalauthoritiestolearnaboutthese
collection centers.
Compliance with RoHS Directive:
TheproductyouhavepurchasedcomplieswithEURoHSDirective(2011/65/EU).It
does not contain harmful and prohibited materials specified in the Directive.
2 Installation
RefertothenearestAuthorisedServiceAgentforinstallation
oftheproduct.Tomaketheproductreadyforuse,review
the information in the user manual and make sure that the
electricity,tapwatersupplyandwaterdrainagesystemsare
appropriatebeforecallingtheAuthorizedServiceAgent.If
theyarenot,callaqualifiedtechnicianandplumbertohave
any necessary arrangements carried out.
CPreparationofthelocationandelectrical,tapwaterand
wastewaterinstallationsattheplaceofinstallationis
under customer's responsibility.
Bwarning: Installationandelectricalconnectionsof
theproductmustbecarriedoutbytheAuthorized
ServiceAgent.Manufacturershallnotbeheldliablefor
damages that may arise from procedures carried out by
unauthorized persons.
Awarning: Priortoinstallation,visuallycheckiftheproduct
hasanydefectsonit.Ifso,donothaveitinstalled.
Damaged products cause risks for your safety.
CMakesurethatthewaterinletanddischargehoses
aswellasthepowercablearenotfolded,pinchedor
crushedwhilepushingtheproductintoitsplaceafter
installation or cleaning procedures.
2.1 Appropriate installation location
• Placethemachineonarigidfloor.Donotplaceitona
long pile rug or similar surfaces.
• Totalweightofthewashingmachineandthedryer-with
fullload-whentheyareplacedontopofeachother
reachestoapprox.180kilograms.Placetheproduct
on a solid and flat floor that has sufficient load carrying
capacity!
• Donotplacetheproductonthepowercable.
• Donotinstalltheproductatplaceswheretemperature
mayfallbelow0ºC.
• Placetheproductatleast1cmawayfromtheedgesof
other furniture.
2.2 Removing packaging reinforcement
Tiltthemachinebackwardstoremovethepackaging
reinforcement. Remove the packaging reinforcement by
pulling the ribbon.
2.3 Removing the transportation locks
Awarning: Do not remove the transportation locks before
taking out the packaging reinforcement.
Awarning: Remove the transportation safety bolts before
operatingthewashingmachine!Otherwise,theproduct
willbedamaged.
1.Loosenalltheboltswithasuitablespanneruntilthey
rotate freely (C).
2. Remove transportation safety bolts by turning them
gently.
3.AttachtheplasticcoverssuppliedintheUserManualbag
into the holes on the rear panel. (P)
CKeep the transportation safety bolts in a safe place to
reusewhenthewashingmachineneedstobemoved
again in the future.
CNevermovetheproductwithoutthetransportationsafety
boltsproperlyfixedinplace!

5 / ENWashing Machine / User’s Manual
2.4 Connecting water supply
The water supply pressure required to run the product is
between 1 to 10 bars (0.1 – 1 MPa). It is necessary to
have 10 – 80 liters of water flowing from the fully open
tap in one minutetohave your machine run smoothly.
Attach a pressure reducing valve if water pressure is
higher.
If you are going to use the double water-inlet product
as asingle (cold)water-inlet unit, you must install the
supplied stopper to the hot water valve before operating
the product. (Applies for the products supplied with a
blind stopper group.)
WARNİNG: Models with a single water inlet should not be
connected to the hot water tap. In such a case the laundry
will get damaged or the product will switch to protection
mode and will not operate.
WARNİNG: Do not use old or used water inlet hoses on the
new product. It may cause stains on your laundry.
1. Connect the special hoses supplied with the product to
the water inlets on the product. Red hose (left) (max. 90
ºC) is for hot water inlet, blue hose (right) (max. 25 ºC) is
for cold water inlet.
WARNİNG: Ensure that the cold and hot water connections
are made correctly when installing the product.
Otherwise, your laundry will come out hot at the end of
the washing process and wear out.
2. Tighten all hose nuts by hand. Never use a tool when
tightening the nuts.
3. Open the taps completely aftermaking the hose
connection to check for water leaks at the connection
points. If any leaks occur, turn off the tap and remove the
nut. Retighten the nut carefully after checking the seal. To
prevent water leakages and damages caused by them,
keep the taps closed when the machine is not in use.
2.5 Connecting tothe drain
•The end of the drain hose must be directly connected to
the wastewater drain or to the washbasin.
WARNİNG: Your house will be flooded if the hose comes
out of its housing during water discharge. Moreover, there
is risk of scalding due to high washing temperatures!
To prevent such situations and to ensure smooth water
intake and discharge of the machine, fix the end of the
discharge hose tightly so that it cannot come out.
•The hose should be attached to a height of at least 40
cm, and 100 cm at most.
•In case the hose is elevated after laying it on the floor
level orclose to the ground (less than 40 cm above the
ground), water discharge becomes more difficult and the
laundry may come out excessively wet. Therefore, follow
the heights described in the figure.
•To prevent flowing of dirty water back into the machine
and to allow for easy discharge, do not immerse the hose
end into the dirty water or do not drive it in the drain more
than 15 cm. If it is too long, cut it short.
•The end of the hose should not be bent, it should not be
stepped on and the hose must not be pinched between
the drain and the machine.
•If the length of the hose is too short, use it by adding
an original extension hose. Length of the hose may
not be longer than 3.2 m. To avoid water leak failures,
the connection between the extension hose and the
drain hose of the product must be fitted well with an
appropriate clamp as not to come off and leak.
2.6 Adjusting the feet
WARNİNG: In order to ensure that the product operates
more silently and vibration-free,itmuststand level and
balanced on its feet. Balance the machine by adjusting
the feet. Otherwise, the product may move from its place
and cause crushing and vibration problems.
1. Loosen the lock nuts on the feet by hand.
2. Adjust the feet until the product stands level and
balanced.
3. Tighten all lock nuts again by hand.
WARNİNG: Do notuse any tools to loosen the lock nuts.
Otherwise, they will get damaged.
2.7 Electrical connection
Connect the product to a grounded outlet protected by a 16
A fuse. Our company shall not be liable for any damages
that will arise when the product is used without grounding in

6 / EN Washing Machine / User’s Manual
accordancewiththelocalregulations.
• Connectionmustcomplywithnationalregulations.
• Powercableplugmustbewithineasyreachafter
installation.
• Ifthecurrentvalueofthefuseorbreakerinthehouseis
lessthan16Amps,haveaqualifiedelectricianinstalla
16Ampfuse.
• Thevoltagespecifiedinthe"Technicalspecifications"
sectionmustbeequaltoyourmainsvoltage.
• Donotmakeconnectionsviaextensioncablesormulti-
plugs.
Bwarning: Damagedpowercablesmustbereplacedby
theAuthorizedServiceAgents.
Transportation of the product
1. Unplug the product before transporting it.
2.Removewaterdrainandwatersupplyconnections.
3.Drainallwaterthathasremainedintheproduct.(SEE
5.5)
4.Installtransportationsafetyboltsinthereverseorderof
removalprocedure;(SEE2.3)
CNevermovetheproductwithoutthetransportationsafety
boltsproperlyfixedinplace!
Awarning:Packagingmaterialsaredangeroustochildren.
Keeppackagingmaterialsinasafeplaceawayfrom
reach of the children.
3 Preparation
3.1 Sorting the laundry
• Sortlaundryaccordingtotypeoffabric,colour,and
degreeofsoilingandallowablewatertemperature.
• Alwaysobeytheinstructionsgivenonthegarmenttags.
3.2 Preparing laundry for washing
• Laundryitemswithmetalattachmentssuchas,
underwiredbras,beltbucklesormetalbuttonswill
damagethemachine.Removethemetalpiecesorwash
theclothesbyputtingtheminalaundrybagorpillow
case.
• Takeoutallsubstancesinthepocketssuchascoins,
pens and paper clips, and turn pockets inside out and
brush.Suchobjectsmaydamagetheproductorcause
noise problem.
• Putsmallsizeclothessuchasinfant'ssocksandnylon
stockingsinalaundrybagorpillowcase.
• Placecurtainsinwithoutcompressingthem.Remove
curtain attachment items.
• Fastenzippers,sewloosebuttonsandmendripsand
tears.
• Wash“machinewashable”or“handwashable”labeled
productsonlywithanappropriateprogramme.
• Donotwashcoloursandwhitestogether.New,dark
coloured cottons release a lot of dye. Wash them
separately.
• Toughstainsmustbetreatedproperlybeforewashing.If
unsure,checkwithadrycleaner.
• Useonlydyes/colourchangersandlimescaleremovers
suitableformachinewash.Alwaysfollowtheinstructions
on the package.
• Washtrousersanddelicatelaundryturnedinsideout.
• KeeplaundryitemsmadeofAngorawoolinthefreezer
forafewhoursbeforewashing.Thiswillreducepilling.
• Laundrythataresubjectedtomaterialssuchasflour,
limedust,milkpowder,etc.intenselymustbeshakenoff
beforeplacingintothemachine.Suchdustsandpowders
on the laundry may build up on the inner parts of the
machine in time and can cause damage.
3.3 Things to be done for energy saving
Followinginformationwillhelpyouusetheproductinan
ecological and energy-efficient manner.
• Operatetheproductinthehighestcapacityallowedby
the programme you have selected, but do not overload;
see,"Programmeandconsumptiontable".
• Alwaysfollowtheinstructionsonthedetergent
packaging.
• Washslightlysoiledlaundryatlowtemperatures.
• Usefasterprogrammesforsmallquantitiesoflightly
soiled laundry.
• Donotuseprewashandhightemperaturesforlaundry
that is not heavily soiled or stained.
• Ifyouplantodryyourlaundryinadryer,selectthe
highestspinspeedrecommendedduringwashing
process.
• Donotusedetergentinexcessoftheamount
recommended on the detergent package.
3.4 Initial use
Beforestartingtousetheproduct,makesurethatall
preparationsaremadeinaccordancewiththeinstructionsin
sections“Importantsafetyinstructions”and“Installation”.
Topreparetheproductforwashinglaundry,performfirst
operationinDrumCleaningprogramme.Ifyourproduct
isnotequippedwithDrumCleaningprogramme,perform
theInitialUseprocedureinaccordancewiththemethods
described under “5.2 Cleaning the loading door and the
drum”sectionoftheusermanual.
CUseananti-limescalesuitableforthewashingmachines.
CSomewatermighthaveremainedintheproductdueto
thequalitycontrolprocessesintheproduction.Itisnot
harmful for the product.

7 / EN Washing Machine / User’s Manual
3.5 Correct load capacity
Themaximumloadcapacitydependsonthetypeoflaundry,
thedegreeofsoilingandthewashingprogrammedesired.
Themachineautomaticallyadjuststheamountofwater
accordingtotheweightoftheloadedlaundry.
Awarning: Followtheinformationinthe“Programme
andconsumptiontable”.Whenoverloaded,machine's
washingperformancewilldrop.Moreover,noiseand
vibration problems may occur.
Laundry type Weight (g)
Bathrobe 1200
Napkin 100
Duvet cover 700
BedSheet 500
Pillowcase 200
Tablecloth 250
Towel 200
Handtowel 100
Eveninggown 200
Underclothing 100
Men’s overalls 600
Men’s shirt 200
Men’s pajamas 500
Blouses 100
3.6 Loading the laundry
1. Open the loading door.
2.Placelaundryitemslooselyintothemachine.
3.Pushtheloadingdoortocloseuntilyouhearalocking
sound. Ensure that no items are caught in the door.
CTheloadingdoorislockedwhileaprogrammeisrunning.
Thedoorcanonlybeopenedawhileaftertheprogramme
comes to an end.
Awarning: Incaseofmisplacingthelaundry,noiseand
vibration problems may occur in the machine.
3.7 Using detergent and softener
CWhen using detergent, softener, starch, fabric dye, bleach
or limescale remover read the manufacturer's instructions
onthepackagecarefullyandfollowthesuggesteddosage
values. Use measuring cup if available.
Detergent Drawer
Thedetergentdraweriscomposedofthreecompartments:
–(1)forprewash
–(2)formainwash
–(3)forsoftener
–(*)inaddition,thereissiphonpieceinthesoftener
compartment.
1
23
Detergent, softener and other cleaning agents
• Adddetergentandsoftenerbeforestartingthewashing
programme.
• Neverleavethedetergentdraweropenwhilethewashing
programme is running!
• Whenusingaprogrammewithoutprewash,donot
putanydetergentintotheprewashcompartment
(compartment nr. "1").
• Inaprogrammewithprewash,donotputliquiddetergent
intotheprewashcompartment(compartmentnr."1").
• Donotselectaprogrammewithprewashifyouareusing
adetergentbagordispensingball.Placethedetergent
bag or the dispensing ball directly among the laundry in
the machine.
• Ifyouareusingliquiddetergent,donotforgettoplace
theliquiddetergentcupintothemainwashcompartment
(compartment nr. "2").
Choosing the detergent type
Thetypeofdetergenttobeuseddependsonthetypeand
colour of the fabric.
• Usedifferentdetergentsforcolouredandwhitelaundry.
• Washyourdelicateclothesonlywithspecialdetergents
(liquiddetergent,woolshampoo,etc.)usedsolelyfor
delicate clothes.
• Whenwashingdarkcolouredclothesandquilts,itis
recommendedtouseliquiddetergent.
• Washwoolenswithspecialdetergentmadespecifically
forwoolens.
Awarning: Use only detergents manufactured specifically
forwashingmachines.
Awarning: Donotusesoappowder.
Adjusting detergent amount
Theamountofwashingdetergenttobeuseddepends
ontheamountoflaundry,thedegreeofsoilingandwater
hardness.
• Donotuseamountsexceedingthedosagequantities
recommended on the detergent package to avoid
problemsofexcessivefoam,poorrinsing,financial
savings and finally, environmental protection.
• Uselesserdetergentforsmallamountsorlightlysoiled
clothes.
Using softeners
Pourthesoftenerintothesoftenercompartmentofthe
detergentdrawer.
• Donotexceedthe(>max<)levelmarkinginthesoftener
compartment.

8 / EN Washing Machine / User’s Manual
• Ifthesoftenerhaslostitsfluidity,diluteitwithwater
beforeputtingitinthedetergentdrawer.
Using liquid detergents
If the product contains a liquid detergent cup:
• Makesurethatyouhaveplacedtheliquiddetergentcup
in compartment nr. "2".
• Iftheliquiddetergenthaslostitsfluidity,diluteitwith
waterbeforeputtinginthedetergentcup.
If the product does not contain a liquid detergent cup:
• Donotuseliquiddetergentfortheprewashina
programmewithprewash.
• Liquiddetergentstainsyourclotheswhenusedwith
DelayedStartfunction.IfyouaregoingtousetheDelayed
Startfunction,donotuseliquiddetergent.
Using gel and tablet detergent
Applythefollowinginstructionswhenusingtablet,geland
similar detergents.
• Ifthegeldetergentthicknessisfluidalandyourmachine
doesnotcontainaspecialliquiddetergentcup,putthe
geldetergentintothemainwashdetergentcompartment
duringfirstwaterintake.Ifyourmachinecontainsaliquid
detergent cup, fill the detergent into this cup before
starting the programme.
• Ifthegeldetergentthicknessisnotfluidalorintheshape
ofcapsuleliquidtablet,putitdirectlyintothedrumbefore
washing.
• Puttabletdetergentsintothemainwashcompartment
(compartment nr. "2") or directly into the drum before
washing.
CTabletdetergentsmayleaveresiduesinthedetergent
compartment.Ifyouencountersuchacase,placethe
tabletdetergentbetweenthelaundry,closetothelower
partofthedruminfuturewashings.
CUsethetabletorgeldetergentwithoutselectingthe
prewashfunction.
Using starch
• Addliquidstarch,powderstarchorthefabricdyeintothe
softener compartment.
• Donotusesoftenerandstarchtogetherinawashing
cycle.
• Wipetheinsideofthemachinewithadampandclean
cloth after using starch.
Using bleaches
• Selectaprogrammewithprewashandaddthebleaching
agentatthebeginningoftheprewash.Donotput
detergentintheprewashcompartment.Asanalternative
application,selectaprogrammewithextrarinseandadd
thebleachingagentwhilethemachineistakingwater
from the detergent compartment during first rinsing step.
• Donotusebleachingagentanddetergentbymixing
them.
• Usejustalittleamount(approx.50ml)ofbleachingagent
andrinsetheclothesverywellasitcausesskinirritation.
Do not pour the bleaching agent onto the clothes and do
not use it for coloured clothes.
• Whenusingoxygenbasedbleaches,selectaprogramme
thatwashesatalowertemperature.
• Oxygenbasedbleachescanbeusedtogetherwith
detergents;however,ifitsthicknessisnotthesame
withthedetergent,putthedetergentfirstintothe
compartmentnr."2"inthedetergentdrawerandwait
untilthedetergentflowswhilethemachineistaking
inwater.Addthebleachingagentfromthesame
compartmentwhilethemachineisstilltakinginwater.
Using limescale remover
• Whenrequired,uselimescaleremoversmanufactured
specificallyforwashingmachinesonly.

9 / EN Washing Machine / User’s Manual
3.8 Tips for efficient washing
Clothes
Light colours and whites Colours Dark colours Delicates/
Woolens/Silks
(Recommended temperature
range based on soiling level:
40-90ºC)
(Recommended temperature
range based on soiling level:
cold-40ºC)
(Recommended
temperature range
based on soiling level:
cold-40ºC)
(Recommended
temperature range
based on soiling level:
cold-30ºC)
Soiling Level
Heavily Soiled
(difficult stains such
as grass, coffee,
fruits and blood.)
Itmaybenecessarytopre-
treat the stains or perform
prewash.Powderandliquid
detergents recommended
forwhitescanbeusedat
dosages recommended for
heavilysoiledclothes.Itis
recommendedtousepowder
detergents to clean clay and
soil stains and the stains that
are sensitive to bleaches.
Powderandliquid
detergents recommended
for colours can be used at
dosages recommended for
heavilysoiledclothes.Itis
recommendedtousepowder
detergents to clean clay and
soil stains and the stains that
are sensitive to bleaches. Use
detergentswithoutbleach.
Liquiddetergents
suitable for colours
and dark colours can
be used at dosages
recommended for
heavily soiled clothes.
Preferliquid
detergents produced
for delicate clothes.
Woollen and silk
clothes must be
washedwithspecial
woollendetergents.
Normally Soiled
(Forexample,stains
caused by body on
collars and cuffs)
Powderandliquiddetergents
recommendedforwhites
can be used at dosages
recommended for normally
soiled clothes.
Powderandliquiddetergents
recommended for colours
can be used at dosages
recommended for normally
soiled clothes. Use detergents
withoutbleach.
Liquiddetergents
suitable for colours
and dark colours can
be used at dosages
recommended for
normally soiled clothes.
Preferliquid
detergents produced
for delicate clothes.
Woollen and silk
clothes must be
washedwithspecial
woollendetergents.
Lightly Soiled
(No visible stains
exist.)
Powderandliquiddetergents
recommendedforwhites
can be used at dosages
recommended for lightly soiled
clothes.
Powderandliquiddetergents
recommended for colours
can be used at dosages
recommended for lightly
soiled clothes. Use detergents
withoutbleach.
Liquiddetergents
suitable for colours
and dark colours can
be used at dosages
recommended for lightly
soiled clothes.
Preferliquid
detergents produced
for delicate clothes.
Woollen and silk
clothes must be
washedwithspecial
woollendetergents.

10 / EN Washing Machine / User’s Manual
4 Operating the product
4.1 Control panel
1-ProgrammeSelectionknob(UppermostpositionOn/Off)
2-ProgrammeFollow-upindicator
3-TemperatureAdjustmentbutton
4-SpinSpeedadjustmentbutton
5-AuxiliaryFunctionbuttons
6-DelayedStartbutton(insomemodels)
7-Start/Pausebutton
4.2 Preparing the machine
Makesurethatthehosesareconnectedtightly.Pluginyour
machine.Turnthetaponcompletely.Placethelaundryinthe
machine.Adddetergentandfabricsoftener.
4.3 Programme selection
Selecttheprogrammesuitableforthetype,quantity
andsoilingdegreeofthelaundryinaccordancewiththe
“Programmeandconsumptiontable”andthetemperature
tablebelow.
90˚C Heavilysoiledwhitecottonsandlinens.(coffeetable
covers,tableclothes,towels,bedsheets,etc.)
60˚C Normally soiled, coloured, fade proof linens, cottons orsyntheticclothes(shirt,nightgown,pajamas,etc.)
andlightlysoiledwhitelinens(underwear,etc.)
40˚C-
30˚C- Cold Blendedlaundryincludingdelicatetextile(veil curtains,etc.),syntheticsandwoolens.
SelectthedesiredprogrammewiththeProgramme
Selectionbutton.
CProgrammesarelimitedwiththehighestspinspeed
appropriate for that particular type of fabric.
CWhenselectingaprogramme,alwaysconsiderthetype
offabric,colour,degreeofsoilingandpermissiblewater
temperature.
CAlwaysselectthelowestrequiredtemperature.Higher
temperaturemeanshigherpowerconsumption.
CForfurtherprogrammedetails,see"Programmeand
consumption table"
4.4 Main programmes
Dependingonthetypeoffabric,usethefollowingmain
programmes.
•Cottons
Use this programme for your cotton laundry (such as bed
sheets,duvetandpillowcasesets,towels,bathrobes,
underwear,etc.).Yourlaundrywillbewashedwithvigorous
washingactionforalongerwashingcycle.
•Synthetics
Usethisprogrammetowashyoursyntheticclothes(shirts,
blouses,synthetic/cottonblends,etc.).Itwasheswitha
gentleactionandhasashorterwashingcyclecomparedto
the Cottons programme.
Forcurtainsandtulle,usetheSynthetic40˚Cprogramme
withprewashandanti-creasingfunctionsselected.Astheir
meshedtexturecausesexcessivefoaming,washtheveils/
tulle by putting little amount of detergent into the main
washcompartment.Donotputdetergentintheprewash
compartment.
•Woollen
Usethisprogrammetowashyourwoollenclothes.Select
theappropriatetemperaturecomplyingwiththetagsofyour
clothes.Useappropriatedetergentsforwoolens.
1 2
76543

11 / EN Washing Machine / User’s Manual
4.5 Additional programmes
For special cases, additional programmes are available in
the machine.
CAdditionalprogrammesmaydifferaccordingtothe
model of the machine.
• Cotton Eco
Youmaywashyournormallysoileddurablecottonand linen
laundryinthisprogrammewiththehighestenergyandwater
savingcomparedtoallotherwashprogrammes suitablefor
cottons.Actualwatertemperaturemaydiffer fromthe
declaredcycletemperature.Programmeduration may
automatically be shortened during later stages of the
programmeifyouwashlessamount(e.g.½capacityor less)
oflaundry.Inthiscaseenergyandwaterconsumption willbe
furtherdecreasedgivingyoutheopportunityfora more
economicalwash.Thisfeatureisavailableforcertain models
having remaining time display.
•BabyProtect
Usethisprogrammetowashbabylaundry,andthelaundry
that belongs to allergic persons. Longer heating time and an
additional rinsing step provide a higher level of hygiene.
•Delicate
Usethisprogrammetowashyourdelicateclothes.Itwashes
withagentleactionwithoutanyinterimspincomparedto the
Syntheticsprogramme.
• Hand wash 20°C
Usethisprogrammetowashyourwoollen/delicateclothes
thatbear“notmachine-washable”tagsandforwhichhand
washisrecommended.Itwasheslaundrywithaverygentle
washingactiontonottodamageclothes.
•Daily Xpress
Usethisprogrammetoquicklywashyourlittleamountof
lightly soiled cotton clothes.
• Xpress Super Short
Usethisprogrammetowashyourlittleamountoflightly
soiled cotton clothes in a short time.
•Darkcare
Usethisprogrammetowashyourdarkcolouredlaundry,or
thecolouredlaundrythatyoudonotwantthemgetfaded.
Washingisperformedwithlessmechanicalmovementsat
lowtemperature.Itisrecommendedtouseliquiddetergent
orwoolshampoofordarkcolouredlaundry.
• Mix 40
Usethisprogrammetowashyourcottonandsynthetic
clothestogetherwithoutsortingthem.
•Shirt
Usethisprogrammetowashtheshirtsmadeofcotton,
synthetic and synthetic blended fabrics together.
•Sport
Usethisprogrammetowashyourgarmentsthatareworn
forashorttimesuchassportswear.Itissuitabletowash
little amount of cotton / synthetic blended garments.
4.6 Special programmes
Forspecificapplications,selectanyofthefollowing
programmes.
•Rinse
Usethisprogrammewhenyouwanttorinseorstarch
separately.
• Spin + Drain
Use this programme to apply an additional spin cycle for
yourlaundryortodrainthewaterinthemachine.
Beforeselectingthisprogramme,selectthedesiredspin
speedandpressStart/Pausebutton.First,themachinewill
drainthewaterinsideofit.Then,itwillspinthelaundrywith
thesetspinspeedanddrainthewatercomingoutofthem.
Ifyouwishtodrainonlythewaterwithoutspinningyour
laundry,selectthePump+Spinprogrammeandthenselect
theNoSpinfunctionwiththehelpofSpinSpeedAdjustment
button.PressStart/Pausebutton.
CUsealowerspinspeedfordelicatelaundries.
4.7 Temperature selection
Wheneveranewprogrammeisselected,themaximum
temperature for the selected programme appears on the
temperature indicator.
Todecreasethetemperature,presstheTemperature
Adjustmentbutton.Temperaturewilldecreasegradually.
CIftheprogrammehasnotreachedtheheatingstep,
youcanchangethetemperaturewithoutswitchingthe
machinetoPausemode.
4.8 Spin speed selection
Wheneveranewprogrammeisselected,therecommended
spin speed of the selected programme is displayed on the
spin speed indicator.
Todecreasethespinspeed,presstheSpinSpeed
Adjustmentbutton.Spinspeeddecreasesgradually.Then,
dependingonthemodeloftheproduct,"RinseHold"and
"NoSpin"optionsappearonthedisplay.See"Auxiliary
functionselection"sectionforexplanationsoftheseoptions.
CIftheprogrammehasnotreachedthespinningstep,
youcanchangethespeedwithoutswitchingthe
machinetoPausemode.

12 / EN Washing Machine / User’s Manual
4.9 Programme and consumption table
•: Selectable
* :Automatically selected, no cancelling.
** : Energy Label programme (EN 60456 Ed.3)
*** : If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin speed.
** “Cotton eco 40°C and Cotton eco 60°C are standard cycles.” These cycles are known as ‘40°C cotton standard cycle’ and
‘60°C cotton standard cycle’ and indicated with the
symbols on the panel.
The auxiliary functions in thetable may vary according to the model of your machine.
Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient
temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.
You can see the washing time of the programme you have selected on the display of the machine. It is normal that small
differences may occur between the time shown on the display and the real washing time.
“Selectability of auxiliary functions might be changed by the manufacturer. New selectabilities might be added orexisting ones
might be removed.”
«The spin speed of your machine may vary among the programmes, however this speed cannot exceed the max. spin speed of
your machine.»
EN 2Auxiliary functions
Programme
Max. Load (kg) Programme Duration (~min) Water Consumption (l) Energy Consumption (kWh) Max. Speed*** Prewash Quick Wash
Temperature
Cotton 90 5 147 66 2.25 1600 • • Cold-90
Cotton 60 5 118 66 1.45 1600 • • Cold-90
Cotton 40 598 66 0.85 1600 • • Cold-90
Cotton Eco 60** 5 159 39 0.74 1600 40-60
Cotton Eco 60** 2.5 129 32 0.69 1600 40-60
Cotton Eco 40** 2.5 129 32 0.61 1600 40-60
BabyProtect 90 5165 85 1.90 1600 •30-90
Xpress Super Short 30 2 14 40 0.11 1400 Cold-30
Daily Xpress 90 588 55 1.90 1400 Cold-90
Daily Xpress 60 558 55 1.00 1400 Cold-90
Daily Xpress 30 528 55 0.20 1400 Cold-90
Dark Care 40 2.5 107 58 0.45 800 Cold-40
Delicate 30 2 59 43 0.23 600 Cold-40
Mix40 40 3 115 45 0.50 800 • • Cold-40
Sport 40 3 101 48 0.45 800 • • Cold-40
Synthetics 60 2.5 116 45 0.90 800 • • Cold-60
Synthetics 40 2.5 106 45 0.42 800 • • Cold-60
woollen 40 1.5 60 40 0.30 600 Cold-40
Shirt 60 2.5 104 55 0.90 600 • • Cold-60
Handwash 20°C 20 1 43 30 0.15 600 20

13 / EN Washing Machine / User’s Manual
Indicative values for Synthetics programmes (EN)
Load (kg) Water Consumption (l) Energy Consumption (kWh) Programme Duration (min) *
Remaining Moisture
Content (%) **
Remaining Moisture
Content (%) **
≤ 1000 rpm > 1000 rpm
Synthetics 60 2.5 45 0.90 01:56 45 40
Synthetics 40 2.5 45 0.42 01:46 45 40
* You can see the washing time of the programme you have selected on the display of the machine. It is normal that small
differences may occur between the time shown on the display and the real washing time.
** Remaining moisture content values may differ according to the selected spin speed.
4.10 Auxiliary function selection
Usethefollowingauxiliaryfunctionsaccordingtoyour
dailyneeds.Selectthedesiredauxiliaryfunctionsbefore
starting the programme. Furthermore, you may also select
orcancelauxiliaryfunctionsthataresuitabletotherunning
programmewithoutpressingtheStart/Pausebuttonwhen
the machine is operating. For this, the machine must be in
astepbeforetheauxiliaryfunctionyouaregoingtoselect
or cancel.
Iftheauxiliaryfunctioncannotbeselectedorcancelled,
lightoftherelevantauxiliaryfunctionwillblink3timesto
warnthe user.
CSomefunctionscannotbeselectedtogether.Ifasecond
auxiliaryfunctionconflictingwiththefirstoneisselected
before starting the machine, the function selected
firstwillbecancelledandthesecondauxiliaryfunction
selectionwillremainactive.Forexample,ifyouwantto
selectQuickWashafteryouhaveselectedthePrewash,
PrewashwillbecancelledandQuickWashwillremain
active.
CAnauxiliaryfunctionthatisnotcompatiblewiththe
programmecannotbeselected.(See“Programmeand
consumptiontable”)
CAuxiliaryFunctionbuttonsmayvaryaccordingtothe
model of the machine.
• Prewash
APrewashisonlyworthwhileforheavilysoiledlaundry.Not
usingthePrewashwillsaveenergy,water,detergentand
time.
CPrewashwithoutdetergentisrecommendedfortulle
and curtains.
• Quick Wash
ThisfunctioncanbeusedinCottonsandSynthetics
programmes.Itdecreasesthewashingtimesandalsothe
number of rinsing steps for lightly soiled laundry.
CWhenyouselectthisfunction,loadyourmachinewith
halfofthemaximumlaundryspecifiedintheprogramme
table.
• Rinse Plus
Thisfunctionenablesthemachinetomakeanotherrinsing
inadditiontotheonealreadymadeafterthemainwash.
Thus,theriskforsensitiveskins(babies,allergicskins,etc.)
to be effected by the minimal detergent remnants on the
laundry can be reduced.
• Anti-Creasing
Thisfunctioncreasestheclotheslesserwhentheyarebeing
washed.Drummovementisreducedandspinningspeedis
limitedtopreventcreasing.Inaddition,washingisdonewith
ahigherwaterlevel.Usethisfunctionfordelicatelaundry
that creases easily.
• Rinse Hold
Ifyouarenotgoingtounloadyourclothesimmediatelyafter
the programme completes, you may use rinse hold function
tokeepyourlaundryinthefinalrinsingwaterinorderto
preventthemfromgettingwrinkledwhenthereisnowater in
themachine.PressStart/Pausebuttonafterthisprocess if
youwanttodrainthewaterwithoutspinningyourlaundry.
Programmewillresumeandcompleteafterdrainingthe
water.
Ifyouwanttospinthelaundryheldinwater,adjusttheSpin
SpeedandpressStart/Pausebutton.
Theprogrammeresumes.Waterisdrained,laundryisspun
and the programme is completed.
•Pet hair removal
Thisfunctionhelpstoremovepethairthatremainonyour
garments more effectively.
Whenyouselectthisfunction,PrewashandExtraRinse
stepsareaddedtothenormalprogramme.Thus,washing is
performedwithmorewater(30%)andthepethairis
removed more effectively.
ANeverwashyourpetsinthewashingmachine.
Delayed Start(Insomemodelsonly)
WiththeDelayedStartfunctionthestartupofthe
programmemaybedelayedupto3,6or9hours.
CDonotuseliquiddetergentswhenyousetDelayedStart!
Thereistheriskofstainingoftheclothes.
Open the loading door, place the laundry and put detergent,
etc.Selectthewashingprogramme,temperature,spin

14 / EN Washing Machine / User’s Manual
speedand,ifrequired,theauxiliaryfunctions.Setthe
desiredtimebypressingtheDelayedStartbutton.Whenthe
button is pressed once, 3 hours delayed start is selected.
Whenthesamebuttonispressedagain,6hoursdelayis
selected,andwhenitispressedforthethirdtime,9hours
delayedstartisselected.IfyoupresstheDelayedStart
buttononceagain,DelayedStartfunctionwillbecancelled.
PressStart/Pausebutton.Previousdelayedstarttimelight
turnsoffandnextdelayedstarttimelightturnsonafter
every3hours.Attheendofthecountdown,alldelayedstart
lightswillturnoffandtheselectedprogrammewillstart.
CAdditionallaundrymaybeloadedduringthedelayed
start period.
Changing the Delayed Start period
PressDelayedStartbutton.Everytimethebuttonispressed,
theperiodwillchangein3-hourincrementsandthelightof
theselecteddelayedstarttimewillturnon.
Cancelling the Delayed Start function
Ifyouwanttocancelthedelayedstartcountdownandstart
the programme immediately:
SettheDelayedStartperiodtozero(alldelayedstartperiod
lightswillturnoff)orturntheProgrammeSelectionknob
toanyprogramme.Thus,DelayedStartfunctionwillbe
cancelled.TheEnd/Cancellightflashescontinuously.Then,
selecttheprogrammeyouwanttorunagain.PressStart/
Pausebuttontostarttheprogramme.
4.11 Starting the programme
PressStart/Pausebuttontostarttheprogramme.
Programmefollow-uplightshowingthestartupofthe
programmewillturnon.
CIfnoprogrammeisstartedornokeyispressedwithin
1 minute during programme selection process, the
machinewillswitchtoPausemodeandtheillumination
level of the temperature, speed and loading door
indicatorlightswilldecrease.Otherindicatorlightsand
indicatorswillturnoff.OncetheProgrammeSelection
knob is rotated or any button is pressed, indicator lights
andindicatorswillturnonagain.
4.12 Child Lock
Use child lock function to prevent children from tampering
withthemachine.Thusyoucanavoidanychangesina
running programme.
CIftheProgrammeSelectionknobisturnedwhenthe
ChildLockisactive,“Con”appearsonthedisplay.
TheChildLockdoesnotallowanychangeinthe
programmes and the selected temperature, speed and
auxiliaryfunctions.
CEvenifanotherprogrammeisselectedwiththe
ProgrammeSelectionknobwhiletheChildLockis
active,previouslyselectedprogrammewillcontinue
running.
CWhen the Child Lock is active and the machine is
running,youcanswitchthemachinetoPausemode
withoutdeactivatingtheChildLockbyturningthe
ProgrammeSelectionknobtoOn/Offposition.When
youturntheProgrammeSelectionknobafterwards,the
programmewillresu
To activate the Child Lock:
Pressandhold1stand2ndAuxiliaryFunctionbuttonsfor
3seconds.Thelightsonthe1stand2ndAuxiliaryFunction
buttonswillflashwhileyoukeepthebuttonspressedfor3
seconds.
To deactivate the Child Lock:
Pressandhold1stand2ndauxiliaryfunctionbuttonsfor3
secondswhileanyprogrammeisrunning.Thelightsonthe
1stand2ndAuxiliaryFunctionbuttonswillflashwhileyou
keep the buttons pressed for 3 seconds.
CInadditiontothemethodabove,todeactivatetheChild
Lock,switchtheProgrammeSelectionknobtoOn/
Offpositionwhennoprogrammeisrunning,andselect
another programme.
CWhenthepowerisrestoredafterapowerfailureorafter
your machine is unplugged and plugged in again, the
ChildLockwillnotbedeactivatedwhenthemachine
resumes operating.
4.13 Progress of programme
Progressofarunningprogrammecanbefollowedfromthe
ProgrammeFollow-upindicator.Atthebeginningofevery
programmestep,therelevantindicatorlightwillturnonand
lightofthecompletedstepwillturnoff.
Youcanchangetheauxiliaryfunctions,speedand
temperaturesettingswithoutstoppingtheprogrammeflow
whiletheprogrammeisrunning.Todothis,thechange
you are going to make must be in a step after the running
programmestep.Ifthechangeisnotcompatible,relevant
lightswillflashfor3times.
CIfthemachinedoesnotpasstothespinningstep,
RinseHoldfunctionmightbeactiveortheautomatic
unbalanced load detection system might be activated
due to the unbalanced distribution of the laundry in the
machine.
4.14 Loading door lock
Thereisalockingsystemontheloadingdoorofthe
machinethatpreventsopeningofthedoorincaseswhen
thewaterlevelisunsuitable.
Loadingdoorlightwillstartflashingwhenthemachine
isswitchedtoPausemode.Machinechecksthelevelof
thewaterinside.Ifthelevelissuitable,LoadingDoorlight
illuminatessteadilywithin1-2minutesandtheloadingdoor
can be opened.
Ifthelevelisunsuitable,LoadingDoorlightturnsoffandthe
loadingdoorcannotbeopened.Ifyouareobligedtoopen
theLoadingDoorwhiletheLoadingDoorlightisoff,you
have to cancel the current programme; see “Cancelling the
programme”.
Changing the selections after
programme has started
Switching the machine to pause mode
PresstheStart/Pausebuttontoswitchthemachineto
pausemodewhileaprogrammeisrunning.Thelightof
thestepwhichthemachineisinstartsflashinginthe
ProgrammeFollow-upindicatortoshowthatthemachine
hasbeenswitchedtothepausemode.
Also,whentheloadingdoorisreadytobeopened,Loading
Doorlightwillalsoilluminatecontinuouslyinadditiontothe
programme step light.

15 / EN Washing Machine / User’s Manual
Changing the speed and temperature settings for
auxiliary functions
Depending on the step the programme has reached, you
maycanceloractivatetheauxiliaryfunctions;see,“Auxiliary
functionselection”.
You may also change the speed and temperature settings;
see,“Spinspeedselection”and“Temperatureselection”.
CIfnochangeisallowed,therelevantlightwillflashfor
3 times.
4.15 Adding or taking out laundry
PresstheStart/Pausebuttontoswitchthemachineto
pausemode.Theprogrammefollow-uplightoftherelevant
stepduringwhichthemachinewasswitchedintothepause
modewillflash.WaituntiltheLoadingDoorcanbeopened.
Open the Loading Door and add or take out the laundry.
ClosetheLoadingDoor.Makechangesinauxiliaryfunctions,
temperatureandspeedsettingsifnecessary.PressStart/
Pausebuttontostartthemachine.
4.16 Cancelling the programme
Tocanceltheprogramme,turntheProgrammeSelection
knobtoselectanotherprogramme.Previousprogrammewill
becancelled.End/Cancellightwillflashcontinuouslyto
notify that the programme has been cancelled.
Yourmachinewillendtheprogrammewhenyouturnthe
ProgrammeSelectionknob;however,itdoesnotdrainthe
waterinside.Whenyouselectandstartanewprogramme,
thenewlyselectedprogrammewillstartdependingonthe
stepthepreviousprogrammewascancelledin.For
example,itmaytakeinadditionalwaterorcontinuetowash
withthewaterinside.
CDependingonthestepwheretheprogrammewas
cancelled in, you may have to put detergent and softener
againfortheprogrammeyouhaveselectedanew.
4.17 Your machine is equipped
with a “Standby Mode”
Incaseofnotstartinganyprogrammeorwaitingwithout
makinganyotheroperationwhenthemachineisturned
onbyOn/Offbuttonandwhileitisinselectionsteporif
nootheroperationisperformedapproximately2minutes
after the programme you selected has come to an end, your
machinewillautomaticallyswitchtoenergysavingmode.
Displaybrightnesswilldecrease.Incaseofrotatingthe
ProgrammeSelectionknoborpressinganybutton,lightswill
restoretotheirpreviouscondition.Thisisnotafault.
1.Pressthedottedpointonthesiphoninthesoftener
compartmentandpulltowardsyouuntilthecompartment
is removed from the machine.
CIfmorethannormalamountofwaterandsoftener
mixturestartstogatherinthesoftenercompartment,the
siphon must be cleaned.
2.Washthedetergentdrawerandthesiphonwithplentyof
lukewarmwaterinawashbasin.Wearprotectivegloves
or use an appropriate brush to avoid touching of the
residuesinthedrawerwithyourskinwhencleaning.
3.Insertthedrawerbackintoitsplaceaftercleaningand
makesurethatitisseatedwell.
Ifyourdetergentdraweristheoneindicatedinthefollowing
figure:
CLift the rear part of the siphon to remove it as illustrated.
Afterperformingtheabovementionedcleaning
procedures, replace the siphon back to its seating and
pushitsfrontsectiondownwardstomakesurethatthe
locking tab engages.
5.2 Cleaning the loading door and the drum
Residues of softener, detergent and dirt may accumulate in
your machine in time and may cause unpleasant odours and
washingcomplaints.Toavoidthis,usetheDrum Cleaning
programme.IfyourmachineisnotfeaturedwithDrum
Cleaning programme, use Cottons-90 programme and
select Additional Water or Extra Rinseauxiliaryfunctions
aswell.Runtheprogrammewithoutanylaundryinthe
machine.Beforestartingtheprogramme,putmax.100
gofpowderanti-limescaleintothemainwashdetergent
compartment(compartmentnr.2).Iftheanti-limescaleisin
tablet form, put only one tablet into compartment nr. 2. Dry
theinsideofthebellowwithacleanpieceofclothafterthe
programme has come to an end.
CRepeat Drum Cleaning process in every 2 months.
CUseananti-limescalesuitableforthewashingmachines.
Aftereverywashingmakesurethatnoforeignsubstanceis
left in the drum.
Iftheholesonthebellowshowninthefigureisblocked,
open the holes using a toothpick.
5 Maintenance and cleaning
Servicelifeoftheproductextendsandfrequentlyfaced
problems decrease if cleaned at regular intervals.
5.1 Cleaning the detergent drawer
Cleanthedetergentdraweratregularintervals(every
4-5washingcycles)asshownbelowinordertoprevent
accumulationofpowderdetergentintime.

16 / EN Washing Machine / User’s Manual
Inordertocleanthedirtyfilteranddischargethewater:
1.Unplugthemachinetocutoffthesupplypower.
Awarning: Temperatureofthewaterinsidethemachine
mayriseupto90ºC.Toavoidburningrisk,filtermustbe
cleanedafterthewaterinthemachinecoolsdown.
2. Open the filter cap.
Ifthefiltercapiscomposedoftwopieces,pressthe
tabonthefiltercapdownwardsandpullthepieceout
towardsyourself.
Ifthefiltercapisonepiece,pullthecapfrombothsidesat
the top to open.
CYou can remove the filter cover by slightly pushing
downwardswithathinplastictippedtool,throughthe
gap above the filter cover. Do not use metal tipped tools
to remove the cover.
3.Someofourproductshaveemergencydraininghoseand
somedoesnothave.Followthestepsbelowtodischarge
thewater.
Dischargingthewaterwhentheproducthasanemergency
draining hose:
a. Pulltheemergencydraininghoseoutfromitsseat
b. Placealargecontainerattheendofthehose.Drainthe
waterintothecontainerbypullingouttheplugattheend
of the hose. When the container is full, block the inlet
ofthehosebyreplacingtheplug.Afterthecontaineris
emptied,repeattheaboveproceduretodrainthewaterin
the machine completely.
c. Whendrainingofwaterisfinished,closetheendbythe
plugagainandfixthehoseinitsplace.
d. Turnthepumpfiltertotakeitout.
CForeignmetalsubstanceswillcauseruststainsinthe
drum. Clean the stains on the drum surface by using
cleaningagentsforstainlesssteel.Neverusesteelwool
orwirewool.
Awarning: Neverusespongeorscrubmaterials.Thesewill
damage the painted and plastic surfaces.
5.3 Cleaning the body and control panel
Wipethebodyofthemachinewithsoapywaterornon-
corrosivemildgeldetergentsasnecessary,anddrywitha
soft cloth.
Use only a soft and damp cloth to clean the control panel.
5.4 Cleaning the water intake filters
Thereisafilterattheendofeachwaterintakevalveatthe
rearofthemachineandalsoattheendofeachwaterintake
hosewheretheyareconnectedtothetap.Thesefilters
preventforeignsubstancesanddirtinthewatertoenterthe
washingmachine.Filtersshouldbecleanedastheydoget
dirty.
1. Close the taps.
2.Removethenutsofthewaterintakehosestoaccess
thefiltersonthewaterintakevalves.Cleanthemwithan
appropriatebrush.Ifthefiltersaretoodirty,takethemout
by means of pliers and clean them.
3.Takeoutthefiltersontheflatendsofthewaterintake
hosestogetherwiththegasketsandcleanthoroughly
underrunningwater.
4. Replace the gaskets and filters carefully in their places
and tighten the hose nuts by hand.
5.5 Draining remaining water and
cleaning the pump filter
Thefiltersysteminyourmachinepreventssoliditems
such as buttons, coins and fabric fibers clogging the pump
impellerduringdischargeofwashingwater.Thus,thewater
willbedischargedwithoutanyproblemandtheservicelife
ofthepumpwillextend.
Ifthemachinefailstodrainwater,thepumpfilterisclogged.
Filtermustbecleanedwheneveritiscloggedorinevery3
months. Water must be drained off first to clean the pump
filter.
Inaddition,priortotransportingthemachine(e.g.,when
moving to another house) and in case of freezing of the
water,watermayhavetobedrainedcompletely.
Awarning: Foreign substances left in the pump filter may
damage your machine or may cause noise problem.

17 / EN Washing Machine / User’s Manual
Dischargingthewaterwhentheproductdoesnothavean
emergency draining hose:
a. Placealargecontainerinfrontofthefiltertocatchwater
from the filter.
b. Loosenpumpfilter(anticlockwise)untilwaterstartsto
flow.Filltheflowingwaterintothecontaineryouhave
placedinfrontofthefilter.Alwayskeepapieceofcloth
handytoabsorbanyspilledwater.
c. Whenthewaterinsidethemachineisfinished,takeout
the filter completely by turning it.
4.Cleananyresiduesinsidethefilteraswellasfibers,if
any, around the pump impeller region.
5.Installthefilter.
6.Ifthefiltercapiscomposedoftwopieces,closethefilter
capbypressingonthetab.Ifitisonepiece,seatthetabs
inthelowerpartintotheirplacesfirst,andthenpressthe
upper part to close.

18 / EN Washing Machine / User’s Manual
6 Technical specifications
Complying Commission Delegated Regulation (EU) No 1061/2010
Suppliernameor trademark
Model name
Rated capacity (kg)
Energy efficiencyclass/ScalefromA+++(HighestEfficiency)toD(LowestEfficiency)
AnnualEnergyConsumption(kWh)(1)
Energy consumption ofthestandard60°Ccottonprogrammeatfullload(kWh)
Energyconsumptionofthestandard60°Ccottonprogramme at partial load (kWh)
Energy consumption of the standard 40°C cotton programme at partial load (kWh)
Powerconsumptionin‘off-mode’(W)
Powerconsumptionin‘left-onmode’ (W)
AnnualWaterConsumption(l)(2)
Spin-dryingefficiencyclass/ScalefromA(HighestEfficiency)toG(Lowest Efficiency)
Maximumspinspeed(rpm)
Remaining moisture Content (%)
Standardcottonprogramme(3)
Programmetimeofthestandard60°Ccottonprogrammeat full load (min)
Programmetimeofthestandard60°C cotton programme at partial load (min)
Programmetimeof the standard 40°C cotton programme at partial load (min)
Duration of the left-on mode (min)
Airborneacousticalnoiseemissionswashing/spinning(dB)
Built-in
Rated capacity (kg)
Height(cm)
Width (cm)
Depth (cm)
Netweight(±4kg.)
FLAVEL
WFA5100W
5
A+
158
0.743
0.687
0.606
0.250
1.000
7260
C
1000
62
CottonEco60°Cand40°C
159
129
129
N/A
59/75
No
5
84
60
48
59
SingleWaterinlet/DoubleWaterinlet •/-
•Available
Electricalinput(V/Hz) 230V~/50Hz
Totalcurrent(A) 10
Totalpower(W) 2200
Main model code 929
(1)EnergyConsumptionbasedon220standardwashingcyclesforcottonprogrammesat60°Cand40°Catfullandpartialload,andtheconsumptionof
thelow-powermodes.Actualenergyconsumptionwilldependonhowtheapplianceisused.
(2)Waterconsumptionbasedon220standardwashingcyclesforcottonprogrammesat60°Cand40°Catfullandpartialload.Actualwaterconsumption
willdependonhowtheapplianceisused.
(3)“Standard60°Ccottonprogramme”andthe“standard40°Ccottonprogramme”arethestandardwashingprogrammestowhichtheinformationinthe
label and the fiche relates and these programmes are suitable to clean normally soiled cotton laundry and that they are the most efficient programmes in
termsofcombinedenergyandwaterconsumption.
Technicalspecificationsmaybechangedwithoutpriornoticetoimprovethequalityoftheproduct.

19 / EN Washing Machine / User’s Manual
7 Troubleshooting
Programme cannot be started or selected.
• Washingmachinehasswitchedtoselfprotectionmodeduetoasupplyproblem(linevoltage,waterpressure,etc.).>>>To cancel the
programme, turn the Programme Selection knob to select another programme. Previous programme will be cancelled. (See “ Cancelling
the programme”)
Water in the machine.
•Somewatermighthaveremainedintheproductduetothequalitycontrolprocessesintheproduction.>>>This is not a failure; water is
not harmful to the machine.
Machine vibrates or makes noise.
•Machinemightbestandingunbalanced.>>>Adjust the feet to level the machine.
•Ahardsubstancemighthaveenteredintothepumpfilter.>>>Clean the pump filter.
•Transportationsafetyboltsarenotremoved.>>>Remove the transportation safety bolts.
•Laundryquantityinthemachinemightbetoolittle.>>>Add more laundry to the machine.
•Machinemightbeoverloadedwithlaundry.>>>Take out some of the laundry from the machine or distribute the load by hand to
balance it homogenously in the machine.
•Machinemightbeleaningonarigiditem.>>>Make sure that the machine is not leaning on anything.
Machine stopped shortly after the programme started.
•Machinemighthavestoppedtemporarilyduetolowvoltage.>>>It will resume running when the voltage restores to the normal level.
Programme time does not countdown. (On models with display)
•Timermaystopduringwaterintake.>>>Timer indicator will not countdown until the machine takes in adequate amount of water. The
machine will wait until there is sufficient amount of water to avoid poor washing results due to lack of water. Timer indicator will resume
countdown after this.
•Timermaystopduringheatingstep.>>>Timer indicator will not countdown until the machine reaches the selected temperature.
•Timermaystopduringspinningstep.>>>Automatic unbalanced load detection system might be activated due to the unbalanced
distribution of the laundry in the drum.
•Machinedoesnotswitchtospinningstepwhenthelaundryisnotevenlydistributedinthedrumtopreventanydamagetothemachineand
to its surrounding environment. Laundry should be rearranged and re-spun.
Foam is overflowing from the detergent drawer.
•Toomuchdetergentisused.>>>Mix 1 tablespoonful softener and ½ l water and pour into the main wash compartment of the
detergent drawer.
•Putdetergentintothemachinesuitablefortheprogrammesandmaximumloadsindicatedinthe“Programmeandconsumptiontable”.
When you use additional chemicals (stain removers, bleachs and etc), reduce the amount of detergent.
Laundry remains wet at the end of the programme
•Excessivefoammighthaveoccurredandautomaticfoamabsorptionsystemmighthavebeenactivatedduetotoomuchdetergentusage.
>>>Use recommended amount of detergent.
•Machinedoesnotswitchtospinningstepwhenthelaundryisnotevenlydistributedinthedrumtopreventanydamagetothemachineand
to its surrounding environment. Laundry should be rearranged and re-spun.
Awarning: Ifyoucannoteliminatetheproblemalthoughyoufollowtheinstructionsinthissection,consultyourdealerorthe
AuthorizedServiceAgent.Nevertrytorepairanonfunctionalproductyourself.
