FM Calefaccion RXB 606 System manual

Manual Usuario Smart v7”_v1
1
Mod. B4600Humid
AUTOMATIC WASHING SYSEM
Models:
RXB 606, RXB 610, F 106, F 110 (SMART v7”)
(TOUCH SCREEN v7“)
INSTRUCTIONS AND INSTALLATIONS
HANDBOOK

Manual Usuario Smart v7”_v1
2
Mod. B4600Humid
INDEX
1. CE CERTIFICATION 3
2. TECHNICAL CHARACTERISTICS 4
3. GERERAL WARNINGS 4
4. WARRANTY 4
5. INSTRUCTIONS FOR INSTALATION & MAINTENANCE 5
5.1 Electric installation 5
5.2 Water connection 5
5.3 Components of the automatic washing system 5
5.4 Washing box 6
5.5 Washing system installation 6
6. OPERATION OF THE WASHING SYSTEM 8

Manual Usuario Smart v7”_v1
3
Mod. B4600Humid
1. CE CERTIFICATION
DECLARACIÓN DE CONFORMIDAD
DECLARATION OF CONFORMITY
Directiva(s) del Consejo con la(s) que se declara conformidad:
Council Directive(s) to which conformity is declared:
DC 2006/95/CE + DC 2004/108/CE + DC 2011/65/EU
Aplicación de las Normas:
Application of the Standards:
EN 60335-1:2012 / EN 60335-2-42:2003 + Corr:2007 + A1:2008 + A11:2012 /
EN 55014-1:2006 + A1:2009 + A2:2011 / EN 55014-2:1997 + A1:2001 + A2:2008 / EN
61000-3-2 :2006 + A1:2009 + A2:2009 / EN 61000-3-3 :2008
Fabricante / Manufacturer´s name FM CALEFACCIÓN S.L.
CIF: B-14343594
Dirección / Manufacturer´s address: CTRA. de Rute km.2.700, C.P.:14900,
Lucena, Cordoba, España
Tipo de equipo / Type of equipment: KIT LAVADO HORNO/WASHING KIT
Marca / Trade.: FM CALEFACCIÓN
Modelo / Model no.: RXB 606, RXB 610, F 106, F 110 (SMART v7”)
Nosotros, los abajo firmantes, declaramos bajo nuestra exclusiva responsabilidad que el
equipo especificado cumple con la(s) Directiva(s) y Norma(s) mencionadas
We, the undersigned, hereby declare under our sole responsibility that the specified
equipment is in conformity with the above Directive(s) and Standard(s)
Lugar / Place:Lucena (Firma / Signature)
B-14785315
(Nombre / Full name)

Manual Usuario Smart v7”_v1
4
Mod. B4600Humid
2. TECHNICAL CHARACTERISTICS
3. GERERAL WARNINGS
Read this manual handbook before you start working with the device. Keep it for consultation, and if you
need technical assistance, you must consult to your distributor.
This manual must be delivered with the appliance.
The installation, start, and maintenance of the oven must be performed only by qualified personal in
accordance with the instructions of the manufacturer.
Not manipulate or disconnect the safety devices of the device, this would lead to the cancellation of the
warranty.
The oven must be operated by personal trained for this purpose.
In case of prolonged inactivity of the device, must suspend all connections (power and water).
The oven must be used only and exclusively for the purpose for which it was designed, i.e. for baking
bread, cakes, all kinds of food, fresh or frozen products. Any different use of this can cause damage to
the oven.
Do not introduced products with a high alcohol concentration.
The inner and outer surfaces of the oven should be cleaned frequently, to ensure hygiene and proper
operation. To clean these surfaces, do not use an abrasive or flammable products, it can damage the
surface of the appliance.
The aftermarket parts do not guarantee the optimal performance of the device and it will cause the loss
of the warranty.
Is recommended to use an anti-lime filter in the water supply inlet, in case of non-use this filter, may be
deteriorated parts of the oven. In this case the oven loses its warranty.
4. WARRANTY
The warranty does not cover damage of the glasses, lamps, door seal or deterioration of the insulating
material or attributable to improper installation, improper maintenance or improper repair or lack thereof, as well
as improper use of the device.
For any inquiry, please always refer to the following specification table:
Warning: improper adjustment, installation, service or maintenance of the device can cause damage on goods
or persons. For this reason please read this manual carefully before starting up the unit.
Distributor
Installer
Model
Serial Number

Manual Usuario Smart v7”_v1
5
Mod. B4600Humid
5. INSTRUCTIONS FOR INSTALATION & MAINTENANCE
5.1 Electric installation
The electric installation must be done with an authorized technician, and compiling all the normatives.
Ascertain that the electric red connection is match with the technical feature of the devices.
5.2Water connection
Is recommended, to use anti-lime system before to connect the water pipes to the device. The
water connection is ¾ “.
Important: The incoming water must have a pressure between 1 and 3 bars with a temperature not exceeding
30 ° C. If the pressure is higher than these values, must install a pressure reducer at the entrance.
5.3Components of the automatic washing system
¡Attention! Please read this manual carefully before starting up the unit.
The washing system consists of the following components:
1. Washing box
2. Rotating arm
3. Security connections clips.
4. Fixing screws.
1
2
4
3

Manual Usuario Smart v7”_v1
6
Mod. B4600Humid
5.4Washing box
5.5Washing system installation
1. First unscrew the cap from the back of the oven.
2. Insert the washing box power cord and connect the quick connection enabled in the back part of the
oven.
Housing
Detergent pump
Rinse aid pump
Detergent aspiration
Inlet
Washing water outlet
Electrical connection
Rinse aid aspiration
Washing water outlet

Manual Usuario Smart v7”_v1
7
Mod. B4600Humid
3. Secure the washing box using the screws provided.
4. Connect the water cables to the corresponding washing box entry.
5. Connect the output water cable of the washing box into the corresponding socket
6. Place the security connection clips.
5.a. Washing water inlet
Inlet
Inlet
Water humidificator
4. Main water

Manual Usuario Smart v7”_v1
8
Mod. B4600Humid
7. Remove the cap from the oven cavity and screw the rotating arm on the roof of the oven.
6. OPERATION OF THE WASHING SYSTEM
Filling the detergent and rinse aid circuit
The first time you install the automatic washing system, you should perform a washing test! Immerse both
pipes “detergent as brightener”, into the cans. Select a washhing program (Soft, Medium or Hard) and wait until
the cycle ends.
Washing programs
The device has 3 different washing programs:
-SOFT: Ideal for frequent use, for the removal of non-fat and low resistance usage.
-MEDIUM: ideal for dirt caused by several consecutive cooking cycles.
-HARD: ideal for very dirty and resistant usage.
For more information about the operation of the automatic washing system see manual of the oven. Section
"AUTOMATIC WASHING"
PROGRAMOZÁS: Service menü, "-19" kód, W17 menüpont, 0-ról átállítani 3-ra!
