BLQ32SVF AND BLQ36SVF BRICK
LINER KIT
INSTALLATION INSTRUCTIONS
www.fmiproducts.com
36" Fiber Panel Kit BLQ36SVF
IMPORTANT: Read entire instruction sheet before installing brick liner
This brick liner accessory is approved for use in VFS32NRK/PRK and VFS36NRK/PRK vent-free gas replaces. Do not use brick
liner accessory in any other replace models.
Description
Rear Panel
Right Side Panel
Left Side Panel
Retainer Brackets
#10 Screws
Part No.
126383-04
126383-06
126383-05
116531-01
Qty.
1
1
1
2
4
Description
Rear Panel
Right Side Panel
Left Side Panel
Retainer Brackets
#10 Screws
Part No.
126377-04
126377-06
126377-05
116531-01
Qty.
1
1
1
2
4
The Brick Liner Kit contains the following:
32" Fiber Panel Kit BLQ32SVF
Figure 1 - Removing Fireplace Screen
Screen
Assembly
Magnet
Bottom Panel
Assembly
Top Panel
Assembly
Top Outer Casing
Fireplace
Hood
1. To remove the screen push in on the bottom left and right
corners. The screen should spring forward, lift screen up off
the hinge brackets.
2. Remove logs. Remove the three screws that attach the log
base assembly to the replace. There are two on the front of
the base and the third one is located behind the base. Care-
fully pull the base forward as far as you can (see Figure 2,
page 2).
CAUTION: Do not pick up log base assembly by burners.
This may damage burners. Only pick up base by the grate.
WARNING: A qualied service person must connect and
disconnect replace to gas supply. Follow all local codes.
3. Install rear panel (small row of bricks at the top) by angling
the bottom of the panel into the replace and sliding it behind
the base. Be careful to not scratch the face of the rear panel.
Stand the panel straight up against the back of the replace
(see Figure 3, page 2).
Tools Required
• Phillips Screwdriver
• 5/16'' Nut Driver
• Flashlight
If any of these parts are missing or damaged, contact the dealer
where you purchase this kit. If they cannot supply original re-
placement parts call FMI PRODUCTS, LLC at 1-866-328-4537
for information.
IMPORTANT: Always handle rebrick panels with two hands.
WARNING: Turn off, unplug, and let replace cool be-
fore installing brick liner. Only a qualied service person
should service and repair replace.
NOTICE: You must remove logs before installing brick liner.

126452-01
Rev. A
10/12
2701 S. Harbor Blvd.
Santa Ana, CA 92704
1-866-328-4537
www.fmiproducts.com
CAUTION: Always handle ber panels with two hands.
Do not force ber panels into place. Excessive force will
break ber panels.
Figure 3 - Installing Rear Brick Panel
Figure 2 - Removing Log Base Assembly from Fireplace
Rear Brick
Panel
Rear Screw
Front Two Screws
4. Place the side panel behind the oor panel retainer. Slide front
side of the panel behind the retaining edge of the replace.
Gently press the panel back against the side wall (see gure
4). The bottom edge of the panel will rest on the oor and
against the back panel.
5. Secure side panel to side wall of replace with one retainer
bracket and two screws (see Figure 5).
6. Repeat steps 4 and 5 to install other side of rebrick panel.
7. Put log base assembly back into replace. Secure log base
assembly with the three screws removed in step 2 (see Figure
2).
Figure 4 - Installing Side Brick Panel
Figure 5 Securing Side Brick Panel
Side Wall
Retainer Bracket
Retaining
Edge
Floor Panel
Retainer
Side Panel
Screws
WARNING: Test all gas piping and connections for
leaks after installing or servicing. Correct all leaks at once.
WARNING: Never use an open ame to check for a
leak. Apply non corrosive leak detection uid to all joints.
Bubbles forming show a leak. Correct all leaks at once.
8. Replace logs. Make sure logs are put in their proper position.
See Installing Logs in the Fireplace Owner ʼs Manual.
9. Replace screen (see Figure 1, page 1).
