FOCO Office-Container User manual

ASSEMBLY INSTRUCTIONS
Office-Container

Tools needed
- Screwdriver or drill (Phillips head)
- 13 mm wrench
- 19 mm wrench
- Torque wrench (13 mm and 19 mm attachments)
Assembly Manual:
[e-mail] www.fococontainers.com0031 85 0685 590
First, using the 19 mm and 13 mm wrenches, remove the screws holding the floor and roof package
together, save these screws. There are four pieces on the long sides and four corner pieces in total.
Then remove the wooden blocks at the corners of the package and the iron blocks in the middle,
these are not required for assembly, but may come in handy in leveling the container.

[e-mail] www.fococontainers.com0031 85 0685 590
Next, remove the panels and materials from the package. Do not place them on the asphalt. This
may cause damage in the form of dents or scratches. Lay the materials down very gently on level
ground. Always assemble a quick build office on a straight level surface. Note that there are short
and long panels. Check all supplied parts as shown in the first picture.
First, install a corner profile in the corner of the
floor.
Then slide a short panel into the profile.
Between the panels you place the coupling
pieces. These are shown to the right.

[e-mail] www.fococontainers.com0031 85 0685 590
In the picture above, you can see that on the short side, two long panels are placed. On the long side
you can see two short panels, and from then in the middle two long panels, so you connect these to
the corner profiles.
The last corner profile is slid down from the top. Because the panels all come separately, it is
possible to decide where you want the windows and door to be.

[e-mail] www.fococontainers.com0031 85 0685 590
Before the roof can be installed, the roof profiles must be mounted on the panels. Four pieces for
four sides.
Roof placement varies by model. For two-by-two meter units, two adults can lift the roof. For three
and four meter offices, we recommend lifting with at least four people.

After the roof is in place, lifting hinges are mounted to each corner of the roof panel.
[e-mail] www.fococontainers.com0031 85 0685 590
A screwdriver can be used to attach the door and window handle. The door handle must be screwed
on both sides with screws. Then the supplied cap can be put on and the door handle is mounted.
The window handle is mounted in the same way. This is done with two screws per handle. You then
place the cover over the window handle as well.
You can now use the quick build office container. If had any difficulties, you can always reach us
using the contact information below.
ENJOY YOUR OFFICE CONTAINER!
