for Living A702000300 User manual

Product No. 088-0052-8
Model No. A702000300
Toll-free: 1-877-483-6759
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
Assembly Instructions
Umbrella Base
Production Number: xxxxxxxx

Imported by Trileaf Distribution Trifeuil, Toronto, Canada M4S 2B8
Made in China

3
Table of Contents
Important Safety Instructions
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY
DO NOT over-tighten any of the bolts or nuts. Tighten each bolt and nut until secure.
DO NOT attempt to over-tighten as this may cause DAMAGE to the threads and umbrella pole.
ENSURE that all nuts are not cross threaded before tightening commences. Repeated assembly can weaken
the locking ability of the washers. Periodically check all bolted connections on your furniture to make sure they
are tight and secure.
For use with patio table only: Must be paired with patio umbrella and table with umbrella hole for required
stability.
3
3
4
5
6
6
Table of Contents
Important Safety Instructions
Part List
Assembly
Technical Data
Warranty

Part List
4Product No. 088-0052-8 •Model No. A702000300
Bolt M10*35 - 1
Washer M10 - 1
Spring Washer M10 - 1
A
Umbrella Pole ￠38 -1
B
Umbrella Base - 1
DD
Wrench M10 - 1
BB
CC
E
Ring ￠36 /￠32/￠30（Pre-assembled on B）- 1
DD
AA H010010022
P008100003
P007300014
P005700326
H050010002
H050020021

Assembly
5
STEP 1: Assembly of Umbrella
1x 1x
B
B
1x
CC
BB

6Product No. 088-0052-8 •Model No. A702000300
Technical Data
Warranty
16.93'' x 16.93'' x 11.81''
Dimensions (L x W x H)
5 .5 kg
Product weight
12 lb
43 x 43 x 30 cm
This For Living™ product carries a one (1) year warranty against defects in workmanship and materials.
Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty period,
when returned by the original purchaser with proof of purchase. This product is not guaranteed against wear
or breakage due to misuse and/or abuse.
