formlabs GALVO Configuration guide

CLEANING THE
GALVO MIRRORS
Tools:
2.5mm hex wrench
Nitrile Gloves
PEC-PAD lint free wipes
Swabsticks
Isopropyl Alcohol
WARNING!
Anything that comes in contact with first surface mirrors in the Form 1+
can cause scratches and irreversible damage. Exercise extreme caution
when the mirror is exposed.
Contact [email protected] with any questions.
Formlabs Customer Support can provide additional information on mirror
cleaning and in some cases, provide the customer with the appropriate
cleaning supplies.
DO NOT COPY OR REDISTRIBUTE THIS INFORMATION

2/7
DO NOT COPY OR REDISTRIBUTE THIS INFORMATION
1. Remove the Back Panel
At the back of the Form 1+, remove two black button-head screws on either
side using the 2.5mm hex wrench. Lift the cover and remove two silver
countersunk screws under the cover. Some machines may also have two
silver countersunk screws along the rear edge on the bottom of the Form
1+.
Carefully remove the back panel after all screws have been removed.
Properly label the galvanometer cables so they will not be switched when
plugging them back in. Unplug the connectors to the Y-Galvanometer, the
X-Galvanometer, and the laser.
2. Unplug Cables + Laser
Y Galvanometer
X Galvanometer
Laser

3/7
3. Remove Galvo Block
Using a 2.5mm hex driver, remove the recessed screws in the upper right
and lower left corners of the galvo block. Once the screws are removed,
slowly wiggle the galvo block free from the Form 1+ frame.
WARNING: DO NOT REMOVE OR TAMPER WITH ANY OTHER SCREWS IN THE
GALVO BLOCK. ADJUSTING ANY OTHER SCREWS WILL MOVE THE PRINTER
OUT OF CALIBRATION.
Cut a strip about 1cm wide out of PEC-PAD. Lay the swab stick on the
PEC-PAD as shown above. Apply a piece of tape extending beyond the length
of the PEC-PAD strip.
DO NOT COPY OR REDISTRIBUTE THIS INFORMATION
4. Prepare the Swab
4. Prepare the Swab

4/7
5. Close the printer
DO NOT COPY OR REDISTRIBUTE THIS INFORMATION
Fold the end of the PEC-PAD over to the side. Begin wrapping the PEC-PAD
tightly down and around the shaft as shown.
Secure the PEC-PAD strip at the bottom of the shaft with another piece of
small tape. When finished, it should look similar to the one shown.
Apply a small amount of isopropyl alcohol to the PEC-PAD swab.

4. Inspect the Mirrors
Closely inspect the mirrors for any signs of particles, dust or residue. Use a
bright light or a flashlight to illuminate the mirrors.
If it is necessary to clean the mirror, carefully position the galvo block as
shown. Use the swab to gently rotate the mirror so that the surface is more
easily accessible. Gently wipe the mirror from the base of the mirror to the
end of the mirror. Rotate the swab and wipe again.
WARNING: DO NOT EXERT EXCESSIVE PRESSURE ON THE GALVO MIRROR.
NEVER TOUCH THE MIRROR WITH ANYTHING OTHER THAN A PEC-PAD. 5/7
DO NOT COPY OR REDISTRIBUTE THIS INFORMATION
5. Wipe Y Galvo Mirror

6. Wipe X Galvo Mirror
Prepare a new swab. It is important to use a fresh swab so as not to spread
any particles or residues that had been caught by the previous swab.
Carefully position the galvo block as shown. Use the swab to gently rotate the
mirror so that the surface is more easily accessible. Gently wipe the mirror
from the base of the mirror to the end of the mirror. Rotate the swab and
wipe again.
.
Once the mirrors are clean, the galvo block can be reinstalled into the Form
1+. Use a bright light or flashlight to illuminate the mirrors.
7. Inspect the Mirrors
6/7
DO NOT COPY OR REDISTRIBUTE THIS INFORMATION

8. Reinstall Galvo Block
Align the alignment pins and insert the galvo block into the Form 1+. Insert
the two screws and secure the galvo block to the Form 1+ frame.
Reconnect the galvanometer cables and the connect the laser to the main
board. Then, reinstall the Form 1+ back panel.
9. Plug in Cables + Laser
Y Galvanometer
X Galvanometer
Laser
7/7
Questions? Get in touch with us at [email protected]
