Foster EcoPro G2 EP700SH User manual

By Appointment to
Her Majesty Queen Elizabeth II
Suppliers of Commercial Refrigeration
Foster Refrigerator,
King’s Lynn
EcoPro G2 EP700SH & EP700SL
Controller & Display FD1-14
English
ISO 9001 ISO 14001
A Division of ITW Ltd
Foster Refrigerator
Oldmedow Road
King’s Lynn
Norfolk, PE30 4JU
United Kingdom
Call: [phone] Email: [e-mail]
Original Instrucons
01-582283-01 November 2019
www.fosterrefrigerator.co.uk

English
Models Applicable to This Manual
EP700SH
EP700SL
Electrical Safety
Foster Refrigerator recommends that the equipment is electrically connected via a Residual Current Device; such as
a Residual Current Circuit Breaker (RCCB) type socket, or through a Residual Current Circuit Breaker with Overload
Protecon (RCBO)
supplied circuit.
Should it be necessary to replace the fuse. The replacement fuse must be of the value stated on the serial label for the
cabinet.
Disposal Requirements
If not disposed of properly all refrigerators have components that can be harmful to the ennviroment. All old
refrigerators must be disposed of by appropriately registered and licensed waste contractors, and in accordance with
naonal laws and regulaons.
Climate Class
Climate class is indicated on the serial plate, shows the temperature & humidity at which this appliance has been test-
ed, for the purposes of establishing values in line with European standards.
Important Note to the Installer:
Please ensure that this document is passed to the user as it
contains important guidelines on operaon, loading, cleaning
and general maintenance and should be kept for reference.
General Safety
Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.
Keep all venlaon openings in the appliance or in the structure of a built in unit clear of any obstrucons.
Do not use electrical appliances inside the storage compartment.
The appliance is air ght when the door is closed therefore under no circumstances should any living body be stored or
‘locked in’ the applicance.
The moving of the appliance should be carried out by competent personnel, ensure that two or more people are used
to guide and support the appliance, the appliance should not be moved over uneven surfaces.
The emied sound level of this appliance is below 70db(A).
To ensure stability the appliance should be located on a at, level surface, correctly loaded with the castors locked.
If the supply cord is damaged, it must be replaced by the manufacturer, it’s service agent or similarly qualied persons
in order to avoid hazards.
Care should be taken to avoid prolonged contact with cold surfaces with unprotected body parts, Correct PPE to be used
at all me.
1

English
Start-Up and Operaon
Aer unpacking, clean and allow the cabinet to stand for 2 hours before turning on (cleaning direcons supplied
within this manual). Ensure the cabinet is situated on a rm, level surface away from both hot and cold air sources, as
this will aect its performance.
Clearance (All models)
Make sure that a minimum clearance of 100mm above and 50mm around the cabinet is available for venlaon and
eecve operaon.
Connect the unit to a suitable mains power outlet and turn the supply on. Please do not plug or unplug the unit with
wet hands.
The cabinet will energise briey showing followed by the power switch slowly pulsing with a blank display. The unit
is now in standby.
Standby
Pressing the power switch for 3 seconds will turn the unit on (the switch backlight is stac and the display shows the
operang temperature) or into standby (the switch backlight pulses slowly on and o).
As the operang temperature has been preset no adjustments are required. Allow the cabinet to reach its normal/set
operang temperature before loading.
Display Icons and Switches
(Cabinet Version)
Keypad Lock Warning/ Alarm
Service Mode Temperature Seng
Compressor Funcon Defrost Funcon
Evaporator Fan Funcon Reduced Energy Mode
Data Download Switch Light Switch
Decrease Switch Increase Switch
Power Switch
(Some icons or switches are only visible during adjustment, when acvated by parameters or through
operaon/manual selecon).
2

English
Adjustment
Screen
T1 Probe
Temperature
Keypad Lock
Screen
Set Point
Screen
T3 Probe
Temperature
T2 Probe
Temperature
To exit this mode scroll back to the adjustment screen and press or wait for 30 seconds and the display will revert to
the normal display showing the operang temperature.
Set Point and Other Mode Adjustments
Access the adjustment mode as described above. Using the or switches to scroll to the mode that requires
adjustments i.e ‘Set Point’ this is the minimum temperature the cabinet is allowed to cool down to (the display shows
the temperature and ash/pulsing icon ). To adjust this press and release the icon will show constantly. Adjust
the seng with the or switch. Conrm the change by pressing and releasing again, the next mode will
automacally show. Scroll through the modes with the or switch unl you return to the adjustment screen and
press and release to exit and save.
If at any point the display is le for 30 seconds it will revert to the normal display and no changes will be saved.
Keypad Security Sengs
Access the ‘Keypad Security’ screen as described above. The screen will show the current status, inially preset to ‘
’, with ashing. Press and release and will show constantly. (If you modify this seng with to show ‘ ‘
the keypad will be locked, will show constantly and the cabinet will not be able to be put into standby, carry out a
manual defrost, adjust temperature set point, download data or switch on/o the units lights. To conrm any change
you must press again so the next screen ‘ ’ shows). Exit any of the ‘Adjustment Modes’ as described above.
Shelves and Supports
G2 shelving for low or high temperature cabinets consist of two trayslides per shelf. These slot directly into the rear of
the cabinet’s airduct and have ladderacking to support the front.
Shelves are the standard wire gastronorm style that slide onto the trayslides.
3
User Adjustment Mode
You are required to enter this mode to make any setup changes.
These include Set Point, Keypad Security and display of T1, 2 or 3 probe temperatures.
Press and immediately release aer which the and switches will ash/pulse together.
Press to scroll through the following screens:

English
Defrost
All Foster G2 cabinets are ed with a fully automac defrost system to ensure that the evaporator coil remains
free from ice during normal use. Melt-water is evaporated using either the heat from the refrigeraon system or a
separate electric heater (dependent upon model and conguraon)
To acvate a manual defrost - while the cabinet is in ‘run’ mode press and hold for 5 seconds. Aer 3 seconds
the display will go blank then return aer a further 2 seconds. At this point a defrost will be performed (subject to
underlying operang parameters), this will terminate automacally.
Cleaning and Maintenance
Important: Before cleaning, the unit should be put into standby and then the power supply should be
turned o at the mains. Please do not plug or unplug the unit with wet hands. Only when cleaning has been
completed and the unit is dry should the cabinet be turned back on at the mains.
Suitable P.P.E (Personal Protecve Equipment) should be worn at all mes.
Regular Maintenance:
> As and when required remove all product and shelving (beware of cold and or sharp components) from the
unit. Clean exterior and interior surfaces with mild liquid detergent, following the direcons on the pack
at all mes. Rinse surfaces with a damp cloth containing clean water. Never use wire wool, scouring pads/
powders or high alkaline cleaning agents i.e bleaches, acids and chlorines as these may cause damage.
> All gaskets should be inspected on a regular basis and replaced if damaged. To clean, wipe with a warm
damp soapy cloth followed by a clean damp cloth. Finally thoroughly dry.
> Shelves and their supports can be removed for cleaning. The shelves are dishwasher safe; however the
vercal supports should be cleaned with warm soapy water then rinsed and dried.
4
Door & Drawer Lock
To lock the door insert the key and turn 90°, turn in the opposite direcon to unlock.
Food
Cover all foods and separate raw and cooked foods to avoid cross contaminaon.
Loading and Airow
Ensure that there is no more than 40kg of evenly distribute product placed on each shelf. Always ensure the air can
circulate around/through the stored product.
It is important that for opmal energy performance that adequate airow is maintained around the perimeter of the
shelves, and around all stored products. On all models please ensure that no product is placed on the unit base.

English
5
4
35
6 7
1 2
If there are any stubborn grease deposits le on or through the condenser call your supplier to carry out a full service
(this is normally chargeable). Failure to maintain the condenser may invalidate the warranty of the condensing unit
and cause premature failure of the motor/compressor. Do not use a wire brush to clean the condenser.
Condenser Cleaning
Maintenance should take place on a regular basis or as and when required by a competent/trained personnel.

English
Troubleshoong
Alarms/Warnings
Low Temperature Alarm Condenser Clean Warning #
High Temperature Alarm Condenser High Temperature Alarm #
T1 Air Probe Failure High Pressure Alarm #
T2 Evaporator Probe Failure #Door Open Alarm #
T3 Condenser Probe Failure #Mains Power Failure #
# only displayed if applicable to model and enabled through parameters.
Power Failure Warning
‘ ‘ will be displayed, the alarm will sound and will show when there has been a mains power failure that
has aected the internal air temperature of the cabinet (not applicable to units when in standby mode).
When mains power is restored the cabinet will connue to operate, and adjust the temperature as
required.
The warning will sound and show unl has been pressed and released, to cancel the alarm.
We would recommend the contents of the unit are inspected.
Before calling your supplier please make sure that:
a. The plug has not come out of the socket and the mains power supply is on i.e. is the controller illuminated?
b. Check to see if the unit is in standby
c. The fuse for the cabinet is intact
d. The cabinet is posioned correctly – cold or warm air sources are not aecng the performance
e. The condenser is not blocked or dirty
f. The products are placed in the unit correctly
g. Defrost is not in progress or required
If the reason for the malfuncon cannot be idened, disconnect the electrical supply to the unit and contact your
supplier. When requesng a service call, please quote the model and serial number which can be found on the silver
label located on the inside of the unit (starts E......).
6
