Foster BIT25 User manual

Undercounter, Space Saver,
Prep Tables & XR415
Cabinet & Counter Models
BIT25 Controller & LCD5S Display
By Appointment to
Her Majesty Queen Elizabeth II
Suppliers of Commercial Refrigeraon
Foster Refrigerator, King’s Lynn
Foster Refrigerator
Oldmedow Road
King’s Lynn
Norfolk, PE30 4JU
United Kingdom
A division of ITW Ltd
Email:[e-mail]: [phone]
www.fosterrefrigerator.co.uk
Call: [phone]
ISO 9001 ISO 14001
English
Original Service Manual

Contents Page
Manual Informaon & Health & Safety Notes 1
Environmental Management Policy 2
Disposal Requirements & Electrical Safety 2
Displays Icons & Switches 3
BIT25 User Funcons - Start Up, Set Point, Standby, Key Security & Defrost Funcon 3 to 4
BIT25 Controller Connecon Drawing & Conguraon of Parameters 4 to 5
BIT25 Controller Default Parameters 5 to 9
Model Temperature Specic Parameters 10 to 12
Wiring Diagram 12
Drawer removal & Cleaning Instrucons 14 to 15
Troubleshoong 16 to 18
English
Service Manual Informaon:
The products and all informaon in this manual are subject to change without prior noce.
We assume by the informaon given that the person(s) working on these refrigeraon units are
fully trained and skilled in all aspects of their workings. Also that they will use the appropriate safety
equipment and take or meet precauons where required.
The service manual does not cover informaon on every variaon of this unit; neither does it cover the
installaon or every possible operang or maintenance instrucon for the units.
Health & Safety Warnings & Information
Make sure the power supply is turned o before making any electrical repairs.
To minimise shock and re hazards, please do not plug or unplug the unit with wet hands.
During maintenance and cleaning, please unplug the unit where required.
Care must be taken when handling or working on the unit as sharp edges may cause
personal injury. We recommend the wearing of suitable PPE.
Ensure the correct moving and liing procedures are used when relocang a unit.
Do NOT use abrasive cleaning products, only those that are recommended. Never scour any
parts of the refrigerator. Scouring pads or chemicals may cause damage by scratching or dulling
polished surface nishes.
Failure to keep the condenser clean may cause premature failure of the motor/compressor which
will NOT be covered under warranty policy.
Do NOT touch the cold surfaces in the freezer compartment. Parcularly when hands are damp
or wet, skin may adhere to these extremely cold surfaces and cause frostbite.
Please ensure the appropriate use of safety aids or Personnel Protecve Equipment (PPE) are
used for you own safety.
1

English
Environmental Management Policy
Product Support and Installaon Contractors.
Foster Refrigerator recognises that its acvies, products and services can have an adverse impact upon the
environment.
The organisaon is commied to implemenng systems and controls to manage, reduce and eliminate its adverse
environmental impacts wherever possible, and has formulated an Environmental Policy outlining our core aims. A copy
of the Environmental Policy is available to all contractors and suppliers upon request.
The organisaon is commied to working with suppliers and contractors where their acvies have the potenal to
impact upon the environment. To achieve the aims stated in the Environmental Policy we require that all suppliers and
contractors operate in compliance with the law and are commied to best pracce in environmental management.
Product Support and Installaon contractors are required to:
1. Ensure that wherever possible waste is removed from the client’s site, where arrangements are in place all waste
should be returned to Foster Refrigerator’s premises. In certain circumstances waste may be disposed of on the
client’s site; if permission is given, if the client has arrangements in place for the type of waste.
2. If arranging for the disposal of your waste, handle, store and dispose of it in such a way as to prevent its escape
into the environment, harm to human health, and to ensure the compliance with the environmental law. Guidance is
available from the Environment Agency on how to comply with the waste management ‘duty of care’.
3. The following waste must be stored of separately from other wastes, as they are hazardous to the environment:
refrigerants, polyurethane foam, and oils.
4. When arranging for disposal of waste, ensure a waste transfer note or consignment note is completed as
appropriate. Ensure that all waste is correctly described on the waste note and include the appropriate six-digit code
from the European Waste Catalogue. Your waste contractor or Foster can provide further informaon if necessary.
5. Ensure that all waste is removed by a registered waste carrier, a carrier in possession of a waste management
licence, or a carrier holding an appropriate exempon. Ensure the person receiving the waste at its ulmate
desnaon is in receipt of a waste management licence or valid exempon.
6. Handle and store refrigerants in such a way as to prevent their emission to atmosphere, and ensure they are
disposed of safely and in accordance with environmental law.
7. Make arrangements to ensure all sta who handle refrigerants do so at a level of competence consistent with the
City Guilds 2079 Handling Refrigerants qualicaon or equivalent qualicaon.
8. Ensure all liquid substances are securely stored to prevent leaks and spill, and are not disposed of into storm
drains, foul drain, or surface water to soil.
Disposal Requirements
If not disposed of properly all refrigerators have components that can be harmful to the environment.
All old refrigerators must be disposed of by appropriately registered and licensed waste contractors,
and in accordance with naonal laws and regulaons.
General Electrical Safety
Foster Refrigerator recommends that the equipment is electrically connected via a Residual Current Device; such as
a Residual Current Circuit Breaker (RCCB) type socket, or through a Residual Current Circuit Breaker with Overload
Protecon (RCBO) supplied circuit.
2

English
Controller Operation - BIT25
The controller consists of two pieces, the controller (BIT25) and separate display (LCD5S).
LCD5S Display Icons and Switches
Display Indicators & Buons Alarms/ Warnings During Normal Operaon
Info/ Set Point Buon Controller in Standby
Manual Defrost/ Decrease Buon Room High Temperature Alarm
Manual Acvaon/ Increase Buon Room Low Temperature Alarm
Exit/ Standby Buon Probe T1 Failure (Air)
Thermostat/ Compressor Output Generic Alarm
Fan Output Defrost In Progress
Alarm Warning Keypad Locked
Defrost Output
Informaon Menu Symbols and Reasons
Instant probe 1 temperature Minimum probe 1 temperature recorded
Maximum probe 1 temperature recorded Compressor working weeks **
** Displayed only if ACC > 0
Start Up and Operaon
User Funcons
Start Sequence
When the unit is rst connected to the mains the display will automacally light up and show either or the
current ambient temperature.
To start or acvate when in standby:
> Press and hold the buon for 5 seconds then release.
Access to the menu and informaon displayed
> Press and immediately release buon .
> With buon or select the data to be displayed
> Press and hold buon to display the value
> To exit from the menu, press buon or wait for 10 seconds.
3

English
Set point: Display and modicaon
>Press buon and hold to display the set point.
>By keeping buon pressed, use buon or to set the desired value (adjustment is within the minimum
SPL and the maximum SPH limit)
>When buon is released, the new value is stored.
Standby
Pressing the buon for 3 seconds, will allow the controller to be put on a standby or output control to be
resumed (with SB = YES only). When on Standby will be displayed.
Keypad Unlock
Press & release then use to select ‘LOC’. Press and hold to change from ‘YES’ to ‘NO’. Leave for 10
seconds or briey press to resume.
Defrost
Automac Defrost
The cabinet will defrost automacally on a predened schedule. This seng will also automacally terminate on a
predened schedule.
Manual Defrost. (Freezer Secons only)
To iniate a manual defrost press and hold the defrost buon for 2 seconds
Controller Connection Drawing and Dimensions
(Dimensions in mm)
4

English
Controller Technical Data
Power Supply Operang Condions
BIT25 ... E 230Vac±10%, 50/60Hz, 3W -10…+50°C; 15%...80%r.H
Relay Output CE (Reference norms)
Compressor 20(8)A 240Vac
Auxiliary Loads 1 16(4)A 240Vac EN55022 (Class B)
Auxiliary Loads 2 7(2)A 240Vac EN50082-1
Input
NTC 10KΩ@25°C
Measurement Range Measurement Accuracy
-50 / -9.9…19.9 /110°C <0.5°C within the measurement range
Conguraon Parameters
>To access to the parameter conguraon menu, press + for 5 seconds
>With buon or select the parameter to be modied.
>Press buon and hold briey to display the value. On releasing the buon the controller will then show the
next parameter.
>By keeping buon pressed, use buon or to set the desired value. On releasing the buon the
controller will store the amended value and then show the next parameter.
>To exit from the setup, press buon or wait for 30 seconds.
Parameter Range Descripon Default
Seng
SPL -50 … SPH Minimum limit for 'SP' seng. 1
SPH SPL … 110° Maximum limit for 'SP' seng. 3
SP SPL … SPH Temperature setpoint to be achieved. 2
C-H REF or HEA Refrigeraon or Heang control mode. REF
HYS 1 … 10° O / On thermostat dierenal. 3
CRT 0 … 30 min Compressor rest me. 2
CT1 0 … 30 min Thermostat run me with faulty T1 probe.
(‘CT1’ = 0 output with faulty T1 will always be o). 6
CT2 0 … 30 min Thermostat o me with faulty T1 probe.
(‘CT2’ = ‘0’ & ‘CT1’ =>’0’ output with faulty T1 will always be on). 4
CSD 0 … 30 min Compressor stop delay aer door has been opened.
(Only if ‘DS’ = ‘YES’). 1
DFM
Defrost start mode:
TIM
NON Defrost funcon is disabled (the following parameter will be 'FCM').
TIM Regular me defrost.
FRO Defrost me elapses only in condion of frost accumulaon.
DFM = ‘TIM’ or ‘FRO’
DFT 0 … 99 hours Time interval between defrosts. 6
DFB
Defrost mer clock.
YESYES Following mains interrupon, mer resumes count.
NO Following mains interrupon, mer restarts from zero.
DLI -50 … 110° Defrost end temperature (Only if ‘T2’ = ‘YES’). 15
DTO 1 … 120 min Maximum defrost duraon. 20
BIT25 Controller Default Parameter Values
5

English
Parameter Range Descripon Defult
Seng
DFM = ‘TIM’ or ‘FRO’
DTY
Defrost type:
OFF
OFF Timed o cycle defrost (compressor and heater o).
ELE Electric heater defrost (compressor o, heater on).
GAS Hot gas defrost (compressor and heater on).
DPD 0 … 240 sec Evaporator pump down. Timed pause at start of defrost. 0
DPR 0 ... 20 sec Defrosng Pressure Reducon. Period between hot gas valve shung and com-
pressor stopping (only acve when 'DTY' = 'GAS'). 3
DRN 0 … 30 min Drain down period. 2
DDM
Defrost display mode:
DEF
RT Real (actual) air temperature.
LT Last temperature display before start of defrost.
SP The current setpoint value.
DEF "DEF"
DDY 0 … 60 min Defrost display delay period.
Time ‘DDM’ is shown following defrost terminaon. 10
FID
Fans in defrost:
YES
YES Fans run during defrost.
NO Fans do not run during defrost.
FDD -50 … 110° Evaporator fan restart temperature following defrost.
(Only if ‘T2’ = ‘YES’). 5
FTO 0 … 120 min Maximum evaporator fan stop period following defrost (only when 'T2' = 'YES'). 3
FCM
Evaporator fan mode during thermostac control:
NON
NON Fan(s) run connuously (subject to door & defrost).
TMP
Temperature based control. When compressor is on, fans are
on. When compressor is o, fans run as long as temperature
dierence Te-Ta > ‘FDT’. Fans on again with ‘FDH’.
TIM
Time based control. When compressor is on, fans are on.
When compressor is o, fans in accordance to parameters
FT1’, ‘FT2’ and ‘FT3’.
FDT -12.0 ... 0° Te-Ta dierence for fans to turn o aer compressor stopped.
(Only if ‘T2’ = ‘YES’ and ‘FCM’ = ‘TMP’). -1
FDH 1 ... 12.0 ° Temperature dierenal for evaporator fan restart.
(Only if ‘T2’ = ‘YES’ and ‘FCM’ = ‘TMP’). 3
FDS 0 ... 120 sec Minimum evaporator fan stop period (following door opening etc.). 20
FT1 0 ... 180 sec Fan stop delay aer compressor stop. 15
FT2 0 ... 30 min Timed fan stop following ‘FT1’.
(With FT2 = ‘0’ the fans remain on all the me). 0
FT3 0 ... 30 min Timed fan run following ‘FT2’.
(With ‘FT3’ = ‘0’ & ‘FT2’ > ‘0’ the fans remain o all the me). 2
ATM
Alarm threshold conguraon:
REL
NON All temperature alarms are inhibited (the following parameter will be 'ADO').
ABS The value set in 'ALA' & 'AHA' represent actual alarm setpoints.
REL The values set in 'ALR' & 'AHR' are alarm dierenals which
relate to ‘SP’ and ‘SP’ + ‘HYS’ (the following parameter will be ‘ALR’).
6

English
Parameter Range Descripon Default
Seng
ATM = ‘ABS’
ALA -50 … 120° Low temperature alarm threshold. -3
AHA -50 … 120° High temperature alarm threshold (the following parameter will be 'ATI'). 8
ATM = ‘REL’
ALR -12 … 0° Low temperature alarm dierenal.
With ‘ALR’ = ‘0’ the low temperature alarm is excluded). -5
AHR 0 … 12° High temperature alarm dierenal.
(With ‘AHR’ = ‘0’ the low temperature alarm is excluded). 5
ATM = ‘ABS’ or ‘REL’
AT1
Alarm probe:
T1
T1 Air temperature probe used for alarm detecon.
T2 Evaporator temperature probe used for alarm detecon (if 'T2' = 'YES').
T3 Third temperature probe used for alarm detecon (if 'DI2' = 'T3').
ATD 0 … 120 min Delay before alarm temperature warning. 90
ADO 0 … 30 min Delay before door open alarm warning (only when 'DI2' = 'DOR'). 8
AHM
Operaon in case of high condenser alarm (if 'DI2' = 'T3' and 'T3' = 'CND' ):
NON
NON High condenser temperature alarm inhibited.
ALR Condenser warning - 'HC' displayed, alarm sounds.
STP As 'ALR', with compressor stopped and defrosts suspended.
AHT -50 … 110° Condenser alarm temperature (if 'DI2' = 'T3'). 65
ACC ‘0 … 52 weeks Condenser cleaning period.
(With ‘ACC’ = ‘0’ condenser cleaning alarm is disabled). 0
IISM
Switch over method to second parameter set:
NON
NON Second parameter set is excluded (the following parameter will be 'SB').
MAN Second parameter set is acvated / deacvated by buon 'M'.
DI2 Second parameter set acvated by 'DI2' input ('DI2' = 'IISM').
ATM = ‘ABS’ or ‘REL’
IISL -50 … IISH Minimum limit for 'IISP' seng. 1
IISH IISL … 110° Maximum limit for 'IISP' seng. 1
IISP IISP … IISH Temperature setpoint to be achieved in 'Mode 2'. 1
IIHY 1 … 10° O / On thermostat dierenal in 'Mode 2'. 3
IIFC
Evaporator fan mode during 'Mode 2' thermostac control:
NON
NON Fan(s) run connuously.
TMP
Temperature based control. When compressor is on, fans are on. When
compressor is o, fans run as long as temperature dierence Te-Ta > 'FDT'.
Fans on again with 'FDH'.
TIM
Time based control. When compressor is on, fans are on.
When compressor is o, fans in accordance to parameters
T1’, ‘FT2’ and ‘FT3’.
IIDF 0 … 99 hours Time interval between defrosts in ‘Mode 2’. 6
SB
Standby buon operaon:
YESYES Standby buon enabled.
NO Standby buon disabled.
7

English
Parameter Range Descripon Default
Seng
DI1
Congurable digital input operaon:
NON
NON Digital input not acvated.
DOR Door switch input.
ALO Alarm ('ALr' displayed) when contact opens.
ALC Alarm ('ALr' displayed) when contact closes.
DI2
Congurable digital input operaon:
NON
NON Digital input not acvated.
DOR Door switch input.
ALO Alarm ('ALr' displayed) when contact opens.
ALC Alarm ('ALr' displayed) when contact closes.
PSP Allows control via potenometer.
IISM Operates 2nd parameter set when contact closes.
T3 Allows for 3rd temperature probe funcon.
DI2 = ‘T3’
T3
T3 probe funcon (only when 'DI2' = 'T3'):
DSPDSP T3 probe temperature displayed.
CND Condenser temperature measurement.
OS3 -12.5 … 12.5°C T3 probe temperature oset (only when 'DI2' = 'T3'): 0
D12 = ‘PSP’
PSL -50 … 70°C Minimum setpoint adjusted by potenometer (only when 'DI2' = 'PSP'): 10
PSR 0.0 … 15.0°C Range of setpoint (hysteresis) for potenometer (only when 'DI2' = 'PSP'):. 10
D12 = ‘PSP’
POF
Potenometer standby enabling operaon (only when 'DI2' = 'PSP'):
YESYES Potenometer standby enabled (when turned to minimum, controller set
to standby).
NO Potenometer standby disabled.
LSM
Light control mode (if 'OA1' = 'LGT'):
MAN
NON Light Control Mode disabled (always o).
MAN Light output operaon is acvated / deacvated by buon 'M'.
D1O Light output is switched on when door is opened (if 'DI1' = 'DOR').
D2O Light output is switched on when door is opened (if 'DI2' = 'DOR').
D2C Light output is switched o when door is opened (if 'DI2' = 'DOR').
OA1
Auxiliary Relay 1 Operaon:
NON
NON Output disabled (always o).
FAN Control of evaporator fan.
DEF Control of defrost heater / device (acvated when 'DTY' = 'ELE' or 'GAS').
LGT Output enabled for light control.
0-1 Contacts open/close with 'Standby'/'On' mode ('SB' = 'YES').
ALO Contacts open when an alarm condion occurs.
ALC Contacts close when an alarm condion occurs.
(Relay contacts open when in stand by mode).
8

English
Parameter Range Descripon Default
Seng
OA2
Auxiliary Relay 2 Operaon:
FAN
NON Output disabled (always o).
FAN Control of evaporator fan.
DEF Control of defrost heater / device (acvated when 'DTY' = 'ELE' or 'GAS').
LGT Output enabled for light control.
0-1 Contacts open/close with 'Standby'/'On' mode ('SB' = 'YES').
ALO Contacts open when an alarm condion occurs.
ALC Contacts close when an alarm condion occurs.
(Relay contacts open when in stand by mode).
OS1 -12.5 … 12.5°C Air temperature probe (T1) oset. 0
T2
T2 probe enabling:
NOYES T2 probe enabled.
NO T2 probe disabled.
OS2 -12.5 … 12.5°C Evaporator temperature probe (T2) oset. 0
TLD 1 … 30 min Delay for min. ('TLO') and max. ('THI') temperature logging. 10
SCL
Readout scale:
2°C
1°C Range -50 …. 110°C (0.1°C resoluon within -9.9 to +19.9°C)
2°C Range -50 …. 110°C
°F Range -58 …. 180°F
SIM 0 … 100 Display slowdown. 5
ADR 1…255 BIT25 address for PC communicaon 1
*Dark grey highlight denotes a parameter that may not be visible unless another is set to a specic value.
For example: OS3 will not show unless DI2 = T3
9

English
Model Specic Parameter Values
Parameter Parameter Descripon Controller
Default
HR140, 150-A, 200,
360.
HR200FT & 360FT
HR140, 150-A, 200 &
360 (with Light)
LR140 & 150-A
HR100 BK, 120, 240
& HRB120
HR120 & 240
(with Lights)
HR200 & 360
(Starbucks)
LR120, 240 & LRB120
LR200 & 360
HR150
(Germany)
LR160
(One Shot)
BOA BOB BOC BOD BOE BOF BOG BOH BOK BOL
SPL Minimum limit for 'SP' seng. 1 3 3 -21 1 1 0 -21 -21 1 -30
SPH Maximum limit for 'SP' seng. 3 3 3 -21 3 3 10 -19 -19 3 -8
SP Temperature setpoint to be achieved. 2 3 3 -21 1 1 3 -21 -21 1 -15
C-H Refrigeraon/ heang control mode. REF REF REF REF REF REF REF REF REF REF REF
HYS O / On thermostat dierenal. 3 3 333333333
CRT Compressor rest me. 2 4 442242241
CT1 Thermostat run me with faulty T1 probe. 6 6 666666666 CT2 Thermostat o me with faulty T1 probe. 4 4 444444444
CSD Compressor stop delay aer door has been
opened. 1 1 111111111
DFM Defrost start mode. TIM TIM TIM NON TIM TIM TIM TIM TIM TIM TIM
DFT Time interval between defrosts. 6 6 6 6 6 6 4 6 6 6 6
DFB Defrost mer clock. YES YES YES YES YES YES YES YES YES YES YES
DLI Defrost end temperature 15 15 15 15 15 15 10 15 10 15 10
DTO Maximum defrost duraon. 20 10 10 20 10 10 20 20 10 10 10
DTY Defrost type. OFF OFF OFF OFF OFF OFF OFF ELE ELE OFF ELE
DPD Evaporator pump down. Timed pause at start
of defrost. 0 0 000000000
DPR Defrosng Pressure Reducon (used when
'DTY' = 'GAS' to over-run compressor). 3 3 333333333
DRN Drain down period. 2 3 3 2 2 2 3 2 2 3 2
DDM Defrost display mode. DEF DEF DEF DEF DEF DEF DEF DEF DEF DEF SP
DDY Defrost display delay period. 10 10 10 10 10 10 10 10 10 10 10
FID Fans in defrost. YES YES YES NO YES YES YES NO NO YES NO
FDD Evaporator fan restart temperature following
defrost. 5 5 555555550
10

English
BOA BOB BOC BOD BOE BOF BOG BOH BOK BOL
FTO Maximum evaporator fan stop period follow-
ing defrost (only when 'T2' = 'YES'). 3 3 333333333
FCM Evaporator fan mode during thermostac
control. NON NON NON NON NON NON NON NON NON NON NON
FDT Te-Ta dierence for fans to turn o aer com-
pressor stopped. -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1
FDH Temperature dierenal for evaporator fan
restart. 3 3 333333333
FDS Minimum evaporator fan stop period (follow-
ing door opening etc.) 20 20 20 20 20 20 20 20 20 20 20
FT1 Fan stop delay aer compressor stop. 15 15 15 15 15 15 15 15 15 15 15 FT2 Timed fan stop following 'FT1'. 0 0 0 0 0 0 0 0 0 0 0 FT3 Timed fan run following 'FT2'. 2 2 2 2 2 2 2 2 2 2 2
ATM Alarm threshold conguraon. REL REL REL REL REL REL REL REL REL REL REL
ALR Low temperature alarm dierenal. -5 -5 -5 -5 -5 -5 -5 -5 -5 -5 -5
AHR High temperature alarm dierenal. 5 5 555555555
ATI Alarm probe. T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1
ATD Delay before alarm temperature warning. 90 90 90 90 90 90 90 90 90 90 90
ADO Delay before door open alarm warning (only
when 'DI2' = 'DOR'). 8 8 888888888
AHM Operaon in case of high condenser alarm (if
'DI2' = 'T3' and 'T3' = 'CND' ): NON NON NON NON NON NON NON NON NON NON NON
ACC Condenser cleaning period. 0 0 0 0 0 0 0 0 0 0 0
IISM Switch over method to second parameter set. NON NON NON NON NON NON NON NON NON NON NON
SB Standby buon operaon. YES YES YES YES YES YES YES YES YES YES YES
DI1 Congurable digital input 1 operaon. NON NON NON NON NON NON NON NON NON NON NON DI2 Congurable digital input 2 operaon. NON NON NON NON NON NON NON NON NON NON NON
LSM Light control mode (if 'OA1' = 'LGT'). NON NON MAN NON NON MAN NON NON NON NON NON
OA1 Auxiliary Relay 1 Operaon. NON NON LGT NON NON LGT NON DEF DEF NON DEF OA2 Auxiliary Relay 2 Operaon. FAN FAN FAN FAN FAN FAN FAN FAN FAN FAN FAN
OS1 Air temperature probe (T1) oset. 0 0 000000000
T2 T2 probe enabling. NO NO NO NO NO NO NO YES YES NO YES
OS2 Evaporator temperature probe (T2) oset. 0 0 000000000
11

English
BOA BOB BOC BOD BOE BOF BOG BOH BOK BOL
TLD Delay for min. ('TLO') and max. ('THI') temper-
ature logging. 10 10 10 10 10 10 10 10 10 10 10
SCL Readout scale. 2°C 2°C 2°C 2°C 2°C 2°C 2°C 2°C 2°C 2°C 2°C
SIM Display slowdown. 5 5 5 5 5 5 5 5 5 5 5
ADR BIT25 address for PC communicaon. 1 1 111111111
*Yellow highlight denotes a parameter dierent to that of the default seng (Parameters sourced from BIT25B0Q3E-2FS Revision13 28.04.2014- Correct at me of print)
12

English
Wiring Diagram
13

English
Drawer Removal
This guide applies only to models that have drawers ed.
Refrigerated Drawers can be removed by pulling out to their full extent and liing so that the roller passes
through the slots in the drawer runner. Please ensure drawers are reed to their original posion.
14
Shelves, Supports & Drawer
Shelves - ‘H’ models are supplied with sloed removeable shelf supports.
The only ‘L’ models that have xed shelves that are part of the freezer system and cannot be removed are the LR150-A &
XR415L, all other ‘L’ models have removeable shelves.

Cleaning and Maintenance
Important: Before cleaning, the unit should be put into standby and then the power supply should be turned o at
the mains. Please do not plug or unplug the unit with wet hands. Only when cleaning has been completed and the
unit is dry should the cabinet be turned back on at the mains.
Suitable P.P.E (Personnel Protecve Equipment) should be worn at all mes.
Regular Maintenance:
> As and when required remove all product from the unit. Clean exterior and interior surfaces with mild liquid
detergent, following the direcons on the pack at all mes. Rinse surfaces with a damp cloth containing clean
water. Never use wire wool, scouring pads/powders or high alkaline cleaning agents i.e bleaches, acids and
chlorines as these may cause damage.
> Condenser Cleaning:
This should take place on a regular basis (4 to 6 weeks) or as and when required by a competent/trained
personnel.
Use a so brush or vacuum cleaner to remove dirt/dust. If there are any stubborn grease deposits le on or
through the condenser, call your supplier to carry out a full service (this is normally chargeable). Failure to
maintain the condenser may invalidate the warranty of the condensing unit and cause premature failure of the
motor/compressor.
Do not use a wire brush to clean the condenser. Vacuum or brush the air lter (where ed).
> All gaskets should be inspected on a regular basis and replaced if damaged. To clean, wipe with a warm damp
soapy cloth followed by a clean damp cloth and thoroughly dry.
If gasket replacement is required, start by ng all the corners of a gaskets into place before working the rest of
the length of the gasket into the retainer. Failure to follow this procedure may result in the gasket stretching and
tment not being possible.
English
15

English
Troubleshooting
Problem Possible Cause Soluon
Compressor will not start
No voltage in socket Use voltmeter to check
Electrical conductor or wires may be cut Use ohmmeter to check for
connuity
Defecve electrical component;
thermostat, relay, thermal protector
etc.
Replace defecve component
Compressor motor has a winding open
or shorted
Measure ohmic resistance of main
and auxiliary winding using
ohmmeter. Compare with correct
values
Compressor stuck Change compressor
Temperature control contacts are open Repair or replace the contacts
Incorrect wiring Check wiring diagram and correct
Fuse blown or circuit breaker tripped Replace fuse or reset circuit breaker
Power cord unplugged Plug in power cord
Controller set too high Set controller to lower temperature
Cabinet in defrost cycle Wait for defrost cycle to nish
The temperature is too cold
Controller is set at a very cold
posion
Set to warmer posion and check if
the compressor stops according to
controllers operang range
Controller does not disconnect the con-
densing unit
Check the insulaon of the
Thermostat. If problem persists,
change the thermostat
Control contacts are stuck closed Change the control. Check amperage
load
Defecve or incorrect temperature
control
Determine correct control and
replace
The temperature is not cold enough
Controller is set at a very warm
posion Adjust to colder seng
Condenser is dirty Clean condenser
The refrigerator has been placed at an
inadequate locaon
The unit must not be near stoves,
walls that are exposed to the sun, or
places that lack sucient air ow
Compressor is inecient or there is
a high pressure due to the air in the
system
If there is air in the system, purge
and recharge
Iced up evaporator coil
Check temperature control refriger-
ant charge, and defrost mechanism.
Remove all ice manually and start
over.
Restricon in system Locate exact point of restricon and
correct
Too many door openings Advise user to decrease if possible
Excessive heat load placed in cabinet Advise user not to put in products
that are too hot.
16

English
The temperature is not cold enough
(Connued)
The refrigerator has been
overcharged with the refrigerant gas
Check to see if condensaon or ice
crystals have formed on the sucon
line. If so, charge with the correct
amount of gas
The refrigerant gas is leaking
Find the locaon of gas leak in order to
seal and replace the defecve
component. Change the drier. Perform
a good vacuum and recharge unit
The evaporator and/or condenser
fans are not working
Check electrical connecons and make
sure that the fan blade isn’t stuck.
Replace the fan motor if it doesn’t
work.
Blocking air ow
Re-arrange product to allow for proper
air ow. Make sure there is at least four
inches of clearance from the
evaporator.
Fuse blown or circuit breaker tripped Replace fuse or reset circuit breaker
Electrical Shock Wires or electrical components are
in direct contact with metallic parts
Check for appropriate insulaon on the
connecons of each component
Noise
The refrigerator is not properly
levelled
Check if the noise goes away aer you
level the refrigerator
The condenser is not fastened
correctly. Copper tubing is in contact
with metal
While the compressor is working, check
to see if metal parts are in contact with
one another and/or if the screws that
fasten the condenser are ghtened
The evaporator and/or condenser
fans are loose
Check if the fans are securely
fastened. Also, check if the fan blades
are loose, broken or cracked. If so,
change the faulty blade
Compressor has an internal noise
If the noise persists aer all other
measures have been taken, it may be
originang from the compressor.
Loose part(s) Locate and ghten loose part(s)
Extreme condensaon inside the
refrigerator
Controller is set at a very cold
posion
Set the controller to a warmer
posion & check to see if compressor
stops as should
The outside environment’s relave
humidity is very high (over 75%)
This type of occurrence is caused by
local climac condions and not by the
refrigeraon unit
The refrigerator door won’t shut
completely
Check the door and/or the magnec
gasket. Adjust the door hinges if
needed; replace the gasket if broken
The refrigerator had been placed at
an inadequate locaon
The unit must not be near sources that
produce too much heat
17

English
Condensing unit runs for long peri-
ods of me
Excessive amount of warm product
placed in cabinet
Advise user to leave adequate me for
products to cool down
Prolonged door opening or door ajar
Advise user to ensure doors are closed
when not in use and to avoid opening
doors for long periods of me
Door gasket(s) not sealing properly
Ensure gaskets are snapped in
completely. Remove gasket and wash
with soap and water. Check condion of
gasket & replace if
necessary
Dirty condenser coil Clean condenser coil
Evaporator coil iced over
Unplug unit and allow coil to defrost.
Make sure thermostat is not set too
cold. Ensure that door gasket(s) are
sealing properly. Select manual
defrost and ensure system works
18

UK Head Oce
Foster Refrigerator
Oldmedow Road
Kings Lynn
Norfolk
PE30 4JU
a Division of ITW (UK) Ltd
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.fosterrefrigerator.co.uk
