Fostex PM-SUBN User manual

Active Sub Woofer
Owner’s Manual
Thank you for purchasing the Fostex PM-SUBn. The PM-SUBn is an active sub woofer
which widens and strengthens the shortage of low frequency region and volume level
reproduced by a small speaker system. It can be used for various applications such as
DTM and home theater.
