Children should be supervised to ensure that they do not
play with the appliance.

The symbol is a warning and indicates the
refrigerant and insulation blowing gas are flammable.
Warning: Risk of fire / flammable materials

940
135
607-627
1120-1140
climate class from SN to ST showed in the

to the left side,if required.
remove door shef
pressinwardly
upper hinge part by a 8mm socket wrench
and the bottom of the upper door that
shelves (to avoid damage) and then close

①
②
for washer(s) between the lower hinge
and the bottom of the lower door that
the lower hinge part by unsrewing
the special flange self-tapping screws.

11.Replace the lower hinge part to the left
12.Transfer the lower door to the property
13.Upturn the middle hinge part the
14. Transfer the upper door to the
self-tapping screws. Replace the adjustable
bottom feet parts to another side and fixing
it.
direction 180 degree, adjust its position,
change the washer on the axis to the
lower side, make the middle hinge axis
15. Transfer the upper hinge part and
16. Install the srew hole cover on the top
17. Open the upper door and install the

2.LED light
3. Wind channel cover in
refrigerator
Wind channel cover in freez
19.
Water tank
15.
Fridge door
12.
11 .Lower freezer shelf
10. Middle freezer drawer
.Freezer tray
4. Refrigerator shelf
Vegetable drawer cover
Vegetable drawer
Upper door shelf
16. Egg tray( inside)
Middle door shelf
Lower door shelf
Fridge
Freezer
er
23
23. Bottle rack

Remove and install the door shelf
Remvoe the door shelf
press inwardly
Press the right side of the door shelf
inwardly ,while holding the left side .
When the notch of the shelf has been
detachesd from the refrigerator door ,
remove the rack obliquely upwardly .
Warning:The door shelf must not removed
and installed by the user! If the door shelf
is damaged ,contact the customer helpline
for assistance .To replace the door shelf,
the below steps can be followed:
press inwa rdly
Install the door shelf
Firstly tilt the left side of the door
shelf ,and make sure the notch has
been fastened to the door .Then
press the right side inwardly ,push
it down to the right place.
Dispenser Pad
Water Dispenser
The water dispenser, located in the fridge
door, is for storing drinking water. With this
appliance you can obtain chilled water
easily without opening the refrigerator. You
should of following tips.review
water storage box
dispenser part
water storage box cover
water supply inlet cover
13
Accessories 2)
It is only applicable to
RD-33WC4SLB/CPA1-001.

Using your appliance
Before using
Before using this appliance for the first
time, you should use it
.
1. Hold the two sides of the water tank
tightly, then pull up the water tank by
shaking up and down.
2. Unscrew the head, then clean it and the
inside of water tank.
based on following
instructions
●
Assembling
Before assembling, please drain the water
1.Insert the head into the hole.
2.Fit the tank along the guides on the
door.
3.Press down on the two side of the tank.
4.When you hear a click sound, that
means the installation is completed.
●
Warning!
1.Be careful not to press on the head.
2.When fitting the water tank, ensure the
head inserted into the hole first.
①
②
dispenser part
Slot
Guide
① ②
③
④
Filling water
1. Open the water supply inlet cover from
the left side.
2.Fill the water.
Caution!
Fill with water up to 2.5L (which is
suggested), and not above the level.
Otherwise, it may overflow when the lid is
close.
Other beverage(milk,juice,carbonated
beverage etc) is not suggested to be
used than potable water .Especially
beverage including grain must not be
used (may result in failure).
Hot water can not be filled into the water
tank directly.
●
●
●
Warning!
Don't touch other parts of the appliance
when filling water, it may cause the water
leakage.
Receiving Water
You should use the correct cups to
receive water underneath the water
dispenser.
Dispenser lever
Suggested position
inside the tank.
14

Receiving tank
Warning!
Don't push the dispenser lever forward
without cup, it may cause the water leak
from the dispenser.
Cleaning
drying or using the dryer.
many times, the water in the receiving
tank may drop on the floor, which may
make your floor wet, and you should clean
the tank with dry towel regularly before
overflow.
1.Clean the tank and dry it by natural
2.If you have used the water dispenser for
15
1.Insufficient refrigeration in chamber.
set the temperature controller at “colder”.
2.Using the refrigerator in normal.
Set the temperature controller at “Mid”.
(e.g. on hot summer days) and a colder
setting can cause the compressor to run
continuously or even non-stop!
So we do not advise the user set the
temperature control knob at “ ” or colder
“cold” in normal.

Energy saving tips
We recommend that you follow the tips
below to save energy.
Try to avoid keeping the door open for
long periods.
Ensure the appliance is away from any
sources of heat (Direct sunlight,
electric oven or cooker etc).
Don't set the temperature colder than
necessary.
Don't store warm food or evaporating
liquid in the appliance.
Place the appliance in a well ventilated,
humidity free, room. Please refer to
Installing your new appliance chapter.
If the diagram shows the correct
combination for the drawers, crisper and
shelves, do not adjust the combination as
this is designed to be the most energy
efficient conflguration.
●
●
●
●
●
●
●
●
Hints for fresh food refrigeration
Do not place hot food directly into the
refrigerator or freezer, the internal
temperature will increase resulting in the
Helpful hints and tips
compressor having to work harder and will
consume more energy.
Cover or wrap food, particularly if it has a
strong flavor.
Place food carefully so that air can
circulate freely around it.
Hints for refrigeration
Meat (All Types) Wrap in polythene food:
wrap and place on the glass shelf above
the vegetable drawer. Always follow food
storage times and use by dates
suggested by manufacturers.
Cooked food, cold dishes, etc.:
They should be covered and may be
placed on any shelf.
Fruit and vegetables:
They should be stored in the special
drawer provided.
Butter and cheese:
Should be wrapped in airtight foil or
plastic film wrap.
Milk bottles:
Should have a lid and be stored in the
door racks.
●
●
●
●
●
●
●
Hints for freezing
When first starting-up or after a period out
of use, let the appliance run at least 2
hours on the higher settings before putting
food in the compartment.
Prepare food in small portions to enable it
to be rapidly and completely frozen and to
make it possible to subsequently thaw
only the quantity required.
Wrap up the food In aluminum foil or
polyethylene food wraps which are airtight.
Do not allow fresh, unfrozen food to touch
the food which is already frozen to avoid
temperature rise of the latter.
Iced products, if consumed immediately
after removal from the freezer
compartment, will probably cause frost
burns to the skin.
●
●
●
●
●
It is recommended to label and date
each frozen package in order to keep
track of the storage time.
●
Hints for the storage of frozen food
Ensure that frozen food has been stored
correctly by the food retailer.
Once defrosted, food will deteriorate
rapidly and should not be re-frozen. Do
not exceed the storage period indicated
by the food manufacturer.
●
●
Switching off your appliance
If the appliance needs to be switched off
for an extended period, the following
steps should be taken prevent mould on
the appliance.
1. Remove all food.
2. Remove the power plug from the mains
socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.
16

Cleaning and care
surface.
-Don't use Thinner, Car detergent, Clorox,
ethereal oil, abrasive cleansers or organic
solvent such as Benzene for cleaning.
They may damage the surface of the
appliance and may cause fire.
Interior cleaning
You should clean the appliance interior
regularly. Wipe the inside of the fridge
freezer with a weak solution of
bicarbonate of soda, and then rinse with
warm water using a wrung-out sponge or
cloth. Wipe completely dry before
replacing the shelves and baskets.
Thoroughly dry all surfaces and
removable parts.
Although this appliance automatically
defrosts, a layer of frost may occur on the
freezer compartment's interior frequently
or kept open too long. If the frost is too
thick, choose a time when the supply of
food stocks are low and proceed as
follows:
1.Remove existing food and accessories
baskets,
For hygienic reasons the appliance
(including exterior and interior
accessories) should be cleaned regularly
(at least every two months).
Caution!
Danger of electrical shock! Before
cleaning switch the appliance off and
remove the plug from the mains socket.
The appliance must not be
connected to the mains during cleaning as
there is a danger of electrical shock.
Exterior cleaning
-Wipe the control panel with a clean, soft
cloth.
-Spray water onto the cleaning cloth
instead of spraying directly on the surface
of the appliance. This helps ensure an
even distribution of moisture to the
surface.
-Clean the doors, handles and cabinet
surfaces with a mild detergent and then
wiped dry with a soft cloth.
Caution!
-Don't use sharp objects as they are likely
to scratch the
Replacing the LED light:
Warning: The LED light should be
replaced by a competent person! If the
LED light is damaged, contact the
customer helpline for assistance.
unplug the appliance from the mains
power and leave the doors open. Ventilate
the room thoroughly to accelerate the
thawing process.
2. When defrosting is completed, clean
your freezer as described above.
Caution! Don't use sharp objects to
remove frost from the freezer
compartment. Only after the interior is
completely dry should the appliance be
switched back on and plugged back into
the mains socket.
Door seals cleaning
Take care to keep door seals clean. Sticky
food and drinks can cause seals to stick
to the cabinet and tear when you open the
door. Wash seal with a mild detergent and
warm water. Rinse and dry it thoroughly
after cleaning.
Caution! Only after the door seals are
completely dry should the appliance be
powered on.
17
To
replace the LED light, the below steps
can be followed:
1.Unplug your appliance.
2.Remove light cover by pushing up
and out.
3.Hold the LED cover with one hand
and pull it with the other hand while
pressing the connector latch.
correctly in place.
4.Replace LED light and snap it

Troubleshooting
If you experience a problem with your appliance or are concerned that the appliance is not
functioning correctly, you can carry out some easy checks before calling for service, please
see below. You can carry out some easy checks according to this section before calling for
service.
Warning! Don't try to repair the appliance yourself. If the problem persists after you have
made the checks mentioned below, contact a qualified electrician, authorized service engineer
or the shop where you purchased the product.
Problem
Check whether the power cord is plugged into the power outlet
properly.
Check the fuse or circuit of your power supply, replace if
necessary.
The ambient temperature is too low. Try setting the chamber
temperature to a colder level to solve this problem.
The interior may need to be cleaned
Some food, containers or wrapping cause odours.
Possible cause & Solution
Appliance is not
working correctly
Odours from the
compartments
The sounds below are quite normal:
Compressor running noises.
compartment or other compartments.
Gurgling sound similar to water boiling.
Popping noise during automatic defrosting.
Clicking noise before the compressor starts.
Noise from the
appliance
Other unusual noises are due
to the reasons below and may
need you to check and take action:
The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers fallen or rolling.
The motor runs
continuously
It is normal to frequently hear the sound of the motor, it will
need to run more when in following circumstances:
Temperature setting is set colder than necessary
Large quantity of warm food has recently been stored within
the appliance.
The temperature outside the appliance is too high.
Doors are kept open too long or too often.
After your installing the appliance or it has been switched off
for a long time.
A layer of frost occurs
in the compartment
Ensure food is placed within the appliance to allow sufficient
ventilation. Ensure that door is fully closed. To remove the
frost, please refer to cleaning and care chapter.
●
●
●
●
●
●
●
●
●
18
It is normal that the freezer is not operating during the
automatic defrost cycle, or for a short time after the appliance
is switched on to protect the compressor.

A layer of frost occurs
in the compartment
Ensure food is placed within the appliance to allow sufficient
ventilation. Ensure that door is fully closed. To remove the
frost, please refer to cleaning and care chapter.
Temperature inside is
too warm
You may have left the doors open too long or too frequently; or
the doors are kept open by some obstacle; or the appliance is
located with insufficient clearance at the sides, back and top.
Temperature inside is
too cold
Increase the temperature by following the "Control panel”
chapter.
Doors cant be closed
easily
Check whether the top of the refrigerator is tilted back by
10-15mm to allow the doors to self close, or if something inside
is preventing the doors from closing.
Water drips on the floor
The water pan (located at the rear bottom of the cabinet) may
not be properly leveled, or the draining spout （located
underneath the top of the compressor depot ）
may not be
properly positioned to direct water into this pan, or the water
spout is blocked. You may need to pull the refrigerator away
from the wall to check the pan and spout.
The light is not working The light may be damaged. Refer to replace lights
in operation chapter.
Disposal of the appliance
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol ar e recyclable. Dispose of the packaging into
a suitable waste collection container to recycle it.
Before disposal of the appliance
1. Pull out the mains plug from the mains socket.
2. Cut off the power cord and discard with the mains plug
Warning! Refrigerators contain refrigerant a nd gases in the insulation. Refrigerant and
gases must be disposed of professionally as
they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal.
Correct Disposal of this product
This symbol on the product or in its packing indicates that this product may
not be treated as household waste. Instead, it should be taken to the
appropriate waste collection point for the recycling of electrical and electronic
equipment. By ensuring this product is di
sposed of correctly, you will help
prevent potential
negative consequences for the environment and human
health, which could otherwise be caus
ed by the inappropriate waste handling
of this product. For more detailed information about the recycling of this
product, please contact your local c
ouncil your household waste disposal
service, or the shop where you purchased the product.
19

20
~
~
~
