Frigidaire CFEF3012LWA User manual

All about the
Use&Care
of your
TABLE OF CONTENTS
www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352
Electric Range
new 316902305 (Dec 2009)
Important Safety Instructions ........................... 3-5
Before Setting Oven Controls .............................. 6
Before Setting Surface Controls ....................... 7-8
Setting Surface Controls (Ceramic cooktop) .... 9-11
Oven Control Functions (100)............................ 12
Setting Oven Controls ..................................12-15
Care & Cleaning ..........................................16-19
Before You Call............................................20-21
Major Appliance Warranty ................................ 22

2
ThankyouforchoosingFrigidare.
This Use & Care Guide is part of our commitment to customer
satisfaction and product quality throughout the service life of
your new appliance.We view your purchase as the beginning
of a relationship. To ensure our ability to continue serving you,
please use this page to record important product information.
©2009 Electrolux Home Products, Inc. All rights reserved. Printed in the USA
Registering your product with Frigidaire enhances our ability
to serve you. You can register online at
www.frigidaire.com or by dropping your Product
Registration Card in the mail.
PRODUCT RECORD AND REGISTRATION
Product Registration
Contents
Serial plate location
Purchase date
Model number
Serial number
Record model & serial numbers here
Need help??
Visit the Frigidaire web site at www.frigidaire.com
Before you call for service, there are a few things you can
do to help us serve your better.
Read this Use & Care manual.
It contains instructions to help you use and maintain your
range properly.
If you received a damaged range ...
immediately contact the dealer (or builder) that sold you the
range.
Save time and money.
Check the section titled “Before you call”. This section helps
step you through some common problems that might occur.
If you do need service, help is only a phone call away. Call
Frigidaire Customer Services at 1-800-944-9044.
Be sure to visit us online at
www.frigidaire.com
for a complete line of accessories.
Product Registration...................................................... 2
Important Safety Instructions ............................ 3-5
Before Setting Oven Controls .................................. 6
Removing, replacing & arranging the oven racks........... 6
Before Setting Surface Controls........................... 7-8
About the ceramic cooktop & radiant elements ............. 7
Cookware material types ............................................ 8
Setting Surface Controls .................................... 9-11
Setting single radiant surface elements........................ 9
Setting dual radiant surface elements ........................ 10
Home canning ......................................................... 11
Oven Control Functions ......................................... 12
Setting Oven Controls ...................................... 12-15
Setting the clock...................................................... 12
Changing oven temperature display (F° or C°)............ 12
Setting minute timer ................................................ 13
Setting bake ........................................................... 13
Setting broil ............................................................ 14
Adjusting oven temperature ..................................... 15
Operating oven light................................................. 15
Care & Cleaning ............................................... 16-19
Cleaning recommendation table ................................ 16
Cooktop maintenance & cleaning...........................17-18
Cautions for aluminum use ....................................... 18
Replacing the oven light ........................................... 18
Removing & replacing oven door ............................... 19
Before You Call
Solutions to common problems .............................20-21
Appliance Warranty .............................................. 22
Serial plate location:
open storage drawer (some models) or
removelowerfrontpanel(somemodels).

3
Read all instructions before using this appliance.
Do not attempt to install or operate your appliance until you
have read the safety precautions in this manual. Safety
items throughout this manual are labeled with a WARNING
or CAUTION statement based on the risk type.
WARNING indicates a potentially hazardous
situation which, if not avoided, may result in death
or serious injury.
Save these instructions for future reference.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
• Remove all tape and packaging before using the
range. Destroy the carton and plastic bags after
unpackingthe range. Neverallowchildren to playwith
packagingmaterial.
• Proper installation—Be sure your appliance is
properly installed and grounded by a qualified
technicianinaccordancewiththeNationalElectrical
CodeANSI/NFPANo.70latesteditionandlocal
electrical code requirements. Installonlyper
installationinstructionsprovidedintheliteraturepackage
for this range.
WARNING
Stepping, leaning or sitting on the door or
drawers of a range can result in serious injuries
and also cause damage to the appliance. DO NOT
allow children to climb or play around the range. The
weight of a child on an open oven door may cause the
range to tip, resulting in serious burns or other injury.
Never use your appliance for warming or heating
the room.
Do not use the oven, warmer drawer or lower
oven (if equipped) for storage.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
IMPORTANT
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
CAUTION
IMPORTANT indicates installation, operation,
maintenance or valuable information that is not hazard
related.
Definitions
Important Safety Instructions
WARNING
•All ranges can tip.
• Injury to persons could result.
• Installanti-tipdevicepacked
withrange.
• SeeInstallation Instructions.
To reduce the risk of tipping, the
range must be secured by properly
installedanti-tipbracketprovided
with the range. To check if the
bracketisinstalledproperly,visually
check that rear leveling leg is
insertedintoand fully secured by the
anti-tipbracketbyremovinglower
front panel or storage drawer from
therange.
For models equipped with a warmer drawer or lower
oven, grasp the top rear edge of the range and carefully
attempt to tilt it forward. Refer to the installation
instructionsforproperanti- tipbracket installation.
• User servicing—Do not repair or replace any part
oftheapplianceunlessspecificallyrecommendedin
the manuals. All other servicing should be done only by a
qualified technician. This may reduce the risk of personal
injury and damage to the range.
Ask your dealer to recommend a qualified technician and
an authorized repair service. Know how to disconnect the
power to the range at the circuit breaker or fuse box in
case of an emergency.
• Remove the oven door from any unused range if it
is to be stored or discarded.
•Never modify or alter the construction of a range
by removing the leveling legs, panels, wire covers,
anti-tip brackets/screws, or any other part of the
range.

4
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
• Do not store items of interest to children in the
cabinets above a range or on the backguard of
the range. Children climbing on the range to reach
items could be seriously injured.
• Do not touch surface heating units or surface
cooking elements, areas near these units or
elements, or interior surface of the oven. Both
surfaceheatingand oven heating elements may behot
even though they are dark in color. Areas near surface
cookingunits maybecome hotenoughto causeburns.
During and after use, do not touch, or let clothing or
otherflammablematerialstouch these areas until they
have had sufficient time to cool. Among these areas
are the cook top, surfaces facing the cook top, the
ovenvent openingsandsurfacesnearthese openings,
oven door and oven door window.
• Wear proper apparel—loose-fitting or hanging
garments should never be worn while using the
appliance. Donotletclothingorotherflammable
materialscontact hotsurfaces.
• Do not use water or flour on grease fires—
smother the fire with a pan lid, or use baking soda,
a dry chemical or foam-type extinguisher.
• When heating fat or grease, watch it closely. Fat
or grease may catch fire if allowed to become too hot.
• Use dry potholders - moist or damp potholders on
hot surfaces may result in burns from steam. Do
notlet potholders touchhotheating elements.Donot use
a towel or other bulky cloth instead of a potholder.
• Do not heat unopened food containers - buildup of
pressure may cause container to burst and result
ininjury.
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
• Use care when opening oven door , lower oven
door or warmer drawer (if equipped)—Stand to the
side of the range when opening the door of a hot oven.
Let hot air or steam escape before you remove or replace
foodin the oven.
• Keep oven vent ducts unobstructed. The oven vent
is located under the left rear surface element if your
model is equipped with coil elements. The oven vent is
locatedbelow the backguardformodels equippedwith
ceramic-glass cook tops. Touching the surfaces in this
area when the oven is operating may cause severe
burns. Also, do not place plastic or heat-sensitive items
on or near the oven vent. These items could melt or
ignite.
• Placement of interior oven racks. Always place oven
racks in desired location while oven is cool. If rack must
be moved while oven is hot use extreme caution. Use
potholders and grasp the rack with both hands to
reposition.Donotletpotholderscontactthehotheating
elements in the oven. Remove all utensils from the rack
beforemoving.
• Do not use the broiler pan without its insert. The
broiler pan and its insert allow dripping fat to drain and
be kept away from the high heat of the broiler. Do not
coverthebroilerinsertwithaluminum foil. Exposed
fat and grease could ignite.
• Protective liners—Donot usealuminum foil to linethe
ovenbottom. Only usealuminumfoilas recommended in
thismanual. Improper installation oftheseliners may
result in risk of electric shock, or fire.
Do not attempt to operate the range during a
power failure. If the power fails, always turn off the
range. If the range is not turned off and the power
resumes, the range will begin to operate again. Once the
power resumes, reset the clock and oven function.
IMPORTANT
• DONOTLEAVECHILDRENALONE—children
should not be left alone or unattended in the
area where appliance is in use. They should never
be allowed to sit or stand on any part of the appliance,
including the storage drawer, lower broiler drawer,
warmer drawer or lower double oven.
• Storagein or on appliance—flammable materials
should not be stored in an oven, warmer
drawer, near surface units or in the storage
drawer. This includes paper, plastic and cloth items,
such as cookbooks, plasticware and towels, as well as
flammableliquids.Donotstoreexplosives,suchas
aerosol cans, on or near the range.
WARNING

5
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT INSTRUCTIONS FOR USING
YOUR COOKTOP
• Know which knob controls each surface heating
unit. Place a pan of food on the unit before turning it on,
and turn the unit off before removing the pan.
• Use proper pan size—This appliance is equipped with
one or more surface units of different sizes. Select
utensilshavingflatbottoms largeenough tocoverthe
surface unit heating element. The use of undersized
utensils will expose a portion of the heating element to
directcontact andmay resultinignition ofclothing.
Proper relationship of utensil to element will also improve
efficiency.
• Utensil handles should be turned inward and not
extend over adjacent surface elements—To reduce
the risk of burns, ignition of flammable materials, and
spillageduetounintentionalcontactwith theutensil,the
handle of the utensil should be positioned so that it is
turnedinward,anddoesnotextendoveradjacent
surfaceunits.
• Never leave surface elements unattended at high
heat settings—Boiloverscause smokingandgreasy
spillovers that may ignite, or a pan that has boiled dry
may melt.
• Do not immerse or soak removable heating
elements—Heatingelementsshouldneverbeimmersed
inwater. Heatingelementscleanthemselvesduring
normaloperation.
•Glazed cooking utensils—Onlycertaintypesofglass,
glass/ceramic, ceramic, earthenware, or other glazed
utensils are suitable for cook top service without breaking
duetothesuddenchangeintemperature. Check the
manufacturer’srecommendationsforcooktopuse.
• When flaming foods under a ventilating hood, turn
the fan on.
IMPORTANTINSTRUCTIONS FOR CLEANING
YOUR RANGE
•Clean the range regularly to keep all parts free of
grease that could catch fire. Pay particular attention
to the area around each surface element. Do not allow
greasetoaccumulate.
• Kitchen cleaners and aerosols—Always follow the
manufacturer’srecommended directions for use.
Be aware that excess residue from cleaners and aerosols
mayignitecausingdamage andinjury.
•Cleanventilatinghoods frequently—Grease should
not be allowed to accumulate on the hood or filter.
Followthemanufacturer’sinstructionsforcleaninghoods.
FOR CERAMIC-GLASS COOK TOP MODELS
• Do not cook on broken cook top—If cook top should
break,cleaningsolutionsandspilloversmaypenetrate
the broken cook top and create a risk of electric shock.
Contactaqualifiedtechnicianimmediately.
• Clean cook top with caution—If a wet sponge or cloth
is used to wipe spills on a hot cooking area, be careful to
avoid a steam burn. Some cleaners can produce noxious
fumes if applied to a hot surface.
IMPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic Enforcement
Act requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth
defects or other reproductive harm, and requires
businesses to warn customers of potential exposure to such
substances.

6
Types of oven racks
Your range may be equipped with one or more of the oven
rackstyles shown.
BEFORE SETTING OVEN CONTROLS
Oven vent location
The oven vent is located under the left side of the
control panel (See Fig. 1). When the oven is on, warm
air passes through this vent. This venting is necessary for
proper air circulation in the oven and good baking results.
Do not block the oven vent.
Fig. 1
flat
oven rack
flat handle
oven rack
offset
oven rack
The flat oven rack or flat handle oven rack (some
models) may be used for most cooking needs.
The offset oven rack (some models) is designed to place
the base of the rack about 1/2 of a rack position lower than
normal.Thisrackdesignprovidesseveral additional
possiblelocationsbetweenthestandardpositions. Air circulation in the oven
For best baking results allow 2-4" (5-10 cm) around the
cookware for proper air circulation and be sure pans and
cookware do not touch each other, the oven door, sides or
back of the oven cavity. Hot air must be able to circulate
around the pans and cookware in the oven for even heat to
reacharoundthefood.
oven vent location
Fig. 2
Removing, replacing & arranging racks
To remove - pull the rack forward until it stops. Lift up
front of rack and slide out.
To replace - fit the rack onto the guides on the oven walls.
Tilt the front of the rack upward and slide the rack back into
place.
Arranging - always arrange the oven racks when the oven
is cool (prior to operating the oven).
Always use oven mitts when using the oven. When
using the appliance, oven racks and cooktop will become
very hot which can cause burns.
CAUTION
Recommended rack positions by food type
Food type Position
Broilingmeats See broil
Cookies, cakes, pies, biscuits & muffins 2 or 3
Frozen pies, angel food cake, yeast, bread
and casseroles 1 or 2
Small cuts of meat or poultry 1 or 2
Turkey, roast or ham 1

7
NOTES
BEFORE SETTING SURFACE CONTROLS
About the ceramic glass cooktop
The ceramic cooktop has radiant surface elements located
below the surface of the glass. The design of the ceramic
cooktop outlines the area of the surface element
underneath. Be sure to match the pan size with the
diameteroftheelementoutlineonthecooktopandonly
flat-bottomedcookwareshouldbeused.
The type and size of cookware, the number of surface
elements in use and their settings are all factors that will
affect the amount of heat that will spread to areas beyond
the surface elements. The areas surrounding the elements
may become hot enough to cause burns.
Be sure to read the detailed instructions for ceramic
glass cooktopcleaning in the Care & Cleaning and
Before You Call checklist sections of this Use & Care
Manual.
About the radiant surface elements
The element temperature rises gradually and evenly. As the
temperature rises, the element will glow red. To maintain
the selected setting the element will cycle ON and OFF. The
heatingelementretainsenoughheattoprovideauniform
andconsistentheat during the offcycle.
For efficient cooking, turn OFF the element several minutes
before cooking is complete. This will allow residual heat to
completethecookingprocess.
Radiant elements have a limiter that allows the element
to cycle ON and OFF, even at the HI setting. This helps
toprevent damage totheceramic smoothtop.Cyclingat
the HI setting is normal and will occur more often if the
cookware is too small for the radiant element or if the
cookwarebottom is not flat.
Element on & hot surface indicator lights
Yourapplianceis equipped with two different typesof
radiant surface control indicator lights that will glow on the
control panel — the on indicator and the hot surface
indicatorlights.
The element on indicator light will glow when any surface
element is turned ON. A quick glance at this indicator light
after cooking is an easy check to be sure the surface
controls are turned OFF (See Fig. 1).
The hot surface indicator light will glow when any surface
cooking area heats up and will remain on until the glass
cooktophascooled to aMODERATE level(SeeFig. 2).
hot surface indicator light
Fig. 1
Fig. 2
element ON indicator light

8
Flat bottom and straight
sides.
Tight fitting lids.
Weight of handle does
not tilt pan. Pan is well
balanced.
Pan sizes match the
amount of food to be
prepared and the size of
the surface element.
Made of a material that
conducts heat well.
Easy to clean.
Always match pot
diameter to element size.
Curved and warped pan.
Panlargerthancookingarea
markedoncooktopbymore
than one-half inch or 12mm.
Heavy handle tilts pan.
Pan is smaller or larger
than heating area marked
on cooktop.
Dual radiant
surface control
(somemodels)
Cookware material types
Thecookware material determines how evenly and quickly
heat is transferred from the surface element to the pan
bottom. The most popular materials available are:
Aluminum - Excellentheatconductor.Sometypesoffood
will cause it to darken (Anodized aluminum cookware
resists staining & pitting). If aluminum pans slide across the
ceramic cooktop, they may leave metal marks which will
resemblescratches. Remove these marksimmediately.
Copper - Excellent heatconductorbutdiscolors easily. May
leave metal marks on ceramic glass (see Aluminum).
Stainless - Slow heat conductor with uneven cooking
results. Is durable, easy to clean and resists staining.
Cast Iron - A slow heat conductor however will retain heat
verywell.Cooks evenly once cooking temperature is
reached.Notrecommendedforuse on ceramic cooktops.
Porcelain-enamel on metal - Heatingcharacteristicswill
varydependingonbase material.Porcelain-enamel coating
mustbesmoothtoavoidscratching ceramiccooktops.
Glass - Slowheatconductor.Notrecommended for
ceramic cooktop surfaces because it may scratch the glass.
Using proper cookware
The size and type of cookware used will influence the
setting needed for best cooking results. Be sure to follow
the recommendations for using proper cookware as
illustrated in Figs. 2 & 3.
Cookwareshould haveflat bottomsthatmakegoodcontact
with the entire surface heating element (See Fig. 2). Check
for flatness by rotating a ruler across the bottom of the
cookware (See Fig. 3). For more information about the
ceramiccooktop see “Cooktopcleaning& maintenance”in
theCare & Cleaning section.
Fig. 2
Fig. 1
Types of cooktop elements
The ceramic glass cooktop has radiant surface elements
located below the surface of the glass. The patterns on the
ceramic glass will outline the size and type of element
available. The single radiantelement will haveoneround
outlinepatternshown.Thedual radiant element is flexible
because you may set just the smaller inner portion as a
single element or both inner and outer portions can be set
to heat together (See Fig. 1).
Fig. 3
BEFORE SETTING SURFACE CONTROLS
Single radiant
surface control

9
SETTING SURFACE CONTROLS
Single radiant surface elements (all models)
To operate the single radiant element:
1. Place correctly sized cookware on single radiant surface
element.
2. Push in and turn the surface control knob in either
direction (Fig. 2) to the desired setting (Refer to the
Suggested radiant surface element settings
table Fig. 1). Start most cooking operations on a
higher setting and then turn to a lower setting to finish
cooking. The surface control knobs do not have to be
set exactly on a particular spot. Use the graphics
provided as a guide and adjust the control knob as
needed (See Fig. 2). Each surface element provides a
constant amount of heat at each setting. A glowing red
surfaceheatingareaextendingbeyondthebottomedge
of the cookware indicates the cookware is too small
for the surface heating area.
3. Whencookingiscomplete,turntheradiantsurface
element OFF before removing the cookware.
The on indicator light will glow when one or more
elements are turned ON. A quick glance at this indicator
light when cooking is finished is an easy check to be sure
all control knobs are turned OFF. The hot surface
indicator light will continue to glow AFTER the control
knob is turned to the “OFF” position and will glow until
theheatingsurface area has cooled sufficiently.
The suggested settings found in Fig.1 below are based
whencookingwithmedium-weightaluminumpanswith
lids. Settings may vary when using other types of pans.
Suggested radiant surface element
settings
The size and type of utensil used, and the amount and
typeof foodbeingcookedwillinfluence thesetting
neededfor best cookingresults.
NOTES
Fig. 2
Suggested settings for single and dual radiant
elements table
Settings Typeofcooking
High(HI -9) Start most foods, bring water to a
boil,panbroiling
Medium high (7 - 8) Continuearapidboil,fry,deepfatfry
Medium (5 - 6) Maintainaslowboil,thickensauces
and gravies or
steamvegetables
Medium Low (2 - 4) Keepfoodscooking,poach,stew
Low (LO - 1) Keep warm, melt, simmer
Radiant surface elements may appear to have cooled
after they have been turned off. The glass surface may
still be hot and burns may occur if the glass surface is
touchedbeforeithascooledsufficiently.
Do not place flammable items suchasplasticsaltand
pepper shakers, spoon holders or plastic wrappings on
top of the range when it is in use.These items could melt
orignite. Potholders, towels or wooden spoons could
catch fire if placed too close to the surface elements.
CAUTION
Fig. 1
IMPORTANT
Donot allowaluminumfoil, orANYmaterialthat can
melttomakecontactwiththeceramicglasscooktop.
If these items melt on the cooktop they will damage the
ceramiccooktop.

10
Radiant surface elements may appear to have cooled
after they have been turned off. The glass surface may
still be hot and burns may occur if the glass surface is
touchedbeforeithascooledsufficiently.
Do not place flammable items suchasplasticsaltand
pepper shakers, spoon holders or plastic wrappings on
top of the range when it is in use. These items could melt
orignite. Potholders, towels or wooden spoons could
catch fire if placed too close to the surface elements.
CAUTION
Heating with inner (small)
element only Heating with both elements
Fig. 1 Fig. 2
Dual radiant surface elements (some models)
Symbols on the backguard are used to indicate which coil of
the dual radiant element will heat. The symbol indicates
the inner coil only. The symbol indicates both inner and
outer coils will heat.
You may switch from either coil setting at any time during
cooking. See Suggested radiant surface element
settings table on previous page.
To operate a dual radiant element:
1. Place correctly sized cookware on dual radiant surface
element.
2. Push in and turn the surface control knob clockwise to
beginheatingboth the inner and outerportionsofthe
dualelement.Ifonly the inner heating portion is
needed like for smaller cookware, push in and turn the
knobcounter-clockwisetostart.
3. When cooking is complete, turn the dual radiant surface
element OFF before removing the cookware.
Areas that heat are shown
darkened.
Start most cooking operations on a higher setting and then
turn to a lower setting to finish cooking. The surface control
knobs do not have to be set exactly on a particular mark.
Use the marks as a guide and adjust the control knob as
needed. A glowing red surface heating area extending
beyondthe bottomedgeof thecookwareindicates the
cookware is too small for the surface heating area.
The size and type of utensil used, and the amount and
typeof foodbeingcookedwillinfluence thesetting
neededfor best cookingresults.
NOTES
IMPORTANT
Donot allowaluminumfoil, orANYmaterialthat can
melttomakecontactwiththeceramicglasscooktop.
If these items melt on the cooktop they will damage the
ceramiccooktop.
SETTING SURFACE CONTROLS
The on indicator light will glow when one or more
elements are turned ON. A quick glance at this indicator
light when cooking is finished is an easy check to be sure
all control knobs are turned OFF. The hot surface
indicator light will continue to glow AFTER the control
knob is turned to the “OFF” position and will glow until
theheatingsurface area has cooled sufficiently.

11
SETTING SURFACE CONTROLS
Home Canning
Be sure to read and observe all the following points when
home canning with your appliance. Check with the USDA
(United States Department of Agriculture) website and be
sure to read all the information they have available as well
as follow their recommendations for home canning
procedures.
Radiant surface elements may appear to have cooled
after they have been turned off. The glass surface may
still be hot and burns may occur if the glass surface is
touchedbeforeithascooledsufficiently.
Do not place flammable items suchasplasticsaltand
pepper shakers, spoon holders or plastic wrappings on
top of the range when it is in use.These items could melt
orignite. Potholders, towels or wooden spoons could
catch fire if placed too close to the surface elements.
CAUTION
• Use only quality flat bottom canners when home canning.
Use a straight-edge to check canner bottom (see
“Cookware material types” in the Before setting
surface controls section).
• Use only a completely flat bottom canner with no
ridges that radiate from the bottom center when home
canning using a ceramic cooktop.
• Make sure the diameter of the canner does not
exceed 1 inch beyond the surface element
markings or burner. It is recommended to use smaller
diameter canners on electric coil and ceramic glass
cooktops.
• Start with hot tap water to bring water to boil more
quickly.
• Use the highest heat setting when first bringing the water
to a boil. Once boiling is achieved, reduce heat to lowest
possible setting to maintain that boil.
IMPORTANT
NEVER place or straddle a cooking utensil over 2 different
surface cooking areas at the same time. This may cause
the ceramic cooktop to fracture.
IMPORTANT
Donot allowaluminumfoil, orANYmaterialthat can
melttomakecontactwiththeceramicglasscooktop.
If these items melt on the cooktop they will damage the
ceramiccooktop.

12
OVEN CONTROL FUNCTIONS
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
For satisfactory use of your oven, become familiar with the various pad features and functions of the oven as described below.
Up and down arrow
pads— Use with the
feature or function
pads to set oven
temperature or
adjusting the clock and
minute timer.
Broil pad— Use to select the
variable broil feature.
Bake pad—Use to select the
bake feature.
Feature indicator lights—
These indicator lights show if
bake or broil is active.
Clock pad— Use to
set the time of day. Clear off pad— Use to clear any feature previously entered except the time of day and
minute timer. Press clear off to stop cooking.
Timer on-off pad— Use to set or cancel the
minute timer. The minute timer does not start or
stop cooking.
Changing the temperature display mode
(°F or °C)
The electronic oven control is set to display °F (Fahrenheit)
when shipped from the factory. The display may be
changed to show either Fahrenheit or Celsius oven
temperatures.
Setting the clock
When the appliance is first plugged in or when the power
supplyto the appliancehasbeeninterrupted, the display
will flash "12:00". It is recommended to always set the
clock for the correct time of day before using the appliance.
To set the clock:
1. Press clock once (do not hold key pad down).
2. Within 5 seconds, press and hold the or until
the correct time of day appears in the display.
SETTING OVEN CONTROLS
To change the temperature display mode from °F to
°C (Celsius) or from °C to °F (Fahrenheit).
1. Press and hold broil (for 6-8 seconds) until F or C
appears in the display. At this time the display will show
the current temperature display mode whether set for F
or C. Before proceeding read the notes below.
2. Press either or key pad to toggle between F
(Fahrenheit)orC(Celsius)mode choices.
3. To accept the change, wait until the oven control
providesthe acceptance beep(SeeNotes below).
4. The display will return to the time of day with the
temperaturedisplaymodechangedthenext timethe
oven is set for bake or broil.
NOTES
•If at any time during the process of changing the
temperaturedisplay modeyoudecidenotto change
the mode, press the clear off key pad once before the
acceptancebeep.
•Thetemperature display modecannotbe changed
whenbake orbroil isactive.

13
SETTING OVEN CONTROLS
Setting the minute timer
1. Press timer on-off.
2. Press the to increase the time in one minute
increments. Press and hold the to increase the
time in 10 minute increments. The timer can be set for
any amount of time from 1 minute to 11 hours and 59
minutes.
Note: If the pad is pressed first, the timer will
advance to 11 hours and 59 minutes.
3. When the set time has run out, the timer will sound a 3
second tone . 0:00 will show in the display until timer
on-off is pressed.
To change the timer while it is in use
While the timer is active and shows in the display, press
and hold the or to increase or decrease the time
remaining.
To cancel the minute timer before the set time has
run out
Press timer on-off once .
NOTES
•The minute timer will not start or stop the cooking
process. It serves as an extra timer in the kitchen that
will beep when the set time has run out. The minute
timer can be used alone or while using any of the other
ovenfeatures.
•If another feature is active when the minute timer is
active, the minute timer will show in the display. To
view information about other active features, press the
padforthatfeature.
Setting bake
The oven can be programmed to bake at any temperature
from 170°F to 550°F (77°C to 287°C). The factory preset
baketemperatureis 350°F (177°C).
To set bake
1. Press bake. "— — —" appears in the display.
2. Within 5 seconds, press the or . The display
willshow "350°F (177°C)." Bypressingandholding
the or , the temperature can then be adjusted
in 5°F increments (1°C if the control is set to display
Celsius).
3. As soon as the or pad is released, the oven
willbegin preheating to the selectedtemperature.
When the oven reaches the desired baking
temperature, the control will beep once.
To change the oven temperature after bake has
started
1. Press bake. Visually check the bake temperature and
that it needs to be changed.
2. Press the or pad to increase or decrease the
set temperature to the desired new oven temperature.
NOTE
To cancel baking at any time, press clear off.
Dark or dull pans absorb more heat than shiny bakeware
resulting in dark or overbrowning of foods. It may be
necessary to reduce the oven temperature or cook time
to prevent overbrowning of some foods. Dark pans are
recommended for pies. Shiny pans are recommended
for cakes, cookies and muffins.
IMPORTANT

14
SETTING OVEN CONTROLS
To set Broil
1. Arrange the oven rack while oven is still cool. Position
theovenrackasneeded.
2. Press broil. " — — " will appear in display.
3. Press and hold the or until the desired broil
settinglevelappearsinthedisplay.Pressthe forHI
broil or the for LO broil. Most foods may be broiled
attheHI broil setting. Select theLO broilsettingto
avoid excess browning or drying of foods that should be
cookedtothewell-done stage.
4. For optimum results, preheat oven for 5 minutes
beforeadding food.
5. Place the insert on the broil pan (some models; Fig. 2),
then place the food on the broil pan insert.
6. Place the broiler pan and insert on the oven rack.
7. Open the oven door to the broil stop position when
broiling.
8. Broil on one side until food is browned. Turn and broil
food on 2nd side.
9. When broiling is finished press clear off.
Use the broil feature to cook meats that require direct
exposureto radiant heatforoptimum browningresults.
When broiling always remember to arrange the oven
racks while oven is still cool.
Setting broil
Insert
Broil pan
Fig. 1 Fig. 2
CAUTION
WARNING
Should an oven fire occur, close the oven door and turn
the oven OFF. If the fire continues, use a fire
extinguisher.DO NOT putwater orflouronthefire.Flour
maybeexplosive.
•The broiler pan and the insert (some models) allows
grease to drain and be kept away from the high heat of
thebroiler.DO NOT usethepanwithouttheinsert.DO
NOTcovertheinsertwithaluminum foil;theexposed
greasecouldignite.
•To insure proper results when broiling use ONLY
ElectroluxHomeProducts,Inc.approvedbroilpan&
insert.
NOTE
Always pull the oven rack out to the stop position before
turningorremovingthefood.
For medium done steaks, position the oven rack closer to
the broil element (positions 4 or 5; Fig. 1). For well-done
foods such as chicken, fish, lobster or thick cuts of meat,
positionthe oven rack further from the broil element.

15
SETTING OVEN CONTROLS
Adjusting oven temperature
Your appliance has been factory calibrated and tested to
ensure an accurate baking temperature. For the first few
uses, follow your recipe times and temperature
recommendationscarefully.Ifyouthinktheoveniscooking
too hot or too cool for your recipe times, you can adjust the
control so the oven cooks hotter or cooler than the
temperaturedisplayed.
•If at any time during the process of adjusting the oven
temperaturefeature you decide not to make the
change, press the clear off key pad once before the
acceptancebeep.
•Theoventemperatureadjustmentfeaturecannotbe
modified if bake orbroil isactive.
•The oven temperature adjustment may be made if
your oven control has been set for °C (Celsius)
temperature display mode. In this case each
press of the or key pad will adjust in 1°C
incrementsupward(maximum+18°C)ordownward
(maximum-18°C),dependingon which arrow key pad
is pressed.
• DO NOT USE oventhermometerssuchasthosefound
ingrocery stores to check the temperature settings
insideyouroven.Theseoventhermometers may vary
as much as 20 to 40 degrees from actual
temperatures.
NOTES
To adjust oven temperature
1. Press & hold the bake key pad and release after the
display shows the factory temperature setting of 00. If
theoventemperature hasbeenpreviouslyadjusted
from the factory setting, the latest adjusted value will
appearin the display instead.
2. You may increase the oven temperature in 5°F
increments with each press of the key pad. You
may also adjust the oven temperature downward in 5°F
increments with each press of the key pad (total
adjustment range is +35°F to -35° F).
3. To accept the change, wait until the oven control
providesthe acceptance beep(See Notes).
4. Theoven temperatureadjustmenthas beenaccepted
by the oven control and the display will return to the
time of day.
Operating oven light (some models)
Theinterior oven light will automatically turn ON whenthe
oven door is opened. Press the oven light switch located on
the upper left control panel to turn the interior oven light ON
and OFF whenever the oven door is closed.
The interior oven light is located at the upper left rear wall
of the oven interior. To change the interior oven light, see
"Changingthe oven light"inthe Care & cleaning section.
Circuit protection (some models)
For protection against surcharge, a 15 amp, 120 volt circuit
breaker reset is provided near the electric outlet located on
top of backguard panel (See Fig. 1). If needed, press circuit
breaker switch to reset.
backguard
panel
electric
outlet
oven
light
switch
circuit
breaker
switch
Fig. 1

16
CARE & CLEANING
•Ceramiccooktop
•Controlpanel
•Decorative trim (somemodels)
Surface type Recommendation
•Oven interior & door liner
•Porcelainenamelbroilerpanand
broilerpaninsert(somemodels)
For general cleaning , use hot, soapy water and a cloth. For more difficult soils and
built-up grease , apply a liquid detergent directly onto the soil. Leave on soil for 30 to
60 minutes. Rinse with a damp cloth and dry. Do not use abrasive cleaners on any
of these materials; they can scratch. To remove control knobs, turn to the OFF
position; grasp firmly and pull straight off the shaft. To replace knobs after cleaning,
line up the flat sides of both the knob and the shaft; then push the knob into place.
Before cleaning the control panel, turn all controls OFF and if needed remove any
knobs from the panel. Clean using hot, soapy water and a dishcloth. Be sure to
squeeze excess water from the dishcloth before wiping the control panel;
especially when wiping around the controls area. Excess water in or around the
controls may cause damage to the appliance. When rinsing, use clean water and a
dishcloth and be sure to squeeze excess water from dishcloth before wiping the
controlpanel.
•Controlknobs
•Painted body parts
•Painteddecorativetrim
•Aluminum,plastic or vinyl trim
pieces
Gentle scouring with a soapy non-abrasive scouring pad will remove most spots.
Rinse with a 1:1 solution of clear water and ammonia. If necessary , cover difficult
spots with an ammonia-soaked paper towel for 30 to 40 minutes. Rinse with clean
water and a damp cloth, and then scrub with a soap-filled non-abrasive scouring pad.
Rinse and wipe dry with a clean cloth. Do not allow food spills with a high sugar or
acid content (milk, tomatoes, sauerkraut, fruit juices or pie filling) to remain on the
surface; they may cause a dull spot even after cleaning.
The oven interior is porcelain coated and is safe to clean using oven cleaners
followingmanufacturer's instructions. Aftercleaning,remove anyovencleaner or the
porcelainmaybecomedamagedduringfutureheating.Do not spray oven cleaneron
any electrical controls or switches. Do not spray or allow oven cleaner to build up on
the oven temperature sensing bulb. Do not spray cleaner on oven door trim, door
gasket, plastic drawer glides, handles or any exterior surfaces of the range.
Clean any soils from the oven frame, the door liner outside the oven door gasket and
the small area at the front center of the oven bottom. Clean with hot, soapy water.
Rinse using clean water and a cloth.
•Stainless Steel (some models)
•Oven racks
•Oven door
Remove oven racks from oven before cleaning. Clean by using a mild, abrasive
cleaner following manufacturer's instructions. Rinse with clean water and dry.
Use soap & water to thoroughly clean the top, sides and front of the oven door. Rinse
well. You may use a glass cleaner on the outside glass of the oven door. Do not
immerse the door in water. Do not spray or allow water or the glass cleaner
to enter the door vents. Do not use oven cleaners, cleaning powders or any
harsh abrasive cleaning materials on the outside of the oven door.
Cleaning recommendation table
Clean heavier soils with hot, soapy water and a dishcloth. Rinse with clean water and
a cloth. Do not use cleaners with high concentrations of chlorides or
chlorine. Do not use harsh scrubbing cleaners. Only use kitchen cleaners that are
especially made for cleaning stainless steel. Always be sure to wipe the cleaners off
from the surface as bluish stains may occur during heating that cannot be removed.
Do not use spray oven cleaners on the cooktop. See cooktop cleaning and
maintenanceintheCare & Cleaning section.

17
Consistent and proper cleaning is essential to
maintainingyourceramic glass cooktop.
Do not:
• Slide anything metal or glass across the cooktop.
• Use cookware with dirt or dirt build up on bottom;
replace with clean cookware before using.
• Use your cooktop as a cutting board or work surface in
thekitchen.
• Cookfoodsdirectlyonthe cooktop surface without a pan.
• Drop heavy or hard objects on the ceramic glass cooktop,
they may cause it to crack.
For light to moderate soil:
Apply a few drops of glass-ceramic cooktop cleaner directly
to the cooktop. Use a paper towel or use a non-abrasive
plastic type no-scratch cleaning pad to clean the entire
cooktopsurface.Makesurethecooktopiscleaned
thoroughly,leavingnoresidue.
For heavy, burned on soil:
Apply a few drops of glass-ceramic cooktop cleaner directly
to the soiled area. Rub the soiled area using a non-abrasive
plastictypeno-scratchcleaning pad, applying pressure as
needed. Do not use the pad you use to clean the cooktop
forany otherpurpose.
If soils remain, carefully scrape soils with a metal razor
blade scraper, holding scraper at a 30 degree angle to the
surface.Removeloosenedsoilswithcooktopcleaning
cream and buff surface clean.
Prior to using your cooktop for the first time, apply some of
the glass-ceramic cooktop cleaner supplied with your new
appliance.Buff with anon-abrasive clothor no-scratch
cleaning pad. This will make cleaning easier when soiled
from cooking. The special cooktop cleaning cream leaves a
protective finish on the glass to help prevent scratches and
abrasions.
Sliding aluminum or copper clad bottom pans on the
cooktopcancausemetalmarkingson the cooktop surface.
Thesemarksshouldberemovedimmediately afterthe
cooktophas cooled usingthecooktop cleaningcream.Metal
marks can become permanent if not removed prior to
futureuse.
Cookware (cast iron, metal, ceramic or glass) with rough or
dirtybottomscanmark or scratch the cooktop surface.
Before cleaning the cooktop, be sure the controls are
turnedtoOFFandthecooktopisCOOL.
Cooktop maintenance Cooktop cleaning
IMPORTANT
CAUTION
CARE & CLEANING

18
CARE & CLEANING
Plastic or foods with a high sugar content:
These types of soils need be removed immediately if spilled
ormeltedonto the ceramic cooktop surface. Permanent
damage (such as pitting of the cooktop surface) may occur
ifnotremovedimmediately.
After turning the surface elements OFF, use a razor blade
scraper or a metal spatula with a mitt and scrape the soil
from the hot surface (as illustrated). Allow the cooktop to
cool, and use the same method for heavy or burned on
soils.
Damage to the ceramic glass cooktop may occur if you
use an abrasive type cleaning pad. Only use cleaning
productsthathavebeen specifically designed for ceramic
glasscooktops.
Caution for aluminum use on the cooktop
•Aluminum Foil - Useofaluminumfoilonahotcooktop
will damage the ceramic cooktop. Do not use thin
aluminumcooking utensils orallowaluminumfoil to
touchtheceramiccooktopunderANYcircumstances.
•Aluminum utensils - Themeltingpointofaluminum
is much lower than that of other metals. Care must be
taken when aluminum pots or pans are used on the
cooktop. If aluminum pans are allowed to boil dry
when using the cooktop, not only will the utensil be
damaged or destroyed, but it may fuse to, break or
mark the ceramic glass surface, permanently
damagingthecooktopsurface.
Do not use the following on the cooktop:
• Do not use abrasive cleaners and scouring pads, such as
metal and some nylon pads. They may scratch the
cooktop,making itmoredifficult toclean.
• Do not use harsh cleaners, such as chlorine bleach,
ammonia or oven cleaners, as they may etch or discolor
thecooktop.
• Do not use dirty sponges, cloths or paper towels, as they
can leave soil or lint on the cooktop which can burn and
causediscoloration.
B
L
E
A
C
H
A
B
R
A
S
I
V
E
C
L
E
A
N
E
R
S
A
M
M
O
N
I
A
Cooktop cleaning (cont’d)
IMPORTANT
DO NOT use a cooktop cleaner on a hot cooktop.
The fumes can be hazardous to your health and
can chemically damage the ceramic glass surface.
WARNING
Replacing oven light
The interior oven light bulb is located at the upper left rear of
the oven cavity.
To replace the oven light bulb
1. Turn electrical power off at the main source or unplug
the range.
2. Replace bulb with a new 40 watt appliance bulb.
3. Turn power back on again at the main source (or plug
the appliance back in).
4. The clock will then need to be reset. To reset, see
“Setting the clock” in this Use & Care Guide.
BesuretherangeisunpluggedandallpartsareCOOLbefore
replacing ovenlight.Wearaleather-facedgloveforprotection
againstpossible brokenglass.
CAUTION

19
CARE & CLEANING
For models that have a visible lower bake element
ONLY - This bake element was designed to be tilted up
using your hand from the front of the bake element for
cleaningpurposes. Removethe bottom oven rack before
raising the element. Do not to raise the element more than
4 or 5 inches from the resting position.
Theovendoorisheavy.Forsafe,temporarystorage,laythe
oven door flat with the inside of the door facing down.
Removing and replacing the lift-off oven door
CAUTION
To remove oven door
1. Open oven door completely (horizontal with floor-Fig. 1).
2. Remove 2 screws located on the inside of the oven door
liner (See AFig. 2).
3. Insert the 2 screws into the door hinge holes located on
the side of the hinge arm, one into each hinge (See B
Fig. 2).
4. Close oven door until the door stops, (do not force the
door to close any further). The placement of these
screws should keep door open in about a 45 degree
position.
5. Grasp oven door firmly on both sides and slide door up
and off hinges at the same angle (See Fig. 3).
6. To clean oven door, follow the instructions provided
listed in the cleaning chart under “oven door”.
To replace oven door
1. Be sure the hinge arms remain at the 45 degree angle
position. Be sure the screws are still locking the hinge
arms from moving. If the screws fall out of the hinge
holes, the hinge(s) may snap back against the oven frame
and could pinch fingers or chip the porcelain finish on the
oven front frame.
2. Hold door at the sides near the top while resting the
lower front of door on your knee. Insert the door
channels at the bottom of door over the door hinges,
(See Fig. 3).
3. Allow the door to slide down into the door hinges evenly
at the same 45 degree angle. The hinge arms should be
inserted into the bottom corners as far as they can go.
4. Open door completely (horizontal with floor) and remove
both screws from holes in door hinges.
5. Reinstall the 2 screws into the door liner (See CFig. 2).
6. If the door is not in alignment with the oven frame,
remove door and repeat the above steps.
Special door care instructions - Most oven doors
contain glass that can break. Read the following
recommendations:
•Do not close the oven door until all the oven racks are fully
in place.
•Do not hit the glass with pots, pans, or any other object.
•Scratching, hitting, jarring or stressing the glass may
weaken its structure causing an increased risk of breakage
at a later time.
Fig. 1
Fig. 2
Oven door hinge
locations
with oven door
fully open.
Fig. 3
Cleaning under lower element (some models)
CAUTION
The oven bake and broil elements may appear to have
cooled afterthey havebeen turned OFF. The elements
may still be hot and burns may occur if these elements
aretouchedbeforetheyhavecooledsufficiently.

20
BEFORE YOU CALL • Solutions to common problems
Surface element does not heat.
Entireappliance doesnot operate. • The time of day is not set. The time of day must first be set in order to
operate the oven. See Setting the clock in the Setting Oven Controls
section.
• Makesure cord/plugis pluggedcorrectlyintooutlet.
• Service wiring is not complete. Contact your dealer, installing agent or
authorizedserviceagent.
• Electrical power outage. Check house lights to be sure. Call your local
electric company for service.
• Be sure the oven controls are set properly for the desired cooking feature.
See Setting Oven Controls in this manual or read the instructions “Entire
appliancedoesnot operate” in thischecklist.
Ovenlightdoes not work.
• Lightweightorwarpedpansused.Use only flat, evenly balanced, medium
or heavyweight cookware. Flat pans heat better than warped pans.
Cookware materials and weight of the material affect heating. Heavy &
medium-weightpansheatevenly.Becauselightweightpansheatunevenly,
foodsmay burneasily.
Cannotmoveapplianceeasily.Appliance
must be accessible for service. • Cabinets not square or are built in too tightly. Contact builder or installer to
makeappliance accessible.
• Carpetinterfereswithappliance.Providesufficientspacesoappliancecanbe
liftedovercarpet.
Surface element too hot or not hot
enough. • Incorrectcontrolsetting.BesurethecorrectcontrolisONfortheelementthat youare attempting to use.
Problem Solution
Applianceis not level. • Be sure floor is level, strong & stable enough to adequately support range.
• If floor is sagging or sloping, contact a carpenter to correct the situation.
• Poor installation. Place oven rack in center of oven. Place a level on the
oven rack. Adjust leveling legs at base of appliance until the rack is level.
• Kitchencabinetalignment may make range appear not level. Be sure
cabinets are square & have sufficient room for appliance clearance.
• Besurethelightissecureinthesocket.AlsoseeChanging&replacingthe
oven light section.
Poorbakingresults. • Many factors affect baking results. Make sure the proper oven rack position
is used. Center food in the oven and space pans to allow air to circulate.
Allow the oven to preheat to the set temperature before placing food in the
oven. Try adjusting the recipe's recommended temperature or baking time.
If you feel the oven is too hot or cool, see Adjusting oven temperature
section in this Use & Care Guide.
Oven portion of appliance does not
operate.
