Bartscher 6K-EBMF User manual

6K-EBMF
286426

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Technical Support Hotline: [phone]
www.bartscher.com
Version: 1.0
Date of preparation: 2022-10-19
EN
2

286426 1 / 48
Original instruction manual
1Safety............................................................................................................2
1.1 Explanation of Signal Words....................................................................2
1.2 Safety instructions....................................................................................3
1.3 Intended Use ...........................................................................................7
1.4 Unintended Use.......................................................................................7
2General information.......................................................................................8
2.1 Liability and Warranty ..............................................................................8
2.2 Copyright Protection ................................................................................8
2.3 Declaration of Conformity ........................................................................8
3Transport, Packaging and Storage................................................................9
3.1 Delivery Check.........................................................................................9
3.2 Packaging................................................................................................9
3.3 Storage....................................................................................................9
4Technical Data.............................................................................................10
4.1 Technical Specifications ........................................................................10
4.2 List of Components of the Appliance .....................................................12
4.3 Functions of the Appliance.....................................................................14
5Installation Instructions................................................................................15
5.1 Installation..............................................................................................15
5.2 Electrical Connection.............................................................................17
6Operating Instruction...................................................................................18
6.1 Using the Induction Plate.......................................................................18
6.2 Induction Plate Operation ......................................................................23
6.3 Using Multi-Functional Oven..................................................................28
6.4 Operating Multi-Functional Oven ...........................................................30
7Cleaning ......................................................................................................40
7.1 Safety Instructions for Cleaning.............................................................40
7.2 Cleaning.................................................................................................41
8Possible Malfunctions..................................................................................46
9Disposal....................................................................................................... 48

Safety
2 / 48 286426
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des Geräts u ndg ilt als wichtige Infor mationsquelle un dN achschlagewer k.Di e Kenntnis aller enthalt enenSic herheitshinw eiseu ndH andlungs anweisungen schafft die V oraussetzung für d as sichere und sac hgerechte Arbeite n mitd emG erät.D arüber hin aus müssen die für den Eins atzbereich des Geräts gelt enden örtlichen Un fallverhütungsvorsc hriften und allgemein en Sicherheitsb estimmungen eingehalt en werden. Diese Bedi enungsanleitung ist Bestandt eild es Produkts und muss i n unmittelbarer Nähe d es Geräts für das In¬stall ations-, Bedienungs- , Wartungs- und Reinigu ngspersonal jederzeit z ugänglich auf¬b ewahrt werden. Wenn das Ger ät an eine dritte Person
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.

Safety
286426 3 / 48
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
1.2 Safety instructions
Electrical Current
•Too high a mains voltage or incorrect installation may cause electric shock.
•The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
•To avoid short-circuit, the appliance should be kept dry.
•If there are malfunctions during operation, disconnect the appliance from the
power supply.
•Do not touch the appliance’s plug with wet hands.
•Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
•Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
•Do not transport the appliance, holding it by the power cord.
•Do not allow the power cord to come into contact with heat sources or sharp
edges.
•Do not bend, pinch nor knot the power cord.

Safety
4 / 48 286426
EN
•Always completely unwind the power cord.
•Never place the appliance or other objects on the power cord.
•Always take hold of the plug to disconnect the appliance from the power supply.
•Check the power cord regularly for damage. Do not use the appliance if the
power cord is damaged. If this cable is damaged, it must be replaced by
customer service or a qualified electrician in order to avoid dangers.
Flammable Materials
•Never subject the appliance to contact with high temperature sources, e.g.:
oven, furnace, open flame, heat generating devices, etc.
•To avoid fire hazard, clean the appliance regularly.
•Do not cover the appliance with, e.g., aluminium foil or cloths.
•Use the appliance only with materials designated to this end and with correct
temperature settings. Materials, groceries and left-overs remaining in the
appliance may catch fire.
•Never use the appliance near flammable or inflammable materials, e.g.: petrol,
spirit, alcohol, etc. High temperature triggers evaporation of these materials,
and, as a result of contact with sources of ignition, an explosion may occur.
•In case of fire, disconnect the appliance from the power supply before
attempting suitable fire-extinguishing actions.
•Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.
Safety of Induction Plate Operation
•During operation, the heating area is getting very hot.
Information: Induction cooker does not generate heat in the process of
cooking. Nevertheless, the temperature of cookware heats up the heating
area and the surface remains hot after use. Do not touch any hot surfaces
of the appliance.
•You may transport and clean the appliance after it cools down entirely.
•It is prohibited to sprinkle hot surfaces with cold water or flammable liquids.
•Do not put metal kitchen utensils, lids, knifes nor any other metal objects on the
heating area. These objects might heat up after switching the appliance on.
•Remember that wearable items, e.g. rings, watches etc., may heat up when they
are close to the cooker’s plate.
•In order to avoid overheating, do not place any aluminium foil or metal plates on
the heating surface of the appliance.

Safety
286426 5 / 48
EN
•Do not heat up sealed containers, e.g. canned food, on the heating area of the
induction cooker. Resulting overpressure may cause explosion (rupture) of a
container or a can. The canned food is best to open it, put it in a pot filled with
water and place the pot on a heating area in order to heat it up.
•The heating area is made of a temperature-resistant glass. In case of damage,
even if it is only a small fracture, the device should be immediately disconnected
from the power supply and you should contact the service company.
Electromagnetic Fields
•Magnetized items, e.g. credit cards, data storage devices or calculators, may
not be placed in an immediate vicinity of the switched on appliance. Magnetic
field might damage them.
•Do not open the bottom cover!
•Cookware should always be placed in the middle of the cooking area, so that
pot bottom covered the electromagnetic field to the maximum extent.
•Scientific researches proved that induction cookers pose no threat.
Nevertheless, people with cardiac pacemaker should keep a distance of at least
60 cm from the working appliance.

Safety
6 / 48 286426
EN
Supervised Usage only
•Only supervised appliance may be used.
•Always remain in an immediate vicinity of the appliance.
Halten Sie Verpacku ngsmaterialien und St yroporteile von Kindern f ern.Si e können sich darin verfangen und erstic ken.
Operating personnel
•The appliance can be used by children of 8 years old and older, as well as by
people with reduced physical, sensory or mental abilities and those with limited
experience/knowledge as long as they are under supervision or have been
instructed on safe use of the appliance and possible risks.
•Keep children under 8 years of age away from the appliance and the power cord
unless they are under constant supervision.
Improper Use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used when its technical condition is flawless and
allows for safe operation.
•The appliance may only be used when all connections are executed according
to rules of law in force.
•The appliance may only be used when it is clean.
•Use only original spare parts. Never attempt to repair the appliance on your own.
•Do not introduce any changes in the appliance nor modify it.
•Pots or pans should always be lifted from the induction hob and not moved over,
as otherwise their bottom might scratch the glass.

Safety
286426 7 / 48
EN
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–Preparing and heating-up foods with the use of suitable cookware.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
–Heating of rooms.
–Heating-up flammable, hazardous to health and volatile, etc. liquids and
materials.

General information
8 / 48 286426
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, Packaging and Storage
286426 9 / 48
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.

Technical Data
10 / 48 286426
EN
4 Technical Data
4.1 Technical Specifications
Name:
Induction stove 6K-EBMF
Art. No.:
286426
Material:
steel
Heating plate material:
glass
Number of hobs:
6
Distribution of hobs:
6 x 3 kW
Size of hobs, in mm:
225 x 225
Glass hob dimensions (W x D), in mm:
880 x 520
Oven's thermal processing chamber
material:
enamelled
Temperature range, min.–max., in °C:
50 - 250
Timer setting, from–to, in min.:
5 - 55
Oven dimensions (W x D x H), in mm:
665 x 400 x 340
Oven volume, in litres:
87
Number of guide rail pairs:
4
Distance between guide rail pairs, in
mm:
60
Oven connected load, in kW:
2,45
Connected load:
10.5 kW | 400 V | 50/60 Hz
Dimensions (W x D x H), in mm:
900 x 600 x 940
Weight, in kg:
99,6
We reserve the right to implement technical modifications.

Technical Data
286426 11 / 48
EN
Version / Characteristics
•Appliance type: standing appliance
•Equipment connection: 3 NAC
•Operating mode: electric
•Hob type: induction
•Oven type: electric
•Multi-functional oven
•Functions:
–defrosting
–double grilling
–ECO
–grill + fan
–multi-functionality (circulating air + fan)
–cleaning
–static + fan
–bottom heating element + grill + fan
–pre-hating
•Oven characteristics:
–triple glazing
–oven lighting
–timer (5–55 min.)
•Fume extractor
•Height-adjustable feet
•Height adjustment: 900 x 940 mm
•The set includes:
–1 baking sheet
–1 grate

Technical Data
12 / 48 286426
EN
4.2 List of Components of the Appliance
Fig. 1
1. Induction plate
2. Control panel
3. Appliance door with handle
4. Storage compartment
5. Height-adjustable feet (4 pcs)
6. Guide rails
7. Grate
8. Fan
9. Internal LED lighting

Technical Data
286426 13 / 48
EN
Induction Plate / Hobs Distribution
Fig. 2
1. Rear left hob
2. Rear centre hob
3. Rear right hob
4. Front left hob
5. Front centre hob
6. Front right hob
7. Induction plate digital display

Technical Data
14 / 48 286426
EN
Control Elements / Indicator Lights
1. Oven and thermostat indicator lights
2. Oven functional controller
3. Oven temperature controller
4. Rear left hob dial knob
5. Front left hob dial knob
6. Rear centre hob dial knob
7. Front centre hob dial knob
8. Front right hob dial knob
Fig. 3
9. Rear right hob dial knob
10.Digital timer
10a '-' key
10b 'Menu' key
10c '+' key
10d Timer digital display
4.3 Functions of the Appliance
The induction cooker is intended for preparation and heating up of foods using
appropriate cookware.
6 hobs and a large, multi-functional electric oven offer more than just a large area
for preparing delicious dishes. Additionally, the versatility of the multi-functional
oven delights when selecting the perfect thermal processing program.

Installation Instructions
286426 15 / 48
EN
5 Installation Instructions
5.1 Installation
CAUTION!
Incorrect installation, positioning, operation, maintenance or misuse of
the appliance may lead to personal injury or property damage.
Positioning and installation, as well as repairs may be performed by
authorised technical service only and in compliance with the applicable
national law.
NOTE!
The manufacturer disclaims all liability and provides no warranty for
damages, which may be attributed to non-observance of regulations or
incorrect installation.
Unpacking / Positioning
ATTENTION!
Due to high weight of the appliance it should be transported, unpacked,
and installed by two persons.
•Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
CAUTION!
Choking hazard!
Prevent children from accessing packaging materials, for instance: plastic
bags and EPS elements.
•Be careful not to damage the rating plate and warning labels affixed to the
appliance.
•Never place the appliance in humid or wet environment.
•Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
•The appliance should be placed on a surface that is:

Installation Instructions
16 / 48 286426
EN
–even, with sufficient load-bearing capacity, resistant to water, dry and
resistant to high temperatures;
–sufficiently large, and thus enabling usage of the appliance with no
problems;
–easily accessible;
–well ventilated.
•To install the appliance, perform the following steps:
–Remove the packaging of the appliance, except for the pallet.
–Lift the appliance with the lift truck and move it to the planned installation
location. Be careful not to damage the appliance. Control the stability in
order not to lose the balance of the appliance.
–Do not drag nor push the appliance, as it may fall down. This may also
cause the damage to external elements or feet.
–As soon as the appliance is in the planned installation location, remove
the pallet.
–Level the appliance by screwing in or out the feet.
–Remove the protective film from the appliance at the end.
Minimum Clearances
Fig. 4
•If the appliance is standing next to a tall cabinet or wall made of combustible
material, maintain a clearance of at least 50 mm between the appliance and the
cabinet/wall.

Installation Instructions
286426 17 / 48
EN
•Maintain a minimum clearance of 650 mm between the hob and any fume
extractor fitted above it.
•If the appliance is permanently installed between two kitchen cabinets, the lining
of the pieces of furniture must be capable of withstanding a temperature of at
least 90°C.
5.2 Electrical Connection
Connection —Electrical Power
•Verify if the technical specification of the appliance (see the rating plate)
correspond to the local electricity grid.
•Electrical connection of the appliance to mains power supply must be executed
by a qualified electrician, according to international, national and local
regulations in force.
•The induction cooker is equipped with power cord. It must be connected with a
plug or directly into a suitable mains wall socket.
•The wall socket and plug must be accessible at all times.
•The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
•Ensure that the connection cable does not come into contact with oven
components that may become hot.
•If a permanent connection is to be executed, ensure that a multi-pole switch with
a gap between contacts of at least 3 mm is installed in the supply line.
•The appliance must not be connected to the mains using a splitter plug or
extension cord. If this is the case, safe use of the appliance cannot be
guaranteed.
•Do not use the appliance with an external timer or remote control.

Operating Instruction
18 / 48 286426
EN
6 Operating Instruction
Before Use
1. Remove all accessories from the oven.
2. Before use, clean the appliance observing instructions in section 6 'Cleaning'.
3. Prior to first use, heat the appliance up with no foods inside for an hour at the
highest temperature, with top and bottom heating element function on,
observing indications in section 'Settings'.
4. Prior to first use, and observing instructions in section 'Settings', heat up the
oven without food to eliminate any unpleasant odours that come from the
thermal insulation. Select the highest temperature and the longest time.
During this process, a protective lubricant used in the manufacturing process should
be removed.
A small amount of smoke or unpleasant odour may be produced. This is normal
during first use and should not recur.
If needed, switch the kitchen hood extractor or ventilate the room.
5. After heating up, open the oven door so that the remaining smoke may escape.
6. When the oven has cooled down, clean the oven with warm water and a soft
cloth or sponge.
7. Dry the appliance thoroughly.
6.1 Using the Induction Plate
Method of operation of heating plates
In induction cookers the electric voltage is applied to a conductive coil under the
glass. This generates magnetic field, which being a physical effect, heats the
bottom of a cookware directly.
This translates to savings of time and energy, as —contradictory to traditional
heating areas —there is no heating up of a heater and then of the glass heating
plate.
Another advantage of the technical features described above is the very short
cooking time.
Additionally, inflow of heat changes instantly with every change of settings and it
may be controlled precisely. The induction heating plate reacts to changes in
settings as fast a gas cooker, for the energy is delivered immediately to a pot,
without the need to prior heating up of other materials.
The induction technology combines the speed of reaction with a basic benefit of the
current, making it possible to precisely control heat inflow.
