Frigidaire MRS20WRGW User manual

P/N 218844800B (9809)
READ AND SAVE THESE INSTRUCTIONS

2
Product Registration ThisOwner's Guide will instruct you on how to properly operate and care for your
product. In addition, please read through the information contained in your
literaturepackto learn more about your new appliance.
Record Your Model and Serial Numbers
RecordtheModelNo.andSerialNo.ofthisrefrigeratorinthespaceprovidedbelow.
Thesenumbersarefoundontheserialplatelocatedontheceilingoftherefrigerator
compartment.
Model No. __________________________________________________
Serial No. ___________________________________________________
Register Your Product
The self-addressed PRODUCT REGISTRATION CARD (shown left) should be filled in
completely, signed and returned to Frigidaire, or in Canada, WCI Canada Inc.
2 Product Registration
2 Versión en español
3 Important Safety Instructions
3 ForYour Safety
3 ChildSafety
3 ElectricalInformation
3 OtherPrecautions
4 FirstSteps
4 Location
4 Installation
4 Door Opening
4 Leveling
4 Cleaning
5 Energy Saving Ideas
5 Setting the Controls
5 Cool Down Period
5 RefrigeratorControl
5 FreezerControl
6 Fresh Food Storage
7-8 Automatic Ice and Water Dispenser
9-10 Care and Cleaning
9 Inside
9 Outside
9 Replacingthe Light Bulb
10 Vacation and Moving Tips
11 Removing Handles and Doors
12-14 Avoid Service Checklist
14 Normal Operating Sounds
15 Warranty in the United States
16 Service Information in Canada
17 Warranty in Canada
Versión en español
Si desea obtener una copia en español de
esteManualdelUsuario,sírvaseescribira
ladirecciónqueseincluyeacontinuación.
SolicitelaP/N218815400.
Spanish Owner's Guides
FrigidaireHomeProducts
P.O. Box 212378
Augusta, GA 30917
Contents
© 1998WhiteConsolidatedIndustries,Inc.
Allrightsreserved.
ThisOwner'sGuide providesspecific
operatinginstructions foryourmodel.
Usetherefrigeratoronlyasinstructed
inthisOwner'sGuide.

3
Important Safety
Instructions Readallinstructionsbeforeusingthisrefrigerator.
For Your Safety
Donotstore, or use gasoline orotherflammablevaporsandliquids in the vicinity
ofthisoranyotherappliance.Readproductlabelsforflammabilityandotherwarnings.
• Destroycarton, plastic bags, and anyexterior wrapping material immediately
afterrefrigeratoris unpacked.Childrenshouldnever usetheseitemsfor play.
Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may
becomeairtight chambers, and canquickly cause suffocation.
• Remove all staples from carton. Staples can cause severe cuts, and destroy
finishesifthey come incontactwithotherappliances or furniture.
• An empty, discarded ice box, refrigerator, or freezer is a very dangerous
attraction to children. Remove door of any appliance that is not in use,
even if it is being discarded.
•Refrigerator must be plugged into its own 115 Volt, 60 Hz, AC only
electricaloutlet. The power cord of the appliance is equipped with a three-
prong grounding plug for your protection against shock hazards. It must be
plugged directly into a properly grounded three-prong receptacle. The
receptacle must be installed in accordance with local codes and ordinances.
Consult a qualified electrician. DO NOT USE AN EXTENSION CORD OR ADAPTER
PLUG.
• If voltage variesby 10 percent or more, performanceof your refrigerator may
be affected. Operating refrigerator with insufficient power can damage
compressor. Such damage is not covered under your warranty. If you suspect
your voltage is high or low, consult your power company for testing.
• Topreventrefrigeratorfrom beingturnedoffaccidentally,donotplugunitinto
anoutletcontrolled by a wallswitchorpullcord.
• Do not pinch, knot, or bend power cord in any manner.
• Neverunplug refrigeratorbypullingon powercord.Always gripplugfirmly,and
pullstraightoutfromreceptacle.
• Toavoidelectricalshock,unplugrefrigeratorbeforecleaningandbeforereplacing
a light bulb. Note: Turning control to OFF turns off compressor, but does not
disconnectpowertolightbulborotherelectricalcomponents.
• Donotoperaterefrigeratorinthepresenceofexplosivefumes.
• Avoid contact with any moving parts of automatic ice maker.
Child Safety
Avoid fire hazard or
electric shock. Do not use an extension
cord or an adapter plug. Do not remove
any prong from the power cord.
These guidelines must be followed to ensure that safety mechanisms in the
design of this refrigerator will operate properly.
Electrical Information
Other Precautions
Proper Disposal of
Your Refrigerator/Freezer
Risk of child entrapment.
Child entrapment and suffocation are
not problems of the past. Junked or
abandonedrefrigeratorsorfreezersare
stilldangerous—eveniftheywillsitfor
"justafew days."Ifyouaregetting rid
ofyouroldrefrigeratororfreezer,please
follow the instructions below to help
preventaccidents.
BEFORE YOU THROW AWAY YOUR
OLD REFRIGERATOR/FREEZER:
Remove
doors.
Leaveshelves
inplaceso
childrenmay
noteasily
climbinside.

4
ThisOwner’sGuideprovides specificoperatinginstructions foryourmodel.Usethe
refrigerator only as instructed in this Owner’s Guide. Before starting the
refrigerator, follow these important first steps:
Location
• Choose a place that is near a grounded electrical outlet. DO NOT use an
extensioncordoradapter plug.
• If possible, place refrigerator out of direct sunlight and away from range,
dishwasher,orotherheatsources.
• Refrigerator must be installed on a floor that is level and strong enough to
supportafullyloadedrefrigerator.
• Considerwatersupply availability forautomaticicemaker.
Installation
• Donotinstallrefrigerator wheretemperaturewill dropbelow60°F(15°C)orrise
above110°F(43°C). Compressorwillnotbeabletomaintain propertemperatures.
• Inarecessed installation, allow an extra 1/2 inch (10-15 mm) on eachsidefor
easeofinstallation.
• Topermitproper door swing,ifthehingeside of theunitwillbeplaced against
a wall, allow a 1-3/4 inch (44 mm) space between wall and refrigerator.
Door Opening
For best use of drawers and freezer basket, refrigerator should be in a position
where both refrigerator and freezer doors can be opened about 135°.
Leveling
•Refrigerator must be leveled with all bottom corners resting firmly on
asolidfloor. Adjustfrontrollerstolevelcabinetbothfront-to-rearandside-
to-side.Keepcabinetaslowaspossibleforstability. Neveradjustcabinetrollers
sofront islowerthan rear.
•Toadjustfrontrollers: Open refrigerator and freezerdoors.Removetoegrill
bypullingitstraightout. Adjustrollersbyturningeachrolleradjustingboltwith
anadjustablewrench,asocketwrench,oranutdriveruntil refrigeratorislevel
andstable. Rearrollersarenotadjustable.
• Checkboth doors to be sure seals touchcabinetevenly on all four sides.
• Iffreezerdoorishigherthanrefrigeratordoor,raiserightcornerand/orlowerleft
corneruntildoorsalignacrosstopofcabinet.
• Ifrefrigeratordoorishigherthanfreezerdoor,raiseleftcornerand/orlowerright
corneruntildoorsalignacrosstopofcabinet.
•Toreplacetoe grill: Line up tabswithholes,and push grillstraighton.
Cleaning
• Wash the inside, all removable parts, and the outside with mild detergent and
warm water. Wipe dry. DO NOT USE HARSH CLEANERS ON THESE
SURFACES.
• Do not use razor blades or other sharp instruments that can scratch appliance
surface,whenremovingadhesive labels. Any glueleftfromtapeorenergy label
can be removed with a mixture of warm water and mild detergent, or touch
residuewithsticky sideoftapealready removed.
• DO NOT REMOVE SERIAL PLATE.
FirstSteps
AdjustingFrontRollers
ROLLER ADJUSTING
BOLT
ReplacingToeGrill

5
• Locatetherefrigeratorinthecoolestpartoftheroom, outofdirectsunlightand
awayfrom heatingductsor registers.Donotplacetherefrigeratornexttoheat-
producingappliancessuchas arange,ovenordishwasher.Ifthisisnotpossible,
asection ofcabinetryoranaddedlayerof insulationbetweenthe twoappliances
willhelptherefrigeratoroperatemoreefficiently.
• Leveltherefrigeratorsothedoorsclosetightly.
• Referto thisOwner'sGuidefor thesuggestedrefrigerator settings.
• Periodiccleaningofthecondenserwillhelptherefrigeratorrunmoreefficiently.
See Outside in the "Care and Cleaning" section.
• Do not overcrowd the refrigerator or block cold air vents. Doing so causes the
refrigeratortorunlongerandusemoreenergy.Shelvesshouldnotbelinedwith
aluminum foil, wax paper or paper toweling. Liners interfere with cold air
circulation, making the refrigerator less efficient, which could cause food
spoilage.
• Coverfoods andwipecontainersdrybefore placingthemintherefrigerator. This
cuts down on moisture build-up inside the unit.
• Organize the refrigerator to reduce door openings. Remove as many items as
needed at one time and close the door as soon as possible.
Setting the Controls Cool Down Period
Toensuresafefood storage,allowtherefrigeratortooperatewiththedoorsclosed
for at least 8 to 12 hours before loading with food.
Refrigerator Control
• Therefrigeratorcontrol should besetatthe midpoint (-)of thedialfora trial
period of 24 hours.
• After24hours, adjust the controlasneeded.Forcoldertemperatures, turnthe
dial a notch toward COLDEST. For warmer temperatures, turn the dial a notch
toward COLD. Adjust temperatures by one increment at a time.
Freezer Control
• Thefreezercontrolshouldbeset atthemidpoint(-)ofthedialforatrialperiod
of 24 hours.
• After24hours, adjust the controlasneeded.Forcoldertemperatures, turnthe
dial a notch toward COLDEST. For warmer temperatures, turn the dial a notch
toward COLD. Adjust temperatures by one increment at a time.
Note: When first setting the controls or when changing a setting, wait 24 hours
forthetemperaturetostabilizebeforemakingadditionalchanges.
Turning the freezer control may change temperatures in both compartments. For
example,ifthefreezercontrolisturnedtoacoldersetting,therefrigeratorcontrol
may have to be adjusted to a warmer one. Turning the refrigerator control will
changeonlytherefrigeratortemperature.
IMPORTANT: If the freezer control is turned to OFF, cooling stops in both
compartments.
You may hear the "Frost Free" system working. A fan circulates air in the
refrigeratorandfreezer compartments. For good circulation and maintenanceof
proper cooling temperatures, do not block cold air vents with food items. Water
draining into the defrost water pan and hissing sounds are normal during the
automatic"FrostFree" cycle.
Energy Saving Ideas
G05C0090
RefrigeratorControl
G05C0091
FreezerControl

6
Fresh Food Storage Shelves
Refrigeratorshelvesareeasilyadjustabletosuitindividualneeds.Somemodelshave
slidingshelves,othershavecantilevershelves,orboth.Beforeadjustingshelves,
removeallfood.Theshippingclips,whichstabilizetheshelvesforshipping,maybe
removed and discarded.
Adjustments:
Toadjustthecantilevershelves (shelvessupportedattherearoftherefrigerator),
liftthebackof the shelf upandout.Replaceshelfby inserting hooks at rearinto
slots.Lower andlockinto position.
Insomemodels,the Spillfree shelvesslideoutforeasyaccesstofoodandfast
cleaning.The shelvesslideout independentlyofthe cantileverbracket.Justpull
frontofshelf forward.Shelfcanbe extended asfaras stopper willallowandis not
removablefromthecantileverbracket.
Door Storage
Doorbinsandshelves areprovidedforconvenientstorageofjars, bottlesandcans.
Itemsused oftenareavailableforquick selection.
Thedoor binscanbe movedtosuitindividualneeds. Removebinsby liftingstraight
up.Place bins in the desired positionand lower over the supports.
The Dairy compartment is warmer than the general food storage section and is
intendedforshorttermstorageofcheese,spreads,orbutter.
Crisper
Thecrisperdrawer,locatedunderthebottomrefrigeratorshelf,isforstoringfruits
and vegetables. Most produce should be washed in clear water and drained before
placinginthisdrawer.Itemswith strong odors or high moisture should be wrapped
beforestoring.
The Humidity Control (some models) allows you to adjust the humidity within the
Crisperdrawer.Thiscanextendthelife offreshvegetables whichkeepbestinhigh
humidity. Leafy vegetables, however, keep best when stored with the Humidity
Control set on HIGHER, or in a drawer without a Humidity Control. This keeps
incoming air to a minimum and maintains maximum moisture content.
Meat Keeper
The Meat Keeper is located at the bottom of the refrigerator. The temperature in
this compartment can be made colder than the rest of the refrigerator compart-
ment by sliding the Chilled Air Control knob within the COLDEST or COLD range.
Meat will be partially frozen and may be kept fresh longer than if stored on a
refrigeratorshelf.
Beforeplacingitemsin the Meat Keeper,followthesestepstokeep the meat fresh:
1. Carefully handle meat with clean hands and always keep the compartment
clean.
2. Storemeatinitsoriginalwrapper.Ifnecessary, overwrapinplasticwraporfoil
topreventdrying.Wrapfishtightlytopreventodortransfertootherfoods.
3. Ifspoilageever occurs, disinfect thecompartmentwithliquidchlorine bleach
followinglabel directions.Thenrinsewithasolutionof bakingsodaandwater.
Rinse with clear water and dry.
Freezer Basket
A slide-out wire basket (some models have two) hangs below the bottom freezer
shelf.Thisbasketprovideseasyaccesstofrozen food packages.
Tall Storage Compartment (some models)
Ashelfis attached to the freezer wall just belowtheice server. This allows for
convenientstorageoftallitemsplacedverticallybetweentheiceserver and the
freezerwall.
Remove Shipping Clips
CantileverShelf
FRESH FRUITS & VEGETABLES
LOWER
FRUITS
HIGHER
HUMIDITY CONTROL
VEGETABLES
Humidity Control
ChilledAirControl
TallStorage
Compartment

7
Automatic Ice and
Water Dispenser
The ice and water dispenser on the freezer door conveniently dispenses chilled
waterandicecubes.Tooperatethedispenser,slidetheknobtotheselectionofyour
choice and press a glass against the dispensing arm, as shown. Be sure to hold the
glassasfarupaspossibletocatchallcubes. Tostopdispensing,pullglassawayfrom
dispensingarm.Releasedispensingarm before the glass is full, butdonotremove
theglass untiltheice hascompletelydispensed.
Asmallheatedareabeneaththedispenserfloorcatchesandevaporatessmallspills.
Do not pour water or excess cubes into this area because there is no drain.
Light
The dispenser has a light that can be turned on and off by sliding the knob to the
desiredposition. The light also turnson automatically when ice and/orwater is
dispensed. Replace light bulb with an appliance bulb of the same wattage.
How the Water Dispenser Works
Thewatertank is located behind the drawers in the refrigeratorcompartment. As
thewaterisdispensed,thetankisautomaticallyrefilled.Forproperoperationofthe
dispenser, the supply water pressure must fall between 30 psi and 120 psi.
Afterthe refrigeratorisinstalledandtheplumbingconnectionsare complete,the
watertank should be filled bydrawing one glass of water.Thiswilltakeabout 1-
1/2 minutes. Then, draw and discard 7 more glasses to be sure that the tank and
plumbingconnectionsare rinsed of any impurities.
Toensure fresh-tastingwater, plan to use the dispenser every day. If the water
dispenser has not been used for a week or more, draw and discard 7-8 glasses to
freshenthetank supply.
How the Ice Dispenser Works
Theice maker and ice storage bin arelocated in the top left corner ofthe freezer
compartment.Aftertherefrigeratorisinstalledproperlyandhascooledforseveral
hours,theicemakercanbeginmakingice.Tobeginiceproduction,lowerthewire
signal arm to the "down" or ON position. As cubes are made, they are stored in the
storagebin.Withnousageitwilltakeapproximately2daystofillthebin.However,
thedispenser may be used after thefirstbatch of ice is made. Theicemaker turns
offautomatically whentheicestoragebin isfull.
Because of new plumbing connections, the first production of ice cubes may be
discolored or have an odd flavor. These should be discarded until the cubes made
arefreeofdiscolorationandtaste. Remember,waterqualitydetermines
youricequality. It is besttoconnecttheice makertowaterthatis not softened.
Chemicals from a malfunctioning softener can damage the ice maker. If ice maker
isconnectedtosoftwater,ensurethesofteneris maintainedandworkingproperly.
Tostopthe ice maker,liftthewire signal armuntilitclicksand locks inthe"up"
orOFFposition.
Ice Maker
Wire
Signal Arm
DispenserSelector
Pressglassagainstdispensing arm.
go5c0092

8
Ice Dispenser Tips
1. Ice cubes stored too long may develop an odd flavor. Empty the container and
return it to the proper position. The ice maker will then produce more ice.
2. Occasionallyshakethecontainertokeepiceseparated.
3. Ifthedispensingarmispushedin for more than 4 minutes, the dispenser motor
mayoverloadand stop. Theoverloadprotectorwillresetautomatically after 3
or4minutes.If alargequantityofice isneededatonetime,itis besttoremove
cubesdirectlyfromtheicestoragebin.
4. Certain sounds are normal when the ice maker is operating. They are:
• Motor operation
• Ice being loosened from the tray
• Icedropping into the storage bin
• Running water
• Water valve opening or closing
For more information on these operations, see "Normal Operating Sounds."
5. Stop the ice maker when cleaning the freezer or for long vacations.
6. Iftheicemakeristobeturnedoffforalongperiodoftime,turnthewatersupply
valvetotheclosedposition.
Cleaning the Ice Dispenser
Cleanthedispenserandicestoragebinatregularintervals,particularlybeforeyou
takea vacation ormove,or if theicedispenser sticks.
1. Stopiceproductionbyliftingthewiresignalarm to the "up" or OFF position.
2. Removeicestoragebinbyliftingupand out. Empty and carefully clean the bin
with milddetergent.Donotsubmergethebinwhilecleaning.Rinsewithclear
water. Do not use harsh or abrasive cleaners. Allow ice bin to dry completely
beforereplacinginthefreezer.
3. Remove ice chips and clean the shelf and chute that supports the ice storage
bin.
4. Replace the ice storage bin. Lower the wire signal arm on the ice maker to the
"down" or ON position and the ice maker will resume production.
IMPORTANT: When removing or replacing the ice bin, do not rotate the auger
intheicebin.Iftheaugerisaccidentallyturned,youmustrealigntheauger by
turningitin90°turnsuntiltheicebinfitsintoplacewiththedrivemechanism.
Forfurther instruction,seethelabelontheicebucket.
Remove and empty the ice storage bin if:
1. An extended power failure (one hour or longer) causes ice cubes in the ice
storage bin to melt and freeze together and jam the dispenser mechanism.
2. Theicedispenserisnotusedfrequently.Icecubeswillfreezetogetherinthebin
and jam the dispenser mechanism. Remove the ice storage bin and shake to
loosenthecubes.
NEVER use an ice pick or similar sharp instrument to break up the ice. This could
damage the ice storage bin and dispenser mechanism.
Do not use the ice
chute as a handle when removing
or replacing the ice storage bin.
Surfaces there may be sharp.
WARNING
Automatic Ice and
Water Dispenser
(continued)
Repositioning the Auger
AUGER
DRIVER
MECHANISM
DO NOT PUT FINGERS UP ICE CHUTE.
SURFACES THERE MAY BE SHARP.

9
Care and Cleaning Keepyourrefrigeratorandfreezercleanto preventodorbuild-up.Wipeupanyspills
immediately and clean both sections at least twice a year. Never use metallic
scouringpads,brushes,abrasivecleanersorstrongalkalinesolutionsonanysurface.
Do not wash any removable parts in a dishwasher.
Always unplug the power cord from the wall outlet before cleaning.
NOTE: Turning the control to OFF does not disconnect power to the controls, light
bulb,orotherelectricalcomponents.
Inside
Washinsidesurfacesoftherefrigeratorand freezerwithasolutionof2tablespoons
baking soda in 1 quart warm water. Rinse and dry thoroughly. Be sure to wring
excesswaterout ofspongeorclothbefore cleaningaroundthecontrols,light bulb,
oranyelectricalparts.
Washremovableparts such as shelves and drawers with baking sodasolutionormild
detergent and warm water. DO NOT USE HARSH CLEANERS ON THESE SURFACES.
Rinse and dry thoroughly. Clean the door gaskets with mild suds, rinse with clear
water and wipe dry. Do not use razor blades or other sharp instruments which can
scratchthe appliance surfacewhenremoving adhesivelabels.Anyglue leftfromthe
tape or energy label can be removed with a mixture of warm water and mild
detergent, or, touch the residue with the sticky side of tape already removed. DO
NOT REMOVE THE SERIAL PLATE.
Outside
Washthecabinet and handles with warm water and mild liquid detergent.Rinsewell
and wipe dry with a clean soft cloth. Do not use commercial household cleaners,
ammonia, or alcohol to clean handles.
Removeany dust or dirt from thefront of the toe grill usinga vacuum cleaner with
itsdustingtoolattachment.Removethetoegrillbypullingitstraightout.Whilethe
grill is removed, vacuum the backside of the grill and wipe with a sudsy cloth or
sponge. Periodically clean the condenser (black tubes and wires beneath the
refrigerator,behindthetoegrill).Donotallowlintordusttoaccumulateonthecoils.
Insert a long handled brush or vacuum attachment between the two coils to bring
thelintforward.Toreplacethetoegrill,lineuptabswithholesandpushgrillstraight
on. Use caution when cleaning in the area of the coils. Surfaces
there may be sharp.
The air vents on the lower access panel at the rear of the refrigerator should be
cleanedperiodically.Cleantheventsbyusingavacuumcleanerwithitsdustingtool
attachment. When moving the refrigerator, pull straight out. Do not shift the
refrigeratorfromsidetosideasthismaytearorgougethefloorcovering.Becareful
not to move the refrigerator beyond plumbing connections.
Replacing the Light Bulb
To replace the light bulb in either compartment:
1. Unplugrefrigerator.
2. Wearglovesasprotection against possible broken glass.
3. Replace old bulb with an appliance bulb of the same wattage.
4. Rememberto plugrefrigeratorbackin.
Damp objects stick to cold
metalsurfaces. Donottouchrefrigerated
surfaces with wet or damp hands.
To avoid damage and help
the refrigerator run as efficiently as
possible, clean the condenser and air
ventsperiodically.
Air Vents on Lower Access Panel
Vents

10
Care and Cleaning
(continued)
Vacation and Moving Tips
Short vacations: Leave the refrigerator operating during vacations of 3 weeks
orless.Useupallperishableitemsfromtherefrigeratorsection.Wrapandstore
otheritemsinthefreezer. Turn off the automatic ice maker,evenifyouwillbe
gone just a few days.
Long vacations: Remove all food and ice if you will be gone 1 month or more.
Turn the controls to OFF and disconnect the power. Turn off the automatic ice
makerandturnthe water supply valve to theclosedposition.Cleantheinterior
thoroughly. Leave both doors open to prevent odor and mold build-up. Block
openif necessary.
Moving: Whenmovingtherefrigerator, follow these guidelines topreventdamage:
• Remove all food and other items from both the refrigerator and freezer
compartments. Empty the ice storage bin.
• If a hand truck is used in moving, load the refrigerator from the side.
• Turntherollersasfarupaspossible.Thiswillprotectthemduringslidingor
moving.
• The cabinet should be well padded and handled with care. DO NOT DROP.
The water tank should be emptied to prevent water from standing for a period of
timeor freezingduringcoldertemperatures. Todrainthetank, followthesesteps:
1. Unplugrefrigerator. Carefullymoverefrigeratorawayfromwall. Becarefulnot
to move refrigerator beyond plumbing connections.
2. Turnoffhouseholdwaterline valve thatsupplieswaterto refrigerator.
3. Disconnect refrigerator water supply line from household water source. Some
waterremaining in line may bespilled out.
4. Placea large pan, withatleasta3-quartcapacity,behind refrigerator next to
watersolenoidvalve.
5. Disconnectwater tank inlet lines at water solenoid valve. Water will spill out
whenwater lineiscompletelyremoved. Putwatertankinletlineintopan tocatch
drainage.
6. Afterdrainagehasstopped,reconnect water tank inlet line towater solenoid
valve. Some water may remain in water tank. If unit freezes, the small amount
of water left should not cause a problem.

11
Removing the Handles
and Doors
If it is necessary to move refrigerator through narrow doorways, follow
these steps to remove refrigerator and freezer handles and/or doors.
To Remove Handles
Full-lengthTrim
1. Usingaputty knife,carefullyslidecornerofthebladeundertrim. Slideblade
downuntilyoufindtrimlock.Carefullymaneuverbladeagainsttrimlockfrom
the side, as shown. Note: Pressing down on trim lock from above will not
releaseit.
2. Carefullypushputtyknifefirmlyagainsttrimlock,andtwistgently.Trimlockwill
snapfreefromdoor.(Eachtrimpiecewillhavetwotrimlocks.)
3. Grasp trim, and pull up away fromhandle using a slight side-to-side motion.
4. Remove screws attaching handle to door.
5. Repeat these steps for each handle end. Keep screws and trim pieces.
6. Toreplace handles,lineuphandle withscrewholes,insertscrews andtighten.
Slideupperandlowertrimpiecesbackonhandleends,andsnaptrimlocksback
intoholes ondoorfront.
To Remove Doors
Beforeremoving doors, be surefreezer control is turned to OFF. Remove all food
fromdoors,and unplugrefrigerator.Removetoe grill.
Tracearoundthe hingeswithasoft leadpencil.Thiswill make iteasiertorealign
the doors when they are replaced. Completely remove one door before starting
removaloftheother.
Freezer Door:
1. Removetoe grill. (See Outside in "Care and Cleaning" section.)
2. Removewiringcoverlocated over lower hinge of freezer door. Cover is held in
placebyasinglescrew.(Illustration1)
3. Disconnectwiringharnessplug(connector).Positionyourselftobeabletoplace
yourthumbsontheflatsidesofeachconnectorpiece.Bendbothpartsbackand
forth.Thenwithafirmgrasp,pullthetwopiecesapart.(Illustration1)
4. Todisconnectwaterline,holdwaterlineelbowandpushinongraycollar,forcing
elbow down, off from tube that runs into door.
5.Placea stripoftapealong door bottom,overlowerhinge anduptheside of door.
This will hold hinge in place when door is removed.
6. Remove top bolt of lower hinge. Loosen, but DO NOT REMOVE bottom bolt of
lowerhinge.
7. Remove top hinge cover by lifting back of cover and sliding forward. Remove
hinge screws from hingebracketwitha counter-clockwisemotion.Note: Hinge
has minimal spring tension. Hold bracket when removing last screw. DO NOT
remove hinge bracket from door.
8. Carefullyliftdoorupandoffloosenedlowerhingebolt.(Illustration2)
Refrigerator Door:
1. Remove top hinge cover by lifting back of cover and sliding forward. Remove
hinge screws from hingebracketwitha counter-clockwisemotion.Note: Hinge
has minimal spring tension. Hold bracket when removing last screw. DO NOT
remove hinge bracket from door.
2. Remove top bolt of lower hinge. Loosen, but DO NOT REMOVE bottom bolt of
lowerhinge.
3. Carefullylift doorupandoffloosened lower hinge bolt.
Storedoorsinasafeplaceuntilrefrigeratorismovedtodesiredlocation.Keepall
hardwareforreinstallation.
To Reinstall Doors
Toreinstall doors,reverseinstructionsusedto removedoors. Note: Toreinstall
water line, push elbow up, onto door tube, until collar touches tube ink mark as
shownleft.
Removing Handles and Trim
WATER LINE NUT
Illustration1
C05I0023
Illustration2

12
Beforecalling forservice,reviewthislist.Itmaysaveyoubothtimeandexpense.
This list includes common occurrences that are not the result of defective
workmanshipormaterialsinthisappliance.
Avoid Service Checklist
SOLUTION
RUNNING OF REFRIGERATOR
Freezercontrol is off. Setfreezercontrol. See Setting theControls.
Refrigeratorisindefrostcycle.Thisisnormalforafullyautomaticdefrostingrefrigerator.Thedefrost
cycleoccursperiodically, lasting about20minutes.
Plugat wall outlet isdisconnected.Make sure plug istightlypushed into outlet.
House fuse has blown or circuit breaker has tripped. Check and/or replace fuse with a 15 amp time-
delayfuse.Resetcircuitbreaker.
Power outage. Check house lights. Call local electric company.
Roomoroutside weather is hot.Itisnormal for the refrigerator toworklonger under these conditions.
Refrigerator has recently been disconnected for a period of time. It takes about 8-12 hours for the
refrigeratorto cool down completely.
Automaticicemakerisoperating.Operationoftheicemakercausestherefrigeratortorunslightlymore.
Doorsare opened toofrequently or toolong.Warm air enteringthe refrigerator causesit to runmore.
Open the doors less often.
Refrigerator or freezer door may be slightly open. Make sure refrigerator is level. Keep food and
containers from blocking door. See Occurrence section OPENING/CLOSING OF DOORS/DRAWERS.
Refrigeratorcontrolissettoocold.Settherefrigeratorcontroltoawarmersettinguntiltherefrigerator
temperatureissatisfactory.Allow24 hours for the temperatureto stabilize.
Refrigeratororfreezergasketis dirty, worn, cracked, or poorlyfitted.Cleanorchangegasket.Leaks
indoor seal willcauserefrigerator to runlonger in ordertomaintain desired temperatures.
Thermostatiskeepingtherefrigeratorat a constant temperature. This is normal.Refrigerator goes on
and off to keep temperature constant.
Freezercontrol issettoocold.Set the freezercontroltoawarmer settinguntilthefreezertemperature
issatisfactory.Allow24hoursforthetemperaturetostabilize.Then,iftherefrigeratortemperature
isnotright,settherefrigeratorcontroltoacoldersetting.
Refrigeratorcontrolissettoocold.Set therefrigeratorcontroltoa warmersetting.Allow24hoursfor
temperaturestostabilize.
Refrigeratorcontrolissettoocold.Seeabovesolution.
Meat should be stored at a temperature just below the freezing point of water (32°F, 0°C) for maximum
fresh storage time. It is normal for ice crystals to form due to the moisture content of meat.
ChilledAirControl set toocold.Adjustthe Chilled AirControlto a lower setting.
Doors are opened too frequently or too long. Warm air enters the refrigerator whenever the door is
opened. Open the door less often.
Door is open slightly. See Occurrence section
OPENING/CLOSING OF DOORS/DRAWERS.
Condenser is dirty. Clean condenser. See "Outside" in Care and Cleaning.
Freezercontrol issettoowarm.Set the freezercontroltoacolder settinguntilthefreezertemperature
issatisfactory.Allow24hoursforthetemperaturetostabilize.Then,iftherefrigeratortemperature
isnotright, set therefrigeratorcontroltoawarmer setting.
Refrigeratorcontrolissettoowarm.Settherefrigeratorcontroltoacoldersetting.Allow24 hoursfor
thetemperaturetostabilize.
ChilledAir Control isset too warm. Adjust theChilledAir Controltoa colder setting.
OCCURRENCE
Refrigerator compressor does not run.
Refrigerator runs too much or too
long.
Refrigerator compressor goes on and
offfrequently.
Temperature in the freezer is too cold
and the refrigerator temperature is
satisfactory.
Temperature in the refrigerator is too
cold and the freezer temperature is
satisfactory.
Food stored in drawers freezes.
Food stored in Meat Keeper freezes.
Temperature in the freezer or
refrigerator is too warm.
Temperature in the freezer is too warm.
Temperature in the refrigerator is too
warm and the freezer temperature is
satisfactory.
Temperature in the Meat Keeper is too
warm.
TEMPERATURES ARE TOO COLD
TEMPERATURES ARE TOO WARM

13
Weatherishot and humid whichincreasesrate of frost buildupandinternalsweating. This is normal.
Door is slightly open. See Occurrence section
OPENING/CLOSING OF DOORS/DRAWERS.
Door is opened too often or too long. Open the door less often.
Vegetables contain and give off moisture. It is not unusual to have moisture on the bottom side of
thecover.
Washed vegetables and fruits drain while in the drawer. Dry items before putting them into drawer.
Water collecting in bottom of drawer is normal.
Weather is humid. This is normal in humid weather. When humidity is lower, the moisture should
disappear.
Doorisslightlyopen,causingcoldairfrominsidetherefrigeratortomeetwarmairfromoutside.See
Occurrence section
OPENING/CLOSING OF DOORS/DRAWERS.
Icemaker wire signal armis in "up"orOFF position. Move wire signal arm to "down" or ON position.
Household water line valve is not open. Turn on household water line valve.
Watersupply valve in refrigeratorisbeing blocked byforeignmaterial. Unplug therefrigeratorand
turnoffwater supply. Slide refrigeratoroutandlocatewherewaterisconnectedto the valve. Unscrew
the brass fitting and pull out the screen from inside the valve mesh. Clean the screen of foreign
material. Replace screen and brass fitting and turn the water supply on; check for leaks. Plug in
refrigeratorandslideintoplace.
Freezer is not cold enough. See Occurrence section
TEMPERATURES ARE TOO WARM.
Saddlevalveoncold water pipe is blocked orrestrictedbyforeignmaterial. Turn off household water
linevalve.Remove,cleanorreplacevalve.
Ice maker is producing less ice than you expect. Ice maker should produce approximately
2 1/2 to 4 pounds of ice every 24 hours.
Freezer is not cold enough. See Occurrence section
TEMPERATURES ARE TOO WARM.
Household water line valve is not completely open. Turn on household water line valve.
Watersupply valve inrefrigerator is beingblocked by foreignmaterial. See Occurrence,"Ice maker
is not making any ice" above.
Ice maker wire arm is being held down by an item in the freezer. Remove item and release arm.
Remove any ice cubes which are frozen together over arm.
Ice cubes are not being used frequently enough. Remove and shake ice bucket to separate cubes.
Icehas pickedupodoror flavorfromstrongfood storedinrefrigeratoror freezer.Coverfoodstightly.
Discardstaleice.Icemaker will produce fresh supply.
Waterrunning to icemaker has poortaste or odor.Add filterto ice maker.Consult a waterpurifying
company.
Ice storage bin is empty. When the first supply of ice is dropped into the bin, the dispenser should
operate.
Freezertemperatureissettoowarm.Turnthefreezercontroltoahighersettingsothaticecubeswill
be made. When first supply of ice is made, the dispenser should operate.
Household water line valve is not open. Open household water line valve and allow sufficient time
for ice to be made. When ice is made, dispenser should operate.
Freezerdoor is notclosed.Be sure freezerdooris closed.
Ice dispensing arm has been held in for more than 4-5 minutes. Motor is overloaded. Motor overload
protectorwill reset inapproximately 3 minutes. Ice canthen be dispensed.
Ice has melted and frozen around auger due to infrequent use, temperature fluctuations and/or
power outages. Remove ice storage bin, thaw and empty the contents. Clean bin, wipe dry and
replace in proper position. When new ice is made, dispenser should operate.
SOLUTION
OCCURRENCE
Moisture collects on inside of refrigerator
walls.
Water collects on bottom side of drawer
cover.
Water collects in bottom of drawer.
Moisture forms on outside of refrigerator
or between doors.
Ice maker is not making any ice.
WATER/MOISTURE/FROST INSIDE REFRIGERATOR
WATER/MOISTURE/FROST OUTSIDE REFRIGERATOR
AUTOMATIC ICE MAKER
Ice maker is not making enough ice.
Ice maker will not stop making ice.
Ice maker is not separating the cubes.
Ice has bad odor and taste.
Dispenser will not dispense ice.
ICE DISPENSER

14
OCCURRENCE
WATER DISPENSER
ICE DISPENSER SOLUTION
Ice cubes are jammed between the ice maker arm and back of the bin. Remove the ice cubes that are jamming
thedispenser.
Ice cubes are frozen together. Use the dispenser often so that cubes do not freeze together.
Household water line valve is not open. Open household water line valve. See Occurrence "Ice maker is not
making any ice."
Freezerdoorisnotclosed.Besurefreezerdoorisclosed.
Water has been in the tank for a period of time. Draw and discard 7-8 glasses of water to freshen the supply.
Draw and discard an additional 3-6 glasses to completely rinse out tank.
Unitnotproperly connected to cold water line. Connectunittocold water line which supplies water tokitchen
faucet.
Tubing used in the household water supply and installation of unit may affect water taste and odor. For best
results,usecopper tubing for water connection.
Water has a high mineral content. Contact water treatment plant for help.
Interior needs to be cleaned. Clean interior with sponge, warm water and baking soda.
Foodwith strong odor isinrefrigerator.Cover food tightly.
Door is not designed to swing shut automatically. Close door securely.
Door was closed too hard, causing other door to open slightly. Close both doors gently.
Refrigeratoris notlevel.It rocksonthe floorwhen itismoved slightly.Besure floorislevel andsolidand can
adequatelysupport refrigerator. Adjustrollersas needed.
Refrigeratoris touching the wallorcabinets.Be sure floor islevelandcan adequately support refrigerator.
Contactcarpenter to correct sagging or sloping floor.
Food is touching shelf on top of drawer. Keep less food in drawer.
Trackthat drawersslideson is dirty.Cleandrawer, rollers,andtrack.
Light bulb is burned out. See "Replacing the Light Bulb" in Care and Cleaning.
Lightswitch isstuck.Light switchislocated ontheinterior doorframe next tothe temperaturecontrolin each
compartment. Push in plunger to release.
No electric current is reaching refrigerator. See Occurrence section RUNNING OF REFRIGERATOR.
ODORS IN REFRIGERATOR
Ice dispenser is jammed.
Dispenser will not dispense water.
Water has an odd taste and/or odor.
Door(s) will not close.
Drawers are difficult to move.
OPENING/CLOSING OF DOORS/DRAWERS
LIGHT BULB IS NOT ON
Normal Operating
Sounds

15
*NORMAL
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IF YOU NEED
SERVICE
This warranty applies only to products in ordinary household use, and the consumer is responsible for the items
listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the appliance and in accordance
withall local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loose
connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which are not
a part of the appliance when it was shipped from the factory.
5. Damagestofinishafterinstallation.
6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).
This warranty does not cover the following:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING
FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation or
exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for appliances not in ordinary
household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by servicers other than Frigidaire or its authorized servicers; use of parts other than
genuine Frigidaire Home Products parts; obtained from persons other than such servicers; or external causes such as abuse,
misuse, inadequate power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily determined.
Keep your bill of sale, delivery slip, or some other appropriate payment record. The date on the bill establishes the warranty
periodshouldserviceberequired. Ifserviceisperformed,itisinyourbest interest to obtain and keep all receipts. This written
warranty gives you specific legal rights. You may also have other rights that vary from state to state. Service under this warranty
must be obtained by contacting Frigidaire Home Products:
800•944•9044
Frigidaire Home Products
P.O. Box 212378
Augusta, GA 30917
Product features or specifications as described or illustrated are subject to change without notice. All warranties are made by
White Consolidated Industries, Inc. This warranty applies only in the 50 states of the U.S.A. and Puerto Rico.
FULL ONE-YEAR
WARRANTY
LIMITED 2ND - 5TH
YEAR WARRANTY
(Sealed System)
LIMITED
WARRANTY
(Applicable to the
State of Alaska)
WARRANTY
PERIOD
One year from original
purchase date.
Second through fifth
years from original
purchase date.
Timeperiods listed above.
WCI, THROUGH ITS AUTHORIZED
SERVICERS, WILL:
Pay all costs for repairing or replacing any parts of this
appliance which prove to be defective in materials or
workmanship.
Repair or replace any parts in the Sealed Refrigeration
System (compressor, condenser, evaporator, drier and
tubing) which prove to be defective in materials or
workmanship.
All of the provisions of the full and limited warranties above
and the exclusions listed below apply.
THE CONSUMER WILL BE
RESPONSIBLE FOR:
Costs of service calls that are listed under NORMAL
RESPONSIBILITIES OF THE CONSUMER.*
Travel costs of the technician, diagnostic costs and
any removal, transportation and reinstallation costs
which are required because of service. Costs for
labor, parts and transportation other than with
respect to the Sealed Refrigeration System.
Costs of the technician's travel to the home and any
costs for pick up and delivery of the appliance
required because of service.
REFRIGERATOR WARRANTY
Yourproduct isprotected by this warranty
Your appliance is warranted by White Consolidated Industries, Inc. WCI has authorized Frigidaire and its authorized servicers to perform services under
this warranty. WCI authorizes no one else to change or add to any of these obligations under this warranty. Any obligations for service and parts under
this warranty must be performed by Frigidaire or an authorized Frigidaire servicer.

16
To avoid unnecessary cost and inconvenience, make a few simple checks
before calling for service. Common occurrences and their solutions can be
found in the Avoid Service Checklist. Be sure you have followed the
instructionsinthis manual.
If you are unable to locate the cause of a problem, call for service. Insist on
factory service by an authorized FRIGIDAIRE PARTS AND SERVICE depot.
FRIGIDAIRE PARTS AND SERVICE
All Frigidaire appliances are backed by FRIGIDAIRE PARTS AND SERVICE, one
of Canada's largest parts and service networks.
The Frigidaire reputation means you can enjoy complete professional service
from one of our hundreds of trained technicians across the country.
FRIGIDAIRE PARTS AND SERVICE
7075 Ordan Drive
Mississauga,Ontario
L5T 1K6
Place the name, address and telephone number of your service depot in
the spaces below.
Product and feature specifications as described or illustrated are
subject to change without notice.
Service Information in
Canada

17
WARRANTY (CANADA)
REFRIGERATORS (FROST FREE)
WARRANTOR:
FrigidaireHomeProducts
7075 Ordan Drive
Mississauga,Ontario
L5T 1K6
Thisrefrigeratoris a brandedproductofFrigidaireCanada.
WARRANTY PERIOD:
For one year after purchase by the original consumer/owner:
Forfiveyears after purchase by the original consumer/owner:
For ten years after purchase by the original consumer/owner:
WARRANTY APPLIES TO:
a) Products purchased and installed in Canada for personal single family household use.
b) Defectsresultingorarisingoutofthe manufacturing process.
c) Productsbearing legible manufacturer’s model andserial numbers.
d) Replacement parts only for the remainder of the original warranty.
WARRANTY DOES NOT APPLY TO:
a) Transportationdamage.
b) Supplyandreplacementofporcelain,fuses,glassandlightbulbs.
c) Parts and service supplied or obtained from other than FRIGIDAIRE PARTS AND SERVICE or FRIGIDAIRE PARTS SERVICE
authorizeddepots.
d) Properinstallation,controlsettingandcareoffinish.
CONSUMER/OWNER RESPONSIBILITY:
a) To provide proof of the original date of purchase by means of a bill of sale or payment.
b) Supplyandreplacementofporcelain,fuses,glassandlightbulbs.
c) To ensure proper power supply and connection of the appliance to same.
d) Properinstallation,controlsettingandcareoffinish.
Thiswarrantyisinadditiontoanystatutorywarrantiescontainedinanyapplicable legislation. Thetermsandconditionsofthis
warranty are not intended to exclude or limit your rights under those statutes. The warrantor however reserves the right to
chargetransportation and travellingcostsfordistances inexcessof 48kilometres(30miles) fromthenearest FRIGIDAIRE PARTS
AND SERVICE authorized service depot.
Thiswarranty,plusthestatutorywarrantiesmentionedaretheonlywarrantiesgiventotheconsumer/ownerforthisproduct.
Forserviceunderthiswarranty,contactyourdealer/retailer,
authorized FRIGIDAIRE PARTS AND SERVICE depot, or:
FRIGIDAIRE HOME PRODUCTS
PARTS AND SERVICE
7075 Ordan Drive
Mississauga,Ontario
L5T 1K6
Tel: [phone]
Fax: [phone]
WARRANTOR WILL THROUGH ITS AUTHORIZED SERVICE
DEPOT:
Paycostto repair or replace any defective parts(including
serviceand labourcharge).
Pay cost (including service and labour charge) to repair or
replace defective parts of the sealed refrigeration system
consisting of the compressor, evaporator, condenser,
interconnectingtubing drierandrefrigerationcharge.
Pay cost (excluding service and labour charge) to replace a
defectivemotor compressor.

18
Notes
