AIR CONDITIONER
CEILING SUSPENSION
TYPE
OPERATING MANUAL
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ΕΓΧΕΙΡΙΔΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
MANUAL DE FUNCIONAMENTO
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
KULLANIM KİTABI
PART No. 9374379736
KEEP THIS MANUAL FOR FUTURE REFERENCE
BEWAHREN SIE DIESES HANDBUCH ZUM SPÄTEREN NACHSCHLAGEN AUF
CONSERVEZ CE MANUEL POUR RÉFÉRENCE ULTÉRIEURE
CONSERVE ESTE MANUAL PARA SU FUTURA CONSULTA
CONSERVARE IL PRESENTE MANUALE PER FUTURE CONSULTAZIONI
ΦΥΛΑΞΤΕ ΤΟ ΕΓΧΕΙΡΙΔΙΟ ΓΙΑ ΜΕΛΛΟΝΤΙΚΗ ΑΝΑΦΟΡΑ
GUARDE ESTE MANUAL PARA REFERÊNCIA FUTURA
РУКОВОДСТВО ДЛЯ СПРАВОК В БУДУЩЕМ
BU KILAVUZU, DAHA SONRA BAŞVURMAK ÜZERE SAKLAYIN
Português EλληvIkά Italiano Español Français Deutsch English
РусскийTürkçe
9374379736_OM.indb 1 6/24/2013 9:24:19 AM

En-2
lDo not attempt to install this air conditioner by yourself.
lThis unit contains no user-serviceable parts. Always consult authorized service per-
sonnel for repairs.
lWhen moving, consult authorized service personnel for disconnection and installa-
tion of the air conditioner.
l
Do not become excessively chilled by staying for many hours in the direct cooling airow.
lDo not insert ngers or objects into the outlet port or intake grilles.
lDo not start and stop air conditioner operation by disconnecting the power supply
cable and so on.
lTake care not to damage the power supply cable.
lIn the event of a malfunction (burning smell, etc.), immediately stop operation, turn
off the electrical breaker, and consult authorized service personnel.
l
If the power supply cable of this appliance is damaged, it should only be replaced by the
authorized service personnel, since special purpose tools and specied cable are required.
lIn the event of the refrigerant leakage, be sure to keep it away from re or any am-
mables. (consult an authorized service personnel)
lProvide occasional ventilation during use.
lDo not direct air ow at replaces or heating apparatus.
lDo not climb on, or place objects on, the air conditioner.
lDo not hang objects from the indoor unit.
lDo not set ower vases or water containers on top of air conditioners.
lDo not expose the air conditioner directly to water.
lDo not operate the air conditioner with wet hands.
lDo not pull power supply cable.
lTurn off power source when not using the unit for extended periods.
lAlways turn off the electrical breaker whenever cleaning the air conditioner or
changing the air lter.
lConnection valves become hot during Heating; handle with care.
lWhen restarting after a long period of disuse in the winter, turn the power switch on
at least 12 hours before starting the unit.
lCheck the condition of the installation stand for damage.
lDo not place animals or plants in the direct path of the air ow.
lDo not drink the water drained from the air conditioner.
lDo not use in applications involving the storage of foods, plants or animals, preci-
sion equipment, or art works.
lDo not apply any heavy pressure to radiator ns.
lOperate only with air lters installed.
lDo not block or cover the intake grille and outlet port.
lEnsure that any electronic equipment is at least 1 m away from either the indoor or
outdoor units.
lAvoid installing the air conditioner near a replace or other heating apparatus.
l
When installing the indoor and outdoor units, take precautions to prevent access by infants.
lDo not use inammable gases near the air conditioner.
CONTENTS
SAFETY PRECAUTIONS
l Before using the appliance, read these “PRECAUTIONS” thoroughly and operate in the correct way.
l The instructions in this section all relate to safety; be sure to maintain safe operating conditions.
l “DANGER”, “WARNING” and “CAUTION” have the following meanings in these instructions:
DANGER This mark indicates procedures which, if improperly performed, are most likely toresult in
the death of or serious injury to the user or service personnel.
WARNING This mark indicates procedures which, if improperly performed, might lead to the death or
serious injury of the user or service personnel.
CAUTION This mark indicates procedures which, if improperly performed, might possibly result in
personal harm to the user, or damage to property.
DANGER
CAUTION
SAFETY PRECAUTIONS......................................2
FEATURES AND FUNCTIONS .............................3
NAME OF PARTS .................................................4
PREPARATION .....................................................6
OPERATION..........................................................7
TIMER OPERATION .............................................9
SLEEP TIMER OPERATION...............................10
MANUAL AUTO OPERATION............................. 10
ADJUSTING THE DIRECTION OF AIR CIRCULATION ... 11
SWING OPERATION ..........................................12
ECONOMY OPERATION....................................12
10 °C HEAT OPERATION ...................................13
SELECTING THE REMOTE CONTROLLER
SIGNAL CODE....................................................13
CLEANING AND CARE.......................................14
TROUBLESHOOTING ........................................15
OPERATING TIPS............................................... 16
9374379736_OM.indb 2 6/24/2013 9:24:19 AM

En-3
10 °C HEAT OPERATION
The room temperature can be maintained at 10°C so as to
prevent the room temperature from falling too far.
n Convenient function
PROGRAM TIMER
The program timer allows you to integrate OFF timer and ON
timer operations in a single sequence. The sequence can in-
volve 1 transition from OFF timer to ON timer, or from ON
timer to OFF timer, within a 24 hour period.
SLEEP TIMER
When the SLEEP timer button is pressed during heating mode,
the air conditioner’s thermostat setting is gradually lowered
during the period of operation; during cooling or dry mode,
the thermostat setting is gradually raised during the period of
operation. When the set time is reached, the unit automatically
turns off.
n Clean function
REMOVABLE AIR FILTER
The indoor unit’s air lter can be removed for easy cleaning
and maintenance.
lThis appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
lIf you see lightning or hear thunder, there might be a lightning strike. To prevent
electric shock hazard, turn off the air conditioner by using the remote controller, and
do not touch the unit or the power plug during thunderstorm.
lDo not place any other electrical products or household belongings under indoor unit
or outdoor unit. Dripping condensation from the unit might get them wet, and may
cause damage or malfunction of your property.
lKeep clean and tidy around the outdoor unit, and do not place the things around it.
If it is covered with fallen leaves, there could be an infiltration of small animals or
insects whose contact with the internal electrical components leads to the product
malfunction.
lDo not stand on unstable steps when operating or cleaning the air conditioner. It may
overturn and can cause the injury.
CAUTION
SAFETY PRECAUTIONS
FEATURES AND FUNCTIONS
n Energy saving and Comfortable function
INVERTER
At the start of operation, large amount of power is used to
bring the room quickly to the desired temperature. Afterwards,
the unit automatically switches to a low power setting for
economic and comfortable operation.
ECONOMY OPERATION
When ECONOMY operation mode is operated, the room
temperature will be little higher than the set-temp under
cooling mode and lower than set-temp under heating mode.
Therefore, the ECONOMY mode is able to save more energy
than other normal mode.
OMNI-DIRECTIONAL AIR FLOW
(SWING OPERATION)
3-dimensional control over air direction swing is possible
through dual use of both an up/down air direction swing and
right/left air direction swing. Since up/down air direction aps
operate automatically according to the operating mode of the
unit, it is possible to set air direction based on the operating
mode.
SUPER QUIET OPERATION
When the FAN button is used to select QUIET, the indoor
unit begins super quiet operation; the indoor unit’s airow is
reduced to produce quieter operation.
AUTO CHANGEOVER
The operation mode (cooling, dry, heating) is switched auto-
matically to maintain the set temperature, and the temperature
is kept constant at all times.
9374379736_OM.indb 3 6/24/2013 9:24:19 AM

En-4
FEATURES AND FUNCTIONS
n Remote controller
WIRELESS REMOTE CONTROLLER
The wireless remote controller allows convenient control of air
conditioner operation.
WIRED REMOTE CONTROLLER (OPTION)
The optional wired remote controller can be used.
When you use remote controller, there are following different
points as compared with using wireless remote controller.
[The additional functions for wired ones]
• Weekly timer
• Temperature set back timer
And you can use both wired and wireless remote controller
simultaneously.
(But function is limited)
When the restricted functions on the remote controller are
used, beeping sound will be heard, OPERATION, TIMER and
the 3rd lamp of the indoor unit will ash.
[The restricted functions for wireless ones]
• SLEEP timer
• TIMER (ON timer, OFF timer and Program timer)
• 10 °C HEAT operation
3 2
1
9
8
7
456
Indoor unit
NAME OF PARTS
1 Control panel
2 MANUAL AUTO button
l When the MANUAL AUTO button is pressed in for more
than 10 seconds, the forced cooling operation will start.
lThe forced cooling operation is used at the time of
installation.
Only for authorized service personnel’s use.
lWhen the forced cooling operation starts by any chance,
press the START/STOP button to stop the operation.
lPlease press the button at Filter Reset.
3 Remote control signal receiver
4 OPERATION indicator lamp (green)
5 TIMER indicator lamp (orange)
lTIMER indicator lamp lights when the timer is set from
wireless remote controller.
l If the TIMER indicator lamp ashes when the timer is
operating, it indicates that a fault has occurred with the
timer setting (see “AUTO Restart” on page 17.)
6 ECONOMY Indicator Lamp (green)
lECONOMY indicator lamp lights in the following
operations:
•ECONOMY operation
•10 ºC HEAT operation (controlled by wireless remote
controller)
7 Intake grille
8 Up/down air direction aps
9 Right/left air direction louvers
(behind up/down air direction aps)
9374379736_OM.indb 4 6/24/2013 9:24:19 AM

En-5
Display panel
To facilitate explanation, the accompanying illustration has
been drawn to show all possible indicators; in actual oper-
ation, however, the display will only show those indicators
appropriate to the current operation.
1 MODE button
2 10 °C HEAT button
3 SET TEMP. button ( / )
4 ECONOMY button
5 SLEEP button
6 FAN button
7 START/STOP button
8 SET button (Vertical)
9 SET button (Horizontal)
0 SWING button
A TIMER MODE button
B TIMER SET ( / ) button
C CLOCK ADJUST button
D RESET button
E TEST RUN button
l This button is used when installing the
conditioner, and should not be used under
normal conditions, as it will cause the air
conditioner’s thermostat function to operate
incorrectly.
l If this button is pressed during normal
operation, the unit will switch to test run
mode, and the indoor unit’s OPERATION
indicator lamp and TIMER indicator lamp
will begin to ash simultaneously.
l To stop the test run, press the START/STOP
button to stop the air conditioner.
F Signal transmitter
G Temperature SET indicator
H Operating mode indicator
I SLEEP indicator
J Transmit indicator
K Fan speed indicator
L SWING indicator
M Timer mode indicator
N Clock indicator
Some indoor units may not be equipped with the functions
corresponding to all of the buttons on this remote
controller. The indoor unit will beep and the OPERATION,
TIMER and ECONOMY lamp flash when a remote
controller button is pressed if the function is not available.
Remote controller
Display panel
NAME OF PARTS
9374379736_OM.indb 5 6/24/2013 9:24:20 AM

En-6
Turn on the Power
1 Turn on the circuit breaker.
Load Batteries (AAA/R03/LR03 × 2)
1 Press and slide the battery compartment lid on the
reverse side to open it.
Slide in the direction of the arrow while pressing the mark.
2 Insert batteries.
Be sure to align the battery polarities ( ) correctly.
3 Close the battery compartment lid.
Set the Current Time
1 Press the CLOCK ADJUST button.
Use the tip of a ball-point pen or other small object to press the button.
2 Use the TIMER SET ( / ) buttons to adjust the
clock to the current time.
button: Press to advance the time.
button: Press to reverse the time.
(Each time the buttons are pressed, the time will be advanced/reversed in
1-minute increments; hold the buttons depressed to change the time quickly
in 10-minute increments.)
3 Press the CLOCK ADJUST button again.
This completes the time setting and starts the clock.
To Use the Remote Controller
lThe remote controller must be pointed at signal receiver to operate correctly.
lOperating range: About 7 meters.
lWhen a signal is properly received by the air conditioner, a beeping sound will be
heard.
lIf no beep is heard, press the button of the remote controller again.
Remote Controller Holder
CAUTION
lTake care to prevent infants from accidentally
swallowing batteries.
lWhen not using the remote controller for an
extended period, remove the batteries to
avoid possible leakage and damage to the
unit.
lIf leaking battery fluid comes in contact
with your skin, eyes, or mouth, imme-
diately wash with copious amounts of
water, and consult your physician.
lDead batteries should be removed
immediately and disposed of properly, either
in a battery collection receptacle or to the
appropriate authority.
lDo not attempt to recharge dry batteries.
Never mix new and used batteries, or
batteries of different types.
Batteries should last about 1 year under
normal use. If the operating range of the
remote controller becomes appreciably
reduced, replace the batteries and
press the RESET button with the tip of a
ballpoint pen or other small object.
3 To remove the remote
controller (when use at
hand).
1 Mount the holder. 2 Set the remote controller.
Screws
Insert
Press in
Slide up
Pull out
PREPARATION
9374379736_OM.indb 6 6/24/2013 9:24:21 AM

En-7
To Select Mode Operation
1 Press the START/STOP button.
The indoor unit’s OPERATION indicator lamp (green) will light.
The air conditioner will start operating.
2 Press the MODE button to select the desired mode.
Each time the button is pressed, the mode will change in the following order.
AUTO COOL DRY
HEAT FAN
About 3 seconds later, the entire display will reappear.
To Set the Room Temperature
Press the SET TEMP. button.
button: Press to raise the thermostat setting.
button: Press to lower the thermostat setting.
l Thermostat setting range:
AUTO ....................................18-30 °C
Heating..................................16-30 °C
Cooling/Dry ...........................18-30 °C
The thermostat cannot be used to set room temperature during the FAN mode (the tem-
perature will not appear on the remote controller display).
About 3 seconds later, the entire display will reappear.
The thermostat setting should be considered a standard value, and may differ some-
what from the actual room temperature.
To Set the Fan Speed
Press the FAN button.
Each time the button is pressed, the fan speed changes in the following order:
AUTO HIGH MED LOW QUIET
About 3 seconds later, the entire display will reappear.
When set to AUTO:
Heating: Fan operates so as to optimally circulate warmed air.
However, the fan will operate at very low speed when the temperature of the
air issued from the indoor unit is low.
Cooling: As the room temperature approaches that of the thermostat setting, the fan
speed becomes slower.
Fan: The fan runs at the low fan speed.
The fan will operate at a very low setting during monitor operation and at the start of the
heating mode.
SUPER QUIET Operation
When set to QUIET:
SUPER QUIET operation begins. The indoor unit’s airow will be reduced for quieter
operation.
lSUPER QUIET operation cannot be used during dry mode. (The same is true when
dry mode is selected during AUTO mode operation.)
lDuring QUIET operation, heating and cooling performance will be reduced somewhat.
If the room does not warm up/cool down when using QUIET operation, please adjust
the air conditioner’s fan speed.
Example: When set to COOL.
Example: When set to 26 °C.
Example: When set to AUTO.
OPERATION
9374379736_OM.indb 7 6/24/2013 9:24:21 AM

En-8
OPERATION
To Stop Operation
Press the START/STOP button.
The OPERATION indicator lamp (green) will go out.
Mode Operation
AUTO (in COOLING model):
l When AUTO (automatic changeover) operation rst selected, the fan will operate at very low speed for about a few
minutes, during which time the indoor unit detects the room conditions and selects the proper mode.
Room temperature is higher than the dened temperature in temperature
setting → Cooling mode or dry mode
Room temperature is close to or lower than the defined temperature in
temperature setting → Monitor operation
lWhen the indoor unit has adjusted your room’s temperature to near the temperature setting, it will begin monitor
operation. In the monitor operation mode, the fan will operate at low speed. If the room temperature subsequently
changes, the indoor unit will once again select the appropriate operation (cooling) to adjust the temperature to the value
set in the temperature setting.
lIf the mode automatically selected by the unit is not what you wish, select one of the mode operation (COOL, DRY, FAN).
AUTO [in HEAT & COOL (Reverse Cycle) model]:
lWhen AUTO (automatic changeover) is selected, the air conditioner selects the appropriate operation mode (cooling or
heating) according to your room’s present temperature.
l
When AUTO operation rst selected, the fan will operate at low speed for about a few minute, during which time the
indoor unit detects the room conditions and selects the proper operation mode.
Room temperature is higher than the dened temperature in temperature
setting → Cooling mode or dry mode
Room temperature is close to the defined temperature in temperature
setting → Determined by outdoor temperature
Room temperature is lower than the defined temperature in temperature
setting → Heating mode
lWhen the air conditioner has adjusted your room’s temperature to near the thermostat setting, it will begin monitor
operation. In the monitor operation mode, the fan will operate at low speed. If the room temperature subsequently
changes, the air conditioner will once again select the appropriate operation (heating, cooling) to adjust the temperature
to the value set in the thermostat.
l
If the mode automatically selected by the unit is not what you wish, select one of the mode operation (HEAT, COOL, DRY, FAN).
Cooling or Dry
Dened
temperature in
temperature
setting
Heating
Determined by
outdoor temperature
Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle).
During heating mode:
Set the thermostat to a temperature
setting that is higher than the current room
temperature. The heating mode will not
operate if the thermostat is set lower than
the actual room temperature.
During cooling/dry mode:
Set the thermostat to a temperature
setting that is lower than the current room
temperature. The cooling and dry modes
will not operate if the thermostat is set
higher than the actual room temperature (in
cooling mode, the fan alone will operate).
During fan mode:
You cannot use the unit to heat and cool
your room.
HEAT*: lUse to warm your room.
lWhen heating mode is selected, the air conditioner will operate at very
low fan speed for about 3 to 5 minutes, after which it will switch to the
selected fan setting. This period of time is provided to allow the indoor unit
to warm up before beginning full operation.
lWhen the room temperature is very low, frost may form on the outside
unit, and its performance may be reduced. In order to remove such frost,
the unit will automatically enter the defrost cycle from time to time. During
automatic defrosting operation, the OPERATION indicator lamp will ash,
and the heat operation will be interrupted.
l
After the start of heating operation, it takes some time before the room
gets warmer.
COOL: lUse to cool your room.
DRY: lUse for gently cooling while dehumidifying your room.
lYou cannot heat the room during dry mode.
lDuring dry mode, the unit will operate at low speed; in order to adjust
room humidity, the indoor unit’s fan may stop from time to time. Also, the
fan may operate at very low speed when adjusting room humidity.
l
The fan speed cannot be changed manually when dry mode has been selected.
FAN: lUse to circulate the air throughout your room.
Dened
temperature in
temperature
setting Monitor operation
Cooling mode
or Dry mode
9374379736_OM.indb 8 6/24/2013 9:24:21 AM

En-9
To Cancel the Timer
Use the TIMER MODE button to select
“CANCEL”.
The air conditioner will return to normal
operation.
To Change the Timer Settings
Perform steps 2and 3.
To Stop Air Conditioner Operation while
the Timer is Operating
Press the START/STOP button.
To Change Operating Conditions
If you wish to change operating conditions
(mode, fan speed, thermostat setting, QUIET
mode), after making the timer setting wait until
the entire display reappears, then press the
appropriate buttons to change the operating
condition desired.
To Cancel the Timer
Use the TIMER MODE button to select
“CANCEL”.
The air conditioner will return to normal
operation.
To Change the Timer Settings
1.
Follow the instructions given in the section
“To Use the ON Timer or OFF Timer” to
select the timer setting you wish to change.
2. Press the TIMER MODE button to select
either OFF ON or OFF ON.
To Stop Air Conditioner Operation while
the Timer is Operating
Press the START/STOP button.
To Change Operating Conditions
If you wish to change operating conditions
(mode, fan speed, thermostat setting, QUIET
mode), after making the timer setting wait until
the entire display reappears, then press the
appropriate buttons to change the operating
condition desired.
To Use the ON Timer or OFF Timer
1 Press the START/STOP button
(if the unit is already operating, proceed to step 2).
The indoor unit’s OPERATION indicator lamp (green) will light.
2 Press the TIMER MODE button to select the OFF tim-
er or ON timer operation.
Each time the button is pressed the timer function changes in the following
order:
CANCEL OFF ON
PROGRAM (OFF →ON, OFF ←ON)
The indoor unit’s TIMER indicator lamp (orange) will light.
3 Use the TIMER SET buttons to adjust the desired OFF
time or ON time.
Set the time while the time indicator is ashing (the ashing will continue for
about 5 seconds).
button: Press to advance the time.
button: Press to reverse the time.
About 5 seconds later, the entire display will reappear.
To Use the Program Timer
1 Press the START/STOP button
(if the unit is already operating, proceed to step 2).
The indoor unit’s OPERATION indicator lamp (green) will light.
2 Set the desired times for OFF timer and ON timer.
See the section “To Use the ON Timer or OFF Timer” to set the desired mode
and times.
About 3 seconds later, the entire display will reappear.
The indoor unit’s TIMER indicator lamp (orange) will light.
3
Press the TIMER MODE button to select the PROGRAM
timer operation (OFF ON or OFF ON will display).
The display will alternately show “OFF timer” and “ON timer”, then change to
show the time setting for the operation to occur rst.
lThe program timer will begin operation. (If the ON timer has been selected
to operate rst, the unit will stop operating at this point.)
About 5 seconds later, the entire display will reappear.
About the Program Timer
lThe program timer allows you to integrate OFF timer and ON timer operations in a
single sequence. The sequence can involve 1 transition from OFF timer to ON timer,
or from ON timer to OFF timer, within a 24 hour period.
lThe first timer function to operate will be the 1 set nearest to the current time.
The order of operation is indicated by the arrow in the remote controller display
(OFF →ON or OFF ←ON).
lAn example of program timer use might be to have the air conditioner automatically
stop (OFF timer) after you go to sleep, then start (ON timer) automatically in the
morning before you arise.
Before using the timer function, be sure that the remote controller is set to the correct current time (☞P. 6).
If the indoor unit is connected to a wired remote controller, the wireless remote controller cannot be used to set the timer.
s
s s
s
TIMER OPERATION
9374379736_OM.indb 9 6/24/2013 9:24:22 AM

En-10
Unlike other timer functions, the SLEEP timer is used to set the length of time until air conditioner operate is stopped.
If the indoor unit is connected to a wired remote controller, the wireless remote controller cannot be used to set the sleep timer.
To Use the SLEEP Timer
While the air conditioner is operating or stopped, press the
SLEEP button.
The indoor unit’s OPERATION indicator lamp (green) lights and the TIMER indicator
lamp (orange) light.
To Change the Timer Settings
Press the SLEEP button once again and set the time using the
TIMER SET ( / ) buttons.
button: Press to advance the time.
button: Press to reverse the time.
About 5 seconds later, the entire display will reappear.
To Cancel the Timer
Use the TIMER MODE button to select
“CANCEL”.
The air conditioner will return to normal
operation.
To Stop the Air Conditioner During
Timer Operation
Press the START/STOP button.
About the SLEEP Timer
To prevent excessive warming or cooling during sleep, the SLEEP timer function automatically modies the thermostat setting in ac-
cordance with the set time setting. When the set time has elapsed, the air conditioner completely stops.
Set time
1 hour
1 °C 2 °C
2 °C 3 °C 4 °C
30
minutes
1 °C
1 hour
1 hour
30 minutes
Set time
During cooling/dry operation:
When the SLEEP timer is set, the thermostat setting is auto-
matically raised 1 °C every 1 hour. When the thermostat has
been raised a total of 2 °C, the thermostat setting at that time is
maintained until the set time has elapsed, at which time the air
conditioner automatically turns off.
SLEEP timer setting
During heating operation:
When the SLEEP timer is set, the thermostat setting is
automatically lowered 1 °C every 30 minutes. When the thermo-
stat has been lowered a total of 4 °C, the thermostat setting at
that time is maintained until the set time has elapsed, at which
time the air conditioner automatically turns off.
SLEEP timer setting
How To Control the Indoor Unit without Remote Controller
Press the MANUAL AUTO button more than 3 seconds and
less than 10 seconds on the indoor unit.
To stop operation, press the MANUAL AUTO button once again.
MANUAL AUTO OPERATION
Perform the MANUAL AUTO operation if you have lost the remote controller or encounter remote control malfunction.
lWhen the air conditioner is operated
with the controls on the indoor unit, it
will perform same mode as the AUTO
mode selected on the remote controller.
lThe fan speed will be set to “AUTO”
and the thermostat setting will be at the
standard value. (24 °C)
SLEEP TIMER OPERATION
9374379736_OM.indb 10 6/24/2013 9:24:22 AM

En-11
DANGER
Never place ngers or foreign objects inside
the outlet ports, since the internal fan operates
at high speed and could cause personal injury.
lAttempting to move up/down air direction
flaps or right/left air direction louvers
manually could result in improper
operation; in this case, stop operation
and restart. The louvers should begin to
operate properly again.
lDuring use of the cooling and dry modes,
do not set the up/down air direction
aps in the heating range (4to 5) for
long periods of time, since water vapor
may condense near the outlet louvers
and drops of water may drip from the air
conditioner. During the cooling and dry
modes, if the airow direction louvers
are left in the heating range for more
than 30 minutes, they will automatically
return to position 3.
lWhen used in a room with infants,
children, elderly or sick persons, the air
direction and room temperature should
be considered carefully when making
settings.
Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle).
lAdjust the up, down, left and right air directions with the SET buttons on the remote controller.
l Use the SET buttons after the indoor unit has started operating and the airow-direction louvers have stopped moving.
Vertical Air Direction Adjustment
Press the SET button (Vertical).
Each time the button is pressed, the air direction range will change as follows:
12345
Types of Airow Direction Setting:
1, 2, 3: During cooling/dry modes
1, 2, 3, 4, 5: During heating mode*
The remote controller display does
not change.
lUse the air direction adjustments within the ranges shown above.
l The vertical airow direction is set automatically as shown, in accordance with the type
of operation selected.
Horizontal ow 1: During cooling/dry mode
Downward ow 5: During heating mode*
l During AUTO mode operation, for the rst minute after beginning operation, airow will
be horizontal 1; the air direction cannot be adjusted during this period.
Horizontal Air Direction Adjustment
Press the SET button (Horizontal).
Each time the button is pressed, the air direction range will change as follows:
12345
The remote controller display does not change.
lUse the air direction adjustments within the ranges shown above.
1
2
3
4
5
12345
Right/left air direction louvers
ADJUSTING THE DIRECTION OF AIR CIRCULATION
9374379736_OM.indb 11 6/24/2013 9:24:22 AM

En-12
To select SWING Operation
Press the SWING button.
Each time the SWING button is pressed, the swing operation will change in the following
order.
To stop SWING Operation
Press the SWING button and select STOP.
Airow direction will return to the setting before swing was begun.
Begin air conditioner operation before performing this procedure.
Up/down swing operation Left/right swing operation
Swing operation stops Up/down/left/right swing operation
About SWING Operation
The type of operation
Cooling/Dry
Heating
Fan
Range of swing
1to 5(All range)
1to 5(All range)
1to 5(All range)
The SWING operation may stop temporarily when the air conditioner’s
fan is not operating, or when operating at very low speeds.
lTo select left/right swing operation
The type of operation
Cooling/Dry
Heating
Fan
Range of swing
1to 4
3to 5
1to 5
The SWING operation may stop temporarily when the air conditioner’s
fan is not operating, or when operating at very low speeds.
lTo select up/down swing operation
ECONOMY OPERATION
Begin air conditioner operation before performing this procedure.
To Use the ECONOMY Operation
Press the ECONOMY button.
The ECONOMY indicator lamp (green) will light.
ECONOMY operation begins.
To Stop the ECONOMY Operation
Press the ECONOMY button again.
The ECONOMY indicator lamp (green) will go out.
Normal operation begins.
About ECONOMY Operation
At the maximum output, ECONOMY operation is approximately 70% of normal air conditioner operation for cooling and heating.
lIf the room is not cooled (or heated) well during ECONOMY operation, select normal operation.
lDuring the monitor period in the AUTO mode, the air conditioner operation will not change to ECONOMY operation even if
ECONOMY operation is selected by pressing the ECONOMY operation button.
lWhen ECONOMY operation mode is operated, the room temperature will be little higher than the set-temp under cooling mode
and lower than set-temp under heating mode. Therefore, the ECONOMY mode is able to save more energy than other normal
mode.
SWING OPERATION
9374379736_OM.indb 12 6/24/2013 9:24:23 AM

En-13
To use 10 °C HEAT Operation
Press the 10 °C HEAT button.
The OPERATION indicator lamp (green) will go out, and the ECONOMY indicator lamp
(green) will light.
While 10 °C HEAT operation is in
progress, only the following
operation can be used.
• SWING
SELECTING THE REMOTE CONTROLLER SIGNAL CODE
When two or more air conditioners are installed in a room and the remote controller is operating an air conditioner other than the
one you wish to set, change the signal code of the remote controller to operate only the air conditioner you wish to set (4 selections
possible).
When two or more air conditioners are installed in a room, please contact your retailer to set the individual air conditioner signal
codes.
Selecting the Remote Controller Signal Code
lIf no buttons are pressed within 30 seconds after the signal code is displayed, the system returns to the original clock dis-
play. In this case, start again from step 1.
lThe air conditioner signal code is set to “A” prior to shipment. Contact your retailer to change the signal code.
lThe remote controller resets to signal code “A” when the batteries in the remote controller are replaced. If you use a signal
code other than signal code “A”, reset the signal code after replacing the batteries.
If you do not know the air conditioner signal code setting, try each of the signal codes ( ) until you nd the code
which operates the air conditioner.
Use the following steps to select the signal code of the remote controller. (Note that the
air conditioner cannot receive a signal code if the air conditioner has not been set for
the signal code.)
1 Press the START/STOP button until only the clock is
displayed on the remote controller display.
2 Press the MODE button for at least ve seconds to
display the current signal code (initially set to ).
3 Press the ( / ) buttons to change the signal code
between . Match the code on the display to
the air conditioner signal code.
4 Press the MODE button again to return to the clock
display. The signal code will be changed.
10 °C HEAT OPERATION
About the 10 °C HEAT Operation
• The heating mode will not operate if the room temperature is high enough.
• The room temperature can be maintained at 10 °C by pressing the 10 °C HEAT button so as to prevent the room temperature from
falling too far.
To stop 10 °C HEAT Operation
Press the START/STOP button.
Then the OPERATION stops and the ECONOMY indicator lamp (green) will go out.
9374379736_OM.indb 13 6/24/2013 9:24:23 AM

En-14
lBefore cleaning the air conditioner, be sure to turn it off and disconnect the power supply.
lTurn off the electrical breaker.
3. Re-attach the air filters to the intake
grille.
The air lters t onto the inside of the intake grille.
l Dust can be cleaned from the air lter either with a
vacuum cleaner, or by washing the lter in a solution of
mild detergent and warm water. If you wash the lter,
be sure to allow it to dry thoroughly in a shady place
before reinstalling.
l If dirt is allowed to accumulate on the air lter, air ow will
be reduced, lowering operating efciency and increasing
noise.
Cleaning the Air Filter
1. Pull the air filters upward to remove
them.
Remove the air lters by raising its handle while pulling it out
towards you.
2. Clean the air lters.
Remove the dust from the air lters by vacuuming or washing
them. After washing, allow the air lters to dry thoroughly in
an area protected from sunlight.
Air lter
Filter Reset (ECONOMY Indicator Lamp ashing/The special setting)
lCan be used if set correctly during installation.
Please consult authorized service personnel when using this function.
• It lights on when it is time to clean the air lters.
After turning the power on, press the MANUAL AUTO button for 2 seconds or less on the indoor unit.
CLEANING AND CARE
CAUTION
lWhen used for extended periods, the unit may accumulate dirt inside, reducing its performance. We recommend that the unit be
inspected regularly, in addition to your own cleaning and care. For more information, consult authorized service personnel.
lWhen cleaning the unit’s body, do not use water hotter than 40 °C, harsh abrasive cleansers, or volatile agents like benzene or
thinner.
lDo not expose the unit body to liquid insecticides or hairsprays.
lIf the unit will not be operated for a period of one month or more, be sure to allow the inner parts of the unit to dry thoroughly, in
advance, by operating the unit in fan mode for half a day.
9374379736_OM.indb 14 6/24/2013 9:24:23 AM

En-15
In the event of a malfunction (burning smell, etc.), immediately stop operation, disconnect the power
supply plug or turn off the circuit breaker, and consult authorized service personnel.
Merely turning off the unit’s power switch will not completely disconnect the unit from the power
source. Always be sure to disconnect the power supply plug or turn off your circuit breaker to ensure
that power is completely off.
Before requesting service, perform the following checks:
Symptom Problem See page
NORMAL
FUNCTION
Does not operate imme-
diately:
lIf the unit is stopped and then immediately started again, the
compressor will not operate for about 3 minutes, in order to
prevent fuse blowouts.
lWhenever the power supply plug is disconnected and then
reconnected to a power outlet, the protection circuit will oper-
ate for about 3 minutes, preventing unit operation during that
period.
—
Noise is heard: lDuring operation and immediately after stopping the unit, the
sound of water owing in the air conditioner’s piping may be
heard. Also, noise may be particularly noticeable for about 2
to 3 minutes after starting operation (sound of coolant ow-
ing).
lDuring operation, a slight squeaking sound may be heard.
This is the result of minute expansion and contraction of the
front cover due to temperature changes.
—
*l During heating operation, a sizzling sound may be heard oc-
casionally. This sound is produced by the automatic defrosting
operation.
16
Smells: lSome smell may be emitted from the indoor unit. This smell is
the result of room smells (furniture, tobacco, etc.) which have
been taken into the air conditioner.
—
Mist or steam are
emitted:
lDuring cooling or dry operation, a thin mist may be seen emit-
ted from the indoor unit. This results from the sudden Cooling
of room air by the air emitted from the air conditioner, result-
ing in condensation and misting.
—
*l During heating operation, the outdoor unit’s fan may stop,
and steam may be seen rising from the unit. This is due to the
automatic defrosting operation.
16
Airow is weak or stops: *l When heating operation is started, fan speed is temporarily
very low, to allow internal parts to warm up.
*l During heating operation, if the room temperature rises above
the thermostat setting, the outdoor unit will stop, and the
indoor unit will operate at very low fan speed. If you wish to
warm the room further, set the thermostat to a higher setting.
—
*l During heating operation, the unit will temporarily stop op-
eration (Max. 15 minutes) as the automatic defrosting mode
operates. During the automatic defrosting operation, the OP-
ERATION indicator lamp will ash.
16
lThe fan may operate at very low speed during dry operation
or when the unit is monitoring the room’s temperature. —
lDuring SUPER QUIET operation, the fan will operate at very
low speed. —
lIn the monitor AUTO operation, the fan will operate at very
low speed. —
Water is produced from the
outdoor unit:
*l During heating operation, water may be produced from the
outdoor unit due to the automatic defrosting operation. 16
The ECONOMY indicator
lamp ashing:
lClean the filter. Afterwards, turn the ECONOMY indicator
lamp off. 14
TROUBLESHOOTING
WARNING
Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle).
9374379736_OM.indb 15 6/24/2013 9:24:23 AM

En-16
Symptom Problem See page
CHECK ONCE
MORE
Does not operate at all: lHas the circuit breaker been turned off?
lHas there been a power failure?
lHas a fuse blown out, or a circuit breaker been tripped?
—
lIs the timer operating? 9 to 10
Poor cooling (or heating*)
performance:
l Is the air lter dirty?
lAre the air conditioner’s intake grille or outlet port blocked?
lDid you adjust the room temperature settings (thermostat)
correctly?
lIs there a window or door open?
lIn the case of cooling operation, is a window allowing bright
sunlight to enter? (Close the curtains.)
lIn the case of cooling operation, are there heating apparatus
and computers inside the room, or are there too many people
in the room?
—
lIs the unit set for QUIET operation? —
The unit operates differ-
ently from the remote con-
troller setting:
lAre the remote controller’s batteries dead?
lAre the remote controller’s batteries loaded properly? 6
If the problem persists after performing these checks, or if you notice burning smells, or the OPERATION indicator lamp and the TIMER
indicator lamp ashes, and ECONOMY indicator lamp ashes fast. Immediately stop operation, turn off the electrical breaker and consult
authorized service personnel.
TROUBLESHOOTING
OPERATING TIPS
Heating Performance*
lThis air conditioner operates on the heat-pump principle,
absorbing heat from outdoor air and transferring that heat
indoors. As a result, the operating performance is reduced
as outdoor air temperature drops. If you feel that insufcient
heating performance is being produced, we recommend you
use this air conditioner in conjunction with another kind of
heating appliance.
lHeat-pump air conditioners heat your entire room by recircu-
lating air throughout the room, with the result that some time
may be required after rst starting the air conditioner until the
room is heated.
When Indoor and Outdoor Temperature are High *
When both indoor and outdoor temperatures are high during use
of the heating mode, the outdoor unit’s fan may stop at times.
Microcomputer-controlled Automatic Defrosting *
lWhen using the heating mode under conditions of low outdoor
temperature and high humidity, frost may form on the outdoor
unit, resulting in reduced operating performance.
In order to prevent this kind of reduced performance, this unit is
equipped with a microcomputer-controlled automatic defrost-
ing function. If frost forms, the air conditioner will temporarily
stop, and the defrosting circuit will operate briey (for about
4 to 15 minutes).
During automatic defrosting operation, the OPERATION
indicator lamp (green) will ash.
lAfter heating operation stops, if frost forms on the outdoor
unit, the unit will start automatic defrosting operation. At this
time, the outdoor unit will automatically stop after operating
for a few minutes.
Low Ambient Cooling*
When the outdoor temperature drops, the outdoor unit’s fans
may switch to low speed.
Hot Start (for heating)*
The indoor unit prevents cold drafts when heating operation
begins.
The indoor unit fan will not operate or it will operate at a very low
speed until the heat exchanger reaches the set temperature.
Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle).
9374379736_OM.indb 16 6/24/2013 9:24:24 AM

En-17
OPERATING TIPS
AUTO Restart
In Event of Power Interruption
lShould the power supply to the air conditioner be
interrupted by a power failure, the air conditioner will restart
automatically in the previously selected mode once the
power is restored.
lShould a power failure occur during TIMER operation, the
timer will be reset and the unit will begin (or stop) operating
under the new timer setting. In this event, the TIMER
indicator lamp (orange) will ash.
lUse of other electrical appliances (electric shaver, etc.) or
nearby use of a wireless radio transmitter may cause the air
conditioner to malfunction. In this event, temporarily discon-
nect the power supply plug, reconnect it, and then use the
remote controller to resume operation.
Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle).
**Dual Remote Controllers (optional)
An additional remote controller can be added up to the maximum of 2 remote controllers. Either remote controller can control the air
conditioner. However, the timer functions cannot be used at the secondary unit.
**Group Control
1 remote controller can control up to 16 air conditioners. All of the air conditioners will be operated with the same settings.
The wired remote controller option is required to use the following function (**).
*lDuring use of the heating mode, the top of the indoor unit
may become warm, but this is due to the fact that cool-
ant is circulated through the indoor unit even when it is
stopped; it is not a malfunction.
*lDuring use of the heating mode, the outdoor unit will
occasionally commence the defrost operation for brief
periods. During the defrosting operation, if the user sets
the indoor unit for heating again, the defrosting mode
will continue, and the heating operation will begin after
completion of defrosting, with the result that some time
may be required before warm air is emitted.
Notices
9374379736_OM.indb 17 6/24/2013 9:24:24 AM
